Scheme 60
Special Tools Required
KTC Trim Tool Set SOJATP2014*
*Available through the Acura Tool and Equipment Program; call 888-424-6857
Note. Take care not to scratch the dashboard or the related parts. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.
Scheme 61
- Pry up the edge of the driver's outer dashboard trim (A) to detach the clips, and remove the trim.
- Install the trim in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips into place securely.
Special Tools Required
KTC Trim Tool Set SOJATP2014*
*Available through the Acura Tool and Equipment Program; call 888-424-6857
'10-11 Models
Note. Take care not to scratch the dashboard or the related parts. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.
Scheme 62
- Remove the driver's inner dashboard trim (A). Pry up the edge of the trim to detach the clips (B, C). For some models: Disconnect the engine start/stop switch connector (D) and the remote slot connector (E).
- Install the trim in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Make sure each connector is plugged in properly. Push the clips into place securely.
'12 Model
Note. Take care not to scratch the dashboard or the related parts. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.
Scheme 63
Scheme 64
- Remove the driver's inner dashboard trim (A) and the driver's leather trim (B) as an assembly. Pry up the edge of the trim to detach the clips (C, D, E, F). For some models: Disconnect the engine start/stop switch connector (G) and the remote slot connector (H).
- Remove the screws, then remove the driver's inner dashboard trim (A) from the driver's leather trim (B).
- Install the trim in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Make sure each connector is plugged in properly. Push the clips into place securely.
Instrument Fascia Removal/Installation
Special Tools Required
KTC Trim Tool Set SOJATP2014*
*Available through the Acura Tool and Equipment Program; call 888-424-6857
Note. Take care not to scratch the dashboard or the related parts. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.
Scheme 65
Scheme 66
- Remove these items: Driver's outer dashboard trim (see «DRIVER'S OUTER DASHBOARD TRIM REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/gauges-instrument-panels/#dashboard) ) Driver's inner dashboard trim (see «DRIVER'S INNER DASHBOARD TRIM REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/gauges-instrument-panels/#dashboard) )
- Adjust the steering column to the full tilt down position, and to the full telescopic out position.
- Detach the clips and release the hooks (A) fastening the instrument fascia (B) from the upper column cover (C). NOTE: Make sure you do not damage the fabric.
- Gently pull out the bottom to detach the clips, and disconnect the dashlights brightness controller switch connector (A), then remove the instrument fascia (B).
- Install the instrument fascia in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Make sure the connector is plugged in properly. Push the clips and the hooks into place securely.
Special Tools Required
KTC Trim Tool Set SOJATP2014*
*Available through the Acura Tool and Equipment Program; call 888-424-6857
Note. Take care not to scratch the dashboard or the related parts. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.
Scheme 67
- Remove the driver's dashboard undercover (A). Turn the lock knob (B) 90 °. Gently pull down the rear edge to detach the clips. Disconnect the footwell light connector (C) and the power mirror control unit connector (D), and detach the harness clips (E). Pull the undercover rearward to release the pin (F) from the holder (G).
- Install the undercover in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Make sure each connector is plugged in properly. Make sure the pin of the undercover is installed securely to the holder. Push the clips into place securely.
Special Tools Required
KTC Trim Tool Set SOJATP2014*
*Available through the Acura Tool and Equipment Program; call 888-424-6857
Driver's Side Vent
Note. Take care not to scratch the dashboard or the related parts. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.
Scheme 68
- Remove the driver's outer dashboard trim (see «DRIVER'S OUTER DASHBOARD TRIM REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/gauges-instrument-panels/#dashboard) ).
- Pry up the bottom edge of the side vent (A) to detach the clips, then remove the side vent.
- Install the side vent in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clip into place securely.
Passenger's Side Vent
Note. Take care not to scratch the dashboard.
Scheme 69
- Remove the passenger's dashboard trim panel (see «PASSENGER'S DASHBOARD TRIM PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/gauges-instrument-panels/#dashboard) ).
- Remove the screw, and pry up the bottom edge of the side vent (A) to detach the clips, then remove the side vent.
- Install the side vent in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips into place securely.
Center Vent
Note. Take care not to scratch the dashboard or the related parts.
Scheme 70
- Remove the audio and HVAC switch panel (without navigation) (see «AUDIO AND HVAC SWITCH PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ) or the audio-navigation and HVAC switch panel (with navigation) (see «AUDIO-NAVIGATION AND HVAC SWITCH PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ).
- From back of the switch panel, remove the screws, and release the hooks (A), then remove the center vents (B).
- Install the center vents in the reverse order of removal, and push the hooks into place securely.
Special Tools Required
KTC Trim Tool Set SOJATP2014*
*Available through the Acura Tool and Equipment Program; call 888-424-6857
Note. Take care not to scratch the dashboard or the related parts. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.
Scheme 71
- Remove the passenger's dashboard trim (see «PASSENGER'S DASHBOARD TRIM REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/gauges-instrument-panels/#dashboard) ).
- Pry up the bottom edge of the passenger's dashboard trim panel (A) to detach the clips, and remove the trim panel.
- Install the trim panel in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips into place securely.
Special Tools Required
KTC Trim Tool Set SOJATP2014*
*Available through the Acura Tool and Equipment Program; call 888-424-6857
Note. Take care not to scratch the dashboard or the related parts. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.
Scheme 72
- Pry up the edge of the passenger's dashboard trim (A) to detach the clips, and remove the trim.
- Install the trim in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips into place securely.
Note. Take care not to scratch the dashboard or the related parts. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.
Scheme 73
Scheme 74
- Pry up the edge of the passenger's dashboard trim (A) and the passenger's leather trim (B) to detach the clips (C, D, E), and remove them as an assembly.
- Remove the screws, then remove the passenger's dashboard trim (A) from the passenger's leather trim (B).
- Install the trim in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips into place securely.
Glove Box Removal/Installation
SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.
Note. Take care not to scratch the dashboard or the related parts.
Scheme 75
Scheme 76
Scheme 77
- Remove the passenger's dashboard trim (see «PASSENGER'S DASHBOARD TRIM REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/gauges-instrument-panels/#dashboard) ).
- Remove the passenger's dashboard side panel (A). Open the front door. Gently pry the notch (B) of the panel with the appropriate trim tool to detach the clips.
- Remove the bolts (A) and the screws (B).
- Remove the glove box (A). Release the hook (B) and pull the glove box by hand to detach the clip. While holding the glove box, disconnect the glove box light bulb (C) and the keyless access system mode switch connector (D) (if equipped).
- Install the glove box in the reverse order of removal, and note these items: If the clip is damaged or stress-whitened, replace it with a new one. Make sure each connector is plugged in properly. Push the clip and the hook into place securely.
Glove Box Lock Cylinder Replacement
Note. Take care not to scratch the glove box.
Scheme 78
Scheme 79
Scheme 80
- Remove the glove box (see «GLOVE BOX REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/gauges-instrument-panels/#dashboard__glove-box-removalinstallation) ).
- While lifting the glove box handle (A), pull out one end of the retainer (B) with a hook-shaped tool of its slot. NOTE: Do not remove the retainer entirely. Leave one end of the retainer in its original position when removing the lock cylinder.
- Remove the glove box lock cylinder (A).
- Reinstall the end of the retainer (A) in its slot, then reinstall the lock cylinder (B). Push the cylinder into place securely until the retainer snaps into place.
Glove Box Damper Replacement
Note. Take care not to scratch the glove box.
Scheme 81
- Remove the glove box (see «GLOVE BOX REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/gauges-instrument-panels/#dashboard__glove-box-removalinstallation) ).
- Release the glove box damper string (A). Remove the screws, then remove glove box damper (B).
- Install the damper in the reverse order of removal.
Note. Take care not to scratch the dashboard or the related parts.
Scheme 82
- Remove the passenger's dashboard undercover (A). Gently pull down the rear edge to detach the clips. Disconnect the footwell light connector (B). Pull the undercover away to release the pins (C) from the holders (D).
- Install the undercover in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Make sure the connector is plugged in properly. Make sure the pins of the undercover are installed securely to the holders. Push the clips into place securely.
Column Cover Removal/Installation
Note. Put on gloves to protect your hands. Take care not to scratch the dashboard or the related parts. Do not pry the column cover surface with any tools.
Scheme 83
Scheme 84
Scheme 85
- Turn the steering wheel to access the mounting screws, then remove the screws from front side of the column cover (A).
- Detach the clips and release the hooks fastening the instrument fascia from the upper column cover (see step 3 ).
- Insert a flat-tip of a small screwdriver or similar tool into the holes (A) in the lower column cover (B). Gently push to release the hooks (C), and pull up the upper column cover (D) to remove it.
- Remove the screws (A, B), and disconnect the power tilt/telescopic steering switch connector (C), then remove the lower column cover (D).
- Install the upper and the lower column covers in the reverse order of removal and note these items: Make sure the wire harnesses are not pinched before tightening the screws. Make sure the connector is plugged in properly. Push the hooks into place securely.
Special Tools Required
KTC Trim Tool Set SOJATP2014*
*Available through the Acura Tool and Equipment Program; call 888-424-6857
SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.
Note. Have an assistant help you when removing and installing the dashboard. Put on gloves to protect your hands. Take care not to scratch the dashboard, the body, or the related parts. Take care not to bend the brackets. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.
Scheme 86
Scheme 87
Scheme 88
Scheme 89
Scheme 90
- Do the battery terminal disconnection procedure (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(/acura/zdx/i-2009-2013/remont/body-electrical/#battery) ), then wait at least 3 minutes before beginning work.
- Remove these items from the dashboard: A-pillar trims, both sides (see «TRIM REMOVAL/INSTALLATION - PILLAR AREAS»(/acura/zdx/i-2009-2013/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-pillar-areas) ) Driver's outer dashboard trim (see «DRIVER'S OUTER DASHBOARD TRIM REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/gauges-instrument-panels/#dashboard) ) Driver's inner dashboard trim (see «DRIVER'S INNER DASHBOARD TRIM REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/gauges-instrument-panels/#dashboard) ) Instrument fascia (see «INSTRUMENT FASCIA REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/gauges-instrument-panels/#dashboard__instrument-fascia-removalinstallation) ) Driver's dashboard undercover (see «DRIVER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/gauges-instrument-panels/#dashboard) ) Steering column (see «STEERING COLUMN REMOVAL AND INSTALLATION»(/acura/zdx/i-2009-2013/remont/manual-power-steering/#power-steering-system__steering-column-removal-and-installation) ) Passenger's dashboard trim (see «PASSENGER'S DASHBOARD TRIM REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/gauges-instrument-panels/#dashboard) ) Passenger's dashboard trim panel (see «PASSENGER'S DASHBOARD TRIM PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/gauges-instrument-panels/#dashboard) ) Dashboard side vents (see «DASHBOARD VENT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/gauges-instrument-panels/#dashboard) ) Glove box (see «GLOVE BOX REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/gauges-instrument-panels/#dashboard__glove-box-removalinstallation) ) Passenger's dashboard undercover (see «PASSENGER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/gauges-instrument-panels/#dashboard) ) Center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/gauges-instrument-panels/#consoles__center-console-removalinstallation) ) Gauge control module (see «GAUGE CONTROL MODULE REPLACEMENT»(/acura/zdx/i-2009-2013/remont/gauges-instrument-panels/#gauges__gauge-control-module-replacement) ) Center speaker (see «FRONT CENTER SPEAKER»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ) Without navigation: Audio and HVAC switch panel (see «AUDIO AND HVAC SWITCH PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ) With navigation: Audio-navigation and HVAC switch panel (see «AUDIO-NAVIGATION AND HVAC SWITCH PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ) Without navigation: Audio display unit (see «AUDIO AND HVAC SWITCH PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ) With navigation: Navigation display unit (see «NAVIGATION DISPLAY UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__navigation-display-unit-removalinstallation) ) Without navigation: Audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ) With navigation: Audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ) With navigation: GPS antenna (see «GPS ANTENNA REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__gps-antenna-removalinstallation) ) For some models: Keyless access control unit (see «CONTROL UNIT INPUT TEST»(/acura/zdx/i-2009-2013/remont/door-locks-anti-theft-systems/#keyless-access-system) ) Front passenger's airbag (see «FRONT PASSENGER'S AIRBAG REPLACEMENT»(/acura/zdx/i-2009-2013/remont/airbag/#srs-supplemental-restraint-system__front-passengers-airbag-replacement) ) Humidity/In-car temperature sensor (see «HUMIDITY/IN-CAR TEMPERATURE SENSOR REPLACEMENT»(/acura/zdx/i-2009-2013/remont/automatic-hvac-system/#climate-control) ) Driver's Side
- Detach the harness clip (A) from between the A-pillar and the dashboard. Middle Area
- From the front of the dashboard, release the harness clip (A). Passenger's Side
- Disconnect the roof wire harness connector (A) and the antenna read connector (B), and detach the harness clip (C).
- Remove the bolts (A) and screws (B) securing the dashboard (C).
- Lift up on the dashboard (A) to release it from the guide pins (B), then carefully remove the dashboard through the front door opening. NOTE: Do not rest the dashboard on its lower center cover opening, or it may be damaged. Lay it on its front or back.
- Install the dashboard in the reverse order of removal, and note these items: Make sure the dashboard fits onto the guide pins correctly. Make sure the dashboard wire harness is not pinched before tightening the bolts. Make sure each connector is plugged in properly. Do the battery terminal reconnection procedure (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(/acura/zdx/i-2009-2013/remont/body-electrical/#battery) ). Check for any DTCs that may have been set during repairs, and clear them.
Special Tools Required
KTC Trim Tool Set SOJATP2014*
*Available through the Acura Tool and Equipment Program; call 888-424-6857
SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.
Note. Have an assistant help you when removing and installing the dashboard. Put on gloves to protect your hands. Take care not to scratch the dashboard, the body, or the related parts. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.
Scheme 91
Scheme 92
Scheme 93
Scheme 94
Scheme 95
Scheme 96
Scheme 97
Scheme 98
Scheme 99
Scheme 100
Scheme 101
Scheme 102
Scheme 103
Scheme 104
- Do the battery terminal disconnection procedure (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(/acura/zdx/i-2009-2013/remont/body-electrical/#battery) ), then wait at least 3 minutes before beginning work.
- Remove these items from the dashboard: A-pillar trims, both sides (see «TRIM REMOVAL/INSTALLATION - PILLAR AREAS»(/acura/zdx/i-2009-2013/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-pillar-areas) ) Driver's dashboard undercover (see «DRIVER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/gauges-instrument-panels/#dashboard) ) Kick panels, both sides (see «TRIM REMOVAL/INSTALLATION - DOOR AREAS»(/acura/zdx/i-2009-2013/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-door-areas) ) Instrument fascia (see «INSTRUMENT FASCIA REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/gauges-instrument-panels/#dashboard__instrument-fascia-removalinstallation) ) Steering column (see «STEERING COLUMN REMOVAL AND INSTALLATION»(/acura/zdx/i-2009-2013/remont/manual-power-steering/#power-steering-system__steering-column-removal-and-installation) ) Center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/gauges-instrument-panels/#consoles__center-console-removalinstallation) ) Passenger's dashboard undercover (see «PASSENGER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/gauges-instrument-panels/#dashboard) ) A-pillar corner trims, both sides (see «A-PILLAR CORNER TRIM REPLACEMENT»(/acura/zdx/i-2009-2013/remont/exteriorinterior-trim/#exterior-trim__a-pillar-corner-trim-replacement) ) Driver's Side
- Disconnect the roof wire harness connector(s) (A).
- Disconnect the left side wire harness connectors (A), the left engine compartment wire harness connectors (B), and the driver's door wire harness connector (C) from the driver's under-dash fuse/relay box (D).
- From under the dash, remove the center frame mounting bolt. Middle Area (Driver's Side)
- Disconnect the console subharness connector(s) (A) and the LF ANT connector (B), and detach the wire harness clips (C).
- Disconnect SRS unit connector A, the A/C wire harness connector (B), and the yaw rate-acceleration sensor connector (C). Middle Area (Passenger's Side)
- Disconnect the shift lever connector (A) and the active noise cancellation unit connector (B). Detach the harness clips (C) and the clip.
- For some models: Disconnect RF unit 1 connector (D) and E-pretensioner unit connectors (E).
- Remove the shift lever bracket (see «SHIFT LEVER DISASSEMBLY/REASSEMBLY»(/acura/zdx/i-2009-2013/remont/automatic-trans/#automatic-transmission__shift-lever-disassemblyreassembly) ). Passenger's Side
- Disconnect the roof wire harness connector (A) and the antenna read connector (B), detach the harness clip (C).
- Disconnect the passenger's door wire harness connectors (A), the floor wire harness connectors (B), the right engine compartment wire harness connectors (C), and the audio amplifier connectors (D). Disconnect the dashboard wire harness connector (E) and the audio wire harness connectors (F) from the passenger's under-dash fuse/relay box (G). Detach the harness clip (H).
- Remove the center joint bracket mounting bolts.
- Remove the special bolts (A) from outside the passenger's door. Loosen the special bolts until they disengage from the threads on the hanger beam side bracket (B), and engage the inside threads of the collar bolts (C). The thread lock on the special bolts makes the special bolts and the collar bolts turn together. Continue loosening the special bolts to turn the collar bolts into the fixed space adjusters (D) until the collar bolts engage the stops (E). This creates a gap (F) between the collar bolts and the body. Loosen the special bolts to disengage them from the collar bolts, then remove them.
- Check that the collar bolts (A) are seated in the fixed space adjusters (B). Insert an 8 mm hex wrench in the collar bolt. Gently turn the wrench counterclockwise. If the wrench turns easily, continue turning until the collar bolt seats and engages the stop (C). If the wrench does not turn easily, the collar bolt is seated. NOTE: If either collar bolt was not seated, replace the special bolts.
- From outside the driver's door, remove the driver's side bracket bolts (A, B).
- Lift up on the dashboard (A) to release it from the guide pins (B) on the body. Carefully remove the dashboard through the front door opening. Take care not to scratch the body with the collar bolts on the passenger's side. NOTE: Do not rest the dashboard on its lower center cover opening, or it may be damaged. Lay it on its front or back.
- Install the dashboard in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Make sure the dashboard fits onto the guide pins correctly. Before tightening the bolts, make sure the wire harnesses are not pinched. Make sure each connector is plugged in properly. Push the clips and the hooks into place securely. Make sure the collar bolts (A) turn easily by hand in the fixed space adjusters (B). Tighten the collar bolts by hand until they engage the stops (C) before reinstalling the dashboard. Before reinstalling the dashboard, screw the special bolts (D) into the collar bolts, and check that they turn together. If they do not turn together, replace the special bolts. After setting the dashboard in the body, reinstall all of the mounting bolts but do not tighten them. First tighten the driver's side bracket bolts to the specified torque. Next, tighten the special bolts. As you tighten the bolts, the collar bolts screw out of the fixed space adjuster until they contact the body. Continue tightening the special bolts to the specified torque. Apply medium strength liquid thread lock to the bolts securing the center joint bracket and the dashboard before reinstallation. After tightening the dashboard mounting bolts, tighten the center joint bracket mounting bolts, and then tighten the center frame mounting bolts. Tighten all remaining mounting bolts to the specified torque. If necessary, adjust the shift cable (see «SHIFT CABLE ADJUSTMENT»(/acura/zdx/i-2009-2013/remont/automatic-trans/#automatic-transmission) ). Do the battery terminal reconnection procedure (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(/acura/zdx/i-2009-2013/remont/body-electrical/#battery) ). Check for any DTCs that may have been set during repairs, and clear them. Special bolt tightening on passenger's side
