Fan Controls Acura TL IV рестайлинг

Cooling Fan 10 illustrations ~789 words

Scheme 34

Scheme 34: Component Location Index
Scheme 34: Component Location Index

Symptom Troubleshooting Index

SymptomDiagnostic ProcedureAlso check for
Engine overheatsCheck the coolant level. Check for any engine coolant leakage (from gaskets, hoses, O-rings, etc.). Check for dirt, leaves, or insects on the radiator and A/C condenser. Check for deteriorated coolant. Check for damaged or deformed fan shrouds. Check the fan motors are operating properly (air should be blowing toward the engine). Inspect the fan motors (see FAN MOTOR TEST ) or fan relays: A/C condenser fan relay (see POWER RELAY TEST ) Relay circuit board (see FIVE-TERMINAL TYPE ) Check the radiator cap (see RADIATOR CAP TEST ). Check the thermostat (see FAN MOTOR TEST ). Inspect the water pump (see WATER PUMP INSPECTION ). Check for plugged or deteriorated radiator hoses. Check for a plugged heater core or hoses. Check for a damaged cylinder head gasket.Check the radiator and A/C condenser fan are operating properly
The radiator fan does not run at high speedRadiator fan high speed circuit troubleshooting (see RADIATOR FAN HIGH SPEED CIRCUIT TROUBLESHOOTING ).Check the connectors are properly connected and the terminals are making good contact
Both the radiator fan and the A/C condenser fan do not run at low speedRadiator and A/C condenser fans low speed circuit troubleshooting (see RADIATOR AND A/C CONDENSER FAN LOW SPEED CIRCUIT TROUBLESHOOTING ).Check the connectors are properly connected and the terminals are making good contact
The A/C condenser fan does not run at high speedA/C condenser fan high speed circuit troubleshooting (see A/C CONDENSER FAN HIGH SPEED CIRCUIT TROUBLESHOOTING ).Check the connectors are properly connected and the terminals are making good contact

Scheme 35

Scheme 35: Without Keyless Access System
Scheme 35: Without Keyless Access System

Scheme 36

Scheme 36: With Keyless Access System
Scheme 36: With Keyless Access System

Radiator Fan High Speed Circuit Troubleshooting

Note. Information marked with an asterisk (*1) applies to without SH-AWD and (*2) applies to with SH-AWD.

Scheme 37

Scheme 37: Radiator Fan High Speed Circuit Troubleshooting
Scheme 37: Radiator Fan High Speed Circuit Troubleshooting

Scheme 38

Scheme 38
Scheme 38

Scheme 39

Scheme 39
Scheme 39

Scheme 40

Scheme 40
Scheme 40

Scheme 41

Scheme 41
Scheme 41

Scheme 42

Scheme 42
Scheme 42

Scheme 43

Scheme 43
Scheme 43
  1. Check the No. 3-5 (30 A) (*1), (40 A) (*2) fuse, the No. 14 (15 A) fuse, and the No. 21 (7.5 A) fuse in the under-hood fuse/relay box, and the No. 16(7.5 A) fuse in the driver's under-dash fuse/relay box. Are the fuse(s) OK? YES - Reinstall the fuses, then go to step 2. NO - Replace the fuse(s) and recheck. If the fuse(s) blow again, repair the short to ground on the No. 3-5 (30A) (*1), (40 A) (*2) fuse, the No. 14 (15A) fuse, the No. 21 (7.5A) fuse, and the No. 16 (7.5A) fuse circuit.
  2. Disconnect and remove the relay circuit board from the under-hood fuse/relay box, and test it (see «FIVE-TERMINAL TYPE»(/acura/tl/iv-2011-2014/remont/body-electrical/#relays__five-terminal-type) ). Is the relay circuit board OK? YES - Go to step 3. NO - Replace the relay circuit board (see «REMOVAL AND INSTALLATION»(/acura/tl/iv-2011-2014/remont/fuses-circuit-breakers/#under-hood-fuserelay-box__removal-and-installation) ).
  3. Measure the voltage between under-hood fuse/relay box connector terminal C3 and body ground. Is there battery voltage? YES - Go to step 4. NO - Replace the under-hood fuse/relay box (see «REMOVAL AND INSTALLATION»(/acura/tl/iv-2011-2014/remont/fuses-circuit-breakers/#under-hood-fuserelay-box__removal-and-installation) ).
  4. Connect under-hood fuse/relay box connector terminals C1 and C3 with a jumper wire. Does the radiator fan run at high speed? YES - Go to step 8 . NO - Go to step 5.
  5. Disconnect the radiator fan motor 2P connector, then test the fan motor (see «FAN MOTOR TEST»(/acura/tl/iv-2011-2014/remont/cooling-fan/#engine-cooling-system) ). Is the fan motor OK? YES - Go to step 6. NO - Replace the radiator fan motor (see «FAN, FAN MOTOR, AND SHROUD REMOVAL AND INSTALLATION»(/acura/tl/iv-2011-2014/remont/cooling-fan/#engine-cooling-system) ).
  6. Check for continuity between under-hood fuse/relay box connector terminal C1 and radiator fan motor 2P connector terminal No. 2. Is there continuity? YES - Go to step 7. NO - Repair an open in the wire between under-hood fuse/relay box connector terminal C1 and radiator fan motor 2P connector terminal No. 2.
  7. Check for continuity between radiator fan motor 2P connector terminal No. 1 and body ground. Is there continuity? YES - Check for poor connections or loose terminals at the radiator fan motor and body ground G302. NO - Repair an open in the wire between radiator fan motor 2P connector terminal No. 1 and body ground.
  8. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  9. Measure the voltage between under-hood fuse/relay box connector terminal B8 and body ground. Is there battery voltage? YES - Go to step 10. NO - Repair an open in the wire between driver's under-dash fuse/relay box connector terminal F26 and under-hood fuse/relay box connector terminal B8.
  10. Measure the voltage between under-hood fuse/relay box connector terminal B9 and body ground. Is there battery voltage? YES - Go to step 11. NO - Check the PGM-FI subrelay. If the relay is OK, replace the under-hood fuse/relay box (see «REMOVAL AND INSTALLATION»(/acura/tl/iv-2011-2014/remont/fuses-circuit-breakers/#under-hood-fuserelay-box__removal-and-installation) ).
  11. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  12. Connect the HDS to the DLC (see «HOW TO USE THE HDS (HONDA DIAGNOSTIC SYSTEM)»(/acura/tl/iv-2011-2014/remont/testing-diagnostics/#fuel-and-emissions-systems__how-to-use-the-hds-honda) ).
  13. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  14. Make sure the HDS communicates with the vehicle and the ECM/PCM. If it does not communicate, troubleshoot the DLC circuit (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/tl/iv-2011-2014/remont/testing-diagnostics/#pgm-fi-system__dlc-circuit-troubleshooting) ).
  15. Jump the SCS line with the HDS, then turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode. NOTE: This step must be done to protect the ECM/PCM from damage.
  16. Disconnect ECM/PCM connector A (49P).
  17. Check for continuity between ECM/PCM connector terminal A5 and under-hood fuse/relay box connector terminal B10. Is there continuity? YES - Update the ECM/PCM if it does not have the latest software (see «ECM/PCM UPDATE»(/acura/tl/iv-2011-2014/remont/testing-diagnostics/#pgm-fi-system__ecmpcm-update) ), or substitute a known-good ECM/PCM (see «SUBSTITUTING THE ECM/PCM»(/acura/tl/iv-2011-2014/remont/testing-diagnostics/#fuel-and-emissions-systems__substituting-the-ecmpcm) ), then recheck. If the symptom/indication goes away with a known-good ECM/PCM, replace the original ECM/PCM (see «ECM/PCM REPLACEMENT»(/acura/tl/iv-2011-2014/remont/testing-diagnostics/#pgm-fi-system__ecmpcm-replacement) ). NO - Repair an open in the wire between under-hood fuse/relay box connector terminal B10 and ECM/PCM connector terminal A5.
