OIL PAN AND OIL PUMP ASSEMBLY OVERVIEW

Note. If large quantities of metal particles or other deposits such as those caused by partial seizure of the crankshaft or connecting rod damage are found in the engine oil, clean the oil channels thoroughly and replace the engine oil cooler to prevent further damage.

Oil pressure, checking. Refer to OIL PRESSURE AND OIL PRESSURE SWITCH, CHECKING .

For engine oil capacities and specifications, refer to the Owner's Manual and/or ServiceNet.

Scheme 28

1. Oil Level Thermal Sensor -G266- Not for engine codes CBFA and CCTA
2. Gasket Replace
3. Bolt Replace Tightening order «OIL PAN AND OIL PUMP ASSEMBLY OVERVIEW»(ref-496105-S22441639472012082100000)
4. Oil Pan Lower Section Removing and installing, refer to «OIL PAN LOWER SECTION»(ref-496105-S36383341382012082100000)
5. Bolt 9 Nm
6. Oil Baffle Replace
7. Bolt 9 Nm
8. Oil Pump Removing and installing, refer to «OIL PUMP»(ref-496105-S09197654802012082100000)
9. Centering Sleeve
10. Chain Tensioner
11. Bolt 9 Nm
12. Bolt Engine codes CDAA and CCZA only 9 Nm
13. Oil Pressure Regulation Valve -N428- Engine codes CDAA and CCZA only
14. O-ring Replace Engine codes CDAA and CCZA only
15. Drive Chain for Oil Pump Mark direction of rotation before removing
16. Gasket Replace
17. Oil Separator Removing and Installing, refer to «OIL SEPARATOR»(ref-496105-S29429487942012082100000)
18. Bolt Tightening Sequence «OIL PAN AND OIL PUMP ASSEMBLY OVERVIEW»(ref-496105-S22441639472012082100000)
19. Oil Pan (Upper Section) Removing and installing, refer to «OIL PAN, UPPER SECTION»(ref-496105-S10836836432012082100000)
20. Bolt 9 Nm
21. Bolt Replace Tightening order «OIL PAN AND OIL PUMP ASSEMBLY OVERVIEW»(ref-496105-S22441639472012082100000)
22. Suction Line Clean strainer if contaminated
23. O-ring Replace
24. Gasket
25. O-ring Replace
26. Non-Return Valve
27. Oil Drain Plug Replace 30 Nm
28. Nut 9 Nm

Oil Pan, Lower Section, Tightening Sequence

Scheme 29

Tighten bolts in 3 stages in -1 to 20- sequence as follows

Oil Pan, Upper Section, Tightening Sequence

Scheme 30

Tighten bolts in 3 stages in -1 to 14- sequence as follows

Oil Separator Tightening Sequence

Scheme 31

Tighten bolts to 9 Nm in the sequence -1 to 9-.

Scheme 32

1. Bracket for Assemblies Removing and installing, refer to «ACCESSORY ASSEMBLY BRACKET»(ref-496101-S24928760432012082100000)
2. Oil Pressure Switch -F1- 1.4 bar - black Checking, refer to «OIL PRESSURE AND OIL PRESSURE SWITCH, CHECKING»(ref-496105-S32558256182012082100000) 20 Nm
3. Gasket Replace
4. O-ring No replacement part, part of the valve unit delivery package
5. O-ring No replacement part, part of the valve unit delivery package
6. Valve Unit With O-rings
7. Oil Filter Element Removing and installing, refer to «ENGINE OIL, DRAINING AND REPLACING OIL FILTER»(ref-496020-S07716678832012082100000) Remove and install using oil filter wrench 3417
8. Bolt 23 Nm
9. Connection
10. Seal Replace
11. Engine Oil Cooler See note, refer to «OIL PAN AND OIL PUMP ASSEMBLY OVERVIEW»(ref-496105-S22441639472012082100000) Ensure sufficient clearance to surrounding components Coolant hose connection diagram, refer to «COOLANT HOSE CONNECTION DIAGRAM»(ref-496038-S21968212452012082100000) Removing and installing, refer to «ENGINE OIL COOLER»(ref-496105-S05104364962012082100000)
12. Gasket Replace
13. Bolt Tightening order «RIBBED BELT DRIVE ASSEMBLY OVERVIEW => Accessory Assembly Bracket Tightening Sequence»(ref-496101-S36985751612012082100000)
