Power Seat System Acura TSX I

Seats 16 illustrations ~392 words

8-way Adjustable ('04-05 models)

For the driver's power seat ('06-08 models), refer to the Driving Position Memory System (DPMS)

Scheme 61

Scheme 61: 8-way Adjustable ('04-05 models)
Scheme 61: 8-way Adjustable ('04-05 models)

Scheme 62

Scheme 62: 4-way Adjustable ('05-08 models)
Scheme 62: 4-way Adjustable ('05-08 models)

Circuit Diagram

8-way Adjustable ('04-05 models)

Scheme 63

Scheme 63: Circuit Diagram
Scheme 63: Circuit Diagram

4-way Adjustable ('05-08 models)

Scheme 64

Scheme 64
Scheme 64

Scheme 65

Scheme 65: Driver's Power Seat (8-way Adjustable) ('04-05 models)
Scheme 65: Driver's Power Seat (8-way Adjustable) ('04-05 models)

Scheme 66

Scheme 66
Scheme 66
  1. Remove the power seat adjustment switch knobs (A) and recline cover from the driver's power seat (see «FRONT SEAT DISASSEMBLY/REASSEMBLY - DRIVER'S 8-WAY POWER»(/acura/tsx/i-2003-2008/remont/seats/#seat-system__front-seat-disassemblyreassembly-drivers-8-way) ), then remove the two screws and the power seat adjustment switch.
  2. Disconnect the 12P connector from the power seat adjustment switch (B).
  3. Reinstall the adjustment switch knobs to the switch.
  4. Check for continuity between the terminals in each switch position.
  5. If the continuity is not as specified, replace the switch.

Scheme 67

Scheme 67: Front Passenger's Power Seat (4-way Adjustable) ('05-08 models)
Scheme 67: Front Passenger's Power Seat (4-way Adjustable) ('05-08 models)

Scheme 68

Scheme 68
Scheme 68
  1. Remove the power seat adjustment switch knobs (A) and recline cover from the front passenger's power seat, then remove the two screws and the power seat switch.
  2. Disconnect the 12P connector from the power seat adjustment switch (B).
  3. Reinstall the adjustment switch knobs to the switch.
  4. Check for continuity between the terminals in each switch position. No. 1,3, 5 and 9 terminals are not used.
  5. If the continuity is not as specified, replace the switch.

Scheme 69

Scheme 69: Driver's 8-way Adjustable Power Seat
Scheme 69: Driver's 8-way Adjustable Power Seat

Scheme 70

Scheme 70
Scheme 70

Scheme 71

Scheme 71
Scheme 71

Scheme 72

Scheme 72
Scheme 72

Scheme 73

Scheme 73
Scheme 73
  1. Remove the driver's seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/seats/#seat-system__front-seat-removalinstallation) ).
  2. Disconnect the 12P connector (A) from the power seat adjustment switch (B).
  3. Test each motor by applying battery voltage and body ground to the terminals. Slide motor Recline motor Front up-down motor Rear up-down motor
  4. If any motor does not run or fails to run smoothly, check for an open in the driver's seat wire harness between the 12P connector and each motor connector. If the harness is OK, replace the motor.

Scheme 74

Scheme 74: Passenger's 4-way Adjustable Power Seat ('05-08 models)
Scheme 74: Passenger's 4-way Adjustable Power Seat ('05-08 models)

Scheme 75

Scheme 75
Scheme 75

Scheme 76

Scheme 76
Scheme 76
  1. Remove the front passenger's seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/seats/#seat-system__front-seat-removalinstallation) ).
  2. Disconnect the 12P connector (A) from the power seat adjustment switch (B).
  3. Test each motor by applying battery voltage and body ground to the terminals. Slide motor Recline motor
  4. If either motor does not run or fails to run smoothly, check for an open in the passenger's seat wire harness between the 12P connector and each motor connector. If the harness is OK, replace the motor.
