Exterior Equipment (coupe) Audi A5 I

Scheme 1

1. Bolt Quantity: 7 1.3 Nm
2. Bolt Quantity: 2 1.3 Nm
3. Clip Quantity: 8
4. Rubber grommet Quantity: 8
5. Double sided adhesive tape on the door sill panel
6. Clip Quantity: 4
7. Double sided adhesive tape on the wheel housing
8. Bolt 1.3 Nm
9. Sill panel cover Removing and Installing, refer to «SIDE MEMBER TRIM PANEL»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe)

Scheme 2

1. Bolt Quantity: 3 1 Nm
2. Cover For the mirror adjusting unit mount Removing and Installing, refer to «MIRROR ADJUSTING UNIT MOUNT COVER»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe) .
3. Side Turn Signal Removing and Installing, refer to «EXTERIOR MIRROR TURN SIGNAL LAMPS -L131- / -L132-, THROUGH 05.09»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
4. Exterior rearview mirror housing Removing and Installing, refer to «EXTERIOR REARVIEW MIRROR HOUSING»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe) .
5. Lane change assist warning lights Removing and Installing, refer to «LANE CHANGE ASSISTANCE»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#interior-lights-switches-coupe) .
6. Mirror adjusting unit mount Removing and Installing, refer to «MIRROR ADJUSTING UNIT MOUNT»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe__mirror-adjusting-unit-mount) .
7. Seal
8. Bolt 10 Nm
9. Bolt 1 Nm
10. Mirror adjusting unit Removing and Installing, refer to «MIRROR ADJUSTING UNIT»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe) .
11. Bolt 1.5 Nm
12. Mirror glass Removing and Installing, refer to «MIRROR GLASS»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe__mirror-glass) .

Scheme 3

1. Bolt Quantity: 2 1 Nm
2. Cover For the mirror adjusting unit mount Removing and Installing, refer to «MIRROR ADJUSTING UNIT MOUNT COVER»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe)
3. Side Turn Signal Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe)
4. Exterior rearview mirror housing Removing and Installing, refer to «EXTERIOR REARVIEW MIRROR HOUSING»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe)
5. Lane change assistance warning lamp inside the exterior mirror Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#interior-lights-switches-coupe)
6. Mirror adjusting unit mount Removing and Installing, refer to «MIRROR ADJUSTING UNIT MOUNT»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe)
7. Seal
8. Bolt 10 Nm
9. Mirror adjusting unit Removing and Installing, refer to «MIRROR ADJUSTING UNIT»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe)
10. Bolt 1 Nm
11. Mirror glass Removing and Installing, refer to «MIRROR GLASS»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe)

Scheme 4

1. Brand emblem Cannot be removed without destroying.
2. Trim Strip For the radiator grille
3. Right mount For the parking aid sensor Removing and Installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
4. Right front center parking aid sensor -G253- Removing and Installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
5. Radiator Grille Removing and Installing, refer to «RADIATOR GRILLE»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe) .
6. Threaded clip
7. Bolt 1.5 Nm
8. Bolt 4 Nm
9. Bolt 1.5 Nm
10. Bracket For the outside air temperature sensor -G17- Removing and Installing, refer to «OUTSIDE AIR TEMPERATURE SENSOR G17 BRACKET»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe) .
11. Outside Air Temperature Sensor -G17- Removing and Installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(/audi/a5/i-2007-2011/remont/gauges-instrument-panels/#instruments-coupe) .
12. Bolt 1.5 Nm
13. Left front center parking aid sensor -G254- Removing and Installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
14. Left mount For the parking aid sensor Removing and Installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .

Scheme 5

1. Trim Strip
2. Bumper cover
3. Bolts - tightening specification see scheme 6
4. Front noise insulation bracket
5. Radiator Grille
6. Bolts - tightening specification see scheme 6
7. Reinforcement brace
8. Bolt - tightening specification see scheme 6

Scheme 6

1. Bolt Quantity: 2 0.9 Nm
2. License plate bracket Different versions Removing and Installing, refer to «LICENSE PLATE BRACKET»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe)
3. Radiator Grille Removing and Installing, refer to «RADIATOR GRILLE»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe)
4. Right mount For the parking aid sensor Removing and Installing, refer to «PARKING AID SENSOR MOUNT»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe)
5. Bolt Depending on the date of manufacture, 2 pieces or 1 piece and retaining clip 1.5 Nm
6. Bolt Quantity: 2 1.5 Nm
7. Bolt Quantity: 2 1.5 Nm
8. Reinforcement brace
9. Bolt Quantity: 6 1.5 Nm
10. Mount For garage door opener control module -J530- Removing and Installing, refer to «GARAGE DOOR OPENER CONTROL MODULE J530 MOUNT»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe)
11. Bolt Quantity: 3 4 Nm
12. Impact absorber Removing and Installing, refer to «IMPACT ABSORBER»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe)
13. Mount For the impact absorber Removing and Installing, refer to «IMPACT ABSORBER»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe)
14. Bolt Quantity: 4 1.5 Nm
15. Bolt Depending on the date of manufacture, 2 pieces or 1 piece and retaining clip 1.5 Nm
16. Left mount For the parking aid sensor Removing and Installing, refer to «PARKING AID SENSOR MOUNT»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe)

REAR SPOILER ASSEMBLY OVERVIEW RS5

Scheme 7

1. Nut Quantity: 16 2 Nm
2. Lower right water drain hose For the rear lid Removing and Installing, refer to «LOWER REAR LID TRIM PANEL»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe)
3. Upper right water drain hose Replacing Mount with drive unit Removing and Installing, refer to «UPPER WATER DRAIN HOSE FOR DRIVE UNIT»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe)
4. Mount with drive unit For the rear spoiler With rear spoiler motor -V52-, rear spoiler stop switch 1 -F135-, rear spoiler stop switch 2 -F136- Removing and Installing, refer to «MOUNT WITH REAR SPOILER DRIVE UNIT»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe)
5. Stop Quantity: 3 Self-adhesive
6. Intermediate piece For the adjusting mechanism
7. Right adjusting mechanism Replacing For balancing out differences in height
8. Spoiler Removing and Installing, refer to «REAR SPOILER»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe)
9. Left adjusting mechanism Replacing For balancing out differences in height
10. Intermediate piece For the adjusting mechanism
11. Bolt Replacing Quantity: 4 9 Nm
12. Upper left water drain hose Replacing Mount with drive unit Removing and Installing, refer to «UPPER WATER DRAIN HOSE FOR DRIVE UNIT»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe)
13. Lower left water drain hose For the rear lid Removing and Installing, refer to «LOWER REAR LID TRIM PANEL»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe)

Scheme 8

1. Wheel spoiler -- Remove the bolts in the wheel housing liner in the spoiler area. -- Press the wheel housing liner to the side in the spoiler area and loosen the locking pins. -- Remove the wheel spoiler under the wheel housing liner.
2. Clamping pin
3. Wheel housing liner
4. Bolt -- 1.5 Nm
5. Noise insulation, front
6. Threaded clip Slide onto the noise insulation.

Scheme 9

1. Mounting bracket For control modules
2. Rear spoiler control module -J223- Removing and Installing, refer to «REAR SPOILER CONTROL MODULE J223»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe)
3. Bracket

Scheme 10

1. Noise Insulation Removing Front wheel spoiler removed «FRONT WHEEL SPOILER ASSEMBLY OVERVIEW»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe) -- Remove the bolts -1- and -2- and remove the noise insulation toward the rear under the bumper. When installing, slide the front noise insulation in under the bumper.
2. Bolt 5 Nm quantity: 2
3. Quick-release fastener Rotate 180° to the left to remove. When installing, the connection must engage when rotating.
4. Washer
5. Rear noise insulation
6. Lock Carrier

Scheme 11

1. Rear noise insulation Loosen the 3 rear quick-release fasteners on the noise insulation. Loosen the quick-release fasteners -6- and remove the noise insulation toward the rear.
2. Crossbrace
3. Transmission crossmember
4. Threaded clip Slide into the transmission crossmember as shown.
5. Washer
6. Quick-release fastener Rotate 180° to the left to remove. When installing, the connection must engage when rotating.
7. Threaded clip Slide sideways into the crossbrace.

AERODYNAMIC TRIM PANELS

Front Aerodynamic Trim Panel

Scheme 12

1. Right aerodynamic trim panel
2. Nut Quantity: 7 on left 2 Nm
3. Expanding clip
4. Right front aerodynamic trim panel
5. Left front aerodynamic trim panel
6. Nut Quantity: 8 on the right 2 Nm
7. Left aerodynamic trim panel
8. Heel plate spoiler

Rear Aerodynamic Trim Panel

Scheme 13

1. Bolt 3.5 Nm
2. Right wheel spoiler
3. Nut 2 Nm
4. Clip
5. Threaded clip
6. Left wheel spoiler Slide wheel spoiler in under wheel housing liner as shown -- Loosen wheel housing liner in wheel spoiler area and move to side. -- Remove bolt -2- and nut -3- and remove wheel spoiler.
7. Rear Wheel Housing Liner

Scheme 14

1. Bolt Quantity: 3 5 Nm
2. Quick-release fastener Quantity: 4
3. Expanding clip Quantity: 3
4. Right spoiler lip Removing and Installing, refer to «SPOILER LIP»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe)
5. Metal nut Quantity: 3
6. Clip nut Quantity: 2
7. Bolt Quantity: 2 1.5 Nm
8. Right inner wheel spoiler Removing and Installing, refer to «FRONT INNER WHEEL SPOILER»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe)
9. Air guide channel for center differential Removing and Installing, refer to «AIR GUIDE CHANNEL FOR THE CENTER DIFFERENTIAL»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe)
10. Mount for air guide channel
11. Rear noise insulation for the transmission Removing and Installing, refer to «REAR NOISE INSULATION»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe)
12. Rubber disc
13. Quick-release fastener Quantity: 2
14. Expanding clip Quantity: 2
15. Noise insulation, front for the engine Removing and Installing, refer to «FRONT NOISE INSULATION»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe)
16. Clip nut Quantity: 2
17. Bolt Quantity: 2 1.5 Nm
18. Left inner wheel spoiler Removing and Installing, refer to «FRONT INNER WHEEL SPOILER»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe)
19. Metal nut Quantity: 4 For the quick release
20. Quick-release fastener Quantity: 4
21. Left spoiler lip Removing and Installing, refer to «SPOILER LIP»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe)
22. Expanding clip Quantity: 3
23. Quick-release fastener Quantity: 5
24. Rubber disc

Scheme 15

1. Front heat shield
2. Lock washer When removing, unscrew it, when installing just press the lock washer on.
3. Floor panel
4. Center heat shield

Heat Shield For Rear Floor Panel, Audi A5

Scheme 16

1. Right heat shield
2. Muffler heat shield
3. Vehicle rear
4. Lock washer When removing, unscrew it, when installing just press the lock washer on.
5. Left heat shield

Heat Shield For Rear Floor Panel, Audi RS5

Scheme 17

1. Nut 2.1 Nm
2. Heat shield For the center of the exhaust system
3. Right interior heat shield For the rear muffler
4. Nut Quantity: 4 2.1 Nm
5. Nut Quantity: 3 2.1 Nm
6. Bolt Quantity: 2 2 Nm
7. Right exterior heat shield For the rear muffler
8. Left interior heat shield For the rear muffler
9. Left exterior heat shield For the rear muffler
10. Bolt Quantity: 2 2 Nm
11. Nut Quantity: 3 2.1 Nm
12. Nut Quantity: 4 2.1 Nm

Tunnel Crossmember

Scheme 18

1. Bolt 55 Nm
2. Front tunnel crossmember
3. Rear tunnel crossmember With integrated spoiler.
4. Screws 55 Nm

Scheme 19

1. Front Wheel Housing Liner Removing and Installing, refer to «FRONT WHEEL HOUSING LINER»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe)
2. Bolt 1.5 Nm
3. Bracket For the wheel housing liner to the fender
4. Clip Quantity: 7
5. Mount Left expanding clip Right wing nut
6. Driveshaft cover
7. Nut Quantity: 2 2 Nm
8. Bolt 2.5 Nm
9. Bolt Quantity: 5 1.5 Nm

Scheme 20

1. A - Left upper rear side panel to the rear spoiler Gap dimension = 2.0 +/- 0.5 mm
2. B - Rear lid to rear spoiler Gap dimension = 2.0 +/- 0.5 mm
3. C - Rear lid to rear spoiler Gap dimension = 2.0 +/- 0.5 mm

LETTERING DIMENSIONS

Scheme 21

Press the lettering firmly onto the body according to the dimensions.

1. Dimension -a- = 26 mm
2. Dimension -b- = 86 mm
3. Dimension -c- = 458 mm
4. Dimension -d- = 4 mm

Lettering for S5 rear lid

Scheme 22

1. Dimension -a- = 26 mm
2. Dimension -b- = 90 mm
3. Dimension -c- = 458 mm

Name plate for S5 fender

Scheme 23

Dimension -a- = 81 mm

Dimension -b- = 103 mm

ROOF TRIM MOLDING

Note. To remove roof trim molding, it is not necessary to remove the side window.

Scheme 24

1. Roof trim molding NOTE: Roof trim molding must not be twisted or bent. -- Remove the door seal from the body flange in the >>A-pillar<< and roof trim molding area. -- Drill off rivet heads of pop rivets, strike rivet shafts through and remove roof trim molding. -- Carefully pry the roof trim molding out of clips over the side window and remove it.
2. Side Window
3. Trim Strip -- To remove the B-pillar, pry it out of the clips on the roof beginning at the side. -- Pry out the side trim strip on the side panel out of the clips. -- Slide the trim molding down out of the roof trim molding.
4. Pop rivet Quantity: 9 on the roof trim molding.

OUTER SILL PANEL STRIP

Note. The sill panel strip is secured to the side member using adhesive strips. It is not possible to remove without destroying.

Scheme 25

1. Door seal
2. Sill panel strip Removing -- Heat the sill panel strip using a hot air gun and pull the molding upward and off. Installing: -- The side member must be free of dirt and grease in the adhesive area. -- Heat the adhesive surface to approximately 40 °C with a hot air blower. -- Remove protective film from adhesive tape. -- Insert the sill panel strip with the centering pins in the side member and press it on firmly in stages from front to back.
3. Adhesive tape Pull off protective foil before installing.

STONE CHIP PROTECTIVE MOLDING

Note. The stone chip protective molding is also secured to the side member using adhesive strips. It is not possible to remove without destroying. The clips are destroyed when removing the stone chip protective molding and must be replaced.

Scheme 26

1. Stone Chip Protective Molding Removing -- Warm the adhesive areas using a hot air gun and remove the stone chip protective molding from the side member in stages. NOTE: The clips are removed from the retaining pins when the stone chip protective molding is pulled off and they must be replaced. Installing: NOTE: The side member must be free of dirt and grease in the area with the adhesive strips. -- Bend the removal tabs on the protective film up so they can be reached when the stone chip protective molding is installed on the side member. -- Slide the stone chip protective molding onto the clips as far as the stop working from back to front. -- Note the order for removing the removal tab. -- Press the stone chip protective molding onto the side member in stages.
2. Clip Quantity: 9 The installation direction for the clip is stamped on. Slide the clips onto the pins according to the installation direction and engage them. Align the clips lengthwise to the side member.
3. Bolts

Removal tab for removing sequence

Scheme 27

Remove the removal tab in the sequence -1-, -2-, -3- and -4-.

Press the stone chip protective molding onto the side member in stages.

ROOF TRIM STRIP

Removal and installation is identical to the A5. Refer to ROOF TRIM MOLDING .

SILL PANEL STRIP

Removal and installation is identical to the A5. Refer to OUTER SILL PANEL STRIP .

Scheme 28

Remove side trim. Refer to Removal and Installation .

Remove the noise insulation -1-.

Loosen the clips -2- in order to carefully press the retaining clips together -arrows-.

Carefully loosen bonding -1- and -2- on the side panel.

Scheme 29

Remove front wheel housing liner FRONT WHEEL HOUSING LINER .

Scheme 30

Remove the bolt -2- and both washers.

Remove the bolts -1- and -3-.

Remove the bolts -2-.

Scheme 31

Open the door.

With a second technician, slide -arrows- the sill panel trim -1- forward and remove it.

1. Unclip the clips for the sill panel trim.

INSTALLING

1. Tightening specifications, refer to «SIDE MEMBER TRIM PANEL ASSEMBLY OVERVIEW - AUDI RS 5»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe) .

Install in reverse order of removal. Note the following

Note. Remove and install damaged clips and rubber grommet.

Make sure to position the clips -2- for the sill panel trim -1- correctly in all of the mounts -arrow- when installing.

Scheme 32

Do not forget the washers when tightening the side trim panel.

MIRROR GLASS

Special tools and workshop equipment required

Scheme 33

1. Pry lever 80 - 200
2. Protective gloves

Scheme 34

Press the mirror glass -1- from the mirror adjusting unit using the pry lever 80 - 200 -arrow-.

Disconnect the heated mirror electrical connectors -2- and -3- on the rear side of the mirror glass -1-.

Scheme 35

Unclip the electrical connector -5- from the bracket, if applicable.

Disconnect the connector -4-.

Install in reverse order of removal. Note the following

Position the mirror glass on the mirror adjusting unit and press it on.

Note. Only press in the center of the mirror when pressing the mirror glass on.

REMOVING

Remove the mirror glass. Refer to MIRROR GLASS .

Note. Cover the area around the mirror housing with a soft cloth to protect the paint.

Remove the bolts -4- and -5-.

Scheme 36

Release the retaining tabs -3- in the -direction of arrow A-.

Release the clip -1- and remove the exterior rearview mirror housing from the cover -2- -B arrows-.

Press the mirror adjusting unit down and remove the exterior rearview mirror housing upward.

Disconnect the connector for the turn signal.

Remove the side turn signal from the exterior mirror housing. Refer to [For engine(s) CAUA, CAEB, CALA] Removal and Installation .

1. Tightening specifications, refer to «EXTERIOR REARVIEW MIRROR ASSEMBLY OVERVIEW - VEHICLES THROUGH MAY 2009»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe) .

Install in reverse order of removal.

Scheme 37

Remove the exterior rearview mirror housing. Refer to EXTERIOR REARVIEW MIRROR HOUSING .

Remove the bolts -arrows-.

Disengage the retaining tab -2- and remove the cover -1- on the mirror adjusting unit mount.

1. Tightening specifications, refer to «EXTERIOR REARVIEW MIRROR ASSEMBLY OVERVIEW - VEHICLES THROUGH MAY 2009»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe) .

Install in reverse order of removal. Note the following

Install the exterior rearview mirror housing. Refer to EXTERIOR REARVIEW MIRROR HOUSING .

Remove the door trim panel. Refer to Removal and Installation .

Remove the speaker trim and the treble speaker bracket. Refer to Removal and Installation .

Disconnect the electrical connector by pulling the retainer -3- back -arrow A- and pressing the release -4- down.

Scheme 38

Pry the grommet -2- out of the exterior mirror seal.

Remove the retainers from the door shell in the exterior mirror area.

Remove the exterior mirror seal -1- off of the door shell while removing the bolts -arrows-.

Remove the mirror adjusting unit mount while guiding the wiring harness out through the body opening.

1. Tightening specifications, refer to «EXTERIOR REARVIEW MIRROR ASSEMBLY OVERVIEW - VEHICLES THROUGH MAY 2009»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe) .

Install in reverse order of removal. Note the following

Install the exterior mirror housing. Refer to DOOR SEALS => Installing .

Install the treble speaker bracket and speaker trim. Refer to Removal and Installation .

Install the door trim panel. Refer to Removal and Installation .

Scheme 39

Remove the mirror glass. Refer to MIRROR GLASS .

Remove the screw -1- from the mirror adjusting unit -2-.

Release the retaining tabs -arrows- and remove the mirror adjusting unit.

Disconnect the electrical connector -1- on the mirror adjusting unit -2-.

Scheme 40

1. Tightening specifications, refer to «EXTERIOR REARVIEW MIRROR ASSEMBLY OVERVIEW - VEHICLES THROUGH MAY 2009»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe) .

Install in reverse order of removal. Note the following

Press the mirror adjusting unit onto the mirror mount until it engages audibly.

Special tools and workshop equipment required

1. Pry lever 80 - 200
2. Protective gloves

Note. Cover the area around the mirror housing with a soft cloth to protect the paint.

Press the mirror glass -1- from the mirror adjusting unit using the pry lever 80 - 200 -arrow-.

Scheme 41

Disconnect the heated mirror electrical connectors -2- and -3- on the rear side of the mirror glass -1-.

Unclip the electrical connector -5- from the bracket, if applicable.

Disconnect the connector -4-.

Install in reverse order of removal. Note the following

Position the mirror glass on the mirror adjusting unit and press it on.

Note. Only press the center of the mirror glass when pressing it on.

Scheme 42

Remove the mirror adjuster. Refer to MIRROR ADJUSTING UNIT .

Note. Cover the area around the mirror housing with a soft cloth to protect the paint.

Remove the bolts -4- and -5-.

Open the clip -2- and remove the exterior mirror housing -3- from the cover -1- -arrows-.

On vehicles with lane change assist, remove the exterior mirror housing -1- just enough until the connector is visible.

Scheme 43

Disconnect the lane change assistance warning lamp connector -2- on the front side of the mirror adjustment unit bracket -3-.

Remove the exterior mirror housing -2- and disconnect the connector -3-.

Scheme 44

Remove the bolts -1- and -4-.

Remove the turn signal bulb housing -5- from the exterior mirror housing -arrow-.

1. Tightening specifications, refer to «EXTERIOR REARVIEW MIRROR ASSEMBLY OVERVIEW - VEHICLES FROM JUNE 2009»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe) .

Install in reverse order of removal. Note the following

Install the exterior mirror turn signal inside the exterior mirror. Refer to [For engine(s) CAUA, CAEB, CALA] Removal and Installation .

Scheme 45

Remove the exterior rearview mirror housing. Refer to EXTERIOR REARVIEW MIRROR HOUSING .

Remove the bolts -2- and -3-.

Disengage the tabs and hooks -arrows A-.

Push the cover -1- down enough so that the tabs disengage and then release the hooks -4- -arrow B-.

Remove the cover on the mirror adjustment unit bracket.

1. Tightening specifications, refer to «EXTERIOR REARVIEW MIRROR ASSEMBLY OVERVIEW - VEHICLES FROM JUNE 2009»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe) .

Install in reverse order of removal. Note the following

Install the exterior rearview mirror housing. Refer to EXTERIOR REARVIEW MIRROR HOUSING .

MIRROR ADJUSTING UNIT MOUNT

Special tools and workshop equipment required

Scheme 46

1. Trim removal wedge 3409

Remove the door trim panel. Refer to Interior Trim .

Remove the speaker trim and the treble speaker bracket. Refer to Interior Trim .

Disconnect the electrical connector by pulling the retainer -3- back -arrow A- and pressing the release -4- down.

Pry the grommet -2- out of the exterior mirror seal.

Remove the retainers from the door shell in the exterior mirror area.

Remove the exterior mirror seal -1- off of the door shell while removing the bolts -arrows-.

Remove the mirror adjusting unit mount while guiding the wiring harness out through the door opening.

1. Tightening specifications, refer to «EXTERIOR REARVIEW MIRROR ASSEMBLY OVERVIEW - VEHICLES FROM JUNE 2009»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe) .

Install in reverse order of removal. Note the following

Install the exterior mirror housing. Refer to DOOR SEALS => Installing .

Install the treble speaker bracket and speaker trim. Refer to Interior Trim .

Install the door trim panel. Refer to Interior Trim .

Remove the mirror glass. Refer to MIRROR GLASS .

Remove the screw -1- for the mirror adjusting unit -2-.

Release the retaining tabs -arrows- and remove the mirror adjusting unit.

Disconnect the electrical connector -1- on the mirror adjusting unit -2-.

1. Tightening specifications, refer to «EXTERIOR REARVIEW MIRROR ASSEMBLY OVERVIEW - VEHICLES FROM JUNE 2009»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe) .

Install in reverse order of removal. Note the following

Press the mirror adjusting unit onto the mirror mount until it engages audibly.

Scheme 47

Proceed as follows

Remove the bumper cover. Refer to BUMPER COVER .

Remove the impact absorber. Refer to IMPACT ABSORBER .

Remove the bolts -3-.

Free up the parking aid sensor electrical wiring harness on the radiator grille, if applicable, by disconnecting the cable ties -1-.

Remove the electrical connector -2- from the bracket.

To do this, press the release in the -direction of arrow A- and remove the electrical connector -1- from the bracket -2- in the -direction of arrow B-.

Scheme 48

Audi S5

Scheme 49

Remove the bolts -arrows-.

Remove the reinforcing bars -1 through 3-.

All

Disconnect the electrical connectors -5- and -6- on the parking aid sensors.

Remove the bolts -arrows- and the radiator grille -4- from the bumper cover.

If necessary, removing the parking aid sensor mount by releasing the clips and removing the mount.

1. Tightening specifications. Refer to «RADIATOR GRILLE ASSEMBLY OVERVIEW»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe) and see scheme 6.

Install in reverse order of removal. Note the following

Install the impact absorber. Refer to IMPACT ABSORBER .

Install the bumper cover. Refer to BUMPER COVER .

Scheme 50

Proceed as follows

Remove the outside air temperature sensor -G17-. Refer to [For engine(s) CAUA, CAEB, CALA] Removal and Installation .

Release the clips -arrows- and remove the bracket -1- from the radiator grille -2-.

Install in reverse order of removal. Note the following

Position the bracket on the radiator grille and press it on until it engages audibly.

Install the outside air temperature sensor -G17-. Refer to [For engine(s) CAUA, CAEB, CALA] Removal and Installation .

Scheme 51

Remove the license plate.

Remove the bolts -2- and -3-.

Detach license plate bracket -1- upward out of the honeycomb-structured grille -arrow- while detaching clips -4-.

Remove the license plate bracket.

1. Tightening specifications, refer to «RADIATOR GRILLE ASSEMBLY OVERVIEW - AUDI RS 5»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe) .

Install in reverse order of removal. Note the following

The license plate bracket must be fully inserted into the honeycomb-structured grille.

Scheme 52

Remove the lock carrier cover.

Release the clamps -arrow- and garage door opener control module -J530- -5- from the mount -2-.

Disconnect the connector -6-.

Remove bolts -1, 3, 4- and mounts.

1. Tightening specifications, refer to «RADIATOR GRILLE ASSEMBLY OVERVIEW - AUDI RS 5»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe) .

Install in reverse order of removal. Note the following

Install the lock carrier cover.

Scheme 53

Remove the bumper cover.

Remove the impact absorber. Refer to IMPACT ABSORBER .

If equipped, disconnect the connectors -1- and -4-.

Free up the wiring harness -2- for parking aid sensor on the radiator grille in order to remove the cable tie.

Remove the electrical connector -3- from the bracket.

To do this,, press the release in the -direction of arrow A- and remove the electrical connector -1- from the bracket -2- in the -direction of arrow B-.

Remove the bolts -2-.

Scheme 54

Remove the bolts -arrows-.

Remove mounts -1- and -4- for parking aid sensor.

Remove radiator grille -3- towards the rear from the bumper cover.

1. Tightening specifications, refer to «RADIATOR GRILLE ASSEMBLY OVERVIEW - AUDI RS 5»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe) .

Install in reverse order of removal. Note the following

Install the impact absorber. Refer to IMPACT ABSORBER .

Install the bumper cover.

Scheme 55

Remove the bumper cover.

Disconnect the front parking aid sensor electrical wiring harness -1- -arrow- if applicable.

Guide the impact absorber -2- out of the brackets -A- and remove it.

Install in reverse order of removal. Note the following

Install the front bumper cover.

Scheme 56

Remove the license plate bracket. Refer to LICENSE PLATE BRACKET .

Remove the impact absorber. Refer to IMPACT ABSORBER .

Remove the bolts -arrows- and the mount -1-.

1. Tightening specifications, refer to «RADIATOR GRILLE ASSEMBLY OVERVIEW - AUDI RS 5»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe) .

Install in reverse order of removal. Note the following

Install the impact absorber. Refer to IMPACT ABSORBER .

Install the license plate bracket. Refer to LICENSE PLATE BRACKET .

Scheme 57

Remove mount for the impact absorber. Refer to IMPACT ABSORBER .

Remove the bolts -arrows- and the mount -1-.

Note. Depending on the date of manufacture, attach the parking aid sensor mount with a retaining clip instead of the second bolt.

1. Tightening specifications, refer to «RADIATOR GRILLE ASSEMBLY OVERVIEW - AUDI RS 5»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe) .

Install in reverse order of removal. Note the following

Install the mount for the impact absorber. Refer to IMPACT ABSORBER .

Scheme 58

Extend the rear spoiler. Refer to the Owner's Manual.

Remove the bolts -arrows-.

Remove the rear spoiler -2- from the drive unit -1-.

1. Gap dimensions «REAR SPOILER GAP DIMENSIONS»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe) .
2. Tightening specifications, refer to «REAR SPOILER ASSEMBLY OVERVIEW RS5»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe__rear-spoiler-assembly-overview-rs5) .

Install in reverse order of removal. Note the following

Note. Replace adjusting mechanism.

Clip the adjusting mechanisms -3- and -4- into the rear spoiler -2-.

Remove the peel-off backing, align the intermediate piece -1- with the adjusting mechanisms and tape it to the rear spoiler.

Retract the rear spoiler. Refer to the Owner's Manual.

Remove the upper water drain hose -1- for drive unit. Refer to UPPER WATER DRAIN HOSE FOR DRIVE UNIT .

Scheme 59

Install and align the rear spoiler in the drive unit. Refer to REAR SPOILER GAP DIMENSIONS .

Push the rear spoiler and hold it with a second technician in alignment with the body contour.

Open the rear lid and tighten the bolts -2- and -3- through the opening for the water drain hose.

Install the upper water drain hose for the drive unit. Refer to UPPER WATER DRAIN HOSE FOR DRIVE UNIT .

Scheme 60

Remove the rear lid trim. Refer to Removal and Installation .

Release the clip -2-.

Remove the water drain hose -3- from the lower water drain hose and then from the mount -4-.

Remove the mount -1- for the upper water drain hose from the rear lid.

1. The tabs -arrows- are shown in the illustration.
2. The upper water drain hose cannot be removed without being damaged.

Install in reverse order of removal. Note the following

Note. Replace the mount and the upper water drain hose.

Install the trim for the rear lid. Refer to Removal and Installation .

Scheme 61

Remove the rear lid trim. Refer to Removal and Installation .

Release the clip -2-.

Remove the water drain hose -3- from the lower water drain hose and then from the mount -4-.

Remove the lower water drain hose -1- from the rear lid -arrow-.

Remove lower water drain hose.

Install in reverse order of removal. Note the following

Install the trim for the rear lid. Refer to Removal and Installation .

Scheme 62

Remove the rear lid trim. Refer to Removal and Installation .

Release the clip -2-.

Remove the water drain hose -3- from the lower water drain hose and then from the mount -1-.

Disconnect the connector -4-.

Remove the nuts -arrows-.

Scheme 63

Remove the mount with the rear lid drive.

1. Gap dimensions «REAR SPOILER GAP DIMENSIONS»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe) .
2. Tightening specifications, refer to «REAR SPOILER ASSEMBLY OVERVIEW RS5»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe__rear-spoiler-assembly-overview-rs5) .

Install in reverse order of removal. Note the following

Install the trim for the rear lid. Refer to Removal and Installation .

Scheme 64

Open the right luggage compartment side trim panel.

Disconnect the connector -3-.

Release the clamp -arrow- and remove the bracket -2-.

Remove the rear spoiler control module -J223- -4- from the frame -1-.

Install in reverse order of removal.

Scheme 65

Remove the bolts -arrows-.

Remove the quick release -1-.

Scheme 66

Remove front wheel spoiler -2-.

1. Tightening specifications, refer to «SPOILER»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe) .

Install in reverse order of removal.

Scheme 67

Remove the expanding pin -3- with the expanding clip -2-.

Remove the spoiler lip -1-.

Install in reverse order of removal.

FRONT WHEEL HOUSING LINER ASSEMBLY OVERVIEW

Note. The front wheel housing liner is made of two pieces and can be removed separately.

Scheme 68

1. Front part of wheel housing liner Removing Driveshaft cover, removing. Press in front wheel accordingly. Remove the bolts on the lower wheel housing liner. Loosen the retainer on the clips, for example, using a small screwdriver, and slide the clip sideways off the retaining pins. -- Disengage wheel housing liner from fender and pull downward and out. Installing: in reverse order
2. Bolt 1.5 Nm
3. Clip Quantity: 7
4. Wheel housing liner

Driveshaft cover

Scheme 69

1. Front part of wheel housing liner
2. Longitudinal member
3. Driveshaft cover
4. Rear part of wheel housing liner
5. Nut 2 Nm

Scheme 70

1. Rear Wheel Housing Liner Removing -- Rear wheel removed. -- Remove the outer bolts. -- Remove the clips from the retaining pins. -- Remove wheel housing liner downward. Installing: in reverse order
2. Screws 1.5 Nm
3. Clip Quantity: 7 Loosen the retainer on the clips, for example, using a small screwdriver, and slide the clip sideways off the retaining pins.

Scheme 71

Remove the nuts.

Remove the driveshaft cover -1-.

Remove the wing nut -2- on the left side of the vehicle and remove the expanding clip on the right side of the vehicle.

Remove the bolts -1-.

Scheme 72

Remove the bolt -3- and remove the mount on the fender.

Remove the clip -1- from the wheel housing liner -4-.

To remove the clips -3-, unlock the release lever -2- with needle nose pliers in -direction of arrow A- and push it off the pin -1- in -direction of arrow B-.

Scheme 73

Remove the wheel housing liner.

1. Tightening specifications, refer to «FRONT WHEEL HOUSING LINERS ASSEMBLY OVERVIEW - AUDI RS 5»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe) .

Install in reverse order of removal.

REAR WHEEL HOUSING LINER

Removal and installation is identical to the A5. Refer to REAR WHEEL HOUSING LINER ASSEMBLY OVERVIEW .

Remove the bolts -arrows-.

Remove the bolts -arrows- for the front wheel housing liner connection -1- and the front wheel spoiler.

Scheme 74

Remove the quick release -arrows-.

Scheme 75

Remove the front noise insulation -1- toward the rear and out of the lower section of the bumper cover.

1. The guide tabs for the front noise insulation will disengage while doing this.

Remove the front noise insulation.

1. Tightening specifications, refer to «UNDERBODY TRIM PANEL AUDI RS 5»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe) .

Install in reverse order of removal.

Scheme 76

Remove the screw -4-.

Remove the expanding pin -1- with the expanding clip.

Remove the quick release -3- from the front noise insulation.

Remove the quick release -5-.

Remove the rear noise insulation -2-.

1. Tightening specifications, refer to «UNDERBODY TRIM PANEL AUDI RS 5»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe) .

Install in reverse order of removal.

Scheme 77

Remove the front noise insulation. Refer to FRONT NOISE INSULATION .

Remove the air guide channel forward -1- from the mount -arrow-.

Install in reverse order of removal. Note the following

Install the front noise insulation. Refer to FRONT NOISE INSULATION .

SPECIAL TOOLS

Special tools and workshop equipment required

1. Pry Lever - Rmv Outside Mirror 80 - 200
2. Trim Removal Wedge 3409

See also:
• EXTERIOR MIRROR TURN SIGNAL LAMPS -L131- / -L132-, THROUGH 05.09
• LANE CHANGE ASSISTANCE
• [For engine(s) CAUA, CAEB, CALA] Removal and Installation
• Removal and Installation
• DOOR SEALS => Installing
• BUMPER COVER
• SIDE MEMBER TRIM PANEL
• MIRROR ADJUSTING UNIT MOUNT
• MIRROR GLASS
• ROOF TRIM MOLDING
• OUTER SILL PANEL STRIP
• REAR SPOILER ASSEMBLY OVERVIEW RS5
