Hydraulic Components - Brake System (coupe) Audi A5 I

BRAKE SYSTEM, BLEEDING

Note. Only use new brake fluid conforming to US-Norm FMVSS 116 DOT 4. Genuine VW/Audi brake fluid conforms to this specification. Do not use any silicone-based fluid. Avoid contaminating brake fluid with particles or lint (for example from cleaning cloths). Rinse off spills, by using plenty of water. Do not work with compressed air and do not move vehicle while the system is open. During the final road test, ensure that a ABS-controlled brake test is performed at least once (pulsation must be felt at the brake pedal). The brake system indicator light blinks when the brake fluid is too low or the ABS system or parking brake is malfunctioning.

BLEEDING, WITH ELECTRONIC STABILITY PROGRAM

Special tools and workshop equipment required

1. VAS 5234 Brake Charger/Bleeder Unit
2. VAS 5234/1 Adapter

Note. There must be a positive pressure of 2 bar to bleed the hydraulic unit N55. Pressure setting must be checked at bleeder device. Only place brake pedal load device on brake system during assembly, then bleed.

Note. Bleed the brake system with the brake charger/bleeder unit VAS 5234 with the adapter VAS 5234/1.

Follow the VAS 5234 operating instructions.

Remove the plenum chamber cover, refer to Removal and Installation .

Raise the vehicle.

Connect the VAS 5234 with VAS 5234/1.

Open the bleeder screws in the specified sequence and bleed (support with pedal pressure if necessary).

Bleeding Sequence

1 - Left front brake caliper

2 - Right front brake caliper

3 - Left rear brake caliper

4 - Right rear brake caliper.

Bleed until brake fluid comes out with no bubbles and foam.

Close the bleeder screws.

Lower the vehicle.

Install plenum chamber cover, refer to Removal and Installation .

BRAKE FLUID, CHANGING

Brake Fluid, Changing

Refer to 405 Work descriptions; changing brake fluid (every 2 years).

BRAKE CALIPER, SERVICING, 1LT

Note. Install complete repair kit when servicing. New brake calipers are filled with brake fluid and are pre-bled. Apply thin coat of assembly paste G 052 150 A2 to brake cylinders, pistons and seals.

Scheme 52

1. Caps Remove the guide pins to remove. Insert the guide pins after installation.
2. Guide Pins 30 Nm Replacing, refer to «BEARING BUSHING AND GUIDE PIN FN-3 BRAKE, 1LT»(/audi/a5/i-2007-2011/remont/mechanical-hydraulic/#hydraulic-components-brake-system-coupe__bearing-bushing-and-guide-pin-fn-3) .
3. Bleeder Valve Apply a thin coat of assembly paste G 052 150 A2 to the threads before installing. 10 Nm
4. Cap Push onto bleeder valve.
5. Brake Caliper Housing
6. Spring Insert with both ends in holes of brake caliper housing. NOTE: Retaining spring must be pressed under brake carrier after it is inserted in both holes. If improperly installed, the wear of the outer brake pad cannot be adjusted, thereby increasing brake pedal travel.
7. Bearing Bushing Insert in brake caliper housing. Replacing, refer to «BEARING BUSHING AND GUIDE PIN FN-3 BRAKE, 1LT»(/audi/a5/i-2007-2011/remont/mechanical-hydraulic/#hydraulic-components-brake-system-coupe__bearing-bushing-and-guide-pin-fn-3) .
8. Brake Carrier Bolt to brake caliper housing.
9. Seal
10. Pistons First apply thin coat of brake cylinder paste G 052 150 A2 on piston. Diameter 57 mm.
11. Cap Do not damage the piston when inserting it.

BRAKE CALIPER, SERVICING, 1LA/1LJ

Note. Install complete repair kit when servicing. Apply thin coat of assembly paste G 052 150 A2 to brake cylinders, pistons and seals.

Scheme 53

1. Bolt 30 Nm
2. Cap Insert in brake caliper. Replacing, refer to «PROTECTIVE CAP AND GUIDE PIN, 1LA/1LJ»(/audi/a5/i-2007-2011/remont/mechanical-hydraulic/#hydraulic-components-brake-system-coupe__protective-cap-and-guide-pin-1la1lj) .
3. Guide Pins Slide through the boot. Replacing, refer to «PROTECTIVE CAP AND GUIDE PIN, 1LA/1LJ»(/audi/a5/i-2007-2011/remont/mechanical-hydraulic/#hydraulic-components-brake-system-coupe__protective-cap-and-guide-pin-1la1lj) .
4. Cap Install on the bleeder valve.
5. Bleeder Valve Apply a thin coat of assembly paste G 052 150 A2 to the threads before installing. 15 Nm
6. Brake Caliper Housing
7. Spring Ensure installation position is correct.
8. Cap Do not damage when installing piston. Coat with Assembly Paste G 052 150 A2.
9. Pistons First apply thin coat of brake cylinder paste G 052 150 A2 on piston. Diameter 57 mm.
10. Seal Coat with assembly paste G 052 150 A2.
11. Brake Carrier Removing and Installing, refer to «FRONT BRAKE CALIPER WITH BRAKE CARRIER»(/audi/a5/i-2007-2011/remont/mechanical-hydraulic/#mechanical-components-brake-system-coupe) . The 4 retaining pins for the brake pads on the brake carrier must not be loosened under any circumstances.
12. Bolt 196 Nm

Scheme 54

1. 1 - Brake Caliper Bolts NOTE: These bolts are not loosened to remove the brake caliper and replace the brake pads.
2. 4 - Brake Caliper When doing work, do not allow to hang from brake hose, rather suspend it from the body using bundling wire. Through "Brake Pads, Removing and Installing", "Brake Caliper, Removing and Installing" and "Brake Piston, Removing and installing" ; do not perform any repairs to the brake caliper. Install hose so it is not twisted. Brake allocation.
3. 10 - Ribbed Bolt Torque specification: 196 Nm If using again, clean the ribs.
4. 11 - Brake Carrier Attach to wheel bearing housing.
5. 12 - Brake Piston WARNING: The brake pistons have different diameters. When re-installing, ensure the respective brake piston is inserted in the correct bore in the brake caliper. The ceramic inserts on the brake pistons serve as heat insulators and must not be removed from the pistons. If the ceramic inserts are damaged, the brake pistons must be replaced for safety reasons.
6. 14 - Brake Line Connection to Brake Line Torque specification: 14 Nm Brake hose must not be twisted.
7. 15 - Brake Line Install in the brake caliper housing. Counterhold by the hexagon on the brake hose and attach to the brake hose. Hose must be installed free of twists. Make sure that lugs are properly seated in grooves in bracket.
8. 16 - Bracket for Brake Line Bolt to brake caliper housing. Hook in brake line.
9. 17 - Brake line in Brake Caliper 16 Nm

ELECTRONIC PARKING BRAKE REAR CALIPER, SERVICING

Note. When servicing, install entire repair kit. Apply thin coat of assembly paste G 052 150 A2 to brake cylinders, pistons and seals.

Scheme 55

1. Self-Locking Bolt 35 Nm Always replace. Counterhold at the guide pin when loosening and tightening.
2. Brake Caliper Housing with Actuator
3. Bleeder Valve 10 Nm
4. Dust Cap Push onto bleed valve.
5. Seal Removing and Installing, refer to «REAR BRAKE CALIPER PISTON»(/audi/a5/i-2007-2011/remont/mechanical-hydraulic/#hydraulic-components-brake-system-coupe__rear-brake-caliper-piston) .
6. Pressure Nut To operate parking brake.
7. Pistons Removing and Installing, refer to «REAR BRAKE CALIPER PISTON»(/audi/a5/i-2007-2011/remont/mechanical-hydraulic/#hydraulic-components-brake-system-coupe__rear-brake-caliper-piston) .
8. Guide Pins Grease before pulling on protective cap. Delivered as a replacement part with sufficient grease. Replacing, refer to «REAR BRAKES GUIDE PINS AND PROTECTIVE CAPS, REPLACING»(/audi/a5/i-2007-2011/remont/mechanical-hydraulic/#hydraulic-components-brake-system-coupe__rear-brakes-guide-pins-and-protective) .
9. Cap Pull onto the brake carrier and guide pin. Replacing, refer to «REAR BRAKES GUIDE PINS AND PROTECTIVE CAPS, REPLACING»(/audi/a5/i-2007-2011/remont/mechanical-hydraulic/#hydraulic-components-brake-system-coupe__rear-brakes-guide-pins-and-protective) .
10. Brake Carrier with Guide Pins and Cap Supplied as an assembled replacement part with sufficient grease on guide pins. If protective caps or guide pins are damaged, install repair kit. Use grease packet supplied to lubricate guide pins.
11. Cap Removing and Installing, refer to «REAR BRAKE CALIPER PISTON»(/audi/a5/i-2007-2011/remont/mechanical-hydraulic/#hydraulic-components-brake-system-coupe__rear-brake-caliper-piston) . Pull onto the piston with the outer sealing lip.

BRAKE BOOSTER/MASTER BRAKE CYLINDER OVERVIEW

Note. Master brake cylinders can no longer be disassembled, servicing is not possible. Use only new brake fluid. Observe information on brake fluid reservoir!

Scheme 56

1. Brake Fluid Reservoir Do not remove the screen in the brake fluid reservoir. Removing and Installing, refer to «BRAKE FLUID RESERVOIR»(/audi/a5/i-2007-2011/remont/mechanical-hydraulic/#hydraulic-components-brake-system-coupe).
2. Brake Fluid Reservoir Cover Not installed in all vehicles. Removing and Installing, refer to «BRAKE FLUID RESERVOIR COVER»(/audi/a5/i-2007-2011/remont/mechanical-hydraulic/#hydraulic-components-brake-system-coupe__brake-fluid-reservoir-cover).
3. Sealing Cap with Seal and Brake Fluid Lever Warning Switch -F34
4. Bolt 5 Nm
5. Wiring to the Clutch Master Cylinder
6. Brake Booster Adjusting ball head (Scheme 57) Functional check: With engine switched off, depress brake pedal firmly several times (to deplete vacuum in tool). Depress and hold brake pedal with average foot pressure and start engine. If brake booster is working properly, pedal will be felt to give noticeably under foot (booster assistance becomes effective). With adhesive seal. If malfunctioning: replace as complete unit. Removing and Installing, refer to «BRAKE BOOSTER»(/audi/a5/i-2007-2011/remont/mechanical-hydraulic/#hydraulic-components-brake-system-coupe).
7. Pedal Support Bolt 20 Nm
8. Brake Pedal Removing and Installing, Manual Transmission, refer to «BRAKE PEDAL, MANUAL TRANSMISSION»(/audi/a5/i-2007-2011/remont/mechanical-hydraulic/#mechanical-components-brake-system-coupe). Removing and Installing, Automatic Transmission, refer to «BRAKE PEDAL, AUTOMATIC TRANSMISSION»(/audi/a5/i-2007-2011/remont/mechanical-hydraulic/#mechanical-components-brake-system-coupe__brake-pedal-automatic-transmission).
9. Brake Lamp Sensor Removing and Installing, refer to «BRAKE LAMP SENSOR»(/audi/a5/i-2007-2011/remont/anti-locktraction-control/#anti-lock-brake-system-coupe__brake-lamp-sensor).
10. Bolt Connects the brake booster to the mounting bracket. 25 Nm
11. Hex Nut For the brake master cylinder. 49 Nm
12. Brake Line Brake master cylinder to the hydraulic unit. 14 Nm
13. Brake Line Brake master cylinder to the hydraulic unit. 14 Nm
14. Seal Replace
15. Brake Master Cylinder Cannot be serviced. Replace as complete unit if malfunctioning. Removing and Installing, refer to «MASTER BRAKE CYLINDER»(/audi/a5/i-2007-2011/remont/mechanical-hydraulic/#hydraulic-components-brake-system-coupe).
16. Sealing Plug Moisten with brake fluid and press into brake fluid reservoir.

Note. Use only new brake fluid. Observe information on brake fluid reservoir!

Scheme 57

Left-hand drive vehicles

a = 164.7 mm +/- 0.5 mm

Note. Surface -1- for measuring. When measuring, ball head must be arranged at a right angle to surface of brake booster. Measure to end of ball head without gasket installed.

Ball Head to the Push Rod, 30 Nm.

VACUUM PUMP -V192- OVERVIEW

Depending on the engine install, a vacuum pump is installed to support the brake booster.

1. Vacuum Pump, Turbo FSI 4-Cylinder, removing and installing, refer to «VACUUM PUMP, TURBO FSI 4-CYLINDER»(/audi/a5/i-2007-2011/remont/mechanical-hydraulic/#hydraulic-components-brake-system-coupe__vacuum-pump-turbo-fsi-4-cylinder) .
2. Vacuum Pump, FSI V6, removing and installing, refer to «VACUUM PUMP, FSI V6»(/audi/a5/i-2007-2011/remont/mechanical-hydraulic/#hydraulic-components-brake-system-coupe__vacuum-pump-fsi-v6) .
3. Vacuum Pump, removing and installing, TFSI V6, refer to «VACUUM PUMP, V6 TFSI»(/audi/a5/i-2007-2011/remont/mechanical-hydraulic/#hydraulic-components-brake-system-coupe__vacuum-pump-v6-tfsi) .
4. Vacuum Pump, V192, removing and installing, refer to «Brake System Vacuum Pump -V192»(/audi/a5/i-2007-2011/remont/mechanical-hydraulic/#hydraulic-components-brake-system-coupe__brake-system-vacuum-pump-v192) .
5. Vacuum Pump, removing and installing, Audi RS 5, refer to «Brake System Vacuum Pump -V192-, RS 5»(/audi/a5/i-2007-2011/remont/mechanical-hydraulic/#hydraulic-components-brake-system-coupe__brake-system-vacuum-pump-v192-rs) .

Note. Only the vacuum pump is shown in the illustration and not the installation location.

Scheme 58

1. Bolt 9 Nm Remove to remove the pump. NOTE: The pump is not designed to be disassembled.
2. Vacuum Pump
3. Vacuum Hose Secure with hose clamps that match those used in production
4. Bolt 5 Nm NOTE: Installing the bolt depends on the model. Alternatively, secure the vacuum hose with the hose clamp for the vehicle version
5. O-Ring Replace NOTE: Installation of the o-ring depends on the model.
6. O-Ring Replace NOTE: Installation of the o-ring depends on the model.
7. O-Ring Replace NOTE: Installation of the o-ring depends on the model.

BRAKE SYSTEM VACUUM PUMP -V192- OVERVIEW

The construction of the brake system vacuum pump -- depends on the engine.

The electrical brake system vacuum pump -- is switched on by the engine control module depending on the intake line pressure.

Scheme 59

1. Vacuum Line
2. Electrical Connector
3. Brake System Vacuum Pump -V192- Removing and Installing, refer to «Brake System Vacuum Pump -V192»(/audi/a5/i-2007-2011/remont/mechanical-hydraulic/#hydraulic-components-brake-system-coupe__brake-system-vacuum-pump-v192) . Checking, refer to «Brake System Vacuum Pump -V192-, CHECKING»(/audi/a5/i-2007-2011/remont/mechanical-hydraulic/#hydraulic-components-brake-system-coupe__brake-system-vacuum-pump-v192-checking) .
4. Check Valve Removing and Installing, refer to «CHECK VALVE»(/audi/a5/i-2007-2011/remont/mechanical-hydraulic/#hydraulic-components-brake-system-coupe) . Checking, refer to «CHECK VALVE, CHECKING»(/audi/a5/i-2007-2011/remont/mechanical-hydraulic/#hydraulic-components-brake-system-coupe__check-valve-checking) .
5. Brake System Vacuum Pump -- Bracket Removing and Installing, refer to «Brake System Vacuum Pump -V192- BRACKET»(/audi/a5/i-2007-2011/remont/mechanical-hydraulic/#hydraulic-components-brake-system-coupe__brake-system-vacuum-pump-v192-bracket) .
6. Bracket Nut 20 Nm

The electrical vacuum pump -- is switched on by the engine control module depending on the intake line pressure.

Note. It is necessary to remove the left front wheel housing liner in order to remove the vacuum pump, refer to Removal and Installation .

Note. View brake system vacuum pump -- from underneath after removing the left front wheel housing liner.

Scheme 60

1. Bracket To remove, remove the brake system vacuum pump --. Removing and Installing, refer to «Brake System Vacuum Pump -V192- BRACKET, RS 5»(/audi/a5/i-2007-2011/remont/mechanical-hydraulic/#hydraulic-components-brake-system-coupe__brake-system-vacuum-pump-v192-bracket) .
2. Bracket Bolt 20 Nm
3. Electrical Connector
4. Brake System Vacuum Pump -- Removing and Installing, refer to «Brake System Vacuum Pump -V192-, RS 5»(/audi/a5/i-2007-2011/remont/mechanical-hydraulic/#hydraulic-components-brake-system-coupe__brake-system-vacuum-pump-v192-rs) . Checking, refer to «Brake System Vacuum Pump -V192-, CHECKING, RS 5»(/audi/a5/i-2007-2011/remont/mechanical-hydraulic/#hydraulic-components-brake-system-coupe__brake-system-vacuum-pump-v192-checking) . NOTE: It is necessary to remove the left front wheel housing liner in order to remove the vacuum pump, refer to «Removal and Installation»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe) .

Note. View brake system vacuum pump -- inside the engine compartment, in the front on the left side.

Scheme 61

1. Bracket Bolt 20 Nm
2. Brake System Vacuum Pump -- Removing and Installing, refer to «Brake System Vacuum Pump -V192-, RS 5»(/audi/a5/i-2007-2011/remont/mechanical-hydraulic/#hydraulic-components-brake-system-coupe__brake-system-vacuum-pump-v192-rs) . Checking, refer to «Brake System Vacuum Pump -V192-, CHECKING, RS 5»(/audi/a5/i-2007-2011/remont/mechanical-hydraulic/#hydraulic-components-brake-system-coupe__brake-system-vacuum-pump-v192-checking) . NOTE: It is necessary to remove the left front wheel housing liner in order to remove the vacuum pump, refer to «Removal and Installation»(/audi/a5/i-2007-2011/remont/mirrors/#exterior-equipment-coupe) .
3. Check Valve Removing and Installing, refer to «CHECK VALVE, RS 5»(/audi/a5/i-2007-2011/remont/mechanical-hydraulic/#hydraulic-components-brake-system-coupe) . Checking, refer to «CHECK VALVE, CHECKING, RS 5»(/audi/a5/i-2007-2011/remont/mechanical-hydraulic/#hydraulic-components-brake-system-coupe__check-valve-checking-rs-5) .
4. Nut Secondary pump hose bracket. 20 Nm
5. Bracket Bolt 20 Nm

BRAKES AND BRAKE LINES LINE ROUTING

Brakes and brake lines are delivered as ready-to-install replacement parts.

Secure brakes and brake lines at original fastening points when installing.

Lines to Hydraulic Assembly

Tighten the nuts -1- through -4- to 14 Nm.

Tighten the nuts -5- and -6- to 14 Nm.

Scheme 62

Brake Hose to Brake Caliper to Front Axle

Item -1- brake hose, ensure retaining tabs are seated correctly in bracket.

Item -2- retaining spring.

3- brake pipe line, 14 Nm

Scheme 63

1- brake pipe line, 14 Nm

Item -2- retaining spring.

Item -3- brake hose, ensure retaining tabs are seated correctly in bracket.

Scheme 64

Brake Line Routing in Wheel Housing to Front Axle

1- brake pipe line, 14 Nm

Item -2- intermediate piece.

3- brake pipe line, 14 Nm

Scheme 65

Brake Line Connecting in Wheel Housing to Front Axle

Item -1- brake hose bracket.

2- brake line, 14 Nm

Scheme 66

Brake Line Routing to Rear Axle

1- brake hose in brake caliper 20 Nm.

2- brake hose bracket, make sure the tabs are secure inside the bracket.

Item -3- retaining spring.

4- brake line, 14 Nm.

Scheme 67

FASTENER TIGHTENING SPECIFICATIONS

BRAKES, TESTING FOR LEAKS

Note. The hydraulic brake system must be bled. Only install genuine parts or components approved by Audi in the brake system. The if the brake fluid replacement interval specified by Audi is exceeded, replace the brake fluid. Check the system visually for leaks. Fix leaks and remove dirt on the hydraulic system.

Switch the engine off.

Press the brake pedal until there is no more brake assistance - "pump the brake booster empty". The brake pedal becomes hard.

Press the brake pedal about 20 mm out of the resting position.

Hold the force on the pedal steady for about 20 seconds.

The brake pedal travel must not increase.

Release the brake pedal.

Press firmly on the brake.

Hold the force on the pedal steady for about 20 seconds.

The brake pedal travel must not increase.

If the pedal sinks down during one of the tests, repeat the visual inspection on the brake system.

If no leaks are found, the brake master cylinder is probably has leaks and must be replaced.

HIGH AND LOW PRESSURE TESTING

Special tools and workshop equipment required

1. Brake Pressure Gauge 0-250 Bar V.A.G 1310A
2. Brake Pedal Actuator V.A.G. 1869/2

Note. The hydraulic brake system must be bled. Only install genuine parts or components approved by Audi in the brake system. The if the brake fluid replacement interval specified by Audi is exceeded, replace the brake fluid. Check the system visually for leaks. Fix leaks and remove dirt on the hydraulic system.

Before Beginning

Check brake system (brake master cylinder, brake hoses, brake lines and brake calipers) for proper seal and function.

High Pressure Testing

Remove bleeder screw at one of the front brake calipers. Connect V.A.G 1310A and bleed.

Install V.A.G 1869/2 between the brake pedal and driver seat.

Scheme 68

Apply pressure to brake pedal until the gauge indicates a pressure of 50 bar.

The pressure must not drop by more than 4 bar during the test period of 45 seconds.

If pressure drop is large, replace hydraulic unit.

Low Pressure Testing

Push V.A.G 1869/2 back until the pressure gauge indicates 6 bar positive pressure.

The pressure must not drop by more than 1 bar during a test period of 3 minutes.

If pressure drop is large, replace hydraulic unit.

BRAKE SYSTEM VACUUM PUMP -V192-, CHECKING

Special tools and workshop equipment required

1. Vehicle Diagnostic Tester VAS 5051B or VAS 5052

Description and Function

The electrical vacuum pump is switched on by the engine control module depending on the intake line pressure.

Vacuum pump has On Board Diagnostic (OBD) properties. Detected faults are stored in engine control module.

Note. The function of the electrical vacuum pump can only be checked using OBD when the engine is switched off.

Procedure

Turn off the ignition.

Press the brake pedal until there is no more brake assistance - "pump the brake booster empty". The brake pedal becomes hard.

Connect the vehicle diagnostic tester to the 16-pin diagnostic connector in the vehicle with the ignition switched off.

Switch on tester -arrow-.

Scheme 69

Turn on the ignition.

Start the program in the vehicle diagnostic tester.

Note. The ignition must be switched off and onto repeat the test.

BRAKE SYSTEM VACUUM PUMP -V192-, CHECKING, RS 5

Description and Function

The electrical vacuum pump is switched on by the engine control module depending on the intake line pressure.

Vacuum pump has On Board Diagnostic (OBD) properties. Detected faults are stored in engine control module.

Note. The function of the electrical vacuum pump can only be checked using OBD when the engine is switched off.

Special tools and workshop equipment required

1. Vehicle Diagnostic Tester

Procedure

Turn off the ignition.

Press the brake pedal until there is no more brake assistance - "pump the brake booster empty". The brake pedal becomes hard.

Connect the vehicle diagnostic tester to the 16-pin diagnostic connector in the vehicle with the ignition switched off.

Switch on tester -arrow-.

Turn on the ignition.

Start the program in the vehicle diagnostic tester.

Note. The ignition must be switched off and onto repeat the test.

CHECK VALVE, CHECKING

Valve must allow air to flow in direction of arrow.

Valve must remain closed in opposite direction.

Observe correct installation position.

The arrow points to the vacuum pump.

CHECK VALVE, CHECKING, RS 5

Valve must allow air to flow in direction of arrow.

Valve must remain closed in opposite direction.

Observe correct installation position.

The arrow points to the vacuum pump.

FRONT BRAKE CALIPER PISTON, 1LT

Special tools and workshop equipment required

1. Assembly Paste G 052 150 A2.
2. Trim Removal Wedge 3409.
3. Piston Resetting Tool T10145.

REMOVING

Force piston from brake caliper housing using compressed air.

Scheme 70

Note. Place a wooden board into the recess of the caliper housing so it is not damaged.

Remove seal.

Scheme 71

Use the 3409 for this.

Note. Be careful not to damage the surface of the cylinder while removing the seal.

INSTALLING

Insert the inner seal in the brake caliper groove -arrow-.

Scheme 72

Press the protective cap onto the brake caliper housing so that it contacts the brake caliper housing all around.

Scheme 73

It should no longer be possible to remove the protective cap from the brake caliper housing by hand.

Thinly coat piston and seal with assembly paste G 052 150 A2 before inserting.

Press the brake piston lightly on the protective cap.

Do not angle piston, to avoid damaging the seal sleeve.

Blow the protective cap on with pressurized air (max. 3 bar). The protective cap will thereby jump over the brake piston.

Press the brake pistons into the caliper using T10145.

Scheme 74

Do not angle piston, to avoid damaging the seal sleeve.

Note. The inner sealing lip of the protective cap thereby slips into the groove on the piston.

BEARING BUSHING AND GUIDE PIN FN-3 BRAKE, 1LT

Note. When removing, mark brake pads that will be used again. Install in the same position, otherwise braking effect will be uneven!

Loosen the brake caliper at the pins -12-.

Scheme 75

Remove the brake caliper.

Note. Do not let the brake caliper hang from the brake hose. Secure it to the body with suitable cable ties or wire. Do not support the weight with the brake hose.

Remove the bushing from the brake caliper.

Installation is performed in reverse sequence.

Use new guide pins.

Special tools and workshop equipment required

1. Assembly paste G 052 150 A2
2. Trim Removal Wedge 3409
3. Piston Resetting Tool T10145

Force piston from brake caliper housing using compressed air.

Scheme 76

Note. Place a wooden board into the recess of the caliper housing so it is not damaged.

Remove seal.

Scheme 77

Use the 3409 for this.

Note. Be careful not to damage the surface of the cylinder while removing the seal.

The surface of the piston and seal must only be cleaned with mineral spirits and then dried.

Thinly coat piston and seal with assembly paste G 052 150 A2 before inserting.

Insert the inner seal in the brake caliper groove -arrow-.

Press the protective cap onto the brake caliper housing so that it contacts the brake caliper housing all around.

It should no longer be possible to remove the protective cap from the brake caliper housing by hand.

Thinly coat piston and seal with assembly paste G 052 150 A2 before inserting.

Press the brake piston lightly on the protective cap.

Do not angle piston, to avoid damaging the seal sleeve.

Blow the protective cap on with pressurized air (max. 3 bar). The protective cap will thereby jump over the brake piston.

Press the brake pistons into the caliper using T10145.

Do not angle piston, to avoid damaging the seal sleeve.

Note. The inner sealing lip of the protective cap thereby slips into the groove on the piston.

PROTECTIVE CAP AND GUIDE PIN, 1LA/1LJ

The guide pins must be removed if the protective caps are damaged.

Note. When removing, mark brake pads that will be used again. Install in the same position, otherwise braking effect will be uneven!

Press the retaining spring -7- in the center.

Note. The spring is tensioned, keep hands protected. When removing the spring, make sure it does not scratch the brake caliper or damage the paint.

Remove the retaining spring carefully.

Remove the bolts -1- on the brake caliper.

Remove the brake caliper.

Note. Do not let the brake caliper hang from the brake hose. Secure it to the body with suitable cable ties or wire. Do not support the weight with the brake hose.

Remove the protective cap -2- on the outside from the groove on the guide pin.

Pull the guide pin -3- outward out of the protective cap.

Remove the protective cap from the brake caliper.

Carefully press the guide pin into the protective cap as far as the first groove.

Insert the protective cap in the brake caliper.

The protective cap must be seated in the center of the brake caliper.

Press the guide pin through the protective cap.

The protective cap must not be seated in both grooves on the guide pin.

Check the movement of the guide pin. Both guide pins must slide.

Install the brake caliper and tighten the bolts -1- to 30 Nm.

Position the retaining spring -7- on the outer brake pad.

Press the retaining spring in the center and insert the center tab of the retaining spring in the hole -arrow- on the brake caliper.

Note. The retaining spring tab must sit correctly in the hole in the brake caliper or it can spring out and the brake pad will not be held in place. The spring is tensioned, keep hands protected. When removing the spring, make sure it does not scratch the brake caliper or damage the paint.

FRONT BRAKE CALIPER PISTON, 1LW

Special tools and workshop equipment required

1. Trim Removal Wedge 3409
2. Piston Resetting Tool -T10145
3. Lithium Grease G 052 150 A2

1. The brake caliper is removed.
2. Brake Caliper, Removing, Ceramic Brakes, refer to «BRAKE CALIPER»(/audi/a5/i-2007-2011/remont/mechanical-hydraulic/#mechanical-components-brake-system-coupe__brake-caliper) .

Force piston from brake caliper housing, one at a time, using compressed air.

Scheme 78

Only one piston can be pressed out at a time. Secure opposite piston in brake caliper housing using piston resetting tool -a-. Block the other pistons, for example using wood blocks -b-. In addition, place a wooden board -c- in front of the piston resetting tool so that the piston will not be damaged when pressed out.

Remove seal with 3409.

Scheme 79

Be careful not to damage the surface of the cylinder while removing the seal.

The surface of the piston and seal must only be cleaned with mineral spirits and then dried.

Thinly coat piston and seal with lithium grease G 052 150 A2 before inserting.

Insert oil seal in brake caliper housing.

Scheme 80

Install protective cap on piston.

Scheme 81

Push piston into brake caliper housing using constant pressure.

Scheme 82

The protective cap must be seated properly in the groove, push slightly farther if necessary.

Brake Caliper, Installing, Ceramic Brakes, refer to BRAKE CALIPER .

Note. Brake line in brake caliper 19 Nm. Brake line connection to brake line 14 Nm

Bleed brake system, refer to BRAKE SYSTEM, BLEEDING .

REAR BRAKE CALIPER PISTON

Special tools and workshop equipment required

1. Torque Wrench 5-50 Nm V.A.G 1331
2. Torque Wrench 40-200 Nm V.A.G 1332
3. Piston Resetting Tool T10145
4. Trim Removal Wedge 3409
5. Vehicle Diagnostic Tester VAS 5051B or VAS 5052

Remove pistons as far as possible from brake caliper.

Force piston out of brake caliper housing using compressed air.

Scheme 83

Note. Be careful not to damage the surface of the cylinder while removing the seal. Place a wooden board into the recess of the caliper housing so it is not damaged.

Remove old seal from brake caliper with 3409.

Scheme 84

Install new seal in brake caliper.

Place new protective cap on brake pistons as shown.

Scheme 85

Install pressure nut to dimension -a- 15 mm.

Scheme 86

Insert protective cap in brake caliper groove. Use 3409 to do so.

Scheme 87

Carefully slide brake piston into brake caliper. Move brake piston when doing so. Brake piston must be guided over pressure nut, this is only possible in four positions.

After brake piston has been guided onto pressure nut, press it as far as stop into brake caliper.

Scheme 88

Note. Make sure that pressure nut is not damaged.

Install the pressure nut clockwise as far as the stop.

Scheme 89

Make sure the rubber makes contact around brake caliper housing -arrows-.

Scheme 90

Press the piston into the brake caliper by hand.

Scheme 91

Note. The inner sealing lip of the protective cap thereby slips into the groove on the piston.

REAR BRAKES GUIDE PINS AND PROTECTIVE CAPS, REPLACING

If protective caps or guide pins are damaged, install repair kit. Use grease packet supplied to lubricate guide pins.

Remove the bolts -1- on the brake caliper.

Remove the brake caliper.

Note. Do not let the brake caliper hang from the brake hose. Secure it to the body with suitable cable ties or wire. Do not support the weight with the brake hose.

Remove the protective cap -9- from the nut on the brake carrier.

Remove the guide pins -8- from the brake carrier.

Remove the protective cap from the guide pin.

Grease the guide pin before inserting.

Slide the protective cap over the groove on the guide pin.

Slide the guide pin -8- with the protective cap -9- through the brake carrier.

Press the protective cap over the groove on the brake carrier.

Insert the brake caliper.

Install the bolts -1- and tighten them.

BRAKE SYSTEM VACUUM PUMP -V192-, RS 5

Note. It is necessary to remove the left front wheel housing liner in order to remove the brake system vacuum pump -V192-, refer to Removal and Installation .

The construction of brake system vacuum pump -- depends on the engine.

The brake system vacuum pump -- is switched on by the engine control module depending on the intake line pressure.

Brake system vacuum pump -- is not intended to be serviced. In case of complains, determine cause with help of function or seal test. If there is a malfunction, replace electrical vacuum pump.

Note. The electric vacuum pump is located inside the engine compartment on the left side.

Raise the vehicle.

Remove left front wheel.

Remove the left front wheel housing liner, refer to Removal and Installation .

Note. View brake system vacuum pump -- from underneath after removing the wheel housing liner.

Disconnect the connector -3- from the brake system vacuum pump --.

Remove the bolt from the bracket -2- for the brake system vacuum pump --.

Remove the secondary pump hose from the bracket for the brake system vacuum pump --.

Lower the vehicle.

Note. View brake system vacuum pump -- inside the engine compartment, in the front on the left side.

Remove the secondary pump hose from the bracket -4-.

Move the secondary pump hose to the side.

Remove the nut from the coolant pipe bracket.

Move the coolant pipe to the side.

Remove the two bolts from the bracket for the brake system vacuum pump -- -1 and 5-.

Remove the vacuum hose for the brake system vacuum pump -- from the brackets inside the engine compartment.

Open the clamp on the vacuum hose with pliers.

Pull the vacuum hose off the brake system vacuum pump --.

Remove the brake system vacuum pump -- and bracket from the engine compartment.

Remove the brake system vacuum pump -- from the bracket.

Press the right and lift clips -arrow- out of the bracket by hand.

Scheme 92

Remove the electrical vacuum pump upward while holding the rubber buffer securely.

Scheme 93

Install in reverse order of removal.

Note. Use new clamps when installing the vacuum line.

Insert the brake system vacuum pump -- into the bracket.

Push the right and link clips -arrow- into the mount and secure the brake vacuum pump --.

Install the bracket, with the brake system vacuum pump -V192- already in it, into the engine compartment.

Note. Make sure it is installed in the correct position.

Tighten the bracket for the brake system vacuum pump -V192- to the body to 20 Nm with two bolts -1 and 5-.

Slide the new clamp over the vacuum hose.

Attach the vacuum hose to the brake system vacuum pump --.

Note. Moisten the hose and the connection with water to make it easier to install.

Close the hose clamp with pliers.

Place the coolant pipe and bracket on the pin.

Tighten the nut on the coolant pipe to 20 Nm.

Tighten the secondary pump hose to the bracket -4-.

Clip the vacuum hose in all brackets inside the engine compartment.

Raise the vehicle.

Tighten the bracket -1- for the brake system vacuum pump -- to the body to 20 Nm with bolt -2-.

Connect the connector -3- to the brake system vacuum pump -- -4-.

Clip the secondary pump hose into the bracket on the brake system vacuum pump --.

Install the wheel housing liner, refer to Removal and Installation .

Mount the left front wheel, refer to Specifications .

Lower the vehicle.

VACUUM PUMP, TURBO FSI 4-CYLINDER

Note. Before removing the vacuum pump, the fuel high pressure pump must be removed, refer to Removal and Installation . The plenum chamber bulkhead does not have to be removed.

The vacuum pump is installed in the engine compartment facing the rear -arrow-.

Scheme 94

Remove the engine covers carefully from the retaining pins, one after another.

Scheme 95

The vacuum pump is installed in the engine compartment on the right side facing the rear.

Disconnect the fuel high pressure pump connector -1-.

Remove the electric line from the bracket -arrow-.

Scheme 96

Remove the fuel high pressure pump -2-, refer to Removal and Installation .

Loosen the ignition coil strip on the bracket.

Disconnect the ignition coil connectors -arrow-.

Scheme 97

Carefully push the ignition coil strip to the side.

Disconnect the wires on the high pressure pump and on the vacuum pump and push them to the side.

Disconnect the vacuum hose at the hose clamp to the vacuum pump.

Remove all the bolts -arrows- on the vacuum pump sealing flange.

Scheme 98

Note. Do not disconnect the vacuum hose from the vacuum line on the plenum chamber bulkhead -2-.

Remove the vacuum pump from the mount.

Note. Replace the seal. Make sure the seal is correctly installed.

Position the vacuum pump tappet so it engages in the groove on the camshaft when vacuum pump is installed.

Insert the vacuum pump.

Make sure the seal is seated correctly.

Install and tighten all the bolts -arrows- on the vacuum pump sealing flange, refer to -Item 1- 1 .

Push the new hose clamps over the vacuum hose.

Push the vacuum hose over the connection to the vacuum pump.

Compress the hose clamp on the vacuum pump connections with pliers.

Connect the wires to the high pressure pump and to the vacuum pump.

Connect the ignition coil connectors -arrow-.

Install the ignition coil strip.

Install the fuel high pressure pump, refer to Removal and Installation .

Install the engine cover.

VACUUM PUMP, FSI V6

Note. The vacuum pump is installed in the engine compartment at the front and on the left side in the driving direction.

Remove the engine covers carefully from the retaining pins, one after another.

Scheme 99

Loosens the hose clamp on the vacuum hose.

Remove the vacuum hose form the vacuum pump.

Remove all the screws on the vacuum pump sealing flange.

Remove the vacuum pump from the mount.

Note. Replace the seal. Make sure the seal is correctly installed.

Position the vacuum pump tappet so it engages in the groove on the camshaft when vacuum pump is installed.

Insert the vacuum pump.

Make sure the seal is seated correctly.

Install and tighten all the screws on the vacuum pump sealing flange, refer to -Item 1- 1 .

Push the new hose clamps over the vacuum hose.

Push the vacuum hose over the connection to the vacuum pump.

Compress the hose clamp on the vacuum pump connections with pliers.

Carefully install the engine covers into the retaining bolts one after the other.

VACUUM PUMP, V6 TFSI

Note. The vacuum pump is installed in the engine compartment at the front and on the left side in the driving direction.

Loosens the hose clamp on the vacuum hose.

Remove the vacuum hose form the vacuum pump.

Remove all the screws on the vacuum pump sealing flange.

Remove the vacuum pump from the mount.

Note. Replace the seal. Make sure the seal is correctly installed.

Position the vacuum pump tappet so it engages in the groove on the camshaft when vacuum pump is installed.

Insert the vacuum pump.

Make sure the seal is seated correctly.

Install and tighten all the screws on the vacuum pump sealing flange.

Push the new hose clamps over the vacuum hose.

Push the vacuum hose over the connection to the vacuum pump.

Compress the hose clamp on the vacuum pump connections with pliers.

BRAKE SYSTEM VACUUM PUMP -V192

The construction of the vacuum pump depends on the engine.

The brake system vacuum pump -- is switched on by the engine control module depending on the intake line pressure.

Vacuum pump is not intended to be serviced. In case of complains, determine cause with help of function or seal test. If there is a malfunction, replace electrical vacuum pump.

Note. The electrical vacuum pump is located in the engine compartment on the right side in front of the plenum chamber bulkhead.

Remove the engine cover.

Disconnect electrical connector -1-.

Scheme 100

Loosen the clamp on the vacuum hose using suitable pliers.

Disconnect the vacuum hose from the vacuum pump.

Press the right and lift clips -arrow- out of the bracket by hand.

Remove the electrical vacuum pump upward while holding the rubber buffer securely.

Note. When removing the vacuum pump, make sure the lower rubber buffer does not fall into the engine compartment.

Install in reverse order of removal.

Push the right and link clips -arrow- into the mount and secure the brake vacuum pump --.

Note. Use new clamps when installing the vacuum line.

BRAKE FLUID RESERVOIR COVER

Not installed in all vehicles.

The brake fluid reservoir cover has an opening on the left to check the brake fluid level. To prevent damage later, brake fluid must not enter between the brake fluid reservoir cover and the brake fluid reservoir.

Remove the plenum chamber cover, refer to Removal and Installation .

Remove the bolt -4-.

Remove the brake fluid reservoir cover from the vehicle.

Place the brake fluid reservoir cover over the brake fluid reservoir.

Install the bolt -4- and tighten.

Install plenum chamber cover, refer to Removal and Installation .

Remove the plenum chamber cover, refer to Removal and Installation .

Disconnect the connector from the brake fluid level warning switch -F34-.

Remove the brake fluid reservoir cover over the brake fluid reservoir BRAKE FLUID RESERVOIR COVER .

To protect against escaping brake fluid, place enough lint-free cloths in the area below the master brake cylinder.

Extract as much brake fluid as possible from the brake fluid reservoir with the brake charger/bleeder unit VAS 5234 and adapter VAS 5234/1.

With manual transmissions, remove the clutch hydraulic line -5- from the brake fluid reservoir and seal it.

Pull the lower locking pin out of the brake fluid reservoir.

Remove the brake fluid reservoir from the brake master cylinder.

Remove the protective cap on the new brake fluid reservoir just before filling it.

Coat the plugs on the brake fluid reservoir with brake fluid.

Insert the brake fluid reservoir in the sealing plugs in the brake master cylinder.

Push the lower locking pin through the brake fluid reservoir.

Connect the electrical connector from the brake fluid level warning switch -F34-.

With manual transmission, connect the clutch hydraulic line -5- to the brake fluid reservoir.

Fill the brake fluid up to the marking.

Bleed the brake system, refer to BRAKE SYSTEM, BLEEDING .

With manual transmissions, bleed the clutch, refer to Description and Operation or to [For engine(s) CAUA] Description and Operation .

Install the brake fluid reservoir cover over the brake fluid reservoir.

Note. The brake fluid reservoir cover is not installed on all vehicle models.

Install plenum chamber cover, refer to Removal and Installation .

Special tools and workshop equipment required

1. Torque Wrench 5-50 Nm V.A.G 1331
2. Adapter VAS 5234/1
3. Brake Charger/Bleeder Unit VAS 5234
4. Sealing Plugs Repair Kit, Part no. 1H0 698 311 A

Remove the plenum chamber cover, refer to Removal and Installation .

Remove the engine cover.

Remove the tower brace, refer to Removal and Installation .

Remove the plenum chamber, refer to Removal and Installation .

To protect against escaping brake fluid, place enough lint-free cloths in the area below the master brake cylinder.

Extract as much brake fluid as possible from the brake fluid reservoir with the VAS 5234.

Remove the brake fluid reservoir, refer to BRAKE FLUID RESERVOIR .

Disconnect brake lines -2- at brake master cylinder and seal brake lines with sealing plugs from repair kit.

Scheme 101

Remove brake master cylinder nuts -3-.

Remove brake master cylinder from brake booster.

Remove the brake master cylinder from the vehicle.

Install in reverse order of removal.

Note. Use new nuts.

Replace sealing ring between brake master cylinder and brake booster.

When replacing brake master cylinder, ensure pressure rod in brake booster is seated correctly.

Press brake pedal down slightly. This makes it easier to guide the push rod into the brake master cylinder.

Install new nuts -3- and tighten. Note torque.

Install brake lines -2- on brake master cylinder. Note torque.

Install the brake fluid reservoir, refer to BRAKE FLUID RESERVOIR .

With manual transmissions, insert the clutch hydraulic line -5- into the brake fluid reservoir.

Fill the brake fluid up to the marking.

Bleed the brake system, refer to BRAKE SYSTEM, BLEEDING .

With manual transmissions, bleed the clutch, refer to General Information or to [For engine(s) CAUA] General Information .

Install the plenum chamber bulkhead, refer to Removal and Installation .

Install the tower brace, refer to Removal and Installation .

Install the engine cover.

Install plenum chamber cover, refer to Removal and Installation .

Perform ESP driving and system test.

Special tools and workshop equipment required

1. Torque Wrench 5-50 Nm V.A.G 1331
2. Adapter VAS 5234/1
3. Brake Charger/Bleeder Unit VAS 5234
4. Sealing Plugs Repair Kit, Part no. 1H0 698 311 A

Switch the engine off.

Press the brake pedal until there is no more brake assistance - "pump the brake booster empty". The brake pedal becomes hard.

Remove the driver side storage compartment -1 to 3-.

Scheme 102

Disconnect the connector -C- on the footwell vent.

Scheme 103

Remove the footwell vents -A-B-.

Remove the brake lamp sensor, refer to BRAKE LAMP SENSOR .

Separate the brake pedal from the brake booster, refer to BRAKE PEDAL AND BRAKE BOOSTER, DISCONNECTING AND CONNECTING .

Remove the engine cover.

Remove the plenum chamber cover, refer to Removal and Installation .

Remove the tower brace, refer to Removal and Installation .

Remove the plenum chamber, refer to Removal and Installation .

Remove the brake fluid reservoir, refer to BRAKE FLUID RESERVOIR .

Remove the brake master cylinder at the nuts -3-, refer to MASTER BRAKE CYLINDER .

Remove the brake master cylinder from the vehicle.

Place the brake master cylinder so no brake fluid can drain out.

Remove the vacuum line -3- from the brake booster.

Scheme 104

Remove the bolts mounting the brake booster -1- to the mounting bracket.

Remove the brake booster from the vehicle.

Insert the brake booster in the vehicle.

Make sure the seal is seated correctly.

Install the bolts from the brake booster -1- to the mounting bracket and tighten them.

Press the vacuum line -3- into the brake booster.

Install the brake master cylinder, refer to MASTER BRAKE CYLINDER .

Install the brake fluid reservoir, refer to BRAKE FLUID RESERVOIR .

With manual transmissions, insert the clutch hydraulic line -5- into the brake fluid reservoir.

Fill the brake fluid up to the marking.

Bleed the brake system, refer to BRAKE SYSTEM, BLEEDING .

With manual transmissions, bleed the clutch, refer to General Information or to [For engine(s) CAUA] General Information .

Install the plenum chamber bulkhead, refer to Removal and Installation .

Install the tower brace, refer to Removal and Installation .

Install the engine cover.

Install plenum chamber cover, refer to Removal and Installation .

Brake Pedal and Brake Booster, Connecting

Hold the push rod ball head in front of the mount and push the brake pedal toward the brake booster, so that the ball head clicks into place.

Install the brake lamp sensor, refer to BRAKE LAMP SENSOR .

Install the footwell vent -A-.

Connect the connector -C- on the footwell vent.

Install the driver side storage compartment -1 to 3-.

Remove the plenum chamber cover, refer to Removal and Installation .

Note. The brake booster pressure sensor -- is located in the plenum chamber near the brake booster.

Disconnect electrical connector -1-.

Remove pressure sensor in -direction of arrow-.

Scheme 105

Note. The pressure sensor is secured with clips.

Release clips with pliers -1-.

Scheme 106

Carefully pry the Brake Booster Pressure Sensor -- off.

Install in reverse order of removal.

BRAKE SYSTEM VACUUM PUMP -V192- BRACKET

Note. To remove the bracket, the vacuum pump must first be removed from the bracket.

Remove the engine cover.

Remove the vacuum pump, refer to Brake System Vacuum Pump -V192 .

Remove the two nuts -6- on the bracket.

Remove the bracket from the vehicle.

Installation is performed in reverse sequence.

Open the clamp on the vacuum hose with pliers.

Disconnect the vacuum hose from the pump.

Remove the vacuum hose on the left and right of the check valve -4-.

Remove the check valve from the vehicle.

Valve must allow air to flow in direction of arrow.

the arrow indicates the direction of the vacuum pump.

Push the left and right vacuum hose onto the check valve -4-.

Note. Moisten the vacuum hose with water to make it easier to install.

Slide the new clamp over the vacuum hose.

Push the vacuum hose onto the pump.

Close the hose clamp with pliers.

Open the clamp on the vacuum hose with pliers.

Disconnect the vacuum hose from the pump.

Remove the vacuum hose on the left and right of the check valve -3-.

Remove the check valve from the vehicle.

Valve must allow air to flow in direction of arrow.

the arrow indicates the direction of the vacuum pump.

Push the left and right vacuum hose onto the check valve -3-.

Note. Moisten the vacuum hose with water to make it easier to install.

Slide the new clamp over the vacuum hose.

Push the vacuum hose onto the pump.

Close the hose clamp with pliers.

BRAKE SYSTEM VACUUM PUMP -V192- BRACKET, RS 5

Note. It is necessary to remove the brake system vacuum pump -- in order to remove the bracket.

Vacuum Pump, Removing, RS 5, refer to Brake System Vacuum Pump -V192-, RS 5 .

Remove the bracket and brake system vacuum pump -- from the bracket.

Installation is performed in reverse sequence.

Vacuum Pump, Installing, RS 5, refer to Brake System Vacuum Pump -V192-, RS 5 .

Scheme 107

Special tools and workshop equipment required

1. Torque Wrench 5-50 Nm V.A.G 1331
2. Torque Wrench 40-200 Nm V.A.G 1332
3. Piston Resetting Tool T10145
4. Trim Removal Wedge 3409
5. Vehicle Diagnostic Tester VAS 5051B or VAS 5052

Special tools and workshop equipment required

Scheme 108

Scheme 109

Scheme 110

Scheme 111

1. Assembly Paste G 052 150 A2.
2. Trim Removal Wedge 3409.
3. Piston Resetting Tool T10145.
4. VAS 5234 Brake Charger/Bleeder Unit
5. VAS 5234/1 Adapter
6. Brake Pressure Gauge 0-250 Bar V.A.G 1310A

See also:
• BRAKE FLUID
• Removal and Installation
• FRONT BRAKE CALIPER WITH BRAKE CARRIER
• BRAKE PEDAL, AUTOMATIC TRANSMISSION
• BRAKE LAMP SENSOR
• Removal and Installation
• BRAKE CALIPER
• Specifications
• Description and Operation
• Removal and Installation
• BRAKE PEDAL AND BRAKE BOOSTER, DISCONNECTING AND CONNECTING
• BEARING BUSHING AND GUIDE PIN FN-3 BRAKE, 1LT
• PROTECTIVE CAP AND GUIDE PIN, 1LA/1LJ
• REAR BRAKE CALIPER PISTON
• REAR BRAKES GUIDE PINS AND PROTECTIVE CAPS, REPLACING
• BRAKE FLUID RESERVOIR
• BRAKE FLUID RESERVOIR COVER
• VACUUM PUMP, TURBO FSI 4-CYLINDER
• VACUUM PUMP, FSI V6
• VACUUM PUMP, V6 TFSI
• Brake System Vacuum Pump -V192
• Brake System Vacuum Pump -V192-, RS 5
• Brake System Vacuum Pump -V192-, CHECKING
• CHECK VALVE, CHECKING
• Brake System Vacuum Pump -V192- BRACKET
• CHECK VALVE, CHECKING, RS 5
• BRAKE SYSTEM, BLEEDING
