Wiring diagram: Memory systems — Memory systems circuit, with convertible Audi A4 B6
All systems
- Air conditioning
- Anti-lock brakes
- Anti-theft 2
- Body control modules
- Computer data lines 2
- Cooling fan
- Cruise control
- Defoggers 2
- Electronic power steering
- Engine performance 1.8l
- Engine performance 3.0l
- Exterior lights 8
- Ground distribution 2
- Headlights 5
- Horn
- Instrument cluster 2
- Interior lights 5
- Memory systems 2
- Navigation
- Power distribution 2
- Power door locks 3
- Power mirrors 3
- Power seats 6
- Power top/sunroof 2
- Power windows 3
- Radio 5
- Shift interlock 2
- Starting/charging 5
- Supplemental restraints 2
- Transmission 2
- Trunk, tailgate, fuel door 2
- Warning systems
- Wiper/washer 2
Memory systems circuit, with convertible (1 of 4) Audi A4 B6
Components on the diagram
Memory systems circuit, with convertible (2 of 4) Audi A4 B6
Components on the diagram
Memory systems circuit, with convertible (3 of 4) Audi A4 B6
