DATA BUS ON BOARD DIAGNOSTIC INTERFACE

General Information

  1. Data bus on board diagnostic interface -J533- interlink the different CAN bus systems in the vehicle.
  2. It transmits data from e.g. the engine control module (drivetrain CAN bus) to the instrument cluster (instrument cluster CAN bus).
  3. Fault finding is done in Guided Fault Finding.
  4. Repairing CAN Bus lines. Refer to General Information .

DATA BUS ON BOARD DIAGNOSTIC INTERFACE CONNECTOR

20-pin connector, black

Scheme 2

Scheme 2: DATA BUS ON BOARD DIAGNOSTIC INTERFACE CONNECTOR
  1. Battery + (terminal 30)
  2. Battery + (terminal 30)
  3. Reserved for external diagnosis
  4. Reserved for K-lead
  5. Comfort CAN bus Low
  6. Powertrain CAN bus Low
  7. Reserved for shielding
  8. CAN Bus instrument cluster Low
  9. Diagnostic CAN bus Low
  10. CAN-Bus Infotainment Low
  11. ground - (terminal 31)
  12. ground - (terminal 31)
  13. Instrument cluster prompt input
  14. Terminal 15
  15. Comfort CAN bus high
  16. Power CAN bus high
  17. Reserved for shielding
  18. CAN Bus instrument cluster High
  19. Diagnostic CAN bus High
  20. CAN-Bus Infotainment High

Removing

If the control module was replaced, select the Replace function for the respective control module in Guided Fault Finding or Guided Functions.

Select the function or path

Vehicle brand
Engine codes
19 - Diagnose interface for data bus
J533 - replacing the diagnosis interface for the data bus (Repair Group 90)

Follow the instructions on the Vehicle Diagnosis Tester display.

Switch off ignition and remove ignition key.

Remove driver's storage compartment. Refer to Removal and Installation .

Remove the screw -arrow- and then remove the air guide -1-.

Scheme 3

Scheme 3

Release retaining clips -1- and -6- by pressing them together -arrows-.

Scheme 4

Scheme 4

Disengage retaining tab -2- on bracket -3-.

Disconnect the connector -4- and remove the data bus on board diagnostic interface -J533- -item 5-.

Installing

Install in reverse order of removal, noting the following

If the data bus on board diagnostic interface was replace, it must be coded again.

Select the function or path

Vehicle brand
Engine codes
19 - Diagnose interface for data bus
J533 - Diagnosis interface for data bus, coding

Follow the instructions on the Vehicle Diagnosis Tester display.

Install air duct. Refer to Removal and Installation or Removal and Installation .

Install driver's storage compartment. Refer to Removal and Installation .
