Servicing - A/t (01v - with 1.8l, 2.7l & 2.8l) Audi A4 B5

APPLICATION

TRANSAXLE APPLICATION

TRANSAXLE IDENTIFICATION PLATE

Volkswagen Audi Group (VAG) transaxle type is cast into transaxle case above left output shaft flange. Transaxle code and build date are located on front top of transaxle case. (Scheme 12) Transaxle code is also on vehicle data label.

Scheme 12

Scheme 13

Transaxle

For models produced from 1996-1997, check fluid level at 15,000 mile intervals. For models produced from 1998 and on, check fluid level at 20,000 mile intervals. On all models, fluid is filled for life. No changing is required.

Center Differential & Final Drives

Check fluid level at 20,000 mile intervals. Fluid is filled for life. No changing is required.

CHECKING FLUID LEVELS

Note. ATF level is affected by ATF temperature. Checking ATF level at too low a temperature leads to overfilling. Checking ATF level at too high a temperature leads to under filling. Overfilling or under filling transaxle can lead to transaxle malfunction.

Note. When ATF level is checked, seal on level plug must always be replaced. VAG Scan Tool (1551) and Diagnosis Cable (1551/3B) are required to check ATF level. Scan tool is used to measure ATF temperature. Follow aftermarket scan tool manufacturer instructions (if applicable) to check ATF temperature.

Note. Some models are equipped with auxiliary ATF cooler. An additional test procedure MAY be required for these vehicles when checking fluid level. See 01V Transaxle (With Auxiliary ATF Cooler) .

Scheme 14

Scheme 15

1. Connect Scan Tool (VAS 1551) to Data Link Connector (DLC), located under left side of instrument panel. (Scheme 14) Turn ignition on. Press buttons "0" and "8" to select "Read measuring value block". Press Q to confirm input. Press "0", "0" and "4" to input display group number "004". Press Q to confirm input. ATF temperature is indicated on scan tool display.
2. Secure container of ATF filler tools (V.A.G. 1924), or equivalent, as high up on vehicle as possible. Raise and support vehicle. Place drip tray (V.A.G. 1306) under transaxle.
3. Once an ATF temperature of 95°F (35°C) is reached, remove ATF check plug (2) and drain excess ATF if necessary. (Scheme 15) If ATF exits from the ATF filler plug hole before the ATF reaches 104°F (40°C), the ATF level is OK. Add ATF if no ATF has escaped from the ATF check plug hole by 104°F (40°C). NOTE: ATF check plug must be closed again by 113°F (45°C) at the latest. For warm countries, check plug must be closed again by 122°F (50°C).
4. If fluid level (3) is okay, install NEW seal on inspection plug and tighten to 59 ft. lbs. (80 N.m).
5. If additional fluid is required, using ATF Fill Tool (V.A.G. 1924), carefully insert fill hose through an opening in deflector cap. (Scheme 16) Fill until ATF runs out of inspection hole.
6. Install NEW seal on inspection plug and tighten to 59 ft. lbs. (80 N.m). Turn engine off.
7. Press right arrow key on scan tool. Press 0 and 6 to select "End Output" function 06. Press Q to confirm input.

01V Transaxle (With Auxiliary ATF Cooler)

Note. This procedure must be performed if auxiliary ATF cooler has been emptied or when it has been replaced.

1. Test requirements: Transaxle is not in emergency running mode. ATF if filled up. See «DRAINING & REFILLING»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l). Set selector lever to Park. A/C system and heating is switched off. ATF temperature is within correct range.
2. Connect Scan Tool (VAS 1551) to Data Link Connector (DLC), located under left side of instrument panel. (Scheme 14) Turn ignition on. Press buttons "0" and "8" to select "Read measuring value block". Press Q to confirm input. Press "0", "0" and "4" to input display group number "004". Press Q to confirm input. ATF temperature is indicated on scan tool display.
3. Let engine run until ATF temperature reaches at least 185°F (85°C). It may be necessary to test drive vehicle to increase ATF temperature. Thermostat at inlet to auxiliary ATF cooler does not open until temperature reaches 176°F (80°C). ATF will then flow into cooler. Ensure ATF is at test temperature.
4. Turn engine off and let ATF cool down until temperature is less than 95°F (35°C). Check ATF level and add fluid as needed. See «01V Transaxle (Without Auxiliary ATF Cooler)»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l).

Front Final Drive

Note. This unit is part of the main transaxle housing.

1. Drive vehicle a short distance to warm up gear oil to approximately 140° F (60° C). Position vehicle on level surface (4-post hoist or over pit). Turn engine off and let gear oil drain for 5 minutes. Place drain pan under final drive.
2. Remove fill plug (arrow) on side of final drive. (Scheme 17) Gear oil level should be at lower edge of fill hole. Add appropriate fluid as required. See «RECOMMENDED FLUIDS»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l__recommended-fluids).
3. Always replace "O" ring for oiler fill plug. Using hex ball socket (3247), install fill plug and tighten to specification. See «TORQUE SPECIFICATIONS»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l__torque-specifications).
4. If gear oil needs to be replenished following final drive repair, fill front final drive slowly and evenly over a period of at least 5 minutes until gear oil drips out over lower edge of fill hole. A filling time of at least 5 minutes is necessary to allow gear oil time to settle evenly in differential and cavities. Perform short road test to heat gear oil up to approximately 140° F (60° C) and check oil level in front final drive.

Center Differential (AWD Vehicles Only)

Note. If necessary, loosen or remove relevant parts of exhaust system to gain access to oil filler plug (arrow "B"). (Scheme 18)

1. Remove fill plug (B) and check gear oil level. (Scheme 18)
2. Gear oil level should be at lower edge of fill hole. Add appropriate fluid as required. See «RECOMMENDED FLUIDS»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l__recommended-fluids).
3. Always replace filler plug. Install NEW oil filler plug. Secure or re-install exhaust system free of stress. Tighten oil fill plug to specification. See «TORQUE SPECIFICATIONS»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l__torque-specifications).

Scheme 16

Rear Final Drive (AWD Vehicles Only)

Remove fill plug (arrow) to check gear oil. (Scheme 19) Oil level is correct when rear final drive is filled to lower edge of fill hole. If necessary, top off gear oil. See RECOMMENDED FLUIDS. Install plug and tighten to specification. See TORQUE SPECIFICATIONS.

Scheme 17

RECOMMENDED FLUIDS

RECOMMENDED FLUIDS

FLUID CAPACITIES

TRANSAXLE FLUID CAPACITIES

FINAL DRIVE & CENTER DIFFERENTIAL FLUID CAPACITIES

01V Transaxle (Changing Or Topping Off After Repair Work)

1. Ensure all electrical components and engine are switched off.
2. Connect ATF reservoir from filling system (V.A.G. 1924) to vehicle. Raise and support vehicle.
3. Place drain pan under transaxle. Remove drain plug (1). (Scheme 15) Drain ATF.
4. Install NEW drain plug and oil seal. Tighten to 30 ft. lbs. (40 N.m).
5. Remove ATF inspection plug (2). (Scheme 15) Using ATF Filling System (V.A.G. 1924), carefully insert fill hose through an opening in deflector cap (4). (Scheme 15)and (Scheme 16). Ensure deflector cap is not pushed upward out of position.
6. Fill until ATF runs out of inspection hole.
7. Shift selector lever into "P" position. Start engine.
8. Press and hold brake pedal. Shift through all selector lever positions with vehicle stationary, leaving selector lever in each position for approximately 10 seconds, and ending in "P" position.
9. Check fluid level and top off. See «CHECKING FLUID LEVELS»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l__checking-fluid-levels). Add ATF as necessary. Replace seal on ATF inspection plug. Tighten inspection plug to 59 ft. lbs. (80 N.m).

ATF LINES & ATF COOLER FLUSHING

01V Transaxle

1. Always blow through ATF cooler and ATF lines with compressed air (10 mbar, maximum) before installing transaxle. Place drip tray underneath ATF lines.
2. Remove bolt (2). (Scheme 20) Pull ATF lines off transaxle. Connect a hose (approximately 18 mm diameter) to ATF line (A) and secure with a hose clamp. Hang other end of hose in a suitable container. Clear ATF line (B) with compressed air. Change hose from ATF pipe (A) over to ATF pipe (B) and repeat sequence.
3. Re-secure ATF lines. Check and top off ATF level. See «CHECKING FLUID LEVELS»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l__checking-fluid-levels). When checking ATF level, check ATF line connections (A) and (B) for leaks. (Scheme 20)

Scheme 18

SHIFT MECHANISM

Note. Ensure motor CANNOT be started in driving ranges "2", "3", "4", "D" and "R".

Note. During vehicle speeds above 3 MPH (5 km/h) and shifting into "N", shift lock solenoid must not engage and lock selector lever. Selector lever can be shifted into a driving range. When driving slower than 1.2 MPH (2 km/h) and shifting into "N", shift lock solenoid must only engage after approximately one second. Selector lever can only be shifted out of "N" when brake pedal is depressed.

1. Place selector lever in "P" position and turn ignition on. With brake pedal not depressed, selector lever should be locked and not able to be moved from "P" position with depressed button in lever. Shift lock solenoid switch locks selector lever.
2. With brake pedal depressed, shift lock solenoid releases selector lever. Selecting driving range must be possible without binding or snagging with button in handle depressed. Move selector lever slowly from "P" to "R, N, D, 4, 3, 2" and check whether driving range position in display of instrument cluster are same.
3. Place selector lever in "N" position and turn ignition on. With brake pedal not depressed, selector lever should be locked and not able to be moved from "N" position with depressed button in lever. Shift lock solenoid switch should lock selector lever. With brake pedal depressed, shift lock solenoid should release selector lever. Selecting a driving range should be possible without binding or snagging with button in handle depressed.
4. Start engine and let run at idle. Engage parking brake and operate brake pedal. Display of selector lever position in instrument cluster should change during shifting into Tiptronic gate from "PRND432" to "54321".

1. Starter must not start with selector lever in positions "2", "3", "4", "D" and "R".
2. For speeds exceeding 5 km/h and shifting into selector lever position "N", the shift lock solenoid must not engage to lock the selector lever. Selector lever can be shifted into a driving mode.
3. For speeds below 2 km/h (almost standstill) and shifting into selector lever position "N", the shift lock solenoid must only engage after about 1 second. Selector lever can only be shifted out of position "N" with the brake pedal operated.

ON-VEHICLE REPAIRS

Note. Various components may be serviced without transaxle removal. For servicing of these components, see appropriate component under ADJUSTMENTS and/or REMOVAL & INSTALLATION .

ADJUSTMENTS

Note. Vehicles may be equipped with a Tiptronic shift mechanism. Selector lever may be shifted from "D" position to Tiptronic gate. This gate allows selector lever to be shifted forward (upshift) or backward (downshift) during vehicle operation.

LOCKING CABLE

Note. When battery is disconnected, vehicle computer and memory systems may lose memory data. Driveability problems may exist until computer systems have completed a relearn cycle.

Scheme 19

1. Shift selector lever into position "2". If vehicle is equipped with coded anti-theft radio, note radio code. Disconnect ground connection at battery.
2. Remove selector lever handle. See «SELECTOR LEVER HANDLE»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l). Remove front center console. See «FRONT CENTER CONSOLE»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l).
3. Shift selector lever into "P" position. Loosen locking cable support bracket bolt. (Scheme 21) It must be possible to slide bracket in direction of arrow. Adjust steering column downward. Locate Position Setting Bar (3352) between lever (for locking cable) and locking cable eye.
4. Pull locking cable in direction of arrow and tighten bolt to 89 INCH lbs. (10 N.m). (Scheme 21) Remove setting bar. Ensure ignition key can be easily removed after each adjustment of locking cable.
5. Install center console. See «FRONT CENTER CONSOLE»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l). Install selector lever handle. See «SELECTOR LEVER HANDLE»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l).

Without Tiptronic Shift Mechanism

Note. Locking cable must always be adjusted in installation position.

1. Remove selector lever handle. See «SELECTOR LEVER HANDLE»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l). Remove front center console. See «FRONT CENTER CONSOLE»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l).
2. Shift selector lever into "P" position. Adjust steering column downward. Loosen locking cable support bracket bolt. (Scheme 21) It must be possible to slide bracket in direction of arrow. Make sure securing spring is correctly seated in shift mechanism housing.
3. Hook locking cable bracket into shift mechanism and locking coupling ring in lever (for locking cable). (Scheme 21)
4. Locate Position Setting Bar (3352) between lever (for locking cable) and locking cable ring.
5. Pull locking cable in direction of arrow and tighten bolt to 89 INCH lbs. (10 N.m). (Scheme 21) Remove setting bar. Ensure ignition key can be easily removed after each adjustment of locking cable.
6. Install center console. See «FRONT CENTER CONSOLE»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l). Install selector lever handle. See «SELECTOR LEVER HANDLE»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l).

Scheme 20

1. To check cable, shift selector lever to "P" position. Raise and support vehicle. Remove selector lever cable protective plate.
2. Using a pry bar, remove selector lever cable from selector shaft lever (arrow). (Scheme 22) Shift selector lever from "P" to "2" position. Selector lever mechanism and selector lever cable must move freely. Replace selector lever cable or service selector lever mechanism as necessary. Shift selector lever to "P" position.
3. Bring selector shaft lever on transaxle to "P" position. Locking lever must engage in park lock wheel, and both front wheels should be blocked (cannot be turned together in a direction). It should be possible to push selector lever cable onto selector shaft lever. Adjust selector lever cable (if necessary).
4. To adjust cable, ensure selector lever cable is disconnected from selector shaft lever. Shift selector lever into "P" position. Locking lever must engage in park lock wheel, and both front wheels should be blocked (cannot be turned together in a direction).
5. Loosen bolts (arrows) securing support bracket to transaxle. (Scheme 23) Press selector lever cable onto shaft lever. Align selector lever cable in bracket.
6. Tighten securing bolts for support bracket to 17 ft. lbs. (23 N.m). Check selector lever mechanism operation. See «SHIFT MECHANISM»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l__shift-mechanism) under INSPECTION. Install selector lever cable protective plate. Tighten bolts to specification. See «TORQUE SPECIFICATIONS»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l__torque-specifications).

Scheme 21

1. To check cable, remove retaining clip (C) for selector lever cable at selector lever on transaxle. (Scheme 80)
2. Press selector lever cable off selector lever. Shift selector lever from "P" to "2" position. Shift mechanism and selector lever cable must move freely during this procedure. If necessary, replace selector lever cable or service shift mechanism.
3. Shift selector lever on transaxle to "P" position. Shift selector lever to "P" position (last position). Ensure shift lock solenoid engages. It should be possible to push selector lever cable onto selector lever shaft on transaxle. Adjust selector lever cable as necessary.
4. To adjust cable, ensure selector lever on transaxle is in "P" position. Ensure selector lever is in "P" position (last position). Ensure shift lock solenoid engages. Slightly loosen mounting bolt at transaxle bracket. Ensure selector lever cable is free of stress. Tighten mounting bolt to specification. See «TORQUE SPECIFICATIONS»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l__torque-specifications).
5. Check shift mechanism operation. See «SHIFT MECHANISM»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l__shift-mechanism) under INSPECTION.

REMOVAL & INSTALLATION

Removal & Installation (A4 With 1.8L)

Place collection pan under vehicle. For procedure, refer to illustration. (Scheme 24)

Scheme 22

Removal & Installation (A4 With 2.8L)

Place collection pan under vehicle. For procedure, refer to illustration. (Scheme 25)

Scheme 23

Removal & Installation (S4 With 2.7L Turbo)

Place collection pan under vehicle. For procedure, refer to illustration. (Scheme 26)

Scheme 24

Removal & Installation (Auxiliary Cooler)

For procedure, refer to illustrations. (Scheme 27)and (Scheme 28).

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

1. Unbolt heat shield for drive shaft from cover for Torsen differential (arrows). (Scheme 29)
2. Check whether there is a factory marking (colored dot) on driveshaft and at center differential flange. If not, place mating marks on driiveshaft flange and center differential flange. Only mark location, if same driveshaft is going to be reinstalled. Unbolt drive shaft (1) from transaxle and let it rest on heat shield (2). (Scheme 30) Secure drive shaft using wire at bracket (3).
3. Remove drain plug (A), and drain center differential gear oil. (Scheme 18) Always replace drain plug with NEW plug.
4. Loosen mounting bolts (arrows) for center differential housing in diagonal sequence and remove center differential. (Scheme 31) Pull Torsen differential off output shaft toward rear. (Scheme 32)
5. Installation is reverse of removal procedure. Check for alignment busing (arrow "A and "B"). (Scheme 33) Lightly coat sealing surface (D) with gear oil to prevent seal from slipping. Install gasket. Slide cleaned magnet into cast holding pocket (1) in intermediate flange.
6. Add 200 ml. gear oil to output housing. Install Torsen differential onto splines of output shaft and bottom spur gear while turning slowly. (Scheme 32) Ensure Torsen differential can be turned by hand.
7. Install fully assembled transfer housing with installed spur gears and rear drive flange onto transmission flange. Insert bolts (arrows) for transfer housing. (Scheme 31) Tighten center differential-to-transaxle housing bolts to specification in diagonal sequence and ensure tightening is done evenly in several stages. See «TORQUE SPECIFICATIONS»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l__torque-specifications).
8. After removing driveshaft, always remove any remaining locking fluid from thread holes in the transmission drive flanges and the rear final drive. Otherwise there is a possibility that the new bolts may get jammed when installed and shear when removed.
9. Replace drive shaft gaskets, and ensure adhesive surface is free of grease. Align drive shaft flanges to original positions, and install NEW self-locking bolts. Tighten bolts to specification. See «TORQUE SPECIFICATIONS»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l__torque-specifications). Fill transfer housing with gear oil and check oil level. See «CHECKING FLUID LEVELS»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l__checking-fluid-levels) under LUBRICATION.

Scheme 32

Scheme 33

Scheme 34

1. Remove front exhaust pipes. Unbolt heat drive shaft heat shield. (Scheme 29)
2. Check whether there is a factory marking (colored dot) on driveshaft and at center differential flange. If not, place mating marks on driiveshaft flange and center differential flange. Unbolt drive shaft (1) from transaxle and let it rest on heat shield (2). (Scheme 30) Secure drive shaft using wire at bracket (3).
3. Open center differential drain plug (A), and drain gear oil. (Scheme 18) Using a drift to counterhold output flange, unbolt output flange. (Scheme 34) Pull out output flange. Using screwdriver, remove center differential seal. (Scheme 35)
4. Installation is reverse of removal procedure. Drive seal in to stop using pressure piece (3402). (Scheme 36) Secure output flange with socket-head bolt. See «TORQUE SPECIFICATIONS»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l__torque-specifications).
5. After removing driveshaft, always remove any remaining locking fluid from thread holes in the transmission drive flanges and the rear final drive. Otherwise there is a possibility that the new bolts may get jammed when installed and shear when removed.
6. Replace drive shaft gaskets, and ensure adhesive surface is free of grease. Align drive shaft flanges to original positions, and install NEW self-locking bolts. Tighten bolts to specification. See «TORQUE SPECIFICATIONS»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l__torque-specifications).
7. Fill center differential with gear oil and check level. See «CHECKING FLUID LEVELS»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l__checking-fluid-levels) under LUBRICATION.

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

1. Remove parking brake lever trim. (Scheme 37) Unclip bolt covers (3). (Scheme 38) Remove bolts (2). Open ashtray cover (5), and lift ashtray up and out. Remove nut (6).
2. If necessary, remove armrest. (Scheme 39)
3. Pull up parking brake lever, lift rear center console (1) slightly and detach from front center console at front. (Scheme 38) Lift rear center console toward front over parking brake lever and remove. Disconnect data link connector (7) from center console.
4. Remove radio. See «RADIO»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l__radio).
5. Remove instrument panel center piece trim. (Scheme 40)
6. On vehicles equipped with manual climate control, remove bolts (6). (Scheme 41) On vehicles equipped with automatic climate control, remove climate control mounting bolts (4) from instrument panel center piece.
7. Unclip cover (3). (Scheme 42) Remove nut (4). Remove bolts (1). Detach center console at position (A), and remove.
8. Installation is reverse of removal procedure. Ensure center console is inserted into clip (5). (Scheme 42) Tighten all nuts and bolts to specification. See «TORQUE SPECIFICATIONS»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l__torque-specifications).

Scheme 41

Scheme 42

Scheme 43

1. Loosen right side drive axle shaft wheel hub bolt while the vehicle is still standing on its wheels. Remove right front wheel. Remove heat shield for right drive axle. Remove left front and right front exhaust pipes.
2. Remove right drive axle shaft. See «AXLE SHAFTS - FRONT & REAR»(/audi/a4/b5-1994-1999/remont/axle-shafts/#axle-shafts-front-rear) article in DRIVELINE/AXLES.
3. Remove transmission support heat shield (C). (Scheme 43) Remove bolts (A) and right heat shield (D). Remove transmission support (E). (Scheme 44)
4. Prevent drive flange from turning using mandrel and remove center bolt from right drive flange (arrow). (Scheme 45) Place drain pan underneath transaxle to catch spilled fluid. Pull out right drive flange.
5. Loosen bolts for differential cover in reverse order of tightening sequence shown in illustration (start at 12, finish at 1), and remove differential cover. (Scheme 46) Replace "O" ring (arrow). (Scheme 47)
6. To install, reverse removal procedure. Tighten differential cover bolts in sequence in 2 stages. (Scheme 46) For first stage, tighten bolts (1, 2 and 3) by hand. For second stage, tighten bolts (1 through 12) to 17 ft. lbs. (23 N.m).
7. Install right transmission support and heat shield. (Scheme 43)and (Scheme 44).
8. Install axle shaft. See «AXLE SHAFTS - FRONT & REAR»(/audi/a4/b5-1994-1999/remont/axle-shafts/#axle-shafts-front-rear) article in DRIVELINE/AXLES. Check final drive fluid level and correct as necessary. See «CHECKING FLUID LEVELS»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l__checking-fluid-levels) under LUBRICATION.

FRONT DIFFERENTIAL/TRANSAXLE HOUSING DOUBLE SEALING RING

Note. A faulty double sealing ring will allow ATF or gear oil to escape into converter housing through center breather (between 2 sealing lips) of shaft seal. Faulty double sealing ring can also allow ATF to get into differential section of transaxle. Differential section becomes overfilled and oil escapes from breather.

Scheme 44

1. Loosen axle shaft-to-wheel hub bolt while vehicle is standing on its wheels. Remove both front wheels. Remove heat shield for right and left drive axles. Remove both drive axles. See «AXLE SHAFTS - FRONT & REAR»(/audi/a4/b5-1994-1999/remont/axle-shafts/#axle-shafts-front-rear) article in DRIVELINE/AXLES.
2. Prevent drive flange from turning using mandrel and remove center bolt from right drive flange (arrow). (Scheme 45) Using oil siphoning unit (VAG 1358 A), siphon gear oil from final drive. Place drain pan underneath transaxle to catch spilled oil. Pull out right drive flange.
3. Remove heat shield (C). (Scheme 43) Remove bolts (A) and right heat shield (D). Remove transmission support (E). (Scheme 44)
4. Remove bolts for differential cover in reverse order of tightening sequence shown in illustration (start at 12, finish at 1), and remove differential cover. (Scheme 46) Remove differential gear.
5. Remove bearing outer race (1) and adjustment shim (2) from transaxle housing by hand. (Scheme 48) Remove left drive flange. See «LEFT DRIVE FLANGE»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l). Pull out seal using release lever (VW 681). (Scheme 49)
6. Check sealing ring seat in transaxle housing for damage and repair if necessary. Coat outer surface and sealing lips of sealing ring with ATF. Slide double sealing ring onto Pressure Piece (3383). Projecting sealing lip of sealing ring faces tool.
7. Drive double sealing ring for torque converter in to stop using Pressure Piece (3383). (Scheme 50) Install adjustment shim (2) and outer bearing race (for differential) in transaxle housing by hand, until stopped. (Scheme 48) Do not tilt race.
8. Replace differential cover "O" ring (arrow). (Scheme 47) Install differential gear in transaxle housing. Install differential cover.
9. Tighten bolts in 2 stages in sequence. For first stage, tighten bolts (1, 2 and 3) by hand. For second stage, tighten bolts (1 through 12) to 17 ft. lbs. (23 N.m) in sequence. (Scheme 46)
10. Install right drive flange. Tighten nuts and bolts to specification. See «TORQUE SPECIFICATIONS»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l__torque-specifications). Install axle shaft. See «AXLE SHAFTS - FRONT & REAR»(/audi/a4/b5-1994-1999/remont/axle-shafts/#axle-shafts-front-rear) article in DRIVELINE/AXLES.
11. Check final drive fluid level and correct as necessary. See «CHECKING FLUID LEVELS»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l__checking-fluid-levels) under LUBRICATION.

Scheme 45

1. Remove left front and right front exhaust pipes. Remove heat shield for selector lever cable. Unbolt selector lever cable heat shield.
2. On models equipped with all wheel drive, remove center differential. See «CENTER DIFFERENTIAL»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l). Remove front final drive intermediate flange bolts (arrows). (Scheme 51)
3. On models equipped with front wheel drive, remove front final drive housing cover bolts in reverse order of tightening sequence shown in illustration (start at 14, finish at 1). (Scheme 52)
4. Place hydraulic jack (V.A.G. 1383 A) with universal mount underneath front final drive. Remove front final drive housing cover.
5. On all models, lift off front final drive housing cover.
6. To install, ensure dowel sleeve (arrow A) is located properly. (Scheme 52) Install gasket. Install front final drive housing cover. Tighten bolts in sequence in 2 stages. For first stage, tighten bolts (1, 2 and 3) by hand. When tightening bolts by hand (first stage), ensure gap between cover and transaxle housing decreases uniformly entire way around cover. For second stage, tighten bolts (1 through 14) to specification. See «TORQUE SPECIFICATIONS»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l__torque-specifications).
7. On AWD vehicles, install center differential. See «CENTER DIFFERENTIAL»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l).
8. On vehicles, change or top off ATF after repair. See «CHECKING FLUID LEVELS»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l__checking-fluid-levels) under LUBRICATION.

INTERNAL OIL LINE

Scheme 46

1. Remove valve body. See «VALVE BODY ASSEMBLY»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l).
2. Pry internal oil line off transaxle housing using a screwdriver. (Scheme 53) Replace "O" rings. Insert internal oil line into fitting tool. Open side of fitting tool faces toward outside of transaxle. (Scheme 54)
3. Using a plastic hammer, drive oil line into transaxle housing until fitting tool (3381) makes contact. Ensure oil line is kept straight. Drive both oil line ends in evenly. Install valve body. Fill with ATF, check ATF level and top off as necessary. See «CHECKING FLUID LEVELS»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l__checking-fluid-levels) under LUBRICATION.

Scheme 47

1. Loosen left drive axle-to-wheel hub bolt while vehicle is standing on its wheels. Remove left wheel. Remove left drive axle shaft. See «AXLE SHAFTS - FRONT & REAR»(/audi/a4/b5-1994-1999/remont/axle-shafts/#axle-shafts-front-rear) article in DRIVELINE/AXLES.
2. Place drip tray underneath final drive. Remove fill plug (arrow) on side of final drive. (Scheme 17) Remove approximately 1/2 quart of gear oil from final drive using Suction Device (VAG 1358 A).
3. Remove heat shield for left drive axle. Disconnect harness connector from speedometer vehicle speed sensor (G22). (Scheme 55) Push retaining bracket of sensor downward, turn, and pull out sensor. Remove bracket for connector from drive flange bracket. Remove bracket for left drive flange (arrows). (Scheme 56) Pull out left drive flange.
4. To install left drive flange, reverse removal procedure. Replace "O" ring (arrow B) for left drive flange bracket. (Scheme 57) Check end of left drive flange (arrow) for burrs and sharp edges and deburr if necessary. (Scheme 58) Install left drive flange in transaxle. Tighten nuts and bolts to specification. See «TORQUE SPECIFICATIONS»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l__torque-specifications).
5. Check final drive fluid level and correct as necessary. See «CHECKING FLUID LEVELS»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l__checking-fluid-levels) under LUBRICATION. Install axle shaft. See «AXLE SHAFTS - FRONT & REAR»(/audi/a4/b5-1994-1999/remont/axle-shafts/#axle-shafts-front-rear) article in DRIVELINE/AXLES.

Scheme 48

Scheme 49

Scheme 50

Scheme 51

1. Remove left drive flange. See «LEFT DRIVE FLANGE»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l). Remove circlip for grooved ball (arrow "A"). (Scheme 57)
2. Press drive flange out of drive flange mounting bracket. (Scheme 59) Remove drive flange seal using extractor lever (VW 681).
3. Press grooved ball bearing out of mounting bracket. (Scheme 60)
4. To install, press NEW grooved ball bearing into mounting bracket. (Scheme 61) Coat outer edge and sealing lip of oil seal with gear oil.
5. Drive in new seal to stop, without canting. (Scheme 62)
6. Set speedometer vehicle speed sensor (G22) on drive flange (arrow). (Scheme 63)
7. Press mounting bracket with grooved ball bearing onto drive flange. (Scheme 64)
8. Insert circlip (arrow"A"). (Scheme 57) Install drive flange. See «LEFT DRIVE FLANGE»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l).

Removal & Installation (With Tiptronic Shift Mechanism)

Note. When battery is disconnected, vehicle computer and memory systems may lose memory data. Driveability problems may exist until computer systems have completed a relearn cycle.

Note. Ensure locking cable is not kinked during installation.

Scheme 52

1. To remove cable, shift selector lever into "2" position. On vehicles equipped with anti-theft radio, note radio code. Disconnect negative battery cable. Remove selector lever handle. See «SELECTOR LEVER HANDLE»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l).
2. Remove front center console. See «FRONT CENTER CONSOLE»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l).
3. Disable air bag system and remove steering wheel with air bag. See appropriate AIRBAG article in RESTRAINTS.
4. Turn ignition key to driving position (ignition on) position. Move selector lever to "P" position. Lift up retaining clip of interlock lever, and pull locking cable out of ignition switch. (Scheme 21)
5. Remove cover of center console above shift mechanism. Remove selector lever handle. See «SELECTOR LEVER HANDLE»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l).
6. Shift selector lever into "P" position by pulling pull rod. Ensure ignition switch is off. Using a bent wire or hook, carefully pry out 4 retaining straps (arrow A) from top of shift mechanism cover. (Scheme 67) Retainer straps are difficult to see from above. Under no circumstances may 4 retaining straps (arrow B), which are visible from above, be pried out. If these straps are pried out, circuit board may be destroyed. If retaining straps (arrow A) cannot be pried out with bent wire or hook, center console must be removed to gain better access. Remove shift mechanism cover with guide upward.
7. Press release at connector and pull it downward out of cover. (Scheme 65)
8. Unclip locking cable from securing spring on support bracket. See «SECURING SPRING FOR LOCKING CABLE»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l). Loosen and remove locking cable from cable tie (2). (Scheme 21)
9. To install cable, route locking cable free of kinks. Turn ignition key to "ignition on" position. Install locking cable to ignition switch. Ensure locking device engages. Secure locking cable to air bag sensor with cable tie. Turn ignition switch to LOCK position (ignition off).
10. Move selector lever to "P" position. Clip locking cable into securing spring of shift mechanism housing. See «SECURING SPRING FOR LOCKING CABLE»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l). Hook locking cable bracket into shift mechanism and locking coupling ring in lever (for locking cable).
11. Adjust locking cable. See appropriate procedure in «LOCKING CABLE»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l__locking-cable) under ADJUSTMENTS.

Scheme 53

Scheme 54

1. Disconnect negative battery cable. Remove driver side storage compartment below steering wheel. (Scheme 66) Remove steering column switch.
2. Set ignition switch in "Drive" position. Shift selector lever into position "P". Lift up locking bracket and pull locking cable out of ignition switch. (Scheme 21)
3. Disengage retaining tabs for shift mechanism housing. Remove selector mechanism cover with light track and guide.
4. Unclip locking cable from securing spring at shift mechanism housing by slightly lifting up securing spring. Loosen cable tie at instrument panel support and remove locking cable.
5. To install, reverse removal procedure. Install locking cable without kinking and secure at instrument panel support position using cable tie. Adjust locking cable. See appropriate procedure in «LOCKING CABLE»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l__locking-cable) under ADJUSTMENTS.

To remove securing spring, slightly lift spring at top (arrow "B"). Remove locking cable from shift mechanism. (Scheme 68) To install securing spring, insert spring (arrow "B") from top and hook in at retaining clip (arrow "C"). Align spring so that it is seated evenly in groove (arrow "A"). Slightly lift spring at top (arrow "B") and insert locking cable into shift mechanism. (Scheme 68)

Scheme 55

RADIO

Scheme 56

Scheme 57

Scheme 58

1. Insert radio removal tools (T10057) into release slots (arrows) as shown until they engage. (Scheme 69)and (Scheme 70). Pull radio out of instrument panel using grip rings on release tool. Unlock and disconnect electrical harness connections.
2. Remove radio removal tools before installing radio. Press locking latch (arrow) and remove radio release tools toward front. (Scheme 71)
3. Connect electrical connections to radio. Slide radio evenly into instrument panel, until it engages in assembly frame.

Removal & Installation (Concert)

Scheme 59

Scheme 60

1. Insert removal tools (3344) into front of radio. (Scheme 72)and (Scheme 73). Remove radio from instrument panel. Disconnect electrical connections and antenna wire.
2. Remove radio removal tools before installing radio. Connect electrical connections. Carefully slide radio into instrument panel and engage in mounting frame. Activate anti-theft coding radio operating instructions.

Scheme 61

1. Loosen axle shaft-to-wheel hub bolt while vehicle is standing on its wheels. Remove right front wheel. Remove heat shield for right axle shaft.
2. Remove right drive axle. See «AXLE SHAFTS - FRONT & REAR»(/audi/a4/b5-1994-1999/remont/axle-shafts/#axle-shafts-front-rear) article in DRIVELINE/AXLES.
3. Prevent drive flange from turning using mandrel and remove center bolt from right drive flange (arrow). (Scheme 45) Place drain pan underneath transaxle to catch spilled fluid. Pull out right drive flange. Remove sealing ring for right drive flange with Release Lever (VW 681). (Scheme 74)
4. Drive sealing ring for right drive flange in to stop using Pressure Piece (3382). (Scheme 75)
5. Install right drive flange. Using a drift, secure drive flange against turning, and install bolt for drive flange. Tighten nuts and bolts to specification. See «TORQUE SPECIFICATIONS»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l__torque-specifications).
6. Install axle shaft. See «AXLE SHAFTS - FRONT & REAR»(/audi/a4/b5-1994-1999/remont/axle-shafts/#axle-shafts-front-rear) article in DRIVELINE/AXLES.
7. Install heat shield for right axle shaft. Tighten bolts to specification. See «TORQUE SPECIFICATIONS»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l__torque-specifications). Check final drive fluid level and correct as necessary. See «CHECKING FLUID LEVELS»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l__checking-fluid-levels) under LUBRICATION.

Note. Vehicles may be equipped with a Tiptronic shift mechanism. Selector lever may be shifted from "D" position to Tiptronic gate. This gate allows selector lever to be shifted forward (upshift) or backward (downshift) during vehicle operation.

Scheme 62

Scheme 63

Scheme 64

1. To remove cable, shift selector lever into "P" position. Raise and support vehicle. Remove crossmember below exhaust system (if installed). Disconnect front exhaust pipes with catalytic converter from rear exhaust system and tie them aside.
2. On AWD vehicles, check whether there is a factory marking (colored dot) on driveshaft and at center differential flange. If not, place mating marks on driiveshaft flange and center differential flange. Unbolt drive shaft (1) from transaxle and let it rest on heat shield (2). (Scheme 30) Secure drive shaft using wire at bracket (3).
3. On all vehicles, unbolt heat shield from below shift mechanism housing. Remove cover from shift mechanism housing (arrows). (Scheme 76)
4. Disconnect selector lever cable from shift mechanism housing as follows: Press together ends of securing clip (B) and remove. Pull down locking plate (A) and remove. (Scheme 77) Locking plate is used to secure selector lever cable to mounting bracket. Pull selector lever cable off selector lever.
5. Remove selector lever cable from selector shaft lever (arrow). (Scheme 22) Remove support bracket from transaxle. Release selector lever cable from support bracket. Pull selector lever cable out from shift mechanism housing. Do not kink cable when removing from housing.
6. To install, bring selector shaft lever to "P" position on transaxle. Locking lever must engage in park lock wheel, and both front wheels are blocked (cannot be turned together in a direction). Do not bend or kink selector lever cable. Lightly grease cable eye and cable ends before installing.
7. Insert selector lever cable in shifting mechanism. Connect selector lever cable to selector lever.
8. To position cable for installation, angled end of locking plate must point toward end of selector lever cable. Install locking plate (A) for selector lever cable onto shift mechanism housing. Press together ends of securing clip (B) and slide onto end of selector lever cable. (Scheme 77) Connect selector lever cable to support bracket hand tight.
9. Bolt support bracket to transaxle hand tight. Align selector cable lever in support bracket.
10. Install support bracket-to-transaxle bolts (1), and selector lever cable-to-support bracket bolts (2) to specification. (Scheme 78) Counterhold on hex, and tighten bolts to specification. See «TORQUE SPECIFICATIONS»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l__torque-specifications).
11. Tighten shift mechanism cover nuts to 89 INCH lbs. (10 N.m). Check selector lever cable adjustment, and adjust if necessary. See appropriate procedure in «SELECTOR LEVER CABLE»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l) under ADJUSTMENTS.
12. On AWD vehicles, install drive shaft to transaxle. Replace drive shaft gaskets, and ensure adhesive surface is free of grease. Align drive shaft flanges to original positions, and install NEW self-locking bolts. Tighten bolts to specification. See «TORQUE SPECIFICATIONS»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l__torque-specifications).
13. Install crossmember below exhaust system (if removed). Connect front exhaust pipes with catalytic converter to rear exhaust system. Install heat shield.

Removal & Installation (Without Tiptronic Shift Mechanism)

Note. Do not bend or kink selector lever cable. Lightly grease coupling ring and coupling ends before installing cable. Selector lever cable can be easily removed with selector lever "P" position.

Scheme 65

Scheme 66

1. To remove cable, remove shielding plate (below shift mechanism) for exhaust system. To remove cover, disengage snap lock of cover by pressing in direction of arrow (I). (Scheme 79)
2. Disengage locking clip by pressing both ends together and pull selector lever cable off selector lever. Pull out securing plate for selector lever cable at shift mechanism housing downward. Insert with angled end toward rear and in groove at selector lever cable. (Scheme 79)
3. Pull selector lever cable out of shift mechanism housing. Remove shielding plate for selector lever cable (B). (Scheme 80) Press retaining clip off of selector lever (C) at transaxle. Press ball socket of selector lever cable off selector lever. Loosen bracket from transaxle (D). If necessary, loosen selector lever cable from bracket (E). (Scheme 80)
4. To install cable, reverse removal procedure. Selector lever and sift rod in position "P" (park lock must engage). Lightly grease selector lever cable coupling ring and ball socket prior to installation.
5. Check and adjust selector lever cable. See appropriate procedure in «SELECTOR LEVER CABLE»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l) under ADJUSTMENTS. Tighten all bolts to specification. See «TORQUE SPECIFICATIONS»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l__torque-specifications).

For selector lever handle removal and installation procedures (Scheme 81)

Scheme 67

Scheme 68

Scheme 69

Scheme 70

1. Remove left transmission mount heat shield (C). (Scheme 82)
2. Remove transmission support (E). (Scheme 44) Traditional transmission mount is represented by "D" in illustration. (Scheme 44) Hydraulic transmission mount is represented by "H" in illustration. Items "C" and "B" are not installed on vehicles with hydraulic transmissions bearing (H). Bolt (G) is threaded directly into transmission bearing.
3. Remove multifunction TR switch. See «TRANSAXLE RANGE SWITCH»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l).
4. Drive spring pin (1) out of transaxle selector lever (2) until transaxle selector lever can be removed from selector shaft. (Scheme 83) Using a screwdriver, pierce sealing ring and pull out.
5. To install, apply ATF to circumference and sealing lips of oil seal. Open side of seal faces transaxle. Using appropriate driver, drive in NEW oil seal until driver contacts stop. (Scheme 84) Ensure oil seal remains straight during installation.
6. Install multifunction TR switch. See «TRANSAXLE RANGE SWITCH»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l). Drive back spring dowel sleeve with transmission not yet removed in opposite direction through lever. Slide transmission shift lever onto shift rod and drive in spring dowel. Install transmission support. (Scheme 44)

Transaxle fluid temperature sensor is integrated in transaxle wiring harness. For temperature sensor replacement, see TRANSAXLE WIRING HARNESS .

Scheme 71

Scheme 72

1. Remove noise insulation panel (arrows). see scheme 74
2. Place drain pan under transaxle. Remove drain plug (1). (Scheme 15) Unscrew oil pan bolts in diagonal sequence and remove oil pan. Clean all 4 magnets in recesses of oil pan. Ensure magnets are seated correctly in pan upon installation.
3. Unscrew 2 bolts on ATF screen. see scheme 75 Pull ATF screen off of valve body. To install ATF screen, lubricate seal on intake neck of ATF screen with ATF. Carefully push intake neck of ATF screen into opening of valve body. Install bolts and tighten to specification. See «TORQUE SPECIFICATIONS»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l__torque-specifications).
4. Install NEW oil pan gasket and oil pan. Install oil pan bolts and tighten in diagonal sequence to specification. See «TORQUE SPECIFICATIONS»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l__torque-specifications).
5. Install drain plug and tighten specification. See «TORQUE SPECIFICATIONS»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l__torque-specifications). Fill transaxle with ATF. See «DRAINING & REFILLING»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l) under LUBRICATION.

Note. Transaxle range switch may also be referred to as multifunction TR switch.

Note. Transmission does not need to be supported when only one transmission support is removed.

1. Remove left heat shield (C). (Scheme 82) Remove transmission support (E). (Scheme 44) Traditional transmission mount is represented by "D" in illustration. (Scheme 44) Hydraulic transmission mount is represented by "H" in illustration. Items "C" and "B" are not installed on vehicles with hydraulic transmissions bearing (H). Bolt (G) is threaded directly into transmission bearing.
2. Unbolt multifunctional TR switch from transmission, and pull off form shift rod. see scheme 76
3. To install, center multifunction TR switch on selector shaft. Flat section in splines in switch (3) must align with flat section of selector shaft (1). Turn switch so that drilling (4) on switch housing can be installed on locating pin (2) on transaxle housing. see scheme 76
4. Install bolts and tighten to 71 INCH lbs. (8 N.m). Remainder of installation is reverse of removal procedure.

Scheme 73

TRANSAXLE FLUID TEMPERATURE SENSOR

Transmission Fluid Temperature Sensor is integrated in the transmission wiring harness.

TRANSAXLE RPM SENSOR

Note. On transaxles with hydraulic control system type E17, transaxle RPM sensor for transaxle input signal (inductive sensor) is attached to underside of valve body. On transaxles with hydraulic control system type E18, transaxle RPM sensor for transaxle input speed (Hall effect sensor) is attached to transaxle housing behind valve body.

Removal & Installation (With E17 Valve Body)

1. Remove valve body. See «VALVE BODY ASSEMBLY»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l). Turn valve body over and unplug connector from transaxle RPM sensor (1). see scheme 77 Remove bolts and remove sensor from valve body.
2. Install sensor with spacers (2) and tighten bolts to 61 INCH lbs. (7 N.m). Ensure sensor is installed correctly. Side of sensor with plug contacts faces toward center of valve body. Install connector to sensor. Install valve body.
3. Fill with ATF and check ATF level. See «CHECKING FLUID LEVELS»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l__checking-fluid-levels) under LUBRICATION.

Scheme 74

Removal & Installation (With E18 Valve Body)

1. Remove valve body. See «VALVE BODY ASSEMBLY»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l).
2. Remove bolt (B) and remove transaxle RPM sensor (A). see scheme 78
3. To install reverse removal procedure. Tighten bolt to 80 INCH lbs. (9 N.m).
4. To ensure wiring harness does not become trapped when installing valve body, route wire with connector (C) according to illustration. see scheme 78
5. Fill with ATF and check ATF level. See «CHECKING FLUID LEVELS»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l__checking-fluid-levels) under LUBRICATION.

Scheme 75

Scheme 76

1. Remove oil pan. See «TRANSAXLE OIL PAN & ATF SCREEN»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l).
2. Pull connector off transaxle vehicle speed sensor. see scheme 79
3. Remove bolt and transaxle vehicle speed sensor (2). see scheme 80
4. To install, position speed sensor with spacer (1) and tighten bolt to 61 INCH lbs. (7 N.m).
5. Connect speed sensor connector. Install oil pan. Fill with ATF and check ATF level. See «CHECKING FLUID LEVELS»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l__checking-fluid-levels) under LUBRICATION.

Scheme 77

Scheme 78

Scheme 79

1. Remove valve body. See «VALVE BODY ASSEMBLY»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l).
2. Using a small screwdriver, pry out retaining tabs on solenoid valve connectors, and pull off connectors (A) one at a time. see scheme 82 Disengage wiring harness from retainers (B) on side of valve body.
3. On E17 valve body, turn valve body over, and unplug connector from transaxle RPM sensor (1). see scheme 77 Remove first retaining clip (A) and unclip harness from second retaining clip (B). Disconnect connector (3) from solenoid valve.
4. Only for E18 valve body, turn valve body on its back side and loosen connector at sensor for transmission RPM (1). see scheme 81 Remove retaining clip (arrow A) and unclip wiring harness from retaining clip (arrow B).
5. To install, reverse removal procedure. When installing wiring harness, plug connectors onto respective solenoid valves. Clip wiring harness into retaining clips. If not installed correctly, wiring harness can be trapped when valve body is installed.
6. Install valve body. See «VALVE BODY ASSEMBLY»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l). Fill with ATF and check ATF level. See «CHECKING FLUID LEVELS»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l__checking-fluid-levels) under LUBRICATION.

Note. Transaxle uses 2 different hydraulic control system valve body designs. Valve bodies are identified as E17 and E18. Following procedures apply to both valve body designs. For valve body exploded views see scheme 83and see scheme 84.

Scheme 80

Scheme 81

Scheme 82

Scheme 83

Scheme 84

1. Remove oil pan and oil ATF screen. See «TRANSAXLE OIL PAN & ATF SCREEN»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l). Disconnect clip for wiring harness connectors (arrows). see scheme 85
2. On vehicles equipped with E17 valve body, pull connector (arrow or "A") off transaxle vehicle speed sensor. see scheme 79 On vehicles equipped with E18 valve body, pull connector (A) off transaxle vehicle speed sensor. see scheme 86 Pull connector (B) off transaxle RPM sensor.
3. On both valve bodies, ONLY remove bolts from valve body which are marked with an arrow. see scheme 87 On E18 valve body, bolt (A) does not apply and should be ignored. On E17 valve body, bolt (A) is shorter than all other bolts.
4. On both valve bodies, do not remove any other bolts as this could influence function of valve body. Detach valve body from transaxle and guide out connector on wiring harness.
5. To install, reverse removal procedure. On E18 valve body, to ensure wiring harness does not become trapped when installing valve body, route wire with connector (C) according to illustration. see scheme 78
6. On both valve bodies, lubricate NEW "O" rings for connector on wiring harness with ATF. Insert wiring harness connector into transmission housing. Place valve body in position so that pin of detent plate (1) engages in slot on selector slide (2). see scheme 88
7. Tighten bolts (arrows) hand tight, securing valve body. On E18 valve body, bolt (A) does not apply and should be ignored. On E17 valve body, bolt (A) is shorter than all other bolts. see scheme 87
8. Tighten valve body bolts to specification, working from inside of valve body outward. See «TORQUE SPECIFICATIONS»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l__torque-specifications).
9. Connect transaxle vehicle speed sensor connector. Pull up wire to transaxle RPM sensor (if equipped) between valve body and wiring harness.
10. On E18 valve body, pull wiring with connector (B) of sensor for transmission RPM (G182) between valve body and wiring harness upward and reconnect harness connector. see scheme 86 Connect harness connector (C) to transmission vehicle speed sensor (G38). On E17 valve body, connect harness connector (arrow) to transmission vehicle speed sensor (G38). see scheme 79
11. On all valve bodies, connect clip to wiring harness connector (arrow). see scheme 85 Install ATF screen and oil pan. See «TRANSAXLE OIL PAN & ATF SCREEN»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l).
12. Fill transaxle with ATF, check ATF level and top off. See «DRAINING & REFILLING»(/audi/a4/b5-1994-1999/remont/automatic-trans/#servicing-at-01v-with-18l-27l-28l).

Remove heat shield for left drive axle. Disconnect harness connector from speedometer vehicle speed sensor (G22). (Scheme 55) Push retaining bracket of sensor downward, turn, and pull out sensor.

To install, replace sealing rings (arrows). Insert "O" rings with grease. Insert sensor. Engage retaining bracket at mounting bracket for flange shaft.

TORQUE SPECIFICATIONS

TORQUE SPECIFICATIONS

See also:
• AXLE SHAFTS - FRONT & REAR
• 01V Transaxle (With Auxiliary ATF Cooler)
• DRAINING & REFILLING
• RECOMMENDED FLUIDS
• TORQUE SPECIFICATIONS
• CHECKING FLUID LEVELS
• ADJUSTMENTS
• REMOVAL & INSTALLATION
• SHIFT MECHANISM
• RADIO
• LOCKING CABLE
