Contents Section: Interior Trim All sections

General information Audi A3 8P рестайлинг 2

Interior Trim 6 illustrations ~1239 words

Scheme 1

Scheme 1: FRONT DOOR TRIM COMPONENT OVERVIEW
Scheme 1: FRONT DOOR TRIM COMPONENT OVERVIEW
  1. Window Regulator Switch Driver side: removing and installing, refer to «DRIVER SIDE WINDOW REGULATOR SWITCH»(/audi/a3/8p-2-2008-2013/remont/exteriorinterior-trim/#interior-trim__driver-side-window-regulator-switch) Front passenger side: removing and installing, refer to «PASSENGER SIDE WINDOW REGULATOR SWITCH»(/audi/a3/8p-2-2008-2013/remont/exteriorinterior-trim/#interior-trim__passenger-side-window-regulator-switch)
  2. Switch Mount For window regulator switch Removing and Installing, refer to «SWITCH MOUNT»(/audi/a3/8p-2-2008-2013/remont/exteriorinterior-trim/#interior-trim__switch-mount)
  3. Bolt 2 Nm
  4. Entry Lamp Removing and Installing, refer to «FRONT DOOR SAFETY LIGHTS AND ENTRY LIGHTS»(/audi/a3/8p-2-2008-2013/remont/exteriorinterior-trim/#interior-trim__front-door-safety-lights-and-entry)
  5. Bolt 4.5 Nm
  6. Door Warning Light With lighting Removing and Installing, refer to «FRONT DOOR SAFETY LIGHTS AND ENTRY LIGHTS»(/audi/a3/8p-2-2008-2013/remont/exteriorinterior-trim/#interior-trim__front-door-safety-lights-and-entry)
  7. Door Warning Light Without lighting Removing and Installing, refer to «FRONT DOOR SAFETY LIGHTS AND ENTRY LIGHTS»(/audi/a3/8p-2-2008-2013/remont/exteriorinterior-trim/#interior-trim__front-door-safety-lights-and-entry)
  8. Passenger Compartment Monitoring Switch -E183- or Alarm System -Off- Switch -E217- Removing and Installing, refer to «PASSENGER COMPARTMENT MONITORING SWITCH OR ALARM SYSTEM -OFF- SWITCH»(/audi/a3/8p-2-2008-2013/remont/exteriorinterior-trim/#interior-trim__passenger-compartment-monitoring-switch-or-alarm)
  9. Securing Clip Quantity: 7
  10. Insulation
  11. Retaining Clip Quantity: 3 for trim panel
  12. Interior Door Mechanism Removing and Installing, refer to «INSIDE DOOR RELEASE MECHANISM»(/audi/a3/8p-2-2008-2013/remont/exteriorinterior-trim/#interior-trim__inside-door-release-mechanism)
  13. Door Opener Lighting
  14. Bolt 1.2 Nm Quantity: 4
  15. Window Regulator Switch (in RF door) -E308- Central locking switch Removing and Installing, refer to «FRONT CENTRAL LOCKING SWITCH»(/audi/a3/8p-2-2008-2013/remont/exteriorinterior-trim/#interior-trim__front-central-locking-switch)
  16. Front Door Trim Removing and Installing, refer to «FRONT DOOR TRIM»(/audi/a3/8p-2-2008-2013/remont/exteriorinterior-trim/#interior-trim) If the door trim panel is being replaced, see if Technical Product Information: 2005913 is applicable
  17. Trim Panel For door trim Removing and Installing, refer to «TRIM MOLDING»(/audi/a3/8p-2-2008-2013/remont/exteriorinterior-trim/#interior-trim__trim-molding)
  18. Bolt 4.5 Nm
  19. Trim Panel Only with BOSE sound system Removing and Installing, refer to «SPEAKER TRIM»(/audi/a3/8p-2-2008-2013/remont/exteriorinterior-trim/#interior-trim__speaker-trim)
  20. Speaker Trim Removing and Installing, refer to «SPEAKER TRIM»(/audi/a3/8p-2-2008-2013/remont/exteriorinterior-trim/#interior-trim__speaker-trim)
  21. Bolt 4.5 Nm
  22. Bolt 2 Nm
  23. Bolt 4.5 Nm
  24. Cover
  25. Bolt 1.2 Nm
  26. Armrest Removing and Installing, refer to «ARMREST»(/audi/a3/8p-2-2008-2013/remont/exteriorinterior-trim/#interior-trim__armrest)
  27. Cover Removing and Installing, refer to «ARMREST»(/audi/a3/8p-2-2008-2013/remont/exteriorinterior-trim/#interior-trim__armrest)
  28. Mirror Adjustment Switch Removing and Installing, refer to «MIRROR ADJUSTMENT SWITCH»(/audi/a3/8p-2-2008-2013/remont/exteriorinterior-trim/#interior-trim__mirror-adjustment-switch)
  29. Symbol Trim

Scheme 2

Scheme 2: DOOR TRIM WIRING ROUTING OVERVIEW
Scheme 2: DOOR TRIM WIRING ROUTING OVERVIEW
  1. Wire to Door Control Module Driver side: Driver Door Control Module -J386- Front passenger side: Front Passenger Door Control Module -J387
  2. Intermediate Coupling for Central Locking -SAFE- Indicator Lamp -K133
  3. Wire to Interior Locking Switch Driver side: driver interior locking button -E308- Front passenger side: front passenger interior locking button -E309
  4. Wire to Door Opener Lighting
  5. Wire to Window Regulator Switch Driver side: power window control head in driver door -E512- Front passenger side: front passenger door window regulator switch -E107
  6. Wire to Passenger Compartment Monitoring Switch -E183- and Alarm System -Off- Switch -E217
  7. Wire to Door Safety Light
  8. Wire to Entry Light
  9. Wire to Mirror Adjustment Switch

Scheme 3

Scheme 3: REAR DOOR TRIM COMPONENT OVERVIEW
Scheme 3: REAR DOOR TRIM COMPONENT OVERVIEW
  1. Armrest Removing and Installing, refer to «ARMREST»(/audi/a3/8p-2-2008-2013/remont/exteriorinterior-trim/#interior-trim)
  2. 2 Nm
  3. Window Regulator Switch Removing and Installing, refer to «WINDOW REGULATOR SWITCH»(/audi/a3/8p-2-2008-2013/remont/exteriorinterior-trim/#interior-trim__window-regulator-switch)
  4. Switch Mount For window regulator switch Removing and Installing, refer to «SWITCH MOUNT»(/audi/a3/8p-2-2008-2013/remont/exteriorinterior-trim/#interior-trim)
  5. Bolt 2 Nm
  6. Cover
  7. Bolt 2 Nm
  8. Door Warning Light With lighting Removing and Installing, refer to «REAR DOOR SAFETY LIGHTS AND ENTRY LIGHTS»(/audi/a3/8p-2-2008-2013/remont/exteriorinterior-trim/#interior-trim__rear-door-safety-lights-and-entry)
  9. Door Warning Light Without lighting Removing and Installing, refer to «REAR DOOR SAFETY LIGHTS AND ENTRY LIGHTS»(/audi/a3/8p-2-2008-2013/remont/exteriorinterior-trim/#interior-trim__rear-door-safety-lights-and-entry)
  10. Securing Clip Quantity: 7
  11. Retaining Clip Quantity: 3 For trim panel
  12. Insulation
  13. Speaker Treble speaker
  14. Interior Door Mechanism Removing and Installing, refer to «INSIDE DOOR RELEASE MECHANISM»(/audi/a3/8p-2-2008-2013/remont/exteriorinterior-trim/#interior-trim)
  15. Door Opener Lighting
  16. Bolt 1.2 Nm Quantity: 4
  17. Rear Door Trim Removing and Installing, refer to «REAR DOOR TRIM»(/audi/a3/8p-2-2008-2013/remont/exteriorinterior-trim/#interior-trim)
  18. Trim Panel For door trim Removing and Installing, refer to «TRIM MOLDING»(/audi/a3/8p-2-2008-2013/remont/exteriorinterior-trim/#interior-trim)
  19. Speaker Trim Removing and Installing, refer to «SPEAKER TRIM»(/audi/a3/8p-2-2008-2013/remont/exteriorinterior-trim/#interior-trim)
  20. Entry Lamp Removing and Installing, refer to «REAR DOOR SAFETY LIGHTS AND ENTRY LIGHTS»(/audi/a3/8p-2-2008-2013/remont/exteriorinterior-trim/#interior-trim__rear-door-safety-lights-and-entry)
  21. Bolt 4.5 Nm
  22. Bolt 1.2 Nm
  23. Cover
  24. Bolt 4.5 Nm

Scheme 4

Scheme 4: DOOR TRIM WIRING ROUTING OVERVIEW
Scheme 4: DOOR TRIM WIRING ROUTING OVERVIEW
  1. Intermediate Coupling For Central Locking -SAFE- Indicator Lamp -K133
  2. Wire to Door Control Module For Left Rear Door Control Module -J388- For Right Rear Door Control Module -J389
  3. Wire to Window Regulator Switch Left rear, refer to Left Rear Power Window Switch In Left Rear Door -E52- Right rear, refer to Right Rear Window Switch In Right Rear Door -E54
  4. Wire to Speaker
  5. Wire to Door Opener Lighting
  6. Wire to Door Safety Light
  7. Wire to Entry Light

Scheme 5

Scheme 5: SUN SHADE COMPONENT OVERVIEW
Scheme 5: SUN SHADE COMPONENT OVERVIEW
  1. Rear Door Trim
  2. Bolt 2.5 Nm
  3. Guide Strip Removing and Installing, refer to «SUN SHADE»(/audi/a3/8p-2-2008-2013/remont/exteriorinterior-trim/#interior-trim__sun-shade)
  4. Sun Shade Removing and Installing, refer to «SUN SHADE»(/audi/a3/8p-2-2008-2013/remont/exteriorinterior-trim/#interior-trim__sun-shade)
  5. Spring Nut

Scheme 6

Scheme 6: INSTRUMENT PANEL COMPONENT LOCATION OVERVIEW
Scheme 6: INSTRUMENT PANEL COMPONENT LOCATION OVERVIEW
  1. Instrument Panel Removing and Installing, refer to «INSTRUMENT PANEL»(/audi/a3/8p-2-2008-2013/remont/exteriorinterior-trim/#interior-trim)
  2. Left Defroster Vent Removing and Installing, refer to «LEFT AND RIGHT DEFROSTER VENTS»(/audi/a3/8p-2-2008-2013/remont/exteriorinterior-trim/#interior-trim__left-and-right-defroster-vents)
  3. Left Instrument Panel Vent Removing and Installing, refer to «LEFT AND RIGHT INSTRUMENT PANEL VENTS»(/audi/a3/8p-2-2008-2013/remont/exteriorinterior-trim/#interior-trim__left-and-right-instrument-panel-vents)
  4. Instrument Cluster Removing and Installing, refer to «[For engine(s) CBRA, BPY, CCTA, CBFA] Removal and Installation»(/audi/a3/8p-2-2008-2013/remont/gauges-instrument-panels/#instruments)
  5. Sunlight Photo Sensor On vehicles without A/C system with cover cap Vehicles with A/C: removing and installing, refer to «SUNLIGHT PHOTO SENSOR»(/audi/a3/8p-2-2008-2013/remont/exteriorinterior-trim/#interior-trim__sunlight-photo-sensor) Vehicles without A/C: removing and installing, refer to «SUNLIGHT PHOTO SENSOR»(/audi/a3/8p-2-2008-2013/remont/exteriorinterior-trim/#interior-trim__sunlight-photo-sensor)
  6. Center Mid/High Range Loudspeaker -R158- Removing and Installing, refer to «Removal and Installation»(/audi/a3/8p-2-2008-2013/remont/communication-devices/#communication)
  7. Center Mid/High Range Speaker Cover Removing and Installing, refer to «CENTER MID/HIGH RANGE SPEAKER COVER»(/audi/a3/8p-2-2008-2013/remont/exteriorinterior-trim/#interior-trim__center-midhigh-range-speaker-cover)
  8. Central Locking -SAFE- Indicator Lamp -K133- Removing and Installing, refer to «CENTRAL LOCKING -SAFE- INDICATOR LAMP»(/audi/a3/8p-2-2008-2013/remont/exteriorinterior-trim/#interior-trim__central-locking-safe-indicator-lamp)
  9. Center Defroster Vent Removing and Installing, refer to «CENTER DEFROSTER VENT»(/audi/a3/8p-2-2008-2013/remont/exteriorinterior-trim/#interior-trim)
  10. Center Instrument Panel Vent Removing and Installing, refer to «CENTER INSTRUMENT PANEL VENT»(/audi/a3/8p-2-2008-2013/remont/exteriorinterior-trim/#interior-trim)
  11. Center Instrument Panel Vent Removing and Installing, refer to «CENTER INSTRUMENT PANEL VENT»(/audi/a3/8p-2-2008-2013/remont/exteriorinterior-trim/#interior-trim)
  12. Passenger Airbag Unit Removing and Installing, refer to «FRONT PASSENGER AIRBAG»(/audi/a3/8p-2-2008-2013/remont/airbag/#passenger-protection-airbags-seat-belts)
  13. Right Defroster Vent Removing and Installing, refer to «LEFT AND RIGHT DEFROSTER VENTS»(/audi/a3/8p-2-2008-2013/remont/exteriorinterior-trim/#interior-trim__left-and-right-defroster-vents)
  14. Right Instrument Panel Cover Removing and Installing, refer to «LEFT AND RIGHT INSTRUMENT PANEL COVER»(/audi/a3/8p-2-2008-2013/remont/exteriorinterior-trim/#interior-trim__left-and-right-instrument-panel-cover)
  15. Right Instrument Panel Vent Removing and Installing, refer to «LEFT AND RIGHT INSTRUMENT PANEL VENTS»(/audi/a3/8p-2-2008-2013/remont/exteriorinterior-trim/#interior-trim__left-and-right-instrument-panel-vents)
  16. Glove Compartment Removing and Installing, refer to «GLOVE COMPARTMENT»(/audi/a3/8p-2-2008-2013/remont/auxiliary-power-unit/#interior-equipment)
  17. CD Changer Removing and Installing, refer to «Removal and Installation»(/audi/a3/8p-2-2008-2013/remont/communication-devices/#communication)
  18. Cell Phone Bracket Removing and Installing, refer to «Removal and Installation»(/audi/a3/8p-2-2008-2013/remont/communication-devices/#communication)
  19. Cupholder/Storage Compartment Cupholder: removing and installing, refer to «CUPHOLDER OR STORAGE COMPARTMENT IN CENTER CONSOLE»(/audi/a3/8p-2-2008-2013/remont/auxiliary-power-unit/#interior-equipment__cupholder-or-storage-compartment-in-center) Storage compartment (depending on the country), removing and installing, refer to «CUPHOLDER OR STORAGE COMPARTMENT IN CENTER CONSOLE»(/audi/a3/8p-2-2008-2013/remont/auxiliary-power-unit/#interior-equipment__cupholder-or-storage-compartment-in-center)
  20. Emergency Flasher Switch Removing and Installing, refer to «EMERGENCY FLASHER SWITCH, FROM 06.2008»(/audi/a3/8p-2-2008-2013/remont/door-locks-anti-theft-systems/#interior-lights-switches__emergency-flasher-switch-from-062008)
  21. Radio Removing and Installing, refer to «Removal and Installation»(/audi/a3/8p-2-2008-2013/remont/communication-devices/#communication)
  22. Right Switch Removing and Installing, refer to «[For engine(s) CBRA, BPY, CCTA, CBFA] FRONT PASSENGER AIRBAG DISABLED INDICATOR LAMP, THROUGH 05.2008»(/audi/a3/8p-2-2008-2013/remont/door-locks-anti-theft-systems/#interior-lights-switches__front-passenger-airbag-disabled-indicator-lamp) or refer to «[For engine(s) CBRA, BPY, CCTA, CBFA] FRONT PASSENGER AIRBAG DISABLED INDICATOR LAMP, FROM 06.2008»(/audi/a3/8p-2-2008-2013/remont/door-locks-anti-theft-systems/#interior-lights-switches__front-passenger-airbag-disabled-indicator-lamp)
  23. ASR/ESP Button Removing and Installing, refer to «[For engine(s) CBRA, BPY, CCTA, CBFA] ASR AND ESP BUTTONS, THROUGH 05.2008»(/audi/a3/8p-2-2008-2013/remont/door-locks-anti-theft-systems/#interior-lights-switches__asr-and-esp-buttons-through-052008) or refer to «[For engine(s) CBRA, BPY, CCTA, CBFA] ASR AND ESP BUTTONS, FROM 06.2008»(/audi/a3/8p-2-2008-2013/remont/door-locks-anti-theft-systems/#interior-lights-switches__asr-and-esp-buttons-from-062008)
  24. Left Switch Removing and Installing, refer to «[For engine(s) CBRA, BPY, CCTA, CBFA] ASR AND ESP BUTTONS, THROUGH 05.2008»(/audi/a3/8p-2-2008-2013/remont/door-locks-anti-theft-systems/#interior-lights-switches__asr-and-esp-buttons-through-052008) and refer to «[For engine(s) CBRA, BPY, CCTA, CBFA] ASR AND ESP BUTTONS, FROM 06.2008»(/audi/a3/8p-2-2008-2013/remont/door-locks-anti-theft-systems/#interior-lights-switches__asr-and-esp-buttons-from-062008)
  25. Heating Controls
  26. Steering Column Switch Module Trim with Gap Cover Removing and Installing, refer to «STEERING COLUMN SWITCH MODULE TRIM»(/audi/a3/8p-2-2008-2013/remont/auxiliary-power-unit/#interior-equipment__steering-column-switch-module-trim)
  27. Lower Steering Column Switch Module Trim Removing and Installing, refer to «STEERING COLUMN SWITCH MODULE TRIM»(/audi/a3/8p-2-2008-2013/remont/auxiliary-power-unit/#interior-equipment__steering-column-switch-module-trim)
  28. Steering Column Switch Module Removing and Installing, refer to «[For engine(s) CBRA, BPY, CCTA, CBFA] Removal and Installation»(/audi/a3/8p-2-2008-2013/remont/exterior-lights/#exterior-lights-switches)
  29. Driver Side Storage Compartment Removing and Installing, refer to «DRIVER SIDE STORAGE COMPARTMENT»(/audi/a3/8p-2-2008-2013/remont/auxiliary-power-unit/#interior-equipment)
  30. Light Switch Removing and Installing, refer to «[For engine(s) CBRA, BPY, CCTA, CBFA] LIGHT SWITCH»(/audi/a3/8p-2-2008-2013/remont/door-locks-anti-theft-systems/#interior-lights-switches__light-switch)
  31. 16-Pin Connector -T16- Diagnostic connector
  32. Fuse Holder Removing and Installing, refer to «[For engine(s) CBRA, BPY, CCTA, CBFA] Removal and Installation»(/audi/a3/8p-2-2008-2013/remont/wiring-system-data-link-connectors-pwr-dist-grnd-dist/#wiring)
  33. Left Instrument Panel Cover Removing and Installing, refer to «LEFT AND RIGHT INSTRUMENT PANEL COVER»(/audi/a3/8p-2-2008-2013/remont/exteriorinterior-trim/#interior-trim__left-and-right-instrument-panel-cover)
  34. Climatronic Control Module -J255- Removing and Installing, refer to «Removal and Installation»(/audi/a3/8p-2-2008-2013/remont/automatic-hvac-system/#air-conditioning)
  35. Radio Preparation Frame Removing and Installing, refer to «RADIO PREPARATION FRAME»(/audi/a3/8p-2-2008-2013/remont/exteriorinterior-trim/#interior-trim__radio-preparation-frame)
  36. Radio Preparation Cover Removing and Installing, refer to «RADIO PREPARATION COVER»(/audi/a3/8p-2-2008-2013/remont/exteriorinterior-trim/#interior-trim__radio-preparation-cover)
  37. Radio Removing and Installing, refer to «Removal and Installation»(/audi/a3/8p-2-2008-2013/remont/communication-devices/#communication)
