1. Turn the map light switch OFF.
2. Open the sunglass holder, then remove the two screws (A).
3. Disconnect the 20P connector (B) from the roof console (C).
4. Inspect the connector and socket terminals to be sure they are all making good contact. If the terminals are bent, loose or corroded, repair them as necessary, and recheck the system. If the terminals look OK, go to step 5.
5. With the connector still disconnected, do the following input tests: If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, go to step 6. Cavity Wire Test condition Test: Desired result Possible cause if desired result is not obtained 5 PNK Disconnect driver's under-dash fuse/relay box connector P (20P) Check for continuity between terminal No. 5 and driver's under-dash fuse/relay box connector P (20P) terminal No. 4: There should be continuity. An open or high resistance in the wire 6 ORN Disconnect driver's under-dash fuse/relay box connector Q (20P) Check for continuity between terminal No. 6 and driver's under-dash fuse/relay box connector Q (20P) terminal No. 4: There should be continuity. An open or high resistance in the wire 8 BLK Disconnect the rear individual map light 10P connector Check for continuity between terminal No. 8 and the rear individual map lights 10P connector terminal No. 8: There should be continuity. An open in the wire 9 LT GRN Disconnect the rear individual map light 10P connector Check for continuity between terminal No. 9 and the rear individual map lights 10P connector terminal No. 9: There should be continuity. An open in the wire 2 RED Disconnect gauge control module connector A (32P) Check for continuity between terminal No. 2 and gauge control module connector A (32P) terminal No. 21: There should be continuity. An open or high resistance in the wire
6. Reconnect the connector to the roof console, and do the following input tests: If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, the roof console must be faulty; replace it. Cavity Wire Test condition Test: Desired result Possible cause if desired result is not obtained 3 LT BLU Under all conditions Measure the voltage to ground: There should be battery voltage. Blown No. 16 (7.5 A) fuse in the under-hood fuse/relay box An open or high resistance in the wire 1 GRY Combination light switch (PARKING LIGHT) ON Measure the voltage to ground: There should be battery voltage. Blown No. 6 (7.5 A) fuse in the passenger's under-dash fuse/relay box An open or high resistance in the wire 4 BLK In all ignition switch positions or all power modes Measure the voltage to ground: There should be less than 0.2 V. Poor ground (G402) An open or high resistance in the ground wire

Scheme 9

1. Carefully pry off the lens (A) with a small screwdriver.
2. Remove the two mounting bolts.
3. Disconnect the 10P connector (B) from the rear individual map light (C).
4. Inspect the connector and socket terminals to be sure they are all making good contact. If the terminals are bent, loose or corroded, repair them as necessary, and recheck the system. If the terminals look OK, go to step 5.
5. With the connector still disconnected, do the following input tests: If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, go to step 6. Cavity Wire Test condition Test: Desired result Possible cause if desired result is not obtained 5 PNK Disconnect driver's under-dash fuse/relay box connector P (20P) Check for continuity between terminal No. 5 and driver's under-dash fuse/relay box connector P (20P) terminal No. 4: There should be continuity. An open or high resistance in the wire 6 ORN Disconnect driver's under-dash fuse/relay box connector Q (20P) Check for continuity between terminal No. 6 and driver's under-dash fuse/relay box connector Q (20P) terminal No. 4: There should be continuity. An open or high resistance in the wire 8 BLK Disconnect the roof console 20P connector Check for continuity between terminal No. 8 and the roof console 20P connector terminal No. 8: There should be continuity. An open in the wire 9 LT GRN Disconnect the roof console 20P connector Check for continuity between terminal No. 9 and the roof console 20P connector terminal No. 9: There should be continuity. An open in the wire 2 RED Disconnect gauge control module connector A (32P) Check for continuity between terminal No. 2 and the gauge control module connector A (32P) terminal No. 21: There should be continuity. An open or high resistance in the wire
6. Reconnect the connector to the rear individual map light, and do the following input tests: If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, the rear individual map light must be faulty; replace it. Cavity Wire Test condition Test: Desired result Possible cause if desired result is not obtained 3 LT BLU Under all conditions Measure the voltage to ground: There should be battery voltage. Blown No. 16 (7.5 A) fuse in the under-hood fuse/relay box An open or high resistance in the wire 1 GRY Combination light switch (PARKING LIGHT) ON Measure the voltage to ground: There should be battery voltage. Blown No. 6 (7.5 A) fuse in the passenger's under-dash fuse/relay box An open or high resistance in the wire 4 BLK In all ignition switch positions or all power modes Measure the voltage to ground: There should be less than 0.2 V. Poor ground(G603) An open or high resistance in the ground wire

Scheme 10

Scheme 11

1. Open the tailgate.
2. Turn the tailgate light switch OFF.
3. Carefully pry the lens (A) off with a small screwdriver. Tailgate Light: 8 W
4. Remove the two screws, then remove the tailgate light (B).
5. Disconnect the 3P connector (C) from the light.
6. Check for continuity between the terminals in each switch position according to the table.
7. If the continuity is not as specified, check the bulb (D). If the bulb is OK, replace the ceiling light.
8. Install the light in the reverse order of removal.

Scheme 12

1. Carefully pry off the lens (A) with a small screwdriver. Courtesy Light: 3.4 W
2. Carefully remove the housing (B) from the door panel by prying at the lift point (C), then disconnect the 2P connector (D).
3. Remove the bulb (E) from the socket.
4. Install the parts in the reverse order of removal. Note the direction of the lens lock tabs (F).

Scheme 13

1. Remove the glove box stops and damper (see «GLOVE BOX DAMPER REPLACEMENT»(/acura/zdx/i-2009-2013/remont/gauges-instrument-panels/#dashboard__glove-box-damper-replacement) ).
2. Carefully pry the glove box light out of the glove box housing.
3. Twist the socket (A) to remove it from the glove box light (B). Glove Box Light 1.4 W
4. Remove the bulb (C) from the socket.
5. Install the light in the reverse order of removal.

Scheme 14

1. Open the center console lid.
2. Carefully pry the console box light out of the center console.
3. Twist the socket (A) to remove it from the console box light (B). Console Box Light: 1.4 W
4. Remove the bulb (C) from the socket.
5. Install the light in the reverse order of removal.

Scheme 15

Scheme 16

1. Remove the sunvisor (see «SUNVISOR REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/exteriorinterior-trim/#interior-trim__sunvisor-removalinstallation) ).
2. Disconnect the 2P connector (A) from the sunvisor (B). Vanity Mirror Light: 1.4 W x 2
3. Check for continuity between the terminals in each vanity mirror cover (C) position according to the table.
4. If the continuity is not as specified, check the bulbs (D). If the bulbs are OK, the vanity mirror light is faulty; replace the sunvisor (see «SUNVISOR REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/exteriorinterior-trim/#interior-trim__sunvisor-removalinstallation) ).
5. Install the parts in the reverse order of removal.

Scheme 17

1. Remove the driver's dashboard undercover (see «DRIVER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/gauges-instrument-panels/#dashboard) ).
2. Remove the footwell light (A) from the driver's dashboard undercover. Footwell Light: LED
3. Install the light in the reverse order of removal.

Scheme 18

1. Remove the passenger's dashboard undercover (see «GLOVE BOX DAMPER REPLACEMENT»(/acura/zdx/i-2009-2013/remont/gauges-instrument-panels/#dashboard__glove-box-damper-replacement) ).
2. Remove the footwell light (A) from the passenger's dashboard undercover. Footwell Light: LED
3. Install the light in the reverse order of removal.

Scheme 19

1. Remove the door panel: Front door panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/exterior-body-panels/#doors__front-door-panel-removalinstallation) ) Rear door panel (see «REAR DOOR PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/exterior-body-panels/#doors__rear-door-panel-removalinstallation) )
2. Disconnect the door inner handle light 2P connector (A).
3. Remove the screw and the door inner handle light (B). NOTE: The illustration shows the driver's door. Door Inner Handle Light: LED
4. Install the light in the reverse order of removal.
