Audio System Acura TL IV

Entertainment Systems 212 illustrations ~28482 words

Scheme 1

Scheme 1: Component Location Index

Scheme 2

Scheme 2

Disconnecting

To disconnect the connector, pull the lever (A) while pushing the lock tab (B) down, then pull the connector (C)

Scheme 3

Scheme 3: Disconnecting

Connecting

To connect the connector, push the connector into the connector sleeve (A) As the connector is pressed in, the lever (B) moves to the locked position

Scheme 4

Scheme 4: Connecting

Symptom Troubleshooting Index

With navigation

SymptomDiagnostic procedureAlso check for
Poor AM or FM radio reception or interferenceSymptom Troubleshooting (see SYMPTOM TROUBLESHOOTING )Antenna lead short or open in the wire Aftermarket window tinting
Audio unit power switch will not turn on (No information display and no sound)Symptom Troubleshooting (see AUDIO UNIT POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) (WITH NAVIGATION) )
Audio unit power switch will not turn offSymptom Troubleshooting (see AUDIO UNIT POWER SWITCH WILL NOT TURN OFF (WITH NAVIGATION) )
No sound is heard from the speaker(s) (display is normal)Symptom Troubleshooting (see NO SOUND IS HEARD FROM THE SPEAKER(S) (DISPLAY IS NORMAL) (WITH NAVIGATION) )
Audio system sound is weak or distorted (display is normal)Symptom Troubleshooting (see AUDIO SYSTEM SOUND IS WEAK OR DISTORTED (DISPLAY IS NORMAL) (WITH NAVIGATION) )
Radio preset memory is lostSymptom Troubleshooting (see RADIO PRESET MEMORY IS LOST (WITH NAVIGATION) )
Volume does not changeSymptom Troubleshooting (see VOLUME DOES NOT CHANGE (WITH NAVIGATION) )
Radio tuner does not change stationsSymptom Troubleshooting (see Radio tuner does not change stations (with navigation) )
Audio system information does not display on the audio-navigation switch panel displaySymptom Troubleshooting (see AUDIO SYSTEM INFORMATION DOES NOT DISPLAY ON THE AUDIO-NAVIGATION SWITCH PANEL DISPLAY (WITH NAVIGATION) )
Audio-navigation switch panel button illumination does not workSymptom Troubleshooting (see AUDIO-NAVIGATION SWITCH PANEL BUTTON ILLUMINATION DOES NOT WORK (WITH NAVIGATION) )
Audio remote switch does not work properlySymptom Troubleshooting (see AUDIO REMOTE SWITCH DOES NOT WORK PROPERLY (WITH NAVIGATION) )
Audio disc does not loadSymptom Troubleshooting (see AUDIO DISC DOES NOT LOAD (WITH NAVIGATION) )Damaged disc
Audio disc does not ejectSymptom Troubleshooting (see AUDIO DISC DOES NOT EJECT (WITH NAVIGATION) )Damaged disc Disc with a label
Audio disc does not playSymptom Troubleshooting (see AUDIO DISC DOES NOT PLAY (WITH NAVIGATION) )Foreign objects such coins or paper inserted into the CD changer/player
Audio disc skipsSymptom Troubleshooting (see AUDIO DISC SKIPS (WITH NAVIGATION) )Tire pressure (over-inflated), disc smudged, or scratched
Audio unit button does not workSymptom Troubleshooting (see AUDIO UNIT BUTTON DOES NOT WORK (WITH NAVIGATION) )
Audio unit disc indicator does not workSymptom Troubleshooting (see AUDIO UNIT DISC INDICATOR DOES NOT WORK (WITH NAVIGATION) )
USB device does not functionSymptom Troubleshooting (see USB DEVICE DOES NOT FUNCTION (WITH NAVIGATION) )
USB input sound is low or cannot be heardSymptom Troubleshooting (see USB INPUT SOUND IS LOW OR CANNOT BE HEARD (WITH NAVIGATION) )
Error code XM NO SIGNAL is displayedSymptom Troubleshooting (see ERROR CODE: XM NO SIGNAL IS DISPLAYED (WITH NAVIGATION) )
Error code XM ANTENNA is displayed (with AcuraLink)Symptom Troubleshooting (see ERROR CODE: XM ANTENNA IS DISPLAYED (WITH ACURALINK) )
XM radio display is blank and no station information is displayed (USA models)Symptom Troubleshooting (see XM RADIO DISPLAY IS BLANK AND NO STATION INFORMATION IS DISPLAYED (USA MODELS WITH NAVIGATION) )Also refer to Audio system information does not display on the audio-navigation switch panel display (see AUDIO SYSTEM INFORMATION DOES NOT DISPLAY ON THE AUDIO-NAVIGATION SWITCH PANEL DISPLAY (WITH NAVIGATION) )
XM radio display is blank and no station information is displayed (Canada models)Symptom Troubleshooting (see XM RADIO DISPLAY IS BLANK AND NO STATION INFORMATION IS DISPLAYED (CANADA MODELS WITH NAVIGATION) )Also refer to Audio system information does not display on the audio-navigation switch panel display (see AUDIO SYSTEM INFORMATION DOES NOT DISPLAY ON THE AUDIO-NAVIGATION SWITCH PANEL DISPLAY (WITH NAVIGATION) )
XM radio preset memory is lost (USA models)Symptom Troubleshooting (see XM RADIO PRESET MEMORY IS LOST (USA MODELS WITH NAVIGATION) )
XM radio preset memory is lost (Canada models)Symptom Troubleshooting (see XM RADIO PRESET MEMORY IS LOST (CANADA MODELS WITH NAVIGATION) )
Poor or no sound with XM radio (Audio unit does display XM channels)Symptom Troubleshooting (see POOR OR NO SOUND WITH XM RADIO (AUDIO UNIT DOES DISPLAY XM CHANNELS) (WITH NAVIGATION) )
No sound when Bluetooth audio is usedHFL Symptom Troubleshooting (see NO SOUND WHEN BLUETOOTH AUDIO IS USED (WITH NAVIGATION) )Bluetooth phone GA-NET line open/short HandsFreeLink control unit Audio-navigation unit
Bluetooth audio does not workHFL Symptom Troubleshooting (see BLUETOOTH AUDIO DOES NOT WORK (WITH NAVIGATION) )Bluetooth phone GA-NET line open/short HandsFreeLink control unit
Bluetooth cell phone cannot be pairedHFL Symptom Troubleshooting (see BLUETOOTH CELL PHONE CANNOT BE PAIRED )Bluetooth phone HandsFreeLink control unit Audio-navigation unit
The communication with cell phone is interrupted or changesHFL Symptom Troubleshooting (see THE COMMUNICATION WITH CELL PHONE IS INTERRUPTED OR CHANGES (WITH NAVIGATION) )Electric wave interference HandsFreeLink control unit Audio-navigation unit Bluetooth phone Harness/connector
Pairing instructions are not displayed on the screenHFL Symptom Troubleshooting (see PAIRING INSTRUCTIONS ARE NOT DISPLAYED ON THE SCREEN )Navigation display unit Bluetooth phone HandsFreeLink control unit The Bluetooth phone may not be compatible (Some Bluetooth phones do not support a part of the guide)
Bluetooth cell phone audio function SKIP and PAUSE/RESUME do not workHFL Symptom Troubleshooting (see BLUETOOTH PHONE AUDIO FUNCTION SKIP AND PAUSE/RESUME DO NOT WORK (WITH NAVIGATION) )Bluetooth phone (Some Bluetooth phones do not support the function) (For further information, please contact the phone company)

SYMPTOM TROUBLESHOOTING CHART

Without navigation

SymptomDiagnostic procedureAlso check for
Poor AM or FM radio reception or interferenceSymptom Troubleshooting (see POOR AM OR FM RADIO RECEPTION OR INTERFERENCE (WITHOUT NAVIGATION) )Antenna lead short or open in the wire Aftermarket window tinting
Audio unit power switch will not turn on (No information display and no sound)Symptom Troubleshooting (see AUDIO UNIT POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) (WITHOUT NAVIGATION) )
Audio unit power switch will not turn offSymptom Troubleshooting (see AUDIO UNIT POWER SWITCH WILL NOT TURN OFF (WITHOUT NAVIGATION) )
No sound is heard from the speaker(s) (display is normal)Symptom Troubleshooting (see NO SOUND IS HEARD FROM THE SPEAKER(S) (DISPLAY IS NORMAL) (WITHOUT NAVIGATION) )
Audio system sound is weak or distorted (display is normal)Symptom Troubleshooting (see AUDIO SYSTEM SOUND IS WEAK OR DISTORTED (DISPLAY IS NORMAL) (WITH NAVIGATION) )
Radio preset memory is lostSymptom Troubleshooting (see RADIO PRESET MEMORY IS LOST (WITH NAVIGATION) )
Volume does not changeSymptom Troubleshooting (see VOLUME DOES NOT CHANGE (WITHOUT NAVIGATION) )
Radio tuner does not change stationsSymptom Troubleshooting (see RADIO TUNER DOES NOT CHANGE STATIONS (WITHOUT NAVIGATION) )
Audio system information does not display on the audio-HVAC display unitSymptom Troubleshooting (see AUDIO SYSTEM INFORMATION DOES NOT DISPLAY ON THE AUDIO-HVAC DISPLAY UNIT (WITHOUT NAVIGATION) )
Audio switch panel button illumination does not workSymptom Troubleshooting (see AUDIO SWITCH PANEL BUTTON ILLUMINATION DOES NOT WORK (WITHOUT NAVIGATION) )
Audio remote switch does not work properlySymptom Troubleshooting (see AUDIO REMOTE SWITCH DOES NOT WORK PROPERLY (WITHOUT NAVIGATION) )
Audio disc does not loadSymptom Troubleshooting (see AUDIO DISC DOES NOT LOAD (WITH NAVIGATION) )Damaged disc
Audio disc does not ejectSymptom Troubleshooting (see AUDIO DISC DOES NOT EJECT (WITH NAVIGATION) )Damaged disc Disc with a label
Audio disc changer does not load all six discsSymptom Troubleshooting (see AUDIO DISC CHANGER DOES NOT LOAD ALL SIX DISCS (WITHOUT NAVIGATION) )Tire pressure (over-inflated), disc smudged, or scratched
Audio disc changer does not move between discsSymptom Troubleshooting (see AUDIO DISC CHANGER DOES NOT LOAD ALL SIX DISCS (WITHOUT NAVIGATION) )
Audio disc does not playSymptom Troubleshooting (see AUDIO DISC DOES NOT PLAY (WITH NAVIGATION) )Foreign objects such coins or paper inserted into the CD changer/player
Audio disc skipsSymptom Troubleshooting (see AUDIO DISC SKIPS (WITHOUT NAVIGATION) )Tire pressure (over-inflated), disc smudged, or scratched
Audio unit button does not workSymptom Troubleshooting (see AUDIO UNIT BUTTON DOES NOT WORK (WITH NAVIGATION) )
Audio unit disc indicator does not workSymptom Troubleshooting (see AUDIO UNIT DISC INDICATOR DOES NOT WORK (WITH NAVIGATION) )
USB device does not functionSymptom Troubleshooting (see USB DEVICE DOES NOT FUNCTION (WITHOUT NAVIGATION) )
USB input sound is low or cannot be heardSymptom Troubleshooting (see USB INPUT SOUND IS LOW OR CANNOT BE HEARD (WITHOUT NAVIGATION) )
Error code XM NO SIGNAL is displayedSymptom Troubleshooting (see ERROR CODE: XM NO SIGNAL IS DISPLAYED (WITHOUT NAVIGATION) )
Error code XM ANTENNA is displayed (without AcuraLink)Symptom Troubleshooting (see ERROR CODE: XM ANTENNA IS DISPLAYED (WITHOUT ACURALINK) )
XM radio display is blank and no station information is displayedSymptom Troubleshooting (see XM RADIO DISPLAY IS BLANK AND NO STATION INFORMATION IS DISPLAYED (WITHOUT NAVIGATION) )Also refer to Audio system information does not display on the audio-HVAC display unit (see AUDIO SYSTEM INFORMATION DOES NOT DISPLAY ON THE AUDIO-HVAC DISPLAY UNIT (WITHOUT NAVIGATION) )
XM radio preset memory is lostSymptom Troubleshooting (see XM RADIO PRESET MEMORY IS LOST (WITHOUT NAVIGATION) )
Poor or no sound with XM radio (Audio unit does display XM channels)Symptom Troubleshooting (see POOR OR NO SOUND WITH XM RADIO (AUDIO UNIT DOES DISPLAY XM CHANNELS) (WITHOUT NAVIGATION) )
No sound when Bluetooth audio is usedHFL Symptom Troubleshooting (see NO SOUND WHEN BLUETOOTH AUDIO IS USED (WITHOUT NAVIGATION) )Bluetooth phone GA-NET line open/short HandsFreeLink control unit Audio unit
Bluetooth audio does not workHFL Symptom Troubleshooting (see BLUETOOTH AUDIO DOES NOT WORK (WITHOUT NAVIGATION) )Bluetooth phone GA-NET line open/short HandsFreeLink control unit
Bluetooth cell phone cannot be pairedHFL Symptom Troubleshooting (see BLUETOOTH CELL PHONE CANNOT BE PAIRED )Bluetooth phone HandsFreeLink control unit Audio unit
The communication with cell phone is interrupted or changesHFL Symptom Troubleshooting (see THE COMMUNICATION WITH CELL PHONE IS INTERRUPTED OR CHANGES (WITHOUT NAVIGATION) )Electric wave interference HandsFreeLink control unit Audio unit Bluetooth phone Harness/connector
Pairing instructions are not displayed on the screenHFL Symptom Troubleshooting (see PAIRING INSTRUCTIONS ARE NOT DISPLAYED ON THE SCREEN )Navigation display unit Bluetooth phone HandsFreeLink control unit The Bluetooth phone may not be compatible (Some Bluetooth phones do not support a part of the guide)
Bluetooth cell phone audio function SKIP and PAUSE/RESUME do not workHFL Symptom Troubleshooting (see BLUETOOTH CELL PHONE AUDIO FUNCTION SKIP AND PAUSE/RESUME DO NOT WORK (WITHOUT NAVIGATION) )Bluetooth phone (Some Bluetooth phones do not support the function) (For further information, please contact the phone company)

SYMPTOM TROUBLESHOOTING CHART

Overview

The audio unit acts as the processor for all audio functions Select audio functions from the audio unit buttons or the audio remote switch (on the steering wheel) The center display provides the current audio status

The audio unit has a built-in EEPROM (electrically erasable programmable read-only memory) This memory holds the audio presets (AM/FM radio frequency, sound settings, etc.) even when the battery is disconnected

A security signal is daisy-chained between the audio and vehicle components for integration into the vehicle's security system

There are two audio systems available for the TL

  1. The ELS audio system is available on vehicles with navigation It includes surround sound with 10 speakers
  2. The premium audio system is on vehicles without navigation It includes 8 speakers
Disc Playback TypesELS Audio SystemPremium Audio System
CD (CD-DA)OO
CD-R/RW (uncompressed)OO
CD-R/RW (MP3/WMA)OO
DVD-AudioOX
DVD-VideoXX
DVD-R/RW (uncompressed)OX
DTS CDOX

PREMIUM AUDIO SYSTEM REFERENCE CHART

o Available

X Not available

HDD recording

The navigation system uses a HDD (hard disc drive) and can store music To record music to the HDD, you must use an original CD or uncompressed CD-R files The music must be loaded on a CD using the CD player You cannot load music through the USB adapter or auxiliary jack

Telematics Muting Logic

The optional navigation system provides voice control for the audio, the XM, and the CD player Voice control commands are communicated through the GA-Net (audio unit) When using the TALK/BACK buttons or route guidance (RG), the center speaker is muted and you hear the navigation instructions through the front speakers When using the HFL/AcuraLink, the center speaker, the rear speakers, and the subwoofer are muted and the front speakers give the telephone sound When using the HFL/AcuraLink and the RG (Route Guidance) or the TALK/BACK buttons, the rear speakers are muted and you hear the telephone sound and navigation instructions through the front speakers Muting commands are passed on the GA-Net bus For more information, see the NAVIGATION SYSTEM . The outline of the audio interruption function is shown in the following table

ContentsAudio output
Center CHLeft front CHRight front CHRight rear CHLeft rear CH
Navigation TALK/BACKMUTENavigation soundNavigation soundAudioAudio
Route GuidanceMUTENavigation soundNavigation soundAudioAudio
HFL/AcuraLinkMUTETelephone soundTelephone soundMUTEMUTE
HFL/AcuraLink and RG or TALK/BACKNavigationTelephone soundTelephone soundMUTEMUTE

AUDIO OUTPUT REFERENCE CHART

Bluetooth Audio

Bluetooth audio allows approved Bluetooth cell phones equipped with music function to play music via a car audio system using Bluetooth technology You can control the phone's music player remotely using the wireless connection

  1. You can play music stored in your cell phone using the wireless connection *1
  2. You can choose next song, previous song and resume/pause via wireless *2

*1 Call phone must support AVRCP1 0, A2DP1 0 for Bluetooth technology, and also be on the Honda approved HFL list at handsfreelink.com

*2 Not all phones support the bluetooth audio function

Supported Devices

  1. Bluetooth music phones that support AVRCP1 0/A2DP1 0
  2. Bluetooth adapters for portable music devices including iPod are not supported

Note. Availability of the functions depends on the connected device The latest support information is updated through the website handsfreelink.com

Pairing a cell phone

To pair a cell phone, refer to pairing a cell phone in the HandsFreeLink system (see NAVIGATION THROUGH HFL MENUS ) Once a cell phone is paired, the process does not have to be repeated for the phone

Scheme 5

Scheme 5: Procedure

Scheme 6

Scheme 6

Scheme 7

Scheme 7

Scheme 8

Scheme 8
  1. Push the AUX button to select Bluetooth Audio source NOTE: If you push the AUX button when no cell phone is connected, NO CONNECT is displayed If you see NO CONNECT when you are using the cell phone music function, check that the device is properly paired If it is paired, the cell phone may not be compatible See «HANDS FREE LINK SYSTEM»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#hands-free-link-system) for more information Music titles and artist names are not displayed
  2. Start playing the music in the paired cell phone NOTE: Depending on the cell phone, the music may start automatically, or the user may need to select headset as an audio output
  3. A user can select the next song or the previous song using the SKIP button
  4. A user can select pause and resume by selecting [RESUME/PAUSE] in the AUDIO MENU using the interface dial

Scheme 9

Scheme 9: With Navigation

Scheme 10

Scheme 10: Without Navigation

Disc Handing and Cleaning

To avoid damaging or leaving fingerprints on a disc (CD, DVD, DVD-A, etc.), always handle it by the edges and place it in a jewel case whenever it is outside the audio or the audio-navigation unit Deep scratches or fingerprints on the back of the disc can cause loading problems, poor sound quality, skipping, or other errors

Scheme 11

Scheme 11: Disc Handing and Cleaning

Smudges and fingerprints can be carefully removed using a mild cleaner and tissues designed to clean eyeglasses To clean a disc, use a clean soft cloth Very gently wipe across the disc from the center to the outside edge, never in a circular motion

Scheme 12

Scheme 12

Do not place stabilizer rings or labels on the disc

Scheme 13

Scheme 13: With Navigation

Scheme 14

Scheme 14: Without Navigation

Note. All items may not apply to this vehicle See the for more information

Audio Glossary

ItemDefinition
Active noise cancellationThe active noise cancellation system cancels some of the vehicle noise This occurs in the 1,500-2,400 RPM range Microphones detect the low frequency sound, and the system outputs a canceling sound from the audio speaker
AM (Amplitude Modulation)The type of transmission used in the standard radio broadcast band from 530 to 1710 kHz
AmplifierA device that increases the level of a signal by increasing the current or voltage
AntennaA device used to send or receive electromagnetic waves through the air
ATA (PC Card)A type of card that has been tested for use in playing WMA and MP3 music files in the PC card slot Sizes of up to 1 GB have been tested
Audio remote switchThe switches on the steering wheel that control the audio system
Auxiliary jackAllows the client to use a portable audio device to input audio recordings
BalanceA control that changes the relative volume of the left and right channels
BandA range of frequencies between two definite limits Bands are assigned by the Federal Communications Commission for specific uses
BassAn adjustment for the low frequency sounds of around 160 Hz and below
Bluetooth AudioAllows the client to play audio recordings stored on their cell phone through the audio system
ByteA unit of storage for computer files and memory A CD holds approximately 700 million bytes
CassetteAudio or video magnetic tape container having two reels Clients can insert it for play back
Compact flashA standard for small-size (3 x 4 cm), memory cards used in mobile computers, PDAs, and digital cameras Compact flash memory cards are available in size of 32 MB up to 4 GB or more and can be played in the audio PC slot Sizes above 1GB have not been tested
CD (Compact Disc)A 4 5-inch plastic disc containing digital audio recording that is played optically on a laser equipped player Never use discs with a paper label In a hot vehicle, labels can curl up and jam the unit
CD (audio disc) changerCD player that can store and play more than one CD Two types are available Some units accept CDs fed into the changer one at a time, and others accept a magazine (with CDs stacked in a container)
CD playerA component designed to play compact disc recordings using a laser optical pickup The signal from a CD player usually requires amplification
Db (Decibels)A method of measuring sound or radio signal strength received by the audio unit antenna
DistortionInexact reproduction of an audio signal caused by playing music at levels the audio system cannot handle
Dolby (noise reduction)A processing system developed by Dolby Laboratories that reduces the background noise on recording media The result is a cleaner playback from the audio system
DUETA serial data communication line used for sub display
DVD (Digital Versatile Disc)A 4 5-inch CD-like format used for storing movies with digital audio and video features The DVD-A format is a DVD format designed for DVD audio systems Some vehicles can play DVD and DVD-A formats
EqualizerA device that changes the relative volume of individual frequency bands to suit personal tastes of the listener
FaderThe control that adjusts the relative volume levels of front and rear speakers in a four-speaker system
FormatTo prepare a PC Card to receive files this function is done on a PC Always choose either FAT or FAT32, as the NTFS format is not accepted by the system Pick the default sectors for the format method selected
FM (Frequency Modulation)The form of modulation used for radio and television sound transmission in most of the world Less prone to interference than AM The FM broadcast band in North America covers roughly 87 7 to 107 9 MHz
GA-NetThe GA-Net allows the audio unit to communicate with all the audio and navigation components in a vehicle If there is an open in the GA-Net or components, the entire audio and navigation system may appear inoperative
GB (Gigabyte)A unit of memory or disk storage equal to one billion bytes (1000 million bytes)
HDDHard disc drive The navigation does not use a DVD, but uses a hard drive to contain the navigation software Can be updated with a CD or DVD that is inserted into the audio disc slot
Hertz (Hz)The unit of frequency equal to one cycle per second (cps) One kilohertz (kHz) equals 1,000 cps, one megahertz (MHz) equals 1 million cps
Integrated amplifierA component that combines a pre amp and a power amp into a single unit A receiver combines an integrated amp and a tuner into a single unit
Jewel caseThe hard plastic case that contains a compact disc or DVD Always use a jewel case to prevent scratches on the underside of a CD or DVD
LCD (Liquid Crystal Display)A type of digital display that changes reflectance or transmittance when an electrical field is applied to it
MemoryCircuitry or devices that hold information in electrical or magnetic form, such as the AM/FM radio presets
MB (Megabyte)One million bytes Written as 1 MB Megabytes are used as a measure of digital storage space For example, a CD can hold 650 MB
MicAn abbreviation for microphone For vehicles with navigation, the microphone accepts navigation voice commands to control audio and navigation functions
MP3 music filesMP3 is an audio coding format MP3 is a popular audio compression format on the Internet and computers CDs and PC cards with these files can be played on some vehicle's audio system
MuteWhen the navigation gives guidance, the front speakers are muted (no music) When you use the voice control system, all of the speakers are muted
NoiseUnwanted random sounds like buzzing, hiss, pops, static, whine, etc.
PC cardThe slot used for playing MP3 and WMA music files The PC Card is usually a combination of a small flash card in a PCMCIA adaptor that slides into the slot The ATA, SD, and compact flash types of cards have been tested up to 1 GB
PCMCIAA computer standard for the slot that the PC card slides into Another term for the PC card slot
ProcessorThe part of an audio device that performs tasks/calculations In the audio unit, the processor handles muting to allow the navigation system to speak its voice commands, and the decoding/playback of the sound files, etc.
RadioA head unit that combines a tuner, a preamplifier, and often a power-amplifier
Route guidance (RG)Spoken voice used for turn-by-turn navigation from the audio speakers
SCF (Cold Start Fix) screensThese screens are displayed if the system requires a GPS initialization The vehicle should be moved outside into an open area away from buildings/power lines
StereoA recording of at least two channels where you can hear sound or music from the left or right side
SD (Secure Digital) cardThis compact type of memory card allows for fast data transfer and has built-in security functions SD cards have a small write-protection switch on the side.
ShieldA metallic foil or braided wire layer surrounding conductors which are designed to prevent electrostatic or electromagnetic interference (noise) from external sources such as buzzing or popping sounds heard on the speakers
Speaker (Loudspeaker)A device that converts electrical energy into acoustical energy (sound)
Speed-sensitive volume compensation (SVC)The SVC increases the audio volume to compensate for increased interior noise when the vehicle is driven at freeway speeds
SubwooferA loudspeaker made to reproduce the lowest audio frequencies, from about 25 Hz to 125 Hz
TrackA sound recording on a CD, tape, or PC Card
TrebleAn adjustment to control the volume of the high frequency sounds
TunerA component (or part of a component) that receives radio signals and selects one broadcast from many
TweeterA speaker designed to reproduce the higher frequencies (treble) only
USBUniversal serial bus The USB is used for playing the compressed audio files (MP3, WMA, ACC, etc.) on the external device through the audio unit
USB jackAllows the clients to play data such as input audio recording from portable audio devices (such as i-pod) or data from USB flash memory
Voice coilA coil of wire wrapped around a tube and then attached to the speaker cone or diaphragm When an audio signal is applied, the coil becomes an electromagnet and interacts with the permanent magnet causing the come or diaphragm to vibrate We interpret this vibrations as sound
Volume controlAllows you to control the loudness of the music
WMA music fileWindows Media Audio File This is an accepted format for music files to be played on either a CD-R, a CD-RW, or a PC Card
WooferA speaker that is designed to reproduce low (bass) frequencies only
XM radioSatellite based radio transmission, which also uses a ground based repeater network to ensure seamless reception The channels originate from XM's broadcast center, in Washington DC, and up link to two satellites These satellites transmit the signal across the entire continental United States
XM receiverThe external component that receives and processes the XM signals from the XM satellites, and terrestrial (land) stations The audio unit communicates to the XM receiver over the GA-Net bus

AUDIO GLOSSARY REFERENCE CHART

With Navigation

Note. Refer to the navigation section for audio-navigation unit connector G, H, and J inputs and outputs (see NAVIGATION UNIT CONNECTORS )

Scheme 15

Scheme 15: With Navigation

Scheme 16

Scheme 16: Audio-Navigation Unit Connector A (24P)
CavityWire ColorTerminal NameConnect to
A1REDILL-LEDGauge control module
A3LT BLUK-LINEData link connector (DLC)
A4WHTSCTY2Navigation display unit
A5YELREMOTE GNDAudio remote, navigation-HFL voice control switch ground
A6WHTSUR R PREStereo amplifier
A7BLKSUR R PRE+Stereo amplifier
A9GRY (1)SUR PRE SHShield for terminals No 6, No 7, No 10, and No 11
A10REDSUR L PREStereo amplifier
A11GRNSUR L PRE+Stereo amplifier
A12BLKGNDBody ground to G502
A13REDNAVI ILL+Gauge control module
A14PURACCNo 18 (7 5 A) fuse in the driver's under-dash fuse/relay box
A15BLUVSPPCM (VSP)
A16PNKREMOTEAudio remote switch
A17WHTSWD +BStereo amplifier
A18REDFR PREStereo amplifier
A19GRNFR PRE+Stereo amplifier
A20GRV (1)FR PRE SHShield for terminals No 18 and No 19
A21GRV (1)FL PRE SHShield for terminals No 22 and No 23
A22REDFL PREStereo amplifier
A23GRNFL PRE+Stereo amplifier
A24WHT+BNo 15 (10 A) fuse in the driver's under-hood fuse/relay box
(1) The shielded wires have a heat-shrunk tube insulating the outside of the wire The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the schematic.
(1)The shielded wires have a heat-shrunk tube insulating the outside of the wire The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the schematic.

TERMINAL REFERENCE CHART

Scheme 17

Scheme 17: Audio-Navigation Unit Connector B (24P)
CavityWire ColorTerminal NameConnect to
B1REDAUX LAuxiliary jack assembly
B2BLKAUX SIG GNDAuxiliary jack assembly
B3ORNAUX DETAuxiliary jack assembly
B5BRNTELM SIG+HandsFreeLink control unit
B9WHTCTR PREStereo amplifier
B10BLKCTR PRE+Stereo amplifier
B11GRY (1)CTR PRE SHShield for terminals No 9, No 10, No 12, and No 24
B12GRNSUBW PRE+Stereo amplifier
B13WHTAUX RAuxiliary jack assembly
B14YELAUX GNDAuxiliary jack assembly
B15GRY (1)AUX SH GNDShield for terminals NO 1, No 2, and No 13
B16YELTELM SIGHandsFreeLink control unit
B17GRY (1)TELM SIG SHShield for terminals No 5 and No 16
B24REDSUBW PREStereo amplifier
(1) The shielded wires have a heat-shrunk tube insulating the outside of the wire The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the schematic
(1)The shielded wires have a heat-shrunk tube insulating the outside of the wire The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the schematic

TERMINAL REFERENCE CHART

Scheme 18

Scheme 18: Audio-Navigation Unit Connector C (14P)
CavityWire ColorTerminal NameConnect to
C1 (3)YEL+BXM receiver
C2 (3)LT BLUSYS ACCXM receiver
C3GRY (1)GA-NET BUS SHShield for terminals No 9 and No 10
C4GRY (1)AUDIO SHShield for terminals No 5, No 6, No 13, and No 14
C5GRNAUDIO R+AcuraLink control unit (XM receiver) (2) , XM receiver (3) , HandsFreeLink control unit
C6BLKAUDIO L+AcuraLink control unit (XM receiver) (2) , XM receiver (3) , HandsFreeLink control unit
C9PNKGA-NET BUS+AcuraLink control unit (XM receiver) (2) , XM receiver (3) , HandsFreeLink control unit, navigation display unit
C10BLUGA-NET BUSAcuraLink control unit (XM receiver) (2) , XM receiver (3) , HandsFreeLink control unit, navigation display unit
C11 (3)BLKGNDXM receiver
C13WHTAUDIO RAcuraLink control unit (XM receiver) (2) , XM receiver (3) , HandsFreeLink control unit
C14REDAUDIO LAcuraLink control unit (XM receiver) (2) , XM receiver (3) , HandsFreeLink control unit
(1) The shielded wires have a heat-shrunk tube insulating the outside of the wire The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the schematic (2) USA models (3) Canada models
(1)The shielded wires have a heat-shrunk tube insulating the outside of the wire The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the schematic
(2)USA models
(3)Canada models

TERMINAL REFERENCE CHART

Scheme 19

Scheme 19: Audio-Navigation Unit Connector D (20P)
CavityWire ColorTerminal NameConnect to
D1REDELS DATAStereo amplifier
D2GRNELS DATA+Stereo amplifier
D3PURHFL MUTEHandsFreeLink control unit, HFL-navigation microphone
D4ORNNAVI SIClimate control unit
D5PURNAVI SOClimate control unit
D6PNKB-CAN HIB-CAN communication bus
D11GRYNAVI CLKClimate control unit
D14BRNB-CAN LOB-CAN communication bus
D15BLU (1)ELS DATA SHShield for terminals No 1 and No 2
(1) The shielded wires have a heat-shrunk tube insulating the outside of the wire The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the schematic
(1)The shielded wires have a heat-shrunk tube insulating the outside of the wire The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the schematic

TERMINAL REFERENCE CHART

Scheme 20

Scheme 20: Audio-Navigation Unit Connector E (5P)
CavityWire ColorTerminal NameConnect to
E1RF INAM/FM antenna amplifier
E2RF SHShield for terminal No 1
E3ANT +BAM/FM antenna amplifier

TERMINAL REFERENCE CHART

Scheme 21

Scheme 21: Audio-Navigation Unit Connector F (12P)
CavityWire ColorTerminal NameConnect to
F1YELDUET RXAudio-navigation switch panel
F2GRY (1)DUET SHShield for terminals No 1 and No 7
F3PUROPERA RXAudio-navigation switch panel
F4GRY (1)OPERA SHShield for terminals No 3 and No 9
F5BLUVOLAudio-navigation switch panel
F6GRY (1)VOL SHShield for terminals No 5, No 11, and No 12
F7BRNDUET TXAudio-navigation switch panel
F8BLUDUET CONTAudio-navigation switch panel
F9LT BLUOPERA TXAudio-navigation switch panel
F10PNKOPERA CONTAudio-navigation switch panel
F11PNKVOL+Audio-navigation switch panel
F12GRNPWR SWAudio-navigation switch panel
(1) The shielded wires have a heat-shrunk tube insulating the outside of the wire The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the schematic
(1)The shielded wires have a heat-shrunk tube insulating the outside of the wire The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the schematic

TERMINAL REFERENCE CHART

Scheme 22

Scheme 22: Audio-Navigation Unit Connector K (7P)
CavityWire ColorTerminal NameConnect to
K1USB VBUSUSB jack
K2USB DATAUSB jack
K3USB DATA+USB jack
K4USB GNDUSB jack
K5USB SHShield for terminals No 1, No 2, No 3, and No 4
K6USB DETConnect to terminal No 7
K7USB DET GNDConnect to terminal No 6

TERMINAL REFERENCE CHART

Scheme 23

Scheme 23: Without Navigation

Scheme 24

Scheme 24: Audio Unit Connector A (24P)
CavityWire ColorTerminal NameConnect to
A1REDILL-LEDGauge control module
A3LT BLUK-LINEData link connector (DLC)
A4BRNSCTY2Passenger's under-dash fuse/relay box
A5YELREMOTE GNDAudio remote-HFL switch ground
A12BLKGNDBody ground to G502
A13GRYILL+No 6 (7 5 A) fuse in the passenger's under-dash fuse/relay box
A14PURACCNo 18 (7 5 A) fuse in the driver's under-dash fuse/relay box
A16PNKREMOTEAudio remote switch
A17WHTSWD +BStereo amplifier
A18REDFR PREStereo amplifier
A19GRNFR PRE+Stereo amplifier
A20GRY (1)FR PRE SHShield for terminals No 18 and No 19
A21GRY (1)FL PRE SHShield for terminals No 22 and No 23
A22REDFL PREStereo amplifier
A23GRNFL PRE+Stereo amplifier
A24WHT+BNo 15 (10 A) fuse in the under-hood fuse/relay box
(1) The shielded wires have a heat-shrunk tube insulating the outside of the wire The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the schematic
(1)The shielded wires have a heat-shrunk tube insulating the outside of the wire The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the schematic

TERMINAL REFERENCE CHART

Scheme 25

Scheme 25: Audio Unit Connector B (14P)
CavityWire ColorTerminal NameConnect to
B1REDSUBW PREStereo amplifier
B2WHTCTR PREStereo amplifier
B3BLKCTR PRE+Stereo amplifier
B4REDSUR L PREStereo amplifier
B5WHTSUR R PREStereo amplifier
B6GRY (1)SUR PRE SHShield for terminals No 4, No 5, No 11, and No 12
B8GRNSUBW PRE+Stereo amplifier
B9GRY (1)CTR PRE SHShield for terminals No 1, No 2, No 3, and No 8
B11GRNSUR L PRE+Stereo amplifier
B12BLKSUR R PRE+Stereo amplifier
B13LT GRNDPL II ON/OFFStereo amplifier
(1) The shielded wires have a heat-shrunk tube insulating the out side of the wire The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the schematic
(1)The shielded wires have a heat-shrunk tube insulating the out side of the wire The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the schematic

TERMINAL REFERENCE CHART

Scheme 26

Scheme 26: Audio Unit Connector C (14P)
CavityWire ColorTerminal NameConnect to
C1YEL+BXM receiver, USB adapter unit
C2LT BLUSYS ACCXM receiver, USB adapter unit
C3GRY (1)GA-NET BUS SHShield for terminals No 9 and No 10
C4GRY (1)AUDIO SHShield for terminals No 5, No 6, No 13, and No 14
C5GRNAUDIO R+XM receiver, HandsFreeLink control unit, USB adapter unit
C6BLKAUDIO L+XM receiver, HandsFreeLink control unit, USB adapter unit
C9PNKGA-NET BUS+XM receiver, HandsFreeLink control unit, USB adapter unit
C10BLUGA-NET BUSXM receiver, HandsFreeLink control unit, USB adapter unit
C11BLKGNDXM receiver, USB adapter unit
C13WHTAUDIO RXM receiver, HandsFreeLink control unit, USB adapter unit
C14REDAUDIO LXM receiver, HandsFreeLink control unit, USB adapter unit
(1) The shielded wires have a heat-shrunk tube insulating the outside of the wire The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the schematic
(1)The shielded wires have a heat-shrunk tube insulating the outside of the wire The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the schematic

TERMINAL REFERENCE CHART

Scheme 27

Scheme 27: Audio Unit Connector D (20P)
CavityWire ColorTerminal NameConnect to
D1PNKCOMPASS 2Electrical compass unit
D2LT BLUCOMPASS 1Electrical compass unit
D3BLKAUX SIG GNDAuxiliary jack assembly
D4GRY (1)AUX SH GNDShield for terminals No 3, No 13, and No 14
D5YELAUX GNDAuxiliary jack assembly
D6BRNDUET TXAudio-HVAC display unit
D7YELDUET RXAudio-HVAC display unit
D8BLUB-CAN LOB-CAN communication bus
D9YELTELM SIGHandsFreeLink control unit
D10GRY (1)TELM SIG SHShield for terminals No 9 and No 19
D11REDCOMPASS 4Electrical compass unit
D12ORNCOMPASS 3Electrical compass unit
D13REDAUX LAuxiliary jack assembly
D14WHTAUX RAuxiliary jack assembly
D15ORNAUX DETAuxiliary jack assembly
D16GRY (1)DUET SHShield for terminals No 6 and No 7
D17BLUDUET CONTAudio-HVAC display unit
D18PNKB-CAN HIB-CAN communication bus
D19BRNTELM SIG+HandsFreeLink control unit
D20PURHFL MUTEHandsFreeLink control unit
(1) The shielded wires have a heat-shrunk tube insulating the outside of the wire The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the schematic
(1)The shielded wires have a heat-shrunk tube insulating the outside of the wire The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the schematic

TERMINAL REFERENCE CHART

Scheme 28

Scheme 28: Audio Unit Connector E (3P)
CavityWire ColorTerminal NameConnect to
E1RF INAM/FM antenna amplifier
E2RF SHShield for terminal No 1
E3ANT +BAM/FM antenna amplifier

TERMINAL REFERENCE CHART

Scheme 29

Scheme 29: Audio-Navigation Switch Panel for Inputs and Outputs (With navigation)

Scheme 30

Scheme 30: Audio-Navigation Switch Panel 24P Connector
CavityWire ColorTerminal NameConnect to
1BLUVOLAudio-navigation unit
2GRY (1)VOL SHShield for terminal No 1, No 13, and No 14
3BLUDUET CONTAudio-navigation unit
4GRY (1)DUET SHShield for terminal No 15 and No 16
5GRY (1)OPERA SHShield for terminal No 6 and No 18
6REDOPERA TXAudio-navigation unit
7REDDISP CLKClimate control unit
10BLKGNDBody ground to G501
11REDILL-LEDGauge control module
12LT BLUILL-LCDGauge control module
13PNKVOL+Audio-navigation unit
14GRNPWR SWAudio-navigation unit
15YELDUET RXAudio-navigation unit
16BRNDUET TXAudio-navigation unit
17PNKOPERA CONTAudio-navigation unit
18PUROPERA RXAudio-navigation unit
19PURDISP SOClimate control unit
21LT GRNIG2No 16 (7 5 A) fuse in the driver's under-dash fuse/relay box
22WHT+BNo 15 (10 A) fuse in the under-hood fuse/relay box
23GRYILL+No 6 (7 5 A) fuse in the passenger's under-dash fuse/relay box
(1) The shielded wires have a heat-shrunk tube insulating the outside of the wire The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the schematic
(1)The shielded wires have a heat-shrunk tube insulating the outside of the wire The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the schematic

TERMINAL REFERENCE CHART

Scheme 31

Scheme 31: With Navigation

Scheme 32

Scheme 32: Stereo Amplifier Connector A (18P)
CavityWire ColorTerminal NameConnect to
A1LT BLUSUBW SPSubwoofer
A2YELCTR SPFront center speaker
A3GRYRR SPRight rear door speaker
A4GRNRL SPLeft rear speaker
A5YELSUR R SPRight rear speaker
A6BRNFR SPFront passenger's door speaker, right tweeter
A7BLUFL SPDriver's door speaker, left tweeter
A8BLUSUR L SPLeft rear speaker
A9BLKGNDBody ground to G653
A10GRYSUBW SP+Subwoofer
A11BRNCTR SP+Front center speaker
A12BRNRR SP+Right rear door speaker
A13REDRL SP+Left rear door speaker
A14BLUSUR R SP+Right rear speaker
A15GRYFR SP+Front passenger's door speaker, right tweeter
A16LT GRNFL SP+Driver's door speaker, left tweeter
A17YELSUR L SP+Left rear speaker
A18WHT+BNo 15 (20 A) fuse in the passenger's under-dash fuse/relay box

TERMINAL REFERENCE CHART

Scheme 33

Scheme 33: Stereo Amplifier Connector B (28P)
CavityWire ColorTerminal NameConnect to
B1REDELS DATAAudio-navigation unit
B3WHTSWD +BAudio-navigation unit
B4BLKCTR PRE+Audio-navigation unit
B6GRNSUBW PRE+Audio-navigation unit
B9BLKRG L GNDAudio-navigation unit
B10GRNFL PRE+Audio-navigation unit
B11GRNFR PRE+Audio-navigation unit
B13GRNSUR L PRE+Audio-navigation unit
B14BLKSUR R PRE+Audio-navigation unit
B15GRNELS DATA+Audio-navigation unit
B18WHTCTR PREAudio-navigation unit
B19REDSUBW PREAudio-navigation unit
B21WHTRG L+Audio-navigation unit
B24REDFL PREAudio-navigation unit
B25REDFR PREAudio-navigation unit
B27REDSUR L PREAudio-navigation unit
B28WHTSUR R PREAudio-navigation unit

TERMINAL REFERENCE CHART

Scheme 34

Scheme 34: Without Navigation

Scheme 35

Scheme 35: Stereo Amplifier Connector A (18P)
CavityWire ColorTerminal NameConnect to
A1BLUSUR L SPLeft rear speaker
A2BLUFL SPDriver's door speaker, left tweeter
A3LT BLUSUBW SPSubwoofer
A5YELSUR R SPRight rear speaker
A6BRNFR SPFront passenger's door speaker, right tweeter
A7YELCTR SPFront center speaker
A9BLKGNDBody ground to G653
A10YELSUR L SP+Left rear speaker
A11LT GRNFL SP+Driver's door speaker, left tweeter
A12GRYSUBW SP+Subwoofer
A14BLUSUR R SP+Right rear speaker
A15GRYFR SP+Front passenger's door speaker, right tweeter
A16BRNCTR SP+Front center speaker
A18WHT+BNo 15 (20 A) fuse in the passenger's under-dash fuse/relay box

TERMINAL REFERENCE CHART

Scheme 36

Scheme 36: Stereo Amplifier Connector B (20P)
CavityWire ColorTerminal NameConnect to
B1WHTSWD +BAudio unit
B3BLKCTR PRE+Audio unit
B4GRNSUBW PRE+Audio unit
B6GRNFL PRE+Audio unit
B7GRNFR PRE+Audio unit
B9GRNSUR R PRE+Audio unit
B10BLKSUR R PRE+Audio unit
B11LT GRNDPL II ON/OFFAudio unit
B13WHTCTR PREAudio unit
B14REDSUBW PREAudio unit
B16REDFL PREAudio unit
B17REDFR PREAudio unit
B19REDSUR L PREAudio unit
B20WHTSUR R PREAudio unit

TERMINAL REFERENCE CHART

Scheme 37

Scheme 37: XM Receiver Connector for Inputs and Outputs (Without AcuraLink)

Scheme 38

Scheme 38: XM Receiver Connector A (14P)

With navigation

CavityWire ColorTerminal NameConnect to
A1YEL+BAudio-navigation unit
A2LT BLUSYS ACCAudio-navigation unit
A3GRY (1)GA-NET BUS SHShield for terminals No 9 and No 10
A4GRY (1)AUDIO SHShield for terminals No 5, No 6, No 13, and No 14
A5GRNAUDIO R+Audio-navigation unit, HandsFreeLink control unit
A6BLKAUDIO L+Audio-navigation unit, HandsFreeLink control unit
A9PNKGA-NET BUS+Audio-navigation unit, HandsFreeLink control unit, navigation display unit
A10BLUGA-NET BUSAudio-navigation unit, HandsFreeLink control unit, navigation display unit
A11BLKGNDAudio-navigation unit
A13WHTAUDIO RAudio-navigation unit, HandsFreeLink control unit
A14REDAUDIO LAudio-navigation unit, HandsFreeLink control unit
(1) The shielded wires have a heat-shrunk tube insulating the outside of the wire The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the schematic
(1)The shielded wires have a heat-shrunk tube insulating the outside of the wire The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the schematic

TERMINAL REFERENCE CHART

Without navigation

CavityWire ColorTerminal NameConnect to
A1YEL+BAudio unit, USB adapter unit
A2LT BLUSYS ACCAudio unit, USB adapter unit
A3GRY (1)GA-NET BUS SHShield for terminals No 9 and No 10
A4GRY (1)AUDIO SHShield for terminals No 5, No 6, No 13, and No 14
A5GRNAUDIO R+Audio unit, USB adapter unit, HandsFreeLink control unit
A6BLKAUDIO L+Audio unit, USB adapter unit, HandsFreeLink control unit
A9PNKGA-NET BUS+Audio unit, USB adapter unit, HandsFreeLink control unit
A10BLUGA-NET BUSAudio unit, USB adapter unit, HandsFreeLink control unit
A11BLKGNDAudio unit, USB adapter unit
A13WHTAUDIO RAudio unit, USB adapter unit, HandsFreeLink control unit
A14REDAUDIO LAudio unit, USB adapter unit, HandsFreeLink control unit
(1) The shielded wires have a heat-shrunk tube insulating the outside of the wire The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the schematic
(1)The shielded wires have a heat-shrunk tube insulating the outside of the wire The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the schematic

TERMINAL REFERENCE CHART

Scheme 39

Scheme 39: XM Receiver Connector B (2P)
CavityWire ColorTerminal NameConnect to
B1SAT/TERXM antenna
B2GND SHShield for terminal No 1

TERMINAL REFERENCE CHART

Scheme 40

Scheme 40: USB Adapter Unit for Inputs and Outputs (Without navigation)

Scheme 41

Scheme 41: USB Adapter Unit Connector A (14P)
CavityWire ColorTerminal NameConnect to
A1YEL+BAudio unit, XM receiver
A2LT BLUSYS ACCAudio unit, XM receiver
A3GRY (1)GA-NET BUS SHShield for terminals No 9 and No 10
A4GRY (1)AUDIO SHShield for terminals No 5, No 6, No 13, and No 14
A5GRNAUDIO R+Audio unit, XM receiver, HandsFreeLink control unit
A6BLKAUDIO L+Audio unit, XM receiver, HandsFreeLink control unit
A9PNKGA-NET BUS+Audio unit, XM receiver, HandsFreeLink control unit
A10BLUGA-NET BUSAudio unit, XM receiver, HandsFreeLink control unit
A11BLKGNDAudio unit, XM receiver
A13WHTAUDIO RAudio unit, XM receiver, HandsFreeLink control unit
A14REDAUDIO LAudio unit, XM receiver, HandsFreeLink control unit
(1) The shielded wires have a heat-shrunk tube insulating the outside of the wire The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the schematic
(1)The shielded wires have a heat-shrunk tube insulating the outside of the wire The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the schematic

TERMINAL REFERENCE CHART

Scheme 42

Scheme 42: USB Adapter Unit Connector B (5P)
CavityWire ColorTerminal NameConnect to
B1USB VBUSUSB jack
B2USB DATAUSB jack
B3USB DATA+USB jack
B4USB GNDUSB jack
B5USB SHShield for terminals No 1, No 2, No 3, and No 4

TERMINAL REFERENCE CHART

Scheme 43

Scheme 43: Audio-HVAC Display Unit Connector for Inputs and Outputs (Without navigation)

Scheme 44

Scheme 44: Audio-HVAC Display Unit 12P Connector
CavityWire ColorTerminal NameConnect to
1YELDUET RXAudio unit
2BRNDUET TXAudio unit
4BLUDUET CONTAudio unit
5LT GRNIG2No 6 (7 5 A) fuse in the driver's under-dash fuse/relay box
6WHT+BNo 15 (10 A) fuse in the under-hood fuse/relay box
7REDDISP CLKClimate control unit
8PURDISP SIClimate control unit
9BLKGNDBody ground to G501
10LT BLUILL - LCDGauge control module
12GRYILL+No 6 (7 5 A) fuse in the passenger's under-dash fuse/relay box

TERMINAL REFERENCE CHART

Scheme 45

Scheme 45: Auxiliary Jack Assembly Connector for Inputs and Outputs

Scheme 46

Scheme 46: Auxiliary Jack Assembly 5P Connector

With navigation

CavityWire ColorTerminal NameConnect to
1ORNAUX DETAudio-navigation unit
2YELAUX GNDAudio-navigation unit
3BLKAUX SIG GNDAudio-navigation unit
4REDAUX LAudio-navigation unit
5WHTAUX RAudio-navigation unit

TERMINAL REFERENCE CHART

Without navigation

CavityWire ColorTerminal NameConnect to
1ORNAUX DETAudio unit
2YELAUX GNDAudio unit
3BLKAUX SIG GNDAudio unit
4REDAUX LAudio unit
5WHTAUX RAudio unit

TERMINAL REFERENCE CHART

Scheme 47

Scheme 47: With navigation

Scheme 48

Scheme 48

Scheme 49

Scheme 49

Scheme 50

Scheme 50

Scheme 51

Scheme 51

Scheme 52

Scheme 52

Scheme 53

Scheme 53: Without navigation

Scheme 54

Scheme 54

Scheme 55

Scheme 55

Scheme 56

Scheme 56

Scheme 57

Scheme 57

How to Obtain the Audio Unit Serial Number

Note. This procedure can only be done after the power has been disconnected and reconnected to the audio unit, and the audio unit displays CODE when the audio unit is turned on

Scheme 58

Scheme 58: How to Obtain the Audio Unit Serial Number

Scheme 59

Scheme 59
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  2. Make sure the audio system is turned off
  3. Push and hold the preset No 1 and No 6 buttons
  4. While holding the buttons, push the VOL PUSH PWR knob to ON
  5. Release the buttons, and the self-diagnostic begins
  6. The display shows an 8 digit serial number
  7. Use all 8 numbers as the serial number when using the Interactive Network (iN) to retrieve the 5 digit anti-theft code
  8. To end the self-diagnostic function, turn the audio system off, or turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode

The audio system has a self-diagnostic function to help find problems with the audio system To run the self-diagnostic function, do the following

Note. Not all self-diagnostic functions appear on all models There may be other self-diagnostic functions that are for factory use only The self diagnostic function does not find every problem with the audio system Check any official Honda service website for more information about the audio system

Scheme 60

Scheme 60: How to check the audio system condition
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  2. Make sure the audio system is turned off
  3. Push and hold the preset No 1 and No 6 buttons
  4. While holding the buttons, push the VOL PUSH PWR knob to ON
  5. Release the buttons, and the self-diagnostic begins
  6. When you are in the self-diagnostic mode, pressing a preset button starts the diagnostic mode that is assigned to that preset button

Note. Any other diagnostic screens shown are for factory use only

No 2 button

Audio button, knob, and audio remote switch detection Allows individual manual selection of all audio panel knobs, buttons, and remote switches to verify if they are functional When properly detected, the selected knob, button, or audio remote switch name and/or value is displayed To exit this mode, go to step 7 Once you exit this test, you must start again at step 1

No 3 button

Entire LCD lighting/light-out mode Turns on/off the entire LCD to show the presence (LCD stuck on) or absence (LCD dead) of an LCD segment

No 4 button

Duty indication mode (for the Illumination dim) Indicates the duty for the Illumination dim when the dash lights are on

No 5 button

Vehicle speed pulse (VSP) indication mode Indicates the vehicle speed pulse

FM button (Push and hold 5 sec)

Reception level indication mode. Indicates the reception level (dB) When entering the reception level check mode, the AM/FM or FM button is used to change the main/sub antenna

Canceling the Self-diagnostic Function

  1. To end the self-diagnostic function, turn the audio system off, or turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode

Display Specifications

Note. Any other diagnostic screens shown are for audio manufacturer's use only

Entry LCD lighting/lights-outs mode (press No 3 button)

This diagnostic screen checks for segments that may be dead (off) or stuck on

All the segments in the display must appear If there are dead segments, replace the audio-navigation switch panel (see AUDIO-NAVIGATION SWITCH PANEL REMOVAL/INSTALLATION ), or the audio-HVAC display unit (see AUDIO-HVAC DISPLAY UNIT REMOVAL/INSTALLATION )

When the display segments are all on, press the No 3 button The entire display must turn black If any segments are stuck on, replace the audio-navigation switch panel (see AUDIO-NAVIGATION SWITCH PANEL REMOVAL/INSTALLATION ), or the audio-HVAC display unit (see AUDIO-HVAC DISPLAY UNIT REMOVAL/INSTALLATION )

Scheme 61

Scheme 61: Entry LCD lighting/lights-outs mode (press No 3 button)

Illumination level (for the gauge illumination) indication (press No 4 button)

This diagnostic screen checks the gauge illumination input

With the headlights on, you should see a values between 1 (max low) and 22 (max high)

When you dim and brighten the gauge with the dimmer knob, you should see this value change accordingly If it doesn't, check for B-CAN DTCs

Scheme 62

Scheme 62: Illumination level (for the gauge illumination) indication (press No 4 button)

Vehicle speed pulse indication (press No 5 button)

This diagnostic screen checks that the audio unit is receiving the VSP indication

When you drive the vehicle, the VSP indicates the vehicle speed in km/h

Scheme 63

Scheme 63: Vehicle speed pulse indication (press No 5 button)

Reception level indication (Push and hold 5 sec AM/FM button)

This diagnostic screen checks the radio reception level This level then can used in the diagnosis of radio reception quality The reception level is displayed in decibels (dB)

Preparation

  1. Park the vehicle outdoors in a location with good radio reception
  2. Tune to a powerful local FM radio station, then write down the radio station number
  3. Tune to a powerful local AM radio station, then write down the radio station number

Scheme 64

Scheme 64
  1. Enter the reception level indication mode in the self-diagnostic function The AM/FM antenna amplifier is on and the character (A) is not displayed in the audio-HVAC display
  2. Tune to the FM radio station you wrote down in preparation using the TUNE button (with navigation) or selector knob (without navigation), and note the decibel level of that station
  3. Press and release the A SEL button to turn the AM/FM antenna amplifier off (A is now displayed in the audio-HVAC display)
  4. Note the decibel level of that station
  5. Press and release the A SEL button to turn the AM/FM antenna amplifier back on (A is not displayed in the audio-HVAC display)
  6. Press and hold the AM/FM button for more than 5 seconds to enter the AM reception mode
  7. Tune to the AM radio station you wrote down in preparation using the TUNE button (with navigation) or selector knob (without navigation), and note the decibel level of that station.
  8. Press and release the A SEL button to turn the antenna amplifier off (A is now displayed in the audio-HVAC display)
  9. Note the decibel level of that station
  10. Press and release the A SEL button to turn the AM/FM antenna amplifier back on (A is not displayed in the audio-HVAC display)
  11. Turn the ignition switch to LOCK(0), or press the engine start/stop button to select the OFF mode, or audio system off to exit the test mode
  12. Compare your results to a known-good vehicle, (make sure it is the same year and trim level) in the same location and direction, and under the same environmental conditions

Speaker check mode

Note. Not all self-diagnostic functions appear on all models There may be other self-diagnostic functions that are for factory use only

Scheme 65

Scheme 65: Speaker check mode
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  2. Make sure the audio system is turned off
  3. Push and hold the preset No 1 and No 3 buttons
  4. While holding the buttons, push the VOL PUSH PWR knob to ON
  5. Release the buttons and the speaker check mode begins A tone should sound from one speaker
  6. Each time you press the SKIP button, the test moves to the next speaker in the order listed in the table NOTE: Adjust the volume level to a comfortable level Display Specifications (-->) is pressed (1)-->(2)-->(3)-->(4)-->(5)-->(6)-->(7) (<--) is pressed (1)-->(7)-->(6)-->(5)-->(4)-->(3)-->(2) SPEAKER REFERENCE CHART Speaker Displayed Segments Remarks (1) Driver's door speaker and left tweeter SPK FR-L You should hear a tone corresponding to the speaker (2) Front center speaker SPK CNT You should hear a tone corresponding to the speaker (3) Front passenger's door speaker and right tweeter SPK FR-R You should hear a tone corresponding to the speaker (4) Right rear door speaker (1) and right rear speaker SPK RR-R You should hear a tone corresponding to the speaker (5) Subwoofer SPK SUBW You should hear a tone corresponding to the speaker (6) Left rear door speaker (1) and left rear speaker SPK RR-L You should hear a tone corresponding to the speaker (7) All speakers SPK ALL You should hear a tone corresponding to the speaker The subwoofer does not sound a tone (1) With navigation NOTE: Any other diagnostic screens are for factory use only
  7. The speaker check mode ends when you turn the audio system off or turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode

XM Self-diagnosis

Note. The diagnostic screen checks the audio unit's XM radio reception level. To check the XM reception, do the following

  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Select XM1 mode.
  3. Make sure the audio system is turned off, then turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  4. Push and hold the preset No. 3 and No. 6 buttons.
  5. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  6. While holding the buttons for 5 seconds, then release the buttons.
  7. Press and release preset No. 1 button to read the error code. Error Code No. Displayed Error Code Title Displayed Solution ERROR 00 NO ERROR System is normal ERROR 04 NO SIGNAL Move the vehicle to an open area and recheck ERROR 05 NO XM ACTIVATION Contact XM satellite radio at 800-852-9696 ERROR 06 NO XM AUTHORIZATION Contact XM satellite radio at 800-852-9696 ERROR 14 ANTENNA NO CONNECTED/NO SIGNAL Refer to Error code: XM ANTENNA is displayed; With AcuraLink (see «Error code: XM ANTENNA is displayed (with AcuraLink)»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__error-code-xm-antenna-or-xm) ) Without AcuraLink (see «Error code: XM ANTENNA is displayed (without AcuraLink)»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__error-code-xm-antenna-or-xm) ) ERROR 24 ANTENNA SHORTED/NO SIGNAL Refer to Error code: XM ANTENNA is displayed; With AcuraLink (see «Error code: XM ANTENNA is displayed (with AcuraLink)»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__error-code-xm-antenna-or-xm) ) Without AcuraLink (see «Error code: XM ANTENNA is displayed (without AcuraLink)»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__error-code-xm-antenna-or-xm) ) ERROR 55 HARDWARE FAILURE (CONDITIONAL ACCESS FAILURE Replace the AcuraLink control unit (XM receiver) (see «With AcuraLink»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__with-acuralink) ) or the XM receiver (see «Without AcuraLink»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__without-acuralink) ) ERROR 65 HARDWARE FAILURE (CONDITIONAL ACCESS FAILURE Replace the AcuraLink control unit (XM receiver) (see «With AcuraLink»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__with-acuralink) ) or the XM receiver (see «Without AcuraLink»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__without-acuralink) )
  8. To end the XM self-diagnosis, turn the audio system off, or turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.

XM Signal Reception Level Indication Mode

Note. When you receive any XM complaint, do the XM self-diagnosis to check for any XM error codes. To get the XM error codes, do the following

  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Select XM2 mode.
  3. Make sure the audio system is turned off, then turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  4. Push and hold the preset No. 3 and No. 6 buttons.
  5. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  6. While holding the buttons for 5 seconds, then release the buttons.
  7. Press and release preset No. 1 button to read the error code. Error Code Displayed Solution SG NOSIG Move the vehicle to an open area and recheck. If the signal does not improve, substitute a known-good XM antenna (see) and recheck. SG GOOD The XM signal is OK. SG MARG The XM signal is OK. SG WEAK Move the vehicle to an open area and recheck. If the signal does not improve, substitute a known-good XM antenna (see «XM Antenna Replacement»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ) and recheck. SG VWEAK Move the vehicle to an open area and recheck. If the signal does not improve, substitute a known-good XM antenna (see «XM Antenna Replacement»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ) and recheck.
  8. To end the XM self-diagnosis, turn the audio system off, or turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.

Error Codes

The audio system can display a few error codes when some problems are detected with the audio disc player, the audio disc, the XM radio, or the anti-theft code This is not a complete list of audio error codes Refer to SYMPTOM TROUBLESHOOTING , or go to any official Honda service website for more service information

CD Error Codes

Error Code DisplayedPossible CauseSolution
DISC ERRORThere is a problem with the disc player A common problem is paper disc labels coming off the disc while in the playerTry to eject the disc and try another one If there is still a problem, replace the audio-navigation unit (see AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION ), or the audio unit (see AUDIO UNIT REMOVAL/INSTALLATION )
HEAT ERRORDisc player is hot This can happen if the vehicle is parked out in the hot sun all dayPark the vehicle in a cooler place for a while and try the disc player again If the error code is still present, try another disc If the error code is still present, replace the audio-navigation unit (see AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION ), or the audio unit (see AUDIO UNIT REMOVAL/INSTALLATION )
UNSUPPORTEDTrack/File format not supportedCurrent track is skipped The next supported track or file plays automatically Verify that CD file names end in CDA Verify that CD-R or CD-RW with compressed music formats end in MP3 or WMA Other file formats like i-Tunes (AAC) or Ogg are not recognized WMA files may have (DRM) copy protection and cannot be read
MECH ERRORCD label jammed in the mechanism CD eject mechanism or motor is inoperative CD spindle motor won't spin up the CDPress the EJECT button and hold it for 5 seconds If the CD does not eject, try again If the CD still won't eject, replace the audio-navigation unit (see AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION ), or the audio unit (see AUDIO UNIT REMOVAL/INSTALLATION )

CD ERROR CODES REFERENCE CHART

USB Error Codes

Error Code DisplayedPossible CauseSolution
FILE ERRORThe audio unit cannot read the file(s)Check the files in the USB device There is a possibility that the files have been damaged or are not supported
MEDIA ERROR UNSUPPORTEDUnsupported USB device is connectedConnect the applicable USB device (see Owner's Manual)
USB LOADINGData is being loaded from the USB deviceCheck the files in the USB device There is a possibility that the files have been damaged, or are not supported
USB NO SONGThere are no files or files that are not supported on the USB deviceCheck the files in the USB device There is a possibility that the files have been damaged, or are not supported
USB NO DATAUSB device is not connectedIf the code appears when the USB devices is connected, go to USB device does not work With navigation (see USB DEVICE DOES NOT FUNCTION (WITH NAVIGATION) ) Without navigation (see USB DEVICE DOES NOT FUNCTION (WITHOUT NAVIGATION) )

USB ERROR CODES REFERENCE CHART

Audio Unit Error Codes

Error Code DisplayedPossible CauseSolution
CODE ERROR 1Anti-theft code mismatch (1 st try)Enter the correct anti-theft code
CODE ERROR EAnti-theft code mismatch (10 th try)Remove the No 15 (10 A) in the under-hood fuse/relay box, then reinsert it You will have 10 more tries to enter the correct anti-theft code

AUDIO UNIT ERROR CODES REFERENCE CHART

XM Error Codes

Error Code DisplayedPossible CauseSolution
LOADINGXM radio is acquiring audio or program informationWait until the radio receives the information
OFF AIRXM channel not in serviceTry another XM channel
NO SIGNALLoss of signalBoth terrestrial and satellite antennas have lost the signal Park the vehicle outside with a clear view of the southern horizon
UPDATINGXM radio is receiving information update from the networkThis message disappears once the update finishes
CHECK ANTENNAXM antenna errorRepair open or short in the satellite antenna Substitute a known-good XM antenna (see XM ANTENNA REPLACEMENT ), and recheck If the error is gone, replace the original XM antenna If the error is still present, replace the antenna lead
ANTENNA ERROR
No signal from XMCheck a known-good vehicle with XM radio If the known-good vehicle has the same symptoms, contact XM satellite radio at 800-852-9696

XM ERROR CODES REFERENCE CHART

Note. Do these checks with the vehicle parked outside with a clear view of the southern horizon

Poor AM or FM radio reception or interference (with navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ) Check the connectors for poor connections or loose terminals Check for aftermarket accessories including cell phones and chargers plugged into the vehicle accessory power sockets Check the radio reception man open area Poor reception/interference can be caused by any of these conditions The radio station is far away Atmospheric conditions are unfavorable Aftermarket metallic window tint A tall building, mountains, or high-voltage power lines are nearby

Scheme 66

Scheme 66: Poor AM or FM radio reception or interference (with navigation)

Scheme 67

Scheme 67

Scheme 68

Scheme 68

Scheme 69

Scheme 69

Scheme 70

Scheme 70

Scheme 71

Scheme 71

Scheme 72

Scheme 72

Scheme 73

Scheme 73
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  2. Do the Seek Stop Test (see «SEEK STOP TEST»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__seek-stop-test) ) and the reception level indication in the Self-diagnostic Function (see «RECEPTION LEVEL INDICATION (PUSH AND HOLD 5 SEC AM/FM BUTTON)»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__reception-level-indication-push-and-hold) ) Is the test vehicle within 10 % of the known-good vehicle? YES -Multipath interference or weak station Operation is normal NO -Go to step 3
  3. Check the reception/interference is the same in several locations Is the reception/interference the same? YES -Go to step 4 NO -Multipath interference or weak station Operation is normal
  4. Check the reception/interference while the engine is running Is there noise (static or whine) only with the engine running? YES -Check the antenna and radio grounds If OK, check the charging system and the ignition system NO -Go to step 5
  5. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
  6. Remove the right C-pillar trim (see «C-PILLAR TRIM»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#interior-trim__c-pillar-trim) )
  7. Check the connections from the AM/FM antenna amplifier to the window antenna Are there any loose or damaged connections? YES -Repair the connections, or substitute a known-good AM/FM antenna amplifier (see «AM/FM ANTENNA AMPLIFIER REPLACEMENT»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__amfm-antenna-amplifier-replacement) ), and retest If the symptom/condition goes away, replace the original AM/FM antenna amplifier NO -Go to step 8
  8. With the help of an assistant inside the vehicle, have the assistant shine a strong flashlight (A) along each antenna wire (B) Check from the outside of the vehicle for any breaks or openings in the antenna wires (the light shines through any breaks or cuts) NOTE: It is easier to see the breaks if you do this test in a dark or shaded area Are there any breaks or cuts in the antenna? YES -Repair the window antenna Go to AM/FM antenna repair (see «AM/FM Antenna Repair»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__amfm-antenna-repair) ), or replace the rear window (see «REAR WINDOW REPLACEMENT»(/acura/tl/iv-2008-2011/remont/windows/#windows-and-glass__rear-window-replacement) ) if the damaged section is too long NO -Go to step 9
  9. Disconnect the AM/FM antenna amplifier 3P connector
  10. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  11. Measure the voltage between AM/FM antenna amplifier 3P connector terminal No 3 and body ground Is there battery voltage? YES -Go to step 17 NO -Go to step 12
  12. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
  13. Remove the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/navigation-system/#navigation-system__audio-navigation-unit-removalinstallation) )
  14. Disconnect audio-navigation unit connector E (5P)
  15. Check for continuity between audio-navigation unit connector E (5P) terminal No 3 and AM/FM antenna amplifier 3P connector terminal No 3 Is there continuity? YES -Go to step 16 NO -Repair open in the wire between the audio-navigation unit and the AM/FM antenna amplifier Also check the AM/FM antenna lead/sublead connector
  16. Check for continuity between audio-navigation unit connector E (5P) terminal No 3 and body ground Is there continuity? YES -Repair short to body ground in the wire between the audio-navigation unit and the AM/FM antenna amplifier NO -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/navigation-system/#navigation-system__audio-navigation-unit-removalinstallation) )
  17. Remove the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/navigation-system/#navigation-system__audio-navigation-unit-removalinstallation) )
  18. Disconnect audio-navigation unit connector E (5P)
  19. Check for continuity between audio-navigation unit connector E (5P) terminal No 1 and AM/FM antenna amplifier 3P connector terminal No 1 Is there continuity? YES -Go to step 20 NO -Replace the AM/FM antenna lead and/or the sublead
  20. Check for continuity between audio-navigation unit connector E (5P) terminal No 1 and body ground Is there continuity? YES -Replace the AM/FM antenna lead and/or the sublead NO -Go to step 21
  21. Check for continuity between audio-navigation unit connector E (5P) terminal No 2 and AM/FM antenna amplifier 3P connector terminal No 2 Is there continuity? YES -Go to step 22 NO -Replace the AM/FM antenna lead and/or the sublead
  22. Check for continuity between audio-navigation unit connector E (5P) terminals No 1 and No 2 Is there continuity? YES -Replace the AM/FM antenna lead and/or the sublead NO -Replace the AM/FM antenna amplifier (see «AM/FM ANTENNA AMPLIFIER REPLACEMENT»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__amfm-antenna-amplifier-replacement) ), and recheck If the reception still poor, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/navigation-system/#navigation-system__audio-navigation-unit-removalinstallation) )

Poor AM or FM radio reception or interference (without navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ) Check the connectors for poor connections or loose terminals Check for aftermarket accessories including cell phones and chargers plugged into the vehicle accessory power sockets Check the radio reception in an open area Poor reception/interference can be caused by any of these conditions The radio station is far away Atmospheric conditions are unfavorable Aftermarket metallic window tint A tall building, mountains, or high-voltage power lines are nearby

Scheme 74

Scheme 74: Poor AM or FM radio reception or interference (without navigation)

Scheme 75

Scheme 75

Scheme 76

Scheme 76

Scheme 77

Scheme 77

Scheme 78

Scheme 78

Scheme 79

Scheme 79

Scheme 80

Scheme 80

Scheme 81

Scheme 81
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  2. Do the Seek Stop Test (see «SEEK STOP TEST»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__seek-stop-test) ) and the reception level indication in the Self-diagnostic Function (see «RECEPTION LEVEL INDICATION (PUSH AND HOLD 5 SEC AM/FM BUTTON)»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__reception-level-indication-push-and-hold) ) Is the test vehicle within 10 % of the known-good vehicle? YES -Multipath interference or weak station Operation is normal NO -Go to step 3
  3. Check the reception/interference is the same in several locations Is the reception/interference the same? YES -Go to step 4 NO -Multipath interference or weak station Operation is normal
  4. Check the reception/interference while the engine is running Is there noise (static or whine) only with the engine running? YES -Check the antenna and radio grounds If OK, check the charging system and the ignition system NO -Go to step 5
  5. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
  6. Remove the right C-pillar trim (see «C-PILLAR TRIM»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#interior-trim__c-pillar-trim) )
  7. Check the connections from the AM/FM antenna amplifier to the window antenna Are there any loose or damaged connections? YES -Repair the connections, or substitute a known-good AM/FM antenna amplifier (see «AM/FM ANTENNA AMPLIFIER REPLACEMENT»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__amfm-antenna-amplifier-replacement) ), and retest If the symptom/condition goes away, replace the original AM/FM antenna amplifier NO -Go to step 8
  8. With the help of an assistant inside the vehicle, have the assistant shine a strong flashlight (A) along each antenna wire (B) Check from the outside of the vehicle for any breaks or openings in the antenna wires (the light shines through any breaks or cuts) NOTE: It is easier to see the breaks if you do this test in a dark or shaded area Are there any breaks or cuts in the antenna? YES -Repair the window antenna Go to AM/FM antenna repair (see «AM/FM ANTENNA AMPLIFIER REPLACEMENT»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__amfm-antenna-amplifier-replacement) ), or replace the rear window (see «REAR WINDOW REPLACEMENT»(/acura/tl/iv-2008-2011/remont/windows/#windows-and-glass__rear-window-replacement) ) if the damaged section is too long NO -Go to step 9
  9. Disconnect the AM/FM antenna amplifier 3P connector
  10. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  11. Measure the voltage between AM/FM antenna amplifier 3P connector terminal No 3 and body ground Is there battery voltage? YES -Go to step 17 NO -Go to step 12
  12. Turn the ignition switch to LOCK (0), press the engine start/stop button to select the OFF mode
  13. Remove the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) )
  14. Disconnect audio unit connector E (3P)
  15. Check for continuity between audio unit connector E (3P) terminal No 3 and AM/FM antenna amplifier 3P connector terminal No 3 Is there continuity? YES -Go to step 16 NO -Repair open in the wire between the audio unit and the AM/FM antenna amplifier Also check the AM/FM antenna lead/sublead connector
  16. Check for continuity between audio unit connector E (3P) terminal No 3 and body ground Is there continuity? YES -Repair short to body ground in the wire between the audio unit and the AM/FM antenna amplifier NO -Replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) )
  17. Remove the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) )
  18. Disconnect audio unit connector E (3P)
  19. Check for continuity between audio unit connector E (3P) terminal No 1 and AM/FM antenna amplifier 3P connector terminal No 1 Is there continuity? YES -Go to step 20 NO -Replace the AM/FM antenna lead and/or the sublead
  20. Check for continuity between audio unit connector E (3P) terminal No 1 and body ground Is there continuity? YES -Replace the AM/FM antenna lead and/or the sublead NO -Go to step 21
  21. Check for continuity between audio unit connector E (3P) terminal No 2 and AM/FM antenna amplifier 3P connector terminal No 2 Is there continuity? YES -Go to step 22 NO -Replace the AM/FM antenna lead and/or the sublead
  22. Check for continuity between audio unit connector E(3P) terminals No 1 and No 2 Is there continuity? YES -Replace the AM/FM antenna lead and/or the sublead NO -Replace the AM/FM antenna amplifier (see «AM/FM ANTENNA AMPLIFIER REPLACEMENT»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__amfm-antenna-amplifier-replacement) ), and recheck If the reception still poor, replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) )

Audio unit power switch will not turn on (No information display and no sound) (with navigation)

Note. Check the vehicle battery condition first Check the connectors for poor connections or loose terminals

Scheme 82

Scheme 82: Audio unit power switch will not turn on (No information display and no sound) (with navigation)

Scheme 83

Scheme 83

Scheme 84

Scheme 84

Scheme 85

Scheme 85

Scheme 86

Scheme 86

Scheme 87

Scheme 87

Scheme 88

Scheme 88

Scheme 89

Scheme 89

Scheme 90

Scheme 90
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  2. Push the power switch on to see if the audio-navigation unit turns on Does the audio-navigation unit display operate properly, and does the audio-navigation unit sound normal? YES -Intermittent failure, the system is OK at this time NO -Go to step 3
  3. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
  4. Check the No 15(10 A) fuse in the under-hood fuse/relay box and the No 18 (7 5 A) fuse in the driver's under-dash fuse/relay box Are the fuses OK? YES -Go to step 5 NO -Replace the fuse, and recheck
  5. Remove the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/navigation-system/#navigation-system__audio-navigation-unit-removalinstallation) ) Check that the audio-navigation unit connectors are properly connected Are they connected properly? YES -Go to step 6 NO -Repair poor connections and reconnect the connectors, and recheck the function
  6. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  7. Measure the voltage between body ground and audio-navigation unit connector A (24P) terminals No 14 and No 24 individually Is there battery voltage? YES -Go to step 8 NO -Repair open in the wire(s) between the No 15 (10 A) fuse in the under-hood fuse/relay box, the No 18 (7 5 A) fuse in the driver's under-dash fuse/relay box and the audio-navigation unit
  8. Measure the voltage between audio-navigation unit connector A (24P) terminal No 12 and body ground. Is there less than 0.2 V? YES -Go to step 9 NO -Repair open or high resistance in the wire between audio-navigation unit connector A (24P) terminal No 12 and body ground (G502), (see «DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE)»(/acura/tl/iv-2008-2011/remont/body-electrical/#connectors-and-harnesses__dashboard-wire-harness-view-of-drivers) ).
  9. Measure the voltage between audio-navigation switch panel 24P connector terminal No. 22 and body ground. Is there battery voltage? YES -Go to step 10 NO -Repair an open in the wire(s) between the No. 15 (10 A) fuse in the under-hood fuse/relay box and the audio-navigation switch panel
  10. Measure the voltage between audio-navigation switch panel 24P connector terminal No. 10 and body ground. Is there less than 0.2 V? YES -Go to step 11 NO -Repair an open or high resistance in the wire between audio-navigation switch panel 24P connector terminal No. 10 and body ground (G501).
  11. Measure the voltage between audio-navigation switch panel 24P connector terminal No 17 and body ground Is there battery voltage? YES -Go to step 12 NO -Repair an open or a short in the wire between the audio-navigation switch panel and the audio-navigation unit.
  12. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  13. Disconnect audio-navigation unit connector F (12P) and the audio-navigation switch panel 24P connector.
  14. Check for continuity between audio-navigation switch panel 24P connector terminal No. 14 and body ground. Is there continuity? YES -Repair a short to body ground in the wire between the audio-navigation switch panel and the audio-navigation unit. NO -Go to step 15
  15. Check for continuity between audio-navigation unit connector F (12P) terminal No. 12 and audio-navigation switch panel 24P connector terminal No. 14. Is there continuity? YES -Go to step 16 NO -Repair an open in the wire between the audio-navigation switch panel and the audio-navigation unit.
  16. Reconnect the audio-navigation switch panel 24P connector.
  17. Check for continuity between audio-navigation switch panel 24P connector terminal No. 14 and body ground. Is there continuity? YES -Replace the audio-navigation switch panel (See «AUDIO-NAVIGATION SWITCH PANEL REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ) NO -Go to step 18
  18. While press and holding the PWR button, check for continuity between audio-navigation switch panel 24P connector terminal No. 14 and body ground. Is there continuity? YES -Go to step 19 YES -Replace the audio-navigation switch panel (See «AUDIO-NAVIGATION SWITCH PANEL REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) )
  19. Disconnect the audio-navigation switch panel 24P connector.
  20. Check for continuity between audio-navigation unit connector F (12P) and the audio-navigation switch panel 24P connector according to the table AUDIO-NAVIGATION SWITCH PANEL CONNECTOR REFERENCE CHART Audio-navigation unit connector Audio-navigation switch panel connector Wire color F1 15 YEL F7 16 BRN F8 3 BLU Is there continuity? YES -Go to step 21 NO -There is an open in the wire(s) between the audio-navigation unit and the audio-navigation switch panel. Repair or replace the affected harness.
  21. Check for continuity between body ground and the audio-navigation switch panel 24P connector according to the table. AUDIO-NAVIGATION SWITCH PANEL CONNECTOR REFERENCE CHART Audio-navigation and HVAC switch panel connector Wire color 3 BLU 15 YEL 16 BRN Is there continuity? YES -There is a short in the wires between the audio-navigation unit and the audio-navigation switch panel. Repair or replace the affected harness. NO -Go to step 22
  22. Check for continuity between the terminals of the audio-navigation switch panel 24P connector according to the table. AUDIO-NAVIGATION SWITCH PANEL CONNECTOR REFERENCE CHART From terminal To terminals 4 (GRY) 15 (YEL), 16 (BRN) 15 (YEL) 16 (BRN) Is there continuity? YES -There is a short in the wires between the audio-navigation unit and the audio-navigation switch panel. Replace the affected shielded harness NO -Substitute a known-good audio-navigation switch panel (see «AUDIO-NAVIGATION SWITCH PANEL REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ), and recheck If the symptom/indication goes away, replace the original audio-navigation switch panel If the symptom is still present, substitute a known-good audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/navigation-system/#navigation-system__audio-navigation-unit-removalinstallation) ), and recheck If the symptom/indication goes away, replace the original audio-navigation unit.

Audio unit power switch will not turn on (No information display and no sound) (without navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ) Check the connectors for poor connections or loose terminals

Scheme 91

Scheme 91: Audio unit power switch will not turn on (No information display and no sound) (without navigation)

Scheme 92

Scheme 92
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  2. Push the power switch on to see if the audio unit turns on Does the audio unit display operate properly, and does the audio unit sound normal? YES -Intermittent failure, the system is OK at this time NO -Go to step 3
  3. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
  4. Check the No 15 (10 A) fuse in the under-hood fuse/relay box and the No 18 (7 5 A) fuse in the driver's under-dash fuse/relay box Are the fuses OK? YES -Go to step 5 NO -Replace the fuse, and recheck
  5. Remove the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ) Check that the audio unit connectors are properly connected Are they connected properly? YES -Go to step 6 NO -Repair poor connections and reconnect the connectors, and recheck the function
  6. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  7. Measure the voltage between body ground and audio unit connector A (24P) terminals No 14 and No 24 individually Is there battery voltage? YES -Go to step 8 NO -Repair open in the wire(s) between No 15 (10 A) fuse in the under-hood fuse/relay box, the No 18 (7 5 A) fuse in the driver's under-dash fuse/relay box and the audio unit
  8. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  9. Measure the voltage between audio unit connector A (24P) terminal No 12 and body ground Is there less than 0 1 V? YES -Substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ), and recheck If the symptom/indication goes away, replace the original audio unit NO -Repair open in the wire between audio unit connector A (24P) terminal No 12 and body ground (G502) (see «AUDIO WIRE HARNESS»(/acura/tl/iv-2008-2011/remont/body-electrical/#connectors-and-harnesses__audio-wire-harness) )

Audio unit power switch will not turn off (with navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ) Check the connectors for poor connections or loose terminals Check for aftermarket accessories plugged info the vehicle's accessory power sockets

Scheme 93

Scheme 93: Audio unit power switch will not turn off (with navigation)
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  2. Push the PWR button off to see if the audio-navigation unit turns off Does the audio system turn off? YES -Go to step 3 NO -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/navigation-system/#navigation-system__audio-navigation-unit-removalinstallation) )
  3. Push the PWR button on, then turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode Does the audio-navigation unit turn off? YES -Operation is normal NO -Go to step 4
  4. Remove the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/navigation-system/#navigation-system__audio-navigation-unit-removalinstallation) ) Disconnect audio-navigation unit connector A (24P) NOTE: Eject all the CDs before disconnecting the audio-navigation unit to prevent damaging the CD player's load mechanism
  5. Measure the voltage between terminal No 14 of audio-navigation unit connector A (24P) and body ground Is there battery voltage? YES -Check for short to power on the PUR wire NO -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/navigation-system/#navigation-system__audio-navigation-unit-removalinstallation) ), and recheck If the symptom/indication goes away, replace the original audio-navigation unit

Audio unit power switch will not turn off (without navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ) Check the connectors for poor connections or loose terminals Check for aftermarket accessories plugged info the vehicle's accessory power sockets

Scheme 94

Scheme 94: Audio unit power switch will not turn off (without navigation)
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Push the PWR button off to see if the audio unit turns off Does the audio unit turn off? YES -Go to step 3 NO -Replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) )
  3. Push the PWR button on, then turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode. Does the audio unit turn off? YES -Operation is normal NO -Go to step 4
  4. Remove the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ) Disconnect audio unit connector A (24P). NOTE: Eject all the CDs before disconnecting the audio unit to prevent damaging the CD player's load mechanism.
  5. Measure the voltage between terminal No 14 of audio unit connector A (24P) and body ground. Is there battery voltage? YES -Check for short to power on the PUR wire NO -Substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ), and recheck If the symptom/indication goes away, replace the original audio unit

No sound is heard from the speaker(s) (display is normal) (with navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ) Check the connectors for poor connections or loose terminals Set the fader and balance positions to the center Before doing the troubleshooting, do the Audio-navigation unit power switch will not turn on troubleshooting (see AUDIO UNIT POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) (WITH NAVIGATION) )

Scheme 95

Scheme 95: No sound is heard from the speaker(s) (display is normal) (with navigation)

Scheme 96

Scheme 96

Scheme 97

Scheme 97

Scheme 98

Scheme 98

Scheme 99

Scheme 99

Scheme 100

Scheme 100

Scheme 101

Scheme 101

Scheme 102

Scheme 102

Scheme 103

Scheme 103

Scheme 104

Scheme 104

Scheme 105

Scheme 105

Scheme 106

Scheme 106

Scheme 107

Scheme 107

Scheme 108

Scheme 108

Scheme 109

Scheme 109

Scheme 110

Scheme 110

Scheme 111

Scheme 111
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  2. Turn on the audio-navigation unit, and make sure the volume button is not set to the MIN level Is it at the MIN level? YES -Raise the volume level, and recheck the function NO -Go to step 3
  3. Check for sound in each mode (AM/FM and CD or DVD). Is the sound OK in each mode? YES -Intermittent failure. The system is OK at this time. Check for loose connections at the audio-navigation unit and speaker(s). NO - If there is no sound in all modes, Go to step 4 If there is no sound in AM/FM mode, do the AM or FM radio reception interference troubleshooting (see «Poor Am Or Fm Radio Reception Or Interference (With Navigation)»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__poor-am-or-fm-radio-reception) ). If there is no sound in CD or DVD mode, do the Audio disc does not play troubleshooting (see «AUDIO DISC DOES NOT PLAY (WITH NAVIGATION)»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__audio-disc-does-not-play-with) ).
  4. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
  5. Remove the center console panel (see «CENTER CONSOLE PANEL REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/gauges-instrument-panels/#consoles__center-console-panel-removalinstallation) )
  6. Disconnect the HandsFreeLink control unit 28P connector (see step 2 on «HANDSFREELINK CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#hands-free-link-system__handsfreelink-control-unit-removalinstallation) )
  7. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode, and recheck the audio system for sound Did the sound return? YES -Reconnect the HandsFreeLink control unit (see «HANDSFREELINK CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#hands-free-link-system__handsfreelink-control-unit-removalinstallation) ) NO -Go to step 8
  8. Do the speaker check mode with the self-diagnostic function (see «SPEAKER CHECK MODE»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__speaker-check-mode) ) Do all speakers produce a tone? YES -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/navigation-system/#navigation-system__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit. NO -Go to step 9
  9. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
  10. Check the No. 15 (20A) fuse in the passenger's under-dash fuse/relay box, No. 15 (10A) fuse in the under-hood fuse/relay box, and the No. 18 (7.5A) fuse in the driver's under-dash fuse/relay box. Are the fuses OK? YES -Go to step 11 NO -Replace the fuses and recheck
  11. Measure the voltage between stereo amplifier connector A (18P) terminal No. 18 and body ground. Is there battery voltage? YES -Go to step 12 NO -Repair an open in the wire between the No. 15 (20 A) fuse in the passenger's under-dash fuse/relay box and stereo amplifier connector A (18P) terminal No. 18.
  12. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  13. Measure the voltage between stereo amplifier connector B (28P) terminal No. 3 and body ground. Is there battery voltage? YES -Go to step 14 NO -Repair an open in the wire between stereo amplifier connector B (28P) terminal No. 3 and audio-navigation unit connector A (24P) terminal No. 17. If the wire and pin fits are OK, substitute a known-good audio-navigation unit (including the HDD), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit. (See «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/navigation-system/#navigation-system__audio-navigation-unit-removalinstallation) ).
  14. Measure the voltage between body ground and stereo amplifier connector A (18P) terminal No. 9. Is there less than 0.2 V? YES -Go to step 15 NO -Repair an open or high resistance in the wire between the stereo amplifier connector A (18P) terminal No. 9 and body ground (G653).
  15. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  16. Check the faulty speaker(s) for damage Is there any damage? YES -Replace the speaker, and recheck NO -Go to step 17
  17. Remove the speaker(s) with no sound (see «SPEAKER TEST/REPLACEMENT»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ), and disconnect its connector.
  18. Check the speaker 2P connector for a loose or poor connection Reconnect the speaker connector, and recheck the symptom, is the condition still present? YES -Go to step 19 NO -Intermittent failure Operation is normal
  19. Test the speakers (see «SPEAKER TEST/REPLACEMENT»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ) Is the speaker(s) OK? YES -Go to step 20 NO -Replace the speaker(s) (see «SPEAKER TEST/REPLACEMENT»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) )
  20. Reconnect the speaker connector(s)
  21. Disconnect stereo amplifier connector A (18P)
  22. Check for continuity between body ground and stereo amplifier connector A (18P) according to the table below. Speaker Stereo Amplifier Connector Wire Color Driver's door speaker, right tweeter A16 LT GRN A7 BLU Front passenger's door speaker, right tweeter A15 GRY A6 BRN Front center speaker A11 BRN A2 YEL Left rear door speaker A13 RED A4 GRN Right rear door speaker A12 BRN A3 GRY Left rear speaker A17 YEL A8 BLU Right rear speaker A14 BLU A5 YEL Subwoofer A10 GRY A1 LT BLU Is there continuity? YES -Repair a short to body ground in the wire(s) between the stereo amplifier connector and the speaker(s) NO -Go to step 23
  23. Disconnect the left tweeter 2P connector and the right tweeter 2P connector.
  24. Measure the resistance between each pair of speaker terminals at stereo amplifier connector A (18P) according to the table below. Speaker Stereo Amplifier Connector Wire Color Resistance Driver's door speaker A16 LT GRN About 2 ohms A7 BLU Front passenger's door speaker A15 GRY About 2 ohms A6 BRN Front center speaker A11 BRN About 2 ohms A2 YEL Left rear door speaker A13 RED About 2 ohms A4 GRN Right rear door speaker A12 BRN About 2 ohms A3 GRY Left rear speaker A17 YEL About 2 ohms A8 BLU Right rear speaker A14 BLU About 2 ohms A5 YEL Subwoofer A10 GRY About 2 ohms A1 LT BLU Is there resistance? YES -Go to step 25 NO -Repair an open or short in the wire between the stereo amplifier and the speaker
  25. Connect stereo amplifier connector A (18P) terminals with jumper wires
  26. Check for continuity between the tweeter 2P connector according to the table. Speaker Terminal Wire Color Left tweeter 1 LT GRN 2 BLU Right tweeter 1 GRY 2 BRN Is there continuity? YES -Go to step 27 NO -Repair an open in the wire between the stereo amplifier and the tweeter
  27. Disconnect jumper wires
  28. Disconnect stereo amplifier connector (28P)
  29. Disconnect audio unit connector D (20P)
  30. Check for continuity between body ground and audio-navigation unit connector D (20P) terminals No. 1 and No. 2 individually Is there continuity? YES -There is a short to body ground in the wire(s) between the audio-navigation unit and the stereo amplifier. Replace the affected shielded harness. NO -Go to step 31
  31. Check for continuity between the terminals of audio-navigation unit connector D (20P) according to the table below. From Terminal To Terminals D1 (RED) D2 (GRN), D11 (GRY) D2 (GRN) D11 (GRY) Is there continuity between any of the terminals? YES -There is a short in the wire(s) between the audio-navigation unit and the stereo amplifier. Replace the affected shielded harness. NO -Go to step 32
  32. Check for continuity between audio-navigation unit connector D (20P) and stereo amplifier connector B (28P) according to the table below. Audio-Navigation Unit Connector Stereo Amplifier Connector Wire Color D1 B1 RED D2 B15 GRN Is there continuity? YES -Go to step 33 NO -There is an open in the wire(s) between the audio-navigation unit and the stereo amplifier. Replace the affected shielded harness.
  33. Disconnect audio-navigation unit connector B (24P).
  34. Check for continuity between audio-navigation unit connector A (24P) and stereo amplifier connector B (28P) according to the table below. Audio-Navigation Unit Connector Stereo Amplifier Connector A6 (WHT) B28 (WHT) A7 (BLK) B14 (BLK) A10 (RED) B27 (RED) A11 (GRN) B13 (GRN) A18 (RED) B25 (RED) A19 (GRN) B11 (BRN) A22 (RED) B24 (RED) A23 (GRN) B10 (GRN) B9 (WHT) B18 (WHT) B10 (BLK) B4 (BLK) B12 (GRN) B6 (GRN) B24 (RED) B19 (RED) Is there continuity? YES -Go to step 35 NO -There is an open in the wire(s) between the audio-navigation unit and the stereo amplifier. Replace the affected shielded harness.
  35. Check for continuity between body ground and audio-navigation unit connector A (24P) and B (24P) according to the table below. Audio-Navigation Unit Connector Wire Color A6 WHT A7 BLK A9 GRY A10 RED A11 GRN` A18 RED A19 GRN A20 GRY A21 RED A22 GRN A23 GRY B9 WHT B10 BLK B11 GRY B12 GRN B24 RED Is there continuity? YES -There is a short to body ground in the wire(s) between the audio-navigation unit and the stereo amplifier. Replace the affected shielded harness. NO -Go to step 36
  36. Check for continuity between the terminals of stereo amplifier connector B (28P) and audio-navigation unit connectors A (24P) according to the table. From Terminals To Terminals Audio-Navigation Unit Connector Stereo Amplifier Connector Audio-Navigation Unit Connector A20 (GRY) B25 (RED) A18 (GRN) B11 (GRN) A19 (GRN) A21 (GRY) B10 (RED) A22 (RED) B24 (GRN) A23 (GRN) A9 (GRY) B28 (RED) A6 (WHT) B14 (GRN) A7 (BLK) B27 (RED) A10 (RED) B13 (GRN) A11 (GRN) B11 (GRY) B18 (RED) A9 (WHT) B4 (GRN) A10 (BLK) B6 (GRN) A12 (GRN) B19 (RED) A24 (RED) Is there continuity between any of the terminals? YES -There is a short in the wire(s) between the audio-navigation unit and the stereo amplifier. Replace the affected shielded harness. NO -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/navigation-system/#navigation-system__audio-navigation-unit-removalinstallation) ) and recheck. If the symptom/indication goes away, replace the original audio-navigation unit. If the symptom is still present, substitute a known-good stereo amplifier (see «STEREO AMPLIFIER REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ) and recheck. If the symptom/indication goes away, replace the original stereo amplifier.

No sound is heard from the speaker(s) (display is normal) (without navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ) Check the connectors for poor connections or loose terminals Set the fader and balance positions to the center Before doing the troubleshooting, do the audio unit power switch will not turn on troubleshooting (see AUDIO UNIT POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) (WITHOUT NAVIGATION) )

Scheme 112

Scheme 112

Scheme 113

Scheme 113

Scheme 114

Scheme 114

Scheme 115

Scheme 115

Scheme 116

Scheme 116

Scheme 117

Scheme 117

Scheme 118

Scheme 118

Scheme 119

Scheme 119

Scheme 120

Scheme 120

Scheme 121

Scheme 121

Scheme 122

Scheme 122

Scheme 123

Scheme 123
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  2. Turn on the audio-navigation unit, and make sure the volume button is not set to the MIN level Is it at the MIN level? YES -Raise the volume level, and recheck the function NO -Go to step 3
  3. Check for sound in each mode (AM/FM and CD or DVD). Is the sound OK in each mode? YES -Intermittent failure. The system is OK at this time. Check for loose connections at the audio-navigation unit and speaker(s). NO - If there is no sound in all modes, Go to step 4 If there is no sound in AM/FM mode, do the AM or FM radio reception interference troubleshooting (see «POOR AM OR FM RADIO RECEPTION OR INTERFERENCE (WITHOUT NAVIGATION)»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__poor-am-or-fm-radio-reception) ). If there is no sound in CD or DVD mode, do the Audio disc does not play troubleshooting (see «Audio Disc Does Not Play (Without Navigation)»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__audio-disc-does-not-play-without) ).
  4. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
  5. Remove the center console panel (see «CENTER CONSOLE PANEL REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/gauges-instrument-panels/#consoles__center-console-panel-removalinstallation) )
  6. Disconnect the HandsFreeLink control unit 28P connector (see step 2 on «HANDSFREELINK CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#hands-free-link-system__handsfreelink-control-unit-removalinstallation) )
  7. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode, and recheck the audio system for sound Did the sound return? YES -Reconnect the HandsFreeLink control unit (see «HANDSFREELINK CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#hands-free-link-system__handsfreelink-control-unit-removalinstallation) ) NO -Go to step 8
  8. Do the speaker check mode with the self-diagnostic function (see «SPEAKER CHECK MODE»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__speaker-check-mode) ) Do all speakers produce a tone? YES -Substitute a known-good audio unit (see «Audio Unit Removal/Installation»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit. NO -Go to step 9
  9. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
  10. Check the No. 15 (20A) fuse in the passenger's under-dash fuse/relay box, No. 15 (10A) fuse in the under-hood fuse/relay box, and the No. 18 (7.5A) fuse in the driver's under-dash fuse/relay box. Are the fuses OK? YES -Go to step 11 NO -Replace the fuses and recheck
  11. Measure the voltage between stereo amplifier connector A (18P) terminal No. 18 and body ground. Is there battery voltage? YES -Go to step 12 NO -Repair an open in the wire between the No. 15 (20 A) fuse in the passenger's under-dash fuse/relay box and stereo amplifier connector A (18P) terminal No. 18.
  12. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  13. Measure the voltage between stereo amplifier connector B (20P) terminal No. 1 and body ground. Is there battery voltage? YES -Go to step 14 NO -Repair an open in the wire between the stereo amplifier and the audio unit. If the wire and pin fits are OK, substitute a known-good audio unit, and recheck. If the symptom/indication goes away, replace the original audio unit (see «Audio Unit Removal/Installation»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ).
  14. Measure the voltage between body ground and stereo amplifier connector A (18P) terminal No. 9. Is there less than 0.2 V? YES -Go to step 15 NO -Repair an open or high resistance in the wire between the stereo amplifier connector A (18P) terminal No. 9 and body ground (G653) (see «RIGHT SIDE WIRE HARNESS (WITHOUT SH-AWD)»(/acura/tl/iv-2008-2011/remont/body-electrical/#connectors-and-harnesses__right-side-wire-harness-without-sh-awd) ).
  15. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  16. Check the faulty speaker(s) for damage. Is there any damage? YES -Replace the speaker (see «Speaker Test/Replacement»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ), and recheck. NO -Go to step 17
  17. Remove the speaker(s) with no sound (see «Speaker Test/Replacement»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ) and disconnect its connector.
  18. Check the speaker 2P connector for a loose or poor connection Reconnect the speaker connector, and recheck the symptom, is the condition still present? YES -Go to step 19 NO -Intermittent failure Operation is normal
  19. Test the speaker(s) (see «Speaker Test/Replacement»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ) Is the speaker OK? YES -Go to step 20 NO -Replace the speaker(s) (see «Speaker Test/Replacement»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) )
  20. Reconnect the speaker connector(s)
  21. Disconnect stereo amplifier connector A (18P)
  22. Check for continuity between body ground and stereo amplifier connector A (18P) according to the table STEREO AMPLIFIER CONNECTOR REFERENCE CHART Speaker Stereo amplifier connector Wire color Driver's door speaker, left tweeter A11 (+) LT GRN A2 (-) BLU Front passenger's door speaker, right tweeter A15 (+) GRY A6 (-) BRN Left rear speaker A10 (+) YEL A1 (-) BLU Right rear speaker A14 (+) BLU A5 (-) YEL Subwoofer A12 (+) GRY A3 (-) LT BLU Front center speaker A16 (+) BRN A7 (-) YEL Is there continuity? YES -Repair short to body ground in the wire(s) between the stereo amplifier and the speaker(s) NO -Go to step 23
  23. Disconnect the left tweeter 2P connector and the right tweeter 2P connector.
  24. Measure the resistance between each pair of speaker terminals at stereo amplifier connector A (18P) according to the table below. Speaker Stereo Amplifier Connector Wire Color Resistance Driver's door speaker A11 LT GRN About 4 ohms A2 BLU Front passenger's door speaker A15 GRY About 4 ohms A6 BRN Front center speaker A16 BRN About 2 ohms A7 YEL Left rear speaker A10 YEL About 4 ohms A1 BLU Right rear speaker A14 BLU About 4 ohms A5 YEL Subwoofer A12 GRY About 2 ohms A3 LT BLU Is there resistance? YES -Go to step 25 NO -Repair an open or short in the wire between the stereo amplifier and the speaker
  25. Connect stereo amplifier connector A (18P) terminals with jumper wires
  26. Check for continuity between the tweeter 2P connector according to the table below. Speaker Terminal Wire Color Left tweeter 1 LT GRN 2 BLU Right tweeter 1 GRY 2 BRN Is there continuity? YES -Go to step 27 NO -Repair an open in the wire between the stereo amplifier and the tweeter
  27. Disconnect jumper wires.
  28. Disconnect audio unit connector A (24P), stereo amplifier connector B (14P), and audio unit connector B (14P) NOTE: Eject all the CDs before disconnecting the audio unit to prevent damaging the CD player's load mechanism.
  29. Check for continuity between audio unit connector A (24P), connector B (14P), and stereo amplifier connector B (28P) according to the table below. STEREO AMPLIFIER CONNECTOR REFERENCE CHART Audio unit connector Stereo amplifier connector A18 (RED) B17 (BLK) A19 (GRN) B7 (WHT) A22 (RED) B16 (GRY) A23 (GRN) B6 (GRY) B1 (RED) B14 (GRN) B2 (WHT) B13 (RED) B3 (BLK) B3 (RED) B4 (RED) B19 (GRN) B5 (WHT) B20 (GRY) B8 (GRN) B4 (GRY) B11 (GRN) B9 (WHT) B12 (BLK) B10 (BLK) Is there continuity? YES -Go to step 30 NO -There is an open in the wire(s) between the stereo amplifier and the audio unit Replace the affected shielded harness
  30. Check for continuity between audio unit connector A(24P) and B (14P) body ground according to the table AUDIO UNIT CONNECTOR REFERENCE CHART Audio unit connector Wire color A18 RED A19 GRN A20 GRY A21 GRY A22 RED A23 GRN B1 RED B2 WHT B3 BLK B4 RED B5 WHT B6 GRY B8 GRN B9 GRY B11 GRN B12 BLK Is there continuity? YES -There is a short to body ground in the wire(s) between the stereo amplifier and the audio unit Replace the affected shielded harness NO -Go to step 26
  31. Check for continuity between the terminals of stereo amplifier connector B (20P) and audio unit connector A (24P) and B (14P) according to the table TERMINAL REFERENCE CHART From terminals To terminals Audio unit connector Stereo amplifier connector Audio unit connector A20 (GRY) B17 (RED) A18 (RED) B7 (GRN) A19 (GRN) A21 (GRY) B16 (RED) A22 (RED) B6 (GRN) A23 (GRN) B6 (GRY) B19 (RED) B4 (RED) B20 (WHT) B5 (WHT) B9 (GRN) B11 (GRN) B10 (BLK) B12 (BLK) B9 (GRY) B14 (RED) B1 (RED) B13 (WHT) B2 (WHT) B3 (BLK) B3 (BLK) B4 (GRN) B8 (GRN) Is there continuity between any of the terminals? YES -There is a short in the wires between the stereo amplifier and the audio unit Replace the affected shielded harness NO -Substitute a known-good audio unit and recheck (see «Audio Unit Removal/Installation»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ). If the symptom/indication goes away, replace the original audio unit. If the symptom is still present, substitute a known-good stereo amplifier (see «Stereo Amplifier Removal/Installation»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ) and recheck. If the symptom/indication goes away, replace the original stereo amplifier.

Note. Check the vehicle battery condition first (see BATTERY TEST ) Check the connectors for poor connections or loose terminals

  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  2. Turn on the audio-navigation unit, and check for sound in each mode (AM, FM, XM, and CD) Is there sound from the speakers, and is the sound quality normal in each mode? YES -Intermittent failure, The system is OK at this time Check for loose connections at the audio unit, the amplifier, and each speaker NO -Speakers all work, sound quality is poor If the sound quality is poor only with XM radio, or the XM radio does not function, go to poor or no sound with XM radio (see «POOR OR NO SOUND WITH XM RADIO (AUDIO UNIT DOES DISPLAY XM CHANNELS) (WITH NAVIGATION)»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__poor-or-no-sound-with-xm) ) If the sound quality is poor only with AM or FM, go to poor AM or FM radio reception or interference (see «Poor Am Or Fm Radio Reception Or Interference (With Navigation)»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__poor-am-or-fm-radio-reception) ) If the sound is poor in all modes, go to sound quality diagnosis (see «SOUND QUALITY DIAGNOSIS»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__sound-quality-diagnosis) )

Note. Check the vehicle battery condition first (see BATTERY TEST ) Check the connectors for poor connections or loose terminals

  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  2. Turn on the audio unit, and check for sound in each mode (AM, FM, XM, and CD) Is there sound from the speakers, and is the sound quality normal in each mode? YES -Intermittent failure The system is OK at this time Check for loose connections at the audio unit, the amplifier, and each speaker NO -Speakers all work, sound quality is poor If the sound quality is poor only with XM radio, or the XM radio does not function, go to poor or no sound with XM radio (see «POOR OR NO SOUND WITH XM RADIO (AUDIO UNIT DOES DISPLAY XM CHANNELS) (WITHOUT NAVIGATION)»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__poor-or-no-sound-with-xm) ) If the sound quality is poor only with AM or FM, go to poor AM or FM radio reception or interference (see «POOR AM OR FM RADIO RECEPTION OR INTERFERENCE (WITHOUT NAVIGATION)»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__poor-am-or-fm-radio-reception) ) If the sound is poor mall modes, go to sound quality diagnosis (see «SOUND QUALITY DIAGNOSIS»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__sound-quality-diagnosis) )

Radio preset memory is lost (with navigation)

Note. If only XM stations are lost, go to XM radio preset memory is lost with AcuraLink (see XM RADIO PRESET MEMORY IS LOST (USA MODELS WITH NAVIGATION) ), without AcuraLink (see XM RADIO PRESET MEMORY IS LOST (CANADA MODELS WITH NAVIGATION) )

  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  2. Turn on the audio-navigation unit, and set each of the radio station preset buttons Do each of the buttons set properly? YES -Go to step 3 NO -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/navigation-system/#navigation-system__audio-navigation-unit-removalinstallation) )
  3. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode for 1 minute, then back to ON (II), or the ON mode
  4. Test the preset buttons for proper recall operation Do the preset buttons recall the set radio stations? YES -System is normal at this time Check connections at the audio-navigation unit NO -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/navigation-system/#navigation-system__audio-navigation-unit-removalinstallation) ), and recheck If the symptom/indication goes away, replace the original audio-navigation unit

Radio preset memory is lost (without navigation)

Note. If only XM stations are lost, go to XM radio preset memory is lost (see XM RADIO PRESET MEMORY IS LOST (WITHOUT NAVIGATION) )

  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  2. Turn on the audio unit, and set each of the radio station preset buttons Do each of the buttons set properly? YES -Go to step 3 NO -Replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) )
  3. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode for 1 minute, then turn it back to ON (II), or the ON mode.
  4. Test the preset buttons for proper recall operation Do the preset buttons recall the set radio stations? YES -System is normal at this time Check connections at the audio unit NO -Substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ), and recheck If the symptom/indication goes away, replace the original audio unit.

Volume does not change (with navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ) Check the connectors for poor connections or loose terminals Set the fader and balance positions to the center

Scheme 124

Scheme 124: Volume does not change (with navigation)

Scheme 125

Scheme 125

Scheme 126

Scheme 126
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  2. Turn on the audio-navigation unit, and check for sound in each mode (AM, FM, XM, and CD) Is the sound normal? YES -Go to step 3 NO -Go to Sound Quality Diagnosis (see «SOUND QUALITY DIAGNOSIS»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__sound-quality-diagnosis) ) or no sound is heard from speaker(s) (display is normal) (see «NO SOUND IS HEARD FROM THE SPEAKER(S) (DISPLAY IS NORMAL) (WITH NAVIGATION)»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__no-sound-is-heard-from-the) )
  3. Operate the volume knob to see if the volume changes Does the volume change? YES -Operation is normal NO -Go to step 4
  4. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
  5. Disconnect the audio switch panel 24P connector and audio-navigation unit connector F (12P)
  6. Check for continuity between the audio-navigation switch panel 24P connector terminals No. 5 and No. 12 and audio-navigation unit connector F (12P) terminals No. 1 and No. 13 respectively. Is there continuity? YES -Go to step 7 NO -There is an open in the wire(s) between the audio-navigation unit and the audio-navigation switch panel Replace the affected shielded harness
  7. Check for continuity between the audio-navigation switch panel 24P connector and body ground according to the table AUDIO-NAVIGATION SWITCH PANEL CONNECTOR REFERENCE CHART Audio-navigation switch panel connector Wire color 1 BLU 13 PNK Is there continuity? YES -There is a short to body ground in the wire(s) between the audio-navigation unit and the audio-navigation switch panel Replace the affected shielded harness NO -Go to step 8
  8. Check for continuity between the terminals of audio-navigation switch panel 24P connector according to the table TERMINAL REFERENCE CHART From terminal To terminals 1 (BLU) 2 (GRY), 13 (PNK) 2 (GRY) 13 (PNK) Is there continuity between any of the terminals? YES -There is a short in the wires between the audio-navigation unit and the audio-navigation switch panel Replace the affected shielded harness NO -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/navigation-system/#navigation-system__audio-navigation-unit-removalinstallation) ), and recheck If the symptom-indication goes away, replace the original audio-navigation unit. If the symptom is still present, substitute a known-good audio-navigation switch panel (see «AUDIO-NAVIGATION SWITCH PANEL REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ), and recheck If the symptom/indication goes away, replace the original audio-navigation switch panel

Volume does not change (without navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ) Check the connectors for poor connections or loose terminals Set the fader and balance positions to the center

  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  2. Turn on the audio unit, and check for sound in each mode (AM, FM, XM, and CD) Is the sound normal? YES -Go to step 3 NO -Go to Sound Quality Diagnosis (see «SOUND QUALITY DIAGNOSIS»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__sound-quality-diagnosis) ) or no sound is heard from speaker(s) (display is normal), (see «NO SOUND IS HEARD FROM THE SPEAKER(S) (DISPLAY IS NORMAL) (WITHOUT NAVIGATION)»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__no-sound-is-heard-from-the) )
  3. Operate the volume knob to see if the volume changes Does the volume change? YES -Operation is normal NO -Substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ), and recheck If the symptom/indication goes away, replace the original audio unit.

Radio tuner does not change stations (with navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ) Check the connectors for poor connection or loose terminals

Scheme 127

Scheme 127: Radio tuner does not change stations (with navigation)

Scheme 128

Scheme 128

Scheme 129

Scheme 129

Scheme 130

Scheme 130
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  2. Turn on the audio-navigation unit, and check the audio information on the display panel Does the audio information display properly? YES -Go to step 3 NO -Go to power switch will not turn on (No information display and no sound). (see «AUDIO UNIT POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) (WITH NAVIGATION)»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__audio-unit-power-switch-will-not) )
  3. Operate the tuning knob to see if the radio station changes Does the radio station change? YES -Intermittent failure, the tuning knob is OK at this time NO -Go to step 4
  4. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
  5. Disconnect the audio-navigation switch panel 24P connector and audio-navigation unit connector F (12P)
  6. Check for continuity between audio-navigation unit connector F (12P) and the audio-navigation switch panel 24P connector according to the table AUDIO-NAVIGATION SWITCH PANEL CONNECTOR REFERENCE CHART Audio-navigation unit connector Audio-navigation switch panel connector Wire color F3 18 PUR F9 6 LT BLU Is there continuity? YES -Go to step 7 NO -There is an open in the wire(s) between the audio-navigation unit and the audio-navigation switch panel Replace the affected shielded harness
  7. Check for continuity between the audio-navigation switch panel 24P connector and body ground according to the table AUDIO-NAVIGATION SWITCH PANEL CONNECTOR REFERENCE CHART Audio-navigation switch panel connector Wire color 6 LT BLU 18 PUR Is there continuity? YES -There is a short to body ground in the wire(s) between audio-navigation unit and audio-navigation switch panel. Replace the affected shielded harness NO -Go to step 8
  8. Check for continuity between the terminals of audio-navigation switch panel 24P connector according to the table TERMINAL REFERENCE CHART From terminal To terminals 5 (GRY) 6 (LT BLU), 18 (PUR) 6 (LT BLU) 18 (PUR) Is there continuity between any of the terminals? YES -There is a short in the wires between the audio-navigation unit and the audio-navigation switch panel Replace the affected shielded harness NO -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/navigation-system/#navigation-system__audio-navigation-unit-removalinstallation) ), and recheck If the symptom/indication goes away, replace the original audio unit If the symptom is still present, substitute a known-good audio-navigation switch panel (see «AUDIO-NAVIGATION SWITCH PANEL REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ), and recheck If the symptom/indication goes away, replace the original audio-navigation switch panel

Radio tuner does not change stations (without navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ) Check the connectors for poor connection or loose terminals

  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  2. Turn on the audio unit, and check the audio information on the display panel Does the audio information display properly? YES -Go to step 3 NO -Go to power switch will not turn on (see «AUDIO UNIT POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) (WITHOUT NAVIGATION)»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__audio-unit-power-switch-will-not) )
  3. Operate the tuning knob to see if the radio station changes Does the radio station change? YES -Intermittent failure, the tuning knob is OK at this time NO -Substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ), and recheck If the symptom/indication goes away, replace the original audio unit

Note. Check the vehicle battery condition first (see BATTERY TEST ) Check the connectors for poor connections or loose terminals

Scheme 131

Scheme 131: Audio system information does not display on the audio-navigation switch panel display (with navigat

Scheme 132

Scheme 132

Scheme 133

Scheme 133

Scheme 134

Scheme 134
  1. Remove the audio-navigation switch panel (see «AUDIO-NAVIGATION SWITCH PANEL REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) )
  2. Check the connections at the audio-navigation switch panel 24P connector and audio-navigation unit connector F (12P) Are the connectors and terminals connected properly? YES -Go to step 3 NO -Repair the connection, and recheck
  3. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  4. Measure the voltage between audio-navigation switch panel 24P connector terminals No 21 and No 22 and body ground individually Is there battery voltage? YES -Go to step 5 NO -Repair open in the wire between the No 15 (10 A) fuse in the under-hood fuse/relay box and audio-navigation switch panel 24P connector terminal No 22, or repair open in the wire between the No 16(7 5 A) fuse in the driver's under-dash fuse/relay box and the audio-navigation switch panel 24P connector terminal No 21
  5. Measure the voltage between audio-navigation switch panel 24P connector terminal No 10 and body ground Is there less than 0.2 V? YES -Go to step 6 NO -Repair open or high resistance in the wire between audio-navigation switch panel 24P connector terminal No 10 and body ground (G501) (see «AUDIO WIRE HARNESS»(/acura/tl/iv-2008-2011/remont/body-electrical/#connectors-and-harnesses__audio-wire-harness) )
  6. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
  7. Disconnect audio-navigation unit connector F (12P)
  8. Check for continuity between audio-navigation unit connector F (12P) and the audio-navigation switch panel 24P connector according to the table AUDIO-NAVIGATION SWITCH PANEL CONNECTOR REFERENCE CHART Audio-navigation unit connector Audio-navigation switch panel connector Wire color F7 16 BRN F1 15 YEL F8 3 BLU Is there continuity? YES -Go to step 9 NO -There is an open in the wire(s) between the audio-navigation unit and the audio-navigation switch panel Repair or replace the affected shielded harness
  9. Check for continuity between the terminals of the audio-navigation switch panel 24P connector and body ground according to the table AUDIO-NAVIGATION SWITCH PANEL CONNECTOR REFERENCE CHART Audio-navigation switch panel connector Wire color 3 BLU 15 YEL 16 BRN Is there continuity? YES -There is a short in the wires between the audio-navigation unit and the audio-navigation switch panel Repair or replace the affected shielded harness NO -Go to step 10
  10. Check for continuity between the terminals of audio-navigation switch panel 24P connector according to the table TERMINAL REFERENCE CHART From terminal To terminals 4 (GRY) 15 (YEL), 16 (BRN) 15 (YEL) 16 (BRN) Is there continuity between any of the terminals? YES -There is a short in the wires between the audio-navigation unit and the audio-navigation switch panel Replace the affected shielded harness NO -Substitute a known-good audio-navigation switch panel (see «AUDIO-NAVIGATION SWITCH PANEL REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ), and recheck If the symptom/indication goes away, replace the original audio-navigation switch panel.If the symptom is still present, substitute a known-good audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/navigation-system/#navigation-system__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit

Note. Check the vehicle battery condition first (see BATTERY TEST ) Check the connectors for poor connections or loose terminals

Scheme 135

Scheme 135: Audio system information does not display on the audio-HVAC display unit (without navigation)

Scheme 136

Scheme 136

Scheme 137

Scheme 137

Scheme 138

Scheme 138

Scheme 139

Scheme 139

Scheme 140

Scheme 140
  1. Remove the audio-HVAC display unit (see «AUDIO-HVAC DISPLAY UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) )
  2. Check the connections at the audio-HVAC display unit 12P connector and audio unit connector D (20P) Are the connectors and terminals connected properly? YES -Go to step 3 NO -Repair the connection, and recheck
  3. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  4. Measure the voltage between audio-HVAC display unit 12P connector terminals No 5 and No 6 and body ground individually Is there battery voltage? YES -Go to step 5 NO -Repair open in the wire between the No 15 (10 A) fuse in the under-hood fuse/relay box and audio-HVAC display unit 12P connector terminal No 6, or repair open in the wire between the No 16 (7 5 A) fuse in the driver's under-dash fuse/relay box and audio-HVAC display unit 12P connector terminal No 5
  5. Measure the voltage between audio-HVAC display unit 12P connector terminal No 9 and body ground Is there less than 0.2 V? YES -Go to step 6 NO -Repair open or high resistance in the wire between audio-HVAC display 12P connector terminal No 9 and body ground (G501) (see «AUDIO WIRE HARNESS»(/acura/tl/iv-2008-2011/remont/body-electrical/#connectors-and-harnesses__audio-wire-harness) )
  6. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
  7. Disconnect audio unit connector D (20P)
  8. Check for continuity between audio unit connector D (20P) and the audio-HVAC display unit 12P connector according to the table AUDIO-HVAC DISPLAY UNIT CONNECTOR REFERENCE CHART Audio unit connector Audio-HVAC display unit connector Wire color D6 2 BRN D7 1 YEL D17 4 BLU Is there continuity? YES -Go to step 9 NO -There is an open in the wire(s) between the audio unit and the audio-HVAC display unit Replace the affected shielded harness
  9. Check for continuity between the terminals of the audio unit connector D (20P) and body ground according to the table AUDIO UNIT CONNECTOR REFERENCE CHART Audio unit connector Wire color D6 BRN D7 YEL D17 BLU Is there continuity? YES -There is a short to body ground in the wire(s) between the audio unit and the audio-HVAC display unit Repair or replace the affected shielded harness NO -Go to step 10
  10. Check for continuity between the terminals of audio unit connector D (20P) according to the table TERMINAL REFERENCE CHART From terminal To terminals 6 (BRN) 7 (YEL), 16 (GRY) 7 (YEL) 16 (GRY) Is there continuity between any of the terminals? YES -There is a short in the wires between the audio unit and the audio-HVAC display unit. Replace the affected shielded harness NO -Substitute a known-good audio-HVAC display unit (see «AUDIO-HVAC DISPLAY UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ), and recheck. If the symptom/indication goes away, replace the original audio-HVAC display unit. If the symptom/indication is still present, replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ).

Audio-navigation switch panel button illumination does not work (with navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ) Check the connectors for poor connections or loose terminals

Scheme 141

Scheme 141: Audio-navigation switch panel button illumination does not work (with navigation)

Scheme 142

Scheme 142
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  2. Turn the combination lighting switch to the parking light position
  3. Check the illumination of the audio-navigation switch panel buttons Are the buttons illuminated? YES -Intermittent problem The audio-navigation switch panel is OK at this time Check for loose or poor connections at the audio-navigation switch panel 24P connector NO -Go to step 4
  4. Check the illumination of several other buttons not related to the audio system Are the buttons illuminated? YES -Go to step 5 NO -Troubleshoot the interior lights Start by checking the No 6 (7 5 A) fuse in the passenger's under-dash fuse/relay box If the fuse is OK, check for an open in the wire between passenger's under-dash fuse/relay box and the audio-navigation switch panel
  5. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
  6. Disconnect the audio-navigation switch panel 24P connector and the gauge control module 32P connector
  7. Check for continuity between audio-navigation switch panel 24P connector terminals No 11 and No 12 and gauge control module 32P connector terminal No 8 and No 27 Is there continuity? YES -Go to step 8 NO -Repair open in the wire between the gauge control module and the audio-navigation switch panel
  8. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  9. With the headlight switch still on, measure the voltage between audio-navigation switch panel 24P connector terminal No 23 and body ground Is there battery voltage? YES -Check the connections at the audio-navigation switch panel 24P connector If all connections are OK, substitute a known-good audio-navigation switch panel (see «AUDIO-NAVIGATION SWITCH PANEL REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ), and recheck If the symptom/indicated goes away, replace the original audio-navigation switch panel NO -Repair open in the wire between the passenger's under-dash fuse/relay box and the audio-navigation switch panel

Audio switch panel button illumination does not work (without navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ) Check the connectors for poor connections or loose terminals

Scheme 143

Scheme 143: Audio switch panel button illumination does not work (without navigation)

Scheme 144

Scheme 144
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  2. Turn the combination lighting switch to the parking light position
  3. Check the illumination of the audio unit buttons Are the buttons illuminated? YES -Intermittent problem, the audio unit is OK at this time Check for loose or poor connections at audio unit connector A (24P) NO -Go to step 4
  4. Check the illumination of several other buttons not related to the audio system Are the buttons illuminated? YES -Go to step 5 NO -Troubleshoot the interior lights Start by checking the No 6 (7 5 A) fuse in the passenger's under-dash fuse/relay box If the fuse is OK, check for an open in the wire between the passenger's under-dash fuse/relay box and the audio unit
  5. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
  6. Disconnect audio unit connector A (24P) NOTE: Eject all the CDs before removing the audio unit to prevent damaging the CD player's load mechanism
  7. Disconnect the gauge control module 32P connector
  8. Check for continuity between audio unit connector A (24P) terminal No 1 and gauge control module 32P connector terminal No 8 Is there continuity? YES -Go to step 9 NO -Repair open in the wire between the gauge control module and the audio unit
  9. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  10. With the headlight switch still on, measure the voltage between audio unit connector A (24P) terminal No 13 and body ground Is there battery voltage? YES -Check the connections at audio unit connector A (24P) If all connections are OK, replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ) NO -Repair open in the wire between the passenger's under-dash fuse/relay box and the audio unit

Audio remote switch does not work properly (with navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ) Check the connectors for poor connections or loose terminals

Scheme 145

Scheme 145: Audio remote switch does not work properly (with navigation)

Scheme 146

Scheme 146
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  2. Turn on the audio-navigation unit, and check the audio remote switch operation (volume up, volume down, CH (UP), CH (DOWN), MODE) Is the audio system operation OK? YES -Intermittent failure, the audio remote switch is OK at this time Check for loose connections NO -Go to step 3
  3. Test the audio remote switch (see «Audio Remote Switch Test»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ) Is the audio remote switch OK? YES -Go to step 4 NO -Replace the audio remote, HFL-navigation voice control switch (see «STEERING WHEEL DISASSEMBLY/REASSEMBLY»(/acura/tl/iv-2008-2011/remont/electronic-steering/#power-steering-system) )
  4. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
  5. Remove the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/navigation-system/#navigation-system__audio-navigation-unit-removalinstallation) )
  6. Disconnect audio-navigation unit connector A (24P) NOTE: Eject all the CDs before disconnecting audio-navigation unit to prevent damaging the CD player's load mechanism
  7. Reconnect the audio remote switch, and measure the resistance between audio-navigation unit connector A (24P) terminals No 5 and No 16 as specified in the table AUDIO REMOTE SWITCH TABLE AUDIO REMOTE SWITCH REFERENCE CHART Button held down VOL DOWN VOL UP CH (-) CH (+) MODE No button pressed Resistance about 100 ohms about 357 ohms about 775 ohms about 1.7 kohms about 3.7 kohms about 10 kohms Is the resistance OK? YES -Go to step 8 NO -Repair short or high resistance in the circuit between the audio-navigation unit and the audio remote switch If the wires are OK, replace the cable reel (see «DISPOSAL OF DAMAGED COMPONENTS»(/acura/tl/iv-2008-2011/remont/airbag/#srs-supplemental-restraint-system__disposal-of-damaged-components) )
  8. Disconnect the audio remote, HFL-navigation voice control switch 12P connector
  9. Check for continuity between body ground and terminals No 5 and No 16 of audio-navigation unit connector A (24P) individually Is there continuity? YES -Repair short to body ground in the circuit between the audio-navigation unit and the audio remote switch If the wires are OK, replace the cable reel (see «CABLE REEL REPLACEMENT»(/acura/tl/iv-2008-2011/remont/airbag/#srs-supplemental-restraint-system) ) NO -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/navigation-system/#navigation-system__audio-navigation-unit-removalinstallation) )

Audio remote switch does not work properly (without navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ) Check the connectors for poor connections or loose terminals

Scheme 147

Scheme 147: Audio remote switch does not work properly (without navigation)

Scheme 148

Scheme 148
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  2. Turn on the audio unit, and check the audio remote switch operation (volume up, volume down, CH (UP), CH (DOWN), MODE) Is the audio system operation OK? YES -Intermittent failure, the audio remote switch is OK at this time Check for loose connections NO -Go to step 3
  3. Test the audio remote switch (see «Audio Remote Switch Test»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ) Is the audio remote switch OK? YES -Go to step 4 NO -Replace the audio remote-HFL switch (see «STEERING WHEEL DISASSEMBLY/REASSEMBLY»(/acura/tl/iv-2008-2011/remont/electronic-steering/#power-steering-system) )
  4. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
  5. Remove the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) )
  6. Disconnect audio unit connector A (24P) NOTE: Eject all the CDs before disconnecting audio unit to prevent damaging the CD player's load mechanism
  7. Reconnect the audio remote switch, and measure the resistance between audio unit connector A (24P) terminals No 5 and No 16 as specified in the table AUDIO REMOTE SWITCH TABLE AUDIO REMOTE SWITCH REFERENCE CHART Button held down VOL DOWN VOL UP CH (-) CH (+) MODE No button pressed Resistance about 100 ohms about 357 ohms about 775 ohms about 1.7 kohms about 3.7 kohms about 10 kohms Is the resistance OK? YES -Go to step 8 NO -Repair short or high resistance in the circuit between the audio unit and the audio remote switch If the wires are OK, replace the cable reel (see «DISPOSAL OF DAMAGED COMPONENTS»(/acura/tl/iv-2008-2011/remont/airbag/#srs-supplemental-restraint-system__disposal-of-damaged-components) )
  8. Disconnect the audio remote-HFL switch 12P connector
  9. Check for continuity between body ground and terminals No 5 and No 16 of audio unit connector A (24P) individually Is there continuity? YES -Repair short to body ground in the circuit between the audio unit and the audio remote switch If the wires are OK, replace the cable reel (see «CABLE REEL REPLACEMENT»(/acura/tl/iv-2008-2011/remont/airbag/#srs-supplemental-restraint-system) ) NO -Replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) )

Audio disc does not load (with navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ) Check the connectors for poor connections or loose terminals Disc labels should not be used in the audio-navigation unit They may jam and damage the player mechanism Make sure the audio disc is compatible with the system (see the owner's manual for more information)

  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  2. Turn on the audio-navigation unit, and insert a known-good disc to see if the symptom can be duplicated Does the disc load? YES -Operation is normal If the disc loads normally, but will not play, go to Audio disc does not play (see «AUDIO DISC DOES NOT PLAY (WITH NAVIGATION)»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__audio-disc-does-not-play-with) ) NO -Go to step 3
  3. Insert another disc Does the disc load? YES -The original disc is faulty NO -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/navigation-system/#navigation-system__audio-navigation-unit-removalinstallation) ) If the symptom/indication goes away, replace the original audio-navigation unit.

Audio disc does not load (without navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ) Check the connectors for poor connections or loose terminals Disc labels should not be used in the audio unit They may jam and damage the player mechanism Make sure the audio disc is compatible with the system (see the owner's manual for more information)

  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  2. Turn on the audio unit, and insert a known-good disc to see if the symptom can be duplicated Does the disc load? YES -Operation is normal If the disc loads normally, but will not play, go to Audio disc does not play (see «Audio disc does not play (without navigation)»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__audio-disc-does-not-play-without) ) NO -Go to step 3
  3. Insert another disc Does the disc load? YES -The original disc is faulty? NO -Substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ) If the symptom/indication goes away, replace the original audio unit?

Audio disc does not eject (with navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ) Disc labels should not be used in the audio-navigation unit They may jam and damage the player mechanism Check the connectors for poor connections or loose terminals

  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  2. Turn on the audio-navigation unit Does the system turn on? YES -Go to step 3 NO -Go to audio unit power switch will not turn on (see «AUDIO UNIT POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) (WITH NAVIGATION)»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__audio-unit-power-switch-will-not) )
  3. Check to see if the disc ejects correctly with no binding when you push the EJECT button Does the disc eject properly? YES -Operation is normal NO -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/navigation-system/#navigation-system__audio-navigation-unit-removalinstallation) ) If the symptom/indication goes away, replace theoriginal audio-navigation unit.

Audio disc does not eject (without navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ) Disc labels should not be used in the audio unit They may jam and damage the player mechanism Check the connectors for poor connections or loose terminals

  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  2. Turn on the audio unit Does the system turn on? YES -Go to step 3 NO -Go to audio unit power switch will not turn on (see «AUDIO UNIT POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) (WITHOUT NAVIGATION)»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__audio-unit-power-switch-will-not) )
  3. Check to see if the disc ejects correctly with no binding when you push the EJECT button Does the disc eject properly? YES -Operation is normal NO -Substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ) If the symptom/indication goes away, replace the orinal audio unit

Audio disc changer does not load all six discs (without navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ) Check the connectors for poor connections or loose terminals Disc labels should not be used in the audio unit They may jam and damage the player mechanism

  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  2. Turn on the audio unit, and try loading six discs into the audio unit (in-dash disc changer) Does the audio unit accept all six discs? YES -Intermittent failure, the audio unit is OK at this time NO -Go to step 3
  3. Try loading the disc player with six known-good discs Does the audio unit (m-dash disc changer) accept all six discs? YES -At least one of the original discs is faulty NO -Substitute a known-good audio unit (in-dash disc changer) (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ), and recheck If the symptom/indication goes away, replace the original audio unit (m-dash disc changer)

Audio disc changer does not move between discs (without navigation)

Note. Check the vehicle battery condition first. (see BATTERY TEST ) Check the connectors for poor connections or loose terminals Disc labels should not be used in the audio unit They may jam and damage the player mechanism

  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  2. Insert six discs into the audio unit (m-dash disc changer), and see if the changer moves between discs Does the changer operate normally? YES -Intermittent failure, the disc changer is OK at this time NO -Go to step 3
  3. Insert six known-good discs into the audio unit Does the changer operate normally? YES -At least one of the original discs is faulty NO -Substitute a known-good audio unit (in-dash disc changer) (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ), and recheck If the symptom/indication goes away, replace the original audio unit (in-dash disc changer).

Audio disc does not play (with navigation)

Special tools required

Diagnostic CD 07AAZ-SDBA100

Note. Check the vehicle battery condition first (see BATTERY TEST ) Check the connectors for poor connections or loose terminals Disc labels should not be used in the audio-navigation unit They may jam and damage the player mechanism

  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  2. Turn on the audio-navigation unit, and try loading a disc Does the disc load? YES -Go to step 3 NO -Go to audio disc does not load (see «AUDIO DISC DOES NOT LOAD (WITH NAVIGATION)»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__audio-disc-does-not-load-with) )
  3. Insert a known-good disc to see if the symptom can be duplicated Does the disc play? YES -Operation is normal NO -Go to step 4
  4. Insert audio diagnostic CD (T/N 07AAZ-SDBA100) in the audio-navigation unit Does the disc play? YES -The original disc is faulty or has an unreadable format NO -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/navigation-system/#navigation-system__audio-navigation-unit-removalinstallation) ) If the symptom/indication goes away, replace the original audio-navigation unit

Audio disc does not play (without navigation)

Special tools required

Diagnostic CD 07AAZ-SDBA100

Note. Check the vehicle battery condition first (see BATTERY TEST ) Check the connectors for poor connections or loose terminals Disc labels should not be used in the audio unit They may jam and damage the player mechanism

  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  2. Turn on the audio unit, and try loading a disc Does the disc load? YES -Go to step 3 NO -Go to audio disc does not load (see «AUDIO DISC DOES NOT LOAD (WITH NAVIGATION)»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__audio-disc-does-not-load-with) )
  3. Insert a known-good disc to see if the symptom can be duplicated Does the disc play? YES -Operation is normal NO -Go to step 4
  4. Insert audio diagnostic CD (T/N 07AAZ-SDBA100) in the audio unit Does the disc play? YES -The original disc is faulty or has an unreadable format NO -Substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ) If the symptom/indication goes away, replace the original audio unit

Audio disc skips (with navigation)

Special tools required

  1. Diagnostic CD 07AAZ-SDBA100
  2. Skip test CD 07AAZ-SDBA200
  3. Skip test CD 07AAZ-SDBA300

Note. Check the vehicle battery condition first (see BATTERY TEST ) Check the connectors for poor connections or loose terminals Disc labels should not be used in the audio-navigation unit They may jam and damage the player mechanism

  1. Confirm the vehicles tires are properly inflated
  2. Check the client's disc for scratches and fingerprints NOTE: The following test should be done with the audio system bass and treble set to the client's listening settings When comparing to known-good vehicles, do the comparison on the same model and trim level
  3. Test-drive the vehicle to identify when the client's disc skips The audio diagnostic CD (T/N 07AAZ-SDBA100) can be used if the client's CD is not available, use tracks 10-12 Does the disc skip? YES -Go to step 4 NO -Operation is normal
  4. Compare the client's CD that skips to a known-good vehicle under the same conditions Does the disc skip in the known-good vehicle under the same conditions? YES -The disc player operation is normal, the problem is with the client's disc NO -Go to step 5 NOTE: Do the following test with vehicle parked and the engine running
  5. Insert the diagnostic skip test CD (T/N 07AAZ-SDBA300) Play tracks 2-11, and note on which track number(s) the disc starts skipping Do the same test on a known-good vehicle Does the disc skip on the same track(s) as the known-good vehicle? YES -Operation is normal NO -Go to step 6
  6. Insert the diagnostic skip test CD (T/N 07AAZ-SDBA200) Play tracks 7-11 and tracks 13-15, and note on which track number(s) the disc starts skipping Do the same test on a known-good vehicle Does the disc skip on the same track number (s) as the known-good vehicle? YES -Operation is normal NO -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/navigation-system/#navigation-system__audio-navigation-unit-removalinstallation) ) If the symptom/indication goes away, replace the original audio-navigation unit

Audio disc skips (without navigation)

Special tools required

  1. Diagnostic CD 07AAZ-SDBA100
  2. Skip test CD 07AAZ-SDBA200
  3. Skip test CD 07AAZ-SDBA300

Note. Check the vehicle battery condition first (see BATTERY TEST ) Check the connectors for poor connections or loose terminals Disc labels should not be used in the audio unit They may jam and damage the player mechanism

  1. Confirm the vehicles tires are properly inflated
  2. Check the client's disc for scratches and fingerprints NOTE: The following test should be done with the audio system bass and treble set to the client's listening settings When comparing to known-good vehicles, do the comparison on the same model and trim level
  3. Test-drive the vehicle to identify when the client's disc skips The audio diagnostic CD (T/N 07AAZ-SDBA100) can be used if the client's CD is not available, use tracks 10-12 Does the disc skip? YES -Go to step 4 NO -Operation is normal
  4. Compare the client's CD that skips to a known-good vehicle under the same conditions Does the disc skip in the known-good vehicle under the same conditions? YES -The disc player operation is normal, the problem is with the client's disc NO -Go to step 5 NOTE: Do the following test with vehicle parked and the engine running
  5. Insert the diagnostic skip test CD (T/N 07AAZ-SDBA300) Play tracks 2-11, and note on which track number(s) the disc starts skipping Do the same test on a known-good vehicle Does the disc skip on the same track(s) as the known-good vehicle? YES -Operation is normal NO -Go to step 6
  6. Insert the diagnostic skip test CD (T/N 07AAZ-SDBA200) Play tracks 7-11 and tracks 13-15, and note on which track number(s) the disc starts skipping Do the same test on a known-good vehicle Does the disc skip on the same track number(s) as the known-good vehicle? YES -Operation is normal NO -Substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ) If the symptom/indication goes away, replace the original audio unit

Audio unit button does not work (with navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ) Check the connectors for poor connections or loose terminals In order to troubleshoot the main power switch, go to Power switch will not turn on (see AUDIO UNIT POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) (WITH NAVIGATION) )

  1. Operate all items in the appropriate switch list Switch list AM/FM, XM, TITLE, , DISC, HDD/AUX, Preset 1-6, CATEGORY+/-, SKIP, TUNE, SCAN, A SEL, AUDIO, VOL Do all the items in the appropriate switch list work properly? YES -Operation is normal NO -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/navigation-system/#navigation-system__audio-navigation-unit-removalinstallation) ) If the symptom/indication goes away, replace the audio-navigation unit If the symptom still present, substitute a known-good audio-navigation switch panel (see «AUDIO-NAVIGATION SWITCH PANEL REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ), and recheck. If the symptom/indication goes away, replace the audio-navigation switch panel

Audio unit button does not work (without navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ) Check the connectors for poor connections or loose terminals In order to troubleshoot the main power switch, go to Power switch will not turn on (see AUDIO UNIT POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) (WITHOUT NAVIGATION) )

  1. Operate all items in the appropriate switch list Switch list AM/FM, XM, CD, AUX, TITLE, CLOCK, Preset 1-6, CATEGORY+/-, SKIP, SCAN, A SEL, RETURN, SET UP, , SEL, VOL Do all the items in the appropriate switch list work properly? YES -Operation is normal NO -Substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ) If the symptom/indication goes away, replace the original audio unit

Audio unit disc indicator does not work (with navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ) Check the connectors for poor connections or loose terminals Discs with labels should not be used in the audio-navigation unit They may jam and damage the player mechanism

  1. Turn on the audio system
  2. Insert a known-good disc or press the EJECT button Is the DISC indicator (LED) indicated? YES -The audio-navigation unit is OK at this time Check for loose or poor connections at the audio-navigation unit and the audio-navigation switch panel NO -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/navigation-system/#navigation-system__audio-navigation-unit-removalinstallation) ), and recheck If the symptom/indication goes away, replace the original audio-navigation unit

Audio unit disc indicator does not work (without navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ) Check the connectors for poor connections or loose terminals Discs with labels should not be used in the audio unit They may jam and damage the player mechanism

  1. Turn on the audio system
  2. Insert a known-good disc or press the EJECT button Is the DISC indicator (LED) indicated? YES -The audio unit is OK at this time Check for loose or poor connections at the audio unit and the audio panel NO -Substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ), and recheck If the symptom/indication goes away, replace the original audio unit

USB device does not function (with navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ) Check the connectors for poor connections or loose terminals Make sure you have the client's USB device to use for testing Check the USB device requirement: Mass-storage class ready digital audio player with USB 2.0 port More than 256 MB of RAM Support MP3, WMA, and AAC (encoded with the iTunes) files, DRM files are not supported Not all players and player functions work with the USB jack Please see the owner's manual for more information Always test the clients USB device in a known-good vehicle of the same year and trim (if possible) Technologies change and are updated frequently which may result in that USB devices may work in newer vehicles, but not in older vehicles of the same model. If UNSUPPORTED appears on the display, the vehicle is OK, there is a software problem with the USB device.

  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  2. Turn on the audio system.
  3. Press the HDD/AUX button, and check if it changes to USB mode NOTE: Do not connect the USB device. Is USB NO DATA displayed in the audio display? YES -Go to step 4 NO - Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/navigation-system/#navigation-system__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit.
  4. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  5. Connect the client's USB device to a known-good vehicle (same year/trim) that is equipped with a USB adapter, and check the USB device operation. Is the USB device working properly in the known-good vehicle? YES -Go to step 6. NO -If the audio display displays UNSUPPORTED or MEDIA ERROR, the USB device may not be supported or is defective. If the audio display displays USB NO MUSIC, the USB device may have no music files or wrong type music files are on the device. See the Owner's Manual for details on USB device requirements and approved file types.
  6. On the client's vehicle, connect the client's USB device to the USB port.
  7. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  8. Turn on the audio system.
  9. Check the USB device operation in the client's vehicle. Does the USB device work properly in the client's vehicle? YES -The system is OK at this time. Inspect the connectors of the USB device, USB port and USB adapter for wear. NO -Check the navigation system error code (see «HOW TO CHECK ERROR HISTORY»(/acura/tl/iv-2008-2011/remont/navigation-system/#navigation-system__how-to-check-error-history) ).

USB device does not function (without navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ) Check the connectors for poor connections or loose terminals Make sure you have the client's USB device to use for testing Check the USB device requirement: Mass-storage class ready digital audio player with USB 2.0 port More than 256 MB of RAM Support MP3, WMA, and AAC (encoded with the iTunes) files, DRM files are not supported Not all players and player functions work with the USB jack Please see the owner's manual for more information Always test the clients USB device in a known-good vehicle of the same year and trim (if possible) Technologies change and are updated frequently which may result in that USB devices may work in newer vehicles, but not in older vehicles of the same model. If UNSUPPORTED appears on the display, the vehicle is OK, there is a software problem with the USB device.

Scheme 149

Scheme 149: USB device does not function (without navigation)

Scheme 150

Scheme 150

Scheme 151

Scheme 151

Scheme 152

Scheme 152

Scheme 153

Scheme 153

Scheme 154

Scheme 154

Scheme 155

Scheme 155

Scheme 156

Scheme 156

Scheme 157

Scheme 157

Scheme 158

Scheme 158
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  2. Turn on the audio system.
  3. Press the HDD/AUX button, and check if it changes to USB mode NOTE: Do not connect the USB device. Is USB NO DATA displayed in the audio display? YES -Go to step 4 NO - Go to step 16
  4. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  5. Connect the client's USB device to a known-good vehicle (same year/trim) that is equipped with a USB adapter, and check the USB device operation. Is the USB device working properly in the known-good vehicle? YES -Go to step 6 NO -If the audio display displays UNSUPPORTED or MEDIA ERROR, the USB device may not be unsupported or is defective. If the audio display displays USB NO MUSIC, the USB device may have no music files or wrong type music files are on the device. See the Owner's Manual for details on USB device requirements and approved file types.
  6. On the client's vehicle, connect the client's USB device to the USB port.
  7. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  8. Turn on the audio system.
  9. Check the USB device operation in the client's vehicle. Does the USB device work properly in the client's vehicle? YES -The system is OK at this time. Inspect the connectors of the USB device, USB port and USB adapter for wear. NO -Go to step 10
  10. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  11. On the client's vehicle, remove the USB device.
  12. Disconnect USB adapter unit connector B (5P)
  13. Check for continuity between USB adapter control unit connector B (5P) and the USB port 5P connector according to the table below. USB ADAPTER UNIT CONNECTOR REFERENCE CHART USB adapter unit connector USB jack B1 1 B2 2 B3 3 B4 4 B5 5 Is there continuity? YES -Replace the USB adapter unit (see «USB ADAPTER CONTROL UNIT REPLACEMENT»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ) NO -Go to step 14
  14. Disconnect the USB adapter 5P connector.
  15. Check for continuity between the USB adapter 5P connector and the USB port 5P connector according to the table below. USB ADAPTER UNIT CONNECTOR REFERENCE CHART USB adapter unit connector USB jack B1 1 B2 2 B3 3 B4 4 B5 5 Is there continuity? YES -There is an open in the wire(s) between the USB adapter control unit and the USB adapter. NO -Replace the affected shielded harness Replace the USB adapter unit (see «USB ADAPTER CONTROL UNIT REPLACEMENT»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ), then recheck.
  16. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  17. Measure the voltage between USB adapter control unit connector A (14P) terminal No. 1 and body ground. Is there battery voltage? YES -Go to step 19 NO -Go to step 18
  18. Measure the voltage between audio unit connector C (14P) terminal No. 1 and body ground. Is there battery voltage? YES -Repair an open or high resistance in the wire between the USB adapter control unit connector A (14P) terminal No. 1 and audio unit connector C (14P) terminal No. 1. NO - Replace the audio unit. (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ).
  19. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  20. Measure the voltage between USB adapter unit connector A (14P) terminal No 11 and body ground. Is there less than 0.2 V? YES -Go to step 21 NO -Repair an open or high resistance in the wire between USB adapter control unit connector A (14P) terminal No. 11 and audio unit connector C (14P) terminal No. 11.
  21. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  22. Disconnect these items: Audio unit connector C (14P) USB adapter control unit connector A (14P) XM receiver connector A (14P)
  23. Check for continuity between USB adapter control unit connector A (14P) terminal No. 2 and body ground. Is there continuity? YES Repair a short to body ground in the wire between USB adapter control unit connector A (14P) terminal No. 2 and audio unit connector C (14P) terminal No. 2. NO -Go to step 24
  24. Check for continuity between audio unit connector C (14P) terminal No. 2 and USB adapter control unit connector A (14P) terminal No. 2. Is there continuity? YES -Go to step 25 NO -Repair an open in the wire between audio unit connector C (14P) terminal No. 2 and USB adapter control unit connector A (14P) terminal No. 2
  25. Check for continuity between USB adapter control unit connector A (14P) and audio unit connector C (14P) according to the table below. USB ADAPTER UNIT CONNECTOR REFERENCE CHART USB adapter control unit connector Audio unit connector Wire color A9 C9 PNK A10 C10 BLU Is there continuity? YES -Go to step 26 NO -There is an open in the wire(s) between the audio unit and the USB adapter control unit. Replace the affected shielded harness.
  26. Disconnect the HandsFreeLink control unit 28P connector.
  27. Check for continuity between body ground and audio unit connector C (14P) according to the table below. USB ADAPTER UNIT CONNECTOR REFERENCE CHART Audio unit connector Wire color C9 PNK C10 BLU Is there continuity? YES -There is a short to body ground in the wire(s) between the audio unit and the USB adapter control unit. Replace the affected shielded harness. NO -Go to step 28
  28. Check for continuity between the terminals of audio unit connector C (14P) according to the table below TERMINAL REFERENCE CHART From terminal To terminals C3 (GRY) C9 (PNK), C10 (BLU) C9 (PNK) C10 (BLU) Is there continuity between any of the terminals? YES -There is a short in the wires between the USB adapter control unit and the audio unit. Replace the affected shielded harness. NO -Substitute a known-good USB adapter control unit, (see «USB ADAPTER CONTROL UNIT REPLACEMENT»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ), and recheck. If the symptom/indication goes away, replace the original USB adapter control unit. If the symptom/indication is still present, Replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ).

USB input sound is low or cannot be heard (with navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ) Check the connectors for poor connections or loose terminals Not all players and player functions work with the USB jack Please see the owner's manual for more information Always test the clients USB device in a known-good vehicle of the same year and trim (if possible) Technologies change and are updated frequently which may result in that USB devices may work in newer vehicles, but not in older vehicles of the same model.

  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  2. Do the speaker check mode with the self-diagnostic mode (see «SPEAKER CHECK MODE»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__speaker-check-mode) ) Do all speakers make a sound? YES -Go to step 3 NO -Go to «No Sound Is Heard From The Speaker(S) (Display Is Normal) (With Navigation)»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__no-sound-is-heard-from-the)
  3. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
  4. On the client's vehicle, connect the client's USB device to the USB adapter
  5. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  6. Turn on the audio system
  7. Press the HDD/AUX button until USB appears on the audio display
  8. Check if the USB device can be operated with the audio-navigation unit (Folders or Files UP/DOWN, etc.) Can you operate the USB device, but there is no sound heard? YES -Go to step 9 NO -If the sound is normal, the USB device is OK at this time If the USB device cannot be operated, go to «USB device does not function (with navigation)»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__usb-device-does-not-function-with)
  9. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
  10. Connect the client's USB device to a known-good vehicle (same year/trim) that is equipped with a USB adapter, and check the USB device operation Is the USB device working properly in the known-good vehicle? YES -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/navigation-system/#navigation-system__audio-navigation-unit-removalinstallation) ) NO -USB device is faulty or not compatible Also check the USB cable and USB adapter connector condition

USB input sound is low or cannot be heard (without navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ) Check the connectors for poor connections or loose terminals Not all players and player functions work with the USB adapter Please see the owner's manual for more information

Scheme 159

Scheme 159

Scheme 160

Scheme 160

Scheme 161

Scheme 161

Scheme 162

Scheme 162

Scheme 163

Scheme 163
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  2. Do the speaker check mode with the self-diagnostic mode (see «SPEAKER CHECK MODE»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__speaker-check-mode) ) Do all speakers make a sound? YES -Go to step 3 NO -Go to «NO SOUND IS HEARD FROM THE SPEAKER(S) (DISPLAY IS NORMAL) (WITHOUT NAVIGATION)»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__no-sound-is-heard-from-the)
  3. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
  4. On the client's vehicle, connect the client's USB device to the USB adapter
  5. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  6. Turn on the audio system
  7. Press the AUX button until USB appears on the audio display
  8. Check if the USB device can be operated with the audio-navigation unit (Folders or Files UP/DOWN, etc.) Can you operate the USB device, but there is no sound heard? YES -Go to step 9 NO -If the sound is normal, the USB device is OK at this time If the USB device cannot be operated, go to «USB DEVICE DOES NOT FUNCTION (WITHOUT NAVIGATION)»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__usb-device-does-not-function-without)
  9. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
  10. Connect the client's USB device to a known-good vehicle (same year/trim) that is equipped with a USB adapter, and check the USB device operation Is the USB device working properly in the known-good vehicle? YES -Go to step 11 NO -USB device is faulty Also check the USB cable and USB adapter connector condition
  11. Return to the client's vehicle
  12. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  13. Turn on the audio unit, and check for sound in each mode (XM and Bluetooth audio) Is the sound normal? YES -Go to step 14 NO -Go to XM or «HFL SYSTEM TROUBLESHOOTING»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#hands-free-link-system__hfl-system-troubleshooting) .
  14. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
  15. Measure the voltage between USB adapter control unit connector A (14P) terminal No. 1 and body ground. Is there battery voltage? YES -Go to step 17 NO -Go to step 16
  16. Measure the voltage between audio unit connector C (14P) terminal No. 1 and body ground. Is there battery voltage? YES -Repair an open or high resistance in the wire between the USB adapter control unit connector A (14P) terminal No. 1 and audio unit connector C (14P) terminal No. 1. NO -Replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) )
  17. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  18. Measure the voltage between USB adapter control unit connector A (14P) terminal No. 11 and body ground. Is there less than 0.2 V? YES -Go to step 19 NO -Repair an open or high resistance in the wire between USB adapter control unit connector A (14P) terminal No. 11 and audio unit connector C (14P) terminal No. 11.
  19. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  20. Disconnect these items: Audio unit connector C (14P) USB adapter control unit connector A (14P) XM receiver connector A (14P)
  21. Check for continuity between USB adapter control unit connector A (14P) terminal No. 2 and body ground. Is there continuity? YES -Repair a short to body ground in the wire between USB adapter control unit connector A (14P) terminal No. 2 and audio unit connector C (14P) terminal No. 2. NO -Go to step 22
  22. Check for continuity between audio unit connector C (14P) terminal No. 2 and USB adapter control unit connector A (14P) terminal No. 2. Is there continuity? YES -Go to step 23 NO -Repair an open in the wire between audio unit connector C (14P) terminal No. 2 and USB adapter control unit connector A (14P) terminal No. 2.
  23. Check for continuity between audio unit connector C (14P) and the USB adapter unit connector A14P according to the table USB ADAPTER UNIT CONNECTOR REFERENCE CHART Audio unit connector USB adapter unit connector Wire color C5 A5 GRN C6 A6 BLK C13 A13 WHT C14 A14 RED Is there continuity? YES -Substitute a known-good USB adapter unit (see «USB ADAPTER UNIT REPLACEMENT»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ) then reconnect all of the connectors, and recheck If the symptom/indication goes away, replace the original USB adapter unit. If the symptom/indication is still present, replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ) NO -There is an open in the wire(s) between the audio unit and the USB adapter unit. Replace the affected shielded harness

Error code: XM NO SIGNAL or XM LOADING is displayed (with navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ) Check the connectors for poor connection or loose terminals Check for other error codes (see ERROR CODES , and check the XM Antenna Signal Reception Level (see XM SIGNAL RECEPTION LEVEL INDICATION MODE ).

  1. Park the vehicle outside with a clear view of the southern horizon
  2. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  3. Check for other XM error codes (see XM error codes under «ERROR CODES»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__error-codes) ). Are there other XM error codes displayed? YES -Go to «ERROR CODES»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__error-codes) . NO -Go to 4
  4. Turn on the audio system, and press the XM button to select the XM radio. Does the XM radio receive a signal? YES -Reception interference operation is normal NO -Go to 5
  5. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
  6. Check the XM antenna 2P connector and AcuraLink control unit (XM receiver) connector B (2P) Are the connectors connected? YES -Go to step 7 NO -Reconnect the XM antenna 2P connector and AcuraLink control unit (XM receiver) connector B (2P), and recheck XM radio operation. If the signal is restored, the system is OK. If the signal is not restored, go to step 7.
  7. Substitute a known-good XM antenna (see «XM Antenna Replacement»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ). Does the XM radio receive a signal? YES -USA models: Substitute a known-good XM antenna lead. If the AcuraLink control unit (XM receiver) receives a signal, replace the original XM antenna lead. If the AcuraLink control unit (XM receiver) does not receive a signal, replace the AcuraLink control unit (XM receiver) (see «AcuraLink Control Unit (XM Receiver) Removal/Installation»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ). NO -Canada models: Substitute a known-good XM antenna lead. If the XM receiver receives signal, replace the original XM antenna lead. If the XM receiver does not receive signal, replace the XM receiver (see «XM Receiver Removal/Installation»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ).

Error code: XM NO SIGNAL or XM LOADING is displayed (without navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ) Check the connectors for poor connection or loose terminals Check for other error codes (see ERROR CODES , and check the XM Antenna Signal Reception Level (see XM SIGNAL RECEPTION LEVEL INDICATION MODE ).

  1. Park the vehicle outside with a clear view of the southern horizon
  2. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  3. Check for other XM error codes (see XM error codes under «ERROR CODES»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__error-codes) ). Are there other XM error codes displayed? YES -Go to «ERROR CODES»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__error-codes) . NO -Go to 4
  4. Turn on the audio unit, and select XM radio. Does the XM radio receive a signal? YES -Reception interference operation is normal NO -Go to 5
  5. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
  6. Check the XM antenna 2P connector and AcuraLink control unit (XM receiver) connector B (2P) Are the connectors connected? YES -Go to step 7 NO -Reconnect the XM antenna 2P connector and XM receiver connector B (2P), and recheck the XM radio operation. If the signal is restored, the system is OK. If the signal is not restored, go to step 7.
  7. Substitute a known-good XM antenna (see «XM Antenna Replacement»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ). Does the XM radio receive a signal? YES -Replace original XM antenna (see «XM Antenna Replacement»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ). NO -Substitute a known-good XM antenna lead. If the XM receiver receives signal, replace the original XM antenna lead. If the XM receiver does not receive a signal, (see «XM Receiver Removal/Installation»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ) Check the connectors for poor connection or loose terminals If you replace the AcuraLink control unit (XM receiver), the AcuraLink must be reactivated by Acura Client Services. Check for other error codes (see ERROR CODES , and check the XM Antenna Signal Reception Level (see XM SIGNAL RECEPTION LEVEL INDICATION MODE ).

  1. Check the connector at the AcuraLink control unit (XM receiver) Is the connector connected? YES -Go to step 2 NO -Reconnect the connector(s) If the error message does not go away, go to step 2
  2. Check the XM antenna 2P connector. Is the connector connected? YES -Go to step 3 NO -Reconnect the connector(s) If the error message does not go away, go to step 4
  3. Check for other XM error codes (see XM error codes under «ERROR CODES»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__error-codes) ). Are there other XM error codes displayed? YES -Go to «ERROR CODES»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__error-codes) . NO -Go to 4
  4. Substitute a known-good XM antenna (see «XM ANTENNA REPLACEMENT»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ) Is the error message gone? YES -Replace the original XM antenna (see «XM ANTENNA REPLACEMENT»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ) NO -Go to step 5
  5. Substitute a known-good AcuraLink control unit (XM receiver) (see «ACURALINK CONTROL UNIT (XM RECEIVER) REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ) Is the error message gone? YES -Update the AcuraLink control unit (see «ACURALINK CONTROL UNIT UPDATE»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#acuralink) ) if it does not have the latest software, then recheck If the software is the latest, substitute a known-good XM antenna lead, and recheck If the AcuraLink control unit (XM receiver) receivers a signal, replace the original XM antenna lead If the symptom/indication is still present, replace the AcuraLink control unit (XM receiver) (see «ACURALINK CONTROL UNIT (XM RECEIVER) REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ). NO -Replace the XM antenna lead.

Note. Check the vehicle battery condition first (see BATTERY TEST ) Check the connectors for poor connection or loose terminals Check for other error codes (see ERROR CODES , and check the XM Antenna Signal Reception Level (see XM SIGNAL RECEPTION LEVEL INDICATION MODE ).

  1. Check the connector at the XM receiver Is the connector connected? YES -Go to step 2 NO -Reconnect the connector(s) If the error message does not go away, go to step 2
  2. Check the XM antenna 2P connector. Is the connector connected? YES -Go to step 3 NO -Reconnect the connector(s) If the error message does not go away, go to step 4
  3. Check for other XM error codes (see XM error codes under «ERROR CODES»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__error-codes) ). Are there other XM error codes displayed? YES -Go to «ERROR CODES»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__error-codes) . NO -Go to 4
  4. Substitute a known-good XM antenna (see «XM ANTENNA REPLACEMENT»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ) Is the error message gone? YES -Replace the original XM antenna (see «XM ANTENNA REPLACEMENT»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ) NO -Go to step 5
  5. Substitute a known-good AcuraLink control unit (XM receiver) (see «ACURALINK CONTROL UNIT (XM RECEIVER) REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ) Is the error message gone? YES -Substitute a known-good XM antenna lead. If the XM receiver receives signal, replace the original XM antenna lead. If the XM receiver does not receive a signal, (see «XM Receiver Removal/Installation»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ). NO -Replace original XM antenna (see «XM Antenna Replacement»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ).

XM radio display is blank and no station information is displayed (USA models with navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ) Check the connectors for poor connections or loose terminals If you replace the XM receiver, the AcuraLink must be reactivated by Acura Client Services

Scheme 164

Scheme 164: XM radio display is blank and no station information is displayed (USA models with navigation)

Scheme 165

Scheme 165

Scheme 166

Scheme 166

Scheme 167

Scheme 167

Scheme 168

Scheme 168

Scheme 169

Scheme 169
  1. Measure the voltage between AcuraLink control unit (XM receiver) connector A (32P) terminal No 1 and body ground Is there battery voltage? YES -Go to step 2 NO -Repair open in the wire between No 15 (10 A) fuse in the under-hood fuse/relay box and AcuraLink control unit (XM receiver) connector A (32P) terminal No 1
  2. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  3. Measure the voltage between body ground and AcuraLink control unit (XM receiver) connector A (32P) terminals No. 2 and No. 3 individually. Is there battery voltage? YES -Go to step 4 NO -Repair open in the wire between the No 18 (7.5 A) fuse in the driver's under-dash fuse/relay box and AcuraLink control unit (XM receiver) connector A (32P) terminal No 3
  4. Measure the voltage between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 28 and body ground. Is there less than 0.2 V? YES -Go to step 5 NO -Repair open or high resistance in the wire between AcuraLink control unit (XM receiver) connector A (32P) terminal No 28 and body ground (G501) (see «AUDIO WIRE HARNESS»(/acura/tl/iv-2008-2011/remont/body-electrical/#connectors-and-harnesses__audio-wire-harness) )
  5. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  6. Disconnect these items Audio-navigation unit connector C (14P) HandsFreeLink control unit 28P connector AcuraLink control unit (XM receiver) connector A (14P) Navigation display unit 32P connector
  7. Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) and audio-navigation unit connector C(14P) according to the table AUDIO-NAVIGATION UNIT CONNECTOR REFERENCE CHART AcuraLink control unit (XM receiver) connector Audio-navigation unit connector Wire color A30 C9 PNK A31 C10 BLU Is there continuity? YES -Go to step 8 NO -There is an open in the wire(s) between the audio-navigation unit and the AcuraLink control unit (XM receiver) Replace the affected shielded harness
  8. Check for continuity between body ground and AcuraLink control unit (XM receiver) connector A (32P) according to the table below. AUDIO-NAVIGATION UNIT CONNECTOR REFERENCE CHART AcuraLink control unit (XM receiver) connector Wire color A30 PNK A31 BLU Is there continuity? YES -There is a short to body ground in the wire(s) between the audio-navigation unit and the AcuraLink control unit (XM receiver) Replace the affected shielded harness NO -Go to step 9
  9. Check for continuity between the terminals of AcuraLink control unit (XM receiver) connector A (32P) according to the table TERMINAL REFERENCE CHART From terminal To terminals A29 (GRY) A30 (PNK), A31 (BLU) A30 (PNK) A31 (BLU) Is there continuity between any of the terminals? YES -There is a short in the wires between the audio-navigation unit and the AcuraLink control unit (XM receiver) Replace the affected shielded harness NO -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/navigation-system/#navigation-system__audio-navigation-unit-removalinstallation) ), and recheck If the symptom/indication goes away, replace the original audio-navigation unit If the symptom is still present, substitute a known-good AcuraLink control unit or update the AcuraLink control unit (see «ACURALINK CONTROL UNIT UPDATE»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#acuralink) ), if it does not have the latest software, then recheck If the symptom/indication goes away after the substitution, replace the original AcuraLink control unit (see «ACURALINK CONTROL UNIT (XM RECEIVER) REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ) If the symptom/indication goes away after the update, troubleshooting is complete If the symptom/indication is still present, go to step 1 and recheck

XM radio display is blank and no station information is displayed (Canada models with navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ) Check the connectors for poor connections or loose terminals

Scheme 170

Scheme 170: XM radio display is blank and no station information is displayed (Canada models with navigation)

Scheme 171

Scheme 171

Scheme 172

Scheme 172

Scheme 173

Scheme 173

Scheme 174

Scheme 174

Scheme 175

Scheme 175

Scheme 176

Scheme 176
  1. Measure the voltage between XM receiver connector A (14P) terminal No 1 and body ground Is there battery voltage? YES -Go to step 3 NO -Go to step 2
  2. Measure the voltage between audio-navigation unit connector C (14P) terminal No. 1 and body ground. Is there battery voltage? YES -Repair an open or high resistance in the wire between the XM receiver connector A (14P) terminal No. 1 and audio-navigation unit connector C (14P) terminal No. 1. NO -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/navigation-system/#navigation-system__audio-navigation-unit-removalinstallation) )
  3. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  4. Measure the voltage between XM receiver connector A (14P) terminal No 11 and body ground Is there less than 0.2 V? YES -Go to step 7 NO -Repair open or high resistance in the wire between XM receiver connector A (14P) terminal No 11 and audio-navigation unit connector C (14P) terminal No 11
  5. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
  6. Disconnect audio-navigation unit connector C (14P) and XM receiver connector A (14P).
  7. Check for continuity between XM receiver connector A (14P) terminal No. 2 and body ground. Is there continuity? YES -Repair a short to body ground in the wire between XM receiver connector A (14P) terminal No. 2 and audio-navigation unit connector C (14P) terminal No. 2. NO -Go to step 8
  8. Check for continuity between audio-navigation unit connector C (14P) terminal No. 2 and XM receiver connector A (14P) terminal No. 2. Is there continuity? YES -Go to step 9 NO -Repair an open in the wire between audio-navigation unit connector C (14P) terminal No. 2 and XM receiver connector A (14P) terminal No. 2
  9. Check for continuity between XM receiver connector A (14P) and audio-navigation unit connector C (14P) according to the table below XM receiver connector Audio-navigation unit connector Wire color A9 C9 PNK A10 C10 BLU Is there continuity? YES -Go to step 10 NO -There is an open in the wire(s) between the audio-navigation unit and the XM receiver. Replace the affected shielded harness.
  10. Disconnect the HandsFreeLink control unit 28P connector.
  11. Check for continuity between body ground and audio-navigation unit connector C (14P) according to the table below. Audio-navigation unit connector Wire color C9 PNK C10 BLU Is there continuity? YES -There is a short to body ground in the wire(s) between the audio-navigation unit and the XM receiver. Replace the affected shielded harness. NO -Go to step 12
  12. Check for continuity between the terminals of XM receiver connector A (14P) according to the table below. From terminal To terminals C3 (GRY) C9 (PNK), C10 (BLU) C9 (PNK) C10 (BLU) Is there continuity between any of the terminals? YES -There is a short in the wires between the audio-navigation unit and the XM receiver Replace the affected shielded harness NO -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/navigation-system/#navigation-system__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit. If the symptom/indication is still present, replace the XM receiver (see «XM RECEIVER REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ).

XM radio display is blank and no station information is displayed (without navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ) Check the connectors for poor connections or loose terminals

Scheme 177

Scheme 177

Scheme 178

Scheme 178
  1. Measure the voltage between XM receiver connector A (14P) terminal No 1 and body ground Is there battery voltage? YES -Go to step 3 NO -Go to step 2
  2. Measure the voltage between audio unit connector C (14P) terminal No. 1 and body ground. Is there battery voltage? YES -Repair an open or high resistance in the wire between the XM receiver connector A (14P) terminal No. 1 and audio unit connector C (14P) terminal No. 1. NO -Replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ).
  3. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  4. Measure the voltage between XM receiver connector A (14P) terminal No 11 and body ground Is there less than 0.2 V? YES -Go to step 7 NO -Repair open or high resistance in the wire between XM receiver connector A (14P) terminal No 11 and audio-navigation unit connector C (14P) terminal No 11
  5. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
  6. Disconnect these items: Audio unit connector C (14P) USB adapter control unit connector A (14P) XM receiver connector A (14P)
  7. Check for continuity between XM receiver connector A (14P) terminal No. 2 and body ground. Is there continuity? YES -Repair a short to body ground in the wire between XM receiver connector A (14P) terminal No. 2 and audio-navigation unit connector C (14P) terminal No. 2. NO -Go to step 8
  8. Check for continuity between audio unit connector C (14P) terminal No. 2 and XM receiver connector A (14P) terminal No. 2. Is there continuity? YES -Go to step 9 NO -Repair an open in the wire between audio unit connector C (14P) terminal No. 2 and XM receiver connector A (14P) terminal No. 2
  9. Check for continuity between XM receiver connector A (14P) and audio unit connector C (14P) according to the table below. XM receiver connector Audio-unit connector Wire color A9 C9 PNK A10 C10 BLU Is there continuity? YES -Go to step 10 NO -There is an open in the wire(s) between the audio unit and the XM receiver. Replace the affected shielded harness.
  10. Disconnect the HandsFreeLink control unit 28P connector.
  11. Check for continuity between body ground and audio-navigation unit connector C (14P) according to the table below. Audio unit connector Wire color C9 PNK C10 BLU Is there continuity? YES -There is a short to body ground in the wire(s) between the audio unit and the XM receiver. Replace the affected shielded harness. NO -Go to step 12
  12. Check for continuity between the terminals of XM receiver connector A (14P) according to the table below. From terminal To terminals C3 (GRY) C9 (PNK), C10 (BLU) C9 (PNK) C10 (BLU) Is there continuity between any of the terminals? YES -There is a short in the wires between the audio unit and the XM receiver Replace the affected shielded harness NO -Substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ), and recheck. If the symptom/indication goes away, replace the original audio unit. If the symptom/indication is still present, replace the XM receiver (see «XM RECEIVER REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ).

XM radio preset memory is lost (USA models with navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ) Make sure the remotes are linked Check the connectors for poor connections or loose terminals If you replace the AcuraLink control unit (XM receiver), the AcuraLink must be reactivated by Acura Client Services If you can only tune to channel 000, 001, 174, and 247, make sure the audio-navigation unit is set to channel mode (see owners manual), if it is set to channel mode, call XM Satellite Radio client support, and check the account activation status

Scheme 179

Scheme 179: XM radio preset memory is lost (USA models with navigation)

Scheme 180

Scheme 180

Scheme 181

Scheme 181
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  2. Turn on the audio system and set each of the XM radio channel preset buttons Do each of the XM radio channel preset buttons set properly? YES -Go to step 3 NO -Go to step 5
  3. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode for 1 minute, then back to ON (II), or the ON mode
  4. Test all of the XM radio channel preset buttons for proper recall operation Do the preset buttons recall the set radio stations? YES -System is normal at this time Check connections at the audio-navigation unit NO -Go to step 5
  5. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
  6. Measure the voltage between AcuraLink control unit (XM receiver) connector A (32P) terminal No 1 and body ground Is there battery voltage? YES -Go to step 7 NO -Repair open in the wire between the No 15 (10 A) fuse in the under-hood fuse/relay box and AcuraLink control unit (XM receiver) connector A (32P) terminal No 1
  7. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  8. Measure the voltage between AcuraLink control unit (XM receiver) connector A (32P) terminals No 2 and No 3 and body ground individually Is there battery voltage? YES -Go to step 9 NO -Repair open in the wire between the No. 12 (7.5 A) fuse in the driver's under-dash fuse/relay box and AcuraLink control unit (XM receiver) connector A (32P) terminal No 2, or repair an open in the wire between the No. 18 (7.5 A) fuse in the driver's under-dash fuse/relay box and AcuraLink control unit (XM receiver) connector A (32P) terminal No 3
  9. Measure the voltage between AcuraLink control unit (XM receiver) connector A (32P) terminal No 28 and body ground Is there less than 0.2 V? YES -Replace the AcuraLink control unit (XM receiver) (see «ACURALINK CONTROL UNIT (XM RECEIVER) REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ) NO -Repair open or high resistance in the wire between AcuraLink control unit (XM receiver) connector A (32P) terminal No 28 and body ground (G501) (see «AUDIO WIRE HARNESS»(/acura/tl/iv-2008-2011/remont/body-electrical/#connectors-and-harnesses__audio-wire-harness) )

XM radio preset memory is lost (Canada models with navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ) Make sure the remotes are linked Check the connectors for poor connections or loose terminals If you can only tune to channel 000, 001, 174, and 247, make sure the audio-navigation unit is set to channel mode (see owner's manual), if it is set to channel mode, call XM radio client support, and check the account activation status

Scheme 182

Scheme 182: XM radio preset memory is lost (Canada models with navigation)

Scheme 183

Scheme 183
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  2. Turn on the audio system, and set each of the XM radio channel preset buttons Do each of the XM radio channel preset buttons set properly? YES -Go to step 3 NO -Go to step 5
  3. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode for 1 minute, then back to ON (II), or the ON mode
  4. Test all of the XM radio channel preset buttons for proper recall operation Do the preset buttons recall the set radio stations? YES -Intermittent failure, the system is normal at this time Check connections at the audio-navigation unit NO -Go to step 5
  5. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
  6. Measure the voltage between XM receiver connector A (14P) terminal No 1 and body ground Is there battery voltage? YES -Go to step 8 NO -Go to step 7
  7. Measure the voltage between audio-navigation unit connector C (14P) terminal No. 1 and body ground. Is there battery voltage? YES -Repair an open or high resistance in the wire between the XM receiver connector A (14P) terminal No. 1 and audio-navigation unit connector C (14P) terminal No. 1 NO -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/navigation-system/#navigation-system__audio-navigation-unit-removalinstallation) )
  8. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  9. Measure the voltage between XM receiver connector A (14P) terminal No 11 and body ground Is there less than 0.2 V? YES -Replace the XM receiver (see «XM Receiver Removal/Installation»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ). NO -Repair open or high resistance in the wire between XM receiver connector A (14P) terminal No 11 and audio-navigation unit connector C (14P) terminal No 11

XM radio preset memory is lost (without navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ) Make sure the remotes are linked Check the connectors for poor connections or loose terminals If you can only tune to channel 000, 001, 174, and 247, make sure the audio unit is set to channel mode (see owner's manual), if it is set to channel mode, call XM radio client support, and check the account activation status

Scheme 184

Scheme 184
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  2. Turn on the audio system, and set each of the XM radio channel preset buttons Do each of the XM radio channel preset buttons set properly? YES -Go to step 3 NO -Go to step 5
  3. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode for 1 minute, then back to ON (II), or the ON mode
  4. Test all of the XM radio channel preset buttons for proper recall operation Do the preset buttons recall the set radio stations? YES -Intermittent failure, the system is normal at this time Check the connections at the audio unit NO -Go to step 5
  5. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
  6. Measure the voltage between XM receiver connector A (14P) terminal No 1 and body ground Is there battery voltage? YES -Go to step 8 NO -Go to step 7
  7. Measure the voltage between audio unit connector C (14P) terminal No. 1 and body ground. Is there battery voltage? YES -Repair an open or high resistance in the wire between the XM receiver connector A (14P) terminal No. 1 and audio unit connector C (14P) terminal No. 1. NO -Replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ).
  8. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  9. Measure the voltage between XM receiver connector A (14P) terminal No 11 and body ground Is there less than 0.2 V? YES -Replace the XM receiver (see «XM Receiver Removal/Installation»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ). NO -Repair open or high resistance in the wire between audio unit connector C (14P) terminal No 11 and XM receiver connector A (14P) terminal No 11

Poor or no sound with XM radio (Audio unit does display XM channels) (with navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ) Check the connector for poor connections or loose terminals Check the radio reception in an open area Poor reception/interference can be caused by tall buildings, mountains, or high-voltage power lines are nearby If you can only tune to channel 000, 001, 174, and 247, make sure the audio-navigation unit is set to channel mode (see owner's manual), if it is set to channel mode, call XM Satellite Radio client support, and check the account activation status If you replace the XM receiver, the AcuraLink must be reactivated by Acura Client Services

Scheme 185

Scheme 185: Poor or no sound with XM radio (Audio unit does display XM channels) (with navigation)

Scheme 186

Scheme 186

Scheme 187

Scheme 187
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  2. Turn on the audio system and select XM radio
  3. Check for an error message on the display Are there any messages displayed? YES -Go to error code list (see «ERROR CODES»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__error-codes) ) NO -Go to step 4
  4. Disconnect these items Audio-navigation unit connector C (14P) HandsFreeLink control unit 28P connector AcuraLink control unit (XM receiver) connector A (32P)
  5. Check for continuity between audio-navigation unit connector C (14P) and body ground according to the table Then check for continuity between the same terminals listed in the table and audio-navigation unit connector C (14P) terminal No 4 (the harness shield) AUDIO-NAVIGATION UNIT CONNECTOR REFERENCE CHART Audio-navigation unit connector Wire color C5 GRN C6 BLK C13 WHT C14 RED Is there continuity? YES -There is a short in the wires between the audio-navigation unit and the XM receiver Replace the affected shielded harness NO -Go to step 6
  6. Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) and audio-navigation unit connector C (14P) according to the table AUDIO-NAVIGATION UNIT CONNECTOR REFERENCE CHART Audio-navigation unit connector AcuraLink control unit (XM receiver) connector Wire color C5 A13 GRN C6 A15 BLK C13 A14 WHT C14 A16 RED Is there continuity? YES -Substitute a known-good AcuraLink control unit (XM receiver) (see «ACURALINK CONTROL UNIT (XM RECEIVER) REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ), then reconnect all connectors, and recheck If the symptom/indication goes away, update the AcuraLink control unit (see «ACURALINK CONTROL UNIT UPDATE»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#acuralink) ) if it does not have the latest software, then recheck If the software is the latest, replace the AcuraLink control unit (XM receiver) If symptom/indication is still present, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/navigation-system/#navigation-system__audio-navigation-unit-removalinstallation) ) NO -There is an open in the wire(s) between the audio-navigation unit and the AcuraLink control unit (XM receiver) Replace the affected shielded harness

Poor or no sound with XM radio (Audio unit does display XM channels) (without navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ) Check the connector for poor connections or loose terminals Check the radio reception in an open area Poor reception/interference can be caused by tall buildings, mountains, or high-voltage power lines are nearby If you can only tune to channel 000 ,001, 174, and 247, make sure the audio unit is set to channel mode (see owners manual), if it is set to channel mode, call XM Satellite Radio client support, and check the account activation status

Scheme 188

Scheme 188

Scheme 189

Scheme 189
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  2. Turn on the audio system and select XM radio
  3. Check for an error message on the display Are there any messages displayed? YES -Go to error code list (see «ERROR CODES»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__error-codes) ) NO -Go to step 4
  4. Disconnect these items Audio unit connector C (14P) HandsFreeLink control unit 28P connector XM receiver connector A (14P) USB adapter unit connector A (14P)
  5. Check for continuity between audio unit connector C (14P) and body ground according to the table Then check for continuity between the same terminals listed in the table and audio unit connector C (14P) terminal No 4 (the harness shield) AUDIO UNIT CONNECTOR REFERENCE CHART Audio unit connector Wire color C5 GRN C6 BLK C13 WHT C14 RED Is there continuity? YES -There is a short in the wires between the audio unit and the XM receiver Replace the affected shielded harness NO -Go to step 6
  6. Check for continuity between XM receiver connector A(14P)and audio unit connector C (14P) according to the table AUDIO UNIT CONNECTOR REFERENCE CHART Audio unit connector XM receiver connector Wire color C5 A14 GRN C6 A6 BLK C13 A13 WHT C14 A5 RED Is there continuity? YES -Substitute a known-good XM receiver (see «ACURALINK CONTROL UNIT (XM RECEIVER) REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ), then reconnect all connectors, and recheck If the symptom/indication goes away, replace the original XM receiver If symptom/indication is still present, replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ) NO -There is an open in the wire(s) between the audio unit and the XM receiver Replace the affected shielded harness

Sound Quality Diagnosis

Special Tools Required

Diagnostic CD 07AAZ-SDBA100

Use the following tests to check sound quality

Note. Before beginning the following tests, write down the client's bass, treble, fader and balance settings, then set them to their center positions for the testing

Left/Right Channel ID

Do this test to confirm proper channel routing

  1. Insert the audio diagnostic CD (T/N 07AAZ-SDBA100) into the audio unit
  2. Play track No 1 (left, both, right channel ID) at a normal, or slightly higher than normal, volume level
  3. The voice should be audible only from the channel or channels when indicated If the channel ID is correct for each side, go to «PHASE TEST»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__phase-test) If the channel ID is not correct, check for Shorted speaker wire Faulty amplifier Faulty audio unit

Phase Test

Do this test to confirm proper speaker phasing

  1. Insert the audio diagnostic CD (T/N 07AAZ-SDBA100) into the audio unit
  2. Play track No 2 (phase) at a normal, or slightly higher than normal, volume level
  3. The voice should sound centered and focused when it is in-phase
  4. The voice should sound diffused, and have less bass when it is out of phase If the voice changes from m-phase to out of phase as indicated by the prompt, the phasing is correct Go to electrical noise test (see «ELECTRICAL NOISE TEST»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__electrical-noise-test) ) If the voice always sounds out of phase, phasing is not correct Check for Crossed speaker wire Faulty amplifier Faulty audio unit

Electrical Noise Test

Do this test to check for electrical noise being induced into the audio system

Note. Electrical noise may be caused by outside sources that cannot be handled by the audio system Make sure you remove any cell phones and/or turn off any aftermarket devices before beginning this test

  1. Insert the audio diagnostic CD (T/N 07AAZ-SDBA100) into the audio unit
  2. Play track No 4 (digital zero) at a normal, or slightly higher than normal, volume level
  3. Operate any electrical device that may create electrical noise in the audio system, including starting the engine
  4. Play track No 5 (near digital zero) at a normal, or slightly higher than normal, volume level
  5. Operate any electrical device that may create electrical noise in the audio system, including starting the engine
  6. Play track No 6 (SNR) at a normal, or slightly higher than normal, volume level
  7. Operate any electrical device that may create electrical noise in the audio system, including starting the engine If no abnormal noise is heard, go to the individual speaker test (see «ELECTRICAL NOISE TEST»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__electrical-noise-test) ) If the noise is present only during the SNR track, replace the audio unit If the noise is heard during the digital zero or near digital zero track, check for Poor ground at the audio unit, amplifier, engine, or battery cable Pinched or shorted speaker or amplifier wire Faulty amplifier Faulty audio unit Other faulty components causing excessive electrical noise (ignition coils, alternator, door lock actuators, etc.) Disconnect any suspect components, and then replay the tracks that were originally noisy If the noise is gone, check the component's circuit and the component

Individual Speaker Test

Do this test to identify a faulty speaker

  1. Insert the audio diagnostic CD (T/N 07AAZ-SDBA100) into the audio unit
  2. Play track No 30 (steady 300 Hz tone) at a normal, or slightly higher than normal, volume level
  3. Listen to each speaker for poor sound compared to the other channels Use the audio unit's fader and balance settings to help isolate the channel with the problem If the sound quality produced by a specific speaker is poor, substitute it with a known-good speaker If the poor sound quality continues, go to the sound balance test (see «SOUND BALANCE TEST»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__sound-balance-test) ) If the sound quality is OK, go to the sound balance test (see «SOUND BALANCE TEST»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__sound-balance-test) )

Sound Balance Test

Do this test to identify a faulty channel or speaker

  1. Insert the audio diagnostic CD (T/N 07AAZ-SDBA100) into the audio unit
  2. Confirm the bass and treble are set to the center positions
  3. Play track No 3 (pink noise) at a normal, or slightly higher than normal, volume level
  4. A static type sound should be heard through all speakers
  5. Insert the audio diagnostic CD (T/N 07AAZ-SDBA100) into the audio unit of a known-good vehicle
  6. Set the bass and treble to the center positions
  7. Play track No 3 (pink noise) all the same level as was played in step 3
  8. Compare the sounds made by the two vehicles If the sound does not have as much bass, check the subwoofer and circuit If the sound does not have enough hiss, check the tweeters and their circuits

Frequency Sweep

Do this test to find rattles or reverberations that may cause a perception of poor sound quality

  1. Insert the audio diagnostic CD (T/N 07AAZ-SDBA100) into the audio unit
  2. Play track No 13 (sweep from 500 Hz to 35 Hz) at a normal, or slightly higher than normal, volume level
  3. Listen to each speaker for poor sound quality or reverberations caused by specific frequencies Use the voice-over to estimate the frequency that causes the vibration Use the audio unit's fader and balance settings to help isolate the channel with the problem If vibrations or poor sound quality are heard, go to step 4 If no vibrations or poor sound quality are heard, go to sound judging (see «SOUND JUDGING»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__sound-judging) )
  4. Choose the appropriate track from No 14 to 25 (small range frequency sweep) or 26 to 53 (single frequencies) to recreate the frequency that caused the poor sound quality or vibration witnessed in step 3, this aids in diagnosis of the cause NOTE: When you get to the track that recreates the problem, select the repeat function on the audio unit, this will help you isolate the cause
  5. Replace or insulate the source of the vibration or, if the speaker is the source of the poor sound quality, replace it

Sound Judging

Do this test to compare overall sound quality, imaging, and dynamics between the client's vehicle and a known-good vehicle Only use a vehicle of the same model and trim level for this test

  1. In the client's vehicle, set the bass, treble, fader, and balance settings to the client's normal settings that were written down before beginning the test
  2. Insert the audio diagnostic CD (T/N 07AAZ-SDBA100) into the audio unit
  3. Play tracks No 7 to 12 (sound quality, midland, dynamics, and imaging demonstration tracks) at a normal, or slightly higher than normal, volume level Write down the volume setting being used
  4. Listen to areas of the track that stand out as being either very clear or poorer than other areas of the track
  5. In a known-good vehicle, insert the audio diagnostic CD (T/N 07AAZ-SDBA100) into the audio unit
  6. Play the tracks at the same volume level and the same bass, treble, balance, and fader settings as used in step 3 in the client's vehicle
  7. Listen to the same area of the track that stood out as being either very clear or poorer than other areas of the track
  8. Compare the client's vehicle's sound quality results the known-good vehicle's results If the sound quality in the client's vehicle is comparable to the sound quality in the known-good vehicle, then the client's vehicle is operating as designed If the sound quality is not comparable, check these items in order Loose or improperly installed speakers or other hardware that may create interference from the vibrations generated by the speakers Poor power or ground to the stereo amplifier Damaged speaker(s) Faulty amplifier Faulty audio unit

Seek Stop Test

Do this test to check the performance of the audio unit's AM and FM reception Refer to symptom troubleshooting audio sound weak or distorted, or no sound is heard from the speaker(s) (display is normal) with navigation (see NO SOUND IS HEARD FROM THE SPEAKER(S) (DISPLAY IS NORMAL) (WITH NAVIGATION) ), without navigation (see NO SOUND IS HEARD FROM THE SPEAKER(S) (DISPLAY IS NORMAL) (WITHOUT NAVIGATION) ) before continuing with this test

Note. Window tint, aftermarket theft-recovery devices and other aftermarket devices may affect reception Changes in cloud cover and other atmospheric conditions will affect the ability of the audio unit to receive radio signals

  1. Park the client's vehicle in an open area away from buildings or other obstructions
  2. Park a known-good vehicle (same year, model, and trim level) next to the client's vehicle, facing the same direction
  3. Start the engine in the client's vehicle, and turn on the radio
  4. 4 Set the FM receiver to 87.7 MHz
  5. Press the Seek + button, and record the first station that the audio unit locks onto
  6. Press the Seek + button repeatedly, and write down each station that the audio unit locks onto until the station recorded in step 5 is reached again
  7. Set the AM receiver to 530 kHz
  8. Press the Seek + button, and record the first station that the audio unit locks onto
  9. Press the Seek + button repeatedly, and write down each station that the audio unit locks onto until the station recorded in step 8 is reached again
  10. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
  11. Start the engine in the known-good vehicle, and then do steps 4 thru 10 on the known-good vehicle
  12. Compare the number of stations received in steps 6 and 9 in the client's vehicle with the number of stations received in the known-good vehicle If the number of stations received is the same, or within 10 %, the audio unit's tuner performance is OK The problem may be atmospheric conditions, multi-path interference, or other obstructions to the radio signal If the client's vehicle receives fewer stations by at least 10 %, go to step 2 of poor AM or FM radio reception or interference with navigation (see «SYMPTOM TROUBLESHOOTING»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ), without navigation (see «POOR AM OR FM RADIO RECEPTION OR INTERFERENCE (WITHOUT NAVIGATION)»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system__poor-am-or-fm-radio-reception) )

Without Navigation

SRS components are located in this area Review the SRS component locations (see COMPONENT LOCATION INDEX ), and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service

Note. Put on gloves to protect your hands Take care not to scratch the dashboard and related parts Lay a shop towel under the parts when working on them to protect the face panel from scratches or other damage Eject all the discs before removing the audio unit to prevent damaging the CD player's load mechanism If you are replacing the audio unit, write down the audio presets (if possible), then enter them into the new audio unit

Scheme 190

Scheme 190: Without Navigation

Scheme 191

Scheme 191
  1. Make sure you have the anti-theft codes for the audio system
  2. Remove the center dashboard trim (see «CENTER TRIM REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#dashboard) )
  3. Remove the dashboard center vent (see «DASHBOARD CENTER VENT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#dashboard) )
  4. Carefully remove the bolts, then pull the audio unit (A) out Bolt Specifications: 5 x 0.8 mm, 4.4 N.m (0.45 kgf m, 3.2 lbf ft
  5. Disconnect the connectors, and detach the clips (B)
  6. Remove the climate control switches (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/automatic-hvac-system/#climate-control-system) )
  7. Remove the bolts and stays (A) Bolt Specifications: 5 x 0.8 mm, 3.7 N.m (0.38 kgf m, 2.7 lbf ft
  8. Install the audio unit in the reverse order of removal, and note these items Make sure all the connectors and the antenna lead are secure Enter the anti-theft codes for the audio system
  9. Give the new anti-theft codes to the client if the audio unit is replaced

SRS components are located in this area Review the SRS component locations (see COMPONENT LOCATION INDEX ), and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service

Note. Put on gloves to protect your hands Take care not to scratch the dashboard and related parts Lay a shop towel under the parts when working on them to protect the face panel from scratches or other damage Eject all the discs before removing the audio-navigation unit to prevent damaging the CD/DVD player's load mechanism Discharge static electricity from your body before and during the work

Scheme 192

Scheme 192: With Navigation
  1. Remove the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/navigation-system/#navigation-system__audio-navigation-unit-removalinstallation) )
  2. Remove the interface dial (see «HFL-NAVIGATION MICROPHONE REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/navigation-system/#navigation-system) ) Do not touch the terminal connector (A) of the audio-navigation switch panel with your bare hands (If you have touched it, wipe it off thoroughly)
  3. Install the audio-navigation switch panel in the reverse order of removal

Note. Put on gloves to protect your hands Take care not to scratch the dashboard and related parts Lay a shop towel under the parts when working on them to protect the face panel from scratches or other damage

Scheme 193

Scheme 193: Without Navigation

Scheme 194

Scheme 194
  1. Remove the dashboard center vent (see «DASHBOARD CENTER VENT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#dashboard) )
  2. Carefully remove the screws from the audio-HVAC display unit (A)
  3. Pull out the audio-HVAC display unit Then disconnect the connector (A) from the audio-HVAC display unit
  4. Install the audio-HVAC display unit in the reverse order of removal

Scheme 195

Scheme 195: Stereo Amplifier Removal/Installation
  1. Remove the right trunk side trim panel (see «TRIM REMOVAL/INSTALLATION - TRUNK AREA»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-trunk-area) )
  2. Loosen the mounting bolts (A), then detach the clip (B) and pull out the stereo amplifier (C) Bolt Specifications: 6 x 1.0 mm, 9.4 N.m (0.95 kgf m, 6.9 lbf ft
  3. Disconnect the connectors from the stereo amplifier, and remove it
  4. Install the stereo amplifier in the reverse order of removal

SRS components are located in this area Review the SRS component locations (see COMPONENT LOCATION INDEX ), and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service

Scheme 196

Scheme 196: With AcuraLink
  1. Remove the center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/gauges-instrument-panels/#consoles__center-console-removalinstallation) ).
  2. Remove the HandsFreeLink control unit (see «HFL SWITCH TEST»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#hands-free-link-system) )
  3. Remove the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/navigation-system/#navigation-system__audio-navigation-unit-removalinstallation) )
  4. Remove the bolts (A), and loosen the bolt (B) Bolt Specifications: 6 x 1.0 mm, 9.4 N.m (0.95 kgf m, 6.9 lbf ft
  5. Pull the AcuraLink control unit (XM receiver) (C) out, then disconnect the connectors from the AcuraLink control unit (XM receiver), and detach the clips
  6. Install the AcuraLink control unit (XM receiver) in the reverse order of removal NOTE: If you replaced the AcuraLink control unit (XM receiver) make sure it has the latest software (see «ACURALINK CONTROL UNIT UPDATE»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#acuralink) )
  7. Call XM Satellite Radio to update the client's account with the new XM/HIP serial number Also call Acura Client Services to reactivate the AcuraLink

SRS components are located in this area Review the SRS component locations (see COMPONENT LOCATION INDEX ), and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service

Scheme 197

Scheme 197: Without AcuraLink
  1. Remove the center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/gauges-instrument-panels/#consoles__center-console-removalinstallation) )
  2. Remove the HandsFreeLink control unit (see «HFL SWITCH TEST»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#hands-free-link-system) )
  3. Remove the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ) If the vehicle is a Canada model with navigation, remove the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/navigation-system/#navigation-system__audio-navigation-unit-removalinstallation) )
  4. Remove the bolts (A), and loosen the bolt (B) Bolt Specifications: 6 x 1.0 mm, 9.4 N.m (0.95 kgf m, 6.9 lbf ft
  5. Pull the XM receiver (C) out, then disconnect the connectors from the XM receiver, and detach the clips
  6. Install the XM receiver in the reverse order of removal

Scheme 198

Scheme 198: Without Navigation
  1. Remove the center console (see «CENTER CONSOLE PANEL DISASSEMBLY/REASSEMBLY»(/acura/tl/iv-2008-2011/remont/gauges-instrument-panels/#consoles__center-console-panel-disassemblyreassembly) )
  2. Disconnect the connectors from the USB adapter control unit (A), then remove the screws and USB adapter control unit
  3. Install the USB adapter control unit in the reverse order of removal

Scheme 199

Scheme 199: Front Door Speaker
  1. Remove the front door panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/exterior-body-panels/#door-system__front-door-panel-removalinstallation) )
  2. Remove the bolt Then lift the speaker straight up to release the lower clips (A) NOTE: If you pull the speaker out too far from the door, you will damage the lower clips Bolt Specifications: 5 x 0.8 mm, 4.4 N.m (0.45 kgf m, 3.2 lbf ft
  3. Disconnect the 2P connector (B), and remove the speaker
  4. Measure the resistance between terminals No 1 and No 2 With navigation, there should be 2 ohms Without navigation, there should be 4 ohms
  5. If the resistance is not as specified, replace the door speaker

Scheme 200

Scheme 200: Front Center Speaker

Scheme 201

Scheme 201
  1. With navigation, remove the navigation display unit (see «NAVIGATION DISPLAY UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/navigation-system/#navigation-system__navigation-display-unit-removalinstallation) ) Without navigation, remove the audio-HVAC display unit (see «AUDIO-HVAC DISPLAY UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) )
  2. Push out the speaker lid (A) from inside the dashboard, and disconnect the connectors
  3. Remove the screws and the front center speaker (A)
  4. Measure the resistance between terminals No 1 and No 2 There should be about 2 ohms
  5. If the resistance is not as specified, replace the front center speaker

Tweeter

SRS components are located in this area Review the SRS component locations (see COMPONENT LOCATION INDEX ), and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service

Scheme 202

Scheme 202: Tweeter

Scheme 203

Scheme 203
  1. Remove the A-pillar trim (see «TRIM REMOVAL/INSTALLATION - PILLAR AREAS»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-pillar-areas) )
  2. Release the hooks, and remove the tweeter (A)
  3. Check the capacitor (B) condition If any malfunction is found, replace the tweeter
  4. Measure the resistance between the tweeter (A) terminal No 2 and the outside terminal of the capacitor There should be about 6 ohms
  5. If the resistance is not as specified, replace the tweeter

Scheme 204

Scheme 204: Rear Speaker
  1. Remove the rear shelf (see «TRIM REMOVAL/INSTALLATION - REAR SHELF AREA»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-rear-shelf-area) )
  2. Remove the mounting bolt, then tilt the speaker forward to release the front clips (A) NOTE: If you pull the speaker out too far from the rear bulkhead, you will damage the lower clips Bolt Specifications: 5 x 0.8 mm, 4.4 N.m (0.45 kgf m, 3.2 lbf ft
  3. Disconnect the 2P connector (B), and remove the rear speaker
  4. Measure the resistance between the terminals No 1 and No 2 With navigation, there should be 2 ohms Without navigation, there should be 4 ohms
  5. If the resistance is not as specified, replace the rear speaker

Scheme 205

Scheme 205: Rear Door Speaker (with ELS audio system)
  1. Remove the rear door panel (see «REAR DOOR PANEL REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/exterior-body-panels/#door-system__rear-door-panel-removalinstallation) )
  2. Remove the bolts, disconnect the 2P connector (A), and remove the speaker (B) Bolt Specifications: 5 x 0.8 mm, 4.4 N.m (0.45 kgf m, 3.2 lbf ft
  3. Measure the resistance between terminals No 1 and No 2 There should be about 2 ohms
  4. If the resistance is not as specified, replace the rear door speaker

Scheme 206

Scheme 206: Subwoofer
  1. Remove the rear shelf (see «TRIM REMOVAL/INSTALLATION - REAR SHELF AREA»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-rear-shelf-area) )
  2. Remove the four mounting bolts from the subwoofer (A) Bolt Specifications: 6 x 1.0 mm, 9.4 N.m (0.95 kgf m, 6.9 lbf ft
  3. Disconnect the 2P connector (B), and remove the subwoofer
  4. Measure the resistance between the terminals No 1 and No 2 There should be about 2 ohms
  5. If the resistance is not as specified, replace the subwoofer

Scheme 207

Scheme 207: Audio Remote Switch Test
  1. Remove the audio remote, HFL-navigation voice control switch or the audio remote-HFL switch (see «STEERING WHEEL DISASSEMBLY/REASSEMBLY»(/acura/tl/iv-2008-2011/remont/electronic-steering/#power-steering-system) )
  2. Measure the resistance between terminals No 11 and No 12 in each switch position according to the table TERMINAL RESISTANCE CHART Position Resistance No button pressed About 10 kohms MODE About 3.7 kohms CH (+) About 1.7 kohms CH (-) About 775 ohms ↑(VOL UP) About 357 ohms ↓(VOL DOWN) About 100 ohms
  3. If the resistance is not as specified, replace the switch

AM/FM Antenna Amplifier Replacement

SRS components are located in this area Review the SRS component locations (see COMPONENT LOCATION INDEX ), and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service

Scheme 208

Scheme 208: AM/FM Antenna Amplifier Replacement
  1. Remove the C-pillar trim (see «C-PILLAR TRIM»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#interior-trim__c-pillar-trim) )
  2. Disconnect the connectors (A) from the AM/FM antenna amplifier (B) and the AM/FM antenna Bolt Specifications: 6 x 1.0 mm, 9.4 N.m (0.95 kgf m, 6.9 lbf ft
  3. Remove the bolt and the AM/FM antenna amplifier
  4. Install the AM/FM antenna amplifier in the reverse order of removal

AM/FM Antenna Repair

Note. To make an effective repair, the broken section must be no longer than one inch

Scheme 209

Scheme 209: AM/FM Antenna Repair

Scheme 210

Scheme 210
  1. Lightly rub the area around the broken section (A) with fine steel wool, then clean it with isopropyl alcohol
  2. Carefully mask above and below the broken portion of the window antenna wire (B) with cellophane tape (C)
  3. Using a commercially available rear window defogger repair kit, apply a heavy coat of paint (A) extending about 1/8" on both sides of the break Allow 30 minutes to dry
  4. Check for continuity in the repaired wire
  5. Apply a second coat of paint in the same way Let it dry 3 hours before removing the tape

Scheme 211

Scheme 211: XM Antenna Replacement
  1. Pull down the rear portion of the headliner (see «HEADLINER REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#interior-trim__headliner-removalinstallation) ) Take care not to damage the headliner
  2. Disconnect the XM antenna lead connector (A)
  3. Remove the nut (B) from the XM antenna (C)
  4. Install the XM antenna in the reverse order of removal

Scheme 212

Scheme 212: Auxiliary Jack Assembly Replacement
  1. Remove the center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/gauges-instrument-panels/#consoles__center-console-removalinstallation) )
  2. Detach the connector (A) from the clip Remove the cover (B) and disconnect the USB adapter cable connector (C)
  3. Carefully pull out the auxiliary jack assembly (D) from the center console box, then disconnect the 5P connector (E) and remove the USB adapter cable connector
  4. Install the auxiliary jack assembly in the reverse order of removal

See also:
NO SOUND WHEN BLUETOOTH AUDIO IS USED (WITH NAVIGATION)
BLUETOOTH AUDIO DOES NOT WORK (WITH NAVIGATION)
BLUETOOTH CELL PHONE CANNOT BE PAIRED
THE COMMUNICATION WITH CELL PHONE IS INTERRUPTED OR CHANGES (WITH NAVIGATION)
PAIRING INSTRUCTIONS ARE NOT DISPLAYED ON THE SCREEN
BLUETOOTH PHONE AUDIO FUNCTION SKIP AND PAUSE/RESUME DO NOT WORK (WITH NAVIGATION)
BLUETOOTH AUDIO DOES NOT WORK (WITHOUT NAVIGATION)
NAVIGATION SYSTEM
NAVIGATION THROUGH HFL MENUS
HANDS FREE LINK SYSTEM
AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION
BATTERY TEST
C-PILLAR TRIM
REAR WINDOW REPLACEMENT
DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE)
AUDIO WIRE HARNESS
CENTER CONSOLE PANEL REMOVAL/INSTALLATION
HANDSFREELINK CONTROL UNIT REMOVAL/INSTALLATION
RIGHT SIDE WIRE HARNESS (WITHOUT SH-AWD)
STEERING WHEEL DISASSEMBLY/REASSEMBLY
DISPOSAL OF DAMAGED COMPONENTS
CABLE REEL REPLACEMENT
HOW TO CHECK ERROR HISTORY
HFL SYSTEM TROUBLESHOOTING
ACURALINK CONTROL UNIT UPDATE
CENTER TRIM REMOVAL/INSTALLATION
CLIMATE CONTROL UNIT REMOVAL/INSTALLATION
TRIM REMOVAL/INSTALLATION - TRUNK AREA
CENTER CONSOLE REMOVAL/INSTALLATION
CENTER CONSOLE PANEL DISASSEMBLY/REASSEMBLY
FRONT DOOR PANEL REMOVAL/INSTALLATION
NAVIGATION DISPLAY UNIT REMOVAL/INSTALLATION
TRIM REMOVAL/INSTALLATION - PILLAR AREAS
TRIM REMOVAL/INSTALLATION - REAR SHELF AREA
REAR DOOR PANEL REMOVAL/INSTALLATION
HEADLINER REMOVAL/INSTALLATION
SYMPTOM TROUBLESHOOTING
AUDIO UNIT POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) (WITH NAVIGATION)
NO SOUND IS HEARD FROM THE SPEAKER(S) (DISPLAY IS NORMAL) (WITH NAVIGATION)
RADIO PRESET MEMORY IS LOST (WITH NAVIGATION)
VOLUME DOES NOT CHANGE (WITH NAVIGATION)
Radio tuner does not change stations (with navigation)
AUDIO-NAVIGATION SWITCH PANEL BUTTON ILLUMINATION DOES NOT WORK (WITH NAVIGATION)
AUDIO REMOTE SWITCH DOES NOT WORK PROPERLY (WITH NAVIGATION)
AUDIO DISC DOES NOT LOAD (WITH NAVIGATION)
AUDIO DISC DOES NOT EJECT (WITH NAVIGATION)
AUDIO DISC DOES NOT PLAY (WITH NAVIGATION)
AUDIO DISC SKIPS (WITH NAVIGATION)
AUDIO UNIT BUTTON DOES NOT WORK (WITH NAVIGATION)
AUDIO UNIT DISC INDICATOR DOES NOT WORK (WITH NAVIGATION)
USB DEVICE DOES NOT FUNCTION (WITH NAVIGATION)
USB INPUT SOUND IS LOW OR CANNOT BE HEARD (WITH NAVIGATION)
ERROR CODE: XM NO SIGNAL IS DISPLAYED (WITH NAVIGATION)
ERROR CODE: XM ANTENNA IS DISPLAYED (WITH ACURALINK)
XM RADIO DISPLAY IS BLANK AND NO STATION INFORMATION IS DISPLAYED (USA MODELS WITH NAVIGATION)
XM RADIO PRESET MEMORY IS LOST (USA MODELS WITH NAVIGATION)
POOR OR NO SOUND WITH XM RADIO (AUDIO UNIT DOES DISPLAY XM CHANNELS) (WITH NAVIGATION)
POOR AM OR FM RADIO RECEPTION OR INTERFERENCE (WITHOUT NAVIGATION)
VOLUME DOES NOT CHANGE (WITHOUT NAVIGATION)
AUDIO SWITCH PANEL BUTTON ILLUMINATION DOES NOT WORK (WITHOUT NAVIGATION)
AUDIO DISC CHANGER DOES NOT LOAD ALL SIX DISCS (WITHOUT NAVIGATION)
AUDIO DISC SKIPS (WITHOUT NAVIGATION)
USB DEVICE DOES NOT FUNCTION (WITHOUT NAVIGATION)
With AcuraLink
Without AcuraLink
SEEK STOP TEST
RECEPTION LEVEL INDICATION (PUSH AND HOLD 5 SEC AM/FM BUTTON)
AM/FM ANTENNA AMPLIFIER REPLACEMENT
AM/FM Antenna Repair
SPEAKER CHECK MODE
Audio Disc Does Not Play (Without Navigation)
SOUND QUALITY DIAGNOSIS
ERROR CODES
XM SIGNAL RECEPTION LEVEL INDICATION MODE
PHASE TEST
ELECTRICAL NOISE TEST
SOUND BALANCE TEST
SOUND JUDGING
