Dash Lights Brightness Controller Acura TL III рестайлинг

Interior/illumination Lights 3 illustrations
Fig. 1: Dash Lights Brightness Controller - Circuit Diagram
Scheme 1: Dash Lights Brightness Controller - Circuit Diagram

Scheme 1

Scheme 1: Dash Lights Brightness Controller Test/Replacement
Scheme 1: Dash Lights Brightness Controller Test/Replacement

Scheme 2

Scheme 2
Scheme 2
  1. Remove the instrument panel (see «INSTRUMENT PANEL REMOVAL/INSTALLATION»(/acura/tl/iii-2006-2008/remont/gauges-instrument-panels/#dashboard-instrument-panel__instrument-panel-removalinstallation) ).
  2. Disconnect the 6P connector (A) from the dash lights brightness controller (B). (Scheme 1): Identifying Dash Lights Brightness Controller And 6P Connector
  3. Remove the two screws and the dash lights brightness controller.
  4. Check for continuity between the terminals in each switch position according to the table. (Scheme 2): Terminals Continuity Chart
  5. If the continuity is not as specified, replace the switch.
  6. If the bulb(s) (C) are faulty, replace the bulb(s).
