Interface Dial Removal/Installation Acura TSX II

Navigation System (v6) 2 illustrations ~139 words

Interface Dial Removal/Installation

Note. Put on gloves to protect your hands. Take care not to scratch the dashboard and related parts. Lay a workshop towel under the parts when working on them to protect the face panel from scratches or other damage.

Scheme 516

Scheme 516: Interface Dial Removal/Installation
Scheme 516: Interface Dial Removal/Installation

Scheme 517

Scheme 517
Scheme 517
  1. Remove the audio-navigation switch panel (see «AUDIO-NAVIGATION SWITCH PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-v6) ).
  2. Remove the screw and harness cover (A).
  3. Disconnect the interface dial connector (A). Remove the screws and interface dial (B). Carefully pry off the knob (C) with a small screwdriver, then apply slow and steady pressure with your thumbs to push out the interface dial until the dial (D) pops off.
  4. Install the dial in the reverse order of removal.

Note. If the hard buttons do not work, but the jog dial does, recheck the interface dial connector connection.
