Power Relay Test
Use this chart to identify the type of relay, then do the test listed for it.
Note. For the turn signal/ hazard relay input test (see TURN SIGNAL/HAZARD RELAY INPUT TEST ).
| Relay | Test |
|---|---|
| Accessory power socket relay | Normally-open type |
| A/C compressor clutch relay | |
| A/C condenser fan relay | |
| A/ F sensor relay | |
| Blower motor relay | |
| Daytime running lights relay | |
| Fog light relay | |
| Ignition coil relay | |
| PGM-FI main relay 1, 2 | |
| Power window relay | |
| Radiator fan relay | |
| Rear window defogger relay | |
| Seat heater relay | |
| Starter cut relay 1, 2 (1) | |
| Throttle actuator control module relay | |
| ACC cut relay (1) | Five-terminal type |
| Fan control relay | |
| IG2 cut relay (1) | |
| (1) A/T | |
| (1) | A/T |
POWER RELAY REFERENCE
Normally-open type
Check for continuity between the terminals.
Scheme 2
- There should be continuity between the No. 1 and No. 2 terminals when power and ground are connected to the No. 3 and No. 4 terminals.
- There should be no continuity between the No. 1 and No. 2 terminals when power is disconnected.
Five-terminal type
Check for continuity between the terminals.
Scheme 3
- There should be continuity between the No. 1 and No. 2 terminals when battery positive terminal is connected to the No. 5 terminal, and battery negative terminal is connected to the No. 3 terminal.
- There should be continuity between the No. 1 and No. 4 terminals when power is disconnected.
