Front and Rear Suspension (v6) Acura TSX II

Scheme 1

Scheme 2

Scheme 3

Wheel Alignment

The suspension can be adjusted for front and rear toe.

Pre-Alignment Checks

For proper inspection and adjustment of the wheel alignment, do these checks

Scheme 4

1. Release the parking brake to avoid an incorrect measurement.
2. Make sure the suspension is not modified.
3. Make sure the fuel tank is full, and that the spare tire, the jack, and the tools are in place on the vehicle.
4. Check the tire size and tire pressure. Tire size: Front/Rear: P235/45R18 94V Tire pressure (at cold): Front/Rear: 230 kPa (2.3 kgf/cm 2 , 33 psi)
5. Check the runout of the wheels and tires (see «WHEEL BEARING END PLAY INSPECTION»(/acura/tsx/ii-2008-2014/remont/wheel-alignment/#front-and-rear-suspension-v6) ).
6. Check the suspension ball joints (Raise and support the vehicle (see «LIFT AND SUPPORT POINTS»(/acura/tsx/ii-2008-2014/remont/oem-general-information/#general-information-v6__lift-and-support-points) ). Hold a tire with your hands, and move it up and down and right and left to check for movement).
7. Before doing alignment inspections, be sure to remove all extra weight from the vehicle, and no one should be inside the vehicle (driver or passengers).
8. Lower the vehicle to the ground. Bounce the vehicle up and down several times to stabilize the suspension.
9. Check that the steering column is set at the center tilt position and the center telescopic position.

Caster Inspection

Use commercially available computerized four wheel alignment equipment to measure wheel alignment (caster, camber, toe, and turning angle). Follow the equipment manufacturer's instructions.

1. Check the caster angle. Caster angle: 3°52' +10 -50 ' (Maximum difference between the right and left side: 0 ° 30') If the measurement is within specifications, measure the camber angle. If the measurement is not within specifications, check for bent or damaged suspension components.

Camber Inspection

Use commercially available computerized four wheel alignment equipment to measure wheel alignment (caster, camber, toe, and turning angle). Follow the equipment manufacturer's instructions.

1. Check the camber angle. Camber angle: Front: -0 ° 03' ±30' Rear: -1° 12' ±30' (Maximum difference between the right and left side: 0 ° 30') If the measurement is within specifications, measure the toe-in. If the measurement is not within specifications, check for bent or damaged suspension components.

Rear Toe Inspection/Adjustment

Use commercially available computerized four wheel alignment equipment to measure wheel alignment (caster, camber, toe, and turning angle). Follow the equipment manufacturer's instructions.

Scheme 5

1. Release the parking brake to avoid an incorrect measurement.
2. Check the toe. Rear toe-in: 2±2 mm (0.08±0.08 in) If adjustment is required, go to step 3. If no adjustment is required, go to front toe inspection/adjustment.
3. Hold the adjusting bolt (A) on the rear control arm (B), and loosen the self-locking nut (C).
4. Replace the self-locking nut with a new one, and lightly tighten it. NOTE: Always use a new self-locking nut whenever it has been tightened to the specified torque.
5. Adjust the rear toe by turning the adjusting bolt until the toe is correct.
6. While holding the adjusting bolt, tighten the self-locking nut to the specified torque.

Front Toe Inspection/Adjustment

Use commercially available computerized four wheel alignment equipment to measure wheel alignment (caster, camber, toe, and turning angle). Follow the equipment manufacturer's instructions.

Scheme 6

1. Set the steering column to the middle tilt position and telescopic positions. Center the steering wheel spokes, and install a steering wheel holder tool.
2. Check the toe with the wheels pointed straight ahead. Front toe-in: 0±2 mm (0±0.08 in) If adjustment is required, go to step 3. If no adjustment is required, remove the alignment equipment.
3. Loosen the tie-rod end locknuts (A) while holding the flat surface sections (B) of the tie-rod end with a wrench, and turn both tie-rods (C) until the front toe is within specifications.
4. After adjusting, tighten the tie-rod end locknuts to the specified torque. Reposition the rack-end boot if it is twisted or displaced.

Turning Angle Inspection

Use commercially available computerized four wheel alignment equipment to measure wheel alignment (caster, camber, toe, and turning angle). Follow the equipment manufacturer's instructions.

Scheme 7

1. Turn the wheel right and left while applying the brake, and measure the turning angle of both wheels. Turning angle: Inward: 36 °59' ±2° Outward (reference): 30 ° 23'
2. If the measurement is not within the specifications, even up both sides of the tie-rod threaded section length while adjusting the front toe. If it is correct, but the turning angle is not within the specifications, check for bent or damaged suspension components.

Scheme 8

Scheme 9

1. Raise and support the vehicle (see «LIFT AND SUPPORT POINTS»(/acura/tsx/ii-2008-2014/remont/oem-general-information/#general-information-v6__lift-and-support-points) ).
2. Remove the wheels.
3. Install suitable flat washers (A) and the wheel nuts (B). Tighten the nuts to the specified torque to hold the brake disc securely against the hub. Front Rear
4. Attach the dial gauge. Place the dial gauge against the hub flange.
5. Measure the bearing end play while moving the brake disc inward and outward. Wheel bearing end play: Front/Rear: 0-0.05 mm (0-0.0020 in)
6. If the bearing end play measurement is more than the standard, replace the wheel bearing or the hub bearing unit.

Scheme 10

Scheme 11

1. Raise and support the vehicle (see «LIFT AND SUPPORT POINTS»(/acura/tsx/ii-2008-2014/remont/oem-general-information/#general-information-v6__lift-and-support-points) ).
2. Check for a bent or deformed wheel.
3. Set up the dial gauge as shown, and measure the axial runout by turning the wheel. Front and rear wheel axial runout: Standard: 0-0.7 mm (0-0.028 in) Service limit: 2.0 mm (0.079 in)
4. Reset the dial gauge to the position shown, and measure the radial runout. Front and rear wheel radial runout: Standard: 0-0.7 mm (0-0.028 in) Service limit: 1.5 mm (0.059 in)
5. If the wheel runout is not within the specification, check the wheel bearing end play (see «WHEEL BEARING END PLAY INSPECTION»(/acura/tsx/ii-2008-2014/remont/wheel-alignment/#front-and-rear-suspension-v6) ), and make sure the mating surfaces between the brake disc and the inside of the wheel are clean.
6. If the bearing end play is within the specification but the wheel runout is more than the service limit, replace the wheel.

Wheel Bolt Replacement

Special Tools Required

Ball Joint Remover, 28 mm 07MAC-SL0A202

Note. Do not use a hammer or impact tools (pneumatic or electric) to remove and install the wheel bolts. Be careful not to damage the threads of the wheel bolts.

Scheme 12

1. Remove the front hub (see «KNUCKLE/HUB REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/suspension-front/#front-suspension-v6) ).
2. Separate the wheel bolt (A) from the hub (B) using a hydraulic press. Support the hub with hydraulic press attachments (C) or equivalent tools. NOTE: Before installing the new wheel bolt, clean the mating surfaces on the bolt and the hub.
3. Insert the new wheel bolt into the hub while aligning the splined surfaces on the hub hole with the wheel bolt. NOTE: Degrease the area around the wheel bolt. Make sure the wheel bolt is installed vertically to the hub disc surface.
4. Install the wheel bolt using a hydraulic press until the wheel bolt shoulder is fully seated.
5. Install the front hub (see «KNUCKLE/HUB REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/suspension-front/#front-suspension-v6) ). NOTE: If you cannot tighten the wheel nut to the specified torque when installing the wheel, replace the front hub as an assembly.

Scheme 13

Scheme 14

1. Raise and support the vehicle (see «LIFT AND SUPPORT POINTS»(/acura/tsx/ii-2008-2014/remont/oem-general-information/#general-information-v6__lift-and-support-points) ).
2. Remove the rear brake disc (see «RUNOUT»(/acura/tsx/ii-2008-2014/remont/mechanical-hydraulic/#conventional-brake-components-v6) ).
3. Separate the wheel bolt (A) from the hub (B) using the ball joint remover (C), and keep the jaw (D) of the ball joint remover vertically against the wheel bolt (see «BALL JOINT REMOVAL»(/acura/tsx/ii-2008-2014/remont/wheel-alignment/#front-and-rear-suspension-v6__ball-joint-removal) ). NOTE: If the angle of the remover against the wheel bolt is not vertical, readjust the ball joint remover by turning the head (E) of the adjusting bolt (F). Before installing the new wheel bolt, clean the mating surfaces on the bolt and the hub.
4. Insert the new wheel bolt (A) into the hub (B) while aligning the splined surfaces (C) on the hub hole with the wheel bolt. Adjust the measurement (D) with the washers (P/N 94101-12800 or equivalent) (E), then install a nut (P/N 90304-SC2-000 or equivalent) (F) hand-tight. NOTE: Degrease the area around the wheel bolt and the threaded section of the nut. Make sure the wheel bolt is installed vertically to the hub disc surface. Do not install the nut and the washers that have been used as tools on a vehicle.
5. Tighten the nut until the wheel bolt is drawn fully into the hub. Do not exceed the maximum torque limit. Make sure there is no gap (G) between the bolt and the hub. Limited torque: 108 N.m (11.0 kgf.m, 80 lbf.ft) max.
6. Install the rear brake disc (see «RUNOUT»(/acura/tsx/ii-2008-2014/remont/mechanical-hydraulic/#conventional-brake-components-v6) ). NOTE: If you cannot tighten the wheel nut to the specified torque when installing the wheel, replace the rear hub bearing unit as an assembly. Before installing the wheel, clean the mating surfaces between the brake disc and the inside of the wheel.

Ball Joint Removal

Special Tools Required

1. Ball Joint Thread Protector, 14 mm 07AAE-SJAA100
2. Ball Joint Thread Protector, 12 mm 07AAF-SDAA100
3. Ball Joint Thread Protector, 10 mm 07AAF-SECA120
4. Ball Joint Remover, 32 mm 07MAC-SL0A102
5. Ball Joint Remover, 28 mm 07MAC-SL0A202

Note. Always use a ball joint remover to disconnect a ball joint. Do not strike the housing or any other part of the ball joint connection to disconnect it.

Scheme 15

Scheme 16

Scheme 17

1. Install a hex nut (A) or the ball joint thread protector onto the threads of the ball joint (B). NOTE: When using a hex nut, make sure the nut is flush with the ball joint pin end to prevent damage to the threaded end of the ball joint pin.
2. Apply grease to the ball joint remover on the areas as shown (A). This will ease the installation of the tool, and prevent damage to the pressure bolt (B) threads.
3. Loosen the pressure bolt (A), and install the ball joint remover as shown. Insert the jaws carefully, making sure not to damage the ball joint boot. Adjust the jaw spacing by turning the adjusting bolt (B). NOTE: Fasten the safety chain (C) securely to a suspension arm or the subframe (D). Do not fasten it to a brake line or wire harness.
4. After adjusting the adjusting bolt, make sure the head of the adjusting bolt is in the position shown to allow the jaw (E) to pivot.
5. With a wrench, tighten the pressure bolt until the ball joint pin pops loose from the ball joint connecting hole. If necessary, apply penetrating type lubricant to loosen the ball joint pin. NOTE: Do not use pneumatic or electric tools on the pressure bolt.
6. Remove the ball joint remover, then remove the nut or the ball joint thread protector from the end of the ball joint pin, and pull the ball joint out of the ball joint connecting hole. Inspect the ball joint boot, and replace it if damaged.

Ball Joint Boot Inspection/Replacement

Special Tools Required

1. Clip Guide, 45 mm 070AG-SJA0300
2. Clip Guide, 41 mm 07974-SA50700

Scheme 18

Scheme 19

Scheme 20

Scheme 21

1. Check the ball joint boot for weakness, damage, cracks, and grease leaks. NOTE: If the ball joint boot is damaged and leaks grease, replace the appropriate part as an assembly. If the ball joint boot is weak and cracked but does not leak grease, go to step 2. Replace the appropriate ball joint boot.
2. Disconnect the appropriate ball joint connection, and remove the component including the ball joint: The front knuckle (see «KNUCKLE/HUB REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/suspension-front/#front-suspension-v6) ). The front upper arm (see «UPPER ARM REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/suspension-front/#front-suspension-v6__upper-arm-replacement) ). The rear upper arm (see «UPPER ARM REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/suspension-rear/#rear-suspension-v6__upper-arm-replacement) ).
3. Paint a alignment mark (A) in the center between the both boot clip end faces (B) on the appropriate part (C).
4. Remove the boot clip and the boot.
5. Pack the interior and lip (A) of a new boot with grease. Keep the grease off of the boot-to-housing mating surfaces (B). NOTE: Use the grease that comes with the ball joint kit, or multi-purpose grease.
6. Pack fresh grease into the base (C). Do not let dirt or other foreign materials get into the boot.
7. Install the boot on the ball joint, then squeeze it gently to force out any air, then wipe the grease off the tapered portion of the ball joint pin (D).
8. The front knuckle ball joint or the rear upper arm ball joint: Adjust the depth by turning the clip guide until its base is just above the groove around (A) the bottom of the boot. Then slide the clip (B) over the tool and into position on the boot.
9. The front upper arm ball joint: Adjust the ball joint boot clip guide with the adjusting bolt (A) until its base is just above the groove around (B) the bottom of the boot. Then slide the clip (C) over the clip guide and into position on the boot.
10. Align the center between the both end faces of the boot clip to alignment mark of the appropriate part.
11. After installing a boot, wipe any grease off the exposed portion of the ball joint pin.
12. Install all of the removed parts.
