Scheme 1: Component Location Index
Scheme 1: Component Location Index

Trim Removal/Installation - Door Areas

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the American Honda Tool and Equipment Program; call 888-424-6857

Front Door Sill Area

Note. Put on gloves to protect your hands. Take care not to bend or scratch the trim and panels. Use the appropriate tool from the KTC trim tool set to avoid damage when prying components.

Scheme 2

Scheme 2: Front Door Sill Area
Scheme 2: Front Door Sill Area

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4
  1. Left side: Remove the footrest (see step 6 ).
  2. Left side: Remove the front side cap from the front door sill trim, and remove the opener lock cylinder and bolt (see «TRUNK LID OPENER/FUEL FILL DOOR OPENER REPLACEMENT»(/acura/tsx/i-2003-2008/remont/door-locks-anti-theft-systems/#openers__trunk-lid-openerfuel-fill-door-opener) ).
  3. Detach the hooks (A) and tabs (B) from the kick panel (C) and B-pillar lower trim (D), and pull the front door sill trim (E) up by hand to detach the clips (F, G), then remove it.
  4. Disconnect the trunk lid opener/fuel fill door opener cable (H) from the opener (I).
  5. If necessary, pull the front side outer trim (J) up to detach the clips (K), then remove the trim.
  6. Remove the left kick panel (A) or the right kick panel (B). Pull out the door opening trim (C) as needed from the kick panel hooks (D) and the door opening flange. Left side: Pull the hood release handle, and hold it. Pull the kick panel back by hand to detach the clips (E, F, G), then remove it.
  7. Pull out the door opening trim (A) from the trim hooks (B) and around the door opening flange, then remove the trim.
  8. Install the trim in the reverse order of removal, and note these items: Check if the clips are damaged or stress-whitened, and if necessary, replace them with new ones. Push the clips and hooks into place securely. Make sure the trunk lid opener/fuel fill door opener cable is connected securely.

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the American Honda Tool and Equipment Program; call 888-424-6857

Rear Door Sill Area

Note. Put on gloves to protect your hands. Take care not to bend or scratch the trim and panels. Use the appropriate tool from the KTC trim tool set to avoid damage when prying components.

Scheme 5

Scheme 5: Rear Door Sill Area
Scheme 5: Rear Door Sill Area

Scheme 6

Scheme 6
Scheme 6
  1. Detach the hook (A) and tab (B) from the B-pillar lower trim (C), and pull the rear door sill trim (D) up by hand to detach the clips (E, F), then remove it.
  2. If necessary, pull the rear side outer trim (G) up to detach the clips (H), then remove the trim.
  3. Pull out the rear door opening trim (A) from the trim hooks (B) and around the rear door opening flange, then remove the trim.
  4. Install the trim in the reverse order of removal, and note these items: Check if the clips are damaged or stress-whitened, and if necessary, replace them with new ones. Push the clips and hooks into place securely.

Trim Removal/Installation - Pillar Areas

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the American Honda Tool and Equipment Program; call 888-424-6857

A-Pillar Trim

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Note. Put on gloves to protect your hands. Take care not to bend or scratch the trim and panels. Use the appropriate tool from the KTC trim tool set to avoid damage when prying components.

Scheme 7

Scheme 7: A-Pillar Trim
Scheme 7: A-Pillar Trim

Scheme 8

Scheme 8
Scheme 8
  1. Remove the A-pillar trim (A). Pull out the door opening trim (B) as needed. Pry the A-pillar cap (C) out until it is stopped by the hooks (D) in the grommet (E). Pull the trim back by hand to detach the clip, then pull the trim up. Release the hooks on the grommet and pull the cap out. Discard the cap.
  2. Install the trim in the reverse order of removal, and note these items: Check if the clip is damaged or stress-whitened, and if necessary, replace it with a new one. Do not reuse the A-pillar cap; always replace it. If the side curtain airbag has deployed, replace the A-pillar trim with a new one. To prevent the side curtain airbags from deploying improperly and possibly causing injury, inspect removed pieces and replace them if they have any of these types of damage: Any cracks, deformations, or stress-whitened areas in the A-pillar trim (A) Any cracks, or stress-whitened areas in the grommet and clip seating surfaces (B) Bent or broken grommet (C) Replace any damaged parts with new ones. Make sure the top of the trim overlaps with the headliner correctly (see «CHECKING AND ADJUSTING THE HEADLINER/PILLAR TRIM OVERLAP»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__checking-and-adjusting-the-headlinerpillar-trim) ). Push the clip into place securely.

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the American Honda Tool and Equipment Program; call 888-424-6857

B-Pillar Upper/Lower Trim

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Note. Put on gloves to protect your hands. Take care not to bend or scratch the trim and panels. Use the appropriate tool from the KTC trim tool set to avoid damage when prying components.

Scheme 9

Scheme 9: B-Pillar Upper/Lower Trim
Scheme 9: B-Pillar Upper/Lower Trim

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11
  1. Remove these items: Front door sill trim (see «FRONT DOOR SILL AREA»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#interior-trim__front-door-sill-area) ) Rear door sill trim (see «REAR DOOR SILL AREA»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#interior-trim__rear-door-sill-area) ) Front door opening trim, as needed (see step 7 ) Rear door opening trim, as needed (see step 3 )
  2. Remove the B-pillar lower trim (A). Detach the lower clips by pulling the bottom of the trim back by hand. Pull the trim down to release the upper hooks (B).
  3. Remove the upper anchor cover, and remove the upper anchor bolt (see «FRONT SEAT BELT»(/acura/tsx/i-2003-2008/remont/restraints-control-systems/#seat-belt-system) ).
  4. Remove the B-pillar upper trim (A). Pull the bottom of the trim back by hand to detach the lower clip. Detach the upper clip by puling the top of the trim. Pull the trim down to release the upper hooks (B) from the side curtain airbag B-pillar bracket (C).
  5. Install the trim in the reverse order of removal, and note these items: Check if the clips are damaged or stress-whitened, and if necessary, replace them with new ones. If the side curtain airbag has deployed, replace the B-pillar upper trim with a new one. To prevent the side curtain airbags from deploying improperly and possibly causing injury, inspect removed pieces and replace them if they have any of these types of damage: Any cracks or deformations in the B-pillar upper trim (A) and the upper hooks (B), and any stress-whitened areas in the upper part of the trim Any cracks or deformations in the B-pillar lower trim (C), and any breakage in the part (D) that fits into the B-pillar upper trim Any cracks or stress-whitened areas in the clip seating surfaces (E) Replace any damaged parts with new ones. Make sure the top of the trim overlaps with the headliner correctly (see «CHECKING AND ADJUSTING THE HEADLINER/PILLAR TRIM OVERLAP»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__checking-and-adjusting-the-headlinerpillar-trim) ). Make sure the trim hooks are installed into the holes in the side curtain airbag B-pillar bracket securely. Push the clips into place securely. Apply medium strength type liquid thread lock to the front seat belt upper anchor bolt before reinstallation (see «FRONT SEAT BELT»(/acura/tsx/i-2003-2008/remont/restraints-control-systems/#seat-belt-system) ). Before installing the anchor bolt, make sure there are no twists or kinks in the seat belt.

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the American Honda Tool and Equipment Program; call 888-424-6857

C-Pillar Trim

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Note. Put on gloves to protect your hands. Take care not to bend or scratch the trim and panels. Use the appropriate tool from the KTC trim tool set to avoid damage when prying components.

Scheme 12

Scheme 12: C-Pillar Trim
Scheme 12: C-Pillar Trim

Scheme 13

Scheme 13
Scheme 13
  1. Remove these items: Rear seat side bolster (see «REAR SEAT REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/seats/#seat-system__rear-seat-removalinstallation) ) Rear door opening trim, as needed (see step 3 )
  2. Remove the C-pillar trim (A). Pry the C-pillar cap (B) out until it is stopped by the hooks (C) in the grommet (D). Pull the C-pillar trim back by hand to detach the clips, then remove the trim. Release the hooks on the grommet and pull the cap out. Discard the cap.
  3. Install the trim in the reverse order of removal, and note these items: Check if the clips are damaged or stress-whitened, and if necessary, replace them with new ones. Do not reuse the C-pillar cap; always replace it. If the side curtain airbag has deployed, replace the C-pillar trim with new one. To prevent the side curtain airbags from deploying improperly and possibly causing injury, inspect removed pieces and replace them if they have any of these types of damage: Any cracks, deformations, or stress-whitened areas in the C-pillar trim (A) Any cracks, or stress-whitened areas in the grommet and clip seating surfaces (B) Bent or broken grommet (C) Replace any damaged parts with new ones. Make sure the top of the trim overlaps with the headliner correctly (see «CHECKING AND ADJUSTING THE HEADLINER/PILLAR TRIM OVERLAP»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__checking-and-adjusting-the-headlinerpillar-trim) ). Push the clips into place securely.

Trim Removal/Installation - Rear Shelf Area

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the American Honda Tool and Equipment Program; call 888-424-6857

Note. Put on gloves to protect your hands. Take care not to bend or scratch the trim and panels. Use the appropriate tool from the KTC trim tool set to avoid damage when prying components.

Scheme 14

Scheme 14: Trim Removal/Installation - Rear Shelf Area
Scheme 14: Trim Removal/Installation - Rear Shelf Area

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16
  1. Remove these items: Seat cushion and seat side bolster (see «REAR SEAT REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/seats/#seat-system__rear-seat-removalinstallation) ) C-pillar trim (see «C-PILLAR TRIM»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#interior-trim__c-pillar-trim) ) Rear center seat belt center anchor bolt (see «FRONT SEAT BELT»(/acura/tsx/i-2003-2008/remont/restraints-control-systems/#seat-belt-system) )
  2. Remove the high mount brake light (A). From the trunk compartment, disconnect the high mount brake light bulb socket (B). Push the high mount brake light towards the rear window, and gently pry up at the back to release the front hooks (C). Release the rear hooks (D), then remove the high mount brake light.
  3. From both sides, pull the rear speaker grille (A) up to detach the clips (B, C), then remove the rear speaker grille.
  4. Remove the rear shelf (A). From the trunk compartment, release the hooks (B) from the rear seat-back lock cylinder (C), then remove the lock cylinder trim (D). Gently pull back front edge of the rear shelf to detach the clips. Lift the rear shelf to detach the clips. Pull back the lid (E)to release the hooks (F), then open the lid.
  5. Pull the rear center seat belt (G) out through the lid opening, and pull the rear seat belts (H) out through the slit (I) in the rear shelf.
  6. Install the shelf in the reverse order of removal, and note these items: Check if the clips are damaged or stress-whitened, and if necessary, replace them with new ones. When installing the rear shelf, slip the rear seat belt through the slit, and through the rear center seat belt into the lid opening in the rear shelf. Push the clips and hooks into place securely. Make sure the high mount brake light bulb socket is connected securely.

Trim Removal/Installation - Trunk Area

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the American Honda Tool and Equipment Program; call 888-424-6857

Note. Put on gloves to protect your hands. Take care not to bend or scratch the trim and panels. Use the appropriate tool from the KTC trim tool set to avoid damage when prying components.

Scheme 17

Scheme 17: Trim Removal/Installation - Trunk Area
Scheme 17: Trim Removal/Installation - Trunk Area

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20
  1. Remove the clips, then remove the spare tire lid (A).
  2. Detach the clips, and release the hooks (A) by pulling the trunk rear trim panel (B) up, then remove it.
  3. Remove the clips (A), and detach the clips (B), then remove the left trunk side trim panel (C) and right trunk side trim panel (D) from the trunk.
  4. If necessary, remove the trunk floor spacer (A) and tie down hooks (B).
  5. Install the trim in the reverse order of removal, and note these items: Check if the clips are damaged or stress-whitened, and if necessary, replace them with new ones. Push the clips into place securely.

Trim Removal/Installation - Trunk Lid

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the American Honda Tool and Equipment Program; call 888-424-6857

Note. Put on gloves to protect your hands. Take care not to bend or scratch the trim and panels. Use the appropriate tool from the KTC trim tool set to avoid damage when prying components.

Scheme 21

Scheme 21: Trim Removal/Installation - Trunk Lid
Scheme 21: Trim Removal/Installation - Trunk Lid

Scheme 22

Scheme 22
Scheme 22

Scheme 23

Scheme 23
Scheme 23

Scheme 24

Scheme 24
Scheme 24
  1. Remove the trunk lid protector (A). Pull back the outside of the trunk lid protector to release the outside hook (B). Slide the trunk lid protector to the outside, then release the hooks (C) to remove it.
  2. Remove the clips (A, B), then remove the trunk lid trim (C).
  3. Detach the clip and pivot the trunk lid handle (A) on the hooks (B), then remove the trunk lid handle.
  4. Remove the trunk lid hinge cover (A). Remove the clip (B), then pull back the trunk side trim panel (C) as needed. Remove the clip (D) and detach the clip (E). Left side: Release the trunk lid opener cable (F) from the hooks (G) in the trunk lid hinge cover.
  5. Install the trim in the reverse order of removal, and note these items: Align the marks (H) on the opener cable with the hook as shown. When installing the trunk lid protectors, install them with the arrow marks toward the inside. Check if the clips are damaged or stress-whitened, and if necessary, replace them with new ones.

Headliner Removal/Installation

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the American Honda Tool and Equipment Program; call 888-424-6857

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Note. Use the appropriate tool from the KTC trim tool set to avoid damage when prying components. When prying with a flat-tip screwdriver, wrap it with protective tape to prevent damage. Take care not to bend or scratch the headliner. Be careful not to damage the dashboard and other interior trim.

Scheme 25

Scheme 25: Headliner Removal/Installation
Scheme 25: Headliner Removal/Installation

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28

Scheme 29

Scheme 29
Scheme 29

Scheme 30

Scheme 30
Scheme 30
  1. Remove these items: A-pillar trim, both sides (see «A-PILLAR TRIM»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#interior-trim__a-pillar-trim) ) Ceiling light (see «CEILING LIGHT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/interiorillumination-lights/#interior-lights) ) Front seat belt upper anchor, both sides (see «FRONT SEAT BELT»(/acura/tsx/i-2003-2008/remont/restraints-control-systems/#seat-belt-system) ). B-pillar lower trim (see «B-PILLAR UPPER/LOWER TRIM»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#interior-trim__b-pillar-upperlower-trim) ) B-pillar upper trim, both sides (see «B-PILLAR UPPER/LOWER TRIM»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#interior-trim__b-pillar-upperlower-trim) ) C-pillar trim, both sides (see «C-PILLAR TRIM»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#interior-trim__c-pillar-trim) )
  2. From both sides, using a trim tool, release the tabs (A), then remove the sunvisor cap (B) from the bracket (C). Turn the cap, and remove it.
  3. From both sides, remove the sunvisor (A) and holder (B). Remove the self-tapping ET screws. Remove the sunvisor from the body and holder. Disconnect the vanity mirror light connector (C). Using a flat-tip screwdriver, push the hook (D), and turn the holder 90°, then pull it out.
  4. Remove the roof console (A). Remove the lens (B). Remove the bolts (C, D). Pull out the roof console, and front individual map light (E). Disconnect the front individual map light connector (F), and ambient light connector (G).
  5. Lower the grab handle, then pry out the lid (A). Remove the self-tapping ET screws, then remove the grab handle (B). Remove the remaining grab handles.
  6. Remove the headliner. Remove the socket plug (A). Remove the front door opening trim (B) and rear door opening trim (C) from each roof portion. Detach the clip (D), and release the Velcro fasteners (E) by pulling the front portion of the headliner (F) down. With the help of an assistant, detach the rear clips (G) by pulling the rear portion of the headliner down, release the headliner from the frame (H) by sliding the headliner rearward, and lowering the headliner. Remove the headliner through the front passenger's door opening.
  7. If necessary, pull down the roof console bracket (A) to release the clip.
  8. Install the headliner in the reverse order of removal, and note these items: If the side curtain airbag has been deployed, replace the headliner and front grab handle on deployed side with new ones. To prevent the side curtain airbags from deploying improperly and possibly causing injury, inspect removed pieces and replace them if they have any of these types of damage: Any creases or tears in the headliner (A) Any Velcro fasteners (B) or clip bases (C) which have come off the headliner Any damage around the grab handle holes (D) or sunvisor holes (E) in the headliner Any deformations in the grab handle (F) Any cracks in the sunvisor stay base (G) Any bends or cracks in the sunvisor stay shaft (H) Any cracks in the sunvisor base (I) Any cracks in the vanity mirror base (J) Any deformations in the grab handle bracket Replace any damaged parts with new ones. Make sure the top of the headliner overlaps with the trim pieces correctly (see «CHECKING AND ADJUSTING THE HEADLINER/PILLAR TRIM OVERLAP»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__checking-and-adjusting-the-headlinerpillar-trim) ). When passing the headliner through the door opening, be careful not to fold or bend it. Also, be careful not to scratch the body. If the threads on a visor or grab handle screw is worn out, use an oversized self-tapping ET screw made specifically for this application: Visor: P/N 90137-S30-003 Grab handle: P/N 90137-S0A-003 Check that both sides of the headliner are securely attached to the trim.

Headliner

Scheme 31

Scheme 31
Scheme 31

Grab handle

Scheme 32

Scheme 32
Scheme 32

Sunvisor

Scheme 33

Scheme 33
Scheme 33

Carpet Replacement

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the American Honda Tool and Equipment Program; call 888-424-6857

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Note. Put on gloves to protect your hands. Take care not to damage, wrinkle or twist the carpet. Use the appropriate tool from the KTC trim tool set to avoid damage when prying components. Be careful not to damage the dashboard or other interior trim pieces.

Scheme 34

Scheme 34: Carpet Replacement
Scheme 34: Carpet Replacement

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36
Scheme 36

Scheme 37

Scheme 37
Scheme 37

Scheme 38

Scheme 38
Scheme 38

Scheme 39

Scheme 39
Scheme 39

Scheme 40

Scheme 40
Scheme 40
  1. Make sure you have the anti-theft codes for the audio system and the navigation system (if equipped), then write down the audio presets.
  2. Disconnect the negative cable from the battery, and wait at least 3 minutes before beginning work.
  3. Remove these items: Front seats, both sides (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/seats/#seat-system__front-seat-removalinstallation) ) Rear seat cushion (see «REAR SEAT REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/seats/#seat-system__rear-seat-removalinstallation) ) Rear seat side bolsters, both sides (see «REAR SEAT REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/seats/#seat-system__rear-seat-removalinstallation) ) Kick panels, both sides (see «TRIM REMOVAL/INSTALLATION - DOOR AREAS»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-door-areas) ) Front door sill trim, both sides (see «FRONT DOOR SILL AREA»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#interior-trim__front-door-sill-area) ) Rear door sill trim, both sides (see «REAR DOOR SILL AREA»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#interior-trim__rear-door-sill-area) ) B-pillar lower trim (see «B-PILLAR UPPER/LOWER TRIM»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#interior-trim__b-pillar-upperlower-trim) ) Center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#consoles__center-console-removalinstallation) ) Driver's dashboard center lower cover (see «DASHBOARD/STEERING HANGER BEAM REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#dashboard) ) Passenger's dashboard center lower cover (see «DASHBOARD/STEERING HANGER BEAM REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#dashboard) ) Driver's dashboard undercover (see «DRIVER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#dashboard) ) Passenger's dashboard lower cover (see «PASSENGER'S DASHBOARD LOWER COVER REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#dashboard) ) Parking brake lever (see «PARKING BRAKE CABLE REPLACEMENT»(/acura/tsx/i-2003-2008/remont/mechanical-hydraulic/#conventional-brake-components) ) Stereo amplifier (see «STEREO AMPLIFIER REPLACEMENT»(/acura/tsx/i-2003-2008/remont/entertainment-systems/#audio-system) )
  4. Remove the front seat belt lower anchor bolt, both sides (see «FRONT SEAT BELT»(/acura/tsx/i-2003-2008/remont/restraints-control-systems/#seat-belt-system) ).
  5. Push; the knob (A) back to release the hooks (B), then pull up the accelerator pedal (C).
  6. Detach the clips, then remove the footrest (A).
  7. M/T model: Remove the bolts, then remove the center console bracket (A).
  8. Disconnect the antenna lead (A) and antenna connector (B). If equipped, disconnect the side curtain airbag subharness connector (C), and release the harness clamp (D). Detach the harness clips (E), and on A/T model, harness clips (F). A/T model M/T model
  9. Remove the bolts securing the change lever bracket or select lever bracket (A).
  10. Remove the floor mat holders (A) from the driver's side, and release the clip (B) from middle of the carpet (C).
  11. Release the hooks (D) with a flat-tip screwdriver by pushing the screwdriver toward the door, then lift upwards. Pull the Velcro fastener (E) out, then remove the carpet.
  12. Install the carpet in the reverse order of removal, and note these items: Take care not to damage, wrinkle or twist the carpet. Make sure the seat harnesses and antenna lead are routed correctly. Check if the clip is damaged or stress-whitened, and if necessary, replace it with a new one. Reconnect the negative cable to the battery. Reset the clock. Enter the anti-theft codes for the audio system and the navigation system (if equipped), then enter the audio presets. Set the clock (on vehicles without navigation).
