ARMREST
Special tools and workshop equipment required
- Trim Removal Wedge 3409
Removing
Scheme 35
Switch off ignition and remove ignition key.
Remove door trim. Refer to FRONT DOOR TRIM .
Remove insulation from door trim.
Remove screws -arrows- and remove armrest.
Release clip -arrow- and remove cover -1-.
Scheme 36
Disconnect the connectors -1- and -2-.
Scheme 37
Remove armrest.
Installation
Installation is reverse of removal, but note the following
Install door trim. Refer to FRONT DOOR TRIM .
Tightening Specifications
| Component | Nm |
|---|---|
| Armrest to door trim | 2 |
