Scheme 1
Scheme 2
Scheme 3
A/C Service Tips and Precautions
| WARNING | Compressed air mixed with the R-134a forms a combustible vapor. The vapor can burn or explode causing serious injury. Never use compressed air to pressure test R-134a service equipment or vehicle air conditioning systems. |
| CAUTION | Air conditioning refrigerant or lubricant vapor can irritate your eyes, nose, or throat. Be careful when connecting service equipment. Do not breathe refrigerant or vapor. |
The air conditioning system uses HFC-134a (R-134a) refrigerant and polyalkyleneglycol (PAG) refrigerant oil.
Use only service equipment that is U.L.-listed and is certified to meet the requirements of SAE J2788 to remove R-134a from the air conditioning system.
If accidental system discharge occurs, ventilate the work area before resuming service.
R-134a service equipment or vehicle air conditioning systems should not be pressure tested or leak tested with compressed air.
Additional health and safety information may be obtained from the refrigerant and lubricant manufacturers.
- Always disconnect the negative cable from the battery whenever replacing air conditioning parts.
- Keep moisture and dirt out of the system. When disconnecting any lines, plug or cap the fittings immediately; do not remove the caps or plugs until just before you reconnect each line.
- Before connecting any hose or line, apply a few drops of refrigerant oil to the O-ring.
- When tightening or loosening a fitting, use a second wrench to support the matching fitting.
- When discharging the system, use an R-134a refrigerant recovery/recycling/charging station; do not release refrigerant into the atmosphere.
A/C System Inspection
Note. For A/C system noise, go to the A/C SYSTEM NOISE CHECK .
Before troubleshooting any problem with the air conditioning system, other than noise, do the following
Scheme 4
Scheme 5
Scheme 6
- Check that the HVAC air intake plenum at the base of the windshield is not blocked by leaves or debris. Remove any blockage.
- Check for kinks or sharp bends in the A/C lines and hoses (which can greatly reduce system performance). If any of the A/C lines and hoses are kinked or bent, replace them (see «A/C LINE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
- Inspect the A/C components, the pressure lines, and the hoses for stains that may indicate a refrigerant or an A/C compressor oil leak. If there is any indication of leaks, do the Refrigerant Leak Check (see «REFRIGERANT LEAK CHECK»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__refrigerant-leak-check) ) to confirm the leak(s).
- Inspect the drive belt for physical damage or signs of slippage (see «DRIVE BELT INSPECTION»(/acura/tsx/ii-2008-2014/remont/charging-system/#charging-system-v6) ). If the drive belt is damaged or shows signs of slippage, replace it and recheck.
- Check the A/C condenser (A) for material clogging the fins (dirt, insects, etc.). If the A/C condenser is clogged or restricted, carefully clean any material from the A/C condenser fins with water and detergent. If deeper cleaning is required, clean the fins with HondaBrite cleaner (P/N 08732-0020B). Be sure to dry the A/C condenser completely.
- Check the A/C condenser for fin damage (bent fins). If any of the A/C condenser fins are bent, try to comb them straight. Do the Refrigerant Leak Check (see «REFRIGERANT LEAK CHECK»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__refrigerant-leak-check) ) to check for leaks if there is visible damage to the A/C condenser. If the A/C condenser is leaking or the fins cannot be straightened, replace the A/C condenser (see «A/C CONDENSER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
- Check the dust and pollen filter. If the dust and pollen filter is clogged or restricted, replace it (see «DUST AND POLLEN FILTER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
- Check for climate control DTCs using the Self-Diagnostic Function (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITH THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ). If there are any DTCs, go to the appropriate troubleshooting (see «CHECKING FOR DTCS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__checking-for-dtcs) ).
- Start the engine, turn the air conditioning system on, and allow it to run for a few minutes and reach stable operation.
- Check that the A/C operates at each position of the fan control button (except OFF). If the A/C does not operate at all fan control button positions, refer to the «SYMPTOM TROUBLESHOOTING»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__symptom-troubleshooting-index) .
- Check that the A/C compressor clutch pressure plate (A) is rotating at the same speed as the pulley and is engaging. If the A/C compressor clutch is not engaging properly, go to the «A/C COMPRESSOR CLUTCH CIRCUIT TROUBLESHOOTING»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__ac-compressor-clutch-circuit-troubleshooting) .
- Check that the A/C condenser fan (B) and the radiator fan (C) operate when the A/C compressor clutch is engaged and blow air toward the engine compartment. If one or both of the fans is networking properly, refer to the «SYMPTOM TROUBLESHOOTING»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__symptom-troubleshooting-index) .
- Check that the engine idle speed is correctly maintained when the A/C is switched on and off, (A/C compressor clutch is engaged and disengaged). If the idle speed increases more than 100 rpm when the A/C compressor engages, confirm that the A/C compressor is the cause of the idle speed increase. Replace the A/C compressor (see «A/C COMPRESSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__ac-compressor-replacement) ), if necessary.
How to Check for DTCs With the HDS
There are three methods used to check for DTCs. The recommended method is to use the Honda Diagnostic System (HDS) with the appropriate software, plugged into the data link connector (DLC).
The second method is to run the self-diagnostic function built into the climate control unit.
The third method is to use the B-CAN system diagnosis test mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A ).
Scheme 7
- Make sure the ignition switch is in LOCK (0).
- Connect the HDS to the DLC (A) located under the driver's side of the dashboard.
- Turn the ignition switch to ON (II).
- Make sure the HDS communicates with the vehicle and the climate control unit. If it does not, go to the DLC circuit troubleshooting (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#pgm-fi-system-v6__dlc-circuit-troubleshooting) ).
- Select HVAC/CLIMATE CONTROL in the BODY ELECTRICAL menu.
- Select DTCs in the HVAC/CLIMATE CONTROL menu.
- Check for DTCs. If any DTCs are indicated, write down the DTCs, then go to the «INDICATED DTC TROUBLESHOOTING»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) . If no DTCs are indicated, refer to «SYMPTOM TROUBLESHOOTING»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__symptom-troubleshooting-index) . NOTE: After troubleshooting, clear the DTCs with the HDS. For specific operations, refer to the user's manual that came with the HDS.
How to Use the Self-Diagnostic Function With the HDS
- Make sure the ignition switch is in LOCK (0).
- Connect the HDS to the DLC (A) located under the driver's side of the dashboard.
- Turn the ignition switch to ON (II).
- Make sure the HDS communicates with the vehicle and the climate control unit. If it does not, go to the DLC circuit troubleshooting (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#pgm-fi-system-v6__dlc-circuit-troubleshooting) ).
- Select HVAC/CLIMATE CONTROL in the BODY ELECTRICAL menu.
- Select INSPECTION in the HVAC/CLIMATE CONTROL menu.
- Select CLIMATE CONTROL SELF TEST in the INSPECTION menu.
- Check for DTCs. If any DTCs are indicated, write down the DTCs, then go to the «INDICATED DTC TROUBLESHOOTING»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) . NOTE: After troubleshooting, clear the DTCs with the HDS. For specific operations, refer to the user's manual that came with the HDS.
How to Use the Self-Diagnostic Function Without the HDS
The climate control unit has a self-diagnostic function. To run the self-diagnostic function, do the following
Scheme 8
- Turn the ignition switch to LOCK (0), and then to ON (II).
- Press and hold the ON/OFF button, then within 10 seconds press and release the REAR WINDOW DEFOGGER/MIRROR DEFOGGER button five times. Release the ON/OFF button, then the self-diagnosis begins. NOTE: The blower motor will run at various speeds regardless of what the panel is displaying. If there is a problem with the system, it will flash 88 and AUTO, 88 and A/C ON, or 88 AUTO and 88 A/C ON, and one or more of the 13 indicator segments (A through N). Refer to «CHECKING FOR DTCS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__checking-for-dtcs) . If there is more than one DTC, they are displayed one at a time in sequence followed by a pause (all the display indicator segments illuminate) between the DTCs. If there are no problems detected, the segments will not illuminate, and the system will appear to be turned off. Canceling the Self-Diagnostic Function
- Turn the ignition switch to LOCK (0) to cancel the self-diagnostic function. After completing repair work, run the self-diagnostic function again to make sure that there are no other DTCs.
Checking for DTCs
The temperature display indicates single or multiple DTCs. If no DTCs are present, the indicator remains blank.
Note. If the driver's indicator segments A, C, D, E, G, K, with the AUTO indicator, or the A/C ON indicator are on at the same time, there may be an open in the common ground wire.
Scheme 9
Scheme 10
Scheme 11
DTC DETECTION ITEM REFERENCE CHART
| DTC (Driver's Temperature Indicator Segment) | Detection Item |
|---|---|
| A | Climate control unit internal error (see DTC INDICATOR A: CLIMATE CONTROL UNIT INTERNAL ERROR ) |
| B | Output shaft (countershaft) speed sensor signal error. Check for DTCs in the A/T system and go to the INDICATED DTC'S TROUBLESHOOTING . If no DTCs are found, replace the climate control unit (see CLIMATE CONTROL UNIT REMOVAL/INSTALLATION ) |
| C | Engine coolant temperature (ECT) sensor signal error. Check for DTCs in the PGM-FI system and go to the INDICATED DTC'S TROUBLESHOOTING . If no DTCs are found, replace the climate control unit (see CLIMATE CONTROL UNIT REMOVAL/INSTALLATION ) |
| D | Communication bus line error (BUS-OFF) (see DTC U1280: COMMUNICATION BUS LINE ERROR (BUS-OFF) ) |
DTC DETECTION ITEM REFERENCE CHART
Displaying Sensor Inputs at the Climate Control Unit
The climate control unit has a mode that displays sensor inputs it receives. This mode shows you what the climate control unit is receiving from each of the sensors, one at a time, and it can help you determine if a sensor is faulty.
Checks Before Using the Sensor Input Display Mode
- Turn the ignition switch to ON (II), and check the recirculation door function; press the recirculation control button to switch from FRESH to RECIRC. The air volume and sound should change slightly.
- Set the climate control switch to the desired test temperature: Press the AUTO button on, the LED turns on. Press the SYNC button off, the LED turns off. When selecting the test temperature, note these items: "Lo" temperature setting will default to MAX COOL, VENT, and RECIRC. "Hi" temperature setting will default to MAX HOT, HEAT, and FRESH. 58 through 86°F (16 through 28°C) settings will use the automatic climate control logic.
- Turn the ignition switch to LOCK (0).
Run the Sensor Input Display Mode
- Turn the ignition switch to LOCK (0).
- Press and hold both the AUTO and RECIRCULATION CONTROL buttons, then start the engine.
- After the engine starts, release both buttons. The audio-navigation switch panel display (with navigation) or the audio-HVAC display (without navigation) will flash the sensor number and then the value for that sensor. Record the value displayed.
- To advance to the next sensor, press the REAR WINDOW DEFOGGER/MIRROR DEFOGGER button. NOTE: The sensor values will be displayed in degrees Celsius (°C) or an alphanumeric code. Use the chart to convert the value to degrees Fahrenheit (°F). If the sensor value displays "Er" this indicates there is an open or short in the circuit or sensor. Check for DTCs using the HDS, or refer to «CHECKING DTCS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__checking-for-dtcs) by DTC indication. If necessary, compare the sensor input display to a known-good vehicle under the same test conditions. If the sensor is out of the normal range, refer to the sensor test or substitute a known-good sensor, and recheck. ITEM DISPLAYED VALUE CHART Sensor Item Displayed Value 1 Mode positioning % 2 In-car temperature °C 3 Outside air temperature °C 4 Solar radiation sensor value: dark = 00, flashlight = 04, cloudy = 10, sunny = 65 10kcal/m 2 .h 5 Evaporator outlet air temperature °C 6 Driver's air mix opening (low value indicates cooler air distribution, higher value indicates warmer air distribution) % of opening 7 Passenger's air mix opening (low value indicates cooler air distribution, higher value indicates warmer air distribution) % of opening 8 Recirculation control opening % of opening 9 Vehicle speed (vehicle must be driven to display speed) 10 km/h A Engine coolant temperature °C b Vent temperature air out (TAO) °C CELSIUS TO FAHRENHEIT CONVERSION CHART °C °F °C °F °C °F °C °F °C °F 0 32 10 50 20 68 30 86 40 104 1 34 11 52 21 70 31 88 41 106 2 36 12 54 22 72 32 90 42 108 3 37 13 55 23 73 33 91 43 109 4 39 14 57 24 75 34 93 44 111 5 41 15 59 25 77 35 95 45 113 6 43 16 61 26 79 36 97 46 115 7 45 17 63 27 81 37 99 47 117 8 46 18 64 28 82 38 100 48 118 9 48 19 66 29 84 39 102 49 120 CELSIUS TO FAHRENHEIT CONVERSION CHART °C °F °C °F °C °F °C °F °C °F 50 122 60 140 70 158 80 176 90 194 51 124 61 142 71 160 81 178 91 196 52 126 62 144 72 162 82 180 92 198 53 127 63 145 73 163 83 181 93 199 54 128 64 147 74 165 84 183 94 201 55 131 65 149 75 167 85 185 95 203 56 133 66 151 76 169 86 187 96 205 57 135 67 152 77 170 87 188 97 , 207 58 136 68 154 78 172 88 190 98 208 59 139 69 158 79 174 89 192 99 210 ALPHANUMERIC CONVERSION CHART Display Reading (Alphanumeric) °C °F % A1 thru A9 -1 thru -9 30 thru 16 -1 thru -9 B0 thru B9 -10 thru -19 14 thru -2 -10 thru -19 C0 thru C9 -20 thru -29 -4 thru -20 -20 thru -29 D0 thru D9 -30 thru -39 -22 thru -38 -30 thru -39 E0 thru E9 -40 thru -49 -40 thru -58 -40 thru -49 F0 thru F9 -50 thru -59 -58 thru -74 + 100 thru +109 ALPHANUMERIC CONVERSION CHART Display Reading (Alphanumeric) Mode Position 0 VENT 18 HEAT/VENT-1 33 HEAT/VENT-2 50 HEAT 66 HEAT/DEF-1 80 HEAT/DEF-2 F0 DEF
- To cancel the sensor input display mode, press the AUTO button or turn the ignition switch to LOCK (0).
DTC Troubleshooting Index
| DTC | Detection Item or Symptom | ECU | DTC Type | Troubleshooting |
|---|---|---|---|---|
| U1280 | Communication bus line error (BUS-OFF) | Climate control unit | Loss of communication | DTC Troubleshooting (see ) |
| U0155 | Lost communication with gauge control module (climate control unit) | Climate control unit | Loss of communication | DTC Troubleshooting (see |
| B121A | An open in the mode control motor circuit | Climate control unit | Signal error | DTC Troubleshooting (see |
| B121B | A short in the mode control motor circuit | Climate control unit | Signal error | DTC Troubleshooting (see |
| B1220 | A short in the recirculation control motor circuit | Climate control unit | Signal error | DTC Troubleshooting (see |
| B1225 | An open in the in-car temperature sensor circuit | Climate control unit | Signal error | DTC Troubleshooting (see |
| B1226 | A short in the in-car temperature sensor circuit | Climate control unit | Signal error | DTC Troubleshooting (see |
| B1227 | An open in the outside air temperature sensor circuit | Climate control unit | Signal error | DTC Troubleshooting (see |
| B1228 | A short in the outside air temperature sensor circuit | Climate control unit | Signal error | DTC Troubleshooting (see |
| B1229 | An open in the sunlight sensor circuit | Climate control unit | Signal error | DTC Troubleshooting (see |
| B1230 | A short in the sunlight sensor circuit | Climate control unit | Signal error | DTC Troubleshooting (see |
| B1231 | An open in the evaporator temperature sensor circuit | Climate control unit | Signal error | DTC Troubleshooting (see |
| B1232 | A short in the evaporator temperature sensor circuit | Climate control unit | Signal error | DTC Troubleshooting (see |
| B1233 | An open in the air mix control motor circuit (driver's) | Climate control unit | Signal error | DTC Troubleshooting (see |
| B1234 | A short in the air mix control motor circuit (driver's) | Climate control unit | Signal error | DTC Troubleshooting (see |
| B1235 | A problem in the air mix control motor circuit, linkage, door, or motor (driver's) | Climate control unit | Signal error | DTC Troubleshooting (see |
| B1236 | An open in the passenger's air mix control motor circuit | Climate control unit | Signal error | DTC Troubleshooting (see |
| B1237 | A short in the passenger's air mix control motor circuit | Climate control unit | Signal error | DTC Troubleshooting. (see |
| B1238 | A problem in the passenger's air mix control motor circuit, linkage, door, or motor | Climate control unit | Signal error | DTC Troubleshooting (see |
| B1240 | A problem in the mode control motor circuit, linkage, door, or motor | Climate control unit | Signal error | DTC Troubleshooting (see |
| B1241 | A problem in the blower motor circuit | Climate control unit | Signal error | DTC Troubleshooting (see |
| B2983 | A problem in the recirculation control motor circuit, linkage, door, or motor | Climate control unit | Signal error | DTC Troubleshooting (see |
| B2986 | An open in the recirculation control motor circuit | Climate control unit | Signal error | DTC Troubleshooting (see |
DTC TROUBLESHOOTING INDEX
Symptom Troubleshooting Index
| Symptom | Diagnostic Procedure | Also Check for |
|---|---|---|
| The blower and heater controls and the A/C system do not work | Probable cause: Climate control unit malfunction. Do the climate control power and ground circuit troubleshooting (see CLIMATE CONTROL POWER AND GROUND CIRCUIT TROUBLESHOOTING ) | Climate control DTCs (see HOW TO CHECK FOR DTCS WITH THE HDS ) Blown fuse No. 16 (7.5 A) in the driver's under-dash fuse/relay box Poor ground at G401; with navigation (see AUDIO WIRE HARNESS (WITH NAVIGATION) ), without navigation (see AUDIO WIRE HARNESS (WITHOUT NAVIGATION) ) Poor or loose connections at the terminals |
| The A/C compressor clutch and the A/C condenser/radiator fans are inoperative, but the blower and heater controls work | Probable cause: A/C pressure sensor circuit malfunction. Do the A/C pressure sensor troubleshooting: A/C pressure sensor circuit low voltage (see DTC P0532: A/C PRESSURE SENSOR CIRCUIT LOW VOLTAGE ), A/C pressure sensor circuit high voltage (see DTC P0533: A/C PRESSURE SENSOR CIRCUIT HIGH VOLTAGE ) NOTE: The A/C pressure sensor can malfunction without setting a DTC | B-CAN U-codes, loss of communication Climate control DTCs (see HOW TO CHECK FOR DTCS WITH THE HDS ) Powertrain DTCs Poor or loose connections at the terminals |
| The A/C compressor clutch does not engage, but the A/C condenser/radiator fans operate, and the blower and heater controls work | Probable cause: No power to the A/C compressor clutch. Do the A/C compressor clutch circuit troubleshooting (see A/C COMPRESSOR CLUTCH CIRCUIT TROUBLESHOOTING ) | Climate control DTCs (see HOW TO CHECK FOR DTCS WITH THE HDS ) Blown fuse No. 20 (7.5 A) in the under-hood fuse/relay box A/C system pressure is normal (see A/C SYSTEM TEST ) Poor or loose connections at the terminals ECT Engine overheating |
| The A/C condenser/radiator fans do not run at low speed with the A/C on, but the blower and heater controls work normally | Probable cause: A/C condenser/radiator fan low speed circuit malfunction. Do the radiator and A/C condenser fan low speed circuit troubleshooting (see RADIATOR AND A/C CONDENSER FAN LOW SPEED CIRCUIT TROUBLESHOOTING ) Probable cause: A/C pressure sensor circuit malfunction. Do the A/C pressure sensor troubleshooting: A/C pressure sensor circuit low voltage (see DTC P0532: A/C PRESSURE SENSOR CIRCUIT LOW VOLTAGE ), A/C pressure sensor circuit high voltage (see DTC P0533: A/C PRESSURE SENSOR CIRCUIT HIGH VOLTAGE ) NOTE: The A/C pressure sensor can malfunction without setting a DTC | Climate control DTCs (see HOW TO CHECK FOR DTCS WITH THE HDS ) Powertrain DTCs Blown fuse No. 3-8 (SUB FAN MTR) (30 A) in the under-hood fuse/relay box Poor ground at G301 (see LEFT ENGINE COMPARTMENT WIRE HARNESS (ENGINE COMPARTMENT BRANCH) ) Poor or loose connections at the terminals |
| NOTE |
|---|
| The A/C pressure sensor can malfunction without setting a DTC |
| NOTE |
|---|
| The A/C pressure sensor can malfunction without setting a DTC |
SYMPTOM TROUBLESHOOTING INDEX
| Symptom | Diagnostic Procedure | Also Check for |
|---|---|---|
| The A/C condenser/radiator fans do not run at high speed, but do run at low speed | Probable cause: Malfunction in the fan(s) high speed circuit. Do the following troubleshooting as needed: A/C condenser fan high speed circuit troubleshooting (see A/C CONDENSER FAN HIGH SPEED CIRCUIT TROUBLESHOOTING ) Radiator fan high speed circuit troubleshooting (see RADIATOR FAN HIGH SPEED CIRCUIT TROUBLESHOOTING ) Probable cause: A/C pressure sensor circuit malfunction. Do the A/C pressure sensor troubleshooting: A/C pressure sensor circuit low voltage (see DTC P0532: A/C PRESSURE SENSOR CIRCUIT LOW VOLTAGE ), A/C pressure sensor circuit high voltage (see DTC P0533: A/C PRESSURE SENSOR CIRCUIT HIGH VOLTAGE ) NOTE: The A/C pressure sensor can malfunction without setting a DTC | Climate control DTCs (see HOW TO CHECK FOR DTCS WITH THE HDS ) Powertrain DTCs Blown fuse No. 3-6 (MAIN FAN MTR) (30 A) in the under-hood fuse/relay box Blown fuse No. 21 (7.5 A) in the under-hood fuse/relay box Poor ground at G301 (see LEFT ENGINE COMPARTMENT WIRE HARNESS (ENGINE COMPARTMENT BRANCH) ) Poor or loose connections at the terminals |
| Voice commands do not work (with navigation) | Probable cause: Communication problem between the climate control unit and the navigation system. Do the navigation communication line circuit troubleshooting (see NAVIGATION COMMUNICATION LINE CIRCUIT TROUBLESHOOTING ) | Climate control DTCs (see HOW TO CHECK FOR DTCS WITH THE HDS ) Navigation System Links (see SYSTEM LINKS ) Poor or loose connections at the terminals |
| The climate control display is inoperative | Probable cause: Communication problem between the climate control unit and the audio-navigation switch panel (with navigation) or the audio-HVAC display unit (with navigation). Do the audio communication line circuit troubleshooting; with navigation system (see WITH NAVIGATION ), without navigation system (see WITHOUT NAVIGATION ) | Climate control DTCs (see HOW TO CHECK FOR DTCS WITH THE HDS ) Audio-navigation switch panel or audio-HVAC display failure Poor or loose connections at the terminals |
| Blower fan runs slower than expected in cold weather (when in AUTO mode) | Probable cause: Engine coolant temperature (ECT) circuit malfunction. Troubleshoot ECT 2 circuit: ECT sensor 2 circuit low voltage (see DTC P2184: ECT SENSOR 2 CIRCUIT LOW VOLTAGE ) ECT sensor 2 circuit high voltage (see DTC P2185: ECT SENSOR 2 CIRCUIT HIGH VOLTAGE ) | Climate control DTCs (see HOW TO CHECK FOR DTCS WITH THE HDS ) Powertrain DTCs Blower motor operation |
| The A/C compressor clutch cycles rapidly on and off | Probable cause: The A/C system is very low on refrigerant, indicating a possible leak. Do the refrigerant leak check (see REFRIGERANT LEAK CHECK ) and repair any leaks. Replace the receiver/dryer (see RECEIVER/DRYER DESICCANT REPLACEMENT ), then recharge the system to specifications (see SYSTEM CHARGING ) | Climate control DTCs (see HOW TO CHECK FOR DTCS WITH THE HDS ) If there is no leak and the refrigerant level is normal, do the A/C compressor clutch circuit troubleshooting (see A/C COMPRESSOR CLUTCH CIRCUIT TROUBLESHOOTING ), and look for an intermittent problem |
| NOTE |
|---|
| The A/C pressure sensor can malfunction without setting a DTC |
SYMPTOM TROUBLESHOOTING INDEX
| Symptom | Diagnostic Procedure | Also Check for |
|---|---|---|
| Driver's and passenger's side vent temperatures vary by more than 20°F (11°C) | Probable causes: The recirculation control door or the air mix doors are malfunctioning. Do the following troubleshooting: Recirculation control motor test (see RECIRCULATION CONTROL MOTOR TEST ) Driver's air mix control motor test (see DRIVER'S AIR MIX CONTROL MOTOR TEST ) Passenger's air mix control motor test (see PASSENGER'S AIR MIX CONTROL MOTOR TEST ) | Climate control DTCs (see HOW TO CHECK FOR DTCS WITH THE HDS ) Poor or loose connections at the terminals |
| HDS does not communicate with the climate control unit or the vehicle | Troubleshoot the DLC circuit (see DLC CIRCUIT TROUBLESHOOTING ) | |
| Insufficient heating | Check the coolant level (see COOLANT CHECK ) Check the radiator cap (see RADIATOR CAP TEST ) Check the coolant temperature during normal operation Check the heater core inlet hose temperature: If it is COLD, check for restrictions in the hose, a damaged or leaking thermostat, or a damaged or leaking water pump If it is HOT, check for restrictions in the heater core. Back flush or replace the heater core Do the driver's air mix control motor test (see DRIVER'S AIR MIX CONTROL MOTOR TEST ) and passenger's air mix control motor test (see PASSENGER'S AIR MIX CONTROL MOTOR TEST ) Check the blower motor unit for obstructions Check for air leaks around the ducts and vents | Climate control DTCs (see HOW TO CHECK FOR DTCS WITH THE HDS ) Damaged cylinder head gasket |
SYMPTOM TROUBLESHOOTING INDEX
System Description
The air conditioning (A/C) system removes heat from the passenger compartment by transferring heat from the ambient air to the evaporator. The A/C refrigerant expands in the evaporator, and the evaporator becomes very cold and absorbs the heat from the ambient air. The blower fan pushes air across the evaporator where the heat is absorbed, and then it blows the cool air into the passenger compartment.
Scheme 12
This vehicle uses HFC-134a (R-134a) refrigerant, which does not contain chlorofluorocarbons. Pay attention to the following service items
- Use only the recommended polyalkyleneglycol (PAG) refrigerant oil (DENSO ND-OIL 8) designed for the R-134a A/C compressor. Intermixing the recommended (PAG) refrigerant oil with any other refrigerant oil will result in A/C compressor failure.
- All A/C system parts (A/C compressor, discharge line, suction line, evaporator, A/C condenser, receiver/dryer, expansion valve, O-rings for joints) are designed for refrigerant R-134a.
- Use a halogen gas leak detector designed for refrigerant R-134a.
- Use only a recovery/recycling/charging station that is U.L.-listed and is certified to meet the requirements of SAE J2788 to service the R-134a air conditioning systems.
- Always recover refrigerant R-134a with an approved recovery/recycling/charging station before disconnecting any A/C fitting.
A/C Pressure Sensor
The A/C pressure sensor converts A/C pressure into electrical signals to the PCM.
| A/C System Pressure | Sensor Output Voltage (V out) | System Operation |
|---|---|---|
| Abnormally low pressure: Below 196 kPa (2.0 kgf/cm 2 , 28 psi) | Below 0.684 V | The PCM disengages the A/C compressor clutch. The radiator and A/C condenser fans operate based on engine coolant temperature. |
| Normal operating pressure: Above 196 kPa (2.0 kgf/cm 2 , 28 psi) Below 1,470 kPa (15.0 kgf/cm 2 , 213 psi) | 0.686 V to 1.944 V | The PCM cycles the A/C compressor clutch based on cooling demand. The radiator and A/C condenser fans operate at low speed unless the engine coolant temperature exceeds 206°F (97°C). |
| High operating pressure: Above 1,470 kPa (15.0 kgf/cm 2 , 213 psi) Below 3,138 kPa (32 kgf/cm 2 , 455 psi) | 1.945 V to 4.575 V | The PCM cycles the A/C compressor clutch based on cooling demand. The radiator and A/C condenser fans operate at high speed. |
| Abnormally high pressure: More than 3,138 kPa (32 kgf/cm 2 , 455 psi) | Above 4.575 V | The PCM disengages the A/C compressor clutch. The radiator and A/C condenser fans operate based on engine coolant temperature. |
TERMINAL VOLTAGE REFERENCE
The response of the A/C pressure sensor is shown in the graph.
Note. When the refrigerant is below 196 kPa (2.0 kgf/cm 2 , 28 psi) or above 3,138 kPa (32 kgf/cm 2 , 455 psi), the PCM turns the A/C compressor clutch relay off to protect the A/C compressor. When the refrigerant pressure is above 1,470 kPa (15.0 kgf/cm 2 , 213 psi), the PCM switches the radiator and A/C condenser fans to high speed.
Scheme 13
Scheme 14
Scheme 15
Scheme 16
i-Dual Climate Control System
This system automatically controls the temperature and the vent mode of the air direction to the driver and passenger's side depending on the angle of the sun and the direction of the vehicle. It calculates information such as date, time, longitude, and latitude from the navigation system, as well as the radiant strength of the sun from the sunlight sensor, to determine the appropriate mode position and temperature to be directed to each side.
Scheme 17
In the event that the navigation system malfunctions, or when driving in areas where the navigation cannot determine the vehicle position (non-coverage areas, tunnels, etc.), the climate control system will operate the same as a vehicle without navigation.
Scheme 18
| Cavity | Wire color | Terminal name | Description | Signal |
|---|---|---|---|---|
| 1 | LT GRN | M-HOT-As | Drives passenger's air mix control motor HOT side | With ignition switch ON (II) and passenger's air mix control motor moving to HOT: battery voltage |
| 2 | LT BLU | M-COOL- As | Drives passenger's air mix control motor COOL side | With ignition switch ON (II) and passenger's air mix control motor moving to COOL: battery voltage |
| 3 | PUR | M-FRS | Drives recirculation control motor FRESH side | With ignition switch ON (II) and recirculation control motor moving to FRESH: battery voltage |
| 4 | LT BLU | M-COOL-Dr | Drives driver's air mix control motor COOL side | With ignition switch ON (II) and driver's air mix control motor moving to COOL: battery voltage |
| 5 | ORN | M-REC | Drives recirculation control motor RECIRCULATE side | With ignition switch ON (II) and recirculation control motor moving to RECIRCU: battery voltage |
| 6 | PNK | M-HOT-Dr | Drives driver's air mix control motor HOT side | With ignition switch ON (II) and driver's air mix control motor moving to HOT: battery voltage |
| 7 | WHT | M-VENT | Outputs mode control motor VENT side | With ignition switch ON (II) and mode control motor moving to VENT: battery voltage |
| 8 | GRN | M-DEF | Outputs mode control motor DEF side | With ignition switch ON (II) and mode control motor moving to DEF: battery voltage |
| 9 | LT GRN | IG2 | IG2 power source | With ignition switch ON (II): battery voltage |
| 11 | RED | MDD-P | Outputs mode control motor potentiometer signal | With ignition switch ON (II): about 0.5-4.5 V (depending on mode control motor position) |
| 12 | YEL | RFD-P | Outputs recirculation control motor potentiometer signal | With ignition switch ON (II): about 1.0-4.0 V (depending on recirculation control motor position) |
| 13 | YEL | AMD-P-As | Outputs passenger's air mix control motor potentiometer signal | With ignition switch ON (II): about 1.5-4.5 V (depending on passenger's air mix control motor position) |
| 14 | GRY | AMD-P-Dr | Outputs driver's air mix control motor potentiometer signal | With ignition switch ON (II): about 0.5-4.5 V (depending on driver's air mix control motor position) |
| 15 | RED | ILL-(LED) | Detects illumination control signal | With illumination switch ON: changed voltage (depending on dashlights brightness controller) |
| 16 | RED | ILL-(BULB) | Detects illumination control signal | With illumination switch ON: changed voltage (depending on dashlights brightness controller) |
| 18 | GRY | ILL+ | Inputs voltage for illumination | With combination light switch ON: battery voltage |
| 19 | RED | DISP-CLK | Communication signal from audio-navigation switch panel (1) or audio-HVAC display unit (2) | With ignition switch ON (II): pulses |
| 20 | PUR | DISP-SI | Communication signal to audio-navigation switch panel (1) or audio-HVAC display unit (2) potentiometer signal | With ignition switch ON (II): pulses |
| 21 | GRN | ACS | Outputs A/C on/off signal | With ignition switch ON (II), normal A/C pressure, and A/C switch ON: less than 0.2 V With ignition switch ON (II), normal A/C pressure, and A/C switch OFF: battery voltage |
| 23 | BRN | Teva | Detects evaporator temperature sensor signal | With ignition switch ON (II): about 1.0-4.0 V (depending on evaporator temperature) |
| 24 | BLU | Tarn | Detects outside air temperature sensor signal | With ignition switch ON (II): about 1.0-4.0 V (depending on out side air temperature) |
| 25 | PUR | Tsun | Detects sunlight sensor signal | With ignition switch ON (II) and sensor out of direct sunlight: 3.6-3.7 V or more With ignition switch ON (II) and sensor in direct sunlight: 3.3-3.5 V or less |
| 26 | WHT | Tr | Detects in-car temperature sensor signal | With ignition switch ON (II): about 1.0-4.0 V (depending on in-car temperature) |
| (1) With navigation (2) Without navigation | ||||
| (1) | With navigation |
| (2) | Without navigation |
CLIMATE CONTROL UNIT CONNECTOR A (28P) TERMINAL REFERENCE
Scheme 19
| Cavity | Wire color | Terminal name | Description | Signal |
|---|---|---|---|---|
| 1 | PNK | B-CAN H | B-CAN communication signal | With ignition switch ON (II): pulses |
| 2 | BLU | B-CAN L | B-CAN communication signal | With ignition switch ON (II): pulses |
| 3 | BLK | GND | Ground for climate control unit (G401) | Less than 0.2 V at all times |
| 5 | YEL | BLW-G | Outputs power transistor gate voltage | With ignition switch ON (II) and fan control button OFF: less than 0.2 V With ignition switch ON (II) and fan control button ON: about 4.0 V-battery voltage (depending on blower motor control) |
| 6 | BLU | BLW-V | Feedback signal of power transistor drain voltage | With ignition switch ON (II): about 0 V-battery voltage (depending on blower motor speed) |
| 7 (1) | PUR | NAVI-SO | Communication signal from Audio-navigation unit | With ignition switch ON (II): pulses |
| 8 (1) | ORN | NAVI-SI | Communication signal to Audio-navigation unit | With ignition switch ON (II): pulses |
| 9 (1) | BRN | NAVI-CLK | Communication signal from Audio-navigation unit | With ignition switch ON (II): pulses |
| 10 | RED | SENS-COM | Sensor ground | Less than 0.2 V at all times |
| 12 | BLK | S5V | Outputs sensor 5V | With ignition switch ON (II): about 5.0 V |
| (1) With navigation | ||||
| (1) | With navigation |
CLIMATE CONTROL UNIT CONNECTOR B (12P) TERMINAL REFERENCE
Scheme 20
Scheme 21
DTC indicator A: Climate Control Unit Internal Error
Note. Check the battery condition (see BATTERY TEST ) and the charging system (see ALTERNATOR AND REGULATOR CIRCUIT TROUBLESHOOTING ).
- Turn the ignition switch to LOCK (0), and then to ON (II).
- Do the Self-Diagnostic Function with the climate control unit (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITHOUT THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ).
- Check for DTCs. Is DTC A indicated? YES -The climate control unit is faulty; replace the climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ). NO -Intermittent failure; the climate control unit is OK at this time. Check for poor connections at the climate control unit and at G401; with navigation (see «AUDIO WIRE HARNESS (WITH NAVIGATION)»(/acura/tsx/ii-2008-2014/remont/body-electrical/#connectors-and-harnesses-v6__audio-wire-harness-with-navigation) ), without navigation (see «AUDIO WIRE HARNESS (WITHOUT NAVIGATION)»(/acura/tsx/ii-2008-2014/remont/body-electrical/#connectors-and-harnesses-v6__audio-wire-harness-without-navigation) ).
DTC U0155: Lost Communication with Gauge Control Module (Climate Control Unit)
Note. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN system diagnosis test mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A ).
Scheme 22
- Clear the DTC with the HDS.
- Turn the ignition switch to LOCK (0), and then to ON (II).
- Do the Self-Diagnostic Function with the HDS (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITH THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ).
- Check for DTCs. Is DTC U0155 indicated? YES -Go to step 5 . NO -The system is OK at this time. Check for loose wires or poor connections on the gauge control module and climate control unit circuit.
- Select B-CAN Control Units Information in the BODY ELECTRICAL menu.
- Select Check Connected Control Units in the B-CAN Control Units Information menu. Is the gauge control module detected? YES -Substitute a known-good climate control unit, and recheck. If the symptom/indication goes away, replace the original climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ). NO -Go to step 7 .
- Disconnect the gauge control module 32P connector.
- Disconnect climate control unit connector B (12P).
- Check for continuity between the following terminals of the gauge control module 32P connector, and climate control unit connector B (12P). 32P: 12P: No. 23 No. 2 No. 24 No. 1 Is there continuity? YES -Go to the gauge control module input test (see «GAUGE CONTROL MODULE INPUT TEST»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#gauges-v6__gauge-control-module-input-test) ). NO -Repair an open in the wire between the climate control unit and the gauge control module.
Scheme 23
Scheme 24
- Clear the DTC with the HDS.
- Turn the ignition switch to LOCK (0), and then to ON (II).
- Do the Self-Diagnostic Function with the HDS (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITH THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ) or the climate control unit (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITHOUT THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ).
- Check for DTCs. Is DTC B121A or G and A/C ON indicated? YES -Go to step 5 . NO -Intermittent failure. Check for loose wires or poor connections on the mode control motor circuit.
- Turn the ignition switch to LOCK (0).
- Test the mode control motor (see «MODE CONTROL MOTOR TEST»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__mode-control-motor-test) ). Is the mode control motor OK? YES -Go to step 7 . NO -Replace the mode control motor (see «MODE CONTROL MOTOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
- Disconnect the mode control motor 7P connector.
- Disconnect climate control unit connectors A (28P) and B (12P).
- Check for continuity between the following terminals of climate control unit connectors A (28P), B (12P), and the mode control motor 7P connector. 28P: 7P: No. 11 No. 3 12P: 7P: No. 10 No. 7 No. 12 No. 5 Is there continuity? YES -Check for loose wires or poor connections at climate control unit connectors A (28P), B (12P), and at the mode control motor 7P connector. If the connections are good, substitute a known-good climate control unit, and recheck. If the symptom/indication goes away, replace the original climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ). NO -Repair an open in the wire(s) between the climate control unit and the mode control motor.
Scheme 25
Scheme 26
Scheme 27
Scheme 28
Scheme 29
Scheme 30
Scheme 31
- Clear the DTC with the HDS.
- Turn the ignition switch to LOCK (0), and then to ON (II).
- Do the Self-Diagnostic Function with the HDS (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITH THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ) or the climate control unit (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITHOUT THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ).
- Check for DTCs. Is DTC B121B or H and A/C ON indicated? YES -Go to step 5 . NO -Intermittent failure. Check for loose wires or poor connection on the mode control motor circuit.
- Check for DTCs. Are these DTCs also present; B1220 or L and A/C ON, and/or B1234 or B and A/C ON, and/or B1237 or E and A/CON? YES -Go to step 13 . NO -Go to step 6 .
- Turn the ignition switch to LOCK (0).
- Test the mode control motor (see «MODE CONTROL MOTOR TEST»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__mode-control-motor-test) ). Is the mode control motor OK? YES -Go to step 8 . NO -Replace the mode control motor (see «MODE CONTROL MOTOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) )
- Disconnect the mode control motor 7P connector.
- Disconnect climate control unit connectors A (28P) and B (12P).
- Check for continuity between climate control unit connector A (28P) terminal No. 11 and body ground. Is there continuity? YES -Repair a short to body ground in the wire between the climate control unit and the mode control motor. NO -Go to step 11 .
- Check for continuity between climate control unit connector A (28P) terminal No. 11 and climate control unit connector B (12P) terminal No. 12. Is there continuity? YES -Repair a short in the wires. NO -Go to step 12 .
- Turn the ignition switch to ON (II), and measure the voltage between climate control unit connector A (28P) terminal No. 11 and body ground. Is there any voltage? YES -Repair a short to power in the wire between the climate control unit and the mode control motor. This short may also damage the climate control unit. Repair a short to power before replacing the climate control unit. NO -Substitute a known-good climate control unit, and recheck. If the symptom/indication goes away, replace the original climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
- Turn the ignition switch to LOCK (0), and disconnect climate control unit connector B (12P).
- Disconnect these items: Driver's air mix control motor Passenger's air mix control motor Recirculation control motor Mode control motor
- Check for continuity between climate control unit connector B (12P) terminal No. 12 and body ground. Is there continuity? YES -Repair a short to body ground in the wire. NO -Go to step 16 .
- Turn the ignition switch to ON (II), and measure the voltage between the same terminal and body ground. Is there any voltage? YES -Repair a short to power in the wire. This short may have also damaged the climate control unit. Repair short to power before replacing the climate control unit. NO -Go to step 17 .
- Turn the ignition switch to LOCK (0).
- Reconnect climate control unit connector B (12P).
- Turn the ignition switch to ON (II), and measure the voltage between climate control unit connector B (12P) terminal No. 12 and body ground. Is there about 5 V? YES -Go to step 20 . NO -Check for a loose wire or poor connection at climate control unit connector B (12P). If the connection is good, substitute a known-good climate control unit, and recheck. If the symptom/indication goes away, replace the original climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
- While measuring the voltage between the same terminal and body ground, reconnect these items individually and note the voltage reading each time: Driver's air mix control motor Passenger's air mix control motor Recirculation control motor Mode control motor Does the voltage remain at about 5 V? YES -Substitute a known-good climate control unit, and recheck. If the symptom/indication goes away, replace the original climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ). NO -Replace the component that caused the voltage drop.
Scheme 32
Scheme 33
Scheme 34
Scheme 35
Scheme 36
Scheme 37
Scheme 38
- Clear the DTC with the HDS.
- Turn the ignition switch to LOCK (0), and then to ON (II).
- Do the Self-Diagnostic Function with the HDS (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITH THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ) or the climate control unit (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITHOUT THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ).
- Check for DTCs. Is DTC B1220 or L and A/C ON indicated? YES -Go to step 5 . NO -Intermittent failure. Check for loose wires or poor connection on the recirculation control motor circuit.
- Check for DTCs. Are these DTCs also present; B121B or H and A/C ON, and/or B1234 or B and A/C ON, and/or B1237 or E and A/C ON? YES -Go to step 13 . NO -Go to step 6 .
- Turn the ignition switch to LOCK (0).
- Test the recirculation control motor (see «RECIRCULATION CONTROL MOTOR TEST»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__recirculation-control-motor-test) ). Is the recirculation control motor OK? YES -Go to step 8 . NO -Replace the recirculation control motor (see «RECIRCULATION CONTROL MOTOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
- Disconnect the recirculation control motor 7P connector.
- Disconnect climate control unit connectors A (28P) and B (12P).
- Check for continuity between climate control unit connector A (28P) terminal No. 12 and body ground. Is there continuity? YES -Repair a short to body ground in the wire between the climate control unit and the recirculation control motor. NO -Go to step 11 .
- Check for continuity between climate control unit connector A (28P) terminal No. 12 and climate control unit connector B (12P) terminal No. 12. Is there continuity? YES -Repair a short in the wires. NO -Go to step 12 .
- Turn the ignition switch to ON (II), and measure the voltage between climate control unit connector A (28P) terminal No. 12 and body ground. Is there any voltage? YES -Repair a short to power in the wire between the climate control unit and the recirculation control motor. This short may also damage the climate control unit. Repair a short to power before replacing the climate control unit. NO -Substitute a known-good climate control unit, and recheck. If the symptom/indication goes away, replace the original climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
- Turn the ignition switch to LOCK (0), and disconnect climate control unit connector B (12P).
- Disconnect these items: Driver's air mix control motor Passenger's air mix control motor Recirculation control motor Mode control motor
- Check for continuity between climate control unit connector B (12P) terminal No. 12 and body ground. Is there continuity? YES -Repair a short to body ground in the wire. NO -Go to step 16 .
- Turn the ignition switch to ON (II), and measure the voltage between the same terminal and body ground. Is there any voltage? YES -Repair a short to power in the wire. This short may have also damaged the climate control unit. Repair a short to power before replacing the climate control unit. NO -Go to step 17 .
- Turn the ignition switch to LOCK (0).
- Reconnect climate control unit connector B (12P).
- Turn the ignition switch to ON (II), and measure the voltage between climate control unit connector B (12P) terminal No. 12 and body ground. Is there about 5 V? YES -Go to step 20 . NO -Check for a loose wire or poor connection at climate control unit connector B (12P). If the connection is good, substitute a known-good climate control unit, and recheck. If the symptom/indication goes away, replace the original climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
- While measuring the voltage between the same terminal and body ground, reconnect these items individually and note the voltage reading each time: Driver's air mix control motor Passenger's air mix control motor Recirculation control motor Mode control motor Does the voltage remain at about 5 V? YES -Substitute a known-good climate control unit, and recheck. If the symptom/indication goes away, replace the original climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ). NO -Replace the component that caused the voltage drop.
Scheme 39
Scheme 40
- Clear the DTC with the HDS.
- Turn the ignition switch to LOCK (0), and then to ON (II).
- Do the Self-Diagnostic Function with the HDS (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITH THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ) or the climate control unit (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITHOUT THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ).
- Check for DTCs. Is DTC B1225 or A and AUTO indicated? YES -Go to step 5 . NO -Intermittent failure. Check for loose wires or poor connections on the in-car temperature sensor circuit.
- Turn the ignition switch to LOCK (0).
- Remove the in-Car temperature sensor (see «IN-CAR TEMPERATURE SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ), and test it (see «IN-CAR TEMPERATURE SENSOR TEST»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__in-car-temperature-sensor-test) ). Is the in-car temperature sensor OK? YES -With the in-car temperature sensor disconnected, go to step 7 . NO -Replace the in-car temperature sensor (see «IN-CAR TEMPERATURE SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
- Disconnect climate control unit connectors A (28P) and B (12P).
- Check for continuity between climate control unit connector A (28P) terminal No. 26 and in-car temperature sensor 2P connector terminal No. 1. Is there continuity? YES -Go to step 9 . NO -Repair an open in the wire between the climate control unit and the in-car temperature sensor.
- Check for continuity between climate control unit connector B (12P) terminal No. 10 and in-car temperature sensor 2P connector terminal No. 2. Is there continuity? YES -Check for loose wires or poor connections at climate control unit connectors A (28P), B (12P), and at the in-car temperature sensor 2P connector. If the connections are good, substitute a known-good climate control unit, and recheck. If the symptom/indication goes away, replace the original climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ). NO -Repair an open in the wire between the climate control unit and the in-car temperature sensor.
Scheme 41
Scheme 42
- Clear the DTC with the HDS.
- Turn the ignition switch to LOCK (0), and then to ON (II).
- Do the Self-Diagnostic Function with the HDS (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITH THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ) or the climate control unit (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITHOUT THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ).
- Check for DTCs. Is DTC B1226 or B and AUTO indicated? YES -Go to step 5 . NO -Intermittent failure. Check for loose wires or poor connection on the in-car temperature sensor circuit.
- Turn the ignition switch to LOCK (0).
- Remove the in-car temperature sensor (see «IN-CAR TEMPERATURE SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ), and test it (see «IN-CAR TEMPERATURE SENSOR TEST»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__in-car-temperature-sensor-test) ). Is the in-car temperature sensor OK? YES -With the in-car temperature sensor disconnected, go to step 7 . NO -Replace the in-car temperature sensor (see «IN-CAR TEMPERATURE SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
- Disconnect climate control unit connectors A (28P) and B (12P).
- Check for continuity between climate control unit connector A (28P) terminal No. 26 and body ground. Is there continuity? YES -Repair a short to body ground in the wire between the climate control unit and the in-car temperature sensor. NO -Go to step 9 .
- Check for continuity between climate control unit connector A (28P) terminal No. 26 and climate control unit connector B (12P) terminal No. 10. Is there continuity? YES -Repair a short in the wires between the climate control unit and the in-car temperature sensor. NO -Substitute a known-good climate control unit, and recheck. If the symptom/indication goes away, replace the original climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
Scheme 43
Scheme 44
- Clear the DTC with the HDS.
- Turn the ignition switch to LOCK (0), and then to ON (II).
- Do the Self-Diagnostic Function with the HDS (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITH THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ) or the climate control unit (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITHOUT THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ).
- Check for DTCs. Is DTC B1227 or C and AUTO indicated? YES -Go to step 5 . NO -Intermittent failure. Check for loose wires or poor connections on the outside air temperature sensor circuit.
- Turn the ignition switch to LOCK (0).
- Remove the outside air temperature sensor (see «OUTSIDE AIR TEMPERATURE SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ), and test it (see «OUTSIDE AIR TEMPERATURE SENSOR TEST»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__outside-air-temperature-sensor-test) ). Is the outside air temperature sensor OK? YES -With the outside air temperature sensor disconnected, go to step 7 . NO -Replace the outside air temperature sensor (see «OUTSIDE AIR TEMPERATURE SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
- Disconnect climate control unit connectors A (28P) and B (12P).
- Check for continuity between climate control unit connector A (28P) terminal No. 24 and outside air temperature sensor 2P connector terminal No. 1. Is there continuity? YES -Go to step 9 . NO -Repair an open in the wire between the climate control unit and the outside air temperature sensor.
- Check for continuity between climate control unit connector B (12P) terminal No. 10 and outside air temperature sensor 2P connector terminal No. 2. Is there continuity? YES -Check for loose wires or poor connections at climate control unit connectors A (28P), B (12P), and at the outside air temperature sensor 2P connector. If the connections are good, substitute a known-good climate control unit, and recheck. If the symptom/indication goes away, replace the original climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ). NO -Repair an open in the wire between the climate control unit and the outside air temperature sensor.
Scheme 45
Scheme 46
- Clear the DTC with the HDS.
- Turn the ignition switch to LOCK (0), and then to ON (II).
- Do the Self-Diagnostic Function with the HDS (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITH THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ) or the climate control unit (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITHOUT THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ).
- Check for DTCs. Is DTC B1228 or D and AUTO indicated? YES -Go to step 5 . NO -Intermittent failure. Check for loose wires or poor connection on the outside air temperature sensor circuit.
- Turn the ignition switch to LOCK (0).
- Remove the outside air temperature sensor (see «OUTSIDE AIR TEMPERATURE SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ), and test it (see «OUTSIDE AIR TEMPERATURE SENSOR TEST»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__outside-air-temperature-sensor-test) ). Is the outside air temperature sensor OK? YES -With the outside air temperature sensor disconnected, go to step 7 . NO -Replace the outside air temperature sensor (see «OUTSIDE AIR TEMPERATURE SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
- Disconnect climate control unit connectors A (28P) and B (12P).
- Check for continuity between climate control unit connector A (28P) terminal No. 24 and body ground. Is there continuity? YES -Repair a short to body ground in the wire between the climate control unit and the outside air temperature sensor. NO -Go to step 9 .
- Check for continuity between climate control unit connector A (28P) terminal No. 24 and climate control unit connector B (12P) terminal No. 10. Is there continuity? YES -Repair a short in the wires between the climate control unit and the outside air temperature sensor. NO -Substitute a known-good climate control unit, and recheck. If the symptom/indication goes away, replace the original climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
Scheme 47
Scheme 48
- Clear the DTC with the HDS.
- Turn the ignition switch to LOCK (0), and then to ON (II).
- Do the Self-Diagnostic Function with the HDS (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITH THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ) or the climate control unit (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITHOUT THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ).
- Check for DTCs. Is DTC B1229 or E and AUTO indicated? YES -Go to step 5 . NO -Intermittent failure. Check for loose wires or poor connections on the sunlight sensor circuit.
- Turn the ignition switch to LOCK (0).
- Disconnect the sunlight sensor 5P connector.
- Disconnect climate control unit connectors A (28P) and B (12P).
- Check for continuity between climate control unit connector A (28P) terminal No. 25 and sunlight sensor 5P connector terminal No. 4. Is there continuity? YES -Go to step 9 . NO -Repair an open in the wire between the climate control unit and the sunlight sensor.
- Check for continuity between climate control unit connector B (12P) terminal No. 10 and sunlight sensor 5P connector terminal No. 2. Is there continuity? YES -Go to step 10 . NO -Repair an open in the wire between the climate control unit and the sunlight sensor.
- Reconnect the sunlight sensor 5P connector.
- Reconnect climate control unit connectors A (28P) and B (12P).
- Test the sunlight sensor (see «SUNLIGHT SENSOR TEST»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__sunlight-sensor-test) ). Is the sunlight sensor OK? YES -Check for loose wires or poor connections at climate control unit connector and at the sunlight sensor 5P connector. If the connections are good, substitute a known-good climate control unit, and recheck. If the symptom/indication goes away, replace the original climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ). NO -Replace the sunlight sensor (see «SUNLIGHT SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__sunlight-sensor-replacement) ).
Scheme 49
Scheme 50
- Clear the DTC with the HDS.
- Turn the ignition switch to LOCK (0), and then to ON (II).
- Do the Self-Diagnostic Function with the HDS (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITH THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ) or the climate control unit (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITHOUT THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ).
- Check for DTCs. Is DTC B1230 or F and AUTO indicated? YES -Go to step 5 . NO -Intermittent failure. Check for loose wires or poor connections on the sunlight sensor circuit.
- Turn the ignition switch to LOCK (0).
- Disconnect the sunlight sensor 5P connector.
- Disconnect climate control unit connectors A (28P) and B (12P).
- Check for continuity between climate control unit connector A (28P) terminal No. 25 and body ground. Is there continuity? YES -Repair a short to body ground in the wire between the climate control unit and the sunlight sensor. NO -Go to step 9 .
- Check for continuity between climate control unit connector A (28P) terminal No. 25 and climate control unit connector B(12P) terminal No. 10. Is there continuity? YES -Repair a short in the wires between the climate control unit and the sunlight sensor. NO -Go to step 10 .
- Reconnect the sunlight sensor 5P connector.
- Reconnect climate control unit connectors A (28P) and B (12P).
- Test the sunlight sensor (see «SUNLIGHT SENSOR TEST»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__sunlight-sensor-test) ). Is the sunlight sensor OK? YES -Substitute a known-good climate control unit, and recheck. If the symptom/indication goes away, replace the original climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ). NO -Replace the sunlight sensor (see «SUNLIGHT SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__sunlight-sensor-replacement) ).
Scheme 51
Scheme 52
- Clear the DTC with the HDS.
- Turn the ignition switch to LOCK (0), and then to ON (II).
- Do the Self-Diagnostic Function with the HDS (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITH THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ) or the climate control unit (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITHOUT THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ).
- Check for DTCs. Is DTC B1231 or G and AUTO indicated? YES -Go to step 5 . NO -Intermittent failure. Check for loose wires or poor connections on the evaporator temperature sensor circuit.
- Turn the ignition switch to LOCK (0).
- Disconnect climate control unit connectors A (28P) and B (12P).
- Check for continuity between climate control unit connector A (28P) terminal No. 23 and evaporator temperature sensor 2P connector terminal No. 2. Is there continuity? YES -Go to step 8 . NO -Repair an open in the wire between the climate control unit and the evaporator temperature sensor.
- Check for continuity between climate control unit connector B (12P) terminal No. 10 and evaporator temperature sensor 2P connector terminal No. 1. Is there continuity? YES -Go to step 9 . NO -Repair an open in the wire between the climate control unit and the evaporator temperature sensor.
- Remove the evaporator temperature sensor (see «EVAPORATOR CORE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ), and test it (see «EVAPORATOR TEMPERATURE SENSOR TEST»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__evaporator-temperature-sensor-test) ). Is the evaporator temperature sensor OK? YES -Check for loose wires or poor connections at climate control unit connectors A (28P), B (12P), and at the evaporator temperature sensor 2P connector. If the connections are good, substitute a known-good climate control unit, and recheck. If the symptom/indication goes away, replace the original climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ). NO -Replace the evaporator temperature sensor (see «EVAPORATOR CORE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
Scheme 53
Scheme 54
- Clear the DTC with the HDS.
- Turn the ignition switch to LOCK (0), and then ON (II).
- Do the Self-Diagnostic Function with the HDS (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITH THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ) or the climate control unit (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITHOUT THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ).
- Check for DTCs. Is DTC B1232 or H and AUTO indicated? YES -Go to step 5 . NO -Intermittent failure. Check for loose wires or poor connections on the evaporator temperature sensor circuit.
- Turn the ignition switch to LOCK (0).
- Disconnect climate control unit connectors A (28P) and B (12P).
- Check for continuity between climate control unit connector A (28P) terminal No. 23 and body ground. Is there continuity? YES -Repair a short to body ground in the wire between the climate control unit and the evaporator temperature sensor. NO -Go to step 8 .
- Check for continuity between climate control unit connector A (28P) terminal No. 23 and climate control unit connector B (12P) terminal No. 10. Is there continuity? YES -Repair a short in the wires between the climate control unit and the evaporator temperature sensor. NO -Go to step 9 .
- Remove the evaporator temperature sensor (see «EVAPORATOR CORE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ), and test it (see «EVAPORATOR TEMPERATURE SENSOR TEST»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__evaporator-temperature-sensor-test) ). Is the evaporator temperature sensor OK? YES -Substitute a known-good climate control unit, and recheck. If the symptom/indication goes away, replace the original climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ). NO -Replace the evaporator temperature sensor (see «EVAPORATOR CORE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
Scheme 55
Scheme 56
- Clear the DTC with the HDS.
- Turn the ignition switch to LOCK (0), and then to ON (II).
- Do the Self-Diagnostic Function with the HDS (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITH THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ) or the climate control unit (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITHOUT THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ).
- Check for DTCs. Is DTC B1233 or A and A/C ON indicated? YES -Go to step 5 . NO -Intermittent failure. Check for loose wires or poor connections on the driver's air mix control motor circuit.
- Turn the ignition switch to LOCK (0).
- Test the driver's air mix control motor (see «DRIVER'S AIR MIX CONTROL MOTOR TEST»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__drivers-air-mix-control-motor-test) ). Is the driver's air mix control motor OK? YES -Go to step 7 . NO -Replace the driver's air mix control motor (see «DRIVER'S AIR MIX CONTROL MOTOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
- Disconnect the driver's air mix control motor 7P connector.
- Disconnect climate control unit connectors A (28P) and B (12P).
- Check for continuity between the following terminals of climate control unit connectors A (28P), B (12P), and the driver's air mix control motor 7P connector. 28P: 7P: No. 14 No. 3 12P: 7P: No. 10 No. 7 No. 12 No. 5 Is there continuity? YES -Check for loose wires or poor connections at climate control unit connectors A (28P), B (12P), and at the driver's air mix control motor 7P connector. If the connections are good, substitute a known-good climate control unit, and recheck. If the symptom/indication goes away, replace the original climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ). NO -Repair an open in the wire(s) between the climate control unit and the driver's air mix control motor.
Scheme 57
Scheme 58
Scheme 59
Scheme 60
Scheme 61
Scheme 62
Scheme 63
- Clear the DTC with the HDS.
- Turn the ignition switch to LOCK (0), and then to ON (II).
- Do the Self-Diagnostic Function with the HDS (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITH THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ) or the climate control unit (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITHOUT THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ).
- Check for DTCs. Is DTC B1234 or B and A/C ON indicated? YES -Go to step 5 . NO -Intermittent failure. Check for loose wires or poor connections on the driver's air mix control motor circuit.
- Check for DTCs. Are these DTCs also present; B121B or H and A/C ON, and/or B1220 or L and A/C ON, and/or B1237 or E and A/C ON? YES -Go to step 13 . NO -Go to step 6 .
- Turn the ignition switch to LOCK (0).
- Test the driver's air mix control motor (see «DRIVER'S AIR MIX CONTROL MOTOR TEST»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__drivers-air-mix-control-motor-test) ). Is the driver's air mix control motor OK? YES -Go to step 8 . NO -Replace the driver's air mix control motor (see «DRIVER'S AIR MIX CONTROL MOTOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
- Disconnect the driver's air mix control motor 7P connector.
- Disconnect climate control unit connectors A (28P) and B (12P).
- Check for continuity between climate control unit connector A (28P) terminal No. 14 and body ground. Is there continuity? YES -Repair a short to body ground in the wire between the climate control unit and the driver's air mix control motor. NO -Go to step 11 .
- Check for continuity between climate control unit connector A (28P) terminal No. 14 and climate control unit connector B (12P) terminal No. 12. Is there continuity? YES -Repair a short in the wires. NO -Go to step 12 .
- Turn the ignition switch to ON (II), and measure the voltage between climate control unit connector A (28P) terminal No. 14 and body ground. Is there any voltage? YES -Repair a short to power in the wire between the climate control unit and the driver's air mix control motor. This short may also damage the climate control unit. Repair a short to power before replacing the climate control unit. NO -Substitute a known-good climate control unit, and recheck. If the symptom/indication goes away, replace the original climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
- Turn the ignition switch to LOCK (0), and disconnect climate control unit connector B (12P).
- Disconnect these items: Driver's air mix control motor Passenger's air mix control motor Recirculation control motor Mode control motor
- Check for continuity between climate control unit connector B (12P) terminal No. 12 and body ground. Is there continuity? YES -Repair a short to body ground in the wire. NO -Go to step 16 .
- Turn the ignition switch to ON (II), and measure the voltage between the same terminal and body ground. Is there any voltage? YES -Repair a short to power in the wire. This short may have also damaged the climate control unit. Repair a short to power before replacing the climate control unit. NO -Go to step 17 .
- Turn the ignition switch to LOCK (0).
- Reconnect climate control unit connector B (12P).
- Turn the ignition switch to ON (II), and measure the voltage between climate control unit connector B (12P) terminal No. 12 and body ground. Is there about 5 V? YES -Go to step 20 . NO -Check for a loose wire or poor connection at climate control unit connector B (12P). If the connection is good, substitute a known-good climate control unit, and recheck. If the symptom/indication goes away, replace the original climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
- While measuring the voltage between the same terminal and body ground, reconnect these items individually and note the voltage reading each time: Driver's air mix control motor Passenger's air mix control motor Recirculation control motor Mode control motor Does the voltage remain at about 5 V? YES -Substitute a known-good climate control unit, and recheck. If the symptom/indication goes away, replace the original climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ). NO -Replace the component that caused the voltage drop.
Scheme 64
Scheme 65
- Clear the DTC with the HDS.
- Turn the ignition switch to LOCK (0), and then to ON (II).
- Do the Self-Diagnostic Function with the HDS (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITH THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ) or the climate control unit (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITHOUT THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ).
- Check for DTCs. Is DTC B1235 or C and A/C ON indicated? YES -Go to step 5 . NO -Intermittent failure. Check for loose wires or poor connections on the driver's air mix control motor circuit.
- Turn the ignition switch to LOCK (0).
- Test the driver's air mix control motor (see «DRIVER'S AIR MIX CONTROL MOTOR TEST»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__drivers-air-mix-control-motor-test) ). Is the driver's air mix control motor OK? YES -Go to step 7 . NO -Replace the driver's air mix control motor (see «DRIVER'S AIR MIX CONTROL MOTOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ), or repair the driver's air mix control linkage or door.
- Disconnect the driver's air mix control motor 7P connector.
- Disconnect climate control unit connector A (28P).
- Check for continuity between the following terminals of climate control unit connector A (28P) and the driver's air mix control motor 7P connector. 28P: 7P: No. 4 No. 2 No. 6 No. 1 Is there continuity? YES -Go to step 10 . NO -Repair an open in the wire(s) between the climate control unit and the driver's air mix control motor.
- Check for continuity between body ground and climate control unit connector A (28P) terminals No. 4 and No. 6 individually. Is there continuity? YES -Repair a short to body ground in the wire(s) between the climate control unit and the driver's air mix control motor. NO -Substitute a known-good climate control unit, and recheck. If the symptom/indication goes away, replace the original climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
Scheme 66
Scheme 67
- Clear the DTC with the HDS.
- Turn the ignition switch to LOCK (0), and then to ON (II).
- Do the Self-Diagnostic Function with the HDS (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITH THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ) or the climate control unit (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITHOUT THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ).
- Check for DTCs. Is DTC B1236 or D and A/C ON indicated? YES -Go to step 5 . NO -Intermittent failure. Check for loose wires or poor connections on the passenger's air mix control motor circuit.
- Turn the ignition switch to LOCK (0).
- Test the passenger's air mix control motor (see «PASSENGER'S AIR MIX CONTROL MOTOR TEST»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__passengers-air-mix-control-motor-test) ). Is the passenger's air mix control motor OK? YES -Go to step 7 . NO -Replace the passenger's air mix control motor (see «PASSENGER'S AIR MIX CONTROL MOTOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
- Disconnect the passenger's air mix control motor 7P connector.
- Disconnect climate control unit connectors A (28P) and B (12P).
- Check for continuity between the following terminals of climate control unit connectors A (28P), B (12P), and the passenger's air mix control motor 7P connector. 28P: 7P: No. 13 No. 3 12P: 7P: No. 10 No. 5 No. 12 No. 7 Is there continuity? YES -Check for loose wires or poor connections at climate control unit connectors A (28P), B (12P), and at the passenger's air mix control motor 7P connector. If the connections are good, substitute a known-good climate control unit, and recheck. If the symptom/indication goes away, replace the original climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ). NO -Repair an open in the wire(s) between the climate control unit and the passenger's air mix control motor.
Scheme 68
Scheme 69
Scheme 70
Scheme 71
Scheme 72
Scheme 73
Scheme 74
- Clear the DTC with the HDS.
- Turn the ignition switch to LOCK (0), and then to ON (II).
- Do the Self-Diagnostic Function with the HDS (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITH THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ) or the climate control unit (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITHOUT THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ).
- Check for DTCs. Is DTC B1237 or E and A/C ON indicated? YES -Go to step 5 . NO -Intermittent failure. Check for loose wires or poor connections on the passenger's air mix control motor circuit.
- Check for DTCs. Are these DTCs also present; B121B or Hand A/C ON, and/or B1220 or L and A/C ON, and/or B1234 or B and A/C ON? YES -Go to step 13 . NO -Go to step 6 .
- Turn the ignition switch to LOCK (0).
- Test the passenger's air mix control motor (see «PASSENGER'S AIR MIX CONTROL MOTOR TEST»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__passengers-air-mix-control-motor-test) ). Is the passenger's air mix control motor OK? YES -Go to step 8 . NO -Replace the passenger's air mix control motor (see «PASSENGER'S AIR MIX CONTROL MOTOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
- Disconnect the passenger's air mix control motor 7P connector.
- Disconnect climate control unit connectors A (28P) and B (12P).
- Check for continuity between climate control unit connector A (28P) terminal No. 13 and body ground. Is there continuity? YES -Repair a short to body ground in the wire between the climate control unit and the passenger's air mix control motor. NO -Go to step 11 .
- Check for continuity between climate control unit connector A (28P) terminal No. 13 and climate control unit connector B (12P) terminal No. 12. Is there continuity? YES -Repair a short in the wires. NO -Go to step 12 .
- Turn the ignition switch to ON (II), and measure the voltage between climate control unit connector A (28P) terminal No. 13 and body ground. Is there any voltage? YES -Repair a short to power in the wire between the climate control unit and the passenger's air mix control motor. This short may also damage the climate control unit. Repair a short to power before replacing the climate control unit. NO -Substitute a known-good climate control unit, and recheck. If the symptom/indication goes away, replace the original climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
- Turn the ignition switch to LOCK (0), and disconnect climate control unit connector B (12P).
- Disconnect these items: Driver's air mix control motor Passenger's air mix control motor Recirculation control motor Mode control motor
- Check for continuity between climate control unit connector B (12P) terminal No. 12 and body ground. Is there continuity? YES -Repair a short to body ground in the wire. NO -Go to step 16 .
- Turn the ignition switch to ON (II), and measure the voltage between the same terminal and body ground. Is there any voltage? YES -Repair a short to power in the wire. This short may have also damaged the climate control unit. Repair a short to power before replacing the climate control unit. NO -Go to step 17 .
- Turn the ignition switch to LOCK (0).
- Reconnect climate control unit connector B (12P).
- Turn the ignition switch to ON (II), and measure the voltage between climate control unit connector B (12P) terminal No. 12 and body ground. Is there about 5 V? YES -Go to step 20 . NO -Check for a loose wire or poor connection at climate control unit connector B (12P). If the connection is good, substitute a known-good climate control unit, and recheck. If the symptom/indication goes away, replace the original climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
- While measuring the voltage between the same terminal and body ground, reconnect these items individually and note the voltage reading each time: Driver's air mix control motor Passenger's air mix control motor Recirculation control motor Mode control motor Does the voltage remain at about 5 V? YES -Substitute a known-good climate control unit, and recheck. If the symptom/indication goes away, replace the original climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ). NO -Replace the component that caused the voltage drop.
Scheme 75
Scheme 76
- Clear the DTC with the HDS.
- Turn the ignition switch to LOCK (0), and then to ON (II).
- Do the Self-Diagnostic Function with the HDS (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITH THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ) or the climate control unit (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITHOUT THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ).
- Check for DTCs. Is DTC B1238 or F and A/C ON indicated? YES -Go to step 5 . NO -Intermittent failure. Check for loose wires or poor connections on the passenger's air mix control motor circuit.
- Turn the ignition switch to LOCK (0).
- Test the passenger's air mix control motor (see «PASSENGER'S AIR MIX CONTROL MOTOR TEST»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__passengers-air-mix-control-motor-test) ). Is the passenger's air mix control motor OK? YES -Go to step 7 . NO -Replace the passenger's air mix control motor (see «PASSENGER'S AIR MIX CONTROL MOTOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ), or repair the passenger's air mix control linkage or door.
- Disconnect the passenger's air mix control motor 7P connector.
- Disconnect climate control unit connector A (28P).
- Check for continuity between the following terminals of climate control unit connector A (28P) and the passenger's air mix control motor 7P connector. 28P: 7P: No. 1 No. 2 No. 2 No. 1 Is there continuity? YES -Go to step 10 . NO -Repair an open in the wire(s) between the climate control unit and the passenger's air mix control motor.
- Check for continuity between body ground and climate control unit connector A (28P) terminals No. 1 and No. 2 individually. Is there continuity? YES -Repair a short to body ground in the wire(s) between the climate control unit and the passenger's air mix control motor. NO -Substitute a known-good climate control unit, and recheck. If the symptom/indication goes away, replace the original climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
Scheme 77
Scheme 78
- Clear the DTC with the HDS.
- Turn the ignition switch to LOCK (0), and then to ON (II).
- Do the Self-Diagnostic Function with the HDS (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITH THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ) or the climate control unit (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITHOUT THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ).
- Check for DTCs. Is DTC B1240 or J and A/C ON indicated? YES -Go to step 5 . NO -Intermittent failure. Check for loose wires or poor connections on the mode control motor circuit.
- Turn the ignition switch to LOCK (0).
- Test the mode control motor (see «MODE CONTROL MOTOR TEST»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__mode-control-motor-test) ). Is the mode control motor OK? YES -Go to step 7 . NO -Replace the mode control motor (see «MODE CONTROL MOTOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ), or repair the mode control linkage or doors.
- Disconnect the mode control motor 7P connector.
- Disconnect climate control unit connector A (28P).
- Check for continuity between the following terminals of climate control unit connector A (28P) and the mode control motor 7P connector. 28P: 7P: No. 7 No. 2 No. 8 No. 1 Is there continuity? YES -Go to step 10 . NO -Repair an open in the wire(s) between the climate control unit and the mode control motor.
- Check for continuity between body ground and climate control unit connector A (28P) terminals No. 7 and No. 8 individually. Is there continuity? YES -Repair a short to body ground in the wire(s) between the climate control unit and the mode control motor. NO -Substitute a known-good climate control unit, and recheck. If the symptom/indication goes away, replace the original climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
Scheme 79
Scheme 80
Scheme 81
Scheme 82
Scheme 83
Scheme 84
Scheme 85
Scheme 86
Scheme 87
Scheme 88
- Clear the DTC with the HDS.
- Turn the ignition switch to LOCK (0), and then to ON (II).
- Do the Self-Diagnostic Function with the HDS (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITH THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ) or the climate control unit (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITHOUT THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ).
- Check for DTCs. Is DTC B1241 or N and A/C ON indicated? YES -Go to step 5 . NO -Intermittent failure. Check for loose wires or poor connections on the blower motor circuit.
- Turn the ignition switch to LOCK (0).
- Check the No. 8 (40 A) fuse in the under-hood fuse/relay box and the No. 16 (7.5 A) fuse in the driver's under-dash fuse/relay box. Are the fuses OK? YES -Go to step 7 . NO -Replace the fuse(s), and recheck. If the fuse(s) blow again, check for a short in the No. 8 (40 A) fuse and the No. 16 (7.5 A) fuse circuits.
- Disconnect the blower motor 2P connector.
- Turn the ignition switch to ON (II).
- Measure the voltage between blower motor 2P connector terminal No. 1 and body ground. Is there battery voltage? YES -Go to step 10 . NO -Go to step 29 .
- Turn the ignition switch to LOCK (0).
- Reconnect the blower motor 2P connector.
- Connect blower motor 2P connector terminal No. 2 to body ground with a jumper wire.
- Turn the ignition switch to ON (II). Does the blower motor run? YES -Go to step 14 . NO -Replace the blower motor (see «BLOWER UNIT COMPONENT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__blower-unit-component-replacement) ).
- Turn the ignition switch to LOCK (0).
- Disconnect the jumper wire.
- Disconnect the power transistor 4P connector.
- Check for continuity between power transistor 4P connector terminal No. 2 and body ground. Is there continuity? YES -Go to step 18 . NO -Check for an open in the BLK wire between the power transistor and body ground. If the wire is OK, check for poor ground at G302 (see «LEFT ENGINE COMPARTMENT WIRE HARNESS DASHBOARD BRANCH)»(/acura/tsx/ii-2008-2014/remont/body-electrical/#connectors-and-harnesses-v6__left-engine-compartment-wire-harness-dashboard) ).
- Connect power transistor 4P connector terminals No. 2 and No. 4 with a jumper wire.
- Turn the ignition switch to ON (II). Does the blower motor run at high speed? YES -Go to step 20 . NO -Repair open in the GRN wire between the power transistor and the blower motor.
- Turn the ignition switch to LOCK (0).
- Disconnect the jumper wire.
- Disconnect climate control unit connector B (12P).
- Check for continuity between body ground and climate control unit connector B (12P) terminals No. 5 and No. 6 individually. Is there continuity? YES -Repair a short to body ground in the wire(s) between the climate control unit and the power transistor. NO -Go to step 24 .
- Check for continuity between the following terminals of climate control unit connector B (12P) and the power transistor 4P connector. 12P: 4P: No. 5 No. 1 No. 6 No. 3 Is there continuity? YES -Go to step 25 . NO -Repair an open in the wire(s) between the climate control unit and the power transistor.
- Turn the ignition switch to ON (II).
- Measure the voltage between body ground and climate control unit connector B (12P) terminals No. 5 and No. 6 individually. Is there voltage? YES -Repair a short to power in the wire(s). NO -Go to step 27 .
- Turn the ignition switch to LOCK (0).
- Test the power transistor (see «POWER TRANSISTOR TEST»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ). Is the power transistor OK? YES -Check for loose wires or poor connections at climate control unit connector B (12P) and at the power transistor 4P connector. If the connections are good, substitute a known-good climate control unit, and recheck. If the symptom/indication goes away, replace the original climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ). NO -Replace the power transistor. NOTE: If the power transistor is faulty, check the blower motor for damage. If necessary, replace the blower motor.
- Turn the ignition switch to LOCK (0).
- Remove the blower motor relay from the under-hood fuse/relay box, and test it (see «POWER RELAY TEST»(/acura/tsx/ii-2008-2014/remont/body-electrical/#relays-v6__power-relay-test) ). Is the relay OK? YES -Go to step 31 . NO -Replace the blower motor relay.
- Check for continuity between blower motor relay 4P socket terminal No. 2 and blower motor 2P connector terminal No. 1. Is there continuity? YES -Go to step 32 . NO -Repair an open in the wire between the blower motor relay and the blower motor.
- Measure the voltage between blower motor relay 4P socket terminal No. 1 and body ground. Is there battery voltage? YES -Go to step 33 . NO -Replace the under-hood fuse/relay box (see «REMOVAL AND INSTALLATION»(/acura/tsx/ii-2008-2014/remont/fuses-circuit-breakers/#under-hood-fuserelay-box-v6__removal-and-installation) ).
- Turn the ignition switch to ON (II).
- Measure the voltage between blower motor relay 4P socket terminal No. 4 and body ground. Is there battery voltage? YES -Check for an open in the wire between the blower motor relay 4P socket terminal No. 3 and body ground. If the wire is OK, check for poor ground at G301 (see «LEFT ENGINE COMPARTMENT WIRE HARNESS (ENGINE COMPARTMENT BRANCH)»(/acura/tsx/ii-2008-2014/remont/body-electrical/#connectors-and-harnesses-v6__left-engine-compartment-wire-harness-engine) ). NO -Repair an open in the wire between the No. 16 (7.5 A) fuse in the driver's under-dash fuse/relay box and the blower motor relay 4P socket.
Scheme 89
Scheme 90
- Clear the DTC with the HDS.
- Turn the ignition switch to LOCK (0), and then to ON (II).
- Do the Self-Diagnostic Function with the HDS (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITH THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ) or the climate control unit (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITHOUT THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ).
- Check the DTCs. Is DTC B2983 or M and A/C ON indicated? YES -Go to step 5 . NO -Intermittent failure. Check for loose wires or poor connections on the recirculation control motor circuit.
- Turn the ignition switch to LOCK (0).
- Test the recirculation control motor (see «RECIRCULATION CONTROL MOTOR TEST»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__recirculation-control-motor-test) ). Is the recirculation control motor OK? YES -Go to step 7 . NO -Replace the recirculation control motor (see «RECIRCULATION CONTROL MOTOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ), or repair the recirculation control linkage or door.
- Disconnect the recirculation control motor 7P connector.
- Disconnect climate control unit connector A (28P).
- Check for continuity between the following terminals of climate control unit connector A (28P) and the recirculation control motor 7P connector. 28P: 7P: No. 3 No. 1 No. 5 No. 2 Is there continuity? YES -Go to step 10 . NO -Repair an open in the wire(s) between the climate control unit and the recirculation control motor.
- Check for continuity between body ground and climate control unit connector A (28P) terminals No. 3 and No. 5 individually. Is there continuity? YES -Repair a short to body ground in the wire(s) between the climate control unit and the recirculation control motor. NO -Substitute a known-good climate control unit, and recheck. If the symptom/indication goes away, replace the original climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
Scheme 91
Scheme 92
- Clear the DTC with the HDS.
- Turn the ignition switch to LOCK (0), and then to ON (II).
- Do the Self-Diagnostic Function with the HDS (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITH THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ) or the climate control unit (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITHOUT THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ).
- Check for DTCs. Is DTC B2986 or K and A/C ON indicated? YES -Go to step 5 . NO -Intermittent failure. Check for loose wires or poor connections on the recirculation control motor circuit.
- Turn the ignition switch to LOCK (0).
- Test the recirculation control motor (see «RECIRCULATION CONTROL MOTOR TEST»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__recirculation-control-motor-test) ). Is the recirculation control motor OK? YES -Go to step 7 . NO -Replace the recirculation control motor (see «RECIRCULATION CONTROL MOTOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
- Disconnect the recirculation control motor 7P connector.
- Disconnect climate control unit connectors A (28P) and B (12P).
- Check for continuity between the following terminals of climate control unit connectors A (28P), B (12P), and the recirculation control motor 7P connector. 28P: 7P: No. 12 No. 3 12P: 7P: No. 10 No. 5 No. 12 No. 7 Is there continuity? YES -Check for loose wires or poor connections at climate control unit connectors A (28P), B (12P), and at the recirculation control motor 7P connector. If the connections are good, substitute a known-good climate control unit, and recheck. If the symptom/indication goes away, replace the original climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ). NO -Repair an open in the wire(s) between the climate control unit and the recirculation control motor.
Scheme 93
Scheme 94
- Check the No. 16 (7.5 A) fuse in the driver's under-dash fuse/relay box. Is the fuse OK? YES -Go to step 2 . NO -Replace the fuse, and recheck. If the fuse blow again, check for a short in the No. 16 (7.5 A) fuse circuit.
- Disconnect climate control unit connector A (28P).
- Turn the ignition switch to ON (II).
- Measure the voltage between climate control unit connector A (28P) terminal No. 9 and body ground. Is there battery voltage? YES -Go to step 5 . NO -Repair an open in the wire between the No. 16 (7.5 A) fuse in the driver's under-dash fuse/relay box and the climate control unit.
- Turn the ignition switch to LOCK (0).
- Disconnect climate control unit connector B (12P).
- Check for continuity between climate control unit connector B (12P) terminal No. 3 and body ground. Is there continuity? YES -Check for loose wires or poor connections at climate control unit connector B (12P). If the connections are good, substitute a known-good climate control unit, and recheck. If the symptom/indication goes away, replace the original climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ). NO -Check for an open in the wire between the climate control unit and body ground. If the wire is OK, check for poor ground at G401; with navigation (see «AUDIO WIRE HARNESS (WITH NAVIGATION)»(/acura/tsx/ii-2008-2014/remont/body-electrical/#connectors-and-harnesses-v6__audio-wire-harness-with-navigation) ), without navigation (see «AUDIO WIRE HARNESS (WITHOUT NAVIGATION)»(/acura/tsx/ii-2008-2014/remont/body-electrical/#connectors-and-harnesses-v6__audio-wire-harness-without-navigation) ).
Radiator and A/C Condenser Fan Low Speed Circuit Troubleshooting
Note. Do not use this troubleshooting procedure if the A/C compressor is inoperative. Refer to the SYMPTOM TROUBLESHOOTING INDEX . Before doing symptom troubleshooting, check for PGM-FI DTCs (see GENERAL TROUBLESHOOTING INFORMATION ).
Scheme 95
Scheme 96
Scheme 97
Scheme 98
Scheme 99
Scheme 100
- Check the No. 3-8 (SUB FAN MTR) (30 A) fuse in the under-hood fuse/relay. Is the fuse OK? YES -Go to step 2 . NO -Replace the fuse, and recheck. If the fuse blow again, check for a short in the No. 3-8 (SUB FAN MTR) (30 A) fuse circuit.
- Connect the HDS to the DLC.
- Turn the ignition switch to ON (II).
- Turn on the A/C.
- Check the FAN LOW CTRL in the PGM-FI Data List with the HDS. Is the FAN LOW CTRL on? YES -Go to step 6 . NO -Substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#fuel-and-emissions-systems-v6__substituting-the-pcm) ), and recheck. If the symptom/indication goes away with a known-good PCM, replace the original PCM (see «PCM REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#pgm-fi-system-v6__pcm-replacement) ).
- Turn the ignition switch to LOCK (0).
- Remove the relay circuit board (see «REMOVAL AND INSTALLATION»(/acura/tsx/ii-2008-2014/remont/fuses-circuit-breakers/#under-hood-fuserelay-box-v6__removal-and-installation) ) from the under-hood fuse/relay box, and test the A/C condenser fan relay and the fan control relay (see «FIVE-TERMINAL TYPE»(/acura/tsx/ii-2008-2014/remont/body-electrical/#relays-v6__five-terminal-type) ). Are the relays OK? YES -Go to step 8 . NO -Replace the relay circuit board.
- Reinstall the relay circuit board.
- Jump the SCS line with the HDS. NOTE: This step must be done to protect the PCM from damage.
- Disconnect PCM connector A (49P).
- Turn the ignition switch to ON (II).
- Measure the voltage between PCM connector A terminal No. 4 and body ground. Is there battery voltage? YES -Go to step 13 . NO -Repair an open in the wires between the under-hood fuse/relay box and the PCM. If the wires are OK, replace the under-hood fuse/relay box (see «REMOVAL AND INSTALLATION»(/acura/tsx/ii-2008-2014/remont/fuses-circuit-breakers/#under-hood-fuserelay-box-v6__removal-and-installation) ).
- Turn the ignition switch to LOCK (0).
- Connect PCM connector A (49P) terminal No. 4 to body ground with a jumper wire.
- Turn the ignition switch to ON (II). Do the A/C condenser and radiator fans run on low? YES -Check for loose wires or poor connections at PCM connector A (49P) terminal No. 4. If the connections are good, substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#fuel-and-emissions-systems-v6__substituting-the-pcm) ), and recheck. If the symptom/indication goes away, replace the original PCM (see «PCM REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#pgm-fi-system-v6__pcm-replacement) ). NO -Go to step 16 .
- Turn the ignition switch to LOCK (0).
- Disconnect the jumper wire.
- Reconnect PCM connector A (49P).
- Disconnect the A/C condenser fan motor 2P connector.
- Turn the ignition switch to ON (II), then turn on the A/C.
- Measure the voltage between A/C condenser fan motor 2P connector terminal No. 2 and body ground. Is there battery voltage? YES -Go to step 22 . NO -Repair an open in the wire between the under-hood fuse/relay box and the A/C condenser fan motor. If the wire is OK, replace the under-hood fuse/relay box (see «REMOVAL AND INSTALLATION»(/acura/tsx/ii-2008-2014/remont/fuses-circuit-breakers/#under-hood-fuserelay-box-v6__removal-and-installation) ).
- Turn off the A/C, then turn the ignition switch to LOCK (0).
- Test the A/C condenser fan motor (see «FAN MOTOR TEST»(/acura/tsx/ii-2008-2014/remont/cooling-fan/#engine-cooling-system-v6) ). Is the motor OK? YES -Go to step 24 . NO -Replace the A/C condenser fan motor (see «FAN, FAN MOTOR, AND SHROUD REMOVAL AND INSTALLATION»(/acura/tsx/ii-2008-2014/remont/cooling-fan/#engine-cooling-system-v6) ).
- Disconnect the under-hood fuse/relay box connector C (5P).
- Check for continuity between under-hood fuse/relay box connector C (5P) terminal No. 3 and A/C condenser fan motor 2P connector terminal No. 1. Is there continuity? YES -Go to step 26 . NO -Repair an open in the wire between the under-hood fuse/relay box and the A/C condenser fan motor.
- Disconnect under-hood fuse/relay box connector B (14P).
- Disconnect the radiator fan motor 2P connector.
- Check for continuity between under-hood fuse/relay box connector B (14P) terminal No. 2 and radiator fan motor 2P connector terminal No. 2. Is there continuity? YES -Go to step 29 . NO -Repair an open in the wire between the under-hood fuse/relay box and the radiator fan motor.
- Check for continuity between radiator fan motor 2P connector terminal No. 1 and body ground. Is there continuity? YES -Replace the radiator fan motor (see «FAN, FAN MOTOR, AND SHROUD REMOVAL AND INSTALLATION»(/acura/tsx/ii-2008-2014/remont/cooling-fan/#engine-cooling-system-v6) ). NO -Check for an open in the wire between the radiator fan motor and body ground. If the wire is OK, check for poor ground at G301 (see «LEFT ENGINE COMPARTMENT WIRE HARNESS (ENGINE COMPARTMENT BRANCH)»(/acura/tsx/ii-2008-2014/remont/body-electrical/#connectors-and-harnesses-v6__left-engine-compartment-wire-harness-engine) ).
A/C Condenser Fan High Speed Circuit Troubleshooting
Note. Do not use this troubleshooting procedure if the A/C compressor is inoperative. Refer to the SYMPTOM TROUBLESHOOTING INDEX . Before doing any symptom troubleshooting, check for PGM-FI DTCs (see GENERAL TROUBLESHOOTING INFORMATION ).
Scheme 101
Scheme 102
- Connect the HDS to the DLC.
- Start the engine.
- Turn on the A/C.
- Using the HDS, confirm the following values in the PGM-FI Data List at idle. PRESSURE CHART ECT SENSOR 2 Above 199°F (93°C) FAN LOW CTRL ON FAN HIGH CTRL ON A/C PRESSURE SENSOR Above 1,470 kPa (213 psi) Are all the values within specifications? YES -Go to step 5 . NO -Troubleshoot the value that is not within the specifications.
- Turn the ignition switch to LOCK (0).
- Remove the relay circuit board (see «REMOVAL AND INSTALLATION»(/acura/tsx/ii-2008-2014/remont/fuses-circuit-breakers/#under-hood-fuserelay-box-v6__removal-and-installation) ) from the under-hood fuse/relay box, and test the fan control relay (see «FIVE-TERMINAL TYPE»(/acura/tsx/ii-2008-2014/remont/body-electrical/#relays-v6__five-terminal-type) ). Is the relay OK? YES -Go to step 7 . NO -Replace the relay circuit board.
- Jump the SCS line with the HDS. NOTE: This step must be done to protect the PCM from damage.
- Disconnect PCM connector A (49P).
- Turn the ignition switch to ON (II).
- Measure the voltage between PCM connector A terminal No. 5 and body ground. Is there battery voltage? YES -Go to step 11 . NO -Repair an open in the wire between the under-hood fuse/relay box and the PCM. If the wire is OK, replace the under-hood fuse/relay box (see «REMOVAL AND INSTALLATION»(/acura/tsx/ii-2008-2014/remont/fuses-circuit-breakers/#under-hood-fuserelay-box-v6__removal-and-installation) ).
- Turn the ignition switch to LOCK (0).
- Connect PCM connector A (49P) terminals No. 4 and No. 5 to body ground with jumper wires.
- Turn the ignition switch to ON (II). Does the A/C condenser fan run on high? YES -Check for loose wires or poor connections at PCM connector A (49P) terminals No. 4 and No. 5. If the connections are good, substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#fuel-and-emissions-systems-v6__substituting-the-pcm) ), and recheck. If the symptom/indication goes away, replace the original PCM (see «PCM REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#pgm-fi-system-v6__pcm-replacement) ). NO -Check for an open in the wire between under-hood fuse/relay box connector C (5P) terminal No. 5 and body ground. If the wire is OK, check for poor ground at G301 (see «LEFT ENGINE COMPARTMENT WIRE HARNESS (ENGINE COMPARTMENT BRANCH)»(/acura/tsx/ii-2008-2014/remont/body-electrical/#connectors-and-harnesses-v6__left-engine-compartment-wire-harness-engine) ).
A/C Compressor Clutch Circuit Troubleshooting
Note. It is normal for the A/C compressor to turn off under certain conditions, such as low idle, high engine coolant temperature, hard acceleration, or high/low refrigerant pressure. Do not use this troubleshooting procedure if the fans are also inoperative with the A/C on. Refer to the SYMPTOM TROUBLESHOOTING INDEX . Before doing any symptom troubleshooting, check for PGM-FI DTCs (see GENERAL TROUBLESHOOTING INFORMATION ). Also check for B-CAN codes (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A ).
Scheme 103
Scheme 104
Scheme 105
Scheme 106
Scheme 107
- Check the No. 20 (7.5 A) fuse in the under-hood fuse/relay box and the No. 16 (7.5 A) fuse in the driver's under-dash fuse/relay box. Are the fuses OK? YES -Go to step 2 . NO -Replace the fuse(s) and recheck. If the fuse(s) blow again, check for a short in the No. 20 (7.5 A) fuse and the No. 16 (7.5 A) fuse circuits.
- Connect the HDS to the DLC.
- Start the engine.
- Turn on the A/C.
- Check the A/C switch in the PGM-FI data list with the HDS. Is the A/C switch ON? YES -Go to step 6 . NO -Go to «A/C SIGNAL CIRCUIT TROUBLESHOOTING»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__ac-signal-circuit-troubleshooting) .
- Using the HDS, confirm the following values in the PGM-FI Data List at idle. PRESSURE CHART TP SENSOR About 0.5 V RPM 630-730 ECT SENSOR 2 176-212°F (80-100°C) A/C SWITCH ON A/C CLUTCH ON A/C PRESSURE SENSOR 196-3,138 kPa (2.0-32 kgf/cm 2 ) [28-455 psi] Are all the values within specifications? YES -Go to step 7 . NO -Troubleshoot the value that is not within the specifications.
- Turn the ignition switch to LOCK (0).
- Remove the A/C compressor clutch relay from the under-hood fuse/relay box, and test it (see «POWER RELAY TEST»(/acura/tsx/ii-2008-2014/remont/body-electrical/#relays-v6__power-relay-test) ). Is the relay OK? YES -Go to step 9 . NO -Replace the A/C compressor clutch relay.
- Measure the voltage between A/C compressor clutch relay 4P socket terminal No. 1 and body ground. Is there battery voltage? YES -Go to step 10 . NO -Replace the under-hood fuse/relay box (see «REMOVAL AND INSTALLATION»(/acura/tsx/ii-2008-2014/remont/fuses-circuit-breakers/#under-hood-fuserelay-box-v6__removal-and-installation) ).
- Connect A/C compressor clutch relay 4P socket terminals No. 1 and No. 2 with a jumper wire. Does the A/C compressor clutch click? YES -Go to step 11 . NO -Go to step 20 .
- Disconnect the jumper wire.
- Turn the ignition switch to ON (II).
- Measure the voltage between A/C compressor clutch relay 4P socket terminal No. 4 and body ground. Is there battery voltage? YES -Go to step 14 . NO -Repair an open in the wire between the No. 16 (7.5 A) fuse in the driver's under-dash fuse/relay box and the A/C compressor clutch relay.
- Turn the ignition switch to LOCK (0).
- Reinstall the A/C compressor clutch relay.
- Jump the SCS line with the HDS. NOTE: This step must be done to protect the PCM from damage.
- Disconnect PCM connector A (49P).
- Connect PCM connector A (49P) terminal No. 13 to body ground with a jumper wire.
- Turn the ignition switch to ON (II). Does the A/C compressor click? YES -Check for loose wires or poor connections at PCM connector A (49P). If the connections are good, check the PCM grounds. If the grounds are good, substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#fuel-and-emissions-systems-v6__substituting-the-pcm) ), and recheck. If the symptom/indication goes away, replace the original PCM (see «PCM REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#pgm-fi-system-v6__pcm-replacement) ). NO -Repair an open in the wire between the A/C compressor clutch relay and the PCM.
- Disconnect the jumper wire.
- Disconnect the A/C compressor clutch 1P connector.
- Check for continuity between A/C compressor clutch relay 4P socket terminal No. 2 and A/C compressor clutch 1P connector terminal No. 1. Is there continuity? YES -Check the A/C compressor clutch clearance, and the A/C compressor clutch field coil (see «A/C COMPRESSOR CLUTCH CHECK»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ). Repair as needed. NO -Repair an open in the wire between the A/C compressor clutch relay and the A/C compressor clutch.
A/C Signal Circuit Troubleshooting
Note. If the blower motor does not run at all speeds, the A/C compressor will be inoperative. Run the self-diagnostic function, and check for DTC B1241. Before performing any other troubleshooting, repair the cause of the inoperative blower motor. Do not use this troubleshooting procedure if any of the following items are operative: The A/C condenser fan, the radiator fan, or the A/C compressor, or if the heater is inoperative. Refer to the SYMPTOM TROUBLESHOOTING INDEX . Before doing symptom troubleshooting, check for PGM-FI DTCs (see GENERAL TROUBLESHOOTING INFORMATION ).
Scheme 108
Scheme 109
Scheme 110
Scheme 111
Scheme 112
Scheme 113
- Turn the ignition switch to ON (II).
- Check if the blower motor operates at all speeds. Does the blower motor operate at all speeds? YES -Go to step 3 . NO -Repair the problem in the blower motor circuit (see «DTC B1241 OR DTC INDICATOR N AND A/C ON: A PROBLEM IN THE BLOWER MOTOR CIRCUIT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
- Do the sensor input display mode (see «RUN THE SENSOR INPUT DISPLAY MODE»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__run-the-sensor-input-display-mode) ). Is Sensor #5 (evaporative outlet air temperature) above 3°C? YES -Go to step 4. NO -Go to step 11 .
- Turn the ignition switch to LOCK (0).
- Disconnect climate control unit connector A (28P).
- Turn the ignition switch to ON (II).
- Measure the voltage between climate control unit connector A (28P) terminal No. 21 and body ground. Is there battery voltage? YES -Go to step 8 . NO -Go to step 10 .
- Connect climate control unit connector A (28P) terminal No. 21 to body ground with a jumper wire.
- Turn the ignition switch to ON (II). Does the A/C system come on? YES -Replace the climate control unit. NO -Check for loose wire or poor connections at climate control unit connector A (28P) and under-dash fuse/relay box connector F (33P). If the connections are good, substitute a known-good climate control unit, and recheck. If the symptom goes away, replace the original climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
- Measure the voltage between driver's under-dash" fuse/relay box connector F (33P) terminal No. 5 and body ground. Is there battery voltage? YES -Repair an open in the wire between the climate control unit and the driver's under-dash fuse/relay box. NO -Check for loose wire or poor connections at driver's under-dash fuse/relay box connector F (33P) terminal No. 5. If the connections are good, substitute a known-good driver's under-dash fuse/relay box, and recheck. If the symptom goes away, replace the original driver's under-dash fuse/relay box; USA models (see «DRIVER'S UNDER-DASH FUSE/RELAY BOX (MICU) REMOVAL AND INSTALLATION»(/acura/tsx/ii-2008-2014/remont/fuses-circuit-breakers/#under-dash-fuserelay-box-v6__drivers-under-dash-fuserelay-box-micu-removal) ), Canada models (see «CANADA MODELS»(/acura/tsx/ii-2008-2014/remont/fuses-circuit-breakers/#under-dash-fuserelay-box-v6__canada-models) ).
- Turn the ignition switch to LOCK (0).
- Disconnect climate control unit connectors A (28P) and B (12P).
- Measure the evaporator temperature sensor resistance between climate control unit connector A (28P) terminal No. 23 and connector B (12P) terminal No. 10. Is the resistance less than 24 kohms? YES -Check for loose wires or poor connections at the climate control unit connectors. If the connections are good, substitute a known-good climate control unit, and recheck. If the symptom goes away, replace the original climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ). NO -Go to step 14 .
- Check for continuity between climate control unit connector A (28P) terminal No. 23 and evaporator temperature sensor 2P connector terminal No. 2. Is there continuity? YES -Go to step 15 . NO -Repair an open in the wire between the climate control unit and the evaporator temperature sensor.
- Check for continuity between climate control unit connector B (12P) terminal No. 10 and evaporator temperature sensor 2P connector terminal No. 1. Is there continuity? YES -Test the evaporator temperature sensor (see «EVAPORATOR TEMPERATURE SENSOR TEST»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__evaporator-temperature-sensor-test) ). NO -Repair an open in the wire between the climate control unit and the evaporator temperature sensor.
Scheme 114
Scheme 115
Scheme 116
Scheme 117
- Disconnect the audio-navigation switch panel 24P connector.
- Turn the ignition switch to ON (II).
- Measure the voltage between audio-navigation switch panel 24P connector terminal No. 21 and body ground. (Scheme 114): Measuring Voltage Between Audio-Navigation Switch Panel 24P Connector Terminal No. 21 And Body Ground Is there battery voltage? YES -Go to step 4. NO -Repair an open in the wire between the No. 16 (7.5 A) fuse in the driver's under-dash fuse/relay box and the audio-navigation switch panel.
- Turn the ignition switch to LOCK (0).
- Disconnect climate control unit connector A (28P).
- Check for continuity between the following terminals of climate control unit connector A (28P) and the audio-navigation switch panel 24P connector. 28P: 24P: No. 19 No. 7 No. 20 No. 19 Is there continuity? YES -Go to step 7. NO -Repair an open in the wire between climate control unit connector A (28P) and the audio-navigation switch panel 24P connector.
- Check for continuity between body ground and climate control unit connector A (28P) terminals No. 19 and No. 20 individually. Is there continuity? YES -Repair a short to body ground in the wire between climate control unit connector A (28P) and the audio-navigation switch panel 24P connector. NO -Go to step 8.
- Reconnect climate control unit connector A (28P).
- Connect audio-navigation switch panel 24P connector terminals No. 7 and No. 19 with a jumper wire.
- Turn the ignition switch to ON (II).
- Press and hold the WINDSHIELD DEFOGGER button and ON/OFF button.
- Check the WINDSHIELD DEFROSTER button LED. Is the LED blinking? YES -The audio-navigation switch panel is faulty, replace the audio-navigation switch panel (see «AUDIO-NAVIGATION SWITCH PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-v6) ). NO -The climate control unit is faulty, replace the climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
Scheme 118
Scheme 119
Scheme 120
Scheme 121
- Disconnect the audio-HVAC display unit 12P connector.
- Turn the ignition switch to ON (II).
- Measure the voltage between audio-HVAC display unit 12P connector terminal No. 5 and body ground. (Scheme 118): Measuring Voltage Between Audio-HVAC Display Unit 12P Connector Terminal No. 5 & Body Ground Is there battery voltage? YES -Go to step 4. NO -Repair an open in the wire between the No. 16 (7.5 A) fuse in the driver's under-dash fuse/relay box and the audio-HVAC display unit.
- Turn the ignition switch to LOCK (0).
- Disconnect climate control unit connector A (28P).
- Check for continuity between the following terminals of climate control unit connector A (28P) and the audio-HVAC display unit 12P connector. 28P: 12P: No. 19 No. 7 No. 20 No. 8 Is there continuity? YES -Go to step 7. NO -Repair an open in the wire(s) between climate control unit connector A (28P) and the audio-HVAC display unit 12P connector.
- Check for continuity between body ground and climate control unit connector A (28P) terminals No. 19 and No. 20 individually. Is there continuity? YES -Repair a short to body ground in the wire between climate control unit connector A (28P) and the audio-HVAC display unit 12P connector. NO -Go to step 8.
- Reconnect climate control unit connector A (28P).
- Connect audio-HVAC display unit 12P connector terminals No. 7 and No. 8 with a jumper wire.
- Turn the ignition switch to ON (II).
- Press and hold the WINDSHIELD DEFOGGER button and ON/OFF button.
- Check the WINDSHIELD DEFROSTER button LED. Is the WINDSHIELD DEFOGGER button LED blinking? YES -The audio-HVAC display unit is faulty, replace the audio-HVAC display unit (see «AUDIO-HVAC DISPLAY UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-v6) ). NO -The climate control unit is faulty, replace the climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
Scheme 122
Scheme 123
Scheme 124
Scheme 125
- Operate the climate control system in several modes. Is the climate control system OK? YES -Go to step 1 . NO -Do the Self-Diagnostic Function with the HDS (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITH THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ) or the climate control unit (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITHOUT THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ).
- Do the system links (see «SYSTEM LINKS»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-v6) ). Is the A/C or Mic icon red? YES - If A/C icon is red, go to step 3 . If Mic icon is red, go to "voice control does not work/respond" in the navigation system symptom troubleshooting (see «GPS ICON IS WHITE OR NOT SHOWN»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-v6__gps-icon-is-white-or-not) ). NO -Go to step 9 .
- Turn the ignition switch to LOCK (0).
- Disconnect audio-navigation unit connector D (20P).
- Disconnect climate control unit connector B (12P).
- Check for continuity between the following terminals of climate control unit connector B (12P) and audio-navigation unit connector D (20P). 12P: 20P: No. 7 No. 5 No. 8 No. 4 No. 9 No. 14 Is there continuity? YES -Go to step 7 . NO -Repair an open in the wire(s) between the climate control unit and the audio-navigation unit.
- Check for continuity between body ground and climate control unit connector B (12P) terminals No. 7, No. 8, and No. 9 individually. Is there continuity? YES -Repair a short to body ground in the wire(s) between the climate control unit and the audio-navigation unit. NO -Reconnect climate control unit connector B (12P), then go to step 9 .
- Turn the ignition switch to LOCK (0).
- Connect audio-navigation unit connector D (20P) terminals No. 4, No. 5, and No. 14 with jumper wires.
- Turn the ignition switch to ON (II).
- Press and hold the AUTO button, then press and hold the ON/OFF button, then turn the ignition switch to ON (II).
- Check the mode indicator displaying in the audio-navigation switch panel display. Is the HEAT/VENT indicator solid with the remaining icons blinking? YES -Substitute a known-good audio-navigation unit (including the HDD). If the symptom goes away, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-v6__audio-navigation-unit-removalinstallation) ). NO -Substitute a known-good climate control unit, and recheck. If the symptom goes away, replace the original climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
In-Car Temperature Sensor Test
Note. Before testing the sensor, check for climate control DTCs (see HOW TO CHECK FOR DTCS WITH THE HDS ).
Scheme 126
- Remove the in-car temperature sensor (see «IN-CAR TEMPERATURE SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
- Test the in-car temperature sensor while holding it in front of the dashboard center vent. Measure the resistance with the system set to Max Cool. Measure the resistance with the system set to Max Hot.
- Compare the resistance reading between terminals No. 1 and No. 2 of the in-car temperature sensor with the specifications shown in the graph; the resistance should be within the specifications.
- If the resistance is not as specified, replace the in-car temperature sensor (see «IN-CAR TEMPERATURE SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
Outside Air Temperature Sensor Test
Note. Before testing the sensor, check for climate control DTCs (see HOW TO CHECK FOR DTCS WITH THE HDS ).
Scheme 127
- Remove the outside air temperature sensor (see «OUTSIDE AIR TEMPERATURE SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
- Dip the sensor in ice water, and measure the resistance. Then pour warm water on the sensor, and check for a change in resistance.
- Compare the resistance reading between terminals No. 1 and No. 2 of the outside air temperature sensor with the specifications shown in the graph; the resistance should be within the specifications.
- If the resistance is not as specified, replace the outside air temperature sensor (see «OUTSIDE AIR TEMPERATURE SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
Sunlight Sensor Test
Note. When prying with a flat-tip screwdriver, wrap it with protective tape to prevent damage. Before testing the sensor, check for climate control DTCs (see HOW TO CHECK FOR DTCS WITH THE HDS ).
Scheme 128
- Remove the sunlight sensor (A) (see «SUNLIGHT SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__sunlight-sensor-replacement) ).
- Turn the ignition switch to ON (II). Measure the voltage between the terminals with the (+) probe on terminal No. 4 and the (-) probe on terminal No. 2 with the connector connected. NOTE: The voltage readings will not change under the light of a flashlight or a fluorescent lamp. Voltage should be: 3.6-3.7 V or more with the sensor out of direct sunlight. 3.3-3.5 V or less with the sensor in direct sunlight.
- If the voltage is not as specified, replace the sunlight sensor (see «SUNLIGHT SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__sunlight-sensor-replacement) ).
Evaporator Temperature Sensor Test
Note. Before testing the sensor, check for climate control DTCs (see HOW TO CHECK FOR DTCS WITH THE HDS ).
Scheme 129
Scheme 130
- Remove the evaporator temperature sensor (see «EVAPORATOR CORE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
- Dip the sensor in ice water, and measure the resistance between terminals No. 1 and No. 2.
- Pour warm water on the sensor, and measure the resistance.
- Compare the resistance readings with the specifications shown in the graph; the resistance should be within the specifications.
- If the resistance is not as specified, replace the evaporator temperature sensor (see «EVAPORATOR CORE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
Scheme 131
Scheme 132
- Remove the passenger's dashboard undercover (see «PASSENGER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__passengers-dashboard-undercover-removalinstallation) ). n
- Disconnect the 4P connector from the power transistor.
- Measure the resistance between terminals No. 3 and No. 4 of the power transistor. It should be about 1.5 kohms. If the resistance is within the specifications, go to step 4 . If the resistance is not within the specifications, replace the power transistor. NOTE: Also check the blower motor. Power transistor failure can be caused by a defective blower motor.
- Reconnect the 4P connector to the power transistor.
- Disconnect climate control unit connector A (28P) and B (12P).
- Connect climate control unit connector A (28P) terminal No. 9 and climate control unit connector B (12P) terminal No. 5 with a jumper wire.
- Turn the ignition switch to ON (II), and check that the blower motor runs. If the blower motor does not run, replace the power transistor. NOTE: A faulty blower motor can cause the power transistor to fail. If the power transistor is replaced, also check the blower motor for binding, and replace it (see «BLOWER UNIT COMPONENT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__blower-unit-component-replacement) ) if necessary. If the blower motor runs, the power transistor is OK.
Driver's Air Mix Control Motor Test
Special Tools Required
Backprobe Set 07SAZ-001000A
Note. Before testing the motor, check for climate control DTCs (see HOW TO CHECK FOR DTCS WITH THE HDS ).
Scheme 133
- Disconnect the 7P connector from the driver's air mix control motor. NOTE: Incorrectly applying power and ground to the air mix control motor will damage it. Follow the instructions carefully.
- Connect battery power to terminal No. 1 of the driver's air mix control motor, and ground terminal No. 2; the driver's air mix control motor should run, and stop at Max Hot. If it does not, reverse the connections; the driver's air mix control motor should run, and stop at Max Cool. When the driver's air mix control motor stops running, disconnect battery power immediately.
- If the driver's air mix control motor did not run in step 2 , remove it, then check the driver's air mix control linkage and door for smooth movement. If the linkage and door move smoothly, replace the driver's air mix control motor (see «DRIVER'S AIR MIX CONTROL MOTOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ). If the linkage or door sticks or binds, repair them as needed. If the air mix control motor runs smoothly, go to step 4 .
- Measure the resistance between terminals No. 5 and No. 7 of the driver's air mix control motor. It should be between 4.2 and 7.8 kohms.
- Reconnect the air mix control motor 7P connector, then turn the ignition switch to ON (II).
- Using the backprobe set (07SAZ-001000A), measure the voltage between terminals No. 3 and No. 7. Max Cool: About 0.5 V Max Hot: About 4.5 V
- If either the resistance or the voltage readings are not as specified, replace the driver's air mix control motor (see «DRIVER'S AIR MIX CONTROL MOTOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
Passenger's Air Mix Control Motor Test
Special Tools Required
Backprobe Set 07SAZ-001000A
Note. Before testing the motor, check for climate control DTCs (see HOW TO CHECK FOR DTCS WITH THE HDS ).
Scheme 134
- Disconnect the 7P connector from the passenger's air mix control motor. NOTE: Incorrectly applying power and ground to the passenger's air mix control motor will damage it. Follow the instructions carefully.
- Connect battery power to terminal No. 1 of the passenger's air mix control motor, and ground terminal No. 2; the passenger's air mix control motor should run, and stop at Max Cool. If it does not, reverse the connections; the passenger's air mix control motor should run, and stop at Max Hot. When the passenger's air mix control motor stops running, disconnect battery power immediately.
- If the passenger's air mix control motor did not run in step 2 , remove it, then check the passenger's air mix control linkage and door for smooth movement. If the linkage and door move smoothly, replace the passenger's air mix control motor (see «PASSENGER'S AIR MIX CONTROL MOTOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ). If the linkage or door sticks or binds, repair them as needed. If the passenger's air mix control motor runs smoothly, go to step 4 .
- Measure the resistance between terminals No. 5 and No. 7 of the passenger's air mix control motor. It should be between 4.2 and 7.8 kohms.
- Reconnect the passenger's air mix control motor 7P connector, then turn the ignition switch to ON (II).
- Using the backprobe set (07SAZ-001000A), measure the voltage between terminals No. 3 and No. 5. Max Cool: About 1.5 V Max Hot: About 4.5 V
- If either the resistance or the voltage readings are not as specified, replace the passenger's air mix control motor (see «PASSENGER'S AIR MIX CONTROL MOTOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
Mode Control Motor Test
Special Tools Required
Backprobe Set 07SAZ-001000A
Note. Before testing the motor, check for climate control DTCs (see HOW TO CHECK FOR DTCS WITH THE HDS ).
Scheme 135
- Disconnect the 7P connector from the mode control motor. NOTE: Incorrectly applying power and ground to the mode control motor will damage it. Follow the instructions carefully.
- Connect battery power to terminal No. 1 of the mode control motor, and ground terminal No. 2; the mode control motor should run, and stop at Defrost. If it does not, reverse the connections; the mode control motor should run, and stop at Vent. When the mode control motor stops running, disconnect battery power immediately.
- If the mode control motor did not run in step 2 , remove it, then check the mode control linkage and door for smooth movement. If the linkage and door move smoothly, replace the mode control motor (see «MODE CONTROL MOTOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ). If the linkage or door sticks or binds, repair them as needed. If the mode control motor runs smoothly, go to step 4 .
- Measure the resistance between terminals No. 5 and No. 7 of the mode control motor. It should be between 4.2 and 7.8 kohms.
- Reconnect the mode control motor 7P connector, then turn the ignition switch to ON (II).
- Using the backprobe set (07SAZ-001000A), measure the voltage between terminals No. 3 and No. 7. Vent: About 0.5 V Defrost: About 4.5 V
- If either the resistance or voltage readings are not as specified, replace the mode control motor (see «MODE CONTROL MOTOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
Recirculation Control Motor Test
Special Tools Required
Backprobe Set 07SAZ-001000A
Note. Before testing the motor, check for climate control DTCs (see HOW TO CHECK FOR DTCS WITH THE HDS ).
Scheme 136
- Disconnect the 7P connector from the recirculation control motor. NOTE: Incorrectly applying power and ground to the recirculation control motor will damage it. Follow the instructions carefully.
- Connect battery power to terminal No. 1 of the recirculation control motor, and ground terminal No. 2; the recirculation control motor should run, and stop at Fresh. If it does not, reverse the connections; the recirculation control motor should run, and stop at Recirculate. When the recirculation control motor stops running, disconnect battery power immediately.
- If the recirculation control motor did not run in step 2 , remove it, then check the recirculation control linkage and door for smooth movement. If the linkage and door move smoothly, replace the recirculation control motor (see «RECIRCULATION CONTROL MOTOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ). If the linkage or door sticks or binds, repair them as needed. If the recirculation control motor runs smoothly, go to step 4 .
- Measure the resistance between terminals No. 5 and No. 7 of the recirculation control motor. It should be between 4.2 and 7.8 kohms.
- Reconnect the recirculation control motor 7P connector, then turn the ignition switch to ON (II).
- Using the backprobe set (07SAZ-001000A), measure the voltage between terminals No. 3 and No. 5. Fresh: About 1.0 V Recirculate: About 4.0 V
- If either the resistance or voltage readings are not as specified, replace the recirculation control motor (see «RECIRCULATION CONTROL MOTOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
Scheme 137
Scheme 138
Scheme 139
- Check the pressure plate for discoloration, peeling, or other damage. If there is damage, replace the clutch set (see «A/C COMPRESSOR CLUTCH OVERHAUL»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__ac-compressor-clutch-overhaul) ).
- Check the pulley bearing play and drag by rotating the pulley by hand. Also check for grease leakage from the bearing. Replace the clutch set with a new one if it is noisy, has excessive play/drag, or has bearing grease contamination on the clutch faces (see «A/C COMPRESSOR CLUTCH OVERHAUL»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__ac-compressor-clutch-overhaul) ). NOTE: The pulley and the pressure plate were mated at the factory by a burnishing operation. Always replace the pulley and the pressure plate as a set. Replacing only one part of the clutch set will cause clutch slippage.
- Measure the clearance between the rotor pulley (A) and the pressure plate (B) all the way around. If the clearance is not within specified limits, remove the pressure plate (see «A/C COMPRESSOR CLUTCH OVERHAUL»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__ac-compressor-clutch-overhaul) ) and add or remove shims as needed to increase or decrease clearance. Clearance: 0.35-0.60 mm (0.0138-0.0236 in) NOTE: The shims are available in three thicknesses: 0.1 mm, 0.3 mm, and 0.5 mm.
- Remove the pressure plate (see «A/C COMPRESSOR CLUTCH OVERHAUL»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__ac-compressor-clutch-overhaul) ), and inspect the pressure plate and pulley friction surface for wear. If there is excessive wear, roughness, or scoring, replace the clutch set.
- Inspect the friction surfaces and the A/C compressor shaft hub for excess oil. If excess oil is present, and it is not from the engine or power steering system, then the A/C compressor shaft seal is leaking. In that case, replace the A/C compressor (see «A/C COMPRESSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__ac-compressor-replacement) ).
- Measure the resistance of the field coil. If resistance is not within specifications, replace the field coil (see «A/C COMPRESSOR CLUTCH OVERHAUL»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__ac-compressor-clutch-overhaul) ). Field Coil Resistance: 3.9-4.3 ohms at 68°F (20°C)
Refrigerant Leak Check
Special Tools Required
- Leak Detector YGK-H-10PM*
- Leak Detector HLD-100*
- Leak Detector TIFZX-1*
- OPTIMAX Jr. A/C Leak Detection Kit TRP124893*
*: These tools are available through the Acura Tool and Equipment Program; call 888-424-6857
| CAUTION | Air conditioning refrigerant or lubricant vapor can irritate your eyes, nose, or throat. Be careful when connecting service equipment. Do not breathe refrigerant or vapor. Do not operate the leak detector near flammable vapors. Its sensor operates at high temperatures, and could ignite the vapors, resulting in personal injury and/or damage to the equipment. |
Note. If accidental system discharge occurs, ventilate the work area before resuming service. Additional health and safety information may be obtained from the refrigerant and lubricant manufacturers. Check the system for leaks using an R-134a refrigerant leak detector with an accuracy of 14 g (0.5 oz) per year or better.
Leak Detector Usage Tips (Refer to the Operator's Manual for complete operating instructions)
- Position the vehicle in a wind-free work area. This will aid in detecting small leaks.
- When using the leak detector for the first time, allow it to warm up for 2 minutes with the probe in a clean atmosphere. This lets the temperature sensor in the detector stabilize.
- The calibration check should be done in the "Search 2" mode. Once that is done, the other check modes do not need calibrating.
- When leak checking through the HVAC module drain hose, avoid drawing water into the probe. Water can damage the internal pump and sensor.
- Avoid creasing the flexible probe extension. Creases can restrict air flow and give false readings.
- Because the detector recalibrates itself for ambient gases, it may be necessary to move the detector away from the leak to clear the sensor. Once the sensor has cleared, recheck the suspected leak.
- When removing the clear probe tip, be careful not to lose the flow ball.
- R-134a is heavier than air; always check below and to the sides of all potential leak sources.
- Halogen leak detectors are sensitive to chemicals: windshield washing solutions, solvents/cleaners, and some vehicle adhesives. Keep these chemicals out of the area when doing leak detection.
Fluorescent Dye Usage Tips
- Use only Tracer-Stick single dose fluorescent dye capsules from Tracerline®. Other dyes contain solvents that may contaminate the refrigerant oil, leading to component failure.
- Adding excessive amounts of dye can damage the A/C compressor.
- PAG oil is water soluble, so condensation on the evaporator core or the refrigerant lines may wash the PAG oil and fluorescent dye away from the actual leak. Condensation may also carry dye through the evaporator module drain.
- After checking and repairing leaks, thoroughly clean any residual dye from the areas where leaks were found. Use GLO-AWAY dye cleaner, from Tracerline®, and hot water to remove the dye (follow the instructions on the bottle). Residual dye stains can cause misdiagnosis of any future A/C system leaks.
- If any refrigerant dye contacts an exterior paint surface, remove it by doing this: Carefully wash the affected surfaces to remove any dirt, and to prevent paint scratching Mix water and isopropyl alcohol in a 50/50 mixture. Soak a soft cotton towel with the water/alcohol mixture, and place the cloth on the affected areas to remove the dye After removing the dye with the water/alcohol-soaked cloth, carefully wash the affected areas, and check that there is no remaining dye
Scheme 140
- Connect an R-134a refrigerant recovery/recycling/charging station (A) to the high-pressure service port (B) and the low-pressure service port (C), as shown, following the equipment manufacturer's instructions.
- Recover refrigerant from the A/C system (see «REFRIGERANT RECOVERY»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__refrigerant-recovery) ), and evacuate the system (see «SYSTEM EVACUATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__system-evacuation) ). If the system achieves a vacuum of approximately -93.3 kPa (-700 mmHg, 27.6 inHg) in 15 minutes, and holds the vacuum for 15 minutes, then the system does not have a leak at this time. If the system cannot achieve or hold a vacuum, continue the refrigerant leak check.
- Open the high pressure valve to charge the system to the specified capacity. Select the appropriate units of measure for your refrigerant charging station. Refrigerant Capacity: 450 to 500 g 0.45 to 0.50 kg 1.0 to 1.1 lbs 15.8 to 17.6 oz
- With the engine OFF, use a halogen leak detector first to detect the leak source. Follow a continuous path in order to ensure that you will not miss any possible leaks. Test the following areas of the system for leaks: DIAGNOSTIC PROCEDURE Possible Leak Area Diagnostic Procedure with the Leak Detector Notes Service ports Check the service ports If the detector "sniffs" a leak, use fluorescent dye to confirm it When capping the service ports, ensure that the seals on the port caps are in place, and that the caps are tight. The caps are used as the final seals in the system A/C condenser If the detector "sniffs" a leak, use fluorescent dye to confirm it Check for joints or connections coated with oily dust Check for damaged and corroded areas Check all fittings, couplings, brazed/welded areas and areas around attachment points Move the probe slowly (1 inch/second or less), and keep it within 1/4 inch of the component being checked. This maximizes the chance of detecting a leak If you detect a leak, blow compressed air over the area, then recheck for leaks. For large leaks, cleaning the area with compressed air may help you pinpoint the leak source Evaporator Check at the evaporator drain hose Check at the passenger's side vent and turn the blower on low speed A/C lines Wiggle the rubber hoses when checking crimped metal ends If the detector "sniffs" a leak, use fluorescent dye to confirm it Check all fittings, couplings, pressure switches, brazed/welded areas, and areas around attachment points on A/C lines and components Check for damaged and corroded areas Move the probe slowly (1 inch/second or less), and keep it within 1/4 inch of the component being checked. This maximizes the chance of detecting a leak
- Close the quick coupler valves, then disconnect the quick couplers from the vehicle service ports.
- Attach the universal connect set, from the Optimax Jr. Leak Detection Kit, to the service valve fitting. Close the control valve (the black knob on the connect set).
- Attach the charging station low pressure hose quick coupler to the service valve fitting, and open the quick coupler valve. Evacuate the connect set using the charging station vacuum pump, then close the quick coupler valve.
- Detach the universal connect set, and install a Tracer-Stick® dye capsule between the connect set and the service valve fitting (see the manufacturer's instructions for more detail).
- Attach the quick coupler on the universal connect set to the low pressure service port on the vehicle. Open the charging station low pressure hose quick coupler valve, but do not open the control valve.
- Start the engine, and set the A/C system to maximum cooling. Open the control valve to let refrigerant and the dye enter the A/C system through the low pressure service port. Close the control valve when the Tracer-Stick® dye capsule is empty.
- Run the engine and A/C system for 15 minutes to thoroughly circulate the dye. Then shut the engine off, and inspect the following areas of the system for leaks. NOTE: Check for leaks in a dark work area, and use the UV light and the special glasses from the leak check kit. Other UV lights may not work well with the Tracer-Stick® dye. Small leaks may take up to 1 week of vehicle operation (with normal A/C use) to become visible. DIAGNOSTIC PROCEDURE Possible Leak Area Diagnostic Procedure with Fluorescent Dye Service ports If a leak is found, replace the cap/o-ring seal or A/C line as needed A/C lines Use a permanent marker pen to circle the leak area If a leak is found, remove and replace the A/C line (see «A/C LINE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ) A/C condenser If a leak is found, remove the A/C condenser (see «A/C CONDENSER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ) Determine whether leak is in the A/C condenser or the receiver/dryer Use a permanent marker pen to circle the leak area Replace either the receiver/dryer (see «RECEIVER/DRYER DESICCANT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__receiverdryer-desiccant-replacement) ), or the A/C condenser (see «A/C CONDENSER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ), depending upon which is leaking A/C compressor Check for leaks at all of the A/C compressor joints, the clutch center, the A/C compressor front housing bolts, and the scroll bolts on the back of the A/C compressor If the A/C compressor relief valve appears to be leaking, determine whether the leak is coming from the relief valve, or the joint between the A/C compressor casing and the valve If the leak is from the relief valve, diagnose and repair the cause of excessive A/C system pressure, then replace the A/C compressor relief valve (see «A/C COMPRESSOR RELIEF VALVE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__ac-compressor-relief-valve-replacement) ) If the leak is from the casing/valve joint, replace the A/C compressor relief valve (see «A/C COMPRESSOR RELIEF VALVE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__ac-compressor-relief-valve-replacement) ) If the leak is coming from the suction hose and/or discharge hose fittings on the A/C compressor, clean the A/C fittings and replace the suction/discharge fitting O-rings For all other A/C compressor leaks, remove and replace the A/C compressor (see «A/C COMPRESSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__ac-compressor-replacement) ) Evaporator Start checking for evaporator leaks by illuminating the evaporator drain tube area. Let the vehicle sit for 30 minutes with the engine off, and the doors and windows closed. Then place the detector probe in the center vent, and turn the fan on to low speed If a leak is found, remove the evaporator core (see «EVAPORATOR CORE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ) Determine whether leak is from the evaporator or the expansion valve Use a permanent marker pen to circle the leak area Replace the expansion valve (see «EXPANSION VALVE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ), or the evaporator core (see «EVAPORATOR CORE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ), depending upon which is leaking
A/C System Noise Check
| CAUTION | Air conditioning refrigerant or lubricant vapor can irritate your eyes, nose, or throat. Be careful when connecting service equipment. Do not breathe refrigerant or vapor. |
The A/C system noise check will help you determine the source of abnormal A/C system noise.
Note. If accidental system discharge occurs, ventilate the work area before resuming service. Additional health and safety information may be obtained from the refrigerant and lubricant manufacturers. Identify the conditions when the noise occurs. The weather, the vehicle speed, the vehicle being in gear or in neutral, the engine temperature, or other conditions may be factors in determining the noise source. Do the A/C system inspection (see A/C SYSTEM INSPECTION ), and correct any problems found prior to diagnosing abnormal noises. Abnormal A/C noises can be misleading. For example, a sound similar to a failed bearing may be caused by loose fasteners, loose mounting brackets, or a faulty A/C compressor clutch assembly.
- Inspect the air inlet grille in the cowl cover for debris. If debris is present, remove it.
- Sit inside the vehicle, close the doors and windows, and turn the ignition switch to ON (II), but do not start the engine. Cycle the HVAC system through all blower speeds and all air distribution modes to determine where and when the noise occurs.
- Operate the blower at each speed with the engine and A/C off, and check for unusual noises and excessive vibration. If noise and/or vibration are present, do the following checks: If the noise or vibration occurs only in a specific mode or setting, then check these items: Operation of the mode control motor, door, and linkage Operation of the air mix control motor(s), door(s), and linkage Operation of the recirculation control motor, door, and linkage If there is a squeaking or chirping noise, but no unusual vibration, replace the blower motor (see «BLOWER UNIT COMPONENT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__blower-unit-component-replacement) ). Remove the blower unit (see «BLOWER UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ), and check for foreign material (leaves or twigs, for example) on the blower motor and fan. If foreign material is present, remove it, and recheck for noise. If you do not find any foreign material, remove the blower motor (see «BLOWER UNIT COMPONENT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__blower-unit-component-replacement) ), and check these items: Check if the fan blades are cracked or broken Make sure the fan retainer is tight Inspect the fan alignment on the blower motor shaft Replace the blower motor if any problems are present.
- Set up the vehicle for the running A/C checks: Select a quiet area for testing Apply the parking brake Shift the vehicle to P or N Start the engine Set the temperature control switch to Max Cool Set the mode control button to VENT Set the fan control button to minimum (but not OFF) Turn the air conditioning button ON Switch the A/C compressor on and off several times to clearly identify the sound during A/C compressor operation. Listen to the noise while the A/C compressor clutch is engaged and disengaged. Probe the A/C system with a stethoscope to pinpoint the noise. NOTE: If the noise does not change when the A/C compressor clutch engages or disengages, the noise may be caused by an engine-related component. Probe the engine area with a stethoscope to pinpoint the noise.
- Turn the ignition switch to LOCK (0), and check the drive belt for excessive wear, oil contamination, improper routing, or a faulty belt tensioner (see «DRIVE BELT AUTO-TENSIONER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/charging-system/#charging-system-v6) ). Correct any problems found. Start the engine, run the A/C system, and check if the noise is coming from the drive belt, the belt tensioner or any of the pulleys. Repair or replace any faulty components.
- Listen for noises coming from the A/C lines, the A/C hoses, the A/C condenser, the evaporator, the receiver/dryer, or the expansion valve, and check these items: Noises caused by A/C components touching other components or the body. Reroute or insulate the A/C component(s) as needed, and recheck for noise. Loose, damaged or excessively worn A/C components or mounting hardware. Repair or replace the faulty component(s) or hardware, and recheck for noise. A moaning noise from the A/C suction line. If there is a moaning noise, check the system refrigerant charge (see «A/C SYSTEM TEST»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__ac-system-test) ). If the refrigerant charge is OK, replace the receiver/dryer (see «RECEIVER/DRYER DESICCANT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__receiverdryer-desiccant-replacement) ). A whistling or hissing noise from the expansion valve. Evacuate the system for 3 hours (see «SYSTEM EVACUATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__system-evacuation) ), then recheck. If the noise is still present, replace the expansion valve (see «EXPANSION VALVE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
- Check the operation of the A/C compressor clutch: Make sure the A/C compressor clutch engages without slipping. If the clutch does not engage, troubleshoot the A/C compressor clutch circuit (see «A/C COMPRESSOR CLUTCH CIRCUIT TROUBLESHOOTING»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__ac-compressor-clutch-circuit-troubleshooting) ). If the A/C compressor clutch slips, replace the A/C compressor clutch assembly (see «A/C COMPRESSOR CLUTCH OVERHAUL»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__ac-compressor-clutch-overhaul) ). And if there is a leak from the shaft seal when the A/C compressor clutch slips, replace the A/C compressor also (see «A/C COMPRESSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__ac-compressor-replacement) ). Make sure the A/C compressor clutch disengages. If the clutch does not disengage, do the A/C compressor clutch circuit troubleshooting (see «A/C COMPRESSOR CLUTCH CIRCUIT TROUBLESHOOTING»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__ac-compressor-clutch-circuit-troubleshooting) ). If the clutch circuit is OK, do the A/C compressor clutch check (see «A/C COMPRESSOR CLUTCH CHECK»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ), and see if the clutch is mechanically jammed. If there are no electrical or mechanical problems with the A/C compressor clutch, replace the A/C compressor (see «A/C COMPRESSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__ac-compressor-replacement) ). Make sure the A/C compressor clutch cycles normally. If the A/C compressor clutch is cycling rapidly, the A/C system is probably low on refrigerant due to a leak. Do the refrigerant leak check (see «REFRIGERANT LEAK CHECK»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__refrigerant-leak-check) ). If the refrigerant charge is OK, and there are no leaks, troubleshoot the A/C compressor clutch circuit (see «A/C COMPRESSOR CLUTCH CIRCUIT TROUBLESHOOTING»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__ac-compressor-clutch-circuit-troubleshooting) ).
- Listen with a stethoscope for noises coming from the A/C compressor, and check these items: The noise changes when the A/C compressor clutch disengages. If the noise does not change when the A/C compressor disengages, the noise may be caused by an engine-related component. Probe the engine area with a stethoscope to pinpoint the noise. The A/C system operating pressures are normal. If the system pressures are abnormal, troubleshoot the problem using the pressure test table in the A/C system test (see «A/C SYSTEM TEST»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__ac-system-test) ). Correct the pressure-related problem(s), and recheck for noise. The A/C compressor hose connections, mounting brackets, and fasteners are in good condition. If any of these components are loose, damaged, or excessively worn, repair or replace the faulty component(s), and recheck for noise. If these components are in good condition, and the noise is still present, replace the A/C compressor (see «A/C COMPRESSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__ac-compressor-replacement) ).
A/C System Test
Special Tools Required
- Big Digit Hygro-Thermometer PYR445703, commercially available
- Throttle Pedal Depressor Tool B240B, commercially available
Performance Test
| CAUTION | Air conditioning refrigerant or lubricant vapor can irritate your eyes, nose, or throat. Be careful when connecting service equipment. Do not breathe refrigerant or vapor. |
The performance test will help determine if the A/C system is operating within specifications.
Note. If accidental system discharge occurs, ventilate the work area before resuming service. Additional health and safety information may be obtained from the refrigerant and lubricant manufacturers.
Scheme 141
Scheme 142
Scheme 143
Scheme 144
- Do the A/C system inspection (see «A/C SYSTEM INSPECTION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__ac-system-inspection) ), and correct any problems found.
- Connect an R-134a refrigerant recovery/recycling/charging station to the high-pressure service port and the low-pressure service port, following the equipment manufacturer's instructions.
- Determine the relative humidity and air temperature.
- Remove the passenger's dashboard trim (see «SPEAKER COVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__speaker-cover-removalinstallation) ), then remove the glove box (see «GLOVE BOX SEPARATOR REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__glove-box-separator-removalinstallation) ).
- Insert a thermometer (A) in the center vent.
- Place a thermometer (B) near the blower unit's recirculation inlet duct.
- Test conditions: Move the vehicle out of direct sunlight and let it cool down to the surrounding (ambient) temperature. If necessary, wash the vehicle to cool it down more quickly. The ambient temperature must be at least 60°F (16°C). Open the hood. Open the front doors. Start the engine. Set the temperature control switch to Max Cool, the mode control button to Vent, and the recirculation control button to Recirculate. Turn the air conditioning button ON and the fan control button to Max. Hold the engine speed at 1,500 rpm. No driver or passengers in the vehicle.
- Inspect the A/C components for the following conditions: A/C compressor clutch not engaged. Abnormal frost areas. Unusual noises. If you observe any of these conditions, refer to the «SYMPTOM TROUBLESHOOTING INDEX»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__symptom-troubleshooting-index) .
- After running the air conditioning for 10 minutes under the above test conditions, read the delivery temperature from the thermometer in the center vent, the intake temperature near the blower unit, and the discharge (high) and suction (low) pressures on the A/C gauges.
- To complete the vent (delivery)/ambient air (intake) temperature chart: Mark the vent (delivery) temperature on the vertical line. Mark the ambient air (intake) temperature on the bottom line. Draw a vertical line from the ambient air (intake) temperature mark. Draw a horizontal line from the vent (delivery) temperature mark until it intersects the vertical line. NOTE: The vent temperature and the ambient air temperature should intersect in the shaded area. Any measurements outside the area may indicate the need for further inspection.
- To complete the high side (discharge) pressure/ambient air (intake) temperature chart: Mark the high side (discharge) pressure on the vertical line. Mark the ambient air (intake) temperature on the bottom line. Draw a vertical line from the ambient air (intake) temperature mark. Draw a horizontal line from the high side (discharge) pressure mark until it intersects the vertical line. NOTE: The high side pressure and the ambient air temperature should intersect in the shaded area. Any measurements outside the area may indicate the need for further inspection.
- To complete the low side (suction) pressure/ambient air (intake) temperature chart: Mark the low side (suction) pressure along the vertical line. Mark the ambient air (intake) temperature along the bottom line. Draw a vertical line from the ambient air (intake) temperature mark. Draw a horizontal line from the low side (suction) pressure mark until it intersects the vertical line. NOTE: The low side pressure and the ambient air temperature should intersect in the shaded area. Any measurements outside the area may indicate the need for further inspection.
Pressure Test
| Test Results | Related Symptoms | Probable Cause |
|---|---|---|
| Driver and passenger's side A/C vent temperatures may vary by approximately 20°F (11°C) or more | Suction pressure may be low | Low refrigerant charge Expansion valve not opening sufficiently |
| Driver's or passenger's air mix door DTCs present | One air mix door stuck or inoperative | |
| Discharge pressure abnormally High | Discharge pressure reduced when A/C condenser cooled with water spray | Significant refrigerant overcharge |
| Restricted/weak airflow through A/C condenser With doors open, fresh air selected and radiator and A/C condenser fan run on high speed, temperature drop across A/C condenser inlet to outlet is less than 41°F (5°C) | Dirty A/C condenser or damaged fins Debris between A/C condenser and radiator One or more cooling fans malfunctioning | |
| Discharge pressure abnormally Low | Suction and discharge pressures equalize rapidly after stopping A/C compressor Suction pressure higher than normal | Faulty A/C compressor discharge valve or seal |
| Suction pressure abnormally Low | Weak or insufficient airflow across evaporator | Restricted blower intake or dust and pollen filter |
| Suction pressure varies from near normal to a vacuum, as moisture freezes in expansion valve orifice | Moisture in the system Faulty expansion valve | |
| Reduced airflow from vents Vent temperature is very low | Condensation freezing on evaporator Faulty evaporator temperature sensor (check DTC) Faulty expansion valve or A/C compressor clutch relay | |
| Suction pressure abnormally High | Lack of slight suction pressure variation at 1,500 rpm when "Recirculated" airflow is switched to "Fresh Air" Discharge pressure near normal | Expansion valve stuck open or open too long |
| Suction and Discharge pressures abnormally High | Sheet of paper does not stick to front of A/C condenser surface with cooling fans on With doors open, fresh air selected and radiator and A/C condenser fan run on high speed, temperature drop across A/C condenser inlet to outlet is less than about 41°F (5°C) | One (or both) cooling fan motor inoperative or wires reversed |
| A/C compressor clutch remains engaged during off cycle Pressure relief valve may open | Insufficient A/C compressor clutch clearance A/C compressor clutch relay or circuit problem Excessive air in system |
PRESSURE TEST RESULTS CHART
| Test Results | Related Symptoms | Probable Cause |
|---|---|---|
| Suction and Discharge pressures abnormally Low | Suction line from expansion valve to A/C compressor is not cold | Excessively low refrigerant charge |
| Lack of slight suction pressure variation at 1,500 rpm when "Recirculated" airflow is switched to "Fresh Air" | Expansion valve clogged with debris/desiccant, stuck closed, or not opening sufficiently | |
| More than 50-60°F (10-16°C) temperature drop across A/C condenser inlet to outlet pipes | Blocked or restricted A/C condenser internal passages or lines/components restricting refrigerant flow | |
| Significant temperature difference along high or low side A/C lines or components NOTE: Some restrictions may not show up until 3,000 rpm | Restriction in A/C suction or discharge lines or components (check temperatures to isolate) | |
| Suction pressure High and Discharge pressure Low | Excessive A/C compressor noise Pressures equalize quickly and noise after A/C compressor turns off | A/C compressor internal damage (Check for A/C system debris contamination) |
| Suction and Discharge pressures normal (or near normal) | Vent temperature too high | Slightly low refrigerant charge Air mix door sticking, misadjusted or inoperative Excessive refrigerant oil in system |
| Static pressures high with A/C system equalized. (After engine is off 4-12 hours) | Air/Non-condensable gasses in system Contaminated or incorrect refrigerant |
| NOTE |
|---|
| Some restrictions may not show up until 3,000 rpm |
PRESSURE TEST RESULTS CHART
Scheme 145
Scheme 146
Scheme 147
Scheme 148
- Recover the refrigerant with a recovery/recycling/charging station (see «REFRIGERANT RECOVERY»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__refrigerant-recovery) ).
- Remove the front bumper (see «FRONT BUMPER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#bumpers-v6__front-bumper-removalinstallation) ).
- Remove the bolt, then disconnect the receiver pipe (A) from the A/C condenser. Remove the O-ring (B).
- Remove the bolts and the radiator upper mount brackets (A).
- Remove the bolt, then disconnect the discharge hose (A) from the A/C condenser. Remove the O-ring (B).
- Remove the bolts, then remove the A/C condenser (A) by lifting it up. Be careful not to damage the radiator or A/C condenser fins when removing the A/C condenser.
- Install the A/C condenser in the reverse order of removal, and note these items: If you're installing a new A/C condenser, add refrigerant oil (DENSO ND-OIL 8) (see «A/C REFRIGERANT OIL REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__ac-refrigerant-oil-replacement) ). Replace the O-rings with new ones at each fitting, and apply a thin coat of refrigerant oil before installing them. Be sure to use the correct O-rings for HFC-134a (R-134a) to avoid leakage. Immediately after using the oil, reinstall the cap on the container, and seal it to avoid moisture absorption. Do not spill the refrigerant oil on the vehicle; it may damage the paint; if the refrigerant oil contacts the paint, wash it off immediately. Be careful not to damage the radiator or the A/C condenser fins when installing the A/C condenser. Charge the system (see «SYSTEM CHARGING»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__system-charging) ).
Receiver/Dryer Desiccant Replacement
Note. Install the receiver/dryer as quickly as possible to prevent the system from absorbing moisture from the air.
Scheme 149
- Remove the A/C condenser (see «A/C CONDENSER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
- Remove the cap (A) from the bottom of the A/C condenser. Remove the O-ring (B) and the desiccant (C).
- Install the receiver/dryer desiccant in the reverse order of removal, and note these items: If you are installing a new desiccant, add refrigerant oil (DENSO ND-OIL 8) (see «A/C REFRIGERANT OIL REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__ac-refrigerant-oil-replacement) ). Replace the O-rings with new ones, and apply a thin coat of refrigerant oil (DENSO ND-OIL 8) before installing them. Be sure to use the correct O-rings for HFC-134a (R-134a) to avoid leakage. Install the cap to the specified torque. It is made of plastic and can be easily stripped.
A/C Compressor Replacement
Note. Do not install the A/C compressor into a system unless you are completely sure that the system is free of contamination. Installing the A/C compressor into a contaminated system can result in premature A/C compressor failure.
Scheme 150
Scheme 151
- If the A/C compressor is marginally operable, run the engine at idle speed, and let the air conditioning work for a few minutes, then shut the engine off.
- Recover the refrigerant with a recovery/recycling/charging station (see «REFRIGERANT RECOVERY»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__refrigerant-recovery) ).
- Remove the A/C condenser fan shroud (see «FAN, FAN MOTOR, AND SHROUD REMOVAL AND INSTALLATION»(/acura/tsx/ii-2008-2014/remont/cooling-fan/#engine-cooling-system-v6) ). NOTE: To avoid damage to the radiator, cover it with cardboard after removing the fan shroud.
- Remove the alternator (see «ALTERNATOR REMOVAL AND INSTALLATION»(/acura/tsx/ii-2008-2014/remont/charging-system/#charging-system-v6) ).
- Disconnect the A/C compressor clutch connector (A). Remove the bolts and the nut, then disconnect the suction hose (B) and the discharge hose (C) from the A/C compressor. Remove the O-rings (D). Plug or cap the lines immediately after disconnecting them to avoid moisture and dust contamination.
- Remove the mounting bolts and the A/C compressor (A). Be careful not to damage the radiator fins when removing the A/C compressor.
- Install the A/C compressor in the reverse order of removal, and note these items: Before installing a new A/C compressor, adjust the A/C compressor oil level (see «A/C REFRIGERANT OIL REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__ac-refrigerant-oil-replacement) ). Inspect the A/C lines for any signs of contamination. If you are installing a new A/C compressor, you must calculate the amount of refrigerant oil to be removed from it (see «A/C REFRIGERANT OIL REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__ac-refrigerant-oil-replacement) ). A new A/C compressor comes with a full charge of oil. Replace the O-rings with new ones at each fitting, and apply a thin coat of refrigerant oil before installing them. Be sure to use the correct O-rings for HFC-134a (R-134a) to avoid leakage. Use only refrigerant oil (DENSO ND-OIL 8) for HFC-134a DENSO A/C compressors only. To avoid contamination, do not return the oil to the container once dispensed, and never mix it with other refrigerant oils. Immediately after using the oil, reinstall the cap on the container, and seal it to avoid moisture absorption. Do not spill the refrigerant oil on the vehicle; it may damage the paint; if the refrigerant oil contacts the paint, wash it off immediately. Be careful not to damage the radiator fins when installing the A/C compressor and the A/C condenser fan shroud. Charge the system (see «SYSTEM CHARGING»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__system-charging) ).
A/C Compressor Clutch Overhaul
Special Tools Required
A/C Compressor Kit 07AAF-000A150
Scheme 152
Scheme 153
Scheme 154
Scheme 155
- Remove the center bolt (A) while holding the pressure plate with the A/C clutch holder (B).
- Remove the pressure plate (A) and the shim(s) (B), taking care not to lose the shim(s). If the clutch needs adjustment, increase or decrease the number and thickness of shims as necessary, then reinstall the pressure plate, and recheck its clearance (see «A/C COMPRESSOR CLUTCH CHECK»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ). NOTE: The shims are available in three thicknesses: 0.1 mm, 0.3 mm, and 0.5 mm. Do not pry on the pressure plate with screwdrivers or similar tools. Prying damages the pressure plate and the pulley. When replacing the clutch set, place a trial stack of shims, 1 mm total thickness, on the A/C compressor shaft. Install the pressure plate, and check its clearance (see «A/C COMPRESSOR CLUTCH CHECK»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ). If the clearance is not with specification, add or subtract shims as needed.
- If you are replacing the field coil, remove the snap ring (A) with snap ring pliers, then remove the pulley (B). Be careful not to damage the pulley or the A/C compressor. NOTE: Do not hammer or pry on the pulley to remove it. Using a hammer damages the A/C compressor. If the pulley is difficult to remove, use the pulley removing tool. Make sure the jaws of the pulling tool engage the back face of the pulley, not the pulley grooves.
- Remove the screw from the field coil ground terminal (A), then remove the wire harness (B) and the bracket (C). Disconnect the field coil connector (D). Remove the snap ring (E) with snap ring pliers, then remove the field coil (F). Be careful not to damage the field coil or the A/C compressor.
- Reassemble the clutch in the reverse order of disassembly, and note these items: When replacing the field coil, check that the new coil has the correct resistance (see step 6 ). Install the field coil with the wire side facing down, and align the boss on the field coil with the hole in the A/C compressor. Clean the pulley and A/C compressor friction surfaces with contact cleaner or other non-petroleum solvent. Install new snap rings, note the installation direction, and make sure they are fully seated in the grooves. Make sure that the pulley turns smoothly after it's reassembled. Route and clamp the wires properly to prevent damage by the pulley.
- After reinstallation, cycle the A/C clutch approximately 20 times by running the engine at 1,500-2,000 rpm and setting the climate control temperature to Lo with the air conditioning button ON. This procedure seats the clutch friction surfaces, and increases clutch torque capacity.
A/C Compressor Relief Valve Replacement
Note. If the A/C compressor relief valve released refrigerant to the atmosphere, determine and correct the cause of the excessive system pressure, then replace the relief valve.
Scheme 156
- Recover the refrigerant with a recovery/recycling/charging station (see «REFRIGERANT RECOVERY»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__refrigerant-recovery) ).
- Remove the relief valve (A) and the O-ring (B). Plug the opening to keep moisture and foreign material from entering the system, and the A/C compressor oil from running out.
- Clean the mating surfaces.
- Replace the O-ring with a new one, and apply a thin coat of refrigerant oil before installing it.
- Remove the plug you installed in step 2 , then install and tighten the relief valve.
- Charge the system (see «SYSTEM CHARGING»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__system-charging) ).
A/C Refrigerant Oil Replacement
Special Tools Required
Oil Injector Tool Robinair ROB16256*, commercially available
*: Available through the Acura Tool and Equipment Program; call 888-424-6857
Recommended PAG oil: DENSO ND-OIL 8
P/N 38897-PR7-A01AH: 120 mL (4 fl.oz)
It is important to have the correct amount of refrigerant oil in the A/C system to ensure proper lubrication of the A/C compressor. Too little oil damages the compressor; too much oil reduces the cooling capacity of the system, and can produce high vent temperatures.
- To avoid contamination, do not return the oil to the container once dispensed, and never mix it with other refrigerant oils.
- Immediately after using the oil, reinstall the cap on the container, and seal it to avoid moisture absorption.
- Do not spill the refrigerant oil on the vehicle; it may damage the paint; if it gets on the paint, wash it off immediately.
Add the recommended refrigerant oil in the amount listed if you replace any of the following parts
A/C condenser (including dryer desiccant)...................50 mL (1 2/3 fl.oz)
Evaporator.................40 mL (1 1/3 fl.oz)
Line or hose...............10 mL (1/3 fl.oz)
Leakage repair...........25 mL (5/6 fl.oz)
Dryer desiccant..........10 mL (1/3 fl.oz)
A/C compressor.........For A/C compressor replacement, subtract the volume of oil drained from the removed A/C compressor from 82 mL (2 7/9 fl.oz), and drain the calculated volume of oil from the new A/C compressor: 82 mL (2 7/9 fl.oz) - Volume of removed A/C compressor = Volume to drain from new A/C compressor.
Note. Even if no oil is drained from the removed A/C compressor, do not drain more than 50 mL (1 2/3 fl.oz) from the new A/C compressor.
Scheme 157
Scheme 158
Scheme 159
Scheme 160
Scheme 161
- Open the glove box. Remove the glove box separator (A) and the glove box cover (B).
- Remove the dust and pollen filter assembly (A) from the blower unit.
- Remove the filter (A) from the housing (B), and replace the filter.
- Install the filter in the reverse order of removal. Make sure that there is no air leaking out of the blower unit.
Scheme 162
Scheme 163
Scheme 164
Scheme 165
- Remove the passenger's dashboard undercover (see «PASSENGER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__passengers-dashboard-undercover-removalinstallation) ).
- Remove the passenger's dashboard trim (see «SPEAKER COVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__speaker-cover-removalinstallation) ).
- Remove the glove box (see «GLOVE BOX SEPARATOR REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__glove-box-separator-removalinstallation) ).
- Remove the passenger's dashboard center lower cover (see «DASHBOARD CENTER LOWER COVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__dashboard-center-lower-cover-removalinstallation) ).
- Remove the bolts (A) and detach the connector clips (B). Then cut the plastic cross brace (C) in the glove box opening with diagonal cutters in the area shown. Retain the plastic cross brace it will be reinstalled.
- Remove the self-tapping screws and the passenger's heater duct (A).
- Disconnect the connector (A) from the blower motor and detach the wire harness clip (B).
- Disconnect the left engine compartment subharness connector from the bracket (A) and detach the harness clips (B). Disconnect the connector (C) from the recirculation control motor. Remove the self-tapping screw (D), the mounting nuts, and the blower unit (E).
- Install the unit in the reverse order of removal. Make sure that there are no air leaks.
Blower Unit Component Replacement
Note these items when overhauling the blower unit
Scheme 166
- The recirculation control motor (A), the blower motor (B), and the dust and pollen filter (C) can be replaced without removing the blower unit.
- Before reassembly, make sure that the recirculation control linkage and door move smoothly without binding.
- After reassembly, make sure the recirculation control motor runs smoothly (see «RECIRCULATION CONTROL MOTOR TEST»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__recirculation-control-motor-test) ).
Scheme 167
- Remove the evaporator core (see «EVAPORATOR CORE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
- Remove the insulator (A) and bolts, then remove the expansion valve (B) and the O-rings (C).
- Install the expansion valve in the reverse order of removal, and note these items: Replace the O-rings with new ones at each fitting, and apply a thin coat of refrigerant oil before installing them. Be sure to use the correct O-rings for HFC-134a (R-134a) to avoid leakage. Immediately after using the oil, reinstall the cap on the container, and seal it to avoid moisture absorption. Do not spill the refrigerant oil on the vehicle; it may damage the paint; if the refrigerant oil contacts the paint, wash it off immediately. Make sure that there are no air leaks. Charge the system (see «SYSTEM CHARGING»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__system-charging) ).
Scheme 168
Scheme 169
Scheme 170
Scheme 171
Scheme 172
Scheme 173
- Recover the refrigerant with a recovery/recycling/charging station (see «REFRIGERANT RECOVERY»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__refrigerant-recovery) ).
- Remove the bolt from the A/C line clamp (A).
- Remove the bolt, then disconnect the A/C line (A) from the evaporator core.
- Remove the blower unit (see «BLOWER UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
- Disconnect these connectors (A): The evaporator temperature sensor, the power transistor, and the passenger's air mix control motor. Detach the connector clip (B) and the harness clip (C). Remove the self-tapping screws, the joint duct (D), and the seal (E).
- Carefully pull out the evaporator core (A) without bending the lines, then remove the plate (B). NOTE: Be careful not to damage the wire harness.
- Remove the clip (A) and the evaporator temperature sensor (B). NOTE: At the factory, the evaporator temperature sensor is installed at the 8th row of fins from the side opposite of the expansion valve.
- When the evaporator temperature sensor (A) is reinstalled onto a new evaporator core, set the evaporator temperature sensor in the 8th row of fins from the side opposite of the expansion valve. NOTE: If you are installing the sensor onto the old evaporator core, install it onto the 9th row of fins, because the other row may be deformed from the previous installation.
- Install the core in the reverse order of removal, and note these items: If you're installing a new evaporator core, add refrigerant oil (DENSO ND-OIL 8) (see «A/C REFRIGERANT OIL REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__ac-refrigerant-oil-replacement) ). Replace the O-rings with new ones at each fitting, and apply a thin coat of refrigerant oil before installing them. Be sure to use the correct O-rings for HFC-134a (R-134a) to avoid leakage. Immediately after using the oil, reinstall the cap on the container, and seal it to avoid moisture absorption. Do not spill the refrigerant oil on the vehicle; it may damage the paint; if the refrigerant oil contacts the paint, wash it off immediately. Charge the system (see «SYSTEM CHARGING»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__system-charging) ). Make sure that there is no air leakage. Make sure that there is no refrigerant leakage.
Heater Unit/Core Replacement
SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ), and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.
Scheme 174
Scheme 175
Scheme 176
Scheme 177
Scheme 178
Scheme 179
Scheme 180
- Do the battery terminal disconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-v6__using-the-gr8-battery-diagnostic-station) ).
- Recover the refrigerant with a recovery/recycling/charging station (see «REFRIGERANT RECOVERY»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__refrigerant-recovery) ).
- Disconnect the A/C line from the evaporator core (see «EVAPORATOR CORE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
- When the engine is cool, drain the engine coolant from the radiator (see «COOLANT CHECK»(/acura/tsx/ii-2008-2014/remont/cooling-fan/#engine-cooling-system-v6) ).
- From under the hood, slide the hose clamps (A) back. Disconnect the inlet heater hose (B) and the outlet heater hose (C) from the heater unit. Note the layout of the hoses. Engine coolant will run out when the hoses are disconnected; drain it into a clean drip pan. Be sure not to let coolant spill on the electrical parts or the painted surfaces. If any coolant spills, rinse it off immediately.
- Remove the mounting nut from the heater unit. Take care not to damage or bend the fuel lines or brake lines, etc..
- Remove the dashboard (see «DASHBOARD REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__dashboard-replacement) ).
- Disconnect the connector (A). Detach the connector clip (B), the harness clips (C), the clips (D), remove the ducts (E) and the drain hose (F). Then remove the mounting nuts and the blower-heater unit (G).
- Disconnect the connector (A) from the blower motor. Detach the wire harness clip (B).
- Disconnect the connectors (A): The mode control motor, the power transistor, the evaporator temperature sensor, the passenger's air mix control motor, and the recirculation control motor. Detach the wire harness clips (B).
- Disconnect the connector (A) from the driver's air mix control motor. Detach the wire harness clips (B), and the connector clip (C), remove the wire harness (D).
- Remove the self-tapping screws and the passenger's heater duct (A). Remove the self-tapping screws and the joint duct (B). Remove the self-tapping screw and the heater core cover (C). Remove the self-tapping screw, the heater pipe bracket (D), and the grommet (E), and carefully pull out the heater core (F).
- Install the heater core, and the evaporator core in the reverse order of removal.
- Install the heater unit in the reverse order of removal, and note these items: Do not interchange the inlet and outlet heater hoses, and install the hose clamps securely. Refill the cooling system with engine coolant (see «COOLANT CHECK»(/acura/tsx/ii-2008-2014/remont/cooling-fan/#engine-cooling-system-v6) ). Make sure that there is no coolant leakage. Make sure that there is no air leakage. Refer to the «EVAPORATOR CORE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) .
- Do the battery terminal reconnection procedure (see «RECONNECTION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-v6__reconnection) ).
Scheme 181
- Remove the driver's dashboard undercover (see «DRIVER'S POCKET REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6) ).
- Disconnect the 7P connector (A) from the driver's air mix control motor (B). Remove the self-tapping screws and the driver's air mix control motor from the heater unit.
- Make sure the air mix door and linkage move smoothly. Then install the motor in the reverse order of removal. Make sure the pin on the motor is properly engaged with the linkage. After installation, make sure the motor runs smoothly.
Scheme 182
- Remove the glove box (see «GLOVE BOX SEPARATOR REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__glove-box-separator-removalinstallation) ).
- Disconnect the 4P connector (A) from the power transistor (B), and the 7P connector (C) from the passenger's air mix control motor (D). Remove the self-tapping screws and the passenger's air mix control motor from the heater unit.
- Make sure the air mix door and linkage move smoothly. Then install the motor in the reverse order of removal. Make sure the pin on the motor is properly engaged with the linkage. After installation, make sure the motor runs smoothly.
Removal
Note. If you reuse the original motor, move the motor to the VENT position before removing the motor.
Scheme 183
- Remove the blower unit (see «BLOWER UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ).
- Disconnect the 7P connector (A) from the mode control motor (B). Remove the self-tapping screws and the mode control motor from the heater unit.
Scheme 184
Scheme 185
Scheme 186
Scheme 187
- Release the lock (A), then remove the motor lever (B) from the mode control motor (C). NOTE: If replacing the mode control motor connect the 7P connector then set the climate control to VENT verify the out put shaft (D).
- Align the position of the damper lever pins (A), then install the motor lever (B).
- Make sure the damper lever pins in the motor lever are visible through the holes. Make sure the mode door and linkage move smoothly.
- Install the mode control motor (A) while holding the motor lever (B).
- After installation, make sure the motor runs smoothly.
Scheme 188
- Remove the glove box (see «GLOVE BOX SEPARATOR REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__glove-box-separator-removalinstallation) ).
- Disconnect the 7P connector (A) from the recirculation control motor (B). Remove the self-tapping screws and the recirculation control motor from the blower unit.
- Make sure the recirculation door and linkage move smoothly. Then install the motor in the reverse order of removal. Make sure the pin on the motor is properly engaged with the linkage. After installation, make sure the motor runs smoothly.
Scheme 189
- Remove the center console panel (see «CENTER CONSOLE PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#consoles-v6__center-console-panel-removalinstallation) ).
- Remove the driver's center trim (see «DRIVER'S OUTER DASHBOARD TRIM REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__drivers-outer-dashboard-trim-removalinstallation) ).
- Pull out the in-car temperature sensor (A), disconnect the connector (B), and remove the in-car temperature sensor from the air hose (C).
- Install the sensor in the reverse order of removal. Be sure to connect the air hose securely.
Scheme 190
- Remove the front bumper (see «FRONT BUMPER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#bumpers-v6__front-bumper-removalinstallation) ).
- Release the lock, then remove the outside air temperature sensor (A) from the front bumper beam. Disconnect the 2P connector (B) from the outside air temperature sensor.
- Install the sensor in the reverse order of removal.
Sunlight Sensor Replacement
Note. When prying with a flat-tip screwdriver, wrap it with protective tape to prevent damage.
Scheme 191
- Using a flat-tip screwdriver wrapped with protective tape, pry up the sunlight sensor (A) from the dashboard, then disconnect the connector (B). Be careful not to damage the sensor and the dashboard.
- Install the sensor in the reverse order of removal.
Scheme 192
Scheme 193
- Remove the passenger's dashboard trim (see «SPEAKER COVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__speaker-cover-removalinstallation) ).
- Remove the center console panel (see «CENTER CONSOLE PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#consoles-v6__center-console-panel-removalinstallation) ).
- Remove the driver's center trim and passenger's center trim (see «DRIVER'S OUTER DASHBOARD TRIM REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__drivers-outer-dashboard-trim-removalinstallation) ).
- Remove the self-tapping screws. Disconnect the connectors (A), then remove the climate control unit (B).
- If necessary, replace the bulbs (A).
- Install the climate control unit in the reverse order of removal. After installation, operate the various functions to make sure they work properly.
- Run the Self-Diagnostic Function to confirm that there are no problems in the system (see «HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITH THE HDS»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__how-to-use-the-self-diagnostic-function) ).
Refrigerant Recovery
| CAUTION | Air conditioning refrigerant or lubricant vapor can irritate your eyes, nose, or throat. Be careful when connecting service equipment. Do not breathe refrigerant or vapor. |
Note. If accidental system discharge occurs, ventilate the work area before resuming service. Additional health and safety information may be obtained from the refrigerant and lubricant manufacturers.
Scheme 194
- Connect an R-134a refrigerant recovery/recycling/charging station (A) to the high-pressure service port (B) and the low-pressure service port (C), as shown, following the equipment manufacturer's instructions.
- Measure the amount of refrigerant oil removed from the A/C system after the recovery process is completed. Be sure to put the same amount of new refrigerant oil back into the A/C system before charging.
System Evacuation
Special Tools Required
Compact Electronic Vacuum Gauge Robinair ROB14777*, commercially available
*: Available through the Acura Tool and Equipment Program; call 888-424-6857
| CAUTION | Air conditioning refrigerant or lubricant vapor can irritate your eyes, nose, or throat. Be careful when connecting service equipment. Do not breathe refrigerant or vapor. |
Note. If accidental system discharge occurs, ventilate the work area before resuming service. Additional health and safety information may be obtained from the refrigerant and lubricant manufacturers. Do not allow moisture to contaminate the A/C system oil. Moisture in the oil is difficult to remove, and it can damage the A/C compressor. Using a compact electronic vacuum gauge may decrease the required evacuation time because you can measure actual moisture level with this tool.
A more efficient way to measure moisture removal is with a special tool called a compact electronic vacuum gauge, measuring vacuum levels in microns.
Connect the tool according to the manufacturers instructions and allow the vacuum pump to run until the gauge reads 500 microns.
Shut off and isolate the vacuum pump, then observe the gauge reading
- If the vacuum level remains stable for at least three minutes, all moisture in the system has been removed.
- A slow increase in the micron reading means there is still moisture boiling out of the system. Restart the vacuum pump and continue evacuating.
- A quick increase of micron levels indicates a leak is present in the system or your service equipment. Determine the cause and correct the leak before continuing.
Scheme 195
- When an A/C system has been opened to the atmosphere, such as during installation or repair, it must be evacuated using an R-134a refrigerant recovery/recycling/charging station. If the system has been open for several days, the receiver/dryer should be replaced, refrigerant oil should be drained and replaced with new oil, and the system should be evacuated for several hours.
- Connect an R-134a refrigerant recovery/recycling/charging station (A) to the high-pressure service port (B) and the low-pressure service port (C), as shown, following the equipment manufacturer's instructions.
- Evacuate the system. The vacuum pump should run for a minimum of 30 minutes to eliminate all moisture from the system. When the suction gauge reads -93.3 kPa (-700 mmHg, -27.6 inHg) for at least 30 minutes, close all valves, and turn off the vacuum pump.
- If the suction gauge does not reach approximately -93.3 kPa (-700 mmHg, -27.6 inHg) in 15 minutes, there is probably a large leak in the system. Partially charge the system, and check for leaks (see «REFRIGERANT LEAK CHECK»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__refrigerant-leak-check) ).
System Charging
| CAUTION | Air conditioning refrigerant or lubricant vapor can irritate your eyes, nose, or throat. Be careful when connecting service equipment. Do not breathe refrigerant or vapor. |
Note. If accidental system discharge occurs, ventilate the work area before resuming service. Additional health and safety information may be obtained from the refrigerant and lubricant manufacturers.
Scheme 196
- Connect an R-134a refrigerant recovery/recycling/charging station (A) to the high-pressure service port (B) and the low-pressure service port (C), as shown, following the equipment manufacturer's instructions.
- Recover the refrigerant in the A/C system (see «REFRIGERANT RECOVERY»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__refrigerant-recovery) ).
- Evacuate the system until the suction gauge reads approximately -93.3 kPa (-700 mmHg, -27.6 inHg). Check that the system holds a vacuum for 15 minutes. If the A/C system hold vacuum for 15 minutes, the system does not have a large leak. Finish the system evacuation (see «SYSTEM EVACUATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__system-evacuation) ), then go to step 4 . If the A/C system does not hold vacuum for 15 minutes, the A/C system has a leak. Find and repair the leak (see «REFRIGERANT LEAK CHECK»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__refrigerant-leak-check) ).
- Add the same amount of new refrigerant oil to the system that was removed during recovery. Use only DENSO ND-OIL 8 refrigerant oil.
- Charge the system with the specified amount of R-134a refrigerant. Do not overcharge the system; the A/C compressor will be damaged. Select the appropriate units of measure for your refrigerant charging station. Refrigerant Capacity: 450 to 500 g 0.45 to 0.50 kg 1.0 to 1.1 lbs 15.8 to 17.6 oz
- Check for refrigerant leaks (see «REFRIGERANT LEAK CHECK»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__refrigerant-leak-check) ).
- Check the system performance (see «PERFORMANCE TEST»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__performance-test) ).
See also:
• DRIVE BELT INSPECTION
• TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A
• DLC CIRCUIT TROUBLESHOOTING
• DTC U1280: COMMUNICATION BUS LINE ERROR (BUS-OFF)
• AUDIO WIRE HARNESS (WITH NAVIGATION)
• AUDIO WIRE HARNESS (WITHOUT NAVIGATION)
• DTC P0532: A/C PRESSURE SENSOR CIRCUIT LOW VOLTAGE
• DTC P0533: A/C PRESSURE SENSOR CIRCUIT HIGH VOLTAGE
• LEFT ENGINE COMPARTMENT WIRE HARNESS (ENGINE COMPARTMENT BRANCH)
• RADIATOR FAN HIGH SPEED CIRCUIT TROUBLESHOOTING
• SYSTEM LINKS
• DTC P2184: ECT SENSOR 2 CIRCUIT LOW VOLTAGE
• DTC P2185: ECT SENSOR 2 CIRCUIT HIGH VOLTAGE
• COOLANT CHECK
• BATTERY TEST
• ALTERNATOR AND REGULATOR CIRCUIT TROUBLESHOOTING
• GAUGE CONTROL MODULE INPUT TEST
• LEFT ENGINE COMPARTMENT WIRE HARNESS DASHBOARD BRANCH)
• POWER RELAY TEST
• REMOVAL AND INSTALLATION
• GENERAL TROUBLESHOOTING INFORMATION
• SUBSTITUTING THE PCM
• PCM REPLACEMENT
• FIVE-TERMINAL TYPE
• DRIVER'S UNDER-DASH FUSE/RELAY BOX (MICU) REMOVAL AND INSTALLATION
• CANADA MODELS
• AUDIO-NAVIGATION SWITCH PANEL REMOVAL/INSTALLATION
• GPS ICON IS WHITE OR NOT SHOWN
• AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION
• PASSENGER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION
• SPEAKER COVER REMOVAL/INSTALLATION
• GLOVE BOX SEPARATOR REMOVAL/INSTALLATION
• FRONT BUMPER REMOVAL/INSTALLATION
• DASHBOARD CENTER LOWER COVER REMOVAL/INSTALLATION
• COMPONENT LOCATION INDEX
• USING THE GR8 BATTERY DIAGNOSTIC STATION
• DASHBOARD REPLACEMENT
• RECONNECTION
• DRIVER'S POCKET REMOVAL/INSTALLATION
• CENTER CONSOLE PANEL REMOVAL/INSTALLATION
• DRIVER'S OUTER DASHBOARD TRIM REMOVAL/INSTALLATION
• A/C SYSTEM NOISE CHECK
• A/C LINE REPLACEMENT
• REFRIGERANT LEAK CHECK
• HOW TO USE THE SELF-DIAGNOSTIC FUNCTION WITH THE HDS
• CHECKING FOR DTCS
• SYMPTOM TROUBLESHOOTING
• A/C COMPRESSOR CLUTCH CIRCUIT TROUBLESHOOTING
• A/C COMPRESSOR REPLACEMENT
• DTC INDICATOR A: CLIMATE CONTROL UNIT INTERNAL ERROR
• U0155
• HOW TO CHECK FOR DTCS WITH THE HDS
• A/C SYSTEM TEST
• RADIATOR AND A/C CONDENSER FAN LOW SPEED CIRCUIT TROUBLESHOOTING
• A/C CONDENSER FAN HIGH SPEED CIRCUIT TROUBLESHOOTING
• RECEIVER/DRYER DESICCANT REPLACEMENT
• SYSTEM CHARGING
• RECIRCULATION CONTROL MOTOR TEST
• DRIVER'S AIR MIX CONTROL MOTOR TEST
• PASSENGER'S AIR MIX CONTROL MOTOR TEST
• MODE CONTROL MOTOR TEST
• IN-CAR TEMPERATURE SENSOR TEST
• OUTSIDE AIR TEMPERATURE SENSOR TEST
• SUNLIGHT SENSOR TEST
• SUNLIGHT SENSOR REPLACEMENT
• EVAPORATOR TEMPERATURE SENSOR TEST
• BLOWER UNIT COMPONENT REPLACEMENT
• A/C SIGNAL CIRCUIT TROUBLESHOOTING
• RUN THE SENSOR INPUT DISPLAY MODE
• A/C COMPRESSOR CLUTCH OVERHAUL
• REFRIGERANT RECOVERY
• SYSTEM EVACUATION
• A/C COMPRESSOR RELIEF VALVE REPLACEMENT
• A/C SYSTEM INSPECTION
• A/C REFRIGERANT OIL REPLACEMENT
• PERFORMANCE TEST
