Steering (v6) Acura TSX II

Manual & Power Steering 33 illustrations ~2608 words

Scheme 1

Scheme 1: Special Tools
Scheme 1: Special Tools

Scheme 2

Scheme 2: Component Location Index
Scheme 2: Component Location Index

Scheme 3

Scheme 3: Steering Wheel Rotational Play Check
Scheme 3: Steering Wheel Rotational Play Check
  1. Turn the front wheels to the straight ahead position.
  2. Measure how far you can turn the steering wheel left and right without moving the front wheels. If the play is within the limit, the steering gearbox and the steering linkage are OK. If the play exceeds the limit, adjust the rack guide (see «RACK GUIDE ADJUSTMENT»(/acura/tsx/ii-2008-2014/remont/manual-power-steering/#steering-v6__rack-guide-adjustment) ). If the play is still excessive after rack guide adjustment, inspect the steering linkage and the steering gearbox (see «STEERING LINKAGE AND GEARBOX INSPECTION»(/acura/tsx/ii-2008-2014/remont/manual-power-steering/#steering-v6) ). Rotational play: 0-10 mm (0-0.39 in)

Power Assist Check

Note. This test should be done with original equipment tires and wheels at the correct tire pressure.

Scheme 4

Scheme 4: Power Assist Check
Scheme 4: Power Assist Check
  1. Start the engine, and let it idle.
  2. Attach a commercially available spring scale (A) to the steering wheel. With the engine idling and the vehicle on a clean, dry floor, pull the scale as shown, and read it as soon as the tires begin to turn. Initial turning load: 29 N (3.0 kgf, 6.6 lbf)
  3. If the scale reads no more than the specification, the power assist is OK. If it reads more, check these items: Steering linkage (see «STEERING LINKAGE AND GEARBOX INSPECTION»(/acura/tsx/ii-2008-2014/remont/manual-power-steering/#steering-v6) ) Rack guide adjustment (see «RACK GUIDE ADJUSTMENT»(/acura/tsx/ii-2008-2014/remont/manual-power-steering/#steering-v6__rack-guide-adjustment) ) EPS system (see «GENERAL TROUBLESHOOTING INFORMATION»(/acura/tsx/ii-2008-2014/remont/electronic-steering/#electronic-power-steering-eps-system-v6) )

Scheme 5

Scheme 5: Steering Linkage and Gearbox Inspection
Scheme 5: Steering Linkage and Gearbox Inspection

Steering Wheel Removal

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ), and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Scheme 6

Scheme 6: Steering Wheel Removal
Scheme 6: Steering Wheel Removal

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8
  1. Do the battery terminal disconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-v6__using-the-gr8-battery-diagnostic-station) ).
  2. Set the front wheels in the straight ahead position, then remove the driver's airbag from the steering wheel (see «DRIVER'S AIRBAG REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__drivers-airbag-replacement) ).
  3. Disconnect the cable reel subharness connector (A).
  4. Loosen the steering wheel bolt (B) three turns.
  5. Install a commercially available steering wheel puller (A) on the steering wheel (B). Free the steering wheel from the steering column shaft by turning the pressure bolt (C) of the puller. Note these items when removing the steering wheel: Do not tap on the steering wheel or the steering column shaft when removing the steering wheel. If you thread the puller bolts (D) into the wheel hub more than five threads, the bolts will hit the cable reel and damage it. To prevent this, install a pair of jam nuts five threads up on each puller bolt.
  6. Remove the steering wheel puller, then remove the steering wheel bolt (A) and the steering wheel (B) from the steering column.

Scheme 9

Scheme 9: Steering Wheel Disassembly/Reassembly
Scheme 9: Steering Wheel Disassembly/Reassembly

Steering Wheel Installation

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ), and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Scheme 10

Scheme 10: Steering Wheel Installation
Scheme 10: Steering Wheel Installation

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12
  1. Before installing the steering wheel, make sure the front wheels are pointing straight ahead, then center the cable reel (A). Do this by first rotating the cable reel clockwise until it stops. Then rotate it counterclockwise about three full turns. The arrow mark (B) on the cable reel label should point straight up.
  2. Position the two tabs (A) of the turn signal canceling sleeve (B) as shown. Install the steering wheel on to the steering column shaft, making sure the steering wheel hub (C) engages the pins (D) of the cable reel and the tabs of the turn signal canceling sleeve. Do not tap on the steering wheel or steering column shaft when installing the steering wheel.
  3. Install the steering wheel bolt (A), and tighten it to the specified torque. Connect the cable reel subharness connector (B). Make sure the wire harness is routed and fastened properly.
  4. Install the driver's airbag (see «DRIVER'S AIRBAG REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__drivers-airbag-replacement) ).
  5. Do the battery terminal reconnection procedure (see «RECONNECTION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-v6__reconnection) ), and check these items: Turn the ignition switch to ON (II), and check that the SRS indicator comes on for about 6 seconds, and then goes off. Make sure the horn and turn signal switches work properly. Make sure the steering wheel switches work properly.
  6. After installation, check the steering wheel spoke angle. If the steering spoke angles to the right and left are not equal (steering wheel is not centered), correct the engagement of the wheel/column shaft splines.

Steering Column Removal and Installation

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ), and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Scheme 13

Scheme 13: Removal
Scheme 13: Removal

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15
  1. Tilt the steering column all the way down, and move it all the way out.
  2. Do the battery terminal disconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-v6__using-the-gr8-battery-diagnostic-station) ).
  3. Remove the driver's airbag (see «DRIVER'S AIRBAG REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__drivers-airbag-replacement) ), and the steering wheel (see «STEERING WHEEL REMOVAL»(/acura/tsx/ii-2008-2014/remont/manual-power-steering/#steering-v6__steering-wheel-removal) ).
  4. Remove the driver's dashboard undercover (see «DRIVER'S POCKET REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6) ).
  5. Remove the column covers (see «SIDE DEFOGGER VENT TRIM REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__side-defogger-vent-trim-removalinstallation) ).
  6. Remove the steering joint cover (A).
  7. Loosen the upper steering joint bolt (A), and remove the lower steering joint bolt (B). Disconnect the steering joint (C) by sliding the steering joint into the column shaft (D). Tighten the upper steering joint bolt to hold the steering joint in place. NOTE: Do not disconnect the steering joint from the column shaft. If the center guide (E) is in place and has not moved, leave it in place. If the center guide has come off, discard it.
  8. Disconnect the wire harness connectors from the combination switch assembly/cable reel (A).
  9. Remove the combination switch assembly/cable reel from the steering column shaft by removing the three screws (B).
  10. Disconnect the connectors from the ignition switch (C), and release the wire harness clips (D) from the steering column.
  11. Make sure that the lock lever (E) is in the locked position. Remove the steering column (F) by removing the attaching nuts and bolts, and carefully guide it out of the dashboard. NOTE: Do not release the lock lever until the steering column is installed.

Scheme 16

Scheme 16: Installation
Scheme 16: Installation

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19
  1. Install the steering column in the reverse order of removal, and note these items: Make sure the wires are not caught or pinched by any parts. Tighten the three screws (A) in the sequence shown.
  2. Center the steering rack within its stroke.
  3. Loosen the upper steering joint bolt (A) and slip the lower end of the steering joint (B) onto the pinion shaft (C). NOTE: Pinion shaft with center guide: Install the steering joint by aligning the center guide (D). Pinion shaft without center guide: Position the steering column by aligning the gap (E) with the angle.
  4. Align the bolt hole (A) on the steering joint with the groove (B) around the pinion shaft, then loosely install the lower steering joint bolt (C). Be sure that the joint bolt is securely in the groove in the pinion shaft.
  5. Pull on the steering joint to make sure that the steering joint is fully seated, then tighten the lower joint bolt to the specified torque.
  6. Tighten the upper steering joint bolt (D) to the specified torque.
  7. Install the steering joint cover (A).
  8. Install the column covers (see «SIDE DEFOGGER VENT TRIM REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__side-defogger-vent-trim-removalinstallation) ).
  9. Install the driver's dashboard undercover (see «DRIVER'S POCKET REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6) ).
  10. Install the steering wheel (see «STEERING WHEEL INSTALLATION»(/acura/tsx/ii-2008-2014/remont/manual-power-steering/#steering-v6__steering-wheel-installation) ), and the driver's airbag (see «DRIVER'S AIRBAG REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__drivers-airbag-replacement) ).
  11. Do the battery terminal reconnection procedure (see «RECONNECTION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-v6__reconnection) ), and check these items: Turn the ignition switch to ON (II), and check that the SRS indicator comes on for about 6 seconds, and then goes off. Make sure the horn and turn signal switches work properly. Make sure the steering wheel switches work properly.
  12. After installation, check these items: Check the steering wheel spoke angle. If the steering spoke angles to the right and left are not equal (steering wheel and rack are not centered), correct the engagement of the joint/pinion shaft splines. Set the steering column to the center tilt position, and to the center telescopic position, then do the front toe inspection (see «WHEEL ALIGNMENT»(/acura/tsx/ii-2008-2014/remont/wheel-alignment/#front-and-rear-suspension-v6__wheel-alignment) ).

Scheme 20

Scheme 20: Inspection
Scheme 20: Inspection
  1. Remove the steering column (see «STEERING COLUMN REMOVAL AND INSTALLATION»(/acura/tsx/ii-2008-2014/remont/manual-power-steering/#steering-v6__steering-column-removal-and-installation) ).
  2. Check these items: Check for loose bearing mounting nuts (A). If they are loose, replace the column as an assembly. Check the steering column ball bearings (B) and the steering joints (C) for play and proper movement. If any bearing is noisy or has excessive play, replace the steering column as an assembly. Check the sliding capsules (D) for distortion or breakage. If there is distortion or breakage, replace the steering column as an assembly, Check the tilt mechanism and telescopic mechanism for movement and damage.
  3. Install the steering column (see «INSTALLATION»(/acura/tsx/ii-2008-2014/remont/manual-power-steering/#steering-v6) ).

Scheme 21

Scheme 21: Check of Tilting Force
Scheme 21: Check of Tilting Force
  1. Set the steering wheel in the straight ahead driving position, and loosen the lock lever fully.
  2. Attach a commercially available spring scale (A) to the highest point of the steering wheel, and tilt the steering column to the lowest position.
  3. Pull the spring scale straight up, and read the force required to move the steering column.
  4. Attach the spring scale to the lowest point of the steering wheel.
  5. Pull the spring scale straight down, and read the force required to move the steering column. Tilting force (upward/downward): Standard: 70 N (7.1 kgf, 16 lbf) max.
  6. If the measurement is higher than specified, replace the steering column as an assembly (see «STEERING COLUMN REMOVAL AND INSTALLATION»(/acura/tsx/ii-2008-2014/remont/manual-power-steering/#steering-v6__steering-column-removal-and-installation) ).

Scheme 22

Scheme 22: Check of Telescoping Force
Scheme 22: Check of Telescoping Force
  1. Set the steering wheel in the straight ahead driving position, and loosen the lock lever fully, and push in the steering wheel to the fully telescoped in position.
  2. Attach a commercially available spring scale (A) to the center point of the steering wheel as shown.
  3. Pull the spring scale, and read the force required to move the steering column during telescoping out. Telescoping force: Standard: 110 N (11.2 kgf, 24.7 lbf) max.
  4. If the measurement is higher than specified, replace the steering column as an assembly (see «STEERING COLUMN REMOVAL AND INSTALLATION»(/acura/tsx/ii-2008-2014/remont/manual-power-steering/#steering-v6__steering-column-removal-and-installation) ).

Scheme 23

Scheme 23: Check of Lock Lever Force
Scheme 23: Check of Lock Lever Force
  1. Move the lock lever (A) from the loosened position to the locked position three to five times, then release the lock lever. Adjust the steering column to the center tilt position and also to the full telescopic out position, and hold the steering wheel.
  2. Using a commercially available push-pull gauge, push the lock lever 10 mm (0.39 in) in from its end, and measure the force required to move the lock lever. Lock lever force: 50-70 N (5.1-7.1 kgf, 11-16 lbf) min.
  3. If the measurement is higher than specified, replace the steering column as an assembly (see «STEERING COLUMN REMOVAL AND INSTALLATION»(/acura/tsx/ii-2008-2014/remont/manual-power-steering/#steering-v6__steering-column-removal-and-installation) ).

Scheme 24

Scheme 24: Steering Lock Replacement
Scheme 24: Steering Lock Replacement

Scheme 25

Scheme 25
Scheme 25
  1. Remove the steering column (see «STEERING COLUMN REMOVAL AND INSTALLATION»(/acura/tsx/ii-2008-2014/remont/manual-power-steering/#steering-v6__steering-column-removal-and-installation) ).
  2. Center-punch both of the shear bolts (A), and drill their heads off with a 5 mm (0.20 in) drill bit. Be careful not to damage the steering lock when removing the shear bolts.
  3. Remove the shear bolts from the steering lock (B), then remove the steering lock.
  4. Remove the immobilizer-keyless control unit from the steering lock, then install it on new steering lock (see «IMMOBILIZER-KEYLESS CONTROL UNIT REGISTRATION»(/acura/tsx/ii-2008-2014/remont/door-locks-anti-theft-systems/#immobilizer-system-v6__immobilizer-keyless-control-unit-registration) ).
  5. Install the steering lock without the key inserted.
  6. Loosely tighten the new shear bolts.
  7. Insert the ignition key, and check for proper operation of the steering wheel lock and that the ignition key turns freely.
  8. Tighten the shear bolts (A) until the hex heads (B) twist off.
  9. Install the steering column (see «INSTALLATION»(/acura/tsx/ii-2008-2014/remont/manual-power-steering/#steering-v6) ).
  10. Rewrite all new keys to the immobilizer-keyless control unit (see «IMMOBILIZER KEY REGISTRATION»(/acura/tsx/ii-2008-2014/remont/door-locks-anti-theft-systems/#immobilizer-system-v6__immobilizer-key-registration) ), and make sure the immobilizer system works properly.

Rack Guide Adjustment

Special Tools Required

Locknut Wrench, 40 mm 07MAA-SL00100, 07916-SA50001, or 07AAA-TL2A100

Scheme 26

Scheme 26: Rack Guide Adjustment
Scheme 26: Rack Guide Adjustment

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28
  1. Set the front wheels in the straight ahead position.
  2. Loosen the rack guide screw locknut (A) with the locknut wrench, then remove the rack guide screw (B).
  3. Remove the old sealant from the rack guide screw (A), and apply new sealant (Three Bond 1215 or Loctite 5699) to the middle of the threads (B). Loosely install the rack guide screw on the steering gearbox. NOTE: If more than 5 minutes has passed after applying the sealant, remove the old sealant and residue, and reapply new sealant.
  4. Tighten the rack guide screw (A) to 25 N.m (2.5 kgf.m, 18 lbf.ft), then loosen it.
  5. Retighten the rack guide screw to 5.9 N.m (0.6 kgf.m, 4 lbf.ft), then back it off to the specified angle. Specified return angle: 10 ± 5 °
  6. Hold the rack guide screw stationary with a wrench, and tighten the locknut (B) by hand until it's fully seated.
  7. Install the locknut wrench on the locknut, and hold the rack guide screw stationary with a wrench. Tighten the locknut to the specified torque.
  8. Check for unusual steering effort through the complete turning range.
  9. Check the steering wheel rotation play (see «STEERING WHEEL ROTATIONAL PLAY CHECK»(/acura/tsx/ii-2008-2014/remont/manual-power-steering/#steering-v6) ) and the power assist (see «POWER ASSIST CHECK»(/acura/tsx/ii-2008-2014/remont/manual-power-steering/#steering-v6__power-assist-check) ).

Tie-Rod End Ball Joint Boot Replacement

Special Tools Required

Bearing Driver Attachment, 36 mm 07965-SA50500

Scheme 29

Scheme 29: Tie-Rod End Ball Joint Boot Replacement
Scheme 29: Tie-Rod End Ball Joint Boot Replacement

Scheme 30

Scheme 30
Scheme 30
  1. Disconnect the tie-rod end ball joint from the knuckle (see «INSTALLATION»(/acura/tsx/ii-2008-2014/remont/electronic-steering/#electronic-power-steering-eps-system-v6) ).
  2. Remove the tie-rod end from the rack end (see «RACK END REMOVAL AND INSTALLATION»(/acura/tsx/ii-2008-2014/remont/electronic-steering/#electronic-power-steering-eps-system-v6) ).
  3. Remove the ball joint boot from the tie-rod end, and wipe the old grease off the ball pin.
  4. Pack the lower area of the ball pin (A) with fresh multipurpose grease.
  5. Pack the interior of the ball joint boot (B) and lip (C) with fresh multipurpose grease. Note these items when installing new grease: Keep grease off the boot mounting area (D) and the tapered section (E) of the ball pin. Do not allow dust, dirt, or other foreign materials to enter the boot.
  6. Install the ball joint boot (A) using the bearing driver attachment. The boot must not have a gap at the boot installation sections (B). After installing the boot, check the ball pin tapered section for grease contamination, and wipe it if necessary.
  7. Install the tie-rod end to the rack end (see «RACK END REMOVAL AND INSTALLATION»(/acura/tsx/ii-2008-2014/remont/electronic-steering/#electronic-power-steering-eps-system-v6) ).
  8. Connect the tie-rod end ball joint to the knuckle (see «RACK END REMOVAL AND INSTALLATION»(/acura/tsx/ii-2008-2014/remont/electronic-steering/#electronic-power-steering-eps-system-v6) ).
  9. Check the wheel alignment, and adjust it if necessary (see «WHEEL ALIGNMENT»(/acura/tsx/ii-2008-2014/remont/wheel-alignment/#front-and-rear-suspension-v6__wheel-alignment) ).

Scheme 31

Scheme 31: Gearbox Mount Cushion Replacement
Scheme 31: Gearbox Mount Cushion Replacement

Scheme 32

Scheme 32
Scheme 32

Scheme 33

Scheme 33
Scheme 33
  1. Remove the steering gearbox (see «STEERING GEARBOX REMOVAL AND INSTALLATION»(/acura/tsx/ii-2008-2014/remont/electronic-steering/#electronic-power-steering-eps-system-v6__steering-gearbox-removal-and-installation) ).
  2. Position a 36 mm socket (A) on the flange part of the gearbox housing with a washer (B), a 10 x 150 mm flange bolt (C) and a 10 mm nut (D) as shown.
  3. Hold the flange bolt with a wrench, and tighten the nut with a wrench. Remove the gearbox mount cushion (E).
  4. Apply a mild soap and water solution to the new gearbox mount cushion surface (A), then place the mount cushion on the gearbox mounting cushion hole.
  5. Position a 36 mm socket (B) on the flange part of the gearbox housing with a washer, a flange bolt, and the nut as shown.
  6. Install the gearbox mount cushion by tightening the nut until the mount cushion edge (A) properly fits on the gearbox flange surface (B).
  7. Install the steering gearbox (see «INSTALLATION»(/acura/tsx/ii-2008-2014/remont/electronic-steering/#electronic-power-steering-eps-system-v6) ).
