TEMPERATURE ADJUSTMENT CABLE
Note. Temperature adjustment Bowden cable is present only on vehicles without A/C system. On vehicles with A/C system, a motor moves the temperature door. Base plate -C- is different between vehicles without A/C system (with a control for Bowden cable to temperature door -E-) and with manually regulated A/C system (without a Bowden cable control -E-).
Removing
Bring rotary switch for temperature preselect -A- into position cold stop.
Remove heater controls (Heater Control Module -J65-), refer to HEATER CONTROLS .
Remove the instrument panel and the instrument panel cross-member (central tube). Refer to Removal and Installation .
Note. To prevent the instrument panel shell from damage, instrument panel should be placed on a clean work bench which is covered with clean cardboard.
Disengage lug -D- of Bowden cable sheath -E- and remove Bowden cable sheath from mount of base plate for heater controls.
Scheme 134
Disengage ball on Bowden cable -F- from operating lever -G
Disengage support bracket -A- of Bowden cable sheath -E- and remove Bowden cable sheath from heater guide -C-.
Disengage ball on Bowden cable -B- from temperature door lever.
Installing
Installation is carried out in the reverse order, when doing this note the following
Only install a Bowden cable which has not been kinked and can move easily in Bowden cable sheath.
Do not kink Bowden cable.
