Acuralink Acura TL IV

Entertainment Systems 28 illustrations ~10628 words

Scheme 306

Scheme 306: Component Location Index
Scheme 306: Component Location Index

Scheme 307

Scheme 307: How to Check for DTCs with the HDS
Scheme 307: How to Check for DTCs with the HDS
  1. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
  2. Connect the HDS to the data link connector (DLC) (A) located under the driver's side of the dashboard
  3. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  4. Make sure the HDS communicates with the vehicle and the AcuraLink control unit (XM receiver) If it doesn't, troubleshoot the DLC circuit (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/tl/iv-2008-2011/remont/testing-diagnostics/#pgm-fi-system__dlc-circuit-troubleshooting) )
  5. Select XM/HIP in the BODY ELECTRICAL menu
  6. Select DTCs in the XM/HIP menu
  7. Check for DTCs If any DTCs are indicated, write down the DTCs, then go to the indicated DTC troubleshooting If no DTCs are indicated, refer to «SYMPTOM TROUBLESHOOTING»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#acuralink)

Note. After troubleshooting, clear the DTCs with the HDS For specific operations, refer to the user's manual that came with the HDS

Disconnecting

To disconnect the connector, pull the lever (A) while pushing the lock tab (B) down, then pull the connector (C)

Scheme 308

Scheme 308: Disconnecting
Scheme 308: Disconnecting

Connecting

To connect the connector, push the connector into the connector sleeve (A). As the connector is pressed in, the lever (B) moves to the locked position

Scheme 309

Scheme 309: Connecting
Scheme 309: Connecting

DTC Troubleshooting Index

AcuraLink Control Unit

DTCDescriptionDTC typeRefer
B2240XM antenna errorInternal error(see DTC TROUBLESHOOTING )
B2248HIP power supply abnormal (more than 16 V)Battery voltage(see DTC TROUBLESHOOTING )
B2249HIP power supply abnormal (less than 9 V)Battery voltage(see DTC B2249: HIP POWER SUPPLY ABNORMAL (LESS THAN 9 V) )
U0100F-CAN lost communication with PCMLoss of communication(see DTC U0100: F-CAN Lost Communication with ECM/PCM )
U0155F-CAN lost communication with gauge control moduleLoss of communication(see DTC U0155: F-CAN Lost Communication with Gauge Control Module )
U1280Communication bus line error (BUS-OFF)Loss of communication(see DTC U1280: COMMUNICATION BUS LINE ERROR (BUS-OFF) )
U128DAcuraLink control unit (XM receiver) lost B-CAN communication with gauge control moduleLoss of communication(see DTC U128D: AcuraLink Control Unit (XM Receiver) Lost B-CAN Communication with Gauge Control Module )

DTC TROUBLESHOOTING CHART

Symptom Troubleshooting Index

SymptomDiagnostic procedureAlso check for
AcuraLink services do not workSymptom Troubleshooting (see SYMPTOM TROUBLESHOOTING )Blown fuse No 15 (10 A) in the under-hood fuse/relay box and No 12 (7 5 A), No 18 (7 5 A) in the driver's under-dash fuse/relay box Poor ground at G501
AcuraLink services do not work after replacing the AcuraLink control unit (XM receiver)Call Acura Client Services and request an activation Call XM customer service and register the replacement AcuraLink control unit (XM receiver)
AcuraLink messages cannot be heard or are weakSymptom Troubleshooting (see ACURALINK MESSAGES CANNOT BE HEARD OR ARE WEAK )
Traffic or Weather information is not shown on map screenNavigation System Symptom Troubleshooting (see TRAFFIC OR WEATHER INFORMATION IS NOT SHOWN ON MAP SCREEN )
AcuraLink messages cannot be deletedHow to Delete Stored AcuraLink Messages (see HOW TO DELETE STORED ACURALINK MESSAGES )

SYMPTOM TROUBLESHOOTING CHART

System Description

The AcuraLink uses the client's cell phone or XM radio to transmit and receive information about the vehicle In addition, the AcuraLink system is also able to initiate voice or data calls with the HandsFreeLink control unit

The AcuraLink control unit (HIP) is very similar in design to an XM receiver, but it has additional communication features The main functions include

  1. Receiving and playing XM stations Displaying station, song title and other information on the audio-HVAC subdisplay using the GA-Net bus
  2. Receiving XM traffic channel data
  3. Gives Feature Guide tips
  4. Receiving AcuraLink messages and displaying them in the navigation display
  5. Processing DTC (diagnostic trouble code) error messages from the PCM, the SRS and other systems, and displaying them on the navi display
  6. Sending DTC information to the AcuraLink servers using the client's cell phone (only if the client has set up and enabled this option)
  7. Receiving weather data

Scheme 310

Scheme 310
Scheme 310

Service Application

  1. Malfunction indicator lamp (MIL) explanation (from server message and vehicle message)
  2. Service information message
  3. Recall Information
  4. Quick tips
  5. Place to provide feedback/view cautions that were not available when vehicle was initially sold
  6. Correction of address and full name that is registered
  7. Real time traffic information
  8. Maintenance information message
  9. Feature guide (90 days)
  10. Weather information

The AcuraLink Satellite Communication System stores and displays these types of messages on the navigation system display screen

  1. Feature Guide info
  2. System malfunction info
  3. Driver warnings
  4. DTCs
  5. Quick tips

Note. To delete any stored AcuraLink messages, follow these procedures. The first procedure is for your client. It lets them delete certain types of messages. The second procedure is for technicians. It lets you delete all stored messages The diagnostic menu includes a DATA RESET function Select this only at TQI and when the vehicle changes ownership It deletes all AcuraLink messages, log data, and AcuraLink registration If you select DATA RESET during the 45-day activation period, the AcuraLink Feature Guide repeats the first message AcuraLink messages related to a repair should be deleted after that repair is done If you don't delete these messages, they stay in your client's AcuraLink message log

Client

  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  2. Touch OK on the disclaimer screen
  3. Press the INFO button to bring up the Information screen
  4. Use the interface dial to select # 1 All Messages
  5. Select the item number you want to delete, then select Delete (If you don't see Delete on the display screen, you can't remove this message)
  6. Select Yes to confirm your choice

Scheme 311

Scheme 311: Service Tech
Scheme 311: Service Tech

Scheme 312

Scheme 312
Scheme 312
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  2. Touch OK on the disclaimer screen
  3. Press and hold the MAP/GUIDE, CANCEL, and MENU buttons at the same time for 3 seconds more, and the self-diagnosis begins
  4. Using the interface dial, select the XM (HIP) from the Detail Information & Setting Press the interface dial Select XM (HIP) Diag (A) from XM (HIP) System Link
  5. Select Diagnostic Info
  6. Select the item you want to delete After the message and date come up, select Delete
  7. Select Yes to confirm your choice
  8. Repeat step 6 and 7 for each message you want to delete

Scheme 313

Scheme 313: AcuraLink Control Unit (XM Receiver) Connector for Inputs and Outputs
Scheme 313: AcuraLink Control Unit (XM Receiver) Connector for Inputs and Outputs

AcuraLink Control Unit (XM Receiver) Connector A (23P)

Scheme 314

Scheme 314
Scheme 314
CavityWire ColorTerminal NameConnect to
A1WHT+BNo 15 (10 A) fuse in the under-hood fuse/relay box
A2BRNIG1No 12 (7 5 A) fuse in the drivers' under-dash fuse/relay box
A3PURACCNo 18 (7 5 A) fuse in the drivers' under-dash fuse/relay box
A6BLKF-CAN LOF-CAN communication bus line
A7WHTF-CAN HIF-CAN communication bus line
A8BLUB-CAN LOB-CAN communication bus line
A9PNKB-CAN HIB-CAN communication bus line
A13GRNAUDIO LAudio-navigation unit, HandsFreeLink control unit
A14WHTAUDIO RAudio-navigation unit, HandsFreeLink control unit
A15BLKAUDIO L+Audio-navigation unit, HandsFreeLink control unit
A16REDAUDIOR+Audio-navigation unit, HandsFreeLink control unit
A17WHTNAVI COMM1Audio-navigation unit
A18REDNAVI COMM2Audio-navigation unit
A19GRNNAVI COMM3Audio-navigation unit
A20BLKNAVI COMM4Audio-navigation unit
A21GRY (1)NAVI COMM SHShield for terminals No 17, No 18, No 19, and No 20
A22REDHIP/HFL COMM3HandsFreeLink control unit
A23WHTHIP/HFL COMM4HandsFreeLink control unit
A24BLKHIP/HFL COMM1HandsFreeLink control unit
A25GRNHIP/HFL COMM2HandsFreeLink control unit
A26GRY (1)HIP/HFL COMM SHShield for terminals No 22, No 23, No 24, and No 25
A28BLKGNDBody ground to G501
A29GRY (1)GA-NET BUS SHShield for terminals No 30 and No 31
A30PNKGA-NET BUS+Audio-navigation unit, HandsFreeLink control unit, navigation display unit
A31BLUGA-NET BUSAudio-navigation unit, HandsFreeLink control unit, navigation display unit
A32GRY (1)AUDIO SHShield for terminals No 13, No 14, No 15, and No 16
(1) The shielded wires have a heat-shrunk tube insulating the outside of the wire The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the schematic
(1)The shielded wires have a heat-shrunk tube insulating the outside of the wire The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the schematic

CONNECTOR TERMINAL REFERENCE CHART

AcuraLink Control Unit (XM Receiver) Connector B (2P)

Scheme 315

Scheme 315
Scheme 315
CavityWireTerminal NameConnect to
B1SAT/TERXM antenna
B2GND SHShield for terminal No 1

CONNECTOR TERMINAL REFERENCE CHART

Scheme 316

Scheme 316: Circuit Diagram
Scheme 316: Circuit Diagram

Scheme 317

Scheme 317
Scheme 317

Scheme 318

Scheme 318
Scheme 318

Scheme 319

Scheme 319
Scheme 319

Self-diagnostic Function

Note. Only select DATA RESET from the XM (HIP) ECU screen when instructed Selecting DATA RESET will clear the AcuraLink registration, and the AcuraLink service resets to the factory default If the vehicle was already registered for the AcuraLink service, it will have to be reactivated by calling Acura Client Services before all features are available

The AcuraLink control unit (XM receiver) has a self-diagnostic function To run the self-diagnostic function, do the following

How to Enter the Self-diagnostic Function

Note. Always check for and repair any CAN DTCs before troubleshooting the AcuraLink system

Scheme 320

Scheme 320: How to Enter the Self-diagnostic Function
Scheme 320: How to Enter the Self-diagnostic Function

Scheme 321

Scheme 321
Scheme 321

Scheme 322

Scheme 322
Scheme 322

Scheme 323

Scheme 323
Scheme 323
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  2. Touch OK on the disclaimer screen
  3. Press and hold the MAP/GUIDE, CANCEL, and MENU buttons at the same time for 3 seconds more, and the self-diagnosis begins
  4. Using the interface dial, select the Select Diagnosis Items from the Detail Information & Setting Press the interface dial
  5. Using the interface dial, select the XM (HIP) from the Detail Information & Setting menu Press the interface dial
  6. The display indicates XM (HIP) System Link, and does an AcuraLink connection check for each device If a connection is faulty, the place where it is faulty is indicated with NG (red color)
  7. When red (NG) is indicated, check the continuity between the AcuraLink control unit(XM receiver) and the device indicated in red ACURALINK CONTROL UNIT RESULT REFERENCE Device indicated in red Test condition Test Desired result Possible cause if result is not obtained F-CAN Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) Yaw rate-lateral acceleration sensor 4P connector (3) Yaw rate-lateral longitudinal acceleration sensor 4P connector (2) Check for continuity between terminal No 7 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 3 of the yaw rate-lateral acceleration sensor 4P connector (2) or yaw rate-lateral/longitudinal acceleration sensor 4P connector (2) There should be continuity An open in the wire Check for continuity between terminal No 6 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 2 of the yaw rate-lateral acceleration sensor 4P connector (2) or yaw rate-lateral/longitudinal acceleration sensor 4P connector (2) There should be continuity An open in the wire Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) PCM connector A (49P) Check for continuity between terminal No 7 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 49 of PCM connector A (49P) There should be continuity An open in the wire Check for continuity between terminal No 6 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 48 of PCM connector A (49P) There should be continuity An open in the wire Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) Gauge control module 32P connector Check for continuity between terminal No 7 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 10 of gauge control module 32P connector There should be continuity An open in the wire Check for continuity between terminal No 6 of AcuraLink control unit(XM receiver) connector A (32P) and terminal No 9 of gauge control module 32P connector There should be continuity An open in the wire Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) TPMS control unit 20P connector Check for continuity between terminal No 7 of AcuraLink control unit(XM receiver) connector A (32P) and terminal No 2 of TPMS control unit 20P connector There should be continuity An open in the wire Check for continuity between terminal No 6 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 11 of TPMS control unit 20P connector There should be continuity An open in the wire Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) Audio-navigation unit connector H (28P) Check for continuity between terminal No 7 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 12 of audio-navigation unit connector H (28P) There should be continuity An open in the wire Check for continuity between terminal No 6 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 25 of audio-navigation unit connector H (28P) There should be continuity An open in the wire Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) EPS control unit connector D (28P) Check for continuity between terminal No 7 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 1 of EPS control unit connector D (28P) There should be continuity An open in the wire Check for continuity between terminal No 6 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 15 of EPS control unit connector D (28P) There should be continuity An open in the wire Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) SH-AWD control unit connector A (20P) (1) Check for continuity between terminal No 7 of AcuraLink control unit(XM receiver) connector A (32P) and terminal No 10 of SH-AWD control unit connector A (20P) There should be continuity An open in the wire Check for continuity between terminal No 6 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 20 of SH-AWD control unit connector A (20P) There should be continuity An open in the wire Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) Steering angle sensor 5P connector (1) Check for continuity between terminal No 7 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 4 of the steering angle sensor 5P connector There should be continuity An open in the wire Check for continuity between terminal No 6 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 2 of steering angle sensor 5P connector There should be continuity An open in the wire Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) Power control unit connector A (36P) Check for continuity between terminal No 7 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 34 of power control unit connector A (36P) There should be continuity An open in the wire Check for continuity between terminal No 6 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 35 of power control unit connector A (36P) There should be continuity An open in the wire Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) VSA modulator-control unit 47P connector Check for continuity between terminal No 7 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 12 of VSA modulator-control unit 47P connector There should be continuity An open in the wire Check for continuity between terminal No 6 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 13 of VSA modulator-control unit 47P connector There should be continuity An open in the wire Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) SRS unit connector A (39P) Check for continuity between terminal No 7 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 17 of SRS unit connector A (39P) There should be continuity An open in the wire Check for continuity between terminal No 6 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 16 of SRS unit connector A (39P) There should be continuity An open in the wire Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) Yaw rate-lateral acceleration sensor 4P connector (3) Yaw rate-lateral/longitudinal acceleration sensor 4P connector (2) PCM connector A (49P) Gauge control module 32P connector Power control unit connector A (36P) TPMS control unit 20P connector VSA modulator-control unit 47P connector SRS unit connector A (39P) EPS control unit connector D (28P) SH-AWD control unit connector A (20P) (2) Steering angle sensor 5P connector (2) Audio-navigation unit connector H (28P) Check for continuity between terminals No 7 and No 6 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the wire Check for continuity between terminals No 1 and No 7 of AcuraLink control unit (XM receiver) connector A (32P) There should be no continuity A short in the wire Check for continuity between terminals No 1 and No 6 of AcuraLink control unit (XM receiver) connector A (32P) There should be no continuity A short in the wire Disconnect these items Yaw rate-lateral acceleration sensor 4P connector (3) Yaw rate-lateral/longitudinal acceleration sensor 4P connector (2) PCM connector A (49P) Gauge control module 32P connector Power control unit connector A (36P) TPMS control unit 20P connector VSA modulator-control unit 47P connector SRS unit connector A (39P) EPS control unit connector D (28P) SH-AWD control unit connector A (20P) (2) Steering angle sensor 5P connector (2) Audio-navigation unit connector H (28P) Check for continuity between terminals No 7 and No 6 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the AcuraLink control unit (XM receiver) Disconnect these items AcuraLink control unit(XM receiver) connector A (32P) PCM connector A (49P) Gauge control module 32P connector Power control unit connector A (36P) TPMS control unit 20P connector VSA modulator-control unit 47P connector SRS unit connector A (39P) EPS control unit connector D (28P) SH-AWD control unit connector A(20P) (2) Steering angle sensor 5P connector (2) Audio-navigation unit connector H (28P) Check for continuity between terminals No 7 and No 6 of AcuraLink control unit(XM receiver) connector A (32P) and body ground There should be no continuity A short in the yaw rate-lateral acceleration sensor (3) or yaw rate-lateral/longitudinal acceleration sensor (2) Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) Yaw rate-lateral acceleration sensor 4P connector (3) Yaw rate-lateral/longitudinal acceleration sensor 4P connector (3) Gauge control module 32P connector Power control unit connector A (36P) TPMS control unit 20P connector VSA modulator-control unit 47P connector SRS unit connector A (39P) EPS control unit connector D (28P) SH-AWD control unit connector A (20P) (2) Steering angle sensor 5P connector (2) Audio-navigation unit connector H (28P) Check for continuity between terminals No 7 and No 6 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the PCM Disconnect these items AcuraLink control unit(XM receiver) connector A (32P) Yaw rate-lateral acceleration sensor 4P connector 2 Yaw rate-lateral/longitudinal acceleration sensor 4P connector 1 PCM connector A (49P) Gauge control module 32P connector Power control unit connector A (36P) TPMS control unit 20P connector VSA modulator-control unit 47P connector SRS unit connector A (39P) SH-AWD control unit connector A (20P) 1 Steering angle sensor 5P connector (2) Audio-navigation unit connector H (28P) Check for continuity between terminals No 7 and No 6 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in EPS control unit Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) Yaw rate-lateral acceleration sensor 4P connector (2) Yaw rate-lateral/longitudinal acceleration sensor 4P connector (2) PCM connector A (49P) Power control unit connector A (36P) TPMS control unit 20P connector VSA modulator-control unit 47P connector SRS unit connector A (39P) EPS control unit connector D (28P) SH-AWD control unit connector A (20P) 1 Steering angle sensor 5P connector (2) Audio-navigation unit connector H (28P) Check for continuity between terminals No 7 and No 6 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the gauge control module Disconnect these items AcuraLink control unit(XM receiver) connector A (32P) Yaw rate-lateral acceleration sensor 4P connector (3) Yaw rate-lateral/longitudinal acceleration sensor 4P connector (2) PCM connector A (49P) Gauge control module 32P connector Power control unit connector A (36P) VSA modulator-control unit 47P connector SRS unit connector A (39P) EPS control unit connector D (28P) SH-AWD control unit connector A (20P) (2) Steering angle sensor 5P connector (2) Audio-navigation unit connector H (28P) Check for continuity between terminals No 7 and No 6 of AcuraLink control unit(XM receiver) connector A (32P) and body ground There should be no continuity A short in the TPMS control unit Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) Yaw rate-lateral acceleration sensor 4P connector (3) Yaw rate-lateral/longitudinal acceleration sensor 4P connector (2) PCM connector A (49P) Gauge control module 32P connector Power control unit connector A (36P) TPMS control unit 20P connector SRS unit connector A (39P) EPS control unit connector D (28P) SH-AWD control unit connector A (20P) (2) Steering angle sensor 5P connector (2) Audio-navigation unit connector H (28P) Check for continuity between terminals No 7 and No 6 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the VSA modulator-control unit Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) Yaw rate-lateral acceleration sensor 4P connector 2 Yaw rate-lateral/longitudinal acceleration sensor 4P connector (2) PCM connector A (49P) Gauge control module 32P connector Power control unit connector A (36P) TPMS control unit 20P connector VSA modulator-control unit 47P connector EPS control unit connector D (28P) SH-AWD control unit connector A (20P) (2) Steering angle sensor 5P connector (2) Audio-navigation unit connector H (28P) Check for continuity between terminals No 7 and No 6 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the SRS unit Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) Yaw rate-lateral acceleration sensor 4P connector 2 Yaw rate-lateral/longitudinal acceleration sensor 4P connector (2) PCM connector A (49P) Gauge control module 32P connector Power control unit connector A (36P) TPMS control unit 20P connector VSA modulator-control unit 47P connector SRS unit connector A (39P) EPS control unit connector D (28P) SH-AWD control unit connector A (20P) (2) Steering angle sensor 5P connector 1 Check for continuity between terminals No 7 and No 6 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the audio-navigation unit Disconnect these items AcuraLink control unit (XM receiver) connector A(32P) Yaw rate-lateral acceleration sensor 4P connector (3) Yaw rate-lateral/longitudinal acceleration sensor 4P connector (2) PCM connector A (49P) Gauge control module 32P connector Power control unit connector A (36P) TPMS control unit 20P connector VSA modulator-control unit 47P connector SRS unit connector A (39P) EPS control unit connector D (28P) Steering angle sensor 5P connector (2) Audio-navigation unit connector H (28P) Check for continuity between terminals No 7 and No 6 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the SH-AWD control unit (2) Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) Yaw rate-lateral acceleration sensor 4P connector (3) Yaw rate-lateral/longitudinal acceleration sensor 4P connector (2) PCM connector A (49P) Gauge control module 32P connector Power control unit connector A (36P) TPMS control unit 20P connector VSA modulator-control unit 47P connector SRS unit connector A (39P) EPS control unit connector D (28P) SH-AWD control unit connector A (20P) (2) Audio-navigation unit connector H (28P) Check for continuity between terminals No 7 and No 6 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the steering angle sensor (2) Disconnect these items AcuraLink control unit(XM receiver) connector A (32P) Yaw rate-lateral acceleration sensor 4P connector (3) Yaw rate-lateral/longitudinal acceleration sensor 4P connector (2) PCM connector A (49P) Gauge control module 32P connector TPMS control unit 20P connector VSA modulator-control unit 47P connector SRS unit connector A (39P) EPS control unit connector D (28P) SH-AWD control unit connector A (20P) (2) Steering angle sensor 5P connector 1 Audio-navigation unit connector H (28P) Check for continuity between terminals No 7 and No 6 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the power control unit B-CAN Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) Driver's under-dash fuse/relay box connector P (20P) Check for continuity between terminal No 9 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 6 of driver's under-dash fuse/relay box connector P (20P) disconnected There should be continuity An open in the wire Check for continuity between terminal No 8 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 5 of driver's under-dash fuse/relay box connector P (20P) disconnected There should be continuity An open in the wire Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) Passenger's under-dash fuse/relay box connector A (38P) Check for continuity between terminal No 9 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 11 of passenger's under-dash fuse/relay box connector A (38P) disconnected There should be continuity An open in the wire Check for continuity between terminal No 8 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 29 of passenger's under-dash fuse/relay box connector A (38P) disconnected There should be continuity An open in the wire Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) Door multiplex control unit 37P connector Check for continuity between terminal No 9 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 35 of door multiplex control unit 37P connector There should be continuity An open in the wire Check for continuity between terminal No 8 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 33 of door multiplex control unit 37P connector There should be continuity An open in the wire Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) Gauge control module 32P connector Check for continuity between terminal No 9 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 26 of gauge control module 32P connector There should be continuity An open in the wire Check for continuity between terminal No 8 of AcuraLink control unit(XM receiver) connector A (32P) and terminal No 25 of gauge control module 32P connector There should be continuity An open in the wire Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) HandsFreeLink control unit 28P connector Check for continuity between terminal No 9 of AcuraLink control unit(XM receiver) connector A (32P) and terminal No 18 of HandsFreeLink control unit 28P connector There should be continuity An open in the wire Check for continuity between terminal No 8 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 17 of HandsFreeLink control unit 28P connector There should be continuity An open in the wire Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) Power seat control unit connector A (40P) Check for continuity between terminal No 9 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 40 of power seat control unit connector A (40P) There should be continuity An open in the wire Check for continuity between terminal No 8 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 39 of power seat control unit connector A (40P) There should be continuity An open in the wire Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) Climate control unit connector C (20P) Check for continuity between terminal No 9 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 8 of climate control unit connector C (20P) There should be continuity An open in the wire Check for continuity between terminal No 8 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 7 of climate control unit connector C (20P) There should be continuity An open in the wire Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) Audio-navigation unit connector D (20P) Check for continuity between terminal No 9 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 6 of audio-navigation unit connector D (20P) There should be continuity An open in the wire Check for continuity between terminal No 8 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 15 of audio-navigation unit connector D (20P) There should be continuity An open in the wire Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) Power control unit connector A (36P) Check for continuity between terminal No 9 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 16 of power control unit connector A (36P) There should be continuity An open in the wire Check for continuity between terminal No 8 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 17 of power control unit connector A (36P) There should be continuity An open in the wire Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) Remote slot control unit 40P connector Check for continuity between terminal No 9 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 3 of remote slot control unit 40P connector There should be continuity An open in the wire Check for continuity between terminal No 8 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 23 of remote slot control unit 40P connector There should be continuity An open in the wire Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) Keyless access control unit connector B (32P) Check for continuity between terminal No 9 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 8 of keyless access control unit connector B (32P) There should be continuity An open in the wire Check for continuity between terminal No 8 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 7 of keyless access control unit connector B (32P) There should be continuity An open in the wire Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) Driver's under-dash fuse/relay box connector P (20P) Passenger's under-dash fuse/relay box connector A (38P) Door multiplex control unit 37P connector Gauge control module 32P connector HandsFreeLink control unit 28P connector Power seat control unit connector A (40P) Climate control unit connector C (20P) Audio-navigation unit connector D (20P) Power control unit connector A (36P) Remote slot control unit 40P connector Keyless access control unit connector B (32P) Check for continuity between terminals No 9 and No 8 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the wire Check for continuity between terminals No 9 and No 8 of AcuraLink control unit (XM receiver) connector A (32P) There should be no continuity A short in the wire Disconnect these items Driver's under-dash fuse/relay box connector P (20P) Passenger's under-dash fuse/relay box connector A (38P) Door multiplex control unit 37P connector Gauge control module 32P connector HandsFreeLink control unit 28P connector Power seat control unit connector A (40P) Climate control unit connector C (20P) Audio-navigation unit connector D (20P) Power control unit connector A (36P) Remote slot control unit 40P connector Keyless access control unit connector B (32P) Check for continuity between terminals No 9 and No 8 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the AcuraLink control unit (XM receiver) Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) Passenger's under-dash fuse/relay box connector A (38P) Door multiplex control unit 37P connector Gauge control module 32P connector HandsFreeLink control unit 28P connector Power seat control unit connector A (40P) Climate control unit connector C (20P) Audio-navigation unit connector D (20P) Power control unit connector A (36P) Remote slot control unit 40P connector Keyless access control unit connector B (32P) Check for continuity between terminals No 9 and No 8 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the driver's under-dash fuse/relay box Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) Driver's under-dash fuse/relay box connector P (20P) Door multiplex control unit 37P connector Gauge control module 32P connector HandsFreeLink control unit 28P connector Power seat control unit connector A (40P) Climate control unit connector C (20P) Audio-navigation unit connector D (20P) Power control unit connector A (36P) Remote slot control unit 40P connector Keyless access control unit connector B (32P) Check for continuity between terminals No 9 and No 8 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the passenger's under-dash fuse/relay box Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) Driver's under-dash fuse/relay box connector P (20P) Passenger's under-dash fuse/relay box connector A (38P) Gauge control module 32P connector HandsFreeLink control unit 28P connector Power seat control unit connector A (40P) Climate control unit connector C (20P) Audio-navigation unit connector D (20P) Power control unit connector A (36P) Remote slot control unit 40P connector Keyless access control unit connector B (32P) Check for continuity between terminals No 9 and No 8 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the door multiplex control unit Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) Driver's under-dash fuse/relay box connector P (20P) Passenger's under-dash fuse/relay box connector A (38P) Door multiplex control unit 37P connector HandsFreeLink control unit 28P connector Power seat control unit connector A (40P) Climate control unit connector C (20P) Audio-navigation unit connector D (20P) Power control unit connector A (36P) Remote slot control unit 40P connector Keyless access control unit connector B (32P) Check for continuity between terminals No 9 and No 8 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the gauge control module Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) Driver's under-dash fuse/relay box connector P (20P) Passenger's under-dash fuse/relay box connector A (38P) Door multiplex control unit 37P connector Gauge control module 32P connector Power seat control unit connector A (40P) Climate control unit connector C (20P) Audio-navigation unit connector D (20P) Power control unit connector A (36P) Remote slot control unit 40P connector Keyless access control unit connector B (32P) Check for continuity between terminals No 9 and No 8 of AcuraLink control unit(XM receiver) connector A (32P) and body ground There should be no continuity A short in the HandsFreeLink control unit Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) Driver's under-dash fuse/relay box connector P (20P) Passenger's under-dash fuse/relay box connector A (38P) Door multiplex control unit 37P connector Gauge control module 32P connector HandsFreeLink control unit 28P connector Climate control unit connector C (20P) Audio-navigation unit connector D (20P) Power control unit connector A (36P) Remote slot control unit 40P connector Keyless access control unit connector B (32P) Check for continuity between terminals No 9 and No 8 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the power seat control unit Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) Driver's under-dash fuse/relay box connector P (20P) Passenger's under-dash fuse/relay box connector A (38P) Door multiplex control unit 37P connector Gauge control module 32P connector HandsFreeLink control unit 28P connector Power seat control unit connector A (40P) Audio-navigation unit connector D (20P) Power control unit connector A (36P) Remote slot control unit 40P connector Keyless access control unit connector B (32P) Check for continuity between terminals No 9 and No 8 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the climate control unit Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) Driver's under-dash fuse/relay box connector P (20P) Passenger's under-dash fuse/relay box connector A (38P) Door multiplex control unit 37P connector Gauge control module 32P connector HandsFreeLink control unit 28P connector Power seat control unit connector A (40P) Climate control unit connector C (20P) Power control unit connector A (36P) Remote slot control unit 40P connector Keyless access control unit connector B (32P) Check for continuity between terminals No 9 and No 8 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the audio-navigation unit Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) Driver's under-dash fuse/relay box connector P (20P) Passenger's under-dash fuse/relay box connector A (38P) Door multiplex control unit 37P connector Gauge control module 32P connector HandsFreeLink control unit 28P connector Power seat control unit connector A (40P) Climate control unit connector C (20P) Audio-navigation unit connector D(20P) Remote slot control unit 40P connector Keyless access control unit connector B (32P) Check for continuity between terminals No 9 and No 8 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the power control unit Disconnect these items AcuraLink control unit (XM receiver) connector A(32P) Driver's under-dash fuse/relay box connector P (20P) Passenger's under-dash fuse/relay box connector A (38P) Door multiplex control unit 37P connector Gauge control module 32P connector HandsFreeLink control unit 28P connector Power seat control unit connector A (40P) Climate control unit connector C (20P) Audio-navigation unit connector D(20P) Power control unit connector A (36P) Keyless access control unit connector B (32P) Check for continuity between terminals No 9 and No 8 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the remote slot control unit Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) Driver's under-dash fuse/relay box connector P (20P) Passenger's under-dash fuse/relay box connector A (38P) Door multiplex control unit 37P connector Gauge control module 32P connector HandsFreeLink control unit 28P connector Power seat control unit connector A (40P) Climate control unit connector C (20P) Audio-navigation unit connector D (20P) Power control unit connector A (36P) Remote slot control unit 40P connector Check for continuity between terminals No 9 and No 8 of AcuraLink control unit(XM receiver) connector A (32P) and body ground There should be no continuity A short in the keyless access control unit Navi Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) Audio-navigation unit connector H (28P) Check for continuity between terminal No 19 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 22 of audio-navigation unit connector H (28P) There should be continuity An open in the wire Check for continuity between terminal No 20 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 9 of audio-navigation unit connector H (28P) There should be continuity An open in the wire Check for continuity between terminal No 17 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 23 of audio-navigation unit connector H (28P) There should be continuity An open in the wire Check for continuity between terminal No 18 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 10 of audio-navigation unit connector H (28P) There should be continuity An open in the wire Check for continuity between terminal No 19 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the wire Check for continuity between terminals No 1 and No 19 of AcuraLink control unit (XM receiver) connector A (32P) There should be no continuity A short to power in the wire Check for continuity between terminal No 20 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the wire Check for continuity between terminals No 1 and No 20 of AcuraLink control unit (XM receiver) connector A (32P) There should be no continuity A short to power in the wire Check for continuity between terminal No 17 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the wire Check for continuity between terminals No 1 and No 17 of AcuraLink control unit (XM receiver) connector A (32P) There should be no continuity A short to power in the wire Check for continuity between terminal No 18 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the wire Check for continuity between terminals No 1 and No 18 of AcuraLink control unit(XM receiver) connector A (32P) There should be no continuity A short to power in the wire Disconnect audio-navigation unit connector H (28P) Check for continuity between terminal No 19 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the AcuraLink control unit (XM receiver) Check for continuity between terminal No 20 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the AcuraLink control unit (XM receiver) Check for continuity between terminal No 17 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the AcuraLink control unit (XM receiver) Check for continuity between terminal No 18 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the AcuraLink control unit (XM receiver) Disconnect AcuraLink control unit (XM receiver) connector A (32P) Check for continuity between terminal No 19 of AcuraLink control unit(XM receiver) connector A (32P) and body ground There should be no continuity A short in the navigation unit Check for continuity between terminal No 20 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the navigation unit Check for continuity between terminal No 17 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the navigation unit Check for continuity between terminal No 18 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the navigation unit HFL Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) HandsFreeLink control unit 28P Check for continuity between terminal No 24 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 20 of the HandsFreeLink control unit 28P connector There should be continuity An open in the wire Check for continuity between terminal No 25 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 21 of the HandsFreeLink control unit 28P connector There should be continuity An open in the wire Check for continuity between terminal No 22 of AcuraLink control unit(XM receiver) connector A (32P) and terminal No 7 of the HandsFreeLink control unit 28P connector There should be continuity An open in the wire Check for continuity between terminal No 23 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 6 of the HandsFreeLink control unit 28P connector There should be continuity An open in the wire Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) HandsFreeLink control unit 28P Check for continuity between terminal No 24 of AcuraLink control unit(XM receiver) connector A (32P) and body ground There should be no continuity A short in the wire Check for continuity between terminal No 1 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 24 of the AcuraLink control unit (XM receiver) connector A (32P) There should be no continuity A short to power in the wire Check for continuity between terminal No 25 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the wire Check for continuity between terminal No 1 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 25 of the AcuraLink control unit (XM receiver) connector A (32P) There should be no continuity A short to power in the wire Check for continuity between terminal No 22 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the wire Check for continuity between terminal No 1 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 22 of the AcuraLink control unit (XM receiver) connector A (32P) There should be no continuity A short to power in the wire Check for continuity between terminal No 23 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the wire Check for continuity between terminal No 1 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 23 of the AcuraLink control unit(XM receiver) connector A (32P) There should be no continuity A short to power in the wire HandsFreeLink control unit 28P connector disconnected Check for continuity between terminal No 24 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the AcuraLink control unit (XM receiver) Check for continuity between terminal No 25 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the AcuraLink control unit (XM receiver) Check for continuity between terminal No 22 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the AcuraLink control unit (XM receiver) Check for continuity between terminal No 23 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the AcuraLink control unit (XM receiver) AcuraLink control unit (XM receiver) connector A (32P) disconnected Check for continuity between terminal No 24 of AcuraLink control unit(XM receiver) connector A (32P) and body ground There should be no continuity A short in the HandsFreeLink control unit Check for continuity between terminal No 25 of AcuraLink control unit(XM receiver) connector A (32P) and body ground There should be no continuity A short in the HandsFreeLink control unit Check for continuity between terminal No 22 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the HandsFreeLink control unit Check for continuity between terminal No 23 of AcuraLink control unit(XM receiver) connector A (32P) and body ground There should be no continuity A short in the HandsFreeLink control unit Audio Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) Audio-navigation unit connector C (14P) Check for continuity between terminal No 30 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 9 of audio-navigation unit connector C (HP) There should be continuity An open in the wire Check for continuity between terminal No 31 of AcuraLink control unit (XM receiver) connector A (32P) and terminal No 10 of audio-navigation unit connector C (HP) There should be continuity An open in the wire Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) Audio-navigation unit connector C (14P) Navigation display unit 32P connector HandsFreeLink control unit 28P connector Check for continuity between terminal No 30 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the wire Check for continuity between terminals No 1 and No 30 of AcuraLink control unit (XM receiver) connector A (32P) There should be no continuity A short to power in the wire Check for continuity between terminal No 31 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the wire Check for continuity between terminals No 1 and No 31 of AcuraLink control unit (XM receiver) connector A (32P) There should be no continuity A short to power in the wire Disconnect these items Audio-navigation unit connector C (14P) Navigation display unit 32P connector HandsFreeLink control unit 28P connector Check for continuity between terminal No 30 of AcuraLink control unit(XM receiver) connector A (32P) and body ground There should be no continuity A short in the AcuraLink control unit (XM receiver) Check for continuity between terminal No 31 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the AcuraLink control unit (XM receiver) Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) Navigation display unit 32P connector HandsFreeLink control unit 28P connector Check for continuity between terminal No 30 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the audio-navigation unit Check for continuity between terminal No 31 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the audio-navigation unit Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) Audio-navigation unit connector C (14P) HandsFreeLink control unit 28P connector Check for continuity between terminal No 30 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the AcuraLink control unit (XM receiver) Check for continuity between terminal No 31 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the navigation display unit Disconnect these items AcuraLink control unit (XM receiver) connector A (32P) Audio-navigation unit connector C (14P) Navigation display unit 32P connector Check for continuity between terminal No 30 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the audio unit Check for continuity between terminal No 31 of AcuraLink control unit (XM receiver) connector A (32P) and body ground There should be no continuity A short in the HandsFreeLink control unit (1) With SH-AWD (2) With SH-AWD (3) Without SH-AWD NOTE: If the XM antenna connection condition is faulty, XM ANTENNA is indicated on the audio-navigation switch panel display
  8. If the indication does not go away, confirm DTCs, and refer to the relevant system troubleshooting and input tests

Canceling the Self-diagnostic Function

  1. Use the interface dial, select the Exit Diag Press the interface dial to cancel the self-diagnostic function

DTC B2240: XM Antenna Error

  1. Connect the HDS to the DLC (see «GENERAL TROUBLESHOOTING INFORMATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#acuralink) )
  2. Clear the DTC with the HDS
  3. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode and then back to ON (II), or the ON mode and wait 30 seconds or more
  4. Check for DTC with the HDS Is DTC B2240 indicated? YES -Go to step 5 NO -Intermittent failure, the XM antenna is OK at this time Check for poor connections or loose terminals at the AcuraLink control unit (XM receiver) and the XM antenna
  5. Check the XM antenna lead connection at the AcuraLink control unit (XM receiver) and at the XM antenna Is it connected properly? YES -Substitute a known-good XM antenna (see «XM ANTENNA REPLACEMENT»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ), and recheck If the symptom/indicated goes away, replace the original XM antenna If the symptom/indicated is still present, update the AcuraLink control unit (see «ACURALINK CONTROL UNIT UPDATE»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#acuralink) ) if it does not have the latest software, then recheck If the software is the latest, replace the AcuraLink control unit (XM receiver) (see «ACURALINK CONTROL UNIT (XM RECEIVER) REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ) NO -Reconnect the connector, and recheck the DTC

DTC B2248: HIP Power Supply Abnormal (more than 16 V)

  1. Connect the HDS to the DLC (see «GENERAL TROUBLESHOOTING INFORMATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#acuralink) )
  2. Clear the DTC with the HDS
  3. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode and then back to ON (II), or the ON mode
  4. Do the alternator and regulator troubleshooting (see «ALTERNATOR AND REGULATOR CIRCUIT TROUBLESHOOTING»(/acura/tl/iv-2008-2011/remont/charging-system/#charging-system__alternator-and-regulator-circuit-troubleshooting) ) Is the charging system OK? YES -Go to step 5 NO -Repair the charging system
  5. Check for DTC with the HDS Is DTC B2248 indicated? YES -Substitute a known-good AcuraLink control unit (XM receiver) (see «ACURALINK CONTROL UNIT (XM RECEIVER) REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ), and reset If the problem goes away, replace the original AcuraLink control unit(XM receiver) NO -Intermittent failure, HIP is OK at this time

Scheme 324

Scheme 324: DTC B2249: HIP Power Supply Abnormal (less than 9 V)
Scheme 324: DTC B2249: HIP Power Supply Abnormal (less than 9 V)
  1. Connect the HDS to the DLC (see «GENERAL TROUBLESHOOTING INFORMATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#acuralink) )
  2. Clear the DTC with the HDS
  3. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode and then back to ON (II), or the ON mode
  4. Check for DTC with the HDS Is DTC B2249 indicated? YES -Go to step 5 NO -Intermittent failure, HIP is OK at this time
  5. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
  6. Measure the voltage between AcuraLink control unit connector A (32P) terminals No 1 and No 28 Is there 9 V or less? YES -Faulty battery or +B line IMO-Substitute a known-good AcuraLink control unit (XM receiver) (see «ACURALINK CONTROL UNIT (XM RECEIVER) REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ), and retest If the problem goes away, replace the original AcuraLink control unit(XM receiver)

DTC U0100: F-CAN Lost Communication with ECM/PCM

  1. Connect the HDS to the DLC (see «GENERAL TROUBLESHOOTING INFORMATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#acuralink) )
  2. Clear the DTC with the HDS
  3. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode and then back to ON (II), or the ON mode
  4. Check for DTC with the HDS Is DTC U0100 indicated? YES -Go to step 5 NO -Intermittent failure, the F-CAN communication line is OK at this time. Check for poor connections or loose terminals at the AcuraLink control unit (XM receiver)
  5. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
  6. Disconnect AcuraLink control unit (XM receiver) connector A (32P)
  7. Jump the SCS line with the HDS
  8. Disconnect ECM/PCM connector A (49P)
  9. Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminals No. 6 and No. 7 and ECM/PCM connector A (49P) terminals No. 49 and No. 48 respectively Is there continuity? YES -Check for poor connections or loose terminals at the AcuraLink control unit (XM receiver). If all connections are OK, replace the AcuraLink control unit (XM receiver) (see «ACURALINK CONTROL UNIT (XM RECEIVER) REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ) NO -Repair an open in the wire between the AcuraLink control unit (XM receiver) and the ECM/PCM

Scheme 325

Scheme 325: DTC U0155: F-CAN Lost Communication with Gauge Control Module
Scheme 325: DTC U0155: F-CAN Lost Communication with Gauge Control Module
  1. Connect the HDS to the DLC (see «GENERAL TROUBLESHOOTING INFORMATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#acuralink) )
  2. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  3. Check for DTCs with the HDS and DTC log data in the navigation system diagnostic mode (see «SELF-DIAGNOSTIC FUNCTION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#acuralink__self-diagnostic-function) ) Is DTC U0155 indicated with HDS and on the navigation display? YES -Go to step 4 NO -Intermittent failure, the F-CAN communication line is OK at this time Check for poor connections or loose terminals at the AcuraLink control unit (XM receiver)
  4. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
  5. Disconnect AcuraLink control unit (XM receiver) connector A (32P) and the gauge control module 32P connector
  6. Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminals No 6 and No 7 and gauge control module 32P connector terminals No 9 and No 10 individually Is there continuity? YES -Check for poor connections or loose terminals at the AcuraLink control unit (XM receiver) If all connections are OK, update the AcuraLink control unit (see «ACURALINK CONTROL UNIT UPDATE»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#acuralink) ) if it does not have the latest software, then recheck If the software is the latest, replace the AcuraLink control unit (XM receiver) (see «ACURALINK CONTROL UNIT (XM RECEIVER) REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ) NO -Repair open in the wire between AcuraLink control unit (XM receiver) and gauge control module

Note. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN system diagnosis test mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A )

  1. Connect the HDS to the DLC (see «GENERAL TROUBLESHOOTING INFORMATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#acuralink) )
  2. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  3. Check for DTCs with the HDS and DTC log data in the navigation system diagnostic mode (see «SELF-DIAGNOSTIC FUNCTION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#acuralink__self-diagnostic-function) ) Is DTC U128D indicated with HDS and on the navigation display? YES -Go to step 4 NO -Intermittent failure, the B-CAN communication line is OK at this time Check for poor connections or loose terminals at the AcuraLink control unit (XM receiver)
  4. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
  5. Disconnect AcuraLink control unit (XM receiver) connector A (32P) and the gauge control module 32P connector
  6. Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminals No 8 and No 9 and gauge control module 32P connector terminals No 25 and No 26 respectively Is there continuity? YES -Check for poor connections or loose terminals at the AcuraLink control unit (XM receiver) If all connections are OK, update the AcuraLink control unit (see «ACURALINK CONTROL UNIT UPDATE»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#acuralink) ) if it does not have the latest software, then recheck If the software is the latest, replace the AcuraLink control unit (XM receiver) (see «ACURALINK CONTROL UNIT (XM RECEIVER) REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ) NO -Repair open in the wire between AcuraLink control unit (XM receiver) and gauge control module

Note. In order for the AcuraLink service to work, the client must have an activated account with XM (receives at least channels, 000, 001, 174, and 247) Verify the client account status by calling XM Satellite Radio at 800-852-9696

Scheme 326

Scheme 326: AcuraLink services do not work
Scheme 326: AcuraLink services do not work

Scheme 327

Scheme 327
Scheme 327

Scheme 328

Scheme 328
Scheme 328
  1. Check the No 15 (10 A) fuse in the under-hood fuse/relay box and the No 12 (7 5 A) fuse and the No 18 (7 5 A) fuse in the driver's under-dash fuse/relay box Are the fuses OK? YES -Go to step 2 NO -Replace the fuse(s), and recheck
  2. Turn the ignition switch to ACCESSORY (I), or press the engine start/stop button to select the ACC mode
  3. Measure the voltage between AcuraLink control unit (XM receiver) connector A (32P) terminal No 3 and body ground Is there battery voltage? YES -Go to step 4 NO -Repair open in the wire(s) between the AcuraLink control unit (XM receiver) and the No 18 (7 5 A) fuse in the driver's under-dash fuse/relay box
  4. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  5. Measure the voltage between AcuraLink control unit (XM receiver) connector A (32P) terminal No 2 and body ground Is there battery voltage? YES -Go to step 6 NO -Repair open in the wire(s) between the AcuraLink control unit (XM receiver) and the No 12 (7 5 A) fuse in the driver's under-dash fuse/relay box
  6. Measure the voltage between AcuraLink control unit (XM receiver) connector A (32P) terminal No 28 and body ground Is there less than 0.2 V? YES -Check for loose terminals or poor connections at the AcuraLink control unit (XM receiver) connector A (32P) If the connections are good, substitute a known-good AcuraLink control unit (XM receiver) (see «ACURALINK CONTROL UNIT (XM RECEIVER) REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ), and recheck If the symptom goes away, replace the original AcuraLink control unit(XM receiver) NO -Check for an open or high resistance in the wire between the AcuraLink control unit(XM receiver) and body ground If the wire is OK, check for poor ground at G501 (see «AUDIO WIRE HARNESS»(/acura/tl/iv-2008-2011/remont/body-electrical/#connectors-and-harnesses__audio-wire-harness) )

Scheme 329

Scheme 329: AcuraLink messages cannot be heard or are weak
Scheme 329: AcuraLink messages cannot be heard or are weak

Scheme 330

Scheme 330
Scheme 330

Scheme 331

Scheme 331
Scheme 331

Scheme 332

Scheme 332
Scheme 332
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
  2. Check that the audio system is operating normally and the speaker sound levels are normal from different audio sources (AM/FM, XM, CD/DVDs, navigation, etc) Does the audio system work normally and is the audio output from the speaker normal when playing various audio sources? YES -Go to step 3 NO -Refer to the audio system «SYMPTOM TROUBLESHOOTING»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system)
  3. Check the audio system when AcuraLink messages are played Does the audio system mute when AcuraLink messages are being played? YES -If audio system mutes and plays the messages at a normal volume, the system is OK at this time If the messages are weaker than normal, go to step 4 NO -Check for B-CAN codes Repair any B-CAN codes, then retest If there are no B-CAN codes, substitute a known-good AcuraLink control unit (XM receiver) (see «ACURALINK CONTROL UNIT (XM RECEIVER) REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) )
  4. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
  5. Disconnect AcuraLink control unit (XM receiver) connector A (32P) and audio-navigation unit connector C(14P)
  6. Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) and audio-navigation unit connector C (14P) according to the table CONNECTOR TERMINAL REFERENCE AcuraLink control unit (XM receiver) connector Audio-navigation unit connector Wire color A17 H23 WHT A18 H10 RED A19 H22 GRN A2 H9 BLK Is there continuity? YES -Go to step 7 NO -There is an open in the wire(s) between the AcuraLink control unit (XM receiver) and the audio-navigation unit Replace the affected shielded harness
  7. Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) and body ground according to the table CONNECTOR TERMINAL REFERENCE AcuraLink control unit (XM receiver) connector Wire color A17 WHT A18 RED A19 GRN A20 BLK Is there continuity? YES -There is short to body ground in the wire(s) between the AcuraLink control unit (XM receiver) and the audio-navigation unit Replace the affected shielded harness NO -Go to step 8
  8. Check for continuity between the terminal of AcuraLink control unit(XM receiver) connector A (32P) according to the table CONNECTOR TERMINAL REFERENCE From terminal To terminals A17 (WHT) A18 (RED), A19 (GRN), A20 (BLK), A21 (GRY) A18 (RED) A19 (GRN), A20 (BLK), A21 (GRY) A19 (GRN) A20 (BLK), A21 (GRY) A20 (BLK) A21 (GRY) Is there continuity between any of the terminals? YES -There is a short in the wires between the AcuraLink control unit (XM receiver) and the audio-navigation unit Replace the affected shielded harness NO -Go to step 9
  9. Measure the voltage between AcuraLink control unit (XM receiver) connector A (32P) and body ground according to the table CONNECTOR TERMINAL REFERENCE AcuraLink control unit (XM receiver) connector Wire color A17 WHT A18 RED A19 GRN A20 BLK Is there less than 0.2 V? YES -Go to step 10 NO -There is a short to power in the wire(s) between the AcuraLink control unit (XM receiver) and the audio-navigation unit Replace the affected shielded harness
  10. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
  11. Substitute a known-good AcuraLink control unit (XM receiver) (see «ACURALINK CONTROL UNIT (XM RECEIVER) REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ), and recheck the function Does the problem go away? YES -Update the AcuraLink control unit (see «ACURALINK CONTROL UNIT UPDATE»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#acuralink) ) if it does not have the latest software, then recheck If the software is the latest, replace the AcuraLink control unit (XM receiver) (see «ACURALINK CONTROL UNIT (XM RECEIVER) REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ) NO -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/navigation-system/#navigation-system__audio-navigation-unit-removalinstallation) )

Special Tools Required

  1. GNA600 kit and an iN workstation with AcuraLink update software
  2. 256 MB PCMCIA Memory Card
  3. AcuraLink Reprogramming Cable

Note. Before you update an AcuraLink control unit, read the procedure. The order of connecting and disconnecting connectors is critical, and some steps must be done within a specified period of time. If the steps are not followed exactly, you may have to repeat the procedure from the start, and in some cases, you may damage the GNA600 or the AcuraLink control unit Whenever you install a new AcuraLink control unit, you must update the AcuraLink control unit with the latest software The GNA600 is the only tool currently available to update the AcuraLink control unit If you are updating an AcuraLink control unit in a new vehicle, make sure all the fuses are installed Make sure the iN workstation has the latest HDS software installed (The AcuraLink update software is contained in the HDS update CD) The update may take up to 60 minutes You cannot update an AcuraLink control unit with its current or previous software versions. It will only accept a new software version Before you update the AcuraLink control unit, test the vehicle battery (see BATTERY TEST ), and only proceed if the results are good. Make sure the battery is connected to a battery booster (not a battery charger) while updating the AcuraLink control unit. If the battery is not in good condition, or it dies during the updating procedure, you may damage the AcuraLink control unit If you encounter errors in the software, follow the onscreen instructions, or if necessary, reboot the iN workstation, and try again There are five process involved in updating the AcuraLink control unit Setting up the GNA600 Capturing the current program ID from the AcuraLink control unit Download the new software to the GNA600 Update the software in the vehicle's AcuraLink control unit Confirm the AcuraLink self-diagnosis While updating the AcuraLink control unit, do not turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode To prevent damage to the AcuraLink control unit, do not operate anything electrical (brakes, head lights, etc) during the update Check any official Honda service website for more service information about updating the AcuraLink control unit To update the AcuraLink control unit, you must connect the GNA600 to the AcuraLink update connector (A), not the DLC

Scheme 333

Scheme 333
Scheme 333
  1. Make sure the ignition switch is in LOCK (0), or engine start/stop button is in the OFF mode
  2. Remove the glove box (see «GLOVE BOX REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#dashboard__glove-box-removalinstallation) )
  3. Launch the AcuraLink Update program, and follow the on-screen instructions to complete the update

Note. If the software in the AcuraLink control unit is the latest, disconnect the update tool from the AcuraLink connector If the update is part of a troubleshooting or a repair procedure, return to that procedure and continue troubleshooting or repairing the vehicle

More articles — Accessories & Equipment
