REAR FINAL DRIVE GEAR OIL, CHECKING

Special tools and workshop equipment required

1. Catch Tray

Remove the sealing plug for checking transmission fluid -arrow-.

Scheme 531

The fluid level is correct when the rear final drive is filled up the lower edge of the fluid fill hole.

1. Transmission fluid specification, refer to «SPECIFICATIONS»(/audi/a4/b8-2007-2012/remont/automatic-trans/#general-technical-data-rear-final-drive-0bc-avant) .

Install the check plug -arrow- and tighten.

Tightening specifications: 30 Nm

DRIVESHAFT BOLTED ON TRANSMISSION-SIDE OVERVIEW

Note. Observe general repair notes, refer to REPAIR INFORMATION . The driveshafts cannot be repaired. They can only be removed, installed and adjusted. Always store and transport driveshaft fully extended only. The driveshaft can be bent at the center joint without using force. A hard bending to the stop may cause damage to the center joint or dust boot. If the driveshaft is only detached at the transmission or from the rear final drive, it should be tied up or supported at the shaft end. If necessary, it is permitted to bend the driveshaft at the center joint without using force. Mark the position of all the parts before removing them. Install the parts in the same position, otherwise the imbalance can damage the bearing causing a humming noise. Use the counterhold tool Touareg V10 T10172 and adapters T10172/5 to loosen or tighten the driveshaft bolts. After disconnecting the driveshaft from the rear final drive, an installed balance washer (thick washer between backing plate and internal multi-point bolt) may not be reinstalled. If there are complaints about noise or vibration, make sure there is no tension on the intermediate bearing before replacing the driveshaft.

Scheme 532

1. Rear Final Drive Removing and installing, refer to «REMOVAL AND INSTALLATION»(/audi/a4/b8-2007-2012/remont/axle-shafts/#rear-final-drive-0bc-avant)
2. Gasket Replace a damaged (bent) gasket. A seal that has a rubber layer peeling off, must be replaced Remove any grease still on the flange and install the gasket. Sides having different color does not influence the installation.
3. Driveshaft Removing and installing, refer to «DRIVESHAFT BOLTED ON TRANSMISSION SIDE»(/audi/a4/b8-2007-2012/remont/axle-shafts/#rear-final-drive-0bc-avant__driveshaft-bolted-on-transmission-side) Removing from the transmission and installing, refer to «DRIVESHAFT, BOLTED ON TRANSMISSION SIDE»(/audi/a4/b8-2007-2012/remont/axle-shafts/#rear-final-drive-0bc-avant) Removing from the rear final drive and installing, refer to «DRIVESHAFT FROM REAR FINAL DRIVE»(/audi/a4/b8-2007-2012/remont/axle-shafts/#rear-final-drive-0bc-avant__driveshaft-from-rear-final-drive)
4. Balance Disc Not present on every vehicle Possibly located between an internal multi-point bolt -item 5- «DRIVESHAFT BOLTED ON TRANSMISSION-SIDE OVERVIEW»(/audi/a4/b8-2007-2012/remont/axle-shafts/#rear-final-drive-0bc-avant__driveshaft-bolted-on-transmission-side-overview) and a backing plate -item 6- «DRIVESHAFT BOLTED ON TRANSMISSION-SIDE OVERVIEW»(/audi/a4/b8-2007-2012/remont/axle-shafts/#rear-final-drive-0bc-avant__driveshaft-bolted-on-transmission-side-overview) on the rear final drive If present, this balancing washer must no longer be installed after disconnecting driveshaft from rear final drive.
5. Bolt Always replace if removed Self-locking Always clean the threaded holes in the flange shafts. (for example, use a thread cutter) On the rear final drive Tightening specification and sequence (Scheme 533)On the transmission 30 Nm + 90° turn
6. Locking Plate
7. Intermediate Bearing
8. Bolt 20 Nm
9. Drive

Scheme 533

1. Always replace the driveshaft bolts -1-.
2. Counter hold using the counterhold tool Touareg V10 T10172 and adapters T10172/5.

Tighten the bolts -1- in 3 steps as follows

Scheme 534

Tighten the bolts -arrows- to 24 Nm.

DRIVESHAFT MOUNTED ON TRANSMISSION-SIDE OVERVIEW

Note. Observe general repair notes, refer to REPAIR INFORMATION. The attached driveshaft can only be removed from the transmission if it is removed completely. The driveshafts cannot be repaired. They can only be removed, installed and adjusted. Always store and transport driveshaft fully extended only. The driveshaft can be bent at the center joint without using force. A hard bending to the stop may cause damage to the center joint or dust boot. If the driveshaft is only detached from rear final drive, it should be tied up or supported at the shaft end. If necessary, it is permitted to bend the driveshaft at the center joint without using force. Use the counterhold tool Touareg V10 T10172 and adapters T10172/5 to loosen or tighten the driveshaft bolts. Always hold the driveshaft horizontal when installing it or removing it from the transmission output shaft. Follow the tightening sequence for attaching the driveshaft bolts to the rear final drive. see scheme 6

If there are complaints (noise, vibration), do the following before replacing the driveshaft

1. Make sure the center bearing is free of tension.
2. Remove the driveshaft bolts on the rear final drive. Tighten the driveshaft following the tightening sequence. see scheme 6

Scheme 535

1. Drive
2. Hose Clamp Replace
3. Driveshaft Removing and installing, refer to «DRIVESHAFT ATTACHED ON TRANSMISSION SIDE»(/audi/a4/b8-2007-2012/remont/axle-shafts/#rear-final-drive-0bc-avant__driveshaft-attached-on-transmission-side). Removing from the rear final drive and installing, refer to «DRIVESHAFT FROM REAR FINAL DRIVE»(/audi/a4/b8-2007-2012/remont/axle-shafts/#rear-final-drive-0bc-avant__driveshaft-from-rear-final-drive)
4. Locking Plate
5. Bolt Self-locking Always replace if removed Threaded holes in the flange shaft at rear final drive must be cleaned of locking compound residue. Use a thread cutter to clean the holes. Tightening specification and sequence see scheme 6
6. Gasket Replace a damaged (bent) gasket. A seal that has a rubber layer peeling off, must be replaced. Remove any grease still on the flange and install the gasket. Sides having different color does not influence the installation.
7. Rear Final Drive Removing and installing, refer to «REMOVAL AND INSTALLATION»(/audi/a4/b8-2007-2012/remont/axle-shafts/#rear-final-drive-0bc-avant)
8. Intermediate Bearing
9. Bolt 20 Nm

1. Always replace the driveshaft bolts -1-.
2. Counter hold using the counterhold tool Touareg V10 T10172 and adapters T10172/5.

Tighten the bolts -1- in 3 steps as follows

Tighten the bolts -arrows- to 24 Nm.

Scheme 536

1. Subframe Removing and installing, refer to «Removal and Installation»(/audi/a4/b8-2007-2012/remont/suspension-rear/#rear-suspension-avant)
2. Bolt 95 Nm
3. Bolt 55 Nm
4. Bolt 55 Nm
5. Heat Shield
6. Bolt 20 Nm
7. Driveshaft Removing and installing, refer to «Removal and Installation»(/audi/a4/b8-2007-2012/remont/suspension-rear/#rear-suspension-avant)
8. Rear Final Drive Removing and installing, refer to «REAR FINAL DRIVE»(/audi/a4/b8-2007-2012/remont/axle-shafts/#rear-final-drive-0bc-avant) Removing and installing, refer to Removing and installing, refer to
9. Driveshaft Removing and installing, refer to «DRIVESHAFT BOLTED ON TRANSMISSION SIDE»(/audi/a4/b8-2007-2012/remont/axle-shafts/#rear-final-drive-0bc-avant__driveshaft-bolted-on-transmission-side) and «DRIVESHAFT ATTACHED ON TRANSMISSION SIDE»(/audi/a4/b8-2007-2012/remont/axle-shafts/#rear-final-drive-0bc-avant__driveshaft-attached-on-transmission-side) Removing from the rear final drive and installing, refer to «DRIVESHAFT FROM REAR FINAL DRIVE»(/audi/a4/b8-2007-2012/remont/axle-shafts/#rear-final-drive-0bc-avant__driveshaft-from-rear-final-drive)
10. Crossmember

FASTENER TIGHTENING SPECIFICATIONS

Driveshaft to Rear Final Drive - Tightening Specification and Sequence

1. Always replace the driveshaft bolts -1-.
2. Counter hold using the counterhold tool Touareg V10 T10172 and adapters T10172/5.

Tighten the bolts -1- in 3 steps as follows

Driveshaft Heat Shield - Tightening Specification

Tighten the bolts -arrows- to 24 Nm.

DRIVESHAFT BOLTED ON TRANSMISSION SIDE

Special tools and workshop equipment required

1. Alignment Fixture-4W Dr. Shaft 3139
2. Counterhold Tool Touareg V10 T10172 and Adapters T10172/5
3. Engine-/Gearbox Jack V.A.G 1383 A with Universal Mount V.A.G 1359/2
4. High temperature grease G 000 633

Removing

1. See note, refer to «DRIVESHAFT BOLTED ON TRANSMISSION-SIDE OVERVIEW»(/audi/a4/b8-2007-2012/remont/axle-shafts/#rear-final-drive-0bc-avant__driveshaft-bolted-on-transmission-side-overview)
2. Working on the driveshaft should only be performed with the vehicle on a two-column shop hoist.

Note. Do not bend the decoupling element in the front exhaust pipe more than 10°, otherwise it will get damaged.

Loosen the clamping sleeve(s) -arrows- and disconnect the exhaust system.

Tie the front exhaust pipe(s) to the underbody.

Install rear section of the exhaust system -2-. Refer to DESCRIPTION AND OPERATION .

Scheme 537

Note. A second technician will be needed to help remove the rear section of the exhaust system.

Audi A4 and Audi A5

Remove the crossmember -1-.

Remove the heat shield -3- -arrows-.

Audi Q5

Scheme 538

Remove the front -2- and rear -3- crossmembers.

Remove the heat shield -1- from the body.

Continuation for All Vehicles

Scheme 539

Remove the heat shield -A- from the transmission -arrows-, if equipped.

Check whether there is a marking (color marking) on driveshaft and at flange/driveshaft at rear final drive -arrow A- and -arrow B-.

Scheme 540

If one of these markings is no longer visible (for example -arrow A- on the driveshaft), then make a new color marking.

1. Die marking on the driveshaft -arrow A- and on the rear final drive -arrow B- must line up.

Attach the 3139 and tighten the plastic nuts.

Scheme 541

Note. Never lay the assembly tool on the balance plates.

Remove the bolts -arrows- for intermediate bearing.

Scheme 542

Remove the bolts connecting the driveshaft to the transmission using the T10172 and T10172/5.

Scheme 543

Remove driveshaft from transmission and support it using V.A.G 1383 A.

Remove the bolts -1- (quantity: 6) from the rear CV joint.

USE THE T10172 AND T10172/5.

Remove driveshaft.

Note. Always store and transport a driveshaft fully extended only.

Installing

Install in reverse order of removal. Note the following

1. Remove any old or dried-up high temperature grease from the CV joints and the driveshaft flanges. Fill with the exact same amount of high temperature grease G 000 633.
2. Clean any locking fluid still inside the threaded holes in the flange shafts for the transmission driveshaft and rear final drive. Use a thread cutter to clean the holes. Otherwise the bolts could break off when being installed.
3. After disconnecting driveshaft from the rear final drive, an additional balance washer (thick washer) that may be located between shim and a bolt may not be reinstalled.
4. Always replace (self-locking) securing bolts for driveshaft.
5. Note installation position of driveshaft: Center CV joint is located behind the intermediate bearing in direction facing the rear final drive.
6. Check the driveshaft seal on the rear final drive and on the transmission for damage (bent or the rubber has started to peel). Replace a damaged gasket.

Install the driveshaft. Pay attention to the installed position on the rear final drive

1. Die markings on the driveshaft -arrow A- and on the rear final drive -arrow B- must line up.
2. Maximum difference between the markings: 30°.

Install the bolts all he way in by hand but to do not tighten them.

Install the bolts -arrows- just far enough so that the intermediate bearing can still be moved.

Tighten the rear bolts -1- on the driveshaft. Follow the tightening sequence (Scheme 533)

Tighten the front bolts on the driveshaft. Tightening specification -item 5- DRIVESHAFT BOLTED ON TRANSMISSION-SIDE OVERVIEW .

Remove alignment fixture 3139.

Attach the driveshaft center bearing to the body making sure it is free of tension. Tightening specification -item 8- DRIVESHAFT BOLTED ON TRANSMISSION-SIDE OVERVIEW .

Attach the heat shield -A- (if equipped) to the transmission -arrows-. Tightening specification (Scheme 534)

Install the heat shield -1-.

Remove the front -2- and rear -3- crossmembers, if equipped. Refer to Description and Operation .

Install and adjust exhaust system free of stress. Refer to DESCRIPTION AND OPERATION .

Special tools and workshop equipment required

1. Counterhold Tool Touareg V10 T10172 and Adapters T10172/5
2. High temperature grease G 000 633

Removing

1. See note, refer to «DRIVESHAFT BOLTED ON TRANSMISSION-SIDE OVERVIEW»(/audi/a4/b8-2007-2012/remont/axle-shafts/#rear-final-drive-0bc-avant__driveshaft-bolted-on-transmission-side-overview) .
2. Working on the driveshaft should only be performed with the vehicle on a two-column workshop hoist.

Note. Do not bend the decoupling element in the front exhaust pipe more than 10°, otherwise it will get damaged.

Loosen the clamping sleeves -1 and 2- and separate the exhaust system.

Tie the front exhaust pipe(s) to the underbody.

Remove the heat shield -A- from the transmission -arrows-, if equipped.

Remove the bolts connecting the driveshaft to the transmission using the T10172 and T10172/5.

Tie the driveshaft to the underbody.

Installing

Install in reverse order of removal. Note the following

1. Remove any old or dried-up high temperature grease from the CV joint and the driveshaft flange. Fill with the exact same amount of high temperature grease G 000 633.
2. Threaded holes in flange shaft on the transmission must be cleaned of locking compound residue. Use a thread cutter to clean the holes. Otherwise the bolts could break off when being installed.
3. Always replace (self-locking) securing bolts for driveshaft.

Check the driveshaft seal on the transmission flange for damage and replace if necessary.

Install the driveshaft and install the new CV joint bolts.

Tighten the front bolts on the driveshaft. Tightening specification -item 5- DRIVESHAFT BOLTED ON TRANSMISSION-SIDE OVERVIEW .

1. Use the T10172 with the T10172/5.

Attach the heat shield -A- (if equipped) to the transmission -arrows-. Tightening specification (Scheme 534)

Assemble the exhaust system and then align it free of tension. Refer to DESCRIPTION AND OPERATION .

DRIVESHAFT FROM REAR FINAL DRIVE

Special tools and workshop equipment required

1. Counterhold Tool Touareg V10 T10172 and Adapters T10172/5
2. High temperature grease G 000 633

1. See note, refer to «DRIVESHAFT BOLTED ON TRANSMISSION-SIDE OVERVIEW»(/audi/a4/b8-2007-2012/remont/axle-shafts/#rear-final-drive-0bc-avant__driveshaft-bolted-on-transmission-side-overview)
2. Working on the driveshaft should only be performed with the vehicle on a two-column shop hoist.

Removing

Note. Do not bend the decoupling element in the front exhaust pipe more than 10°, otherwise it will get damaged.

Loosen the clamping sleeves -1 and 2- and separate the exhaust system.

Tie the front exhaust pipe(s) to the underbody.

Note. A second technician will be needed to help remove the rear section of the exhaust system.

Remove rear portion of exhaust system. Refer to DESCRIPTION AND OPERATION .

Check whether there is a marking (color marking) on driveshaft and at flange/driveshaft at rear final drive -arrow A- and -arrow B-.

If one of these markings is no longer visible (for example -arrow A- on the driveshaft), then make a new color marking.

1. Die marking on the driveshaft -arrow A- and on the rear final drive -arrow B- must line up.

Remove the bolts -1- (quantity: 6) from the rear CV joint.

Use the T10172 with the T10172/5.

Remove the driveshaft from the rear final drive and lay it on the subframe.

INSTALLING

Install in reverse order of removal. Note the following

1. Remove any old or dried-up high temperature grease from the CV joint and the driveshaft flange. Fill with the exact same amount of high temperature grease G 000 633.
2. Threaded holes in the flange shaft at the rear final drive must be cleaned of locking compound residue. Use a thread cutter to clean the holes. Otherwise the bolts could break off when being installed.
3. After disconnecting driveshaft from rear final drive, an additional balance washer (thick washer) that may be located between the shim and a bolt may not be reinstalled.
4. Always replace (self-locking) securing bolts for driveshaft.
5. Check the driveshaft seal on the rear final drive for damage (bent or the rubber has started to peel). Replace a damaged gasket.

Position the driveshaft on the rear final drive paying attention to the installed position

1. Die markings on the driveshaft -arrow A- and on the rear final drive -arrow B- must line up.
2. Maximum difference between the markings: 30°.

Install and tighten the driveshaft bolts -1-. Follow the tightening sequence (Scheme 533)

Install rear part of exhaust system. Refer to DESCRIPTION AND OPERATION .

DRIVESHAFT ATTACHED ON TRANSMISSION SIDE

Special tools and workshop equipment required

1. Transmission Support VW 785/1 B
2. Counterhold Tool Touareg V10 T10172
3. Adapter T10172/5
4. Hose Clamp Pliers V.A.G 1275
5. High temperature grease G 000 633

Removing

Note. The attached driveshaft can only be removed from the transmission if it is removed completely. Working on the driveshaft should only be performed with the vehicle on a two-column shop hoist. Tie up or support the end of the shaft after disconnecting if from the rear final drive. The driveshaft can be bent at the center joint without using force. A hard bending to the stop may cause damage to the center joint or dust boot. Always hold the driveshaft horizontal when installing it or removing it from the transmission output shaft.

Scheme 544

Loosen the clamping sleeves -1 and 2- and slide them to the rear.

Attach the front muffler and/or left and right front exhaust pipe to the underbody.

Remove the bolts -arrows- and remove the driveshaft heat shield -1-, if equipped.

Cut the hose clamp -1- for the driveshaft boot and remove it.

Scheme 545

Note. Ignore -2-.

Audi A6 and Audi A7

Scheme 546

Remove the crossbrace -2-. Refer to "Heat Shields and Crossbraces" in Removal and Installation .

Audi A4, Audi A5 Coupe, Audi A5 Sportback, Audi A5 Cabriolet and Audi Q5

Remove the front crossmember -2- and the rear crossmember -3-. Refer to Description and Operation .

Continuation for All Vehicles

Remove the heat shield -1-.

Lower the exhaust system rear section near the front and secure it using the VW 785/1 B as illustrated.

Scheme 547

Check whether there is a marking (color marking) on the driveshaft and at flange/driveshaft at rear final drive -arrow A- and -arrow B-.

If one of these markings is no longer visible, then make a new color marking.

1. Die markings on the driveshaft -arrow A- and on the rear final drive -arrow B- must line up.

Remove the driveshaft bolts -1- on the rear final drive.

Counter hold using the T10172 and T10172/5.

Remove the bolts -arrows- from the driveshaft intermediate bearing.

Scheme 548

Lower the rear driveshaft at the fuel tank and at the subframe and remove it from the transmission.

Installing

1. Tightening specifications, refer to «DRIVESHAFT MOUNTED ON TRANSMISSION-SIDE OVERVIEW»(/audi/a4/b8-2007-2012/remont/axle-shafts/#rear-final-drive-0bc-avant__driveshaft-mounted-on-transmission-side-overview) and see scheme 7.

Note. Remove old and dry high-temperature grease from CV joint and flange for driveshaft. Fill with the exact same amount of high temperature grease G 000 633. Threaded holes in the flange shaft at the rear final drive must be cleaned of locking compound residue. Use a thread cutter to clean the holes. Otherwise the bolts could break off when being installed. Replace the self-locking bolts. Replace the clamp -1- for the driveshaft rubber boot -2-. Check the driveshaft seal on the rear final drive for damage (bent or the rubber has started to peel) Replace a damaged gasket. Wipe off the splines on the transmission output shaft with a towel before attaching it to the driveshaft. Do not grease the splines.

First attach the driveshaft to the transmission.

1. Maximum bend angle: 10°.
2. After installing the driveshaft approximately 50 mm onto the transmission output shaft, turn the driveshaft slightly to make sure the splines on the transmission output shaft mesh with the splines on the driveshaft.
3. Push the driveshaft all the way onto the splines on the transmission output shaft.

Install the bolts -arrows- just far enough so that the intermediate bearing can still be moved.

Position the driveshaft on the rear final drive paying attention to the installed position

1. Die markings on the driveshaft -arrow A- and on the rear final drive -arrow B- must line up.
2. Maximum difference between the markings: 30°.

Install the bolts all he way in by hand but to do not tighten them.

Align the clamp -1- for the driveshaft boot with the mounting points -2- and then tighten is using V.A.G 1275.

Note. Pushing the driveshaft back just a little makes it easier to install the V.A.G 1275 correctly.

Tighten the driveshaft bolts -1-. Follow the tightening sequence see scheme 6

Attach the driveshaft intermediate bearing to the body making sure it is free of tension. Tightening specification -item 9- DRIVESHAFT BOLTED ON TRANSMISSION-SIDE OVERVIEW .

Install in reverse order of removal. Be sure to note the following

Attach the heat shield -A- (if equipped) to the transmission -arrows-. Tightening specification see scheme 7

Install the heat shield -1-. Refer to Description and Operation .

Remove the front -2- and rear -3- crossmembers, if equipped. Refer to Description and Operation .

Install the exhaust system and adjust it so that it is free of tension. Refer to DESCRIPTION AND OPERATION .

Special tools and workshop equipment required

1. Engine-/Gearbox Jack V.A.G 1383 A with Universal Transmission Support V.A.G 1359/2
2. Tensioning Strap T10038
3. Wheel Hub Support T10149
4. Counterhold tool Touareg V10 T10172 and adapters T10172/5
5. Socket XZN 12T40154

Removing

Observe general repair notes, refer to REPAIR INFORMATION .

Place the vehicle on a hoist.

Remove the hub cap from the left rear wheel. On a light alloy wheels, remove cover cap (removal hook in vehicle tool kit).

Remove the left rear wheel.

Vehicles with a 6- or 8-cylinder engine (except Audi Q5)

Remove the rear crossmember -1-.

Install rear section of the exhaust system -2-. Refer to DESCRIPTION AND OPERATION .

Note. A second technician will be needed to help remove the rear section of the exhaust system.

Attach the rear crossmember -1- to the body.

Continuation for All Vehicles

Remove the heat shield -3- from the body -arrows-.

Remove the driveshaft from the rear final drive. Refer to DRIVESHAFT FROM REAR FINAL DRIVE .

Place a block of wood -A- (approximately 40 mm tall) on the rear crossmember -C- and secure the driveshaft -B-.

Scheme 549

Note. The heat shield under the intermediate bearing supports the driveshaft -B- on the Audi Q5. The driveshaft can be bent at the center joint without using force. A hard bending to the stop may cause damage to the center joint or dust boot.

Remove the bolts from the driveshaft intermediate bearing -arrows-.

Push the driveshaft forward while pulling of off the rear final drive.

Tie the driveshaft to the side of the subframe.

Remove the left driveshaft heat shield -A- from the crossmember/rear final drive -arrows-.

Scheme 550

Remove the left -1- and right -3- driveshafts.

Scheme 551

Loosen the bolts -2- approximately 3 turns.

Remove the bolt -4-.

Place the V.A.G 1383 A with the V.A.G 1359/2 and a block of wood -A- (approximately 80 mm tall) under the rear final drive.

Scheme 552

Note. Make sure the V.A.G 1359/2 is not touching the fuel tank.

Remove the bolts -1- (lower crossmember bolt to the rear final drive) and -2-.

Remove the two upper crossmember bolts -B- to the rear final drive.

Scheme 553

Guide the T40154 through the holes in the subframe -A-. Move the final drive to the left or to the right if necessary.

Push the final drive -A- slightly to the front.

Scheme 554

Turn the crossmember -B- to the left in direction of -arrow 1- while guiding it past the final drive -arrow 2- and remove it.

Note. A second technician will be needed to continue removing the rear final drive. Secure the vehicle to the support arm on the vehicle with a T10038 before lifting the left rear suspension.

Remove the V.A.G 1383 A from under the final drive. A second technician must secure the rear final drive from falling out while doing this.

Place the T10149 in the V.A.G 1383 A.

Attach the T10149 to the suspension left rear wheel hub using a wheel bolt -arrow A-.

Scheme 555

Lift the left rear suspension using the V.A.G 1383 A just far enough until the support arm -1- on the vehicle hoist starts to lift the vehicle -arrow B-.

A second technician must lift the rear final drive -1- in direction of -arrow- toward the left side of the vehicle.

Scheme 556

Guide the right drive axle -5- upward and out of the final drive flange shaft -4-.

Guide the left drive axle -3- and, with a second technician, remove the final drive from the subframe -2- toward the rear.

Installing

Install in reverse order of removal. Note the following

With a second technician, mount the rear final drive -1- on the subframe -2-.

Install the left drive axle -3- into the final drive flange shaft.

A second technician must lift the rear final drive -1- in direction of -arrow- toward the left side of the vehicle.

Attach the right drive axle -5- to the final drive flange shaft -4-.

Remove the V.A.G 1383 A and the T10149 from the left rear suspension.

Place the V.A.G 1383 A with the V.A.G 1359/2 and a block of wood (approximately 80 mm tall) under the rear final drive -A-.

Push the final drive -A- slightly to the front.

Rotate and install the crossmember -B- opposite the direction of -arrow 1- while guiding past the final drive -arrow 2-.

Diagonally tighten the 4 bolts for attaching the crossmember -B- to the rear final drive. Tightening specification -item 4- REAR FINAL DRIVE OVERVIEW .

Guide the T40154 through the holes in the subframe -A-. Move the final drive to the left or to the right if necessary.

Install the bolts -2 and 4- hand-tight.

Note. The V.A.G 1383 A and the V.A.G 1359/2 are not shown in the illustration.

Tighten the bolt -4-. Tightening specification -item 3- REAR FINAL DRIVE OVERVIEW .

Tighten the bolts -2-. Tightening specification -item 1- REAR FINAL DRIVE OVERVIEW .

Remove the V.A.G 1383 A from under the final drive.

Tighten the left -1- and right -3- drive axles. Refer to Removal and Installation .

Attach the left drive axle heat shield -A- to the crossmember/rear final drive -arrows- -item 6- REAR FINAL DRIVE OVERVIEW .

Attach the driveshaft to the rear final drive DRIVESHAFT FROM REAR FINAL DRIVE .

Attach the driveshaft intermediate bearing to the body free of tension Tightening specification -item 8- DRIVESHAFT BOLTED ON TRANSMISSION-SIDE OVERVIEW .

Check axle oil level in rear final drive. Refer to REAR FINAL DRIVE GEAR OIL, CHECKING .

Attach the heat shield -3- to the body -arrows-.

Install and adjust rear section of the exhaust system free of stress. Refer to DESCRIPTION AND OPERATION .

Install the crossmember -1- (if equipped). Refer to Description and Operation .

Install the left rear wheel. Refer to Removal and Installation .

FLANGE SHAFT SEALS, REAR FINAL DRIVE REMOVED

1. The seals can only be replaced when the final drive is removed.

Special tools and workshop equipment required

1. Puller T10037
2. Needle Bearing Drift VW 295
3. Thrust Piece T40108
4. Sealing grease G 052 128 A1

Removing

Follow the general repair instructions. Refer to REPAIR INFORMATION .

Remove rear final drive. Refer to REAR FINAL DRIVE .

Removing Right Flange Shaft

Scheme 557

Thread T10037 tightly to housing -arrow- and pull out flange shaft.

Removing Left Flange Shaft

Scheme 558

Thread T10037 tightly to housing -arrow- and pull out flange shaft.

Pry out the shaft seal.

Scheme 559

Installing

Install in reverse order of removal. Note the following

Install Right Shaft Seal

Scheme 560

Coat the outer circumference of the shaft seal with gear oil.

Fill the space between the sealing and dust lips halfway with sealing grease G 052 128 A1.

Install the new shaft seal all the way without tilting it.

Install Left Shaft Seal

Scheme 561

Coat the outer circumference of the shaft seal with gear oil.

Fill the space between the sealing and dust lips halfway with sealing grease G 052 128 A1.

Install the new shaft seal all the way without tilting it.

Install Right and Left Flange Shafts

Scheme 562

Drive in flange shaft using VW 295.

Install rear final drive. Refer to REAR FINAL DRIVE .

Check the gear oil in the rear final drive. Refer to REAR FINAL DRIVE GEAR OIL, CHECKING .

FLANGE SHAFT RING

Special tools and workshop equipment required

1. Thrust Plate VW 401
2. Thrust Plate VW 402
3. Thrust Disc VW 412
4. Press Support-R and R Ball Joints 3146
5. 3- Separating Device 22 to 115 mm, for example Kukko 17/2

Scheme 563

B - Separating Tool 22 to 115 mm, for example Kukko 17/2

Scheme 564

1. Installed position of the ring -A- : the larger outer circumference of the ring faces the flange.

FLANGE/DRIVESHAFT SEAL

Special tools and workshop equipment required

1. Puller VW 391
2. Adapter VW 771/40 from the Slide Hammer-Complete Set VW 771
3. Retainer 3028
4. Puller T10055
5. 2- Adapter T10055/2
6. Thrust Piece T40109
7. Assembly Tool T40222/1
8. Sealing grease G 052 128 A1
9. Two M8 x 30 bolts
10. 1 M8 x 45 bolt

Removing

1. The rear final drive is installed
2. Observe general repair notes. Refer to «REPAIR INFORMATION»(/audi/a4/b8-2007-2012/remont/automatic-trans/#general-technical-data-rear-final-drive-0bc-avant__repair-information) .

Separate the exhaust system at the clamping sleeves -1 and 2-.

Remove rear section of the exhaust system. Refer to DESCRIPTION AND OPERATION .

Note. A second technician will be needed to help remove the rear section of the exhaust system.

Open the gear oil drain plug -arrow- and let approximately 250 ml gear oil drain out.

Scheme 565

Install the drain plug -arrow- and tighten.

1. Tightening specification: 30 Nm

Remove the driveshaft from the rear final drive. Refer to DRIVESHAFT FROM REAR FINAL DRIVE .

Audi A8

Guide the driveshaft between the fuel tank and the rear subframe downward and tie it to the side.

Audi A6 and Audi A7

Remove the crossbrace -2-. Refer to "Heat Shields and Crossbraces" in Removal and Installation .

Audi A4, Audi A5 Coupe, Audi A5 Sportback, Audi A5 Cabriolet and Audi Q5

Remove the front -2- and rear -3- crossmembers, if equipped.

Remove the heat shield -1-.

Remove the bolts -arrows- from the driveshaft intermediate bearing.

Lower the driveshaft by the center bearing.

At the same time, guide the driveshaft between the fuel tank and the rear subframe downward.

Install the bolts -arrows- for the intermediate bearing hand-tight.

Tie up the driveshaft.

Continuation for All Vehicles

Scheme 566

Remove any high temperature grease inside the flange/driveshaft.

Remove the locking ring -arrow-.

Mark the position of the flange/driveshaft -B- to the pinion -A- -arrow-.

Scheme 567

Note. This mark -arrow- is needed so that the color dot -C- on the outside of the flange remains in its earlier position. Only by doing this can the smallest imbalance possible inside the rear final drive be guaranteed.

Install 2 M8 x 30 bolts -arrow- into the flange.

Scheme 568

Pull off driveshaft flange using VW 391.

Place an absorbent cloth -A- under the final drive on the subframe.

Scheme 569

Puncture the metal cover on the shaft seal -A- in direction of -arrow- using a scriber -B-.

Scheme 570

Insert a screw -arrow- into this opening -A-.

Scheme 571

Remove the flange/driveshaft seal -A- in direction of -arrow-.

Scheme 572

B- screw

Installing

Scheme 573

Install in reverse order of removal. Note the following

Fill the space between the sealing and dust lips halfway with sealing grease G 052 128 A1.

Place the new seal -A- on the T40222/1.

Note. Make sure the spring on the seal is behind the sealing lip when it is installed.

Coat the outer circumference of the shaft seal with gear oil.

Install the T40222/1 and the shaft seal -A- on the pinion -B-.

Install the seal -A- all the way.

Remove the T40222/1.

Install the new shaft seal all the way without tilting it.

Scheme 574

Position the flange/driveshaft -B- on the pinion -A- so that the marking -arrow- lines up.

Install the VW 771/40 into the threaded hole in the pinion.

Scheme 575

Attach the 3028 to the flange/driveshaft with the M8 x 30 bolts -arrow A-.

Secure the VW 391 with the M8 x 45 bolt -arrow B-. Turn the VW 391 spindles in the VW 771/40.

Install the flange/driveshaft all the way while counter holding the VW 391 spindle with a wrench.

Scheme 576

1. The bevel on the inner diameter of the locking ring -arrow A- faces out, toward the driveshaft.
2. If equipped, the wide strip on the ring -arrow B- must be on the right side, as illustrated.

Note the following when replacing the flange/driveshaft

1. A new locking ring -1- must be selected.
2. First determine and then install the thickest possible circlip that can be installed into the groove -1- that can be used; for the correct part number.

Driveshaft, attaching to rear final drive DRIVESHAFT FROM REAR FINAL DRIVE

Audi A4, A5 Coupe, A5 Sportback, A5 Cabriolet, Q5, A6, A7

Tighten the driveshaft center bearing in the body free of tension. Tightening specification -item 9- DRIVESHAFT MOUNTED ON TRANSMISSION-SIDE OVERVIEW .

Install the heat shield and the crossmember. Refer to Description and Operation .

Continuation for All Vehicles

Fill the gear oil in the rear final drive. Refer to REAR FINAL DRIVE GEAR OIL, CHECKING .

Install rear section of the exhaust system. Refer to DESCRIPTION AND OPERATION .

FLANGE/DRIVESHAFT RING

Special tools and workshop equipment required

1. Needle Bearing Drift VW 295 A
2. Thrust Plate VW 402
3. Punch VW 408 A
4. Support Channels VW 457
5. 3- Separating Device 22 to 75 mm, for example Kukko 17/1

Scheme 577

B - Separating Tool 12 to 75 mm, for example Kukko 17/1

Scheme 578

1. The ring -A- must be installed with the elevation -arrow 1- into the chamfer -arrow 2- on the flange -B-. The smaller outer circumference face the flange -arrow 3-.

Scheme 579

1. The ring -A- must clip into the chamfer in the flange. (Scheme 582)

SPECIAL TOOLS

Special tools and workshop equipment required

Scheme 580

Scheme 581

Scheme 582

Scheme 583

Scheme 584

Scheme 585

Scheme 586

Scheme 587

Scheme 588

Scheme 589

Scheme 590

Scheme 591

Scheme 592

Scheme 593

Scheme 594

Scheme 595

Scheme 596

Scheme 597

Scheme 598

Scheme 599

Scheme 600

Scheme 601

Scheme 602

Scheme 603

Scheme 604

1. Retainer 3028
2. Alignment Fixture-4W Dr. Shaft 3139
3. Press Support-R and R Ball Joints 3146
4. 3- Separating Device 22 to 115 mm, for example Kukko 17/2
5. 3- Separating Device 22 to 75 mm, for example Kukko 17/1
6. Tensioning Strap T10038
7. Puller T10037
8. Puller T10055
9. 2- Adapter T10055/2
10. Wheel Hub Support T10149
11. Counterhold Tool Touareg V10 T10172 and Adapters T10172/5
12. Thrust Piece T40108
13. Thrust Piece T40109
14. Socket XZN 12 T40154
15. Assembly Tool T40222/1
16. Hose Clamp Pliers V.A.G 1275
17. Engine-/Gearbox Jack V.A.G 1383 A with Universal Transmission Support V.A.G 1359/2
18. Needle Bearing Drift VW 295 A
19. Puller VW 391
20. Thrust Plate VW 401
21. Thrust Plate VW 402
22. Punch VW 408 A
23. Thrust Disc VW 412
24. Needle Bearing Drift VW 295
25. Support Channels VW 457
26. Adapter VW 771/40 from the Slide Hammer-Complete Set VW 771
27. Transmission Support VW 785/1 B
28. Not Illustrated

Edition 1 27 2012

See also:
• SPECIFICATIONS
• REPAIR INFORMATION
• Removal and Installation
• DESCRIPTION AND OPERATION
• Description and Operation
• Removal and Installation
• REMOVAL AND INSTALLATION
• DRIVESHAFT BOLTED ON TRANSMISSION SIDE
• DRIVESHAFT FROM REAR FINAL DRIVE
• DRIVESHAFT BOLTED ON TRANSMISSION-SIDE OVERVIEW
• DRIVESHAFT ATTACHED ON TRANSMISSION SIDE
• DRIVESHAFT MOUNTED ON TRANSMISSION-SIDE OVERVIEW
• REAR FINAL DRIVE GEAR OIL, CHECKING
