Communication: Component Locations Audi A3 8P facelift

Communication Devices 4 illustrations ~526 words

RNS-E NAVIGATION SYSTEM COMPONENT LOCATIONS

  1. CD Changer -R41- Inside the glove compartment. Connectors, refer to «CD CHANGER CONNECTOR AND CONNECTOR ASSIGNMENTS»(ref-496064-S38473877352012082100000) . Removing and installing, refer to «CD CHANGER»(ref-496064-S39797285392012082100000) . - iPod Baseplate -R192- Connectors, refer to «IPOD BASEPLATE CONNECTOR AND CONNECTOR ASSIGNMENTS»(ref-496064-S12402399332012082100000) . Removing and installing, refer to «IPOD BASEPLATE»(ref-496064-S01466273762012082100000) .
  2. Center Mid/High Range Loudspeaker -R158- In front instrument panel, center. Removing and installing, refer to «CENTER MID/HIGH RANGE SPEAKER»(ref-496064-S31805197162012082100000) .
  3. Inside Microphone -R74- Only with BOSE. In Front Interior Light -W1-. Function test, refer to «INSIDE MICROPHONE, FUNCTION TEST»(ref-496064-S23770732262012082100000) . Removing and installing, refer to «INSIDE MICROPHONE»(ref-496064-S39329393522012082100000) .
  4. Digital Sound System Control Module -R12- Only with BOSE. Behind luggage compartment right side trim. Connectors, refer to «DIGITAL SOUND SYSTEM CONTROL MODULE CONNECTOR AND CONNECTOR ASSIGNMENTS»(ref-496064-S22042643142012082100000) .
  5. Antenna -R11- Ter/Sat/GPS/GSM. Roof antenna. Removing and installing, refer to «ANTENNA»(ref-496064-S03995110302012082100000) .
  6. Antenna Amplifier -R24- On upper left of rear lid. Connectors, refer to «ANTENNA AMPLIFIER CONNECTORS AND CONNECTOR ASSIGNMENTS»(ref-496064-S05910603922012082100000) . Removing and installing, refer to «ANTENNA AMPLIFIER, RIGHT ANTENNA MODULE AND ANTENNA AMPLIFIER 2»(ref-496064-S33359927532012082100000) .
  7. Left Antenna Module -R108- At the bottom of the rear lid on the left side. Connectors, refer to «LEFT ANTENNA MODULE CONNECTORS»(ref-496064-S38897559962012082100000) . Removing and installing, refer to «LEFT ANTENNA MODULE»(ref-496064-S39867532552012082100000) .
  8. Amplifier with Bass Speaker in Left Luggage Compartment -R44- /Bass Speaker -R100- Behind luggage compartment left side trim Connectors amplifier with bass speaker in left luggage compartment, refer to «AMPLIFIER WITH BASS SPEAKER IN LEFT LUGGAGE COMPARTMENT CONNECTOR AND CONNECTOR ASSIGNMENTS»(ref-496064-S19209239642012082100000) . Removing and installing amplifier with bass speaker in left luggage compartment, refer to «AMPLIFIER WITH BASS SPEAKER IN LEFT LUGGAGE COMPARTMENT»(ref-496064-S14601618572012082100000) . Removing and installing bass speaker, refer to «BASS SPEAKER»(ref-496064-S16440821462012082100000) .
  9. Satellite Radio -R146- Behind luggage compartment left side trim. Connectors, refer to «SATELLITE RADIO CONNECTORS AND CONNECTOR ASSIGNMENTS»(ref-496064-S16018678962012082100000) . Removing and installing, refer to «SATELLITE RADIO»(ref-496064-S17529314822012082100000) . Activating, refer to «SATELLITE RADIO, ACTIVATING»(ref-496064-S40645210072012082100000) .
  10. Left Rear Midrange Speaker -R105- /Right Rear Midrange Speaker -R106- In bottom of rear doors. Removing and installing, refer to «REAR MIDRANGE SPEAKER»(ref-496064-S20631648032012082100000) .
  11. Left Rear Treble Speaker -R14- /Right Rear Treble Speaker -R16- In top of rear doors. Removing and installing, refer to «REAR TREBLE SPEAKER»(ref-496064-S01912581702012082100000) .
  12. Left Front Mid/Low Range Loudspeaker -R101- /Right Front Mid/Low Range Loudspeaker -R102- In bottom of front doors. Removing and installing, refer to «FRONT MID/LOW RANGE LOUDSPEAKER»(ref-496064-S04782989402012082100000) .
  13. Left Front Treble Speaker -R20- /Right Front Treble Speaker -R22- In the center of the A-pillar. Removing and installing, refer to «FRONT TREBLE SPEAKER»(ref-496064-S28322094612012082100000) .
  14. Operating Electronics, Navigation Control Module -J402- In the top of the center console. Connectors, refer to «OPERATING ELECTRONICS, NAVIGATION CONTROL MODULE CONNECTORS AND CONNECTOR ASSIGNMENTS»(ref-496064-S09065947052012082100000) . Removing and installing, refer to «OPERATING ELECTRONICS, NAVIGATION CONTROL MODULE»(ref-496064-S29545008472012082100000) .

Scheme 13

Scheme 13: STEERING COLUMN SWITCH MODULE OVERVIEW
  1. Airbag Spiral Spring
  2. Wiper Switch/On-Board Computer
  3. Steering Angle Sensor -G85
  4. Steering Column Electronic Systems Control Module -J527
  5. Black 20-Pin Connector (T20b) on Steering Column Electronic Systems Control Module -J527
  6. Ignition/Starter Switch -D
  7. Turn Signal Switch/Cruise Control Switch

SPECIAL TOOLS

Special tools and workshop equipment required

Scheme 14

Scheme 14: SPECIAL TOOLS

Scheme 15

Scheme 15

Scheme 16

Scheme 16
  1. Vehicle Diagnosis, Testing and Information System VAS 5051
  2. Radio Removal Tool T10057
  3. Trim removal wedge 3409
  4. Special hook 3370
