Power Mirrors Acura TL III

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

1. Remove the driver's dashboard lower cover (see «DRIVER'S DASHBOARD LOWER COVER REMOVAL/INSTALLATION»(/acura/tl/iii-2003-2006/remont/exteriorinterior-trim/#dashboard) ).
2. Disconnect the 13P connector (A) from the power mirror switch (B).
3. Check for continuity between the terminals in each switch position according to the table. Mirror Switch: Defogger Switch
4. If the continuity is not as specified, remove the screws and replace the power mirror switch.

Power Mirror Actuator Test

Note. The power mirror actuator can be tested by using the HDS by following these steps

1. Select BODY ELECTRICAL from the SYSTEM SELECTION MENU.
2. Select FUNCTION TESTS, and then the appropriate power mirror function test.

Scheme 19

Scheme 20

1. Remove the door panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(/acura/tl/iii-2003-2006/remont/windows/#door-system__front-door-panel-removalinstallation) ).
2. Disconnect the 13P connector (A) from the power mirror (B).
3. Check actuator operation by connecting power and ground according to the table.
4. If the mirror fails to work properly, replace the mirror actuator.

Defogger Test

1. 5. Check for continuity between the No. 5 and No. 4 terminals of the 13P connector. There should be continuity with the defogger switch ON. If there is no continuity, check for an open circuit.

Scheme 21

Scheme 22

Scheme 23

1. Remove the mirror holder (see «POWER MIRROR REPLACEMENT»(/acura/tl/iii-2003-2006/remont/mirrors/#mirrors) ), power mirror (see «POWER MIRROR REPLACEMENT»(/acura/tl/iii-2003-2006/remont/mirrors/#mirrors) ), and disconnect the connectors.
2. Remove the gasket (A).
3. Record the terminal location and wire harness colors, then cut the wire harness with cutter.
4. Remove the three Torx screws, and separate the power mirror actuator (A) from the housing (B).
5. Remove the screws and separate the mirror housing (A) and the bracket (B).

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

1. 6. Route a new actuator harness (A) through the bracket (B).
2. 7. Install the bracket (A) on the mirror housing (B).
3. 8. Install the mirror actuator (A) to the bracket (B).
4. 9. Route the wire harness (A) through the hole of the gasket (B), then install the gasket.
5. 10. Insert the terminals into the connector in the original arrangement as shown.
6. 11. Reassemble in the reverse order of disassembly. Be careful not to break the mirror holder when reinstalling it to the actuator (see «POWER MIRROR REPLACEMENT»(/acura/tl/iii-2003-2006/remont/mirrors/#mirrors) ).
7. 12. Reinstall the mirror assembly to the door.
8. 13. Operate the power mirror to ensure smooth operation.
