Engine Assembly — Acura TL IV рестайлинг (2011-2014)

Engine Removal

Special Tools Required

2008 V6 Attachment Arm SIL02C000033*
Engine Support Hanger, A and Reds AAR-T1256*
Engine Hanger Balance Bar VSB02C000019*
Subframe Adapter VSB02C000016*

*: Available through the Acura Tool and Equipment Program, 888-424-6857.

Note. Use fender covers to avoid damaging painted surfaces. To avoid damaging the wiring and terminals, unplug the wiring connectors carefully while holding the connector portion. Mark all wiring and hoses to avoid misconnection. Also, be sure that they do not contact other wiring or hoses, or interfere with other parts.

Scheme 375

Scheme 376

Scheme 377

Scheme 378

Scheme 379

Scheme 380

Scheme 381

Scheme 382

Scheme 383

Scheme 384

Scheme 385

Scheme 386

Scheme 387

Scheme 388

Scheme 389

Scheme 390

Scheme 391

Scheme 392

Scheme 393

Scheme 394

Scheme 395

Scheme 396

Scheme 397

Scheme 398

Scheme 399

Scheme 400

Scheme 401

Scheme 402

Scheme 403

Scheme 404

Scheme 405

Scheme 406

Scheme 407

Scheme 408

Disconnect the support struts from both sides of the pivot ball (bolted to the hood). Secure the hood in a vertical position. Install the right side pivot ball into the lower threaded hole. NOTE: Do not attempt to close the hood with the support strut in the vertical position, as it will damage the support strut and hood.
Relieve the fuel pressure (see «FUEL PRESSURE RELIEVING»(/acura/tl/iv-2011-2014/remont/fuel-system/#fuel-supply-system__fuel-pressure-relieving) ).
Remove the engine compartment covers (see «ENGINE COMPARTMENT COVER REPLACEMENT»(/acura/tl/iv-2011-2014/remont/exteriorinterior-trim/#exterior-trim__engine-compartment-cover-replacement) ).
Remove the air intake duct splash separator.
Do the battery removal procedure (see «BATTERY REMOVAL AND INSTALLATION»(/acura/tl/iv-2011-2014/remont/body-electrical/#battery) ).
Remove the air cleaner (see «THROTTLE BODY CLEANING»(/acura/tl/iv-2011-2014/remont/mechanical/#intake-air-system__throttle-body-cleaning) ).
Remove the harness clamp (A) from the battery base (B).
M/T model: Remove the harness clamps (C) from the battery base.
Remove the bolts (D), and loosen the bolt (E), then remove the battery base.
M/T model: Remove the harness clamp (A) and the ground cable (B), then disconnect the positive starter cable (C).
A/T model: Remove the harness clamps (A), then disconnect the positive starter cable (B).
Remove the strut brace (see «FRAME BRACE REPLACEMENT»(/acura/tl/iv-2011-2014/remont/exterior-body-panels/#frame) ).
Disconnect the battery cable (A) from the under-hood fuse/relay box.
Remove the harness clamps (B).
Remove the harness clamp (A), then disconnect the harness connectors (B).
Remove the harness clamp (A), then disconnect the ECM/PCM connectors (B).
Remove the quick-connect fitting cover (A), then disconnect the fuel feed hose (B) (see «FUEL LINE/QUICK-CONNECT FITTING REMOVAL»(/acura/tl/iv-2011-2014/remont/fuel-system/#fuel-supply-system) ).
Disconnect the brake booster vacuum hose (A) and the EVAP canister hose (B).
M/T model: Remove the three bolts securing the shift cable holder, then remove the shift cable and the select cable (see step 23 under «TRANSMISSION REMOVAL»(/acura/tl/iv-2011-2014/remont/manual-trans/#manual-transmission__transmission-removal) ). Do not bend the cables excessively.
M/T model: Remove the clutch slave cylinder and the clutch line bracket mounting nut (see step 24 under «TRANSMISSION REMOVAL»(/acura/tl/iv-2011-2014/remont/manual-trans/#manual-transmission__transmission-removal) ). Do not operate the clutch pedal once the slave cylinder has been removed.
A/T model: Remove the shift cable (see «SHIFT CABLE REPLACEMENT»(/acura/tl/iv-2011-2014/remont/automatic-trans/#automatic-transmission) ). Do not bend the shift cable excessively.
Remove the drive belt (see «DRIVE BELT REPLACEMENT»(/acura/tl/iv-2011-2014/remont/charging-system/#charging-system__drive-belt-replacement) ).
Disconnect the EPS connectors (A).
Remove the steering joint cover (A).
Loosen the upper steering joint bolt (B) and the lower steering bolt (C).
Center the steering wheel spokes, and install a commercially available steering wheel holder tool (A).
Remove the lower steering joint bolt (A). Disconnect the steering joint (B) by sliding the steering joint into the column shaft (C). Tighten the upper steering joint bolt (D) to hold the steering joint in place. NOTE: Do not disconnect the steering joint from the column shaft.
Remove the center guide (A) (if equipped) from the top of the pinion shaft (B), and discard it.
Wrap vinyl tape over the splines on the pinion shaft.
Wait until the engine is cool, then carefully remove the radiator cap.
Raise the vehicle on the lift.
Remove the front wheels.
Remove the front splash shield (see «FRONT SPLASH SHIELD REPLACEMENT»(/acura/tl/iv-2011-2014/remont/exterior-body-panels/#fenderwell__front-splash-shield-replacement) ).
Loosen the drain plug in the radiator, and drain the engine coolant (see «COOLANT CHECK»(/acura/tl/iv-2011-2014/remont/cooling-fan/#engine-cooling-system) ).
Drain the transmission fluid: Manual transmission (see «TRANSMISSION FLUID INSPECTION AND REPLACEMENT»(/acura/tl/iv-2011-2014/remont/manual-trans/#manual-transmission__transmission-fluid-inspection-and-replacement) ) Automatic transmission (see «ATF REPLACEMENT»(/acura/tl/iv-2011-2014/remont/automatic-trans/#automatic-transmission__atf-replacement) )
Drain the engine oil (see «ENGINE OIL LEVEL CHECK»(/acura/tl/iv-2011-2014/remont/lubrication-system/#engine-lubrication) ).
Remove the damper fork (see step 4 under «DAMPER/SPRING REMOVAL AND INSTALLATION»(/acura/tl/iv-2011-2014/remont/suspension-front/#front-suspension) ).
Separate the tie-rod end ball joints from the knuckles (see step 13 under «RACK END REMOVAL AND INSTALLATION»(/acura/tl/iv-2011-2014/remont/electronic-steering/#electronic-power-steering-eps-system) ).
Separate the knuckles from the suspension lower arms (see step 7 under «LOWER ARM REMOVAL/INSTALLATION»(/acura/tl/iv-2011-2014/remont/suspension-front/#front-suspension__lower-arm-removalinstallation) ).
Remove the driveshafts (see «DRIVESHAFT INSPECTION»(/acura/tl/iv-2011-2014/remont/axle-shafts/#drivelineaxle-tl__driveshaft-inspection) ). Coat all precision-finished surfaces with new engine oil. Tie plastic bags over the driveshaft ends.
Remove the front subframe stiffener.
Remove exhaust pipe A. With SH-AWD
With SH-AWD: Remove the propeller shaft (see «PROPELLER SHAFT REMOVAL»(/acura/tl/iv-2011-2014/remont/axle-shafts/#drivelineaxle-tl) ).
With SH-AWD: Remove the transfer assembly: Manual transmission (see «TRANSFER ASSEMBLY FLUID INSPECTION AND REPLACEMENT»(/acura/tl/iv-2011-2014/remont/manual-trans/#manual-transmission) ) Automatic transmission (see «TRANSFER ASSEMBLY REMOVAL»(/acura/tl/iv-2011-2014/remont/automatic-trans/#automatic-transmission) )
A/T model: Disconnect the ATF cooler hoses from the transmission, then plug the ATF cooler hoses and the lines (see step 44 under «TRANSMISSION REMOVAL»(/acura/tl/iv-2011-2014/remont/automatic-trans/#automatic-transmission__transmission-removal) ).
Lower the vehicle on the lift.
Disconnect the upper radiator hose (A) and the lower radiator hose (B).
Disconnect the heater hoses.
Remove the radiator (see «RADIATOR REPLACEMENT»(/acura/tl/iv-2011-2014/remont/cooling-fan/#engine-cooling-system) ).
Disconnect the A/C compressor clutch connector (A), and remove the harness clamp (B).
Remove the A/C compressor without disconnecting the A/C hoses. Do not bend the A/C hoses excessively. NOTE: Hang the A/C compressor with a wire tie.
Remove the bolt (A) securing the connector bracket (B) from the front cylinder head; use the bracket bolt hole (C) to attach the engine hanger balance bar front arm.
Remove the harness clamp (A), then remove the bolt (B) securing the engine mount control solenoid valve bracket (C) from the rear cylinder head; use the bracket bolt hole (D) to attach the 2008 V6 attachment arm.
A/T model: Disconnect the vacuum hose (E).
Install the engine hanger balance bar (VSB02C000019). Attach the front arm (A) to the front cylinder head with a 10 mm (0.39 in) spacer (B) and a 10 x 1.25 mm bolt (C). Remove the rear arm from the engine hanger balance bar, then install the 2008 V6 attachment arm (SIL02C000033). Attach the 2008 V6 attachment arm to the rear cylinder head with a 10 mm (0.39 in) spacer (D) and an 8 x 1.25 mm bolt (E).
Install the engine support hanger (AAR-T1256) onto the vehicle as shown, and attach the hook to the slotted hole in the engine hanger balance bar. Tighten the wing nut (F) by hand, and lift and support the engine/transmission. NOTE: Be careful when working around the windshield. AAR-T1256 two sets required for stacking two cross section bars.
M/T model: Remove the front engine mount (see «FRONT ENGINE MOUNT REMOVAL AND INSTALLATION»(/acura/tl/iv-2011-2014/remont/mechanical/#engine-assembly) ).
A/T model: Disconnect the vacuum hose (A) and remove the front engine mount stop (B), then remove the front engine mount bolt (C).
M/T model: Remove the rear engine mount bolt (A).
A/T model: Remove the rear engine mount stop (A), then remove the rear engine mount bolt (B).
Raise the vehicle on the lift.
Loosen the subframe middle mount bolts.
Remove the lower transmission mount nuts (A).
A/T model: Remove the ground cable (B).
Attach the subframe adapter (VSB02C000016) to the front subframe by looping the belt (A) over the front of the subframe (B), then secure the belt with its stop (C).
Raise the transmission jack and line up the slots in the subframe adapter arms with the bolt holes on the jack base, then securely attach them with four bolts.
Remove the four 12 x 1.25 mm bolts (A) securing the subframe stiffeners (B), the four subframe mounting bolts (C), and the stiffeners, then lower the front subframe (D).
Lower the vehicle on the lift.
Attach a chain hoist (A) to the engine hanger (B) and the transmission hanger (C), then lift the engine/transmission until it's securely supported by the chain hoist and remove the engine support hanger, the engine hanger balance bar, and the 2008 V6 attachment arm.
Remove the mounting bolts from the upper half of the side engine mount bracket.
Remove the upper transmission mount bracket mounting bolts. NOTE: Do not remove the bolt (A) from the. upper transmission mount. If the bolt is removed, the upper transmission mount must be replaced as an assembly. M/T model A/T model
Check that the engine/transmission is completely free of the vacuum hoses, the fuel hoses, the coolant hoses, and the electrical wiring.
Slowly lower the engine/transmission about 150 mm (6 in). Check once again that all the hoses and the electrical wiring are disconnected and free from the engine/transmission, then lower it all the way and support it.
Disconnect the chain hoist from the engine/transmission.
Raise the vehicle, and remove the engine/transmission from under the vehicle.

Engine Installation

Special Tools Required

Engine Support Hanger, A and Reds AAR-T1256*
Engine Hanger Balance Bar VSB02C000019*
2008 V6 Attachment Arm SIL02C000033*
Subframe Adapter VSB02C000016*

*: Available through the Acura Tool and Equipment Program, 888-424-6857.

Scheme 409

Scheme 410

Scheme 411

Scheme 412

Scheme 413

Scheme 414

Scheme 415

Scheme 416

Scheme 417

Scheme 418

Scheme 419

Scheme 420

Scheme 421

Scheme 422

Scheme 423

Scheme 424

Scheme 425

Scheme 426

Scheme 427

Scheme 428

Scheme 429

Scheme 430

Scheme 431

Scheme 432

Scheme 433

Scheme 434

Scheme 435

Scheme 436

Scheme 437

Scheme 438

Scheme 439

Scheme 440

Scheme 441

Scheme 442

Scheme 443

Scheme 444

Install the engine mount brackets and the accessory brackets and tighten their bolts to the specified torque.
Position the engine/transmission under the vehicle. Be sure that they are properly aligned. Carefully lower the vehicle until the engine/transmission are properly positioned in the engine compartment. Make sure the vehicle is not resting on any part of the engine/transmission. Support the engine/transmission with a chain hoist (A) and carefully raise the engine/transmission into place. NOTE: Reinstall the mounting bolts/support nuts in the sequence given in the following steps. Failure to follow this sequence may cause excessive noise and vibration, and reduce engine mount life.
Install the new mounting bolts into the upper half of the side engine mount bracket. Tighten the bolts to the specified torque.
Tighten the new upper transmission mount bracket mounting bolts to the specified torque. NOTE: If bolt (A) was removed by mistake during removal, the upper transmission mount bracket must be replaced as an assembly. M/T model A/T model
Install the engine hanger balance bar (VSB02C000019). Attach the front arm (A) to the front cylinder head with a 10 mm (0.39 in) spacer (B) and a 10 x 1.25 mm bolt (C). Remove the rear arm from the engine hanger balance bar, then install the 2008 V6 attachment arm (SIL02C000033). Attach the 2008 V6 attachment arm to the rear cylinder head with a 10 mm (0.39 in) spacer (D) and an 8 x 1.25 mm bolt (E).
Install the engine support hanger (AAR-T1256) onto the vehicle as shown, and attach the hook to the slotted hole in the engine hanger balance bar. Tighten the wing nut (F) by hand, and lift and support the engine/transmission. NOTE: Be careful when working around the windshield. AAR-T1256 two sets required for stacking additional cross section bar.
Remove the chain hoist, then raise the vehicle on the lift.
Attach the subframe adapter (VSB02C000016) to the subframe by looping the belt (A) over the front of the front subframe (B), then secure the belt with its stop (C).
Line up the slots in the subframe adapter arms with the bolt holes on the jack base, then securely attach them with four bolts, then raise the front subframe up to the body.
Loosely install the new subframe mounting bolts (four) (A), the 12 x 1.25 mm bolts (two) (B), the new 12 x 1.25 mm (two) (C), and the stiffeners (D).
Align the front subframe with the subframe alignment pin (see «FRONT SUBFRAME ALIGNMENT»(/acura/tl/iv-2011-2014/remont/exterior-body-panels/#frame) ).
Remove the transmission jack and the front subframe adapter.
Tighten the bolts securing the subframe middle mount.
Tighten the lower transmission mount nuts (A).
A/T model: Install the ground cable (B).
Lower the vehicle on the lift.
Remove the engine support hanger, the engine hanger balance bar, and the 2008 V6 attachment arm.
M/T model: Install the front engine mount (see «FRONT ENGINE MOUNT REMOVAL AND INSTALLATION»(/acura/tl/iv-2011-2014/remont/mechanical/#engine-assembly) ).
A/T model: Tighten the new front engine mount bolt (A), then install the front engine mount stop (B) and connect the vacuum hose (C).
M/T model: Tighten the new rear engine mount bolt.
A/T model: Tighten the new rear engine mount bolt (A), then install the rear engine mount stop (B) using new nuts (C).
Loosen the mounting bolts for the upper half of the side engine mount bracket, then retighten them in the numbered sequence shown.
Loosen the mounting bolts for the upper transmission mount bracket, then retighten them to the specified torque. M/T model A/T model
Install the connector bracket to the front cylinder head.
Install the engine mount control solenoid valve bracket to the rear cylinder head, then install the harness clamp (A).
A/T model: Connect the vacuum hose (B).
Install the A/C compressor, then install the harness clamp (A) and connect the A/C compressor clutch connector (B).
Install the radiator (see «RADIATOR REPLACEMENT»(/acura/tl/iv-2011-2014/remont/cooling-fan/#engine-cooling-system) ).
Connect the heater hoses (A).
Connect the upper radiator hose (A) and the lower radiator hose (B).
Raise the vehicle on the lift.
A/T model: Connect the ATF cooler hoses to the transmission (see step 30 under «TRANSMISSION INSTALLATION»(/acura/tl/iv-2011-2014/remont/automatic-trans/#automatic-transmission__transmission-installation) ).
With SH-AWD: Install the transfer assembly: Manual transmission (see «TRANSFER ASSEMBLY INSTALLATION»(/acura/tl/iv-2011-2014/remont/manual-trans/#manual-transmission) ) Automatic transmission (see «TRANSFER ASSEMBLY INSTALLATION»(/acura/tl/iv-2011-2014/remont/automatic-trans/#automatic-transmission) )
With SH-AWD: Install the propeller shaft (see «PROPELLER SHAFT INSTALLATION»(/acura/tl/iv-2011-2014/remont/axle-shafts/#drivelineaxle-tl) ).
Install exhaust pipe A using new gaskets (6) and new self-locking nuts (C).
Install the front subframe stiffener (A) using new bolts (B).
Install a new set ring on the end of each driveshaft, then install the driveshafts (see «FRONT DRIVESHAFT INSTALLATION»(/acura/tl/iv-2011-2014/remont/axle-shafts/#drivelineaxle-tl__front-driveshaft-installation) ). Make sure each ring "clicks" into place in the differential and the intermediate shaft.
Connect the suspension lower arm to the knuckles (see step 7 under «LOWER ARM REMOVAL/INSTALLATION»(/acura/tl/iv-2011-2014/remont/suspension-front/#front-suspension__lower-arm-removalinstallation) ).
Connect the tie-rod end ball joints to the knuckles (see step 42 under «STEERING GEARBOX REMOVAL AND INSTALLATION»(/acura/tl/iv-2011-2014/remont/electronic-steering/#electronic-power-steering-eps-system__steering-gearbox-removal-and-installation) ).
Install the damper fork (see step 4 under «DAMPER/SPRING REMOVAL AND INSTALLATION»(/acura/tl/iv-2011-2014/remont/suspension-front/#front-suspension) ).
Install the front splash shield (see «FRONT SPLASH SHIELD REPLACEMENT»(/acura/tl/iv-2011-2014/remont/exterior-body-panels/#fenderwell__front-splash-shield-replacement) ).
Install the front wheels.
Lower the vehicle on the lift.
Loosen the upper steering joint bolt (A), and slip the lower end of the steering joint (B) onto the pinion shaft (C).
Align the bolt hole (D) on the steering joint with the groove (E) around the pinion shaft, then loosely install the lower steering joint bolt (F). Be sure that the joint bolt is securely in the groove in the pinion shaft.
Remove the steering wheel holder tool (A).
Tighten the upper and lower steering joint bolts (A) to the specified torque.
Install the steering joint cover (B).
Install the drive belt (see «DRIVE BELT REPLACEMENT»(/acura/tl/iv-2011-2014/remont/charging-system/#charging-system__drive-belt-replacement) ).
Connect the EPS connectors (A).
A/T model: Install the shift cable (see «SHIFT CABLE REPLACEMENT»(/acura/tl/iv-2011-2014/remont/automatic-trans/#automatic-transmission) ).
M/T model: Install the clutch slave cylinder and the clutch line bracket mounting bolt (see step 49 under «TRANSMISSION INSTALLATION»(/acura/tl/iv-2011-2014/remont/manual-trans/#manual-transmission__transmission-installation) ).
M/T model: Install the shift cable and the select cable, then tighten the three bolts securing the shift cable holder (see step 50 under «TRANSMISSION INSTALLATION»(/acura/tl/iv-2011-2014/remont/manual-trans/#manual-transmission__transmission-installation) ).
Connect the brake booster vacuum hose (A) and the EVAP canister hose (B).
Connect the fuel feed hose (A), then install the quick-connect fitting cover (B) (see «FUEL LINE/QUICK-CONNECT FITTING INSTALLATION»(/acura/tl/iv-2011-2014/remont/fuel-system/#fuel-supply-system) ).
Connect the ECM/PCM connectors (A), then install the harness clamp (B).
Connect the harness connectors (A), then install the harness clamp (B).
Install the harness clamps (A).
Connect the battery cable (B) to the under-hood fuse/relay box.
Install the strut brace (see «FRAME BRACE REPLACEMENT»(/acura/tl/iv-2011-2014/remont/exterior-body-panels/#frame) ).
M/T model: Connect the positive starter cable (A), then install the harness clamp (B). Make sure the crimped side of the ring terminal face away from the starter when you connect it.
M/T model: Install the ground cable (C).
A/T model: Connect the positive starter cable (A), then install the harness clamps (B). Make sure the crimped side of the ring terminal face away from the starter when you connect it.
Install the battery base (A), then install the harness clamp (B).
M/T model: Install the harness clamps (C).
Install the air cleaner (see «THROTTLE BODY CLEANING»(/acura/tl/iv-2011-2014/remont/mechanical/#intake-air-system__throttle-body-cleaning) ).
Do the battery installation procedure (see «BATTERY REMOVAL AND INSTALLATION»(/acura/tl/iv-2011-2014/remont/body-electrical/#battery) ).
Install the air intake duct splash separator.
Inspect for fuel leaks. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode (do not operate the starter) so the fuel pump runs for about 2 seconds and pressurizes the fuel line. Repeat this operation three times, then check for fuel leaks at any point in the fuel line.
Refill the engine with engine oil (see «ENGINE OIL LEVEL CHECK»(/acura/tl/iv-2011-2014/remont/lubrication-system/#engine-lubrication) ).
Refill the transmission with fluid: Manual transmission (see «TRANSMISSION FLUID INSPECTION AND REPLACEMENT»(/acura/tl/iv-2011-2014/remont/manual-trans/#manual-transmission__transmission-fluid-inspection-and-replacement) ) Automatic transmission (see «ATF REPLACEMENT»(/acura/tl/iv-2011-2014/remont/automatic-trans/#automatic-transmission__atf-replacement) )
M/T model: Check that the transmission shifts into all gears smoothly.
A/T model: Move the shift lever to each gear, and verify that the A/T gear position indicator follows the transmission range switch.
Refill the radiator with engine coolant, and bleed the air from the cooling system (see «COOLANT CHECK»(/acura/tl/iv-2011-2014/remont/cooling-fan/#engine-cooling-system) ).
Check for fluid leaks.
Do the ECM/PCM reset procedure (see «HDS CLEAR COMMAND»(/acura/tl/iv-2011-2014/remont/testing-diagnostics/#fuel-and-emissions-systems__hds-clear-command) ).
Do the CKP pattern clear/CKP pattern learn procedure (see «CKP PATTERN CLEAR/CKP PATTERN LEARN»(/acura/tl/iv-2011-2014/remont/testing-diagnostics/#fuel-and-emissions-systems) ).
Inspect the idle speed (see «IDLE SPEED INSPECTION»(/acura/tl/iv-2011-2014/remont/testing-diagnostics/#idle-control-system__idle-speed-inspection) ).
Inspect the ignition timing (see «IGNITION TIMING INSPECTION»(/acura/tl/iv-2011-2014/remont/ignition-system/#ignition-system) ).
Install the engine compartment covers (see «ENGINE COMPARTMENT COVER REPLACEMENT»(/acura/tl/iv-2011-2014/remont/exteriorinterior-trim/#exterior-trim__engine-compartment-cover-replacement) ).
Check the wheel alignment (see «WHEEL ALIGNMENT»(/acura/tl/iv-2011-2014/remont/wheel-alignment/#front-and-rear-suspension-inspection__wheel-alignment) ).

Scheme 445

Scheme 445: Removal

Scheme 446

Remove the engine compartment covers (see «ENGINE COMPARTMENT COVER REPLACEMENT»(/acura/tl/iv-2011-2014/remont/exteriorinterior-trim/#exterior-trim__engine-compartment-cover-replacement) ).
Lift and support the engine with a jack and a wood block under the oil pan.
Remove the ground cable (A), then remove the upper half of the side engine mount bracket (B).
Remove the side engine mount.

Scheme 447

Scheme 447: Installation

Scheme 448

Install the side engine mount using new bolts.
Loosely install the upper half of the side engine mount bracket (A) using new bolts.
Remove the jack and the wood block.
Tighten the bolts in the numbered sequence shown.
Install the ground cable (B).
Install the engine compartment covers (see «ENGINE COMPARTMENT COVER REPLACEMENT»(/acura/tl/iv-2011-2014/remont/exteriorinterior-trim/#exterior-trim__engine-compartment-cover-replacement) ).

Scheme 449

Scheme 449: Removal

Scheme 450

Remove the engine compartment covers (see «ENGINE COMPARTMENT COVER REPLACEMENT»(/acura/tl/iv-2011-2014/remont/exteriorinterior-trim/#exterior-trim__engine-compartment-cover-replacement) ).
Remove the front warm up TWC (see «WARM UP TWC REMOVAL/INSTALLATION»(/acura/tl/iv-2011-2014/remont/exhaust/#catalytic-converter-system) ).
Remove the front engine mount stop (A), then remove the front engine mount bolt (B).
Remove the front engine mount mounting bolts (A). A
Lift and support the engine with a jack and a wood block under the engine/transmission.
Remove the front engine mount and disconnect the vacuum hose (B). NOTE: A/T model: Do not bend the ATF cooler pipe when removing the front engine mount.

Scheme 451

Scheme 451: Installation

Scheme 452

Connect the vacuum hose (A), then align the front engine mount with its mounting holes and install the new front engine mount mounting bolts (B). NOTE: A/T model: Do not bend the ATF cooler pipe when installing the front engine mount.
Remove the jack and the wood block.
Tighten the new front engine mount bolt (A), then install the front engine mount stop (B) using new nuts.
Install the front warm up TWC (see «WARM UP TWC REMOVAL/INSTALLATION»(/acura/tl/iv-2011-2014/remont/exhaust/#catalytic-converter-system) ).
Install the engine compartment covers (see «ENGINE COMPARTMENT COVER REPLACEMENT»(/acura/tl/iv-2011-2014/remont/exteriorinterior-trim/#exterior-trim__engine-compartment-cover-replacement) ).

Scheme 453

Scheme 453: Removal-M/T model

Scheme 454

Scheme 455

Scheme 456

Scheme 457

Scheme 458

Scheme 459

Scheme 460

Remove the engine compartment covers (see «ENGINE COMPARTMENT COVER REPLACEMENT»(/acura/tl/iv-2011-2014/remont/exteriorinterior-trim/#exterior-trim__engine-compartment-cover-replacement) ).
Do the battery removal procedure (see «BATTERY REMOVAL AND INSTALLATION»(/acura/tl/iv-2011-2014/remont/body-electrical/#battery) ).
Remove the air cleaner (see «THROTTLE BODY CLEANING»(/acura/tl/iv-2011-2014/remont/mechanical/#intake-air-system__throttle-body-cleaning) ).
Remove the cowl cover (see «FRONT BULKHEAD BRACE COVER REPLACEMENT»(/acura/tl/iv-2011-2014/remont/exteriorinterior-trim/#exterior-trim__front-bulkhead-brace-cover-replacement) ).
Remove the strut brace (see «FRAME BRACE REPLACEMENT»(/acura/tl/iv-2011-2014/remont/exterior-body-panels/#frame) ).
Remove the harness clamp (A), then disconnect the harness connectors (B) on the left strut tower.
Remove the two harness clamps (A) and the brake booster vacuum hose clamp (B) from the under-hood fuse/relay box mounting bracket (C).
Remove the mounting bolt (A) and the two mounting nuts (B) from the under-hood fuse/relay box mounting bracket, then tilt the under-hood fuse/relay box forward.
Raise the vehicle on the lift.
Remove the front splash shield (see «FRONT SPLASH SHIELD REPLACEMENT»(/acura/tl/iv-2011-2014/remont/exterior-body-panels/#fenderwell__front-splash-shield-replacement) ).
Remove the front subframe stiffener (see step 41 ).
Remove exhaust pipe A (see step 42 ).
Remove the two rear engine mount bracket mounting bolts (A).
Lower the vehicle on the lift.
Lift and support the engine with a jack and a wood block under the engine/transmission.
Remove the harness bracket (A).
Remove the rear engine mount mounting bolt (B), then remove the two rear engine mount bracket mounting bolts (C).
Remove the rear engine mount bracket (A) from the top by sliding it out, and lifting it out from the driver's side.
Remove the rear engine mount mounting bolts (A).
Remove the rear engine mount (A).

Scheme 461

Scheme 461: Installation-M/T model

Scheme 462

Scheme 463

Scheme 464

Scheme 465

Scheme 466

Scheme 467

Scheme 468

Scheme 469

Install the rear engine mount (A).
Align the rear engine mount with its mounting holes and install the new rear engine mount mounting bolts (A).
Install the rear engine mount bracket (A) from the top by sliding it into place from the driver's side.
Loosely install the new two rear engine mount bracket mounting bolts (A) and the new rear engine mount mounting bolt (B).
Install the harness bracket (C).
Remove the jack and the wood block, then raise the vehicle on the lift.
Tighten the new two rear engine mount bracket mounting bolts (A).
Install exhaust pipe A (see step 35 ).
Install the front subframe stiffener (see step 36 ).
Install the front splash shield (see «FRONT SPLASH SHIELD REPLACEMENT»(/acura/tl/iv-2011-2014/remont/exterior-body-panels/#fenderwell__front-splash-shield-replacement) ).
Lower the vehicle on the lift.
Tighten the two rear engine mount bracket mounting bolts (A), then tighten the rear engine mount mounting bolt (B).
Install the under-hood fuse/relay box with the mounting bracket, and tighten the two mounting nuts (A) and the mounting bolt (B).
Install the two harness clamps (A) and the brake booster vacuum hose clamp (B) to the under-hood fuse/relay box mounting bracket (C).
Connect the harness connectors (A), then install the harness clamp (B) on the left strut tower.
Install the strut brace (see «FRAME BRACE REPLACEMENT»(/acura/tl/iv-2011-2014/remont/exterior-body-panels/#frame) ).
Install the cowl cover (see «FRONT BULKHEAD BRACE COVER REPLACEMENT»(/acura/tl/iv-2011-2014/remont/exteriorinterior-trim/#exterior-trim__front-bulkhead-brace-cover-replacement) ).
Install the air cleaner (see «THROTTLE BODY CLEANING»(/acura/tl/iv-2011-2014/remont/mechanical/#intake-air-system__throttle-body-cleaning) ).
Do the battery installation procedure (see «BATTERY REMOVAL AND INSTALLATION»(/acura/tl/iv-2011-2014/remont/body-electrical/#battery) ).
Install the engine compartment covers (see «ENGINE COMPARTMENT COVER REPLACEMENT»(/acura/tl/iv-2011-2014/remont/exteriorinterior-trim/#exterior-trim__engine-compartment-cover-replacement) ).

Scheme 470

Scheme 470: Removal-A/T model

Scheme 471

Scheme 472

Scheme 473

Scheme 474

Scheme 475

Scheme 476

Remove the engine compartment covers (see «ENGINE COMPARTMENT COVER REPLACEMENT»(/acura/tl/iv-2011-2014/remont/exteriorinterior-trim/#exterior-trim__engine-compartment-cover-replacement) ).
Do the battery removal procedure (see «BATTERY REMOVAL AND INSTALLATION»(/acura/tl/iv-2011-2014/remont/body-electrical/#battery) ).
Remove the air cleaner (see «THROTTLE BODY CLEANING»(/acura/tl/iv-2011-2014/remont/mechanical/#intake-air-system__throttle-body-cleaning) ).
Remove the cowl cover (see «FRONT BULKHEAD BRACE COVER REPLACEMENT»(/acura/tl/iv-2011-2014/remont/exteriorinterior-trim/#exterior-trim__front-bulkhead-brace-cover-replacement) ).
Remove the strut brace (see «FRAME BRACE REPLACEMENT»(/acura/tl/iv-2011-2014/remont/exterior-body-panels/#frame) ).
Remove the harness clamp (A), then disconnect the harness connectors (B) on the left strut tower.
Remove the two harness clamps (A) and the brake booster vacuum hose clamp (B) from the under-hood fuse/relay box mounting bracket (C).
Remove the mounting bolt (A) and the two mounting nuts (B) from the under-hood fuse/relay box mounting bracket, then tilt the under-hood fuse/relay box forward.
Remove the vacuum hose (A) from the clamp (B) and disconnect the vacuum hose from the three way valve (C).
Remove the rear engine mount stop (A), then remove the rear engine mount bolt (B).
Remove the rear engine mount mounting bolts (A). A
Lift and support the engine with a jack and a wood block under the engine/transmission.
Remove the rear engine mount (A) from the top by sliding it out, and lifting it out from the driver's side.

Scheme 477

Scheme 477: Installation-A/T model

Scheme 478

Scheme 479

Scheme 480

Scheme 481

Scheme 482

Scheme 483

Install the rear engine mount (A) from the top by sliding it into place from the driver's side and route the vacuum hose (B) through the hole in the mount base bracket (C).
Align the rear engine mount with its mounting holes and install the new rear engine mount mounting bolts (A).
Remove the jack and the wood block.
Tighten the new rear engine mount bolt (A), then install the rear engine mount stop (B) using new nuts.
Connect the vacuum hose (A) to the three way valve (B) and install the vacuum hose on its clamp (C) at the mark (D).
Install the under-hood fuse/relay box with the mounting bracket, and tighten the two mounting nuts (A) and the mounting bolt (B).
Install the two harness clamps (A) and the brake booster vacuum hose clamp (B) to the under-hood fuse/relay box mounting bracket (C).
Connect the harness connectors (A), then install the harness clamp (B) on the left strut tower.
Install the strut brace (see «FRAME BRACE REPLACEMENT»(/acura/tl/iv-2011-2014/remont/exterior-body-panels/#frame) ).
Install the cowl cover (see «FRONT BULKHEAD BRACE COVER REPLACEMENT»(/acura/tl/iv-2011-2014/remont/exteriorinterior-trim/#exterior-trim__front-bulkhead-brace-cover-replacement) ).
Install the air cleaner (see «THROTTLE BODY CLEANING»(/acura/tl/iv-2011-2014/remont/mechanical/#intake-air-system__throttle-body-cleaning) ).
Do the battery installation procedure (see «BATTERY REMOVAL AND INSTALLATION»(/acura/tl/iv-2011-2014/remont/body-electrical/#battery) ).
Install the engine compartment covers (see «ENGINE COMPARTMENT COVER REPLACEMENT»(/acura/tl/iv-2011-2014/remont/exteriorinterior-trim/#exterior-trim__engine-compartment-cover-replacement) ).

Scheme 484

Scheme 484: Removal-M/T model

Scheme 485

Remove the front splash shield (see «FRONT SPLASH SHIELD REPLACEMENT»(/acura/tl/iv-2011-2014/remont/exterior-body-panels/#fenderwell__front-splash-shield-replacement) ).
Remove the engine compartment covers (see «ENGINE COMPARTMENT COVER REPLACEMENT»(/acura/tl/iv-2011-2014/remont/exteriorinterior-trim/#exterior-trim__engine-compartment-cover-replacement) ).
Remove the air cleaner (see «THROTTLE BODY CLEANING»(/acura/tl/iv-2011-2014/remont/mechanical/#intake-air-system__throttle-body-cleaning) ).
Lift and support the engine with a jack and a wood block under the transmission.
Remove the upper transmission mount bracket mounting bolts. NOTE: Do not remove the bolt (A) from the upper transmission mount. If the bolt is removed, the upper transmission mount must be replaced as an assembly.
Remove the upper transmission mount.

Scheme 486

Scheme 486: Installation-M/T model

Scheme 487

Install the upper transmission mount.
Loosely install the new upper transmission mount bracket mounting bolts.
Remove the jack and the wood block.
Tighten the upper transmission mount bracket mounting bolts.
Install the air cleaner (see «THROTTLE BODY CLEANING»(/acura/tl/iv-2011-2014/remont/mechanical/#intake-air-system__throttle-body-cleaning) ).
Install the engine compartment covers (see «ENGINE COMPARTMENT COVER REPLACEMENT»(/acura/tl/iv-2011-2014/remont/exteriorinterior-trim/#exterior-trim__engine-compartment-cover-replacement) ).
Install the front splash shield (see «FRONT SPLASH SHIELD REPLACEMENT»(/acura/tl/iv-2011-2014/remont/exterior-body-panels/#fenderwell__front-splash-shield-replacement) ).

Scheme 488

Scheme 488: Removal-A/T model

Scheme 489

Remove the front splash shield (see «FRONT SPLASH SHIELD REPLACEMENT»(/acura/tl/iv-2011-2014/remont/exterior-body-panels/#fenderwell__front-splash-shield-replacement) ).
Remove the engine compartment covers (see «ENGINE COMPARTMENT COVER REPLACEMENT»(/acura/tl/iv-2011-2014/remont/exteriorinterior-trim/#exterior-trim__engine-compartment-cover-replacement) ).
Remove the air cleaner (see «THROTTLE BODY CLEANING»(/acura/tl/iv-2011-2014/remont/mechanical/#intake-air-system__throttle-body-cleaning) ).
Lift and support the engine with a jack and a wood block under the transmission.
Disconnect the transmission fluid pressure switch E (6th clutch) connector (A). Remove the harness bracket (B), then remove the upper transmission mount bracket mounting bolts. NOTE: Do not remove the bolt (C) from the upper transmission mount. If the bolt is removed, the upper transmission mount must be replaced as an assembly.
Remove the upper transmission mount.

Scheme 490

Scheme 490: Installation-A/T model

Scheme 491

Install the upper transmission mount.
Loosely install the new upper transmission mount bracket mounting bolts, then install the harness bracket (A). Connect the transmission fluid pressure switch E (6th clutch) connector (B).
Remove the jack and the wood block.
Tighten the upper transmission mount bracket mounting bolts.
Install the air cleaner (see «THROTTLE BODY CLEANING»(/acura/tl/iv-2011-2014/remont/mechanical/#intake-air-system__throttle-body-cleaning) ).
Install the engine compartment covers (see «ENGINE COMPARTMENT COVER REPLACEMENT»(/acura/tl/iv-2011-2014/remont/exteriorinterior-trim/#exterior-trim__engine-compartment-cover-replacement) ).
Install the front splash shield (see «FRONT SPLASH SHIELD REPLACEMENT»(/acura/tl/iv-2011-2014/remont/exterior-body-panels/#fenderwell__front-splash-shield-replacement) ).

Scheme 492

Scheme 492: Removal-M/T model

Remove the front splash shield (see «FRONT SPLASH SHIELD REPLACEMENT»(/acura/tl/iv-2011-2014/remont/exterior-body-panels/#fenderwell__front-splash-shield-replacement) ).
Support the engine/transmission with a transmission jack.
Remove the lower transmission mount bracket (A), then remove the lower transmission mount (B).

Scheme 493

Scheme 493: Installation-M/T model

Install the lower transmission mount (A).
Loosely install the lower transmission mount bracket (B) using new bolts.
Remove the transmission jack.
Tighten the lower transmission mount bracket mounting bolts and the lower transmission mount mounting nuts.
Install the front splash shield (see «FRONT SPLASH SHIELD REPLACEMENT»(/acura/tl/iv-2011-2014/remont/exterior-body-panels/#fenderwell__front-splash-shield-replacement) ).

Scheme 494

Scheme 494: Removal-A/T model

Remove the front splash shield (see «FRONT SPLASH SHIELD REPLACEMENT»(/acura/tl/iv-2011-2014/remont/exterior-body-panels/#fenderwell__front-splash-shield-replacement) ).
Lift and support the engine with a transmission jack and a wood block under the transmission.
Remove the lower transmission mount bracket (A), then remove the lower transmission mount (B).

Scheme 495

Scheme 495: Installation-A/T model

Install the lower transmission mount (A).
Loosely install the lower transmission mount bracket (B) using new bolts (C).
Remove the transmission jack and the wood block.
Tighten the lower transmission mount bracket mounting bolts and the lower transmission mount mounting nuts.
Install the front splash shield (see «FRONT SPLASH SHIELD REPLACEMENT»(/acura/tl/iv-2011-2014/remont/exterior-body-panels/#fenderwell__front-splash-shield-replacement) ).

Engine Assembly Acura TL IV рестайлинг
