Maintenance Information Audi 5000 CS

Procedures 9 illustrations ~4116 words

VIN LOCATION

The Vehicle Identification Number (VIN) is located on the left side of the dash panel at the base of the windshield. The VIN chart explains the code characters.

VIN CODE ID EXPLANATION

Numbers preceding the explanations in the legend below refer to the sequence of characters as listed on VIN identification label. See VIN example below.

VIN Code ID Explanation. Scheme 2

Scheme 2: VIN Code ID Explanation
Scheme 2: VIN Code ID Explanation

SEVERE & NORMAL SERVICE DEFINITIONS

Note. Use the Severe Service schedule if the vehicle to be serviced is operated under ANY (one or more) of these conditions

Service is recommended at mileage intervals based on vehicle operation. Service schedules are based on the following primary operating conditions

Normal Service

  1. Driven More Than 10 Miles Daily
  2. No Operating Conditions From Severe Service

Severe Service (Unique Driving Conditions)

  1. Short Trips In Freezing Temperatures
  2. Towing Or Heavily Loaded
  3. Severe Dust Conditions
  4. Hot Weather, Stop-And-Go Driving
  5. Extensive Idling Conditions (Taxi Or Delivery Type Service)

CAMSHAFT TIMING BELT

CAUTIONFailure to replace a faulty camshaft timing belt may result in serious engine damage.

The condition of camshaft drive belts should always be checked on vehicles which have more than 50,000 miles. Although some manufacturers do not recommend belt replacement at a specified mileage, others require it at 60,000-100,000 miles. A camshaft drive belt failure may cause extensive damage to internal engine components on most engines, although some designs do not allow piston-to-valve contact. These designs are often called "Free Wheeling".

Many manufacturers changed their maintenance and warranty schedules in the mid-1980's to reflect timing belt inspection and/or replacement at 50,000-60,000 miles. Most service interval schedules in this manual reflect these changes.

Belts or components should be inspected and replaced if any of the following conditions exist

  1. Cracks Or Tears In Belt Surface
  2. Missing, Damaged, Cracked Or Rounded Teeth
  3. Oil Contamination
  4. Damaged Or Faulty Tensioners
  5. Incorrect Tension Adjustment

Check camshaft timing belt condition every 20,000 miles. Replace belt as necessary. Timing belt failure will result in engine damage.

BRAKE FLUID SERVICE

CAUTIONReplace brake fluid and check BRAKE warning light switch function every 2 years regardless of mileage. DO NOT add or mix DOT 5 silicone type brake fluid with brake fluid in vehicle, as severe component corrosion could result and may lead to brake system failure.

Scheme 3

Scheme 3: SERVICE POINT LOCATIONS
Scheme 3: SERVICE POINT LOCATIONS

LUBRICATION SPECIFICATIONS

Note. Audi does not recommend the use of oil additives, as it may adversely affect the warranty.

TIRE SIZE & INFLATION SPECIFICATIONS

Tire specifications are imprinted on tire sidewall. The required cold tire inflation pressures are listed on a sticker on inside of fuel filler door and must never exceed maximum value molded on tire sidewall. Before replacing original tires on vehicle with all season or radial snow tires, consult an Audi dealer for technical information on the required specifications. Snow tires should be mounted on all four wheels on FWD vehicles, and must be mounted on all four wheel for vehicles with 4WD. Snow chains may be used on front wheels only. The compact spare tire is intended for temporary use only; it is limited to 50 MPH (80 km/h) and must be inflated to 60 psi (4.22 kg/cm 2 ).

CAUTIONDO NOT mix tires of different design such as steel belted radials with radial bias belted or bias ply tires. Mixing tire types will adversely affect road handling and may lead to loss of vehicle control. DO NOT use spare tire on any other wheel or any other tire on compact spare wheel. DO NOT use snow chains on compact spare.

WHEEL RIM & LUG BOLT SPECIFICATIONS

The original wheel rims on vehicle comply with all applicable Federal Motor Vehicle Safety Standards. Before replacing original wheel rims, consult an Audi dealer for technical information regarding wheel rims and bolt specifications. Tighten all wheel lug nuts to 80 ft. lbs. (108 N.m). Always tighten wheel lug nuts in a crisscross pattern.

BATTERY SPECIFICATIONS

CAUTIONWhen battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See COMPUTER RELEARN PROCEDURES article in the GENERAL INFORMATION section.

Battery is located under rear seat in vehicle with factory-installed air conditioner. On other vehicles, battery is installed under engine hood. Under normal operating conditions, battery delivered with vehicles is maintenance-free. However, at high outside temperature it is advisable to check battery fluid level at regular intervals through transparent battery housing. Fluid level should always be between MIN and MAX marks in each cell. Battery specifications are listed on battery housing. Replacement battery must meet all requirements and dimensions as specified on original battery.

ANTI-LOCK BRAKE SYSTEM

The anti-lock brake system contains electronic equipment that can be susceptible to interference caused by improperly installed or high output radio transmitting equipment. Since this interference could cause the possible loss of the anti-lock braking capability, such equipment should be installed by qualified professionals.

On models equipped with anti-lock brake systems, ALWAYS observe the following cautions

  1. DO NOT attempt to bleed hydraulic system without first referring to the appropriate ANTI-LOCK BRAKE SYSTEM article in the BRAKES Section.
  2. DO NOT mix tire sizes. As long as tires remain close to the original diameter, increasing the width is acceptable. Rolling diameter must be identical for all 4 tires. Some manufacturers recommend tires of the same brand, style and type. Failure to follow this precaution may cause inaccurate wheel speed readings.
  3. Use ONLY recommended brake fluids. DO NOT use silicone brake fluids in an ABS-equipped vehicle.

BATTERY WARNING

WARNINGWhen battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION section.

REPLACING BLOWN FUSES

Before replacing a blown fuse, remove ignition key, turn off all lights and accessories to avoid damaging the electrical system. Be sure to use fuse with the correct indicated amperage rating. The use of an incorrect amperage rating fuse may result in a dangerous electrical system overload.

BRAKE PAD WEAR INDICATOR

Indicator will cause a squealing or scraping noise, warning that brake pads need replacement.

CATALYTIC CONVERTER

Continued operation of vehicle with a severe malfunction could cause converter to overheat, resulting in possible damage to converter and vehicle.

Any modification to the exhaust system on turbo models, which reduces exhaust backpressure, will lead to lean fuel mixtures and excessive spark advance. This could cause serious engine damage.

COOLANT (PROPYLENE-GLYCOL FORMULATIONS)

CAUTIONTo avoid possible damage to vehicle use only ethylene-glycol based coolants with a mixture ratio from 44-68% anti-freeze. DO NOT use 100% anti-freeze as it will cause the formation of cooling system deposits. This results in coolant temperatures of over 300° F (149°C) which can melt plastics. 100% anti-freeze has a freeze point of only -8° F (-22°C).
CAUTIONPropylene-Glycol Mixtures has a smaller temperature range than Ethylene-Glycol. The temperature range (freeze-boil) of a 50/50 Anti-Freeze/Water Mix is as follows: Propylene-Glycol -26° F (-32°C) - 257° F (125°C) Ethylene-Glycol -35° F (-37°C) - 263° F (128°C)
CAUTIONPropylene-Glycol/Ethylene-Glycol Mixtures can cause the destabilization of various corrosion inhibitors. Also Propylene-Glycol/Ethylene-Glycol has a different specific gravity than Ethylene-Glycol coolant, which will result in inaccurate freeze point calculations.

ELECTROSTATIC DISCHARGE SENSITIVE (ESD) PARTS

WARNINGMany solid state electrical components can be damaged by static electricity (ESD). Some will display a warning label, but many will not. Discharge personal static electricity by touching a metal ground point on the vehicle prior to servicing any ESD sensitive component.

ENGINE OIL

CAUTIONNever use non-detergent or straight mineral oil.

FUEL SYSTEM SERVICE

WARNINGRelieve fuel system pressure prior to servicing any fuel system component (fuel injection models).

HALOGEN BULBS

WARNINGHalogen bulbs contain pressurized gas which may explode if overheated. DO NOT touch glass portion of bulb with bare hands. Eye protection should be worn when handling or working around halogen bulbs.

RADIATOR CAP

CAUTIONAlways disconnect the fan motor when working near the radiator fan. The fan is temperature controlled and could start at any time even when the ignition key is in the OFF position. DO NOT loosen or remove radiator cap when cooling system is hot.

RADIATOR FAN

WARNINGKeep hands away from radiator fan. Fan is controlled by a thermostatic switch which may come on or run for up to 15 minutes even after engine is turned off.

TURBOCHARGED MODELS

CAUTIONDo not race engine immediately after starting. When stopping engine, allow engine to idle for approximately 60 seconds before shutting it off. Failure to do so may cause turbocharger damage due to lack of oil flowing to the turbocharger bearings.

WARRANTY INFORMATION

CAUTIONDue to the different warranties offered in various regions and the variety of after-market extended warranties available, please refer to the warranty package that came with the vehicle to verify all warranty options.
CAUTIONAlways refer to customer's copy of warranty information for specific model application and/or coverage limitations. Due to mileage and time limits, factory warranties may no longer apply to these models (except rust perforation warranty on 1987 models).

BASIC NEW CAR LIMITED WARRANTY

Everything is covered for 24 months, regardless of mileage, provided vehicle is maintained and used in accordance with instructions for care and use in Audi Owner's Manual. Warranty begins on date vehicle is delivered or put in use, whichever occurs first. Covers cost to all parts and labor needed to repair or adjust any item (except tires) on vehicle that have been proven defective in material or workmanship under normal use. If a tire is defective, a credit will be given towards purchase of new tire. The amount of credit is equal to percentage of original tread depth remaining, multiplied by the suggested retail price of an equivalent new tire.

PERFORATION WARRANTY

Covers any repair or replacement of body-sheet metal parts on 1985 and newer vehicles that is perforated due to corrosion as a result of defects in workmanship or material. Warranty begins on date vehicle is delivered or first put in use, whichever occurs first and lasts for 6 years regardless of mileage.

EMISSION CONTROL SYSTEM WARRANTY (EXCEPT CALIFORNIA)

Manufacturer warrants its emission components in vehicle to be free of defects in material and workmanship and that vehicle is designed, built and equipped to conform at time of sale to all applicable Federal standards for emission control system. Warranty begins on date vehicle is delivered or first put in use and is effective for 5 years or 50,000 miles, whichever occurs first.

EMISSION PERFORMANCE WARRANTY (EXCEPT CALIFORNIA)

Vehicle is warranted to comply to all applicable emissions standards as judged by an EPA-approved State Inspection and Maintenance Test (I/M Test) for 5 years or 50,000 miles, whichever occurs first. Listed below are primary components affecting vehicle's emission control system. The components listed are covered for 5 years or 50,000 miles, whichever occurs first. Warranty begins on date vehicle is delivered or first put in use, whichever occurs first.

  1. Air/Fuel Ration Feedback And Control System
  2. Deceleration Devices
  3. Spark Advance/Retard System
  4. Vapor Storage Canister
  5. Vapor Liquid Separator
  6. Fuel Tank And Filler Cap
  7. Vacuum Restrictor
  8. PCV Valve
  9. EGR Valve
  10. EGR Rate Feedback And Control System
  11. Catalytic Converter
  12. Restricted Fuel Filler Neck
  13. CO Testing Tube And Components
  14. Hoses, Clamps, Fittings And Tubing
  15. Vacuum, Time Sensitive Valves And Temperature Switches
  16. Electronic Controls
  17. Mileage Counter

EMISSION CONTROL SYSTEMS WARRANTY (CALIFORNIA)

Emissions control system in vehicle is warranted to be free of defects in material and workmanship, and that vehicle is designed, built and equipped to conform at time of sales to applicable requirements of the California Air Resources Board. For vehicles equipped with fuel injection engine, warranty period is for 5 years/50,000 miles, except for few items, which are only covered for 24 months/24,000 miles. Diesel engine vehicles are covered for 10 years or 100,000 miles, whichever occurs first. Warranty begins on date vehicle is delivered or put in use, whichever occurs first. The warranted parts are as listed below.

2 Years/24,000 Miles - Gasoline Engine

  1. Fuel Injection System
  2. Cold Start Enrichment System
  3. Distributor And Internal Parts
  4. Spark Plugs
  5. Ignition Wires
  6. Hoses, Clamps, Fittings, Tubing, Sealing Gaskets/Devices And Mounting Hardware
  7. Pulleys, Belts And Idlers

5 Years/50,000 Miles - Gasoline Engine

  1. Air/Fuel Ration Feedback And Control System
  2. Controlled Hot Air Intake System
  3. Intake Manifold
  4. Turbocharger
  5. Spark Advance/Retard System
  6. Ignition Coil And Control Module
  7. Vapor Storage Canister
  8. Vapor Liquid Separator
  9. Fuel Tank And Filler Cap
  10. PCV Valve
  11. Oil Filler Cap
  12. EGR Valve
  13. EGR Rate Feedback And Control System
  14. Catalytic Converter
  15. Restricted Fuel Filler Neck
  16. Exhaust Manifold-To-Catalytic Converter
  17. Vacuum, Time Sensitive Valve And Temperature Switches
  18. Electronic Controls

5 Years/50,000 Miles - Diesel Engine

  1. Fuel Injection System
  2. Fuel Injection Nozzles
  3. Hoses, Clamps, Fittings And Tubing
  4. Pulleys, Belt And Idlers

FUSE PANEL LOCATION

The fuses are arranged in one centralized unit. The fuse/relay box is located under engine hood, on left side in water drain tray and is protected by a cover. In addition to fuse/relay panel, some of the newer models are equipped with auxiliary relay panels.

CAUTIONUse extreme care when trouble shooting electrical system. Relay locations are subject to change and may vary from vehicle to vehicle depending on options. If in doubt, consult an Audi dealer before replacing any relay.

Scheme 4

Scheme 4: FUSE PANEL IDENTIFICATION (1983-85 5000 & 5000 TURBO)
Scheme 4: FUSE PANEL IDENTIFICATION (1983-85 5000 & 5000 TURBO)

Fuse & Circuit Breaker Identification

  1. 1 - 25 Amp Large Heater Blower, A/C, Tachometer
  2. 2 - 8 Amp (Spare)
  3. 3 - 8 Amp Left High Beam Headlight
  4. 4 - 8 Amp Right High Beam Headlight
  5. 5 - 16 Amp Fuel Pump (CIS Fuel Injection)
  6. 6 - 8 Amp Right Side Marker & Taillights
  7. 7 - 8 Amp Left Side Marker & Taillights, Engine Hood Illumination
  8. 8 - 8 Amp Glove Compartment & License Plate Lights, Instrument Panel Illumination
  9. 9 - 16 Amp Combination Instrument, Sliding Roof, Cruise Control, Horn
  10. 10 - 25 Amp Radiator Fan Motor
  11. 11 - 16 Amp Brakelights
  12. 12 - 16 Amp Interior Light, Radio, Electrical Mirror, Clock, Cigarette Lighter, Power Antenna
  13. 13 - 8 Amp Right Low Beam Headlight
  14. 14 - 8 Amp Left Low Beam Headlight
  15. 15 - 16 Amp Back-Up Lights, Wiper Motor
  16. 16 - 25 Amp Rear Window Defogger
  17. 17 - 8 Amp Flasher Unit, Turn Signals
  18. 18 - 25 Amp Power Windows
  19. 19 - 16 Amp Rear Cigarette Lighter
  20. 20 - 8 Amp Central Locking System
  21. 21 - Blank
  22. 22 - Blank

Scheme 5

Scheme 5: FUSE PANEL IDENTIFICATION (1984 5000S)
Scheme 5: FUSE PANEL IDENTIFICATION (1984 5000S)
  1. 1 - 15 Amp Foglights
  2. 2 - 15 Amp Emergency Flasher, Turn Signals
  3. 3 - 25 Amp Horn, Cigarette Lighter, Reading Lights, Clock, Make-Up Mirror, Interior Lights
  4. 4 - 15 Amp Brakelights, Luggage Compartment Light
  5. 5 - Blank
  6. 6 - 5 Amp Right Side Marker Light
  7. 7 - 5 Amp Left Side Marker Light
  8. 8 - 10 Amp Right High Beam Headlight
  9. 9 - 10 Amp Left High Beam Headlight
  10. 10 - 10 Amp Right Low Beam Headlight
  11. 11 - 10 Amp Left Low Beam Headlight
  12. 12 - 15 Amp Instrument, Back-Up & Auto-Check Lights
  13. 13 - 15 Amp Fuel Pump
  14. 14 - 15 Amp Instrument Panel, License Plate, Glove & Engine Compartments Lights
  15. 15 - 15 Amp Windshield Washer & Wiper
  16. 16 - 30 Amp Rear Window Defogger
  17. 17 - 30 Amp A/C, Heater Fan
  18. 18 - 30 Amp Power Sun Roof
  19. 19 - 10 Amp Central Locking System
  20. 20 - 30 Amp Seat Heater, Electric Mirror
  21. 21 - 25 Amp Rear Cigarette Lighter
  22. 22 - 80 Amp (Diesel Only) Glow Plug
  23. 23 - Blank
  24. 24 - 15 Amp Seat Memory (Power Seat Adjustment)
  25. 25 - Blank
  26. 26 - Blank
  27. 27 - 30 Amp Power Windows
  28. 28 - Blank
  29. 29 - Spare Fuses
  30. 30 - Relay Foglights (If Equipped)
  31. 31 - Relay Radiator Fan
  32. 32 - Relay Upshift Indicator (If Equipped)
  33. 33 - Relay Manual Transmission Fuel Shut-Off (If Equipped)
  34. 34 - Relay Load Reduction
  35. 35 - Relay A/C Clutch Cut-Out (Temperature)
  36. 36 - Relay Horn
  37. 37 - Relay Automatic Transmission
  38. 38 - Relay Wash/Wipe Interval
  39. 39 - Relay (Gasoline) Fuel Pump Relay (Diesel) Diesel Pre-Glow
  40. 40 - Relay A/C Magnetic Clutch

Scheme 6

Scheme 6: FUSE PANEL IDENTIFICATION (1985-88 5000S)
Scheme 6: FUSE PANEL IDENTIFICATION (1985-88 5000S)
  1. 1 - 15 Amp (1985-86) Foglights Blank (1987-88)
  2. 2 - 15 Amp Emergency Flasher
  3. 3 - 25 Amp Horn, Stoplights
  4. 4 - 15 Amp (1985-86) Luggage Compartment, Interior & Vanity Mirror Lights, Clock, Radio & Cigarette Lighter
  5. 15 Amp (1987-88) Reading, Luggage Compartment, Interior & Vanity Mirror Lights, Radio, Clock, Board Computer, Cigarette Lighter
  6. 5 - Blank
  7. 6 - 5 Amp Right Side Marker Light
  8. 7 - 5 Amp Left Side Marker Light
  9. 8 - 10 Amp Right High Beam, High Beam Indicator
  10. 9 - 10 Amp Left High Beam Headlight
  11. 10 - 10 Amp Right Low Beam Headlight
  12. 11 - 10 Amp Left Low Beam Headlight
  13. 12 - 5 Amp (1985-86) Instrument, Back-Up & Turn Signal Lights 5 Amp (1987-88) Instrument, Back-Up, Turn Signal & Auto-Check Lights, Differential Locks
  14. 13 - 15 Amp Fuel Pump
  15. 14 - 5 Amp License Plate Light
  16. 15 - 25 Amp Windshield Wipers
  17. 16 - 30 Amp Rear Window Defogger
  18. 17 - 30 Amp Heater Control Illumination, A/C, Glove Compartment Light
  19. 18 - 25 Amp Rear Window Wiper
  20. 19 - 10 Amp Locking System & Power Mirrors
  21. 20 - 20 Amp Seat Heater
  22. 21 - 25 Amp Rear Cigarette Lighter
  23. 22 - 80 Amp (Diesel Only) Glow Plug
  24. 23 - 30 Amp Seat Memory (Power Seat Adjustment)
  25. 24 - 10 Amp CIS-E Power Supply
  26. 25 - Blank
  27. 26 - Blank
  28. 27 - Blank
  29. 28 - Blank
  30. 29 - Spare Fuses
  31. 30 - Relay Foglights (If Equipped)
  32. 31 - Relay Radiator Cooling Fan (2nd Stage)
  33. 32 - Relay Upshift Indicator (If Equipped)
  34. 33 - Relay Manual Transmission Fuel Shut-Off (If Equipped)
  35. 34 - Relay Load Reduction
  36. 35 - Relay (1985) Reading Lights Blank (1986) Relay (1987-88) Radiator Cooling Fan (1st Stage)
  37. 36 - Relay Horn
  38. 37 - Relay (1985-86) Automatic Transmission Relay (1987-88) Anti-Theft
  39. 38 - Relay Wash/Wipe Interval
  40. 39 - Relay (Gasoline) Fuel Pump Relay (Diesel) Diesel Pre-Glow
  41. 40 - Relay (1985 & 1987-88) A/C Magnetic Clutch Relay (1986) Radiator Cooling Fan (1st Stage)
  1. 1 - Blank (1984 5000S) 15 Amp (1985 5000S) Foglights
  2. 2 - 15 Amp (1984 5000S) Emergency Flasher, Turn Signals 15 Amp (1985 5000S) Emergency Flasher
  3. 3 - 25 Amp (1984 5000S) Horn, Cigarette Lighter, Brakelights, Clock 25 Amp (1985 5000S) Horn, Stoplights
  4. 4 - 15 Amp (1984 5000S) Luggage Compartment Light 15 Amp (1985 5000S) Luggage Compartment, Interior & Vanity Mirror Lights, Clock, Socket, Radio, Cigarette Lighter
  5. 5 - Blank
  6. 6 - 5 Amp Right Side Marker Light
  7. 7 - 5 Amp Left Side Marker Light
  8. 8 - 10 Amp (1984 5000S) Right High Beam Headlight
  9. 9 - 10 Amp Left High Beam Headlight
  10. 10 - 10 Amp Right Low Beam Headlight
  11. 11 - 10 Amp Left Low Beam Headlight
  12. 12 - 15 Amp (1984 5000S) Instrument Panel, Trip Computer, Back-Up & Auto-Check Lights 5 Amp (1985 5000S) Combination Instrument, Back-Up & Turn Signal Lights
  13. 13 - 15 Amp Fuel Pump
  14. 14 - 15 Amp (1984 5000S) License Plate & Engine Compartment Lights 5 Amp (1985 5000S) License Plate Light
  15. 15 - 15 Amp (1984 5000S) Windshield Wash/Wipe 25 Amp (1985 5000S) Windshield Wipers
  16. 16 - 30 Amp Rear Window Defogger
  17. 17 - 30 Amp (1984 5000S) Fresh Air Fan 30 Amp (1985 5000S) Heater Control Illumination, A/C, Glove Compartment Light
  18. 18 - 30 Amp (1984 5000S) 25 Amp (1985 5000S) Rear Window Wiper
  19. 19 - 10 Amp Central Locking System, Power Mirrors
  20. 20 - 30 Amp (1984 5000S) Seat Heater 20 Amp (1985 5000S) Seat Heater
  21. 21 - 25 Amp Rear Cigarette Lighter
  22. 22 - Blank
  23. 23 - 30 Amp Seat Memory (Power Seat Adjustment)
  24. 24 - 30 Amp (1984 5000S) Sun Roof 10 Amp (1985 5000S) CIS-E Power Supply
  25. 25 - Blank
  26. 26 - Blank
  27. 27 - Blank
  28. 28 - Blank
  29. 29 - Spare Fuses
  30. 30 - Blank
  31. 31 - Relay Radiator Cooling Fan (2nd Stage)
  32. 32 - Blank
  33. 33 - Blank
  34. 34 - Relay Load Reduction
  35. 35 - Blank (1984 5000S) Relay (1985 5000S) Reading Lights
  36. 36 - Relay Horn
  37. 37 - Relay (1984 5000S) Automatic Transmission, Starter Lockout Relay (1985 5000S) Automatic Transmission
  38. 38 - Relay Wash/Wipe Interval
  39. 39 - Relay Fuel Pump
  40. 40 - Relay (1984 5000S) Radiator Cooling Fan (1st Stage) Relay (1985 5000S) Air Conditioner

Scheme 7

Scheme 7: FUSE PANEL ID (1987-88 5000CS TURBO & TURBO QUATTRO)
Scheme 7: FUSE PANEL ID (1987-88 5000CS TURBO & TURBO QUATTRO)
  1. 1 - Blank
  2. 2 - 15 Amp Emergency Flasher
  3. 3 - 25 Amp Horn, Stoplights
  4. 4 - 15 Amp Clock, Luggage Compartment Light, Interior & Vanity Mirror Lights, Board Computer, Front Cigarette Lighter, radio, readings lites.
  5. 5 - Blank
  6. 6 - 5 Amp Right Side Marker Light
  7. 7 - 5 Amp Left Side Marker Light
  8. 8 - 10 Amp Right High Beam, High Beam Indicator
  9. 9 - 10 Amp Left High Beam Headlight
  10. 10 - 10 Amp Right Low Beam Headlight
  11. 11 - 10 Amp Left Low Beam Headlight
  12. 12 - 5 Amp Combination Instrument, Back-Up, Turn Signal & Auto-Check Lights, Differential Locks
  13. 13 - 15 Amp Fuel Pump
  14. 14 - 5 Amp License Plate Light
  15. 15 - 25 Amp Windshield Wipers
  16. 16 - 30 Amp Rear Window Defogger
  17. 17 - 30 Amp Heater Control Illumination, A/C, Glove Compartment Light
  18. 18 - 25 Amp Rear Window Wiper
  19. 19 - 10 Amp Central Locking System, Electric Mirrors
  20. 20 - 20 Amp (1986-88 5000CS) Seat Heater
  21. 21 - 25 Amp Rear Cigarette Lighter
  22. 22 - Blank Diesel Only
  23. 23 - 30 Amp Power Seat, Control Unit, Memory
  24. 24 - 10 Amp CIS-E Power Supply
  25. 25 - Blank
  26. 26 - Blank
  27. 27 - Blank
  28. 28 - Blank
  29. 29 - Blank
  30. 30 - Relay Radiator Cooling Fan (2nd Stage)
  31. 31 - Blank
  32. 32 - Blank
  33. 33 - Relay Load Reduction
  34. 34 - Relay Radiator Cooling Fan (1st Stage)
  35. 35 - Relay Horn
  36. 36 - Relay Anti-Theft
  37. 37 - Relay Intermittent wiper relay
  38. 38 - Relay Fuel Pump
  39. 39 - Relay Air Conditioner

Scheme 8

Scheme 8: AUXILIARY RELAY IDENTIFICATION (1984 5000S)
Scheme 8: AUXILIARY RELAY IDENTIFICATION (1984 5000S)

Relay Identification

  1. 1 - Brake Pad Wear Indicator Relay
  2. 2 - Seat Heater Relay
  3. 3 - (Blank)
  4. 4 - A/C Clutch Cut-Out Relay (Full Throttle)
  5. 5 - Front Light Monitoring Unit
  6. 6 - Seat Belt Warning Chime
  7. 7 - Blank
  8. 8 - Blank
  9. 9 - Safety Cut-Out
  10. 10 - A/C Condenser Fan Relay (2 Stage)
  11. 11 - Idle Stabilizer Relay (11 & 12 Are One Relay)
  12. 12 - Idle Stabilizer Relay (11 & 12 Are One Relay)
  13. 13 - Power Windows & Seat Circuit Breaker
  14. 14 - Driver's Power Window Relay
  15. 15 - Blank
  16. 16 - Blank
  17. 17 - Starting Enrichment Relay
  18. 18 - Oxygen Sensor Power Supply Relay

Scheme 9

Scheme 9
Scheme 9
  1. 1 - Power Window Relay
  2. 2 - Power Window & Sun Roof Control Unit
  3. 3 - Chime Warning Relay
  4. 4 - A/C Clutch Control Relay
  5. 5 - Blank
  6. 6 - Front Light Monitoring Unit
  7. 7 - Idle Control
  8. 8 - Idle Control
  9. 9 - Idle Control
  10. 10 - Radiator Fan (High Speed)
  11. 11 - Blank
  12. 12 - Rear Defogger
  13. 13 - Seat Heater Control Unit (Passenger)
  14. 14 - Seat Heater Control Unit (Driver)
  15. 15 - Injector Cooling Fan
  16. 16 - Power Windows & Seat Circuit Breaker
  17. 17 - Blank
  18. 18 - Radio & Park Light Warning Buzzer
  19. 19 - Jumper Block, Terminal 15 (Black Adapter)
  20. 20 - Jumper Block, Terminal 30 (Red Adapter)
  21. 21 - Switch Illumination Relay (Red Adapter)
  22. 22 - Blank
  23. 23 - Control Relay, Dome Lights (Blue Adapter)
  24. 24 - Blank
  25. 25 - Jumper Block, Terminal 58 (Gray Adapter)
  26. 26 - Blank
  27. 27 - Blank
  28. 28 - Blank
  1. 1 - Power Window Relay
  2. 2 - Power Window & Sun Roof Control Unit
  3. 3 - Radio & Park Light Warning Buzzer
  4. 4 - A/C Clutch Control Relay
  5. 5 - ABS Combination Relay
  6. 6 - Front Light Monitoring Unit
  7. 7 - Idle Control
  8. 8 - Idle Control
  9. 9 - Idle Control
  10. 10 - Radiator Cooling Fan (3rd Stage)
  11. 11 - Blank
  12. 12 - Rear Defogger
  13. 13 - Seat Heater Control Unit (Passenger)
  14. 14 - Seat Heater Control Unit (Driver)
  15. 15 - Injector Cooling Fan
  16. 16 - Power Windows & Seat Circuit Breaker
  17. 17 - Radiator Cooling Fan Relay (After-Run)
  18. 18 - Radio & Park Light Warning Buzzer
  1. 1 - ABS Combination Relay
  2. 2 - Seat Belt, Parklight & Radio Warning Control Unit
  3. 3 - Illuminated Entry Module
  4. 4 - Cigarette Lighter Relay
  5. 5 - Blank
  6. 6 - Front Light Monitoring Unit
  7. 7 - Blank
  8. 8 - Blank
  9. 9 - Blank
  10. 10 - Power Window Control Unit
  11. 11 - Power Window Control Unit
  12. 12 - Radiator Cooling Fan (3rd Stage)
  13. 13 - Power Windows & Seat Circuit Breaker
  14. 14 - Rear Wiper/Washer Relay
  15. 15 - Blank
  16. 16 - Seat Heater Control Unit (Passenger)
  17. 17 - Seat Heater Control Unit (Driver)
  18. 18 - Radiator Cooling Fan Relay (After-Run)

Scheme 10

Scheme 10
Scheme 10
  1. 1 - Window & Sun Roof Control
  2. 2 - Blank
  3. 3 - Chime Warning Relay
  4. 4 - A/C Clutch Control Relay
  5. 5 - Blank
  6. 6 - Front Light Monitoring Unit
  7. 7 - Blank
  8. 8 - Idle Control
  9. 9 - Idle Control
  10. 10 - Radiator Fan (High Speed)
  11. 11 - Blank
  12. 12 - Rear Defogger
  13. 13 - Driver's Window Control Relay
  14. 14 - Blank
  15. 15 - Injector Cooling Fan
  16. 16 - Power Windows & Seat Circuit Breaker
  17. 17 - Heated Seat
  18. 18 - Blank
  19. 19 - Jumper Block, Terminal 15
  20. 20 - Jumper Block, Terminal 30
  21. 21 - Jumper Block, Terminal 58 (Park Lights)
  22. 22 - Center Console Lights Relay
  23. 23 - Dome Lights Control Relay
  1. 1 - Power Window Relay
  2. 2 - Power Window & Sun Roof Control Unit
  3. 3 - Chime Warning Relay
  4. 4 - A/C Clutch Control Relay
  5. 5 - Blank
  6. 6 - Front Light Monitoring Unit
  7. 7 - Idle Control
  8. 8 - Idle Control
  9. 9 - Idle Control
  10. 10 - Radiator Fan (High Speed)
  11. 11 - Blank
  12. 12 - Rear Defogger
  13. 13 - Seat Heater Control Unit (Passenger)
  14. 14 - Seat Heater Control Unit (Driver)
  15. 15 - Injector Cooling Fan
  16. 16 - Power Windows & Seat Circuit Breaker
  17. 17 - Blank
  18. 18 - Radio & Parklight Warning Buzzer
  19. 19 - Jumper Block, Terminal 15 (Black Adapter)
  20. 20 - Jumper Block, Terminal 30 (Red Adapter)
  21. 21 - Switch Illumination Relay (Red Adapter)
  22. 22 - Turbocharger Cooling Pump Control Unit (Brown Adapter)
  23. 23 - Dome Lights Control Relay (Blue Adapter)
  24. 24 - Blank
  25. 25 - Jumper Block, Terminal 58 (Gray Adapter)
  26. 26 - Blank
  27. 27 - Blank
  28. 28 - Blank
  1. 1 - ABS Combination Relay
  2. 2 - Blank
  3. 3 - Chime Warning Relay
  4. 4 - Power Window & Sun Roof Control Unit
  5. 5 - Power Window Relay
  6. 6 - Front Light Monitoring Unit
  7. 7 - Idle Control
  8. 8 - Idle Control
  9. 9 - Idle Control
  10. 10 - Radiator Cooling Fan (3rd Stage)
  11. 11 - Blank
  12. 12 - Rear Defogger
  13. 13 - Seat Heater Control Unit (Passenger)
  14. 14 - Seat Heater Control Unit (Driver)
  15. 15 - Injector Cooling Fan
  16. 16 - Power Windows & Seat Circuit Breaker
  17. 17 - Blank
  18. 18 - Radio & Parklight Warning Buzzer
  19. 19 - T35, Wire Distributor, Terminal 15
  20. 20 - T39, Wire Distributor, Terminal 30A
  21. 21 - T38, Wire Distributor, Terminal 54
  22. 22 - Turbocharger Cooling Pump Control Unit
  23. 23 - Interior Light Delay Control
  24. 24 - T40, Wire Distributor, Terminal 58D
  25. 25 - Jumper Block, Terminal 58 (Gray Adapter)
  26. 26 - Blank
  27. 27 - Blank
  28. 28 - Blank

Relay Identification (Not On Relay Panel)

  1. 29 - Instrument Panel Light Booster (Behind Auto-Check Main Control Unit)
  2. 30 - Instrument Panel Light Booster (Behind Auto-Check Main Control Unit)
  3. 31 - Blank (Behind Auto-Check Main Control Unit)
  4. 32 - Blank (Behind Auto-Check Main Control Unit)
  1. 1 - ABS Combination Relay
  2. 2 - Seat Belt Warning Relay
  3. 3 - Radiator Cooling Fan Relay
  4. 4 - Blank
  5. 5 - Blank
  6. 6 - Front Light Monitoring Unit
  7. 7 - Idle Control
  8. 8 - Idle Control
  9. 9 - Idle Control
  10. 10 - Radiator Cooling Fan (3rd Stage)
  11. 11 - Rear Wiper Relay (If Equipped)
  12. 12 - Blank
  13. 13 - Seat Heater Control Unit (Passenger)
  14. 14 - Seat Heater Control Unit (Driver)
  15. 15 - Injector Cooling Fan Relay
  16. 16 - Power Windows & Seat Circuit Breaker
  17. 17 - Blank
  18. 18 - Blank
  19. 19 - T35, Wire Distributor, Terminal 15
  20. 20 - T39, Wire Distributor, Terminal 30AC
  21. 21 - T38, Wire Distributor, Terminal 54
  22. 22 - T40, Wire Distributor, Terminal 58D
  23. 23 - Interior Light Delay Control
  24. 24 - Blank
  25. 25 - Blank
  26. 26 - Cigarette Lighter Relay
  27. 27 - Power Window Control Unit
  28. 28 - Power Window Control Unit
  1. 29 - Instrument Panel Light Booster (Behind Auto-Check Main Control Unit)
  2. 30 - Instrument Panel Light Booster (Behind Auto-Check Main Control Unit)
  3. 31 - Blank (Behind Auto-Check Main Control Unit)
  4. 32 - Blank (Behind Auto-Check Main Control Unit)
  5. 33 - Blank (Behind Auto-Check Main Control Unit)
  6. 34 - Blank (Behind Auto-Check Main Control Unit)

More articles — Maintenance
