FASTENER TIGHTENING SPECIFICATIONS
| Component | Fastener Size | Nm |
|---|---|---|
| Decorative Trim to Wheel Rim Bolt | 5 | |
| Metal Valve to Wheel Rim Union Nut | Refer to UNION NUT TIGHTENING SPECIFICATION | |
| Wheel Electronics to Metal Valve Microencapsulated Bolt, Beru System | 4 |
WHEEL BOLT TIGHTENING SPECIFICATIONS
| CAUTION | In order to make sure the wheel bolts fit correctly, be use to use the correct wheel bolts specified for the model. The wheel bolts for each model have different diameters on the surface of the ball running surface on the wheel rim and they have different lengths. |
| Model | Model | Tightening Specification |
|---|---|---|
| RS 2 | 895 | 130 Nm |
| RS 4 | 8D | 140 Nm |
| A1 | 8X | 120 Nm |
| A2 | 8Z | 120 Nm |
| A3 | 8P | 120 Nm |
| S3 | 8P | 120 Nm |
| A3 Cabrio | 8P | 120 Nm |
| A4 | 8E | 120 Nm |
| S4 | 8E | 120 Nm |
| RS 4 | 8E | 120 Nm |
| A4 B8 | 8K | 120 Nm |
| S4 B8 | 8K | 120 Nm |
| A4 allroad | 8K | 120 Nm |
| RS 4 B8 | 8K | 120 Nm |
| A5 Coupe | 8T | 120 Nm |
| S5 Coupe | 8T | 120 Nm |
| A5 Sportback | 8T | 120 Nm |
| A5 Cabrio | 8F | 120 Nm |
| S5 Cabrio | 8F | 120 Nm |
| RS -5 | 8T | 120 Nm |
| A6 | 4B / 4F / 4G | 120 Nm |
| A6 allroad | 4B / 4F | 120 Nm |
| S6 | 4B / 4F | 120 Nm |
| RS 6 | 4B / 4F | 120 Nm |
| A7 | 4G | 120 Nm |
| A8 | 4D / 4E / 4H | 120 Nm |
| TT | 8N / 8J | 120 Nm |
| R8 | 42 | 120 Nm |
| Q5 | 8R | 140 Nm |
| Q7 | 4L | 160 Nm |
| Q7 - 12-cylinder | 4L | 160 Nm |
| Pax wheels A6 | 4B / 4F | 120 Nm |
| Pax wheels A8 | 4D / 4E / 4H | 140 Nm |
| A 6 (security) | 4B / 4F | 120 Nm |
| A 8 (security) | 4D / 4E / 4H | 140 Nm |
| All other Audi models | 120 Nm |
SPECIFICATIONS FOR RADIAL AND LATERAL RUN-OUT ON WHEEL
| Steel Wheel | Radial Run-Out | Lateral Run-Out |
|---|---|---|
| Steel wheel | 0.5 mm | 0.5 mm |
| Aluminum wheel | 0.3 mm | 0.3 mm |
Note. If the measured value exceeds the specified value, no acceptable smooth running can be attained.
UNION NUT TIGHTENING SPECIFICATION
| Model, Type | System | Country | Nm |
|---|---|---|---|
| A1, 8X | TPMS + indirect measuring (2) | USA and rest of the world | |
| A3, 8P | Direct measuring, Siemens (3) | USA | 8 Nm |
| A3, 8P | TPMS + indirect measuring (1) | Rest of the world | |
| A4, 8E | Direct measuring, Beru (3) | USA and rest of the world | 4 Nm |
| A4, 8K | Direct measuring, Siemens (3) | USA | 8 Nm |
| A4, 8K | TPMS + indirect measuring (2) | Rest of the world | |
| A5, 8T | Direct measuring, Siemens (3) | USA | 8 Nm |
| A5, 8T | TPMS + indirect measuring (2) | Rest of the world | |
| S5, 8T | Direct measuring, Siemens (3) | USA | 8 Nm |
| S5, 8T | TPMS + indirect measuring (2) | Rest of the world | |
| A5, S5 Cabriolet 8F | Direct measuring, Siemens (3) | USA | 8 Nm |
| A5, S5 Cabriolet 8F | TPMS + indirect measuring (2) | Rest of the world | |
| A6, 4B | Direct measuring, Beru (3) | USA and rest of the world | 4 Nm |
| A6, 4F | Direct measuring, Beru (3) | USA and rest of the world | 4 Nm |
| RS 6, 4F | Direct measuring, Beru (3) | USA and rest of the world | 6 Nm |
| A6, 4G | TPMS + indirect measuring (2) | USA and rest of the world | |
| A7, 4G | TPMS + indirect measuring (2) | USA and rest of the world | |
| A8, 4E | Direct measuring, Beru (3) | USA and rest of the world | 4 Nm |
| A8, 4H | TPMS + indirect measuring (2) | USA and rest of the world | |
| Q5, 8R | Direct measuring, Siemens (3) | USA | 8 Nm |
| Q7, 4L | Direct measuring, Beru (3) | USA and rest of the world | 4 Nm |
| Q7, 4L, 12-cylinder | Direct measuring, Beru (3) | USA and rest of the world | 4 Nm |
| TT, 8J | Direct measuring, Siemens (3) | USA | 8 Nm |
| TT, 8J | TPMS + indirect measuring (2) | Rest of the world | |
| R8, 42 | Direct measuring, Beru (3) | USA and rest of the world | 6 Nm |
| (1) TPMS indirect measuring. There are no wheel electronics installed inside the wheel. With the help of the ABS sensors, the TPMS compares the rolling circumference of the individual wheels. The loss of pressure is determined indirectly. If there is a change in the tire pressure, then the speed of the tire will also change. (2) TPMS + indirect measuring. There are no wheel electronics installed inside the wheel. With the help of the ABS sensors, the TPMS compares the speed and rolling circumference of the individuals wheels. The loss of pressure is determined indirectly. If there is a change in the tire pressure, then the speed and the rolling circumference of wheel will also change. (3) TPMS direct measuring. The wheel electronics are installed inside the wheel on the metal valve; the tire pressure and temperature values are transmitted and evaluated periodically. | |||
| (1) | TPMS indirect measuring. There are no wheel electronics installed inside the wheel. With the help of the ABS sensors, the TPMS compares the rolling circumference of the individual wheels. The loss of pressure is determined indirectly. If there is a change in the tire pressure, then the speed of the tire will also change. |
| (2) | TPMS + indirect measuring. There are no wheel electronics installed inside the wheel. With the help of the ABS sensors, the TPMS compares the speed and rolling circumference of the individuals wheels. The loss of pressure is determined indirectly. If there is a change in the tire pressure, then the speed and the rolling circumference of wheel will also change. |
| (3) | TPMS direct measuring. The wheel electronics are installed inside the wheel on the metal valve; the tire pressure and temperature values are transmitted and evaluated periodically. |
All other models: 4 Nm
Secure against turning with counterhold -1- (for example, a 2 mm drill bit).
Scheme 1
Note. Be careful not to scratch off the glued- on wheel trim on these rims. The surface of the wheel trim is very sensitive. The rim will have be replaced if the wheel trim is damaged. The wheel trim cannot be replaced.
