STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE CONNECTOR ASSIGNMENT Audi A3 8P рестайлинг 2

Exterior Lights, Switches 7 illustrations ~1060 words

STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE CONNECTOR ASSIGNMENT

The steering column electronic systems control module -J527- is part of the complete system steering column switch module. and receives signals from steering column switch, for example.

Check steering column electronic systems control module.

Scheme 12

Scheme 12: STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE CONNECTOR ASSIGNMENT
Scheme 12: STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE CONNECTOR ASSIGNMENT
  1. A - Tiptronic switch connector mount 1 - Analog value Tiptronic left down 2 - Ground Tiptronic left 3 - Ground Tiptronic right 4 - Analog value Tiptronic left up
  2. B - Connector mount turn signal switch/cruise control 1 - Voltage supply (terminal 15) 2 - Locked Off 3 - Res (+)/Set (-) 4 - On/off 5 - ground 6 - Lighting (terminal 58) 7 - Headlamp flasher 8 - High beams 9 - Turn signal switch 10 - Ground, turn signal switch
  3. C - Electrical system connector mount Connector assignment (Scheme 13)
  4. D - Connector mount, airbag control module Connector assignment see scheme 14
  5. E - Ignition switch/ignition key removal lock connector mount 1 - Not used 2 - Not used 3 - Ignition key removal lock on terminal 30 4 - Ignition switch ground 5 - Not used 6 - Not used 7 - Ignition switch output terminal 50 8 - Voltage supply terminal 30 to ignition switch 9 - Out put ignition switch terminal S 10 - Output ignition switch terminal X 11 - Output ignition switch terminal P 12 - Output ignition switch terminal 15
  6. F - Connector mount wiper system/DIS 1 - Windshield washer switch signal 2 - Windshield washer ground 3 - Signal wiping rear lid/washing 4 - Not used 5 - DIS signal 6 - DIS/interval potentiometer ground 7 - Signal interval speeds 8 - Not used
  7. G - Spiral spring/airbag/steering wheel heating/multi-function steering wheel/signal horn connector mount 1 - Heated steering wheel + 2 - Heated steering wheel - 3 - Airbag 1 + 4 - Airbag 1 - 5 - Airbag 2 + 6 - Airbag 2 - 7 - Ground (for coil spring/multi-function steering wheel/horn) 8 - Cruise control locked Off/horn signal 9 - Temperature signal on steering wheel heating 10 - Voltage supply terminal 15 with multi-function steering wheel
  8. H - Steering angle sensor connector mount 1 - Light barrier 5 2 - Light barrier 3 3 - Light barrier 1 4 - 12V voltage supply 5 - 5 V voltage supply 6 - Light barrier 6 7 - Light barrier 4 8 - Light barrier 2 9 - Steering angle sensor ground 10 - Light barrier 7

C - Electrical system connector mount

Scheme 13

Scheme 13
Scheme 13
  1. Taxi radio telephone 2
  2. Taxi radio telephone 1
  3. Taxi alarm 2
  4. Taxi alarm 1
  5. Not used
  6. Not used
  7. Not used
  8. Not used
  9. Not used
  10. Powertrain CAN-Bus, shielding
  11. Powertrain CAN bus Low
  12. Power CAN bus high
  13. Cruise control latched Off
  14. Comfort CAN bus high
  15. Comfort CAN bus Low
  16. P-IN (Selector lever P contact)
  17. Auxiliary output terminal 15
  18. Auxiliary output terminal 50
  19. Terminal 30 voltage supply
  20. Terminal 31 voltage supply

D - Connector mount, airbag control module

  1. Airbag 1
  2. Airbag 1 +
  3. Airbag 2 +
  4. Airbag 2

Scheme 14

Scheme 14: IGNITION SWITCH PIN ASSIGNMENT
Scheme 14: IGNITION SWITCH PIN ASSIGNMENT
  1. Terminal 50
  2. Terminal 30
  3. S terminal
  4. X terminal
  5. Terminal P
  6. Terminal 15

Scheme 15

Scheme 15: PARKING AID ASSEMBLY OVERVIEW, THROUGH 05.2008
Scheme 15: PARKING AID ASSEMBLY OVERVIEW, THROUGH 05.2008
  1. Rear Parking Aid Warning Buzzer -H15- Under the belt guide for the rear right seat belt Removing and installing, refer to «REAR PARKING AID WARNING BUZZER»(/audi/a3/8p-2-2008-2013/remont/exterior-lights/#exterior-lights-switches__rear-parking-aid-warning-buzzer)
  2. Parking Aid Control Module -J446- In luggage compartment at rear, right side, below side trim Removing and installing, refer to «PARKING ASSIST CONTROL MODULE»(/audi/a3/8p-2-2008-2013/remont/exterior-lights/#exterior-lights-switches__parking-assist-control-module)
  3. Sensor for Parking Aid In rear bumper Removing and installing, refer to «REAR PARKING AID SENSORS»(/audi/a3/8p-2-2008-2013/remont/exterior-lights/#exterior-lights-switches)

Scheme 16

Scheme 16: FRONT PART ASSIST ASSEMBLY OVERVIEW, FROM 06.2008
Scheme 16: FRONT PART ASSIST ASSEMBLY OVERVIEW, FROM 06.2008
  1. Left Front Parallel Parking Assistance Sensor (vehicle - left side) -G568- Only on vehicles with parallel parking assistance Removing and installing, refer to «LEFT AND RIGHT FRONT PARALLEL PARKING ASSISTANCE SENSORS»(/audi/a3/8p-2-2008-2013/remont/exterior-lights/#exterior-lights-switches)
  2. Left Front Parking Aid Sensor -G255- In front bumper Removing and installing, refer to «FRONT PARKING AID SENSORS»(/audi/a3/8p-2-2008-2013/remont/exterior-lights/#exterior-lights-switches)
  3. Left Front Center Parking Aid Sensor -G254- In the radiator grille Removing and installing, refer to «FRONT PARKING AID SENSORS»(/audi/a3/8p-2-2008-2013/remont/exterior-lights/#exterior-lights-switches)
  4. Right Front Center Parking Aid Sensor -G253- In the radiator grille Removing and installing, refer to «FRONT PARKING AID SENSORS»(/audi/a3/8p-2-2008-2013/remont/exterior-lights/#exterior-lights-switches)
  5. Right Front Parking Aid Sensor -G252- In front bumper Removing and installing, refer to «FRONT PARKING AID SENSORS»(/audi/a3/8p-2-2008-2013/remont/exterior-lights/#exterior-lights-switches)
  6. Right Front Parallel Parking Assistance Sensor -G569- Only on vehicles with parallel parking assistance Removing and installing, refer to «LEFT AND RIGHT FRONT PARALLEL PARKING ASSISTANCE SENSORS»(/audi/a3/8p-2-2008-2013/remont/exterior-lights/#exterior-lights-switches)
  7. Parking Aid Button -E266- Only with 8-channel parking aid Removing and installing, refer to «PARK ASSIST BUTTON, FROM 06.2008»(/audi/a3/8p-2-2008-2013/remont/door-locks-anti-theft-systems/#interior-lights-switches__park-assist-button-from-062008)
  8. Parking Aid Control Module -J446- - three-door
  9. Bracket For parking aid control module - three-door
  10. Bracket For parking aid control module - Sportback
  11. Parking Aid Control Module - Sportback Removing and installing, refer to «PARKING ASSIST CONTROL MODULE»(/audi/a3/8p-2-2008-2013/remont/exterior-lights/#exterior-lights-switches)
  12. Expanding Clip
  13. Front Parking Aid Warning Buzzer -H22- On the central tube for the instrument panel behind the driver side storage compartment Removing and installing, refer to «FRONT PARKING AID WARNING BUZZER, 8-CHANNEL PARKING AID»(/audi/a3/8p-2-2008-2013/remont/exterior-lights/#exterior-lights-switches)
  14. Expanding Clip

Scheme 17

Scheme 17: REAR PARK ASSIST ASSEMBLY OVERVIEW, FROM 06.2008
Scheme 17: REAR PARK ASSIST ASSEMBLY OVERVIEW, FROM 06.2008
  1. Parking Aid Control Module -J446- - three-door
  2. Bracket For parking aid control module - three-door
  3. Right Rear Parking Aid Sensor -G206- Removing and installing, refer to «REAR PARKING AID SENSORS»(/audi/a3/8p-2-2008-2013/remont/exterior-lights/#exterior-lights-switches)
  4. Right Rear Center Parking Aid Sensor -G205- Removing and installing, refer to «REAR PARKING AID SENSORS»(/audi/a3/8p-2-2008-2013/remont/exterior-lights/#exterior-lights-switches)
  5. Left Rear Center Parking Aid Sensor -G204- Removing and installing, refer to «REAR PARKING AID SENSORS»(/audi/a3/8p-2-2008-2013/remont/exterior-lights/#exterior-lights-switches)
  6. Left Rear Parking Aid Sensor -G203- Removing and installing, refer to «REAR PARKING AID SENSORS»(/audi/a3/8p-2-2008-2013/remont/exterior-lights/#exterior-lights-switches)
  7. Expanding clip
  8. Rear Parking Aid Warning Buzzer -H15- - Sportback Removing and installing, refer to «REAR PARKING AID WARNING BUZZER»(/audi/a3/8p-2-2008-2013/remont/exterior-lights/#exterior-lights-switches)
  9. Expanding Clip
  10. Expanding Clip
  11. Rear Parking Aid Warning Buzzer -H15- - Three-door
  12. Expanding Clip
  13. Bracket For parking aid control module - Sportback
  14. Parking Aid Control Module - Sportback Removing and installing, refer to «PARKING ASSIST CONTROL MODULE»(/audi/a3/8p-2-2008-2013/remont/exterior-lights/#exterior-lights-switches)

Scheme 18

Scheme 18: AUTOMATIC HEADLAMP VERTICAL AIM CONTROL ASSEMBLY OVERVIEW
Scheme 18: AUTOMATIC HEADLAMP VERTICAL AIM CONTROL ASSEMBLY OVERVIEW
  1. Right Headlamp Beam Adjustment Motor -V49- Inside the headlamp
  2. Left Headlamp Beam Adjustment Motor -V48- Inside the headlamp
  3. Left Front Level Control System Sensor -G78- Component location is on left front control arm Removing and installing. Refer to «Removal and Installation»(/audi/a3/8p-2-2008-2013/remont/suspension-front/#front-suspension)
  4. Headlamp Range Control Module -J431- Component location is on the front of the central tube for the instrument panel inside the driver footwell Removing and installing, refer to «HEADLAMP RANGE CONTROL MODULE»(/audi/a3/8p-2-2008-2013/remont/exterior-lights/#exterior-lights-switches__headlamp-range-control-module)
  5. Left Rear Level Control System Sensor -G76- Component location is on rear left control arm Removing and installing. Refer to «Removal and Installation»(/audi/a3/8p-2-2008-2013/remont/suspension-rear/#rear-suspension)
