CONTACT CORROSION
Contact corrosion can occur if incorrect fasteners (bolts, nuts, washers, etc.) are used.
For this reason, only fasteners with a special surface coating are used.
In addition, rubber or plastic parts and adhesive consist of non-conductive materials.
If there are doubts as to whether parts are suitable or not, use new parts.
Note. We only recommend original replacement parts, they have been tested and are compatible with aluminum. We recommend using Audi accessories. Damage resulting from contact corrosion is not covered by warranty.
WINDSHIELD WIPERS, BRINGING INTO SERVICE POSITION
Note. If the windshield wiper motor is to be run during the work procedure, the hood must be closed, otherwise the voltage supply of the wiper motor will be interrupted.
Make sure the wiper blades are not frozen.
Briefly switch ignition on and off again.
Activate one-touch wiping within 10 seconds.
- The windshield wipers run into service position.
Vehicles with Driver Information System
Scheme 36
Switch on ignition.
Press the Reset button -1- on the windshield wiper switch until the menu display appears.
Select the desired menu item by pressing the wiper switch -2- and confirm the respective end position by pressing the Reset button
| Adjusting | ||||
|---|---|---|---|---|
| Wiper | ||||
| Front | ||||
| Service Position | ||||
- The windshield wipers run into service position.
All Vehicles
Turn off the ignition.
| CAUTION | Risk of damaging the hood by running the wipers back in basic position. Do not drive a vehicle with windshield wiper arms folded up. The windshield wipers automatically go back into their rest position when the wiper switch is activated or when driving faster than 6 km/h. |
Scheme 37
- Connecting Pipe For nozzle
- Securing Nut 12 Nm
- Spray Nozzle Removing and installing, refer to «REAR WINDOW SPRAY NOZZLE»(ref-496034-S09275245032012082100000) Adjusting, refer to «REAR WINDOW SPRAY NOZZLE, ADJUSTING»(ref-496034-S00195786352012082100000)
- Cap for Rear Wiper
- Wiper Arm Removing and installing, refer to «REAR WINDOW WIPER ARM»(ref-496034-S16442633952012082100000)
- Wiper Blade Replacing, refer to «REAR WINDOW WINDSHIELD WIPER BLADES»(ref-496034-S31044246232012082100000)
Scheme 38
- Securing Nut 8 Nm
- Windshield Wiper Motor Removing and installing, refer to «REAR WINDOW WIPER MOTOR»(ref-496034-S19764325852012082100000)
- Rubber Seal
- Washer Fluid Hose
WINDSHIELD WIPER ARMS, ADJUSTING
Procedure
Note. If the windshield wiper motor is to be run during the work procedure, the hood must be closed, otherwise the voltage supply of the wiper motor will be interrupted.
Remove wiper arms, refer to WINDSHIELD WIPER ARMS .
Switch on ignition.
Activate one-touch wiping and let wiper motor run in end position.
Note. Every second time the wiper motor is switched off, it returns the wiper arms to a slightly upper rest position, thus tipping the wiper blade lips the other way. The wiper motor will run all the way down to the end position and then a bit up again. This upper rest position must not be used to adjust the wiper crank. Only use end position where wiper arms run directly end position with no overstroke. Activate one-touch wiping again if necessary.
Turn off the ignition.
Position wiper arm with wiper blade installed at wiper axle and align wiper blade at windshield as follows
Scheme 39
- Dimension -a- = 0 to 10 mm.
- Dimension -b- = 0 to 10 mm.
Note. The dimensions indicate the gap between the wiper blades to cowl panel of plenum chamber at lower edge of windshield.
Tighten the nuts -2- for the wiper arms -1-.
Scheme 40
Switch on ignition.
Activate one-touch wiping and let wiper arms run in end position.
Turn off the ignition.
Check adjustment of wiper arms again, correct if necessary.
Press the caps -arrows- onto the wiper arms.
Tightening Specifications
| Component | Nm |
|---|---|
| Wiper arm nut | 17 |
SPRAY NOZZLES, ADJUSTING, THROUGH 05.2008
Special tools and workshop equipment required
- Windshield washer aiming tool T40187 equipped with Replacement tip 3125/5A
Adjusting
Scheme 41
Note. The settings indicate the values for a moving vehicle, i.e. the spray from the jets is slightly offset when the vehicle is stationary.
Mark the four points on windshield using a water soluble marker
- Dimension -a- = 270 mm
- Dimension -b- = 460 mm
- Dimension -c- = 540 mm
- Dimension -d- = 385 mm.
Scheme 42
| WARNING | Risk of injury. If the windshield washer aiming tool T40187 is not used, ensure that both sides are always covered and secured by covers -3- and -4-. If one side is not secured by the cover, injury can be caused by the needle 3125/5A -1- or adjusting pin -2-. When opening each side, always ensure that the other side is not pointing toward the hand. |
Unlock the short cover -1- on the T40187 -arrow A- and push it back -arrow B-.
Scheme 43
Install the 3125/5A -2- into the spray nozzle -arrow- in the spray nozzle unit -1- and aim at the points on the windshield and adjust if necessary.
Scheme 44
If the spray field does not correspond to the specifications, clean dirty spray jet.
| WARNING | Risk of injury. The adjusting pin must be covered and secured by the cover after each use. |
Cleaning the nozzle
Remove nozzle. Refer to SPRAY NOZZLES .
Flush nozzle opposite to spray direction using clear water.
To remove remaining impurities, the nozzle must only be blown out opposite to spray direction using compressed air.
If the spray field still does not correspond to the specifications, replace the spray jet.
SPRAY NOZZLES, ADJUSTING, FROM 06.2008
Special tools and workshop equipment required
- Windshield Washer Aiming Tool T40187 equipped with Replacement Tip 3125/5A
Adjusting
Scheme 45
Note. The settings indicate the values for a moving vehicle, i.e. the spray from the jets is slightly offset when the vehicle is stationary.
Mark the six points on windshield using a water soluble marker
| Dimensions in mm | Driver side | Passenger side | |
|---|---|---|---|
| A | = | 335 | 335 |
| B | = | 570 | 570 |
| C | = | 380 | 380 |
| D | = | 335 | 335 |
| E | = | 590 | 590 |
| F | = | 185 | 185 |
| WARNING | Risk of injury. If the windshield washer aiming tool T40187 is not used, ensure that both sides are always covered and secured by covers -3- and -4-. If one side is not secured by the cover, injury can be caused by the needle 3125/5A -1- or adjusting pin -2-. When opening each side, always ensure that the other side is not pointing toward the hand. |
Unlock long cover -1- on the T40187 -arrow A- and push it back -arrow B-.
Scheme 46
Place adjusting pin -2- on the respective nozzle -arrow- of nozzle unit -1- and aim at the points on the windshield and adjust if necessary.
Scheme 47
If the spray field does not correspond to the specifications, clean dirty spray jet.
| WARNING | Risk of injury. The adjusting pin must be covered and secured by the cover after each use. |
Cleaning the nozzle
Remove nozzle. Refer to SPRAY NOZZLES .
Flush nozzle opposite to spray direction using clear water.
To remove remaining impurities, the nozzle must only be blown out opposite to spray direction using compressed air.
If the spray field still does not correspond to the specifications, replace the spray jet.
REAR WINDOW SPRAY NOZZLE, ADJUSTING
Special tools and workshop equipment required
- Windshield washer aiming tool T10127 fitted with replacement tip 3125/5 A
Procedure
Scheme 48
Adjust nozzles using T10127 so that the water jets are sprayed onto the rear window above the wipers at the points shown.
- Dimension -a- = approximately 125 mm.
- Dimension -b- = approximately 295 mm.
- Dimension -c- = approximately 5 mm.
If the spray field does not correspond to the specifications, clean dirty spray jet.
Cleaning the nozzle
Remove nozzle. Refer to REAR WINDOW SPRAY NOZZLE .
Flush nozzle opposite to spray direction using clear water.
To remove remaining impurities, the nozzle must only be blown out opposite to spray direction using compressed air.
If the spray field still does not correspond to the specifications, replace the spray jet.
REAR WINDOW WIPER ARM, ADJUSTING
Procedure
Scheme 49
Position wiper arm with wiper blade installed at wiper axle and align wiper blade at rear window as follows
- Dimension -a- = 15 to 20 mm.
Note. Dimension is the gap between tip of wiper blade and lower edge of window.
Switch on ignition.
Activate the rear window wiper and allow the wiper arm to move to end position.
Check adjustment of wiper arm again, correct if necessary.
Tightening Specifications
| Component | Nm |
|---|---|
| Wiper arm nut | 12 |
HEADLAMP SPRAY NOZZLES, ADJUSTING
Note. The nozzles are already adjusted by the manufacturer and must not be adjusted after installation.
WIPER BLADE, OLD VERSION
Observe notes on contact corrosion. Refer to CONTACT CORROSION .
Removing
Scheme 50
Bring windshield wiper into service position. Refer to WINDSHIELD WIPERS, BRINGING INTO SERVICE POSITION .
Lift the wiper arm off the windshield and turn the wiper blade 90° -arrow 1-.
Remove the wiper blade from the wiper arm axle -arrow-.
Installing
| CAUTION | There is a risk of damaging the body. The driver and passenger side wiper blades are different lengths. |
Install in reverse order of removal, noting the following
If the windshield wiper switch is operated or a speed of 6 km/h is exceeded, the wipers leave the service position.
WIPER BLADE, NEW VERSION
Observe notes on contact corrosion. Refer to CONTACT CORROSION .
Removing
Scheme 51
Bring windshield wiper into service position. Refer to WINDSHIELD WIPERS, BRINGING INTO SERVICE POSITION .
Raise the wiper arm off the windshield.
Compress clip -arrows 1-.
Push wiper blade off wiper arm -arrow 2-.
Remove wiper blade.
Installing
| CAUTION | There is a risk of damaging the body. The driver and passenger side wiper blades are different lengths. |
Install in reverse order of removal, noting the following
Guide wiper arm tab -2- into wiper blade -1- -arrow-.
Scheme 52
If the windshield wiper switch is operated or a speed of 6 km/h is exceeded, the wipers leave the service position.
WINDSHIELD WIPER ARMS
Special tools and workshop equipment required
- Windshield wiper arm tool set T10369
Observe notes on contact corrosion. Refer to CONTACT CORROSION .
Removing
Note. If the windshield wiper motor is to be run during the work procedure, the hood must be closed, otherwise the voltage supply of the wiper motor will be interrupted.
Switch on ignition.
Activate one-touch wiping and allow wiper arms to move to end position.
Switch off ignition and remove ignition key.
Using a screwdriver, pry the caps -arrows- off the wiper arms -1-.
Loosen the nuts -2- one turn.
Position the T10369/1 on the wiper arm -1- as illustrated.
Scheme 53
Position the thrust piece -2- on the wiper axle.
Rotate the bolt -3- clockwise until the wiper arm is removed from the axle.
Remove nuts completely and remove wiper arms.
Installing
| CAUTION | There is a risk of damaging the body. The driver and passenger side wiper arms are different lengths. |
Install in reverse order of removal, observing the following
Adjust wiper arms. Refer to WINDSHIELD WIPER ARMS, ADJUSTING .
WIPER MOTOR WITH WIPER MOTOR CONTROL MODULE, THROUGH 05.2008
Special tools and workshop equipment required
- Pry lever 80-200
Observe notes on contact corrosion. Refer to CONTACT CORROSION .
The Wiper Motor Control Module -J400- is integrated in the windshield wiper motor.
Removing
| CAUTION | Danger of damaging the plenum chamber cover. Coat the transition between the windshield and cowl panel trim -2- with some soapy water and carefully pull the cowl panel trim vertically out of the retainer on the windshield beginning at the edge of the window. |
| CAUTION | Danger of damaging the paint. Protect the fender from scratches with adhesive tape. |
Scheme 54
Remove wiper arms. Refer to WINDSHIELD WIPER ARMS .
Remove the spray nozzles -arrow-.
Push the spray jet with the lines connected through the opening in the plenum chamber.
Remove the rubber seal -1- in the plenum chamber -2-.
Scheme 55
Remove plenum chamber cover -2- by carefully removing cover from retainer on windshield.
Scheme 56
Disconnect electrical connector -2-.
Remove bolts -1- and -3-.
Lift the wiper arm frame with the linkage and wiper motor and remove it toward the left and out of the plenum chamber.
Installing
Install in reverse order of removal, noting the following
Install wiper motor with wiper frame in vehicle.
Adjust wiper arms. Refer to WINDSHIELD WIPER ARMS, ADJUSTING .
Tightening Specifications
| Component | Nm |
|---|---|
| Wiper frame to plenum chamber | 8 |
WINDSHIELD WIPER MOTOR WITH WIPER MOTOR CONTROL MODULE, FROM 06.2008
Special tools and workshop equipment required
- Pry lever 80-200
Observe notes on contact corrosion. Refer to CONTACT CORROSION .
The Wiper Motor Control Module -J400- is integrated in the windshield wiper motor.
Removing
| CAUTION | Danger of damaging the plenum chamber cover. Coat the transition between the windshield and cowl panel trim -2- with some soapy water and carefully pull the cowl panel trim vertically out of the retainer on the windshield beginning at the edge of the window. |
Remove wiper arms. Refer to WINDSHIELD WIPER ARMS .
Remove the spray nozzles -arrow-.
Push the spray jet with the lines connected through the opening in the plenum chamber.
Remove the seal -1-.
Remove plenum chamber cover -2- by carefully removing cover from retainer on windshield.
Scheme 57
| CAUTION | Danger of damaging the paint. Protect the suspension strut dome from scratches with adhesive tape. |
Turn the wiper arm linkage -4- until it is parallel to the body.
Disconnect the electrical connector -5-.
Remove the bolts -arrows-.
Pull the wiper frame with the linkage and wiper motor -1- far enough forward until the retaining pin -2- no longer is inside the mount -3-.
Remove the wiper frame with linkage and the wiper motor from the plenum chamber.
Installing
Scheme 58
Install in reverse order of removal, observing the following
Install the wiper frame -1- with linkage and the wiper motor into the plenum chamber; when doing this, the retaining pin -3- must fit into the mount -4- on the body -arrow-.
Tighten the screws -2- and -5-.
Adjust wiper arms. Refer to WINDSHIELD WIPER ARMS, ADJUSTING .
Tightening Specifications
| Component | Nm |
|---|---|
| Wiper frame to plenum chamber | 8 |
WINDSHIELD WIPER MOTOR WITH WIPER MOTOR CONTROL MODULE
Observe notes on contact corrosion. Refer to CONTACT CORROSION .
If the control module was replaced, select the Replace function for the respective control module in Guided Fault Finding or Guided Functions.
Select the function or path
| Vehicle brand | |||||
|---|---|---|---|---|---|
| Engine codes | |||||
| 09 - Electronic central electrical | |||||
| J400 - Replacing (repair group 92) | |||||
Follow the instructions on the Vehicle Diagnosis Tester display.
Remove the wiper motor. Vehicles through 05.08, refer to WIPER MOTOR WITH WIPER MOTOR CONTROL MODULE, THROUGH 05.2008 , vehicles from 06.08, refer to WINDSHIELD WIPER MOTOR WITH WIPER MOTOR CONTROL MODULE, FROM 06.2008 .
Pry the drive rod -arrow- off the wiper motor crank using the pry lever 80-200.
Scheme 59
Remove nut -1-.
Scheme 60
Remove the crank -2- from the wiper motor.
Remove wiper motor from wiper frame -arrows-.
Bolt wiper motor without crank onto wiper frame -arrows-.
Scheme 61
Connect electrical connector.
Switch on ignition.
Perform next program step in Guided Functions.
Note. The Replace function in Guided Functions switches the wiper motor alternating park position off. The wiper motor then runs always to the lower park position which is the one for adjustment.
Activate one-touch wiping and let wiper motor run in end position.
Switch off ignition and remove ignition key.
Align crank -2- toward wiper frame.
Scheme 62
- Dimension -a- = 3 0.2 mm.
Keep crank in position and hand-tighten nut -1- in order to maintain this position.
Then, counterhold the crank in position using an open-end wrench and tighten nut.
Switch on ignition.
Activate one-touch wiping and let wiper motor run in end position.
Check if dimension -a- is reached; align again if necessary.
Switch off ignition and remove ignition key.
Install the wiper motor. Vehicles through 05.08, refer to WIPER MOTOR WITH WIPER MOTOR CONTROL MODULE, THROUGH 05.2008 , vehicles from 06.08, refer to WINDSHIELD WIPER MOTOR WITH WIPER MOTOR CONTROL MODULE, FROM 06.2008 .
Tightening Specifications
| Component | Nm |
|---|---|
| Wiper motor to wiper frame | 9 |
| Wiper crank to wiper motor | 18 |
WINDSHIELD WASHER SYSTEM, THROUGH 05.2008
Observe notes on contact corrosion. Refer to CONTACT CORROSION .
SPRAY NOZZLES
Removing
Switch off ignition and remove ignition key.
Remove the nozzle from the plenum chamber cover -arrow-.
Disconnect the water hose connection from the nozzle.
If equipped, disconnect the connector for the nozzle heating.
Installing
Install in reverse order of removal, noting the following
- Washer fluid hose must engage audibly into spray jet connector.
WINDSHIELD WASHER SYSTEM, FROM 06.2008
Observe notes on contact corrosion. Refer to CONTACT CORROSION .
WINDSHIELD WASHER PUMP
Special tools and workshop equipment required
- Drip tray
Removing
Scheme 63
Switch off ignition and remove ignition key.
Remove the front section of the front right wheel housing liner. Refer to Removal and Installation .
Remove fog lamp. Refer to FOG LAMP, THROUGH 05.2008 .
Disconnect the electrical connector -4-.
Place a drip tray under the windshield washer fluid reservoir.
Release the securing clip -1- in the -direction of the arrow- and remove the washer fluid line -1- from the windshield washer fluid pump.
Remove the windshield washer pump -V5- -item 3- upward out of the washer fluid reservoir.
Installing
Scheme 64
Install in reverse order of removal, observing the following
Check the sealing grommet -1- for damage.
From above, push the windshield washer pump -V5- -item 2- into the windshield washer fluid reservoir; while doing this the washer fluid pump is guided by both mounting tabs -arrows-.
Install fog lamp. Refer to FOG LAMP, THROUGH 05.2008 .
Install the front section of the front right wheel housing liner. Refer to Removal and Installation .
Removing
Switch off ignition and remove ignition key.
Remove the nozzle from the plenum chamber cover -arrow-.
Release the securing clip and remove the washer fluid line -3- from the nozzle -1- for the windshield washer system.
Scheme 65
Disconnect the electrical connector -2- if applicable.
Installing
Install in reverse order of removal, observing the following
Make sure the securing clip engages audibly in the washer line connection when connecting the line.
Install the nozzle into the plenum chamber cover.
REAR WINDOW SPRAY NOZZLE
Removing
Scheme 66
Carefully expand ends of caps -3- and lift off from wiper arm -1-.
Carefully remove nozzle -2- from connecting pipe.
Installing
Install in reverse order of removal, observing the following
- Insert nozzle so that spray opening faces cut-out at wiper arm.
REAR WINDOW WIPER ARM
Removing
Scheme 67
Switch on ignition.
Activate the rear window wiper and allow the wiper arm to move to end position.
Switch off ignition and remove ignition key.
Carefully expand cap -arrows- and remove.
Carefully remove nozzle -2- from connecting pipe.
Scheme 68
Loosen hex head nut -1- a few turns.
Loosen wiper arm by tilting slightly from the wiper arm axle, remove the hex nut and then remove the wiper arm.
Installing
Install in reverse order of removal, observing the following
Adjust wiper arm. Refer to REAR WINDOW WIPER ARM, ADJUSTING .
Tightening Specifications
| Component | Nm |
|---|---|
| Wiper arm nut | 12 |
REAR WINDOW WINDSHIELD WIPER BLADES
Removing
Scheme 69
Lift off wiper arm from front rear window.
Release clips -arrows- using a screwdriver and pull wiper blade -2- out of wiper arm -1-.
Installing
Install in reverse order of removal, observing the following
- The wiper blade can only be installed in one position.
- Wiper blade must audibly engage in wiper arm.
REAR WINDOW WIPER MOTOR
Removing
Remove wiper arm. Refer to REAR WINDOW WIPER ARM .
Remove lower luggage compartment lid trim. Refer to Removal and Installation .
Disconnect electrical connector -2-.
Scheme 70
Remove washer fluid hose -1- from spray nozzle connecting hose.
Remove the nuts -arrows- and remove wiper motor.
Installing
Install in reverse order of removal, observing the following
Carefully attach rubber seal in rear window opening.
- Washer fluid hose must engage audibly into spray jet connector.
Switch on ignition.
Activate the rear window wiper and allow the wiper motor to move to end position.
Turn off the ignition.
Install lower rear lid trim. Refer to Removal and Installation .
Adjust wiper arm. Refer to REAR WINDOW WIPER ARM, ADJUSTING .
| Component | Nm |
|---|---|
| Wiper motor to rear lid | 8 |
HEADLAMP WASHER SYSTEM SPRAY NOZZLES
Special tools and workshop equipment required
- Hose clamps up to 25 mm 3094
- Hose clamp pliers V.A.G 1275
Removing
Remove front bumper cover. Refer to Removal and Installation .
Note. Protect bumper cover by laying rag underneath and secure nozzle using pliers.
Pull spray jet covers upward at bumper and carefully unlatch retainers -arrows-.
Scheme 71
Clamp off the windshield washer fluid hose -1- with hose clamps 3094.
Scheme 72
Note. Lay a cloth under the point of separation to catch any washer fluid.
Disconnect water hose -1- from nozzle -4-.
Remove the bolts -2- and -3- and remove the spray nozzle.
Installing
Install in reverse order of removal, noting the following
Note. Secure all hose connections using standard hose clamps.
Install hose clamps with Hose Clamp Pliers V.A.G 1275.
Install the front bumper cover. Refer to Removal and Installation .
Tightening Specifications
| Component | Nm |
|---|---|
| Spray jet to bumper | 2.5 |
HEADLAMP WASHER PUMP
Special tools and workshop equipment required
- Drip tray
Removing
Scheme 73
Switch off ignition and remove ignition key.
Remove the front section of the front right wheel housing liner. Refer to Removal and Installation .
Remove fog lamp. Refer to FOG LAMP, THROUGH 05.2008 .
Disconnect the electrical connector -4-.
Place a drip tray under the windshield washer fluid reservoir.
Release the securing clip -2- in the -direction of the arrow- and remove the washer fluid line -1- from the headlamp washer pump.
Remove the headlamp washer pump -V11- -item 3- upward out of the washer fluid reservoir.
Installing
Scheme 74
Install in reverse order of removal, observing the following
Check the sealing grommet -1- for damage.
From above, push the headlamp washer pump -item 2- into the windshield washer fluid reservoir; while doing this the pump is guided by both mounting tabs -arrows-.
Install fog lamp. Refer to FOG LAMP, THROUGH 05.2008 .
Install the front section of the front right wheel housing liner. Refer to Removal and Installation .
Special tools and workshop equipment required
- Hose clamps up to 25 mm 3094
Left side of the vehicle
Remove the front wheel housing liner. Refer to Removal and Installation .
Right side of the vehicle
Remove front bumper cover. Refer to Removal and Installation .
Continuation for both sides of the vehicle
Clamp off the windshield washer fluid hose -1- with hose clamps 3094.
Note. Lay a cloth under the point of separation to catch any washer fluid.
Press release button -2- and detach fluid hose -1-.
Release the nozzle retaining springs upward -arrows- and at the same time remove the nozzle -3- toward the rear from the retainer.
Installing
Install in reverse order of removal, observing the following
The nozzle retaining springs must audibly engage.
Left side of the vehicle
Install the front wheel housing liner. Refer to Removal and Installation .
Right side of the vehicle
Install the front bumper cover. Refer to Removal and Installation .
