Communication: Other Audi A3 8P facelift

RADIO SYSTEMS

Radio Systems

1. "Chorus"
2. "Concert"
3. "Symphony"

Speaker Systems

1. Active speakers (rear speakers use Amplifier/Woofer (in left rear luggage compartment) -R44-).
2. BOSE sound

Radio Preparation

4 or 6 passive speakers and rear window antennas.

General Information

From KW 22/04, the "chorus" has a second antenna connection (IF).

Radio generation II+ introduced from KW 45/06.

This uses two internal tuners with "phase diversity" for reception.

Further removal steps are the same as with the "symphony" radio.

Besides switching diversity, "phase diversity" is the second procedure for reducing reception interference.

At least two antennas with an amplifier and a radio -R- with two tuners are required.

If the signal received is interrupted, both signals are digitalized and separated in the tuners in the radio so that the disrupted signals are blocked out as much as possible.

If the reception signal is not disrupted, the radio constantly compares which antenna has the strongest reception. This is then transferred.

In this case, the second tuner checks the frequency band in the background for better reception frequencies for the selected station. If a better signal is found, this tuner switches to reception and the other to the background.

Communication with other vehicle systems takes place via the Infotainment CAN-Bus and Data Bus On Board Diagnostic Interface -J533-.

Fault finding is performed via "Guided Fault Finding" using the Vehicle Diagnosis, Testing & Information SystemVAS5051.

Repairs on antenna wires, refer to ANTENNA WIRES, REPAIRING .

Repair to CAN bus lines, refer to CAN BUS WIRE, REPAIRING .

Transport Mode in "Symphony II+"

The "symphony" generation II+ has a special protection lock for the internal CD changer.

This is active when the unit is shifted and must be deactivated after installation.

In the same way, the transport protection must be activated before removing the unit.

Transportation mode, activating and deactivating, refer to RADIO, SYMPHONY II+ IN TRANSPORT MODE, ACTIVATING/DEACTIVATING .

SDARS RADIO SYSTEMS

Radio Systems

1. "Concert"
2. "Symphony"

The radio systems are prepared for satellite radio -R146- use or satellite radio is installed.

Radio generation II+ introduced from KW 22/06.

This uses two internal tuners with "phase diversity" for reception.

Further removal steps are the same as with the "symphony" radio.

Besides switching diversity, "phase diversity" is the second procedure for reducing reception interference.

At least two antennas with an amplifier and a radio -R- with two tuners are required.

If the signal received is interrupted, both signals are digitalized and separated in the tuners in the radio so that the disrupted signals are blocked out as much as possible.

If the reception signal is not disrupted, the radio constantly compares which antenna (amplifier) has the strongest reception. This is then transferred.

In this case, the second tuner checks the frequency band in the background for better reception frequencies for the selected station. If a better signal is found, this tuner switches to reception and the other to the background.

Speaker Systems

1. Active speakers (rear speakers use Amplifier/Woofer (in left rear luggage compartment) -R44-)
2. BOSE sound

General Information

Communication with other vehicle systems takes place via the Infotainment CAN-Bus and Data Bus On Board Diagnostic Interface -J533-.

Fault finding is performed via "Guided Fault Finding" using the Vehicle Diagnosis, Testing & Information SystemVAS5051.

Repairs on antenna wires, refer to ANTENNA WIRES, REPAIRING .

Repair to CAN bus lines, refer to CAN BUS WIRE, REPAIRING .

Transport Mode in "Symphony II+"

The "symphony" generation II+ has a special protection lock for the internal CD changer.

This is active when the unit is shifted and must be deactivated after installation.

In the same way, the transport protection must be activated before removing the unit.

Transportation mode, activating and deactivating, refer to RADIO, SYMPHONY II+ IN TRANSPORT MODE, ACTIVATING/DEACTIVATING .

TELEPHONE SYSTEM

Mobile Phone Prep

1. Telephone transceiver -R36
2. Antenna -R11- (Ter/Sat/GPS/GSM) roof antenna
3. Telephone baseplate -R126- with cellular phone -R54
4. Telephone Microphone -R38

The telephone transceiver is equipped with a Bluetooth Antenna -R152-. Using this, all cellular phones approved by Audi can be operated with the Bluetooth interface with the cell phone preparation installed in the vehicle.

It is not possible to connect other devices via Bluetooth, for example headset, laptop, PDA, or similar.

Cell Phone Preparation Preliminary Setup

1. Black 18-pin connector behind the glove compartment.
2. Antenna (Ter/Sat/GPS/GSM) roof antenna.
3. Telephone microphone

Fault finding is performed via "Guided Fault Finding" using the Vehicle Diagnosis, Testing & Information SystemVAS5051.

Repairs on antenna wires, refer to ANTENNA WIRES, REPAIRING .

Repair to CAN bus lines, refer to CAN BUS WIRE, REPAIRING .

NAVIGATION SYSTEM

Description

RNS-E navigation system is an enhancement of the established navigation system II-D. The function selection switch is integrated in the unit (MMI operation). A DVD is used as the navigation CD.

Screen folds away. DVD drive and two MP3 card readers are located behind.

In addition to the navigation system, the RNS-E has a radio, two MP3 card readers and connections for Navigation/TV Tuner -J415- and CD Changer -R41-. The DVD drive can play music CDs.

Fault finding is performed via "Guided Fault Finding" using the Vehicle Diagnosis, Testing & Information SystemVAS5051.

Repairs on antenna wires, refer to ANTENNA WIRES, REPAIRING .

Repair to CAN bus lines, refer to CAN BUS WIRE, REPAIRING .

STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE

Description

The steering column electronic systems control module -J527- is a part of the steering column switch module. The steering column switch module consists of

1. Left and right steering column switch
2. Airbag spiral spring
3. Steering Angle Sensor -G85
4. Ignition/Starter Switch -D
5. Steering column electronic systems control module

The steering column electronic systems control module exchanges data between vehicle control modules (e.g. Vehicle Electrical System Control Module -J519-) and steering column modules (e.g. steering column switch) and steering wheel modules (e.g. airbag).

In addition, multi-function steering wheel button signals are process and relayed via CAN BUS.

Fault finding is performed via "Guided Fault Finding" using the Vehicle Diagnosis, Testing & Information System VAS5051.

Steering column switch module, removing and installing, refer to [For engine(s) CBRA, BPY, CCTA, CBFA] Removal and Installation .

Repair to CAN bus lines, refer to CAN BUS WIRE, REPAIRING .

MULTIFUNCTION STEERING WHEEL

Description

Buttons are integrated in the steering wheel for easier operation of the radio -R-, cellular telephone -R54-, navigation and CD changer -R41-.

With Tiptronic (automatic transmission), additional switches are installed.

The electronics integrated in the steering wheel take over signal processing from the buttons and transfer signals via the LIN data bus (single wire bus) to the steering column electronics control module -J527-. The conversion to CAN BUS (comfort) takes place there.

The multi-function steering wheel is part of the complete steering column switch module (SMLS) system and delivers data via the LIN data bus to the steering column electronics control module.

The individual button blocks and the Tiptronic switch can be replaced separately.

The electronics inside the steering wheel cannot be replaced individually. If faulty, the entire steering wheel must be replaced.

Fault finding is performed via "Guided Fault Finding" using the Vehicle Diagnosis, Testing & Information SystemVAS5051.

Repair to CAN bus lines, refer to CAN BUS WIRE, REPAIRING .

CD CHANGER CONNECTOR AND CONNECTOR ASSIGNMENTS

Note. Unlisted connector terminals are not used.

Black 12-Pin Connector

Scheme 17

1 - Data out to Radio -R- /Operating Electronics, Navigation Control Module -J402- /Radio/Navigation Display Control Module -J503

2 - CLK out to Radio/Operating Electronics, Navigation Control Module/Radio/Navigation Display Control Module

3 - Radio ground/terminal 31 (with RNS/radio generation II+)

4 - Data in from Radio/Operating Electronics, Navigation Control Module/Radio/Navigation Display Control Module

6 - Permanent positive from Radio/Operating Electronics, Navigation Control Module/Radio/Navigation Display Control Module

7 - Right signal to Radio/Operating Electronics, Navigation Control Module/Radio/Navigation Display Control Module

8 - Positive switched from Radio/Operating Electronics, Navigation Control Module/Radio/Navigation Display Control Module

9 - Signal ground from Radio/Operating Electronics, Navigation Control Module/Radio/Navigation Display Control Module

10 - Left signal to Radio/Operating Electronics, Navigation Control Module/Radio/Navigation Display Control Module

11 - TOC Check Control (not used)

12 - Terminal 58 (not used)

IPOD BASEPLATE CONNECTOR AND CONNECTOR ASSIGNMENTS

Note. Unlisted connector terminals are not used.

Black 12-Pin Connector

Scheme 18

1 - Data out to Radio -R- /Operating Electronics, Navigation Control Module -J402- /Radio/Navigation Display Control Module -J503

2 - CLK out to Radio/Operating Electronics, Navigation Control Module/Radio/Navigation Display Control Module

3 - Terminal 31

4 - Data in from Radio/Operating Electronics, Navigation Control Module/Radio/Navigation Display Control Module

6 - Permanent positive from Radio/Operating Electronics, Navigation Control Module/Radio/Navigation Display Control Module

7 - Right signal to Radio/Operating Electronics, Navigation Control Module/Radio/Navigation Display Control Module

8 - Positive switched from Radio/Operating Electronics, Navigation Control Module/Radio/Navigation Display Control Module

9 - Signal ground from Radio/Operating Electronics, Navigation Control Module/Radio/Navigation Display Control Module

10 - Left signal to Radio/Operating Electronics, Navigation Control Module/Radio/Navigation Display Control Module

11 - TOC Check Control (not used)

12 - Terminal 58 (not used)

DIGITAL SOUND SYSTEM CONTROL MODULE CONNECTOR AND CONNECTOR ASSIGNMENTS

Note. Unlisted connector terminals are not used.

Black 32-Pin Connector

Scheme 19

1 - Terminal 30

2 - Terminal 31

3 - Bass speaker -R100- (PIN 4)

4 - Loudspeaker, left rear (-)

5 - Loudspeaker, right rear (+)

6 - Positive switched from Radio -R- /Operating Electronics, Navigation Control Module -J402- /Radio/Navigation Display Control Module -J503

7 - Signal ground from Radio/Operating Electronics, Navigation Control Module/Radio/Navigation Display Control Module

11 - Bass speaker -R100- (PIN 3)

12 - Bass speaker (PIN 1)

13 - Center Mid/High Range Speaker -R158- (-)

14 - Center Mid/High Range Speaker (+)

15 - Bass speaker (PIN 2)

16 - Loudspeaker, left rear (+)

17 - Loudspeaker, right rear (-)

19 - Left front signal from Radio/Operating Electronics, Navigation Control Module/Radio/Navigation Display Control Module

20 - Right front signal from Radio/Operating Electronics, Navigation Control Module/Radio/Navigation Display Control Module

21 - Left rear signal from Radio/Operating Electronics, Navigation Control Module/Radio/Navigation Display Control Module

22 - Right rear signal from the radio/operating electronics/navigation system control module

24 - Positive switched from the radio/operating electronics/navigation system control module (through MY 04)

26 - Loudspeaker, right front (-)

27 - Loudspeaker, right front (+)

29 - Microphone input (+) from interior microphone -R74

30 - Microphone input (-) from interior microphone

31 - Loudspeaker, left front (+)

32 - Loudspeaker, left front (-)

AMPLIFIER WITH BASS SPEAKER IN LEFT LUGGAGE COMPARTMENT CONNECTOR AND CONNECTOR ASSIGNMENTS

Note. Unlisted connector terminals are not used.

23-Pin Connector, Blue

Scheme 20

1 - Right rear signal from Radio -R- /Operating Electronics, Navigation Control Module -J402- /Radio/Navigation Display Control Module -J503

2 - Signal ground from Radio/Operating Electronics, Navigation Control Module/Radio/Navigation Display Control Module

3 - Left rear signal from Radio/Operating Electronics, Navigation Control Module/Radio/Navigation Display Control Module

5 - CAN-Bus Low (Infotainment)

6 - CAN-Bus High (Infotainment)

9 - Positive switched from Radio/Operating Electronics, Navigation Control Module/Radio/Navigation Display Control Module

17 - Loudspeaker, left rear (+)

18 - Loudspeaker, left rear (-)

20 - Loudspeaker, right rear (+)

21 - Loudspeaker (-) rear right

22 - Terminal 31

23 - Terminal 30

Scheme 21

1. Connection (Black) rear window antenna 1 -R130- /central locking and anti-theft alarm system antenna -R47
2. CLS Connection (Gray) to Comfort System Central Control Module -J393
3. HF Connection (White) to the Radio -R- /Operating Electronics/Navigation System Control Module -J402- /Radio/Navigation Display Unit Control Module -J503
4. IF Connection (Black) from the Radio -R- /Operating Electronics/Navigation System Control Module -J402- /Radio/Navigation Display Unit Control Module -J503
5. 1-Pin Connector to the Rear Window Defogger -Z1- (-)
6. 1-Pin Connector to the Rear Window Defogger -Z1- (+)
7. 1-Pin Connector from the Vehicle Electrical System Control Module -J519
8. TV2 Connection (Black) to the Navigation/TV Tuner -J415
9. TV1 Connection (Brown) to the Navigation/TV Tuner -J415
10. 3-Pin Connector to the Antenna Amplifier -R24

LEFT ANTENNA MODULE CONNECTORS, RADIO GENERATION II+ ONLY

1. Connection Rear Window Antenna 1 -R130- /Central Locking and Anti-Theft Alarm System Antenna -R47
2. CLS Connection (Gray) to Comfort System Central Control Module -J393
3. HF Connection (White) to the Radio -R
4. Not Used
5. 1-Pin Connector to the Rear Window Defogger -Z1- (-)
6. 1-Pin Connector to the Rear Window Defogger -Z1- (+)
7. 1-Pin Connector from the Vehicle Electrical System Control Module -J519
8. Not Used
9. Not Used
10. Not Used

ANTENNA AMPLIFIER, RIGHT ANTENNA MODULE AND ANTENNA AMPLIFIER 2 CONNECTORS AND CONNECTOR ASSIGNMENTS

Antenna Amplifier -R24

Scheme 22

1 - Not used

2 - Connection (black) to the left antenna module -R108

3 - Connection rear window antenna 1 -R130

Antenna Amplifier, only with Radio Generation II+

1 - Not used

2 - HF2 connection (black) to the radio -R

3 - Connection rear window antenna 1 -R130

Right Antenna Module -R109

Scheme 23

1 - Connection rear window antenna 2 -R131

2 - TV4 connection (green) to the navigation/TV tuner -J415

3 - TV3 connection (green) to navigation/TV tuner

Antenna Amplifier 2 -R111-, only Central Locking System

1 - CLS connection (gray) to comfort system central control module -J393

2 - Not used

3 - Connection central locking and anti-theft alarm system antenna -R47

Scheme 24

1. CD Changer -R41- Inside the glove compartment. Connectors, refer to «CD CHANGER CONNECTOR AND CONNECTOR ASSIGNMENTS»(ref-496064-S00711427652012082100000) . Removing and installing, refer to «CD CHANGER»(ref-496064-S39797285392012082100000) . - iPod Baseplate -R192- Connectors, refer to «IPOD BASEPLATE CONNECTOR AND CONNECTOR ASSIGNMENTS»(ref-496064-S12402399332012082100000) . Removing and installing, refer to «IPOD BASEPLATE»(ref-496064-S01466273762012082100000) .
2. Center Mid/High Range Loudspeaker -R158- In front instrument panel, center. Removing and installing, refer to «CENTER MID/HIGH RANGE SPEAKER»(ref-496064-S31805197162012082100000) .
3. Inside Microphone -R74- Only with BOSE in Front Interior Light -W1- Function test, refer to «INSIDE MICROPHONE, FUNCTION TEST»(ref-496064-S23770732262012082100000) . Removing and installing, refer to «INSIDE MICROPHONE»(ref-496064-S39329393522012082100000) .
4. Digital Sound System Control Module -R12- Only with BOSE. behind luggage compartment right side trim. Connectors, refer to «DIGITAL SOUND SYSTEM CONTROL MODULE CONNECTOR AND CONNECTOR ASSIGNMENTS»(ref-496064-S22042643142012082100000) .
5. Antenna Amplifier -R24- On upper left of rear lid. Connectors, refer to «ANTENNA AMPLIFIER, RIGHT ANTENNA MODULE AND ANTENNA AMPLIFIER 2 CONNECTORS AND CONNECTOR ASSIGNMENTS»(ref-496064-S25862038322012082100000) . Radio generation II+ connections, refer to «ANTENNA AMPLIFIER, RIGHT ANTENNA MODULE AND ANTENNA AMPLIFIER 2 CONNECTORS AND CONNECTOR ASSIGNMENTS»(ref-496064-S25862038322012082100000) . Removing and installing, refer to «ANTENNA AMPLIFIER, RIGHT ANTENNA MODULE AND ANTENNA AMPLIFIER 2»(ref-496064-S33359927532012082100000) .
6. Left Antenna Module -R108- At the bottom of the rear lid on the left side. Connectors, refer to «LEFT ANTENNA MODULE CONNECTORS»(ref-496064-S02964627012012082100000) . Radio generation II+ connections, refer to «LEFT ANTENNA MODULE CONNECTORS, RADIO GENERATION II+ ONLY»(ref-496064-S09723734212012082100000) . Removing and installing, refer to «LEFT ANTENNA MODULE»(ref-496064-S39867532552012082100000) .
7. Amplifier with Bass Speaker in Left Luggage Compartment -R44- /Bass Speaker -R100- Behind luggage compartment left side trim. Connectors amplifier with bass speaker in left luggage compartment, refer to «AMPLIFIER WITH BASS SPEAKER IN LEFT LUGGAGE COMPARTMENT CONNECTOR AND CONNECTOR ASSIGNMENTS»(ref-496064-S19209239642012082100000) . Removing and installing amplifier with bass speaker in left luggage compartment, refer to «AMPLIFIER WITH BASS SPEAKER IN LEFT LUGGAGE COMPARTMENT»(ref-496064-S14601618572012082100000) . Removing and installing bass speaker, refer to «BASS SPEAKER»(ref-496064-S16440821462012082100000) .
8. Left Rear Midrange Speaker -R105- /Right Rear Midrange Speaker -R106- in bottom of rear doors. Removing and installing, refer to «REAR MIDRANGE SPEAKER»(ref-496064-S20631648032012082100000) .
9. Left Rear Treble Speaker -R14- /Right Rear Treble Speaker -R16- In top of rear doors. Removing and installing, refer to «REAR TREBLE SPEAKER»(ref-496064-S01912581702012082100000) .
10. Left Front Mid/Low Range Loudspeaker -R101- /Right Front Mid/Low Range Loudspeaker -R102- In bottom of front doors. Removing and installing, refer to «FRONT MID/LOW RANGE LOUDSPEAKER»(ref-496064-S04782989402012082100000) .
11. Left Front Treble Speaker -R20- /Right Front Treble Speaker -R22- In the center of the A-pillar. Removing and installing, refer to «FRONT TREBLE SPEAKER»(ref-496064-S28322094612012082100000) .
12. Radio -R- In the top of the center console. Connectors, chorus, through KW 21/04, refer to «RADIO SYSTEM CONNECTORS AND CONNECTOR ASSIGNMENTS, CHORUS THROUGH KW 21/04»(ref-496064-S27031951272012082100000) . Connectors, chorus, from KW 22/04, refer to «RADIO SYSTEM CONNECTORS AND CONNECTOR ASSIGNMENTS, CONCERT AND CHORUS, FROM KW 22/2004»(ref-496064-S38893641042012082100000) Concert connections, refer to «RADIO SYSTEM CONNECTORS AND CONNECTOR ASSIGNMENTS, CONCERT AND CHORUS, FROM KW 22/2004»(ref-496064-S38893641042012082100000) . Chorus/Concert, removing and installing, refer to «RADIO, CHORUS/CONCERT»(ref-496064-S27614276542012082100000) . Symphony, connections, refer to «RADIO SYSTEM CONNECTORS AND CONNECTOR ASSIGNMENTS, SYMPHONY»(ref-496064-S31298899312012082100000) . Radio, generation II+ connections, refer to «RADIO SYSTEM CONNECTORS AND CONNECTOR ASSIGNMENTS, CHORUS/CONCERT/SYMPHONY (RADIO GENERATION II+) FROM KW 45/06»(ref-496064-S05801589242012082100000) . Symphony, removing and installing, refer to «RADIO, SYMPHONY»(ref-496064-S33789336072012082100000) . Symphony II+ transport protection, activating/deactivating, refer to «RADIO, SYMPHONY II+ IN TRANSPORT MODE, ACTIVATING/DEACTIVATING»(ref-496064-S14964923652012082100000) .

RADIO, SYMPHONY II+ IN TRANSPORT MODE, ACTIVATING/DEACTIVATING

Transport mode must be activated before removing/sending every "symphony II+" radio.

After activation, the internal CD changer drive is in transport position.

After replacing a "symphony II+", transport mode must be deactivated after installation.

Transport Mode, Activating

"Symphony II+" is connected and installed.

Press station buttons 3 and 5 and TONE button at the same time.

After about 5 seconds, "TRANSPORT" appears on the radio display.

Transport Mode, Deactivating

"Symphony II+" is connected and installed.

Press CANCEL button.

"TRANSPORT" display goes out.

Transport mode is deactivated.

Scheme 25

1. Antenna -R11- (Ter/Sat/GPS/GSM) Roof Antenna
2. Rear Window Antenna 1 -R130
3. Rear Window Defogger with Window Antenna -Z24
4. Left Antenna Module -R108- at the Bottom of the Rear Lid on the Left Side
5. Left Front Treble Speaker -R20- /Right Front Treble Speaker -R22- in the Center of the A-Pillar
6. Left Front Mid-Bass Speaker -R101- /Right Front Mid-Bass Speaker -R102- at Bottom in Front Doors
7. Center Mid/High Range Speaker -R158- in Center Instrument Panel, Front
8. Left Rear Treble Speaker -R14- /Right Rear Treble Speaker -R16- at Top in Rear Doors
9. Left Rear Midrange Speaker -R105- /Right Rear Midrange Speaker -R106- at the Bottom of the Rear Doors
10. Amplifier with Bass Speaker in Left Luggage Compartment -R44- Behind the Left Side Trim Panel in the Luggage Compartment
11. Radio -R- in Upper Center Console
12. CD Changer -R41- in Glove Compartment
13. Satellite Radio -R146- behind Luggage Compartment Left Side Trim
14. CAN-BUS (Infotainment)
15. Antenna Amplifier -R24- at the Top of the Rear Lid on the Left Side

Scheme 26

1. Antenna -R11- (Ter/Sat/GPS/GSM) Roof Antenna
2. Rear Window Antenna 1 -R130
3. Rear Window Defogger with Window Antenna -Z24
4. Left Antenna Module -R108- at the Bottom of the Rear Lid on the Left Side
5. Amplifier -R12- behind Luggage Compartment Right Side Trim
6. Left Front Treble Speaker -R20- /Right Front Treble Speaker -R22- in the Center of the A-Pillar
7. Left Front Mid-Bass Speaker -R101- /Right Front Mid-Bass Speaker -R102- at Bottom in Front Doors
8. Left Rear Treble Speaker -R14- /Right Rear Treble Speaker -R16- at Top in Rear Doors
9. Left Rear Midrange Speaker -R105- /Right Rear Midrange Speaker -R106- at the Bottom of the Rear Doors
10. Center Mid/High Range Speaker -R158- in Center Instrument Panel, Front
11. Bass Loudspeaker -R100- behind Luggage Compartment Left Side Trim
12. Inside Microphone -R74- in Front Interior Light -W1
13. Radio -R- in Upper Center Console
14. CD Changer -R41- in Glove Compartment
15. Satellite Radio -R146- behind Luggage Compartment Left Side Trim
16. CAN-BUS (Infotainment)
17. Antenna Amplifier -R24- at the Top of the Rear Lid on the Left Side

Scheme 27

1. Antenna -R11- (Sat/GPS/GSM) Roof Antenna
2. Window Antenna
3. Left Antenna Module -R108- at the Bottom of the Rear Lid on the Left Side
4. Radio -R- in Upper Center Console
5. Sound Systems
6. CD Changer -R41- /iPod Baseplate -R192- in Glove Compartment
7. Satellite Radio -R146- behind Luggage Compartment Left Side Trim
8. Not Used
9. CAN-BUS (Infotainment)
10. Antenna Amplifier -R24- at the Top of the Rear Lid on the Left Side

SDARS RADIO SYSTEM CONNECTORS AND CONNECTOR ASSIGNMENTS, CONCERT

1. 10-Pin Connector IV, (T10h) Red
2. 20-Pin Connector I, (T20i) Black
3. Device Fuse
4. 8-Pin Connector III, (T8) Black
5. 8-Pin Connector II, (T8k) Brown
6. ZF Connection (Yellow) to the Left Antenna Module -R108
7. HF Connection (Black) from the Left Antenna Module -R108

Note. Unlisted connector terminals are not used.

1 - 10-Pin Connector IV, (T10h) Red

1 - LF mute from preliminary setup for cell phone preparation

3 - LF (+) from telephone transceiver -R36- /preliminary setup for cell phone package

4 - LF (-) from telephone transceiver/preliminary setup for cell phone package

5 - LF (+) Navigation (not used)

6 - LF (-) Navigation (not used)

7 - Navigation control wire (not used)

2 - 20-Pin Connector, (T20i) Black

1 - Left rear signal to Amplifier/Woofer (in left rear luggage compartment) -R44- /Amplifier -R12

2 - Right rear signal to Amplifier/Woofer (in left rear luggage compartment)/Amplifier

3 - Signal ground to Amplifier/Woofer (in left rear luggage compartment)/Amplifier

4 - Left front signal to Amplifier (only with BOSE)

5 - Right front signal to Amplifier (only with BOSE)

6 - Positive switched to Amplifier/Woofer (in left rear luggage compartment)/Amplifier

7 - CAN-Bus High (Infotainment)

10 - CD ground to CD Changer -R41

12 - CAN-Bus Low (Infotainment)

13 - CD data in from CD Changer

14 - CD data out to CD Changer

15 - CD CLK in from CD Changer

16 - Permanent positive to CD Changer

17 - Positive switched to CD Changer

18 - Signal ground to CD Changer/Satellite Radio -R146

19 - Left signal from CD Changer/Satellite Radio

20 - Right signal from CD Changer/Satellite Radio

4 - 8-Pin Connector III, 8-Pin, (T8) Black

1 - BOSE coding to ground PIN 8 (only with BOSE)

2 - Anti-theft warning system (not used)

5 - Positive switched to the antenna amplifier (not used)

7 - Terminal 30

8 - Terminal 31

5 - 8-Pin Connector II, (T8k) Brown

3 - Right front speaker (+) (not with BOSE)

4 - Right front speaker (-) (not with BOSE)

5 - Left front speaker (+) (not with BOSE)

6 - Left front speaker (-) (not with BOSE)

SDARS RADIO SYSTEM CONNECTORS AND CONNECTOR ASSIGNMENTS, SYMPHONY

1. HF Connection (Black) from the Left Antenna Module -R108
2. ZF Connection (Yellow) to the Left Antenna Module -R108
3. 10-Pin Connector IV, (T10h) Red
4. 8-Pin Connector III, (T8) Black
5. Device Fuse
6. 8-Pin Connector II, (T8k) Brown
7. 20-Pin Connector I, (T20i) Black

Note. Unlisted connector terminals are not used.

3 - 10-Pin Connector IV, (T10h) Red

1 - LF mute from preliminary setup for cell phone preparation

3 - LF (+) from telephone transceiver -R36- /preliminary setup for cell phone package

4 - LF (-) from telephone transceiver/preliminary setup for cell phone package

5 - LF (+) Navigation (not used)

6 - LF (-) Navigation (not used)

7 - Navigation control wire (not used)

4 - 8-Pin Connector III, 8-Pin, (T8) Black

1 - BOSE coding to ground PIN 8 (only with BOSE)

2 - Anti-theft warning system (not used)

5 - Positive switched to the antenna amplifier -R24- (not used)

7 - Terminal 30

8 - Terminal 31

6 - 8-Pin Connector II, (T8k) Brown

3 - Right front speaker (+) (not with BOSE

4 - Right front speaker (-) (not with BOSE)

5 - Left front speaker (+) (not with BOSE)

6 - Left front speaker (-) (not with BOSE)

7 - 20-Pin Connector, (T20i) Black

1 - Left rear signal to Amplifier/Woofer (in left rear luggage compartment) -R44- /Amplifier -R12

2 - Right rear signal to Amplifier/Woofer (in left rear luggage compartment)/Amplifier

3 - Signal ground to Amplifier/Woofer (in left rear luggage compartment)/Amplifier

4 - Left front signal to Amplifier (only with BOSE)

5 - Right front signal to Amplifier (only with BOSE)

6 - Positive switched to Amplifier/Woofer (in left rear luggage compartment)/Amplifier

7 - CAN-Bus High (Infotainment)

10 - CD ground to CD Changer -R41

12 - CAN-Bus Low (Infotainment)

13 - CD data in from CD Changer

14 - CD data out to CD Changer

15 - CD CLK in from CD Changer

16 - Permanent positive to CD Changer

17 - Positive switched to CD Changer

18 - Signal ground to CD Changer/Satellite Radio -R146

19 - Left signal from CD Changer/Satellite Radio

20 - Right signal from CD Changer/Satellite Radio

SDARS RADIO SYSTEM CONNECTORS AND CONNECTOR ASSIGNMENTS, CONCERT/SYMPHONY (RADIO GENERATION II+) FROM KW 22/06

1. Connector Block with 4-Pin Connectors and Fuse
2. C
3. HF2 (White) Connection on the Antenna Amplifier -R24

Note. Unlisted connector terminals are not used.

A - 8-Pin Connector (T8) Black

2 - Right front speaker (+) (not with BOSE)

3 - Left front speaker (+) (not with BOSE)

6 - Right front speaker (-) (not with BOSE)

7 - Left front speaker (-) (not with BOSE)

B - 12-Pin Connector (T12f) Blue

1 - LF in left (not used)

2 - Signal ground to CD Changer -R41- /Satellite Radio -R146

3 - LF in ground (not used)

4 - Permanent positive to CD Changer

5 - BOSE coding to ground (only with BOSE)

6 - CD data out to CD Changer

7 - LF in right (not used)

8 - Left signal from CD Changer/Satellite Radio

9 - Right signal from CD Changer/Satellite Radio

10 - Positive switched to CD Changer

11 - CD data in from CD Changer

12 - CD CLK from CD Changer

C - 12-Pin Connector (T12) Green

1 - Speed signal (not used)

3 - Left front signal to Amplifier -R12- (only with BOSE)

5 - Left rear signal to Amplifier/Woofer (in left rear luggage compartment) -R44- /Amplifier

6 - LF (-) from Telephone Transceiver -R36- /preliminary setup for cell phone package

7 - K diagnostic (not used)

8 - Signal ground to Amplifier/Woofer (in left rear luggage compartment)/Amplifier

9 - Right front signal to Amplifier (only with BOSE)

10 - Audio Pilot in/out (not used)

11 - Right rear signal to Amplifier/Woofer (in left rear luggage compartment)/Amplifier

12 - LF (+) from Telephone Transceiver/preliminary setup for cell phone package

D - 8-Pin Connector (T8h) Black

9 - CAN-Bus High (Infotainment)

10 - CAN-Bus Low (Infotainment)

11 - LF mute from preliminary setup for cell phone preparation

12 - Terminal 31

13 - Positive switched to Amplifier/Woofer (in left rear luggage compartment) -R44- /Amplifier -R12

14 - Anti-theft warning system (not used)

15 - Terminal 30

16 - Permanent positive connected with PIN 15 (anti-theft warning system)

Note. Unlisted connector terminals are not used.

Black 12-Pin Connector

1 - Data out to the radio -R- /operating electronics/navigation system control module -J402

2 - CLK out to the radio/operating electronics/navigation system control module

3 - Ground from Radio/terminal 31 (with RNS-E/radio generation II+)

4 - Data in from the radio/operating electronics/navigation system control module

6 - Continuous plus from the radio/operating electronics, navigation control module -J402

7 - Right signal to the radio/operating electronics, navigation control module/satellite radio -R146

8 - Positive switched from the Radio/operating electronics, navigation control module

9 - Signal ground from the radio/operating electronics, navigation control module/satellite radio

10 - Left signal to the radio/operating electronics, navigation control module/satellite radio

11 - TOC Check Control (not used)

12 -Terminal 58 (not used)

IPOD BASEPLATE CONNECTORS AND CONNECTOR ASSIGNMENTS

Note. Unlisted connector terminals are not used.

Black 12-Pin Connector

1 - Data out to the radio -R- /operating electronics/navigation system control module -J402

2 - CLK out to the radio/operating electronics/navigation system control module

3 - Terminal 31

4 - Data in from the radio/operating electronics/navigation system control module

6 - Continuous plus from the radio/operating electronics/navigation system control module

7 - Right signal to the radio/operating electronics/navigation system control module/satellite radio -R146

8 - Positive switched from the radio/operating electronics/navigation system control module

9 - Signal ground from the radio/operating electronics/navigation system control module/satellite radio

10 - Left signal to the radio/operating electronics/navigation system control module/satellite radio

11 - TOC Check Control (not used)

12 - Terminal 58 (not used)

SATELLITE RADIO CONNECTORS AND CONNECTOR ASSIGNMENTS

Note. Unlisted connector terminals are not used.

Connectors

Scheme 28

A - Black 8-pin connector (T8t)

B - 8-pin connector (T8u) black

C - Ter connection (brown) from antenna -R11- (through October 06

D - Sat connection (green) from the antenna

A - 8-Pin Connector (T8t)

1 - CAN-Bus High (Infotainment)

2 - CAN-Bus Low (Infotainment)

3 - Left signal from CD Changer -R41- /iPod Baseplate -R192

4 - Right signal from CD Changer/iPod Baseplate

5 - Signal ground to the radio -R- /operating electronics, navigation control module -J402

6 - Left signal to the radio/operating electronics, navigation control module

7 - Right signal to the radio/operating electronics, navigation control module

8 - Signal ground from CD Changer/iPod Baseplate

B - 8-Pin Connector (T8u) Black

1 - Terminal 31

2 - Terminal 30

LEFT ANTENNA MODULE CONNECTORS

1. Connection Rear Window Antenna 1 -R130- /Central Locking and Antitheft Alarm System Antenna -R47
2. CLS Connection (Gray) to Comfort System Central Control Module -J393
3. HF Connection (White) to the Radio -R- /Operating Electronics/Navigation System Control Module -J402
4. IF Connection (Black) from the Radio -R- /Operating Electronics/Navigation System Control Module -J402
5. 1-Pin Connector to the Rear Window Defogger -Z1- (-)
6. 1-Pin Connector to the Rear Window Defogger -Z1- (+)
7. 1-Pin Connector from the Vehicle Electrical System Control Module -J519
8. Not Used
9. Not Used
10. 3-Pin Connector to the Antenna Amplifier -R24

LEFT ANTENNA MODULE CONNECTORS, ONLY RADIO GENERATION II+

1. Connection Rear Window Defogger with Window Antenna -Z24
2. Central Locking and Anti-Theft Alarm System Antenna -R47- CLS Connection (Gray)
3. HF Connection (White) to the Radio -R
4. Not Used
5. 1-Pin Connector to the Rear Window Defogger -Z1- (-)
6. 1-Pin Connector to the Rear Window Defogger -Z1- (+)
7. 1-Pin Connector from the Vehicle Electrical System Control Module -J519
8. Not Used
9. Not Used
10. Not Used

ANTENNA AMPLIFIER CONNECTORS AND CONNECTOR ASSIGNMENTS

1 - Not used

2 - Connection (black) to the left antenna module -R108

3 - Connection rear window antenna 1 -R130

1 - Not used

2 - HF2 connection (black) to the radio -R

3 - Connection rear window antenna 1 -R130

Scheme 29

1. CD Changer -R41- Inside the glove compartment. Connectors, refer to «CD CHANGER CONNECTOR AND CONNECTOR ASSIGNMENTS»(ref-496064-S38473877352012082100000). Removing and installing, refer to «CD CHANGER»(ref-496064-S39797285392012082100000). - iPod Baseplate -R192- Connectors, refer to «IPOD BASEPLATE CONNECTORS AND CONNECTOR ASSIGNMENTS»(ref-496064-S21202299102012082100000). Removing and installing, refer to «IPOD BASEPLATE»(ref-496064-S01466273762012082100000).
2. Center Mid/High Range Loudspeaker -R158- In front instrument panel, center. Removing and installing, refer to «CENTER MID/HIGH RANGE SPEAKER»(ref-496064-S31805197162012082100000).
3. Inside Microphone -R74- Only with BOSE in Front Interior Light -W1- Function test, refer to «INSIDE MICROPHONE, FUNCTION TEST»(ref-496064-S23770732262012082100000). Removing and installing, refer to «INSIDE MICROPHONE»(ref-496064-S39329393522012082100000).
4. Digital Sound System Control Module -R12- Only with BOSE. Behind luggage compartment right side trim. Connectors, refer to «DIGITAL SOUND SYSTEM CONTROL MODULE CONNECTOR AND CONNECTOR ASSIGNMENTS»(ref-496064-S22042643142012082100000).
5. Antenna -R11- Ter/Sat/GPS/GSM Roof antenna. Removing and installing, refer to «ANTENNA»(ref-496064-S03995110302012082100000).
6. Antenna Amplifier -R24- On upper left of rear lid. Connectors, refer to «ANTENNA AMPLIFIER CONNECTORS AND CONNECTOR ASSIGNMENTS»(ref-496064-S05910603922012082100000). Radio generation II+ connections see scheme 65 Removing and installing, refer to «ANTENNA AMPLIFIER, RIGHT ANTENNA MODULE AND ANTENNA AMPLIFIER 2»(ref-496064-S33359927532012082100000).
7. Left Antenna Module -R108- At the bottom of the rear lid on the left side. Connectors, refer to «LEFT ANTENNA MODULE CONNECTORS»(ref-496064-S38897559962012082100000). Radio generation II+ connections, refer to «LEFT ANTENNA MODULE CONNECTORS, ONLY RADIO GENERATION II+»(ref-496064-S17775337622012082100000). Removing and installing, refer to «LEFT ANTENNA MODULE»(ref-496064-S39867532552012082100000).
8. Amplifier with Bass Speaker in Left Luggage Compartment -R44- /Bass Speaker -R100- Behind luggage compartment left side trim. Connectors amplifier with bass speaker in left luggage compartment, refer to «AMPLIFIER WITH BASS SPEAKER IN LEFT LUGGAGE COMPARTMENT CONNECTOR AND CONNECTOR ASSIGNMENTS»(ref-496064-S19209239642012082100000). Removing and installing amplifier with bass speaker in left luggage compartment, refer to «AMPLIFIER WITH BASS SPEAKER IN LEFT LUGGAGE COMPARTMENT»(ref-496064-S14601618572012082100000). Removing and installing bass speaker, refer to «BASS SPEAKER»(ref-496064-S16440821462012082100000).
9. Satellite Radio -R146- Behind luggage compartment left side trim. Connectors, refer to «SATELLITE RADIO CONNECTORS AND CONNECTOR ASSIGNMENTS»(ref-496064-S16018678962012082100000). Removing and installing, refer to «SATELLITE RADIO»(ref-496064-S17529314822012082100000). Activating, refer to «SATELLITE RADIO, ACTIVATING»(ref-496064-S40645210072012082100000).
10. Left Rear Midrange Speaker -R105- /Right Rear Midrange Speaker -R106- In bottom of rear doors. Removing and installing, refer to «REAR MIDRANGE SPEAKER»(ref-496064-S20631648032012082100000).
11. Left Rear Treble Speaker -R14- /Right Rear Treble Speaker -R16- In top of rear doors. Removing and installing, refer to «REAR TREBLE SPEAKER»(ref-496064-S01912581702012082100000).
12. Left Front Mid/Low Range Loudspeaker -R101- /Right Front Mid/Low Range Loudspeaker -R102- In bottom of front doors. Removing and installing, refer to «FRONT MID/LOW RANGE LOUDSPEAKER»(ref-496064-S04782989402012082100000).
13. Left Front Treble Speaker -R20- /Right Front Treble Speaker -R22- In the center of the A-pillar. Removing and installing, refer to «FRONT TREBLE SPEAKER»(ref-496064-S28322094612012082100000).
14. Radio -R- In the top of the center console. Concert connections, refer to «SDARS RADIO SYSTEM CONNECTORS AND CONNECTOR ASSIGNMENTS, CONCERT»(ref-496064-S04289602062012082100000). Concert, removing and installing, refer to «RADIO, CHORUS/CONCERT»(ref-496064-S27614276542012082100000). Symphony connections, refer to «SDARS RADIO SYSTEM CONNECTORS AND CONNECTOR ASSIGNMENTS, SYMPHONY»(ref-496064-S19022645282012082100000). Radio generation II+ connections, refer to «SDARS RADIO SYSTEM CONNECTORS AND CONNECTOR ASSIGNMENTS, CONCERT/SYMPHONY (RADIO GENERATION II+) FROM KW 22/06»(ref-496064-S39034925412012082100000). Symphony, removing and installing, refer to «RADIO, SYMPHONY»(ref-496064-S33789336072012082100000). Symphony II+ transport protection, activating/deactivating, refer to «RADIO, SYMPHONY II+ IN TRANSPORT MODE, ACTIVATING/DEACTIVATING»(ref-496064-S14964923652012082100000).

Scheme 30

1. Telephone Baseplate -R126- with Cellular Telephone -R54- to the Instrument Panel/Center Armrest
2. Radio -R- /Operating Electronics, Navigation Control Module -J402- in Top of Center Console
3. Sound Systems
4. Bluetooth Antenna -R152- at Telephone Transceiver -R36
5. Telephone Transceiver -R36- in Electronics Box Under Left Front Seat
6. Telephone Microphone -R38- in Front Interior Light -W1
7. Antenna -R11- (Ter/Sat/GPS/GSM) Roof Antenna

Scheme 31

1. Black 18-pin connector behind the glove compartment
2. Antenna -R11- (Ter/Sat/GPS/GSM) roof antenna
3. Telephone Microphone -R38
4. Radio -R
5. Sound Systems
6. Terminal 15
7. Terminal 30
8. Terminal 31

Scheme 32

A - Bluetooth Antenna -R152- connection (yellow)

B - Black 54-pin connector (T54)

Note. Unlisted connector terminals are not used.

B - Black 54-Pin Connector (T54)

1 - Terminal 30

2 - Terminal 31

8 - NF (+) to the radio -R- /operating electronics, navigation control module -J402

9 - NF (-) to the radio/operating electronics, navigation control module

10 - Terminal 31 (screen ground) (not used)

11 - Microphone input (+) telephone microphone -R38- /operating electronics/navigation system control module

12 - Microphone input (-) telephone microphone/operating electronics/navigation system control module

16 - LF mute to the operating electronics/navigation system control module

17 - CAN-Bus High (Infotainment)

18 - CAN-Bus Low (Infotainment)

37 - Terminal 30 to telephone baseplate -R126

39 - Terminal 31 to telephone baseplate

41 - Terminal 30 to telephone baseplate

42 - Microphone output (+) to telephone baseplate

43 - Microphone output (-) to telephone baseplate

44 - Terminal 31 (screen ground)

45 - LF input (+) from telephone baseplate

46 - LF input (-) from telephone baseplate

47 - SNDREQ signal from telephone baseplate

49 - Ser-Tx (+) to telephone baseplate

50 - Ser-Tx (-) to telephone baseplate

51 - Ser-Rx (+) from telephone baseplate

52 - Ser-Rx (-) from telephone baseplate

Scheme 33

1 - Terminal 31

4 - LF mute to radio -R

7 - LF (-) to radio

9 - telephone microphone -R38- (-)

10 - Terminal 15

11 - Terminal 30

16 - LF (+) to radio

18 - Telephone microphone (+)

Scheme 34

1. CD Changer -R41- Inside the glove compartment.
2. Center Mid/High Range Loudspeaker -R158- In front instrument panel, center.
3. Telephone Baseplate -R126- On the instrument panel. Overview, refer to «TELEPHONE BASEPLATE ON INSTRUMENT PANEL OVERVIEW»(ref-496064-S40434308842012082100000) . Removing and installing, refer to «TELEPHONE BASEPLATE ON INSTRUMENT PANEL»(ref-496064-S24486365622012082100000) . In center armrest. Removing and installing, refer to «TELEPHONE BASEPLATE IN CENTER ARMREST»(ref-496064-S22136410812012082100000) .
4. Telephone Microphone -R38- In Front Interior Light -W1-. Removing and installing, refer to «TELEPHONE MICROPHONE»(ref-496064-S29616670812012082100000) .
5. Digital Sound System Control Module -R12- Only with BOSE. behind luggage compartment right side trim.
6. Antenna -R11- Ter/Sat/GPS/GSM. Roof antenna. Removing and installing, refer to «ANTENNA»(ref-496064-S03995110302012082100000) .
7. Antenna Amplifier -R24- On upper left of rear lid.
8. Left Antenna Module -R108- At the bottom of the rear lid on the left side.
9. Amplifier with Bass Speaker in Left Luggage Compartment -R44- /Bass Speaker -R100- Behind luggage compartment left side trim.
10. Satellite Radio -R146- Behind luggage compartment left side trim.
11. Left Rear Midrange Speaker -R105- /Right Rear Midrange Speaker -R106- In bottom of rear doors.
12. Left Rear Treble Speaker -R14- /Right Rear Treble Speaker -R16- In top of rear doors.
13. Left Front Mid/Low Range Loudspeaker -R101- /Right Front Mid/Low Range Loudspeaker -R102- In bottom of front doors.
14. Telephone Transceiver -R36- In electronics box under left front seat. Connectors, refer to «TELEPHONE TRANSCEIVER CONNECTORS AND CONNECTOR ASSIGNMENTS»(ref-496064-S41605828422012082100000) . Removing and installing, refer to «TELEPHONE TRANSCEIVER»(ref-496064-S32490373582012082100000) .
15. Left Front Treble Speaker -R20- /Right Front Treble Speaker -R22- In the center of the A-pillar.
16. Radio -R- In the top of the center console.

Scheme 35

1. Connecting Wire From the telephone baseplate to the telephone transceiver -R36- and the antenna wire to the cellular telephone amplifier -R86
2. Bolt 2 Nm
3. Telephone Baseplate -R126- with Base Plate
4. Mounting Plate
5. Connecting Piece

Scheme 36

1. Antenna -R11- (Ter/Sat/GPS/GSM) Roof Antenna
2. Rear Window Defogger with Window Antenna -Z24
3. Antenna Amplifier -R24- (Rear Window Antenna 1 -R130-) at the Top of the Rear Lid on the Left Side
4. Left Front Treble Speaker -R20- /Right Front Treble Speaker -R22- in the Center of the A-Pillar
5. Left Front Mid-Bass Speaker -R101- /Right Front Mid-Bass Speaker -R102- at Bottom in Front Doors
6. Center Mid/High Range Speaker -R158- in Center Instrument Panel, Front
7. Left Rear Treble Speaker -R14- /Right Rear Treble Speaker -R16- at Top in Rear Doors
8. Left Rear Midrange Speaker -R105- /Right Rear Midrange Speaker -R106- at the Bottom of the Rear Doors
9. Amplifier with Bass Speaker in Left Luggage Compartment -R44- behind the Left Side Trim Panel in the Luggage Compartment
10. Operating Electronics, Navigation Control Module -J402- in Top of Center Console
11. CD Changer -R41- /iPod Baseplate -R192- in Glove Compartment
12. Satellite Radio -R146- behind Luggage Compartment Left Side Trim
13. Left Antenna Module -R108- at the Bottom of the Rear Lid on the Left Side

Scheme 37

1. Antenna -R11- (Ter/Sat/GPS/GSM) Roof Antenna
2. Rear Window Defogger with Window Antenna -Z24
3. Antenna Amplifier -R24- (Rear Window Antenna 1 -R130-) at the Top of the Rear Lid on the Left Side
4. Inside Microphone -R74- in Front Interior Light -W1
5. Amplifier -R12- behind Luggage Compartment Right Side Trim
6. Left Front Treble Speaker -R20- /Right Front Treble Speaker -R22- in the Center of the A-Pillar
7. Left Front Mid-Bass Speaker -R101- /Right Front Mid-Bass Speaker -R102- at Bottom in Front Doors
8. Left Rear Treble Speaker -R14- /Right Rear Treble Speaker -R16- at Top in Rear Doors
9. Left Rear Midrange Speaker -R105- /Right Rear Midrange Speaker -R106- at the Bottom of the Rear Doors
10. Center Mid/High Range Speaker -R158- in Center Instrument Panel, Front
11. Bass Loudspeaker -R100- behind Luggage Compartment Left Side Trim
12. Operating Electronics, Navigation Control Module -J402- in Top of Center Console
13. CD Changer -R41- /iPod Baseplate -R192- in Glove Compartment
14. Satellite Radio -R146- behind Luggage Compartment Left Side Trim
15. Left Antenna Module -R108- at the Bottom of the Rear Lid on the Left Side

Scheme 38

1. 32-Pin Connector, Not Used
2. GPS Connection (Blue) from the Antenna -R11- (Ter/Sat/GPS/GSM)
3. Connection Block with Four Multi-Pin Connectors and a Fuse for Unit
4. ZF Connection (White) to the Left Antenna Module -R108
5. HF Connection (White) from the Left Antenna Module -R108

Note. Unlisted connector terminals are not used.

1 - Multi-Pin Connector, 32-Pins (Not Used)

Scheme 39

13 - Right audio input

14 - Screen ground

15 - Video input sync.

16 - Green video input

19 - LF input (-)

20 - LF input (+)

28 - Audio ground

29 - Left video input

30 - Video ground

31 - Blue video input

32 - Red video input

A - 8-Pin Connector (T8p) Brown

2 - Right front speaker (+) (not with BOSE)

3 - Left front speaker (+) (not with BOSE)

6 - Right front speaker (-) (not with BOSE)

7 - Left front speaker (-) (not with BOSE)

B - 12-Pin Connector (T12l) Blue

2 - Signal ground to CD Changer -R41- /Satellite Radio -R146

3 - Speed signal (not used)

4 - Permanent positive to CD Changer

5 - K diagnostic (not used)

6 - CD data out to CD Changer

7 - BOSE coding to ground (only with BOSE)

8 - Left signal from CD Changer/Satellite Radio

9 - Right signal from CD Changer/Satellite Radio

10 - Positive switched to CD Changer

11 - CD data in from CD Changer

12 - CD CLK from CD Changer

C - 12-Pin Connector (T12m) Black

1 - Microphone input (-) from telephone microphone (from MY06)

2 - Signal from Back-Up Light Switch -F4- (not used)

3 - Left front signal to Amplifier (only with BOSE)

4 - Microphone output (-) to Telephone Transceiver -R36- (from MY06)

5 - Left rear signal to Amplifier/Woofer (in left rear luggage compartment) -R44- /Amplifier

6 - LF (-) from Telephone Transceiver/preliminary setup for cell phone package

7 - Microphone input (+) from Telephone Microphone -R38- (from MY06)

8 - Signal ground to Amplifier/Woofer (in left rear luggage compartment)/Amplifier

9 - Right front signal to Amplifier -R12- (only with BOSE)

10 - Microphone output (+) to Telephone Transceiver (from MY06)

11 - Right rear signal to Amplifier/Woofer (in left rear luggage compartment)/Amplifier

12 - LF (+) from Telephone Transceiver/preliminary setup for cell phone package

D - 8-Pin Connector (T16g) Black

9 - CAN-Bus High (Infotainment)

10 - CAN-Bus Low (Infotainment)

11 - NF mute from telephone transceiver -R36- /preliminary setup for cell phone package

12 - Terminal 31

13 - Positive switched to Amplifier/Woofer (in left rear luggage compartment) -R44- /Amplifier -R12

14 - Anti-theft warning system (not used)

15 - Terminal 30

16 - Permanent positive (not used)

STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE CONNECTORS

Connectors

Scheme 40

A - 4-pin connector (T4n) yellow

B - Black 20-pin connector (T20b)

B - Black 20-Pin Connector (T20b)

Scheme 41

11 - CAN bus low (powertrain)

12 - CAN bus high (powertrain)

13 - Cruise control locked "OFF" to engine control module (ECM) -J623

14 - CAN bus high (Comfort)

15 - CAN bus low (Comfort)

16 - "Parking lock" signal from automatic transmission shift gate

17 - Terminal 15 to Vehicle Electrical System Control Module -J519

18 - Terminal 50 to Vehicle Electrical System Control Module

19 - Terminal 30

20 - Terminal 31

Scheme 42

1. Multifunction Steering Wheel Multifunction buttons, removing and installing, refer to «MULTIFUNCTION BUTTONS»(ref-496064-S09369716642012082100000) . Tiptronic Switch, removing and installing, refer to «TIPTRONIC SWITCH»(ref-496064-S15997047482012082100000) .
2. Steering Column Electronic Systems Control Module -J527- On steering column. Connectors, refer to «STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE CONNECTORS»(ref-496064-S23907097332012082100000) . Removing and installing, refer to «STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE»(ref-496064-S29305777182012082100000) .
3. Telephone Transceiver -R36- In electronics box under left front seat.
4. CAN Bus (Comfort)
5. Data Bus OBED Interface -J533- Behind driver side storage compartment.
6. CAN-BUS (Infotainment)
7. Radio -R- In the top of the center console.
8. CD Changer -R41- Inside the glove compartment.
9. CAN Bus (Powertrain)
10. Engine Control Module -J623- In plenum chamber.
11. CAN-Bus (Instrument Cluster)
12. Instrument Cluster Control Module -J285- (Instrument Cluster) In instrument panel.
13. LIN Data Bus (Single Wire Bus)

WIRE CONNECTIONS, RADIO AND CD CHANGER, THROUGH KW 44/06, CHECKING

Switch radio -R- off.

"Chorus"

Press CC/CD button on radio and at the same time, switch radio on.

"Concert"

Press CC button on radio and at the same time, switch radio on.

"Symphony"

Press station button 4 on radio and simultaneously switch radio on and hold down switch-on button.

All

Note. Data wire from radio to CD changer -R41- is not checked.

Wire Connection OK

Shown on display

"CDC CONNECTED"

Wire Connection not OK

Shown on display

"NO CDC"

Check the connector on the CD changer.

Repeat wiring check and if not OK, check wiring connector according to wiring diagram. Refer to the appropriate System Wiring Diagram information.

SATELLITE RADIO, ACTIVATING

When using for first time or when replacing satellite radio -R146- tuner, it must be enabled (activated) by the provider (XM or Sirius).

The subscription and application for activation can coincide with submission of all necessary data (US postal address, credit card number, radio ID (XM) or SID (Sirius)) to the provider's call center.

Only SIRIUS

SIRIUS sends the activation sequence 6 times within the first hour after apply for the activation. If no successful activation results, another activation sequence must be requested at the SIRIUS call center.

Requirements

1. Customer has subscribed to XM or Sirius.
2. Satellite radio is installed and connected.
3. The radio -R- /operating electronics/navigation system control module -J402- is adapted/coded.
4. Ignition switched on.

Procedure

Turn on the radio/operating electronics/navigation system control module and select a satellite radio -R146- reception range.

Attempt to receive "free" channels in XM (e.g. channel 1) or Sirius band (only channel 184).

Change location if necessary.

If free channels can be received clearly, the activation information sent by the provider (XM or Sirius) can also be received clearly.

A poor reception situation can prevent a successful activation even though activation information is being broadcast. In this case, vehicle location must be changed (an activation is also possible while vehicle is moving). There are e.g. workshops, garages, parking buildings, underground garages, fuel filling stations with extensive roofs and all other parking areas with signal shadows must be avoided.

In built-up areas with terrestrial radio system coverage (so-called terrestrial repeaters) as well as inner cities, activation via a repeater is possible instead of satellite.

NAVIGATION SYSTEM, ERROR MESSAGES ON SCREEN

Special tools and workshop equipment required

1. Vehicle Diagnosis, Testing and Information System VAS 5051

If there is a malfunction in the system, either a fault is saved in the DTC and/or an error message is given on the Operating Electronics, Navigation Control Module -J402- display.

At this time, the following error messages can be shown on the operating electronics/navigation system control module display.

Indicator in display

This error message appears

1. DVD cannot be read.
2. DVD is faulty.
3. DVD drive is faulty.

See if DVD drive can read a replacement DVD.

Same error

Perform in adaptation channel 41.

Use the VAS 5051 to do so.

Indicator in display

This error message appears

1. DVD drive cannot read DVD data.
2. DVD is faulty.
3. DVD drive is faulty.

See if DVD drive can read a replacement DVD.

Same error

Perform in adaptation channel 41.

Use the VAS 5051 to do so.

RADIO, CHORUS/CONCERT

Special tools and workshop equipment required

1. Vehicle Diagnosis, Testing and Information System VAS 5051
2. Radio Removal Tool T10057

Note. If control module is replaced, select Replacement function for appropriate control module in "Guided Fault-Finding" routine with the VAS 5051.

Switch off all electrical consumers.

Remove the key.

Removing

Insert two clips on T10057 in release slits on radio -R- until they engage. Points on grip eyes face outward.

Scheme 43

Remove radio from instrument panel.

Release connectors at radio and remove.

Remove T10057 by pressing locking tabs on radio.

Installing

Connect all harness connectors.

Carefully slide radio into instrument panel and let it engage in mounting frame.

RADIO, SYMPHONY

Special tools and workshop equipment required

1. Vehicle Diagnosis, Testing and Information System VAS 5051
2. Radio Removal Tool T10057

Note. If control module is replaced, select Replacement function for appropriate control module in "Guided Fault-Finding" routine with the VAS 5051.

Activate the transportation mode in "symphony II+". Refer to RADIO, SYMPHONY II+ IN TRANSPORT MODE, ACTIVATING/DEACTIVATING .

Switch off all electrical consumers.

Remove the key.

Removing

Insert the T10057 into the slits in the radio -arrows- until it engages. Points on grip eyes face outward.

Scheme 44

Remove radio -R- from instrument panel.

Release connectors at radio and remove.

Remove T10057 by pressing locking tabs on radio.

Installing

Connect all harness connectors.

Carefully slide radio into instrument panel and let it engage in mounting frame.

Deactivate the transportation mode in "symphony II+". Refer to RADIO, SYMPHONY II+ IN TRANSPORT MODE, ACTIVATING/DEACTIVATING .

CD CHANGER

Special tools and workshop equipment required

1. Radio Removal Tool T10057

Switch off all electrical consumers.

Remove the key.

Removing

Open the glove box.

Insert two clips on T10057 in release slits on CD Changer -R41- until they engage. Points on the grip eyelets of tool face outward.

Scheme 45

Remove CD changer from mounting frame.

Disconnect the connector from the CD changer.

Remove T10057 by pushing locking tabs on CD changer.

Installing

Connect harness connector.

Slide CD changer into mounting frame until it engages.

Check the wiring connection to radio (not radio generation II+) after installing. Refer to WIRE CONNECTIONS, RADIO AND CD CHANGER, THROUGH KW 44/06, CHECKING .

IPOD BASEPLATE

Special tools and workshop equipment required

1. Trim removal wedge 3409

Switch off all electrical consumers.

Remove the key.

Removing

Open the glove box.

Remove iPod -1- from iPod Baseplate -R192-.

Scheme 46

Using 3409, carefully pry iPod Baseplate out of retainer -arrows-.

Remove iPod Baseplate from glove compartment and disconnect connection.

Installing

Install in reverse order of removal.

FRONT MID/LOW RANGE LOUDSPEAKER

Note. Removing and installing the left front mid/low range loudspeaker -R101- and right front mid/low range loudspeaker -R102- is the same.

Switch off all electrical consumers.

Remove the key.

Removing

Remove front door trim. Refer to Removal and Installation .

Disconnect the connector on the left front mid/low range loudspeaker -1-.

Scheme 47

Remove screws -2- (2 Nm).

Remove the left front mid/low range loudspeaker -1- from the door.

Installing

Install in reverse order of removal.

REAR MIDRANGE SPEAKER

Note. Removal and installation of Left Rear Midrange Speaker -R105- and Right Rear Midrange Speaker -R106- are identical.

Switch off all electrical consumers.

Remove the key.

Removing

Remove rear door trim. Refer to Removal and Installation .

Disconnect the connector from the left rear midrange speaker -1-.

Remove screws -2- (2 Nm).

Remove the left rear midrange speaker -1- from the door.

Installing

Install in reverse order of removal.

FRONT TREBLE SPEAKER

Note. Removal and installation of Left Front Treble Speaker -R20- and Right Front Treble Speaker -R22- is the same.

Switch off all electrical consumers.

Remove the key.

Removing

The left front treble speaker is attached to the speaker trim and the speaker trim is attached to the A-pillar trim.

Remove A-pillar trim. Refer to Removal and Installation .

Disconnect the connector from the left front treble speaker.

Scheme 48

Turn the left front treble speaker in -direction of arrow- until both tabs line up exactly.

Remove the left front treble speaker.

Installing

Install in reverse order of removal.

Make sure both tabs are lined up exactly and then turn the left front treble speaker counter-clockwise.

REAR TREBLE SPEAKER

Note. Removal and installation of Left Rear Treble Speaker -R14- and Right Rear Treble Speaker -R16- is identical.

Switch off all electrical consumers.

Remove the key.

Removing

Remove rear door trim. Refer to Removal and Installation .

Disconnect the connector -1- from the left rear treble speaker -2-.

Scheme 49

Release the retainers -arrows- and remove the left rear treble speaker -2-.

Installing

Install in reverse order of removal.

CENTER MID/HIGH RANGE SPEAKER

Switch off all electrical consumers.

Remove the key.

Removing

Remove the cover over the center midrange speaker -R158-.

Remove screws -2- (1 Nm).

Scheme 50

Remove the center midrange speaker -1- from the instrument panel -4- and disconnect the connector -3-.

Installing

Install in reverse order of removal.

REAR SPEAKER

Note. Removal and installation of Left Rear Bass Speaker -R4- and Right Rear Bass Speaker -R5- are the same.

Switch off all electrical consumers.

Remove the key.

Removing

Remove the rear side trim panel. Refer to Removal and Installation .

Disconnect the connector on the left rear speaker -1-.

Scheme 51

Remove screws -3- (2 Nm).

Remove the left rear speaker -1- from the side -2-.

Installing

Install in reverse order of removal.

BASS SPEAKER

Switch off all electrical consumers.

Remove the key.

Removing

Remove left luggage compartment side trim. Refer to Removal and Installation .

Disconnect the connector from the bass speaker -R100- -2-.

Scheme 52

Remove nut -1- (5 Nm).

Remove screws -3- (5 Nm).

Remove the bass speaker.

Installing

Install in reverse order of removal.

AMPLIFIER WITH BASS SPEAKER IN LEFT LUGGAGE COMPARTMENT

Note. The amplifier with bass speaker in left luggage compartment -R44- is diagnostic-capable.

Switch off all electrical consumers.

Remove the key.

Removing

Remove left luggage compartment side trim. Refer to Removal and Installation .

Disconnect the connector -2- from the amplifier with bass speaker in left luggage compartment -1-.

Scheme 53

Remove nut -3- (5 Nm).

Remove screws -4- (5 Nm).

Remove the amplifier with bass speaker in left luggage compartment.

Installing

Install in reverse order of removal.

AMPLIFIER

Note. The amplifier -R12- is not diagnostic-capable. Use current flow diagram to check wiring. Refer to the appropriate System Wiring Diagram information.

Switch off all electrical consumers.

Remove the key.

Removing

Remove luggage compartment right side trim. Refer to Removal and Installation .

Disconnect connector on amplifier -2-.

Scheme 54

Remove the screws -1- (4 Nm) and remove the amplifier -2- from the bracket -3-.

Installing

Install in reverse order of removal.

INSIDE MICROPHONE

Special tools and workshop equipment required

1. Special hook 3370

Switch off all electrical consumers.

Remove the key.

Removing

Carefully remove cover on front interior light -W1- with 3370.

Scheme 55

Remove screws -arrows- (3 Nm).

Scheme 56

Tip front interior light downward and out.

If present, release retaining clips -arrows- and remove Radar Interior Monitoring Control Module 1 -G303- -1- from front interior light -W1-.

Scheme 57

Disconnect connector -1- on inside microphone -R74- -2-.

Scheme 58

Release retaining hooks -arrows- and remove inside microphone -2-.

Installing

Install in reverse order of removal.

ANTENNA AMPLIFIER, RIGHT ANTENNA MODULE AND ANTENNA AMPLIFIER 2

Note. There is no difference in removing and installing the antenna amplifier -R24-, right antenna module -R109- and the antenna amplifier 2 -R111-.

Switch off all electrical consumers.

Remove the key.

Removing

Remove rear lid trim. Refer to Removal and Installation .

Disconnect the connectors -1-, -3- and -4- from antenna amplifier -5-.

Scheme 59

Remove the screw -2- (2 Nm) and remove the antenna amplifier -5- from the rear lid.

Installing

Install in reverse order of removal.

LEFT ANTENNA MODULE

Switch off all electrical consumers.

Remove the key.

Removing

Remove the rear lid lower trim panel. Refer to Removal and Installation .

Disconnect all the connectors from the left antenna module -R108-.

Pay attention to the connector leading to the rear window -arrow-.

Scheme 60

Loosen the nut -3- (6 Nm).

Remove the screws -1- and -2- (6 Nm).

Remove the left antenna module from the rear lid.

Installing

Install in reverse order of removal.

Pay attention to the connector leading to the rear window -arrow-.

SATELLITE RADIO

If control module is replaced, select "Replacement" function for appropriate control module in "Guided Fault-Finding" routine with the Vehicle Diagnosis, Testing and Information System VAS 5051

Switch off all electrical consumers.

Remove the key.

Removing

Open the door in the trim panel on the left side of the luggage compartment.

Two clips -2 - hold the satellite radio -R146- -1- in its mount -3-.

Scheme 61

Unclip the clips -2 -.

Remove the satellite radio -1- from the mount -3- and disconnect the connectors.

Installing

Install in reverse order of removal.

Enable satellite radio. Refer to SATELLITE RADIO, ACTIVATING .

Open the door in the trim panel on the left side of the luggage compartment.

TELEPHONE BASEPLATE ON INSTRUMENT PANEL

Switch off all electrical consumers.

Remove the key.

Removing

Remove the cellular telephone -R54- from the telephone baseplate and unclip it.

Turn the telephone baseplate -R126- in -direction of arrow 1- and then remove it in -direction of arrow 2- from the instrument panel.

Scheme 62

Disconnect the connectors -1- and -2- and remove the telephone baseplate.

Scheme 63

Installing

Connect all the connectors.

Push the telephone baseplate onto the mounting plate until it engages.

TELEPHONE BASEPLATE IN CENTER ARMREST

Switch off all electrical consumers.

Remove the key.

Removing

Remove cellular telephone -R54- from telephone baseplate -R126- and unclip it.

Beginning at front -arrow-, carefully pry storage compartment -1- out of trim -2-.

Scheme 64

Remove bolts -arrows- (2 Nm) from underside of storage compartment.

Scheme 65

Disconnect connector -1- and remove bolts -arrows- (1 Nm).

Scheme 66

Disconnect remaining connectors and remove telephone baseplate.

Installing

Install in reverse order of removal.

TELEPHONE MICROPHONE

Switch off all electrical consumers.

Remove the key.

Removing

Unclip the cover on the front interior lamp -W1-.

Disconnect the connector -1- from the telephone microphone -R38- -2-.

Scheme 67

Remove the telephone microphone -2- from the cover -3-.

Installing

Install in reverse order of removal.

ANTENNA

Note. The antenna wires on the satellite radio -R146- (Ter/Sat) and on the coupling (GSM/GPS) are attached inside the luggage compartment on the left side.

Removing

Remove left luggage compartment side trim. Refer to Removal and Installation .

Remove left D-pillar trim. Refer to Removal and Installation .

Lower the rear molded headliner. Refer to Removal and Installation .

Disconnect the connectors -4- on the satellite radio and the coupling.

Scheme 68

Disconnect the cable ties along the antenna wire up to the antenna -R11- -1- on the roof -2-.

Remove nut -3- (6 Nm).

Remove the antenna -1- from the roof -2-.

Installing

Mount the antenna -1- on the roof -2- and align it with the drive direction.

Lay antenna wires in opening on antenna base -arrow- so nut -3- (6 Nm) can be turned.

The antenna wires must lie in the nut opening -3-.

Align the antenna -1- one more time with the drive direction before tightening the nut -3-.

Perform further installation in reverse order.

TELEPHONE TRANSCEIVER

If control module is replaced, select "Replacement" function for appropriate control module in "Guided Fault-Finding" routine using the Vehicle Diagnosis, Testing and Information System VAS 5051.

Switch off all electrical consumers.

Remove the key.

Removing

Remove left front seat. Refer to Removal and Installation .

Fold back the floor mat. Refer to Removal and Installation .

Unclip cover -1- on electronics box -2- and remove it upward.

Scheme 69

Open the locking mechanism on the electronics box in -direction of arrow-.

Remove Bluetooth Antenna -R152- -3- from Telephone Transceiver -R36- -4-.

Remove the telephone transceiver -1- from the electronics box -3- and disconnect the connector -2-.

Scheme 70

Installing

Install in reverse order of removal.

TELEPHONE/NAVIGATION SYSTEM/AUXILIARY HEATER ANTENNA

Note. All vehicles with a telephone and/or navigation and/or an auxiliary heater have a telephone/navigation system/auxiliary heater antenna -R66- (roof antenna). The antenna wires are connected to the cellular telephone amplifier -R86- and/or to the navigation system with CD drive control module -J401- at the left side of the luggage compartment. The antenna wire to the auxiliary heater radio receiver -R64- is routed along the right D-pillar. The trim must be removed from the telephone/navigation system/auxiliary heater antenna up to the control module brackets inside the luggage compartment at the rear and on the left and right side when replacing the telephone/navigation system/auxiliary heater antenna.

Removing

Remove the trim panels on the left and right sides of the luggage compartment. Refer to Removal and Installation .

Remove the trim on the left and right D-pillars. Refer to Removal and Installation .

Lower the rear molded headliner. Refer to Removal and Installation .

Remove nut -2- (5 Nm).

Scheme 71

Disconnect the antenna wire connectors from the cellular telephone amplifier/navigation system with CD drive control module/auxiliary heater radio receiver.

Remove the telephone/navigation system/auxiliary heater antenna -1- from the roof.

Installing

Mount the telephone/navigation system/auxiliary heater antenna -1- on the roof and align it with the drive direction.

Install the antenna wires -3- into the slot on the antenna base -arrow- and install the nut -2- (5 Nm).

The antenna wire -3- must be inside the slit in the nut -2-.

Align the telephone/navigation system/auxiliary heater antenna -2- in drive direction again before tightening nut -3-.

Perform further installation in reverse order.

OPERATING ELECTRONICS, NAVIGATION CONTROL MODULE

Special tools and workshop equipment required

1. Radio Removal Tool T10057

If control module is replaced, select "Replacement" function for appropriate control module in "Guided Fault-Finding" routine using the Vehicle Diagnosis, Testing and Information System VAS 5051.

Switch off all electrical consumers.

Remove the key.

Removing

Place T10057 -arrows- in release slits on Operating Electronics, Navigation Control Module -J402- until they engage. Points on grip eyes face outward.

Scheme 72

Remove Operating Electronics, Navigation Control Module from instrument panel.

Release connectors on Operating Electronics, Navigation Control Module and remove it.

Remove T10057 by pushing locking tabs on Operating Electronics, Navigation Control Module to do so.

Installing

Connect all harness connectors.

Slide Operating Electronics, Navigation Control Module straight into instrument panel until it engages in installation frame.

NAVIGATION/TV TUNER

Special tools and workshop equipment required

1. Radio Removal Tool T10057

Switch off all electrical consumers.

Remove the key.

Removing

Insert the two clips on the T10057 into the slits on the navigation/TV tuner -J415- until they engage. Points on grip eyes face outward.

Scheme 73

Remove navigation/TV tuner from its frame.

Release connectors on navigation/TV tuner and remove it.

Remove T10057 by pushing locking tabs on navigation/TV tuner to do so.

Installing

Connect all harness connectors.

Slide Navigation/TV Tuner -J415- into installation frame until it engages.

RADIO/NAVIGATION DISPLAY CONTROL MODULE

Special tools and workshop equipment required

1. Radio Removal Tool T10057

If control module is replaced, select "Replacement" function for appropriate control module in "Guided Fault-Finding" routine using the Vehicle Diagnosis, Testing and Information System VAS 5051.

Switch off all electrical consumers.

Remove the key.

Removing

Place T10057 -arrows- in release slits on Radio/Navigation Display Control Module -J503- until they engage. Points on grip eyes face outward.

Scheme 74

Remove radio/navigation display control module from instrument panel.

Release connectors on radio/navigation display control module and remove it.

Remove T10057 by pressing locking tabs on radio/navigation display control module.

Installing

Connect all harness connectors.

Slide radio/navigation display control module straight into instrument panel until it engages in installation frame.

If control module is replaced, select "Replacement" function for appropriate control module in "Guided Fault-Finding" routine using the Vehicle Diagnosis, Testing and Information System VAS 5051.

Removing

Disconnect battery ground wire. Refer to [For engine(s) CBRA, BPY, CCTA, CBFA] Removal and Installation .

Observe airbag system safety precautions. Refer to General Information .

Remove the steering wheel. Refer to Removal and Installation .

Remove steering column switch module. Refer to FASTENER TIGHTENING SPECIFICATIONS .

Remove bolt -arrow- (2 Nm) below spiral spring.

Scheme 75

The Steering Column Electronic Systems Control Module -J527- is secure to steering column module with two spring retainers.

Release springs -1- and -2- with a small screwdriver.

Scheme 76

Remove steering column electronic systems control module downward from steering column module.

Installing

Observe airbag system safety precautions. Refer to General Information .

Install in reverse order of removal.

Make sure that all connections have engaged and lines lie in proper guides.

MULTIFUNCTION BUTTONS

Two versions of the multifunction steering wheel are used.

Scheme 77

Multifunction buttons, removing and installing, refer to MULTIFUNCTION BUTTONS, WITH TWO BLOCKS OF BUTTONS .

Scheme 78

Multifunction buttons, removing and installing, refer to MULTIFUNCTION BUTTONS, WITH ROLLER BUTTONS .

MULTIFUNCTION BUTTONS, WITH TWO BLOCKS OF BUTTONS

Removing

Disconnect battery ground wire. Refer to [For engine(s) CBRA, BPY, CCTA, CBFA] Removal and Installation .

Observe airbag system safety precaution. Refer to General Information .

Remove driver's airbag. Refer to Removal and Installation .

Disconnect electrical connection -2-.

Scheme 79

Remove bolts -1- and -3- (1 Nm).

Remove switch unit -4- in -direction of arrow- from airbag unit.

Installing

Install in reverse order of removal.

Make sure that all connections have engaged and lines lie in proper guides.

MULTIFUNCTION BUTTONS, WITH ROLLER BUTTONS

Removing

Disconnect battery ground wire. Refer to [For engine(s) CBRA, BPY, CCTA, CBFA] Removal and Installation .

Observe airbag system safety precautions. Refer to General Information .

Remove driver's airbag. Refer to Removal and Installation .

Disconnect harness connector -1- at button -2-.

Scheme 80

Slide button -2- out of steering wheel in -direction of arrow-.

Turn the button around.

Disconnect the connector -2- to tiptronic switch from multifunction button -1- and remove button.

Scheme 81

Installing

Install in reverse order of removal.

Note. Removal and installation of left multifunction button is identical.

TIPTRONIC SWITCH

Two versions of the multifunction steering wheel are used.

Tiptronic switch, removing and installing, refer to TIPTRONIC SWITCH, WITH TWO BLOCKS OF BUTTONS .

Tiptronic switch, removing and installing, refer to TIPTRONIC SWITCH, WITH ROLLER BUTTONS .

TIPTRONIC SWITCH, WITH TWO BLOCKS OF BUTTONS

Removing

Disconnect battery ground wire. Refer to [For engine(s) CBRA, BPY, CCTA, CBFA] Removal and Installation .

Observe airbag system safety precautions. Refer to General Information .

Remove driver's airbag. Refer to Removal and Installation .

Disconnect electrical connection -2-.

Scheme 82

Rotate buttons -1- inward (to steering wheel center point) and remove.

Installing

Install in reverse order of removal.

Make sure that all connections have engaged and lines lie in corresponding guides.

TIPTRONIC SWITCH, WITH ROLLER BUTTONS

Removing

Remove driver's airbag. Refer to Removal and Installation .

Disconnect trim ring from steering wheel.

Slide multifunction button -2- out of steering wheel in -direction of arrow-.

Turn the button around.

Disconnect the connector -2- from the multifunction button -1-.

Remove screw -arrow- and remove Tiptronic switch downward.

Scheme 83

Installing

Install in reverse order of removal.

Removal and installation of the left switch is identical.

A00503359 051310
