EGR System (v6) Acura TSX II

Auxiliary Emission Control Systems 21 illustrations ~3466 words

Scheme 1

Scheme 1: Component Location Index
Scheme 1: Component Location Index

DTC P0400: EGR System Leak Detected

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

  1. Check for a loose or damaged EGR pipe. Is the EGR pipe OK? YES -Go to step 2 . NO -Reconnect or replace the EGR pipe, then go to step 7 .
  2. Start the engine. Hold the engine speed at 3,000 rpm without load (in P or N) until the radiator fan comes on, then let it idle.
  3. Test-drive under these conditions: Engine coolant temperature (ECT SENSOR 1) above 158°F (70°C) Transmission in D Vehicle speed at 25 mph (40 km/h) for 5 minutes or more Maintain the vehicle speed at 32 mph (50 km/h) and the engine speed between 1,300-3,000 rpm for 1 minute or more with cruise control set
  4. Monitor the OBD STATUS for DTC P0400 in the DTCs MENU with the HDS. Does the screen indicate FAILED? YES -Go to step 5 . NO -If the screen indicates PASSED, intermittent failure, the system is OK at this time. Check for exhaust gas leakage between the EGR pipe and the EGR valve. If the screen indicates NOT COMPLETED, go to step 3 and recheck.
  5. Turn the ignition switch to LOCK (0).
  6. Replace the EGR valve (see «EGR VALVE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/auxiliary-emission-control-systems/#egr-system-v6) ).
  7. Turn the ignition switch to ON (II).
  8. Reset the PCM with the HDS.
  9. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#idle-control-system-v6__pcm-idle-learn-procedure) ).
  10. Test-drive under these conditions: Engine coolant temperature (ECT SENSOR 1) above 158°F (70°C) Transmission in D Vehicle speed at 25 mph (40 km/h) for 5 minutes or more Maintain the vehicle speed at 32 mph (50 km/h) and the engine speed between 1,300-3,000 rpm for 1 minute or more with cruise control set
  11. Check for Pending or Confirmed DTCs with the HDS. Is DTC P0400 indicated? YES -Check for leakage between the EGR pipe and the EGR valve, then go to step 1 . NO -Go to step 12 .
  12. Monitor the OBD STATUS for DTC P0400 in the DTCs MENU with the HDS. Does the screen indicate PASSED? YES -Troubleshooting is complete. If any other Pending or Confirmed DTCs were indicated in step 11 , go to the indicated DTC's troubleshooting. NO -If the screen indicates FAILED, check for leakage between the EGR pipe and the EGR valve, then go to step 1 . If the screen indicates NOT COMPLETED, go to step 10 .

DTC P0401: EGR Insufficient Flow

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

  1. Turn the ignition switch to ON (II).
  2. Clear the DTC with the HDS.
  3. Start the engine. Hold the engine speed at 3,000 rpm without load (in P or N) until the radiator fan comes on, then let it idle.
  4. Do the EGR TEST in the INSPECTION MENU with the HDS. Is the result OK? YES -Go to step 5 , NO -Go to step 7 .
  5. Test-drive under these conditions: Engine coolant temperature (ECT SENSOR 1) above 158°F (70°C) Transmission in D Drive at a steady speed between 55-75 mph (88-120 km/h) for at least 10 seconds During the drive, decelerate (with the throttle fully closed) for 5 seconds
  6. Monitor the OBD STATUS for DTC P0401 in the DTCs MENU with the HDS. Does the screen indicate FAILED? YES -Clean the intake manifold EGR port and the EGR pipe (see «EGR PIPE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/auxiliary-emission-control-systems/#egr-system-v6) ) with throttle plate cleaner. Also, clean the passage inside the EGR valve with throttle plate cleaner, then go to step 9 . NO -If the screen indicates PASSED, intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the EGR valve and the PCM. If the screen indicates EXECUTING, keep driving until a result comes on. If the screen indicates OUT OF CONDITION, go to step 5 and recheck.
  7. Turn the ignition switch to LOCK (0).
  8. Replace the EGR valve (see «EGR VALVE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/auxiliary-emission-control-systems/#egr-system-v6) ).
  9. Turn the ignition switch to ON (II).
  10. Reset the PCM with the HDS.
  11. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#idle-control-system-v6__pcm-idle-learn-procedure) ).
  12. Test-drive under these conditions: Engine coolant temperature (ECT SENSOR 1) above 158°F (70°C) Transmission in D Drive at a steady speed between 55-75 mph (88-120 km/h) for at least 10 seconds During the drive, decelerate (with the throttle fully closed) for 5 seconds
  13. Check for Pending or Confirmed DTCs with the HDS. Is DTC P0401 indicated? YES -Check for poor connections or loose terminals at the EGR valve and the PCM. If the connections and the terminals are OK, go to step 15 . NO -Go to step 14 .
  14. Monitor the OBD STATUS for DTC P0401 in the DTCs MENU with the HDS. Does the screen indicate PASSED? YES -Troubleshooting is complete. If any other Pending or Confirmed DTCs were indicated in step 13 , go to the indicated DTC's troubleshooting. NO -If the screen indicates FAILED, check for poor connections or loose terminals at the EGR valve and the PCM, then go to step 1 . If the screen indicates EXECUTING, keep driving until a result comes on. If the screen indicates OUT OF CONDITION, go to step 12 .
  15. Update the PCM if it does not have the latest software (see «PCM UPDATE»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#pgm-fi-system-v6__pcm-update) ), or substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#fuel-and-emissions-systems-v6__substituting-the-pcm) ).
  16. Test-drive under these conditions: Engine coolant temperature (ECT SENSOR 1) above 158°F (70°C) Transmission in D Drive at a steady speed between 55-75 mph (88-120 km/h) for at least 10 seconds During the drive, decelerate (with the throttle fully closed) for 5 seconds
  17. Check for Pending or Confirmed DTCs with the HDS. Is DTC P0401 indicated? YES -Check for poor connections or loose terminals at the EGR valve and the PCM. If the PCM was updated, substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#fuel-and-emissions-systems-v6__substituting-the-pcm) ), then go to step 16 . If the PCM was substituted, go to step 1 . NO -Go to step 18 .
  18. Monitor the OBD STATUS for DTC P0401 in the DTCs MENU with the HDS. Does the screen indicate PASSED? YES -If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#pgm-fi-system-v6__pcm-replacement) ). If any other Pending or Confirmed DTCs were indicated in step 17 , go to the indicated DTC's troubleshooting. NO -If the screen indicates FAILED, check for poor connections or loose terminals at the EGR valve and the PCM. If the PCM was updated, substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#fuel-and-emissions-systems-v6__substituting-the-pcm) ), then go to step 16 . If the PCM was substituted, go to step 1 . If the screen indicates EXECUTING, keep driving until a result comes on. If the screen indicates OUT OF CONDITION, go to step 16 .

DTC P0404: EGR Circuit Range/Performance Problem

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 2

Scheme 2: DTC P0404: EGR Circuit Range/Performance Problem
Scheme 2: DTC P0404: EGR Circuit Range/Performance Problem

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6
  1. Turn the ignition switch to ON (II).
  2. Clear the DTC with the HDS.
  3. Start the engine. Hold the engine speed at 3,000 rpm without load (in P or N) until the radiator fan comes on, then let it idle.
  4. Do the EGR TEST in the INSPECTION MENU with the HDS. Is the result OK? YES -Intermittent failure, the system is OK at this time. Clean any carbon build-up on the EGR valve with throttle plate cleaner. NO -Go to step 5 .
  5. Turn the ignition switch to LOCK (0).
  6. Disconnect the EGR valve 5P connector.
  7. At the EGR valve side, measure the resistance between EGR valve 5P connector terminals No. 2 and No. 3. Is there 100 kohms or more? YES -Go to step 25 . NO -Go to step 8 .
  8. At the EGR valve side, measure the resistance between EGR valve 5P connector terminals No. 2 and No. 4. Is there 100 kohms or more? YES -Go to step 25 . NO -Go to step 9 .
  9. Check for continuity between EGR valve 5P connector terminal No. 5 and body ground. Is there continuity? YES -Go to step 10 . NO -Repair open in the wire between the EGR valve and G101, then go to step 26 .
  10. Jump the SCS line with the HDS.
  11. Disconnect PCM connector C (49P).
  12. Check for continuity between PCM connector terminal C10 and body ground. Is there continuity? YES -Repair short in the wire between the PCM (C10) and the EGR valve, then go to step 26 . NO -Go to step 13 .
  13. Check for continuity between PCM connector terminal C10 and EGR valve 5P connector terminal No. 1. Is there continuity? YES -Go to step 14 . NO -Repair open in the wire between the PCM (C10) and the EGR valve, then go to step 26 .
  14. Remove the EGR valve (see «EGR VALVE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/auxiliary-emission-control-systems/#egr-system-v6) ).
  15. Clean any carbon build-up on the EGR valve with throttle plate cleaner.
  16. Install the EGR valve (see «EGR VALVE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/auxiliary-emission-control-systems/#egr-system-v6) ).
  17. Reconnect the EGR valve 5P connector.
  18. Reconnect PCM connector C (49P).
  19. Turn the ignition switch to ON (II).
  20. Reset the PCM with the HDS.
  21. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#idle-control-system-v6__pcm-idle-learn-procedure) ).
  22. Start the engine. Hold the engine speed at 3,000 rpm without load (in P or N) until the radiator fan comes on, then let it idle.
  23. Do the EGR TEST in the INSPECTION MENU with the HDS. Is the result OK? YES -Go to step 32 . NO -Go to step 24 .
  24. Turn the ignition switch to LOCK (0).
  25. Replace the EGR valve (see «EGR VALVE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/auxiliary-emission-control-systems/#egr-system-v6) ).
  26. Reconnect all connectors.
  27. Turn the ignition switch to ON (II).
  28. Reset the PCM with the HDS.
  29. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#idle-control-system-v6__pcm-idle-learn-procedure) ).
  30. Start the engine. Hold the engine speed at 3,000 rpm without load (in P or N) until the radiator fan comes on, then let it idle.
  31. Do the EGR TEST in the INSPECTION MENU with the HDS.
  32. Check for Pending or Confirmed DTCs with the HDS. Is DTC P0404 indicated? YES -Check for poor connections or loose terminals at the EGR valve and the PCM, then go to step 1 . If the connections and terminals are OK, go to step 33 . NO -Troubleshooting is complete. If any other Pending or Confirmed DTCs are indicated, go to the indicated DTC's troubleshooting.
  33. Update the PCM if it does not have the latest software (see «PCM UPDATE»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#pgm-fi-system-v6__pcm-update) ), or substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#fuel-and-emissions-systems-v6__substituting-the-pcm) ).
  34. Start the engine. Hold the engine speed at 3,000 rpm without load (in P or N) until the radiator fan comes on, then let it idle.
  35. Do the EGR TEST in the INSPECTION MENU with the HDS.
  36. Check for Pending or Confirmed DTCs with the HDS. Is DTC P0404 indicated? YES -Check for poor connections or loose terminals at the EGR valve and the PCM. If the PCM was updated, substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#fuel-and-emissions-systems-v6__substituting-the-pcm) ), then go to step 34 . If the PCM was substituted, go to step 1 . NO -If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#pgm-fi-system-v6__pcm-replacement) ). If any other Pending or Confirmed DTCs are indicated, go to the indicated DTC's troubleshooting.

DTC P0406: EGR Valve Position Sensor Circuit High Voltage

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 7

Scheme 7: DTC P0406: EGR Valve Position Sensor Circuit High Voltage
Scheme 7: DTC P0406: EGR Valve Position Sensor Circuit High Voltage

Scheme 8

Scheme 8
Scheme 8
  1. Turn the ignition switch to ON (II).
  2. Check the EGR VLS in the DATA LIST with the HDS. Is 4.88 V or more indicated? YES -Go to step 3 . NO -Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the EGR valve and the PCM.
  3. Turn the ignition switch to LOCK (0).
  4. Disconnect the EGR valve 5P connector.
  5. Turn the ignition switch to ON (II).
  6. Measure the voltage between EGR valve 5P connector terminals No. 3 and No. 4. Is there about 5 V? YES -Go to step 11 . NO -Go to step 7 .
  7. Turn the ignition switch to LOCK (0).
  8. Jump the SCS line with the HDS.
  9. Disconnect PCM connector C (49P).
  10. Check for continuity between PCM connector terminal C16 and EGR valve 5P connector terminal No. 3. Is there continuity? YES -Go to step 18 . NO -Repair open in the wire between the EGR valve and the PCM (C16), then go to step 13 .
  11. Turn the ignition switch to LOCK (0).
  12. Replace the EGR valve (see «EGR VALVE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/auxiliary-emission-control-systems/#egr-system-v6) ).
  13. Reconnect all connectors.
  14. Turn the ignition switch to ON (II).
  15. Reset the PCM with the HDS.
  16. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#idle-control-system-v6__pcm-idle-learn-procedure) ).
  17. Check for Pending or Confirmed DTCs with the HDS. Is DTC P0406 indicated? YES -Check for poor connections or loose terminals at the EGR valve and the PCM, then go to step 1 . NO -Troubleshooting is complete. If any other Pending or Confirmed DTCs are indicated, go to the indicated DTC's troubleshooting.
  18. Reconnect all connectors.
  19. Update the PCM if it does not have the latest software (see «PCM UPDATE»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#pgm-fi-system-v6__pcm-update) ), or substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#fuel-and-emissions-systems-v6__substituting-the-pcm) ).
  20. Check for Pending or Confirmed DTCs with the HDS. Is DTC P0406 indicated? YES -Check for poor connections or loose terminals at the EGR valve and the PCM. If the PCM was updated, substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#fuel-and-emissions-systems-v6__substituting-the-pcm) ), then recheck. If the PCM was substituted, go to step 1 . NO -If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#pgm-fi-system-v6__pcm-replacement) ). If any other Pending or Confirmed DTCs are indicated, go to the indicated DTC's troubleshooting.

DTC P2413: EGR System Malfunction

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 9

Scheme 9: DTC P2413: EGR System Malfunction
Scheme 9: DTC P2413: EGR System Malfunction

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18
  1. Turn the ignition switch to ON (II).
  2. Clear the DTC with the HDS.
  3. Start the engine. Hold the engine speed at 3,000 rpm without load (in P or N) until the radiator fan comes on, then let it idle.
  4. Do the EGR TEST in the INSPECTION MENU with the HDS. Is the result OK? YES -Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the EGR valve and the PCM. NO -Go to step 5 .
  5. Turn the ignition switch to LOCK (0).
  6. Turn the ignition switch to ON (II).
  7. Check the EGR VLS in the DATA LIST with the HDS. Is about 0 Vindicated? YES -Go to step 8 . NO -Go to step 21 .
  8. Turn the ignition switch to LOCK (0).
  9. Disconnect the EGR valve 5P connector.
  10. Turn the ignition switch to ON (II).
  11. Measure the voltage between EGR valve 5P connector terminal No. 4 and body ground. Is there about 5 V? YES -Go to step 16 . NO -Go to step 12 .
  12. Turn the ignition switch to LOCK (0).
  13. Jump the SCS line with the HDS.
  14. Disconnect PCM connector C (49P).
  15. Check for continuity between PCM connector terminal C12 and EGR valve 5P connector terminal No. 4. Is there continuity? YES -Go to step 50 . NO -Repair open in the wire between the EGR valve and the PCM (C12), then go to step 42 .
  16. Turn the ignition switch to LOCK (0).
  17. Jump the SCS line with the HDS.
  18. Disconnect PCM connector C (49P).
  19. Check for continuity between PCM connector terminal C34 and body ground. Is there continuity? YES -Repair short in the wire between the PCM (C34) and the EGR valve, then go to step 42 . NO -Go to step 20 .
  20. Check for continuity between PCM connector terminal C34 and EGR valve 5P connector terminal No. 2. Is there continuity? YES -Go to step 21 . NO -Repair open in the wire between the PCM (C34) and the EGR valve, then go to step 42 .
  21. Turn the ignition switch to LOCK (0).
  22. Disconnect the EGR valve 5P connector.
  23. At the EGR valve side, measure the resistance between EGR valve 5P connector terminals No. 2 and No. 3. Is there 100 kohms or more? YES -Go to step 41 . NO -Go to step 24 .
  24. At the EGR valve side, measure the resistance between EGR valve 5P connector terminals No. 2 and No. 4. Is there 100 kohms or more? YES -Go to step 41 . NO -Go to step 25 .
  25. Check for continuity between PCM connector terminal C10 and body ground. Is there continuity? YES -Repair short in the wire between the PCM (C10) and the EGR valve, then go to step 42 . NO -Go to step 26 .
  26. Check for continuity between PCM connector terminal C10 and EGR valve 5P connector terminal No. 1. Is there continuity? YES -Go to step 27 . NO -Repair open in the wire between the PCM (C10) and the EGR valve, then go to step 42 .
  27. Check for continuity between EGR valve 5P connector terminal No. 5 and body ground. Is there continuity? YES -Go to step 28 . NO -Repair open in the wire between the EGR valve and G101, then go to step 42 .
  28. Reconnect PCM connector C (49P).
  29. At the EGR valve side, connect the battery positive terminal to EGR valve 5P connector terminal No. 1 with a jumper wire.
  30. Start the engine, and let it idle, then connect the battery negative terminal to EGR valve 5P connector terminal No. 5 with a jumper wire. Does the engine stall? YES -Go to step 48 . NO -Go to step 31 .
  31. Turn the ignition switch to LOCK (0).
  32. Remove the EGR valve (see «EGR VALVE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/auxiliary-emission-control-systems/#egr-system-v6) ).
  33. Clean any carbon build-up inside the EGR valve with throttle plate cleaner.
  34. Install the EGR valve (see «EGR VALVE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/auxiliary-emission-control-systems/#egr-system-v6) ).
  35. Reconnect all connectors.
  36. Turn the ignition switch to ON (II).
  37. Reset the PCM with the HDS.
  38. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#idle-control-system-v6__pcm-idle-learn-procedure) ).
  39. Do the EGR TEST in the INSPECTION MENU with the HDS. Is the result OK? YES -Go to step 47 . NO -Go to step 40 .
  40. Turn the ignition switch to LOCK (0).
  41. Replace the EGR valve (see «EGR VALVE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/auxiliary-emission-control-systems/#egr-system-v6) ).
  42. Reconnect all connectors.
  43. Turn the ignition switch to ON (II).
  44. Reset the PCM with the HDS.
  45. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#idle-control-system-v6__pcm-idle-learn-procedure) ).
  46. Do the EGR TEST in the INSPECTION MENU with the HDS.
  47. Check for Pending or Confirmed DTCs with the HDS. Is DTC P2413 indicated? YES -Check for poor connections or loose terminals at the EGR valve and the PCM, then go to step 1 . NO -Troubleshooting is complete. If any other Pending or Confirmed DTCs are indicated, go to the indicated DTC's troubleshooting.
  48. Turn the ignition switch to LOCK (0).
  49. Reconnect all connectors.
  50. Update the PCM if it does not have the latest software (see «PCM UPDATE»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#pgm-fi-system-v6__pcm-update) ), or substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#fuel-and-emissions-systems-v6__substituting-the-pcm) ).
  51. Do the EGR TEST in the INSPECTION MENU with the HDS.
  52. Check for Pending or Confirmed DTCs with the HDS. Is DTC P2413 indicated? YES -Check for poor connections or loose terminals at the EGR valve and the PCM. If the PCM was updated, substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#fuel-and-emissions-systems-v6__substituting-the-pcm) ), then go to step 51 . If the PCM was substituted, go to step 1 . NO -If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#pgm-fi-system-v6__pcm-replacement) ). If any other Pending or Confirmed DTCs are indicated, go to the indicated DTC's troubleshooting.

Scheme 19

Scheme 19: EGR Valve Replacement
Scheme 19: EGR Valve Replacement
  1. Disconnect the EGR valve 5P connector (A).
  2. Remove the EGR valve (B).
  3. Install the parts in the reverse order of removal with a new gasket (C).

Scheme 20

Scheme 20: EGR Pipe Replacement
Scheme 20: EGR Pipe Replacement

Scheme 21

Scheme 21
Scheme 21
  1. Raise the vehicle on a lift.
  2. Remove the splash shield (see «FRONT SPLASH SHIELD REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#fenderwell-v6__front-splash-shield-replacement) ).
  3. Remove the mounting nuts (A).
  4. Lower the vehicle.
  5. Remove the mounting bolts (A).
  6. Remove the EGR pipe (B).
  7. Install the parts in the reverse order of removal with new gaskets (C).
