Installing
Install in reverse order of removal, noting the following
Do not touch glass cone with bare hands.
Secure socket by turning clockwise.
Close the housing lid.
Scheme 30
Switch off ignition and remove ignition key.
Turn light switch to 0 position.
To work on the left headlamp, remove the air filter housing. Refer to PREPARING TO WORK ON HEADLAMPS, THROUGH 05.2008 .
Release spring clip -arrow- and remove high beam/parking lamp housing cover from headlamp housing.
Remove bulb -2- from spring clips -arrows-.
Scheme 31
Disconnect harness connector -1- at high beam bulb.
Install in reverse order of removal, noting the following
Insert bulb in housing, taking care not to touch glass bulb with bare hands.
Place bulb on lower spring clip.
Press bulb in housing over upper spring clamp resistance.
Connect the connector and close the housing cover.
Secure housing cover using wire clamp.
