Evap System Acura TL III

Auxiliary Emission Control Systems 53 illustrations ~8454 words

Scheme 130

Scheme 130: Component Location Index
Scheme 130: Component Location Index

DTC Troubleshooting

DTCDescription
DTC P0442, P0456EVAP System Small Leak Detected, EVAP System Very Small Leak Detected
DTC P0443EVAP Canister Purge Valve Circuit Malfunction
DTC P0451FTP Sensor Circuit Range/Performance Problem
DTC P0452FTP Sensor Circuit Low Voltage (2004-2005 Models)
DTC P0452FTP Sensor Circuit Low Voltage (2006 Model)
DTC P0453FTP Sensor Circuit High Voltage (2004-2005 Models)
DTC P0453FTP Sensor Circuit High Voltage (2006 Model)
DTC P0457EVAP System Leak Detected/Fuel Fill Cap Loose or Missing
DTC P0496EVAP System High Purge Flow
DTC P0497EVAP System Low Purge Flow
DTC P0498EVAP Canister Vent Shut Valve Circuit Low Voltage (2004-2005 Models)
DTC P0498EVAP Canister Vent Shut Valve Circuit Low Voltage (2006 Model)
DTC P0499EVAP Canister Vent Shut Valve Circuit High Voltage
DTC P1454, P2422FTP Sensor Circuit Range/Performance Problem, EVAP Canister Vent Shut Valve Stuck Closed Malfunction

DTC TROUBLESHOOTING INDEX

Note. The fuel system is designed to allow specified maximum vacuum and pressure conditions. Do not deviate from the vacuum and pressure tests as indicated in these procedures. Excessive pressure/vacuum would damage the EVAP components or cause eventual fuel tank failure.

Special Tools Required

  1. Vacuum pump/gauge, 0-30 in.Hg, Snap-on YA4000A or equivalent, commercially available
  2. Vacuum/pressure gauge, 0-4 in.Hg, 07JAZ-001000B

Note. Fresh fuel has a higher volatility that will create greater pressure/vacuum. The optimum condition for testing is less than a full tank of fresh fuel, If possible, to assist in leak detection, add 1 gallon of fresh fuel to the tank (as long as it will not fill the tank), just before starting these procedures. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 131

Scheme 131
Scheme 131

Scheme 132

Scheme 132
Scheme 132

Scheme 133

Scheme 133
Scheme 133

Scheme 134

Scheme 134
Scheme 134
  1. Check the fuel fill cap (the cap must say "Tighten to click"). It should turn 1/4 turn after it's tight, then it clicks. Is the correct fuel fill cap installed and properly tightened? YES - Go to step 2 . NO - Replace or tighten the fuel fill cap, then go to step 22 .
  2. Check the fuel fill cap seal (A) and the fuel fill pipe mating surface (B). Verify that the fuel fill cap tether cord (C) is not caught under the cap. Is the fuel fill cap seal missing or damaged, is the fuel fill pipe damaged, or is the tether cord caught under the cap? YES - Replace the fuel fill cap or the fuel fill pipe, then go to step 22 . NO - Go to step 3 .
  3. Turn the ignition switch ON (II).
  4. Clear the DTC with the HDS.
  5. Do the EVAP FUNCTION TEST in the INSPECTION MENU with the HDS. Is the result OK? YES - Intermittent failure, system is OK at this time. Check for poor connections or loose terminals at the FTP sensor, the EVAP canister purge valve, or the EVAP canister vent shut valve and the ECM/PCM. NO - Go to step 6 .
  6. Turn the ignition switch OFF.
  7. Turn the ignition switch ON (II).
  8. Check for a poor connection or damage at the fuel tank vapor recirculation tube. Is the tube OK? YES - Go to step 9 . NO - Replace the fuel tank vapor recirculation tube, then go to step 22 . If necessary, replace the fuel tank (see «FUEL TANK REPLACEMENT»(/acura/tl/iii-2003-2006/remont/fuel-system/#fuel-supply-system) ), then go to step 22 .
  9. Disconnect the fuel tank vapor recirculation tube (A) from the EVAP canister (B), and plug the EVAP canister port (C).
  10. Disconnect the vacuum hose (purge line) (A) from the EVAP canister purge valve (B) in the engine compartment, and connect a T-fitting (C) from the vacuum gauge and the vacuum pump/gauge, 0-30 in.Hg, to the vacuum hose (A) as shown.
  11. Select EVAP CVS ON in the INSPECTION MENU with the HDS.
  12. Apply vacuum to the hose until the FTP reads 1.90 V or -2.0 kPa (-0.59 in.Hg, -15.1 mmHg).
  13. Monitor the FTP SENSOR in the DATA LIST for 1 minute with the HDS. Does the voltage increase more than 0.2 V or 0.3 kPa (0.1 in.Hg, 2.5 mmHg)? YES - Go to step 14 . NO - Go to step 19 .
  14. Select EVAP CVS OFF in the INSPECTION MENU with the HDS.
  15. Disconnect the fresh air hose (A) from the EVAP canister vent shut valve (B), and plug the EVAP canister vent shut valve port (C).
  16. Apply vacuum to the EVAP system until the FTP reads 1.90 V or -2.0 kPa (-0.59 in.Hg, -15.1 mmHg).
  17. Monitor the FTP SENSOR in the DATA LIST for 1 minute with the HDS. Does the voltage increase more than 0.2 V or 0.3 kPa (0.1 in.Hg, 2.5 mmHg)? YES - Go to step 18 . NO - Replace the EVAP canister vent shut valve, then go to step 21 .
  18. Check for a loose or damaged EVAP canister purge line between the EVAP canister and the EVAP canister purge valve. Is the line OK? YES - Replace the following parts, then go to step 21 . FTP sensor O-ring EVAP canister vent shut valve case and O-ring EVAP canister NO - Reconnect or repair the EVAP canister purge line, then go to step 21 .
  19. Select EVAP CVS OFF in the INSPECTION MENU with the HDS.
  20. Check these parts for looseness or damage: Fuel fill pipe Fuel vapor return pipe Are the parts OK? YES - Check the fuel tank unit base gasket (see «FUEL PUMP/FUEL GAUGE SENDING UNIT REPLACEMENT»(/acura/tl/iii-2003-2006/remont/fuel-system/#fuel-supply-system__fuel-pumpfuel-gauge-sending-unit-replacement) ), and check the fuel tank, then go to step 21 . NO - Repair or replace the damaged parts, then go to step 21 .
  21. Reconnect all hoses and connectors.
  22. Turn the ignition switch ON (II).
  23. Reset the ECM/PCM with the HDS.
  24. Do the ECM/PCM idle learn procedure (see «ECM/PCM IDLE LEARN PROCEDURE»(/acura/tl/iii-2003-2006/remont/testing-diagnostics/#idle-control-system__ecmpcm-idle-learn-procedure) ).
  25. Do the EVAP FUNCTION TEST in the INSPECTION MENU with the HDS. Is the result OK? YES - Troubleshooting is complete. NO - Check for poor connections or loose terminals at the FTP sensor, the EVAP canister purge valve, or the EVAP canister vent shut valve and the ECM/PCM, then go to step 1 .

DTC P0443: EVAP Canister Purge Valve Circuit Malfunction

Special Tools Required

Vacuum pump/gauge, 0-30 in.Hg, Snap-on YA4000A or equivalent, commercially available

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 135

Scheme 135: DTC P0443: EVAP Canister Purge Valve Circuit Malfunction
Scheme 135: DTC P0443: EVAP Canister Purge Valve Circuit Malfunction

Scheme 136

Scheme 136
Scheme 136

Scheme 137

Scheme 137
Scheme 137

Scheme 138

Scheme 138
Scheme 138

Scheme 139

Scheme 139
Scheme 139

Scheme 140

Scheme 140
Scheme 140

Scheme 141

Scheme 141
Scheme 141
  1. Turn the ignition switch ON (II).
  2. Clear the DTC with the HDS.
  3. Start the engine. Hold the engine speed at 3,000 rpm without load (in Park or neutral) until the radiator fan comes on, then let it idle.
  4. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0443 indicated? YES - Go to step 5 . NO - Intermittent failure, system is OK at this time. Check for poor connections or loose terminals at the EVAP canister purge valve and the ECM/PCM.
  5. Turn the ignition switch OFF, and allow the engine to cool to below 149°F (65°C).
  6. Disconnect the vacuum hose (A) from the EVAP purge valve service port (B) in the engine compartment, and connect a vacuum pump/gauge, 0-30 in.Hg, to the hose.
  7. Start the engine, and let it idle. Is there vacuum? YES - Go to step 8 . NO - Go to step 14 .
  8. Turn the ignition switch OFF.
  9. Disconnect the EVAP canister purge valve 2P connector.
  10. Check for continuity between EVAP canister purge valve 2P connector terminal No. 1 and body ground. Is there continuity? YES - Go to step 11 . NO - Go to step 24 .
  11. Jump the SCS line with the HDS.
  12. Disconnect ECM/PCM connector B (24P).
  13. Check for continuity between EVAP canister purge valve 2P connector terminal No. 1 and body ground. Is there continuity? YES - Repair short in the wire between the EVAP canister purge valve and the ECM/PCM (B2), then go to step 25 . NO - Go to step 31 .
  14. Turn the ignition switch OFF.
  15. Disconnect the EVAP canister purge valve 2P connector.
  16. Turn the ignition switch ON (II).
  17. Measure voltage between EVAP canister purge valve 2P connector terminal No. 2 and body ground. Is there battery voltage? YES - Go to step 18 . NO - Repair open in the wire between the EVAP canister purge valve and the No. 18 IG ACG (15 A) fuse in the under-dash fuse/relay box, then go to step 25 .
  18. Turn the ignition switch OFF.
  19. Jump the SCS line with the HDS.
  20. Disconnect ECM/PCM connector B (24P).
  21. Connect EVAP canister purge valve 2P connector terminal No. 1 to body ground with a jumper wire.
  22. Check for continuity between ECM/PCM connector terminal B2 and body ground. Is there continuity? YES - Go to step 23 . NO - Repair open in the wire between the EVAP canister purge valve and the ECM/PCM (B2), then go to step 25 .
  23. Measure resistance between EVAP canister purge valve 2P connector terminals No. 1 and No. 2. Is there about 33ohm at room temperature? YES - Go to step 31 . NO - Go to step 24 .
  24. Replace the EVAP canister purge valve (see «EVAP CANISTER PURGE VALVE REPLACEMENT»(/acura/tl/iii-2003-2006/remont/auxiliary-emission-control-systems/#evap-system) ).
  25. Reconnect all connectors.
  26. Turn the ignition switch ON (II).
  27. Reset the ECM/PCM with the HDS.
  28. Do the ECM/PCM idle learn procedure (see «ECM/PCM IDLE LEARN PROCEDURE»(/acura/tl/iii-2003-2006/remont/testing-diagnostics/#idle-control-system__ecmpcm-idle-learn-procedure) ).
  29. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P0443 is indicated, check for poor connections or loose terminals at the EVAP canister purge valve and the ECM/PCM, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTC's troubleshooting. NO - Go to step 30 .
  30. Monitor the OBD STATUS for DTC P0443 in the DTCs MENU with the HDS. Does the screen indicate PASSED? YES - Troubleshooting is complete. NO - If the screen indicates FAILED, check for poor connections or loose terminals at the EVAP canister purge valve and the ECM/PCM, then go to step 1 . If the screen indicates EXECUTING, keep idling until a result comes on. If the screen indicates OUT OF CONDITION, go to step 29 and recheck.
  31. Update the ECM/PCM if it does not have the latest software, or substitute a known-good ECM/PCM (see «HOW TO TROUBLESHOOT CIRCUITS AT THE ECM/PCM»(/acura/tl/iii-2003-2006/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__how-to-troubleshoot-circuits-at-the) )
  32. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P0443 is indicated, check for poor connections or loose terminals at the EVAP canister purge valve and the ECM/PCM, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTC's troubleshooting. NO - If the ECM/PCM was updated, troubleshooting is complete. If the ECM/PCM was substituted, replace the original ECM/PCM (see «ECM/PCM REPLACEMENT»(/acura/tl/iii-2003-2006/remont/testing-diagnostics/#pgm-fi-system) ).

DTC P0451: FTP Sensor Circuit Range/Performance Problem

Note. If DTC P2422 is stored at the same time as DTC P0451, troubleshoot DTC P2422 first, then recheck for DTC P0451. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

  1. Turn the ignition switch ON (II).
  2. Clear the DTC with the HDS.
  3. Start the engine, and let it idle 1 minute.
  4. Monitor the OBD STATUS for DTC P0451 in the DTCs MENU with the HDS. Does the screen indicate FAILED? YES - Go to step 5 . NO - If the screen indicates PASSED, intermittent failure, system is OK at this time. Check for poor connections or loose terminals at the FTP sensor and the ECM/PCM. If the screen indicates NOT COMPLETED, go to step 3 and recheck.
  5. Turn the ignition switch OFF.
  6. Replace the FTP sensor (see «FTP SENSOR REPLACEMENT»(/acura/tl/iii-2003-2006/remont/auxiliary-emission-control-systems/#evap-system) ).
  7. Turn the ignition switch ON (II).
  8. Reset the ECM/PCM with the HDS.
  9. Do the «ECM/PCM IDLE LEARN PROCEDURE»(/acura/tl/iii-2003-2006/remont/testing-diagnostics/#idle-control-system__ecmpcm-idle-learn-procedure) .
  10. Start the engine, and let it idle 1 minute.
  11. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES -If DTC P0451 is indicated, check for poor connections or loose terminals at the FTP sensor and the ECM/PCM, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTC's troubleshooting. NO - Go to step 12 .
  12. Monitor the OBD STATUS for DTC P0451 in the DTCs MENU with the HDS. Does the screen indicate PASSED? YES - Troubleshooting is complete. NO - If the screen indicates FAILED, check for poor connections or loose terminals at the FTP sensor and the ECM/PCM, then go to step 1 . If the screen indicates NOT COMPLETED, go to step 10 and recheck.

DTC P0452: FTP Sensor Circuit Low Voltage (2004-2005 Models)

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 142

Scheme 142: DTC P0452: FTP Sensor Circuit Low Voltage (2004-2005 Models)
Scheme 142: DTC P0452: FTP Sensor Circuit Low Voltage (2004-2005 Models)

Scheme 143

Scheme 143
Scheme 143

Scheme 144

Scheme 144
Scheme 144
  1. Turn the ignition switch ON (II).
  2. Clear the DTC with the HDS.
  3. Turn the ignition switch OFF.
  4. Remove the fuel fill cap.
  5. Turn the ignition switch ON (II).
  6. Check the FTP SENSOR in the DATA LIST with the HDS. Is about - 7.3 kPa (-2.16 in.Hg, - 55 mmHg), or 0.3 V or less indicated? YES - Go to step 10 . NO - Go to step 7 .
  7. Install the fuel fill cap.
  8. Start the engine.
  9. Monitor the OBD STATUS for DTC P0452 in the DTCs MENU with the HDS. Does the screen indicate FAILED? YES - Go to step 10 . NO - If the screen indicates PASSED, intermittent failure, system is OK at this time. Check for poor connections or loose terminals at the FTP sensor and the ECM/PCM. If the screen indicates NOT COMPLETED, go to step 5 . and recheck.
  10. Turn the ignition switch OFF.
  11. Disconnect the FTP sensor 3P connector.
  12. Turn the ignition switch ON (II).
  13. Check the FTP SENSOR in the DATA LIST with the HDS. Is about -7.3 kPa (-2.16 in.Hg, -55 mmHg), or 0.3 V or less indicated? YES - Go to step 20 . NO - Go to step 14 .
  14. Measure voltage between FTP sensor 3P connector terminal No. 1 and body ground. Is there about 5 V? YES - Go to step 16 . NO - Go to step 15 .
  15. Measure voltage between ECM/PCM connector terminal A12 and body ground. Is there about 5 V? YES - Repair open in the wire between the ECM/PCM (A12) and the FTP sensor, then go to step 22 . NO - Go to step 28 .
  16. Turn the ignition switch OFF.
  17. Jump the SCS line with the HDS.
  18. Disconnect ECM/PCM connector A (31P).
  19. Check for continuity between FTP sensor 3P connector terminal No. 2 and body ground. Is there continuity? YES - Repair short in the wire between the ECM/PCM (A29) and the FTP sensor, then go to step 22 . NO - Go to step 28 .
  20. Turn the ignition switch OFF.
  21. Replace the FTP sensor (see «FTP SENSOR REPLACEMENT»(/acura/tl/iii-2003-2006/remont/auxiliary-emission-control-systems/#evap-system) ).
  22. Reconnect all connectors.
  23. Turn the ignition switch ON (II).
  24. Reset the ECM/PCM with the HDS.
  25. Do the «ECM/PCM IDLE LEARN PROCEDURE»(/acura/tl/iii-2003-2006/remont/testing-diagnostics/#idle-control-system__ecmpcm-idle-learn-procedure) ).
  26. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P0452 is indicated, check for poor connections or loose terminals at the FTP sensor and the ECM/PCM, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTC's troubleshooting. NO - Go to step 27 .
  27. Monitor the OBD STATUS for DTC P0452 in the DTCs MENU with the HDS. Does the screen indicate PASSED? YES - Troubleshooting is complete. NO - If the screen indicates FAILED, check for poor connections or loose terminals at the FTP sensor and the ECM/PCM, then go to step 1 . If the screen indicates NOT COMPLETED, go to step 25 and recheck.
  28. Update the ECM/PCM if it does not have the latest software, or substitute a known-good ECM/PCM (see «HOW TO TROUBLESHOOT CIRCUITS AT THE ECM/PCM»(/acura/tl/iii-2003-2006/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__how-to-troubleshoot-circuits-at-the) ).
  29. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P0452 is indicated, check for poor connections or loose terminals at the FTP sensor and the ECM/PCM, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTC's troubleshooting. NO - If the ECM/PCM was updated, troubleshooting is complete. If the ECM/PCM was substituted, replace the original ECM/PCM (see «ECM/PCM REPLACEMENT»(/acura/tl/iii-2003-2006/remont/testing-diagnostics/#pgm-fi-system) ).

DTC P0452: FTP Sensor Circuit Low Voltage (2006 Model)

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 145

Scheme 145: DTC P0452: FTP Sensor Circuit Low Voltage (2006 Model)
Scheme 145: DTC P0452: FTP Sensor Circuit Low Voltage (2006 Model)

Scheme 146

Scheme 146
Scheme 146

Scheme 147

Scheme 147
Scheme 147
  1. Turn the ignition switch ON (II).
  2. Clear the DTC with the HDS.
  3. Turn the ignition switch OFF.
  4. Remove the fuel fill cap.
  5. Turn the ignition switch ON (II).
  6. Check the FTP SENSOR in the DATA LIST with the HDS. Is about -7.3 kPa (-2.16 in.Hg, -55 mmHg), or 0.3 V or less Indicated? YES - Go to step 10 . NO - Go to step 7 .
  7. Install the fuel fill cap.
  8. Start the engine.
  9. Monitor the OBD STATUS for DTC P0452 in the DTCs MENU with the HDS. Does the screen indicate FAILED? YES - Go to step 10 . NO - If the screen indicates PASSED, intermittent failure, system is OK at this time. Check for poor connections or loose terminals at the FTP sensor and the ECM/PCM. If the screen indicates NOT COMPLETED, go to step 5 . and recheck.
  10. Turn the ignition switch OFF.
  11. Disconnect the FTP sensor 3P connector.
  12. Turn the ignition switch ON (II).
  13. Check the FTP SENSOR in the DATA LIST with the HDS. Is about - 7.3 kPa (-2.16 in.Hg, - 55 mmHg), or 0.3 V or less indicated? YES - Go to step 20 . NO - Go to step 14 .
  14. Measure voltage between FTP sensor 3P connector terminal No. 1 and body ground. Is there about 5 V? YES - Go to step 16 . NO - Go to step 15 .
  15. Measure voltage between ECM/PCM connector terminal E12 and body ground. Is there about 5 V? YES - Repair open in the wire between the ECM/PCM (E12) and the FTP sensor, then go to step 22 . NO - Go to step 28 .
  16. Turn the ignition switch OFF.
  17. Jump the SCS line with the HDS.
  18. Disconnect ECM/PCM connector E (31P).
  19. Check for continuity between FTP sensor 3P connector terminal No. 2 and body ground. Is there continuity? YES - Repair short in the wire between the ECM/PCM (E29) and the FTP sensor, then go to step 22 . NO - Go to step 28 .
  20. Turn the ignition switch OFF.
  21. Replace the FTP sensor (see «FTP SENSOR REPLACEMENT»(/acura/tl/iii-2003-2006/remont/auxiliary-emission-control-systems/#evap-system) ).
  22. Reconnect all connectors.
  23. Turn the ignition switch ON (II).
  24. Reset the ECM/PCM with the HDS.
  25. Do the «ECM/PCM IDLE LEARN PROCEDURE»(/acura/tl/iii-2003-2006/remont/testing-diagnostics/#idle-control-system__ecmpcm-idle-learn-procedure) ).
  26. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P0452 is indicated, check for poor connections or loose terminals at the FTP sensor and the ECM/PCM, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTC's troubleshooting. NO - Go to step 27 .
  27. Monitor the OBD STATUS for DTC P0452 in the DTCs MENU with the HDS. Does the screen indicate PASSED? YES - Troubleshooting is complete. NO - If the screen indicates FAILED, check for poor connections or loose terminals at the FTP sensor and the ECM/PCM, then go to step 1 . If the screen indicates NOT COMPLETED, go to step 25 and recheck.
  28. Update the ECM/PCM if it does not have the latest software, or substitute a known-good ECM/PCM (see «HOW TO TROUBLESHOOT CIRCUITS AT THE ECM/PCM»(/acura/tl/iii-2003-2006/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__how-to-troubleshoot-circuits-at-the) ).
  29. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P0452 is indicated, check for poor connections or loose terminals at the FTP sensor and the ECM/PCM, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting. NO - If the ECM/PCM was updated, troubleshooting is complete. If the ECM/PCM was substituted, replace the original ECM/PCM (see «ECM/PCM REPLACEMENT»(/acura/tl/iii-2003-2006/remont/testing-diagnostics/#pgm-fi-system) ).

DTC P0453: FTP Sensor Circuit High Voltage (2004-2005 Models)

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 148

Scheme 148: DTC P0453: FTP Sensor Circuit High Voltage (2004-2005 Models)
Scheme 148: DTC P0453: FTP Sensor Circuit High Voltage (2004-2005 Models)

Scheme 149

Scheme 149
Scheme 149

Scheme 150

Scheme 150
Scheme 150

Scheme 151

Scheme 151
Scheme 151

Scheme 152

Scheme 152
Scheme 152
  1. Turn the ignition switch ON (II).
  2. Clear the DTC with the HDS.
  3. Turn the ignition switch OFF.
  4. Remove the fuel fill cap.
  5. Turn the ignition switch ON (II).
  6. Check the FTP SENSOR in the DATA LIST with the HDS. Is about 7.3 kPa (2.16 in.Hg, 55 mmHg), or 4.7 V or more indicated? YES -Go to step 10 . NO - Go to step 7 .
  7. Install the fuel fill cap.
  8. Start the engine.
  9. Monitor the OBD STATUS for DTC P0453 in the DTCs MENU with the HDS. Does the screen indicate FAILED? YES - Go to step 10 . NO - If the screen indicates PASSED, intermittent failure, system is OK at this time. Check for poor connections or loose terminals at the FTP sensor and the ECM/PCM. If the screen indicates NOT COMPLETED, go to step 6 and recheck.
  10. Turn the ignition switch OFF.
  11. Disconnect the FTP sensor 3P connector.
  12. Connect FTP sensor 3P connector terminals No. 2 and No. 3 with a jumper wire.
  13. Turn the ignition switch ON (II).
  14. Check the FTP SENSOR in the DATA LIST with the HDS. Is about 7.3 kPa (2.16 in.Hg, 55 mmHg), or 4.7 V or more indicated? YES - Go to step 15 . NO - Go to step 25 .
  15. Measure voltage between FTP sensor 3P connector terminals No. 1 and No. 3. Is there about 5 V? YES - Go to step 21 . NO - Go to step 16 .
  16. Turn the ignition switch OFF.
  17. Jump the SCS line with the HDS.
  18. Disconnect ECM/PCM connector A (31P).
  19. Connect FTP sensor 3P connector terminal No. 3 to body ground with a jumper wire.
  20. Check for continuity between ECM/PCM connector terminal A1 and body ground. Is there continuity? YES - Go to step 33 . NO - Repair open in the wire between the ECM/PCM (A1) and the FTP sensor, then go to step 27 .
  21. Turn the ignition switch OFF.
  22. Connect ECM/PCM connector terminals A1 and A29 with a jumper wire.
  23. Turn the ignition switch ON (II).
  24. Check the FTP SENSOR in the DATA LIST with the HDS. Is about 7.3 kPa (2.16 in.Hg, 55 mmHg), or 4.7 V or more indicated? YES - Go to step 33 . NO - Repair open in the wire between the ECM/PCM (A29) and the FTP sensor, then go to step 27 .
  25. Turn the ignition switch OFF.
  26. Replace the FTP sensor (see «FTP SENSOR REPLACEMENT»(/acura/tl/iii-2003-2006/remont/auxiliary-emission-control-systems/#evap-system) ).
  27. Reconnect all connectors.
  28. Turn the ignition switch ON (II).
  29. Reset the ECM/PCM with the HDS.
  30. Do the «ECM/PCM IDLE LEARN PROCEDURE»(/acura/tl/iii-2003-2006/remont/testing-diagnostics/#idle-control-system__ecmpcm-idle-learn-procedure) .
  31. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P0453 is indicated, check for poor connections or loose terminals at the FTP sensor and the ECM/PCM, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTC's troubleshooting. NO - Go to step 32 .
  32. Monitor the OBD STATUS for DTC P0453 in the DTCs MENU with the HDS. Does the screen indicate PASSED? YES - Troubleshooting is complete. NO - If the screen indicates FAILED, check for poor connections or loose terminals at the FTP sensor and the ECM/PCM, then go to step 1 . If the screen indicates NOT COMPLETED, go to step 30 and recheck.
  33. Update the ECM/PCM if it does not have the latest software, or substitute a known-good ECM/PCM (see «HOW TO TROUBLESHOOT CIRCUITS AT THE ECM/PCM»(/acura/tl/iii-2003-2006/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__how-to-troubleshoot-circuits-at-the) ).
  34. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P0453 is indicated, check for poor connections or loose terminals at the FTP sensor and the ECM/PCM, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTC's troubleshooting. NO - If the ECM/PCM was updated, troubleshooting is complete. If the ECM/PCM was substituted, replace the original ECM/PCM (see «ECM/PCM REPLACEMENT»(/acura/tl/iii-2003-2006/remont/testing-diagnostics/#pgm-fi-system) ).

DTC P0453: FTP Sensor Circuit High Voltage (2006 Model)

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 153

Scheme 153: DTC P0453: FTP Sensor Circuit High Voltage (2006 Model)
Scheme 153: DTC P0453: FTP Sensor Circuit High Voltage (2006 Model)

Scheme 154

Scheme 154
Scheme 154

Scheme 155

Scheme 155
Scheme 155

Scheme 156

Scheme 156
Scheme 156

Scheme 157

Scheme 157
Scheme 157
  1. Turn the ignition switch ON (II).
  2. Clear the DTC with the HDS.
  3. Turn the ignition switch OFF.
  4. Remove the fuel fill cap.
  5. Turn the ignition switch ON (II).
  6. Check the FTP SENSOR in the DATA LIST with the HDS. Is about 7.3 kPa (2.16 in.Hg, 55 mmHg), or 4.7 V or more indicated? YES - Go to step 10 . NO - Go to step 7 .
  7. Install the fuel fill cap.
  8. Start the engine.
  9. Monitor the OBD STATUS for DTC P0453 in the DTCs MENU with the HDS. Does the screen indicate FAILED? YES - Go to step 10 . NO - If the screen indicates PASSED, intermittent failure, system is OK at this time. Check for poor connections or loose terminals at the FTP sensor and the ECM/PCM. If the screen indicates NOT COMPLETED, go to step 6 . and recheck.
  10. Turn the ignition switch OFF.
  11. Disconnect the FTP sensor 3P connector.
  12. Connect FTP sensor 3P connector terminals No. 2 and No. 3 with a jumper wire.
  13. Turn the ignition switch ON (II).
  14. Check the FTP SENSOR in the DATA LIST with the HDS. Is about 7.3 kPa (2.16 in.Hg, 55 mmHg), or 4.7 V or more indicated? YES - Go to step 15 . NO - Go to step 25 .
  15. Measure voltage between FTP sensor 3P connector terminals No. 1 and No. 3. Is there about 5 V? YES - Go to step 21 . NO - Go to step 16 .
  16. Turn the ignition switch OFF.
  17. Jump the SCS line with the HDS.
  18. Disconnect ECM/PCM connector E (31P).
  19. Connect FTP sensor 3P connector terminal No. 3 to body ground with a jumper wire.
  20. Check for continuity between ECM/PCM connector terminal E1 and body ground. Is there continuity? YES - Go to step 1 . NO - Repair open in the wire between the ECM/PCM (E1) and the FTP sensor, then go to step 27 .
  21. Turn the ignition switch OFF.
  22. Connect ECM/PCM connector terminals E1 and E29 with a jumper wire.
  23. Turn the ignition switch ON (II).
  24. Check the FTP SENSOR in the DATA LIST with the HDS. Is about 7.3 kPa (2.16 in.Hg, 55 mmHg), or 4.7 V or more indicated? YES - Go to step 1 . NO - Repair open in the wire between the ECM/PCM (E29) and the FTP sensor, then go to step 27 .
  25. Turn the ignition switch OFF.
  26. Replace the FTP sensor (see «FTP SENSOR REPLACEMENT»(/acura/tl/iii-2003-2006/remont/auxiliary-emission-control-systems/#evap-system) ).
  27. Reconnect all connectors.
  28. Turn the ignition switch ON (II).
  29. Reset the ECM/PCM with the HDS.
  30. Do the «ECM/PCM IDLE LEARN PROCEDURE»(/acura/tl/iii-2003-2006/remont/testing-diagnostics/#idle-control-system__ecmpcm-idle-learn-procedure) )
  31. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P0453 is indicated, check for poor connections or loose terminals at the FTP sensor and the ECM/PCM, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTC's troubleshooting. NO - Go to step 32 .
  32. Monitor the OBD STATUS for DTC P0453 in the DTCs MENU with the HDS. Does the screen indicate PASSED? YES - Troubleshooting is complete. NO - If the screen indicates FAILED, check for poor connections or loose terminals at the FTP sensor and the ECM/PCM, then go to step 1 . If the screen indicates NOT COMPLETED, go to step 30 and recheck.
  33. Update the ECM/PCM if it does not have the latest software, or substitute a known-good ECM/PCM (see «HOW TO TROUBLESHOOT CIRCUITS AT THE ECM/PCM»(/acura/tl/iii-2003-2006/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__how-to-troubleshoot-circuits-at-the) ).
  34. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P0453 is indicated, check for poor connections or loose terminals at the FTP sensor and the ECM/PCM, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTC's troubleshooting. NO - If the ECM/PCM was updated, troubleshooting is complete. If the ECM/PCM was substituted, replace the original ECM/PCM (see «ECM/PCM REPLACEMENT»(/acura/tl/iii-2003-2006/remont/testing-diagnostics/#pgm-fi-system) ).

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 158

Scheme 158: DTC P0457: EVAP System Leak Detected/Fuel Fill Cap Loose or Missing
Scheme 158: DTC P0457: EVAP System Leak Detected/Fuel Fill Cap Loose or Missing

Scheme 159

Scheme 159
Scheme 159
  1. Check the fuel fill cap (the cap must say "Tighten to click"). It should turn 1/4 turn after it's tight, then it clicks. Is the correct fuel fill cap installed and properly tightened? YES - Go to step 2 . NO - Replace or tighten the fuel fill cap, then go to step 19 .
  2. Check the fuel fill cap seal (A) and the fuel fill pipe mating surface (B). Verify that the fuel fill cap tether cord (C) is not caught under the cap. Is the fuel fill cap seal missing or damaged, is the fuel fill pipe damaged, or is the tether cord caught under the cap? YES - Replace the fuel fill cap or the fuel fill pipe, then go to step 19 . NO - Go to step 3 .
  3. Turn the ignition switch ON (II).
  4. Clear the DTC with the HDS.
  5. Do the EVAP FUNCTION TEST in the INSPECTION MENU with the HDS. Is the result OK? YES - Intermittent failure, system is OK at this time. Check for poor connections or loose terminals at the FTP sensor, or the EVAP canister vent shut valve and the ECM/PCM. NO - Go to step 6 .
  6. Turn the ignition switch OFF.
  7. Remove the EVAP canister vent shut valve from the EVAP canister (see «EVAP CANISTER VENT SHUT VALVE REPLACEMENT»(/acura/tl/iii-2003-2006/remont/auxiliary-emission-control-systems/#evap-system) ).
  8. Connect the 2P connector to the EVAP canister vent shut valve.
  9. Turn the ignition switch ON (II).
  10. Select EVAP CVS ON in the INSPECTION MENU with the HDS.
  11. Check the EVAP canister vent shut valve (A) operation. Does the valve operate? YES - Check the routing of the EVAP canister vent tube, then go to step 18 . NO - Go to step 12 .
  12. Turn the ignition switch OFF.
  13. Replace the EVAP canister vent shut valve (see «EVAP CANISTER VENT SHUT VALVE REPLACEMENT»(/acura/tl/iii-2003-2006/remont/auxiliary-emission-control-systems/#evap-system) ).
  14. Turn the ignition switch ON (II).
  15. Reset the ECM/PCM with the HDS.
  16. Do the «ECM/PCM IDLE LEARN PROCEDURE»(/acura/tl/iii-2003-2006/remont/testing-diagnostics/#idle-control-system__ecmpcm-idle-learn-procedure) )
  17. Do the EVAP FUNCTION TEST in the INSPECTION MENU with the HDS. Is the result OK? YES - Troubleshooting is complete. NO - Check for poor connections or loose terminals at the FTP sensor, or the EVAP canister vent shut valve and the ECM/PCM, then go to step 1 .
  18. Reinstall the EVAP canister vent shut valve.
  19. Turn the ignition switch ON (II).
  20. Reset the ECM/PCM with the HDS.
  21. Do the «ECM/PCM IDLE LEARN PROCEDURE»(/acura/tl/iii-2003-2006/remont/testing-diagnostics/#idle-control-system__ecmpcm-idle-learn-procedure) ).
  22. Do the EVAP FUNCTION TEST in the INSPECTION MENU with the HDS. Is the result OK YES - Troubleshooting is complete. NO - Check for poor connections or loose terminals at the FTP sensor, or the EVAP canister vent shut valve and the ECM/PCM, then go to step 1 .

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

  1. Turn the ignition switch ON (II).
  2. Clear the DTC with the HDS.
  3. Do the EVAP FUNCTION TEST in the INSPECTION MENU with the HDS. Is the result OK? YES - Intermittent failure, system is OK at this time. Check for poor connections or loose terminals at the FTP sensor, the EVAP canister purge valve, or the EVAP canister vent shut valve and the ECM/PCM. NO - Go to step 4 .
  4. Turn the ignition switch OFF.
  5. Replace the EVAP canister purge valve (see «EVAP CANISTER PURGE VALVE REPLACEMENT»(/acura/tl/iii-2003-2006/remont/auxiliary-emission-control-systems/#evap-system) ).
  6. Turn the ignition switch ON (II).
  7. Reset the ECM/PCM with the HDS.
  8. Do the «ECM/PCM IDLE LEARN PROCEDURE»(/acura/tl/iii-2003-2006/remont/testing-diagnostics/#idle-control-system__ecmpcm-idle-learn-procedure) .
  9. Do the EVAP FUNCTION TEST in the INSPECTION MENU with the HDS. Is the result OK? YES - Troubleshooting is complete. NO - Check for poor connections or loose terminals at the FTP sensor, the EVAP canister purge valve, or the EVAP canister vent shut valve and the ECM/PCM, then go to step 1 .

Special Tools Required

  1. Vacuum pump/gauge, 0-30 in.Hg, Snap-on YA4000A or equivalent, commercially available
  2. Vacuum/pressure gauge, 0-4 in.Hg, 07JAZ-001000B

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 160

Scheme 160
Scheme 160

Scheme 161

Scheme 161
Scheme 161

Scheme 162

Scheme 162
Scheme 162

Scheme 163

Scheme 163
Scheme 163
  1. Check the fuel fill cap (the cap must say "Tighten to click"). It should turn 1/4 turn after it's tight, then it clicks. Is the correct fuel fill cap installed and properly tightened? YES - Go to step 2 . NO - Replace or tighten the fuel fill cap, then go to step 24 .
  2. Turn the ignition switch ON (II).
  3. Clear the DTC with the HDS.
  4. Do the EVAP FUNCTION TEST in the INSPECTION MENU with the HDS. Is the result OK? YES -Intermittent failure, system is OK at this time. Check for poor connections or loose terminals at the FTP sensor, the EVAP canister purge valve, or the EVAP canister vent shut valve and the ECM/PCM. NO - Go to step 5 .
  5. Check for a loose or damaged EVAP canister purge line between the intake manifold and the EVAP canister purge valve. Is the line OK? YES - Go to step 6 . NO - Reconnect or repair the EVAP canister purge line, then go to step 24 .
  6. Disconnect the vacuum hose from the EVAP canister purge valve service port (A) in the engine compartment, and connect a T-fitting (B) from the vacuum gauge and the vacuum pump/gauge, 0-30 in.Hg, to the vacuum hose (C) as shown.
  7. Select EVAP PCS ON in the INSPECTION MENU with the HDS.
  8. Slowly apply about 2.0 kPa (0.6 in.Hg, 15 mmHg) of vacuum to the hose. Does it hold vacuum? YES - Replace the EVAP canister purge valve, then go to step 24 . NO - Go to step 9 .
  9. Reconnect the vacuum hose to the EVAP service port.
  10. Disconnect the vacuum hose from the EVAP canister purge line (at the EVAP canister side), and connect a T-fitting (A) from the vacuum gauge and the vacuum pump/gauge, 0-30 in.Hg, to the hose as shown.
  11. Select EVAP PCS ON in the INSPECTION MENU with the HDS.
  12. Slowly apply about 2 kPa (0.6 in.Hg, 15 mmHg) of vacuum to the hose. Does it hold vacuum? YES - Check for a restricted EVAP canister purge line between the EVAP canister purge valve and the EVAP canister, then go to step 23 . NO - Go to step 13 .
  13. Remove the FTP sensor with its connector connected (see «FTP SENSOR REPLACEMENT»(/acura/tl/iii-2003-2006/remont/auxiliary-emission-control-systems/#evap-system) ).
  14. Connect a T-fitting (A) from the vacuum pump/gauge, 0-30 in.Hg, and the vacuum pressure gauge 0-4 in.Hg (0-100 mmHg) to the FTP sensor (B) as shown.
  15. Check and record the FTP SENSOR reading in the DATA LIST with the HDS.
  16. Slowly apply about 1.3 kPa (0.4 in.Hg, 10 mmHg) of vacuum to the hose.
  17. Check the FTP SENSOR in the DATA LIST with the HDS. Is the difference more than 1.1 kPa (0.31 in.Hg, 8 mmHg) before and after applying vacuum? YES - Go to step 18 . NO - Replace the FTP sensor (see «FTP SENSOR REPLACEMENT»(/acura/tl/iii-2003-2006/remont/auxiliary-emission-control-systems/#evap-system) ), then go to step 23 .
  18. Reconnect the vacuum hoses to the EVAP canister purge line (EVAP canister side), and reinstall the FTP sensor.
  19. Disconnect the vacuum hose (A) from the EVAP canister purge valve (B), and connect a T-fitting (C) from the vacuum gauge and the vacuum pump/gauge, 0-30 in.Hg, to the hose as shown.
  20. Select EVAP CVS ON in the INSPECTION MENU with the HDS.
  21. Slowly apply about 2 kPa (0.6 in.Hg, 15 mmHg) of vacuum to the hose. Does the hose hold vacuum? YES - Check for blockage on the EVAP canister port, then go to step 22 . NO - Replace the EVAP canister vent shut valve (see «EVAP CANISTER VENT SHUT VALVE REPLACEMENT»(/acura/tl/iii-2003-2006/remont/auxiliary-emission-control-systems/#evap-system) ), then go to step 22 .
  22. Install the FTP sensor (see «FTP SENSOR REPLACEMENT»(/acura/tl/iii-2003-2006/remont/auxiliary-emission-control-systems/#evap-system) ).
  23. Reconnect all hoses.
  24. Turn the ignition switch ON (II).
  25. Reset the ECM/PCM with the HDS.
  26. Do the «ECM/PCM IDLE LEARN PROCEDURE»(/acura/tl/iii-2003-2006/remont/testing-diagnostics/#idle-control-system__ecmpcm-idle-learn-procedure) .
  27. Do the EVAP FUNCTION TEST in the INSPECTION MENU with the HDS. Is the result OK? YES - Troubleshooting is complete. NO - Check for poor connections or loose terminals at the FTP sensor, the EVAP canister purge valve, or the EVAP canister vent shut valve and the ECM/PCM, then go to step 1 .

DTC P0498: EVAP Canister Vent Shut Valve Circuit Low Voltage (2004-2005 Models)

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 164

Scheme 164: DTC P0498: EVAP Canister Vent Shut Valve Circuit Low Voltage (2004-2005 Models)
Scheme 164: DTC P0498: EVAP Canister Vent Shut Valve Circuit Low Voltage (2004-2005 Models)

Scheme 165

Scheme 165
Scheme 165

Scheme 166

Scheme 166
Scheme 166

Scheme 167

Scheme 167
Scheme 167

Scheme 168

Scheme 168
Scheme 168
  1. Turn the ignition switch ON (II).
  2. Clear the DTC with the HDS.
  3. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0498 indicated? YES - Go to step 6 . NO - Go to step 4 .
  4. Select EVAP CVS ON in the INSPECTION MENU with the HDS.
  5. Check for Temporary DTCs or DTCs with the HDS Is DTC P0498 indicated? YES - Go to step 6 . NO - Intermittent failure, system is OK at this time. Check for poor connections or loose terminals at the EVAP canister vent shut valve and the ECM/PCM.
  6. Turn the ignition switch OFF.
  7. Disconnect the EVAP canister vent shut valve 2P connector.
  8. Turn the ignition switch ON (II).
  9. Measure voltage between EVAP canister vent shut valve 2P connector terminal No. 2 and body ground. Is there battery voltage? YES - Go to step 10 . NO - Repair open in the wire between the EVAP canister vent shut valve and the No. 18 IG ACG (15 A) fuse in the under-dash fuse/relay box, then go to step 18 .
  10. Turn the ignition switch OFF.
  11. Measure resistance between EVAP canister vent shut valve 2P connector terminals No. 1 and No. 2. Is there about 25 - 30 ohm at room temperature? YES - Go to step 12 . NO - Go to step 17 .
  12. Jump the SCS line with the HDS.
  13. Disconnect ECM/PCM connector A (31P).
  14. Check for continuity between ECM/PCM connector terminal A10 and body ground. Is there continuity? YES - Repair short in the wire between the EVAP canister vent shut valve and the ECM/PCM (A10), then go to step 18 . NO - Go to step 15 .
  15. Connect EVAP canister vent shut valve 2P connector terminal No. 1 to body ground with a jumper wire.
  16. Check for continuity between ECM/PCM connector terminal A10 and body ground. Is there continuity? YES - Go to step 24 . NO - Repair open in the wire between the EVAP canister vent shut valve and the ECM/PCM (A10), then go to step 18 .
  17. Replace the EVAP canister vent shut valve (see «EVAP CANISTER VENT SHUT VALVE REPLACEMENT»(/acura/tl/iii-2003-2006/remont/auxiliary-emission-control-systems/#evap-system) ).
  18. Reconnect all connectors.
  19. Turn the ignition switch ON (II).
  20. Reset the ECM/PCM with the HDS.
  21. Do the «ECM/PCM IDLE LEARN PROCEDURE»(/acura/tl/iii-2003-2006/remont/testing-diagnostics/#idle-control-system__ecmpcm-idle-learn-procedure) .
  22. Select EVAP CVS ON in the INSPECTION MENU with the HDS.
  23. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P0498 is indicated, check for poor connections or loose terminals at the EVAP canister vent shut valve and the ECM/PCM, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTC's troubleshooting. NO - Troubleshooting is complete.
  24. Update the ECM/PCM if it does not have the latest software, or substitute a known-good ECM/PCM (see «HOW TO TROUBLESHOOT CIRCUITS AT THE ECM/PCM»(/acura/tl/iii-2003-2006/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__how-to-troubleshoot-circuits-at-the) ).
  25. Select EVAP CVS ON in the INSPECTION MENU with the HDS.
  26. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P0498 is indicated, check for poor connections or loose terminals at the EVAP canister vent shut valve and the ECM/PCM, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTC's troubleshooting. NO - If the ECM/PCM was updated, troubleshooting is complete. If the ECM/PCM was substituted, replace the original ECM/PCM (see «ECM/PCM REPLACEMENT»(/acura/tl/iii-2003-2006/remont/testing-diagnostics/#pgm-fi-system) ).

DTC P0498: EVAP Canister Vent Shut Valve Circuit Low Voltage (2006 Model)

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 169

Scheme 169: DTC P0498: EVAP Canister Vent Shut Valve Circuit Low Voltage (2006 Model)
Scheme 169: DTC P0498: EVAP Canister Vent Shut Valve Circuit Low Voltage (2006 Model)

Scheme 170

Scheme 170
Scheme 170

Scheme 171

Scheme 171
Scheme 171

Scheme 172

Scheme 172
Scheme 172

Scheme 173

Scheme 173
Scheme 173
  1. Turn the ignition switch ON (II).
  2. Clear the DTC with the HDS.
  3. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0498 indicated? YES - Go to step 6 . NO - Go to step 4 .
  4. Select EVAP CVS ON in the INSPECTION MENU with the HDS
  5. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0498 indicated? YES - Go to step 6 . NO - Intermittent failure, system is OK at this time. Check for poor connections or loose terminals at the EVAP canister vent shut valve and the ECM/PCM.
  6. Turn the ignition switch OFF.
  7. Disconnect the EVAP canister vent shut valve 2P connector.
  8. Turn the ignition switch ON (II).
  9. Measure voltage between EVAP canister vent shut valve 2P connector terminal No. 2 and body ground. Is there battery voltage? YES - Go to step 10 . NO - Repair open in the wire between the EVAP canister vent shut valve and the No. 18 IG ACG (15 A) fuse in the under-dash fuse/relay box, then go to step 18 .
  10. Turn the ignition switch OFF.
  11. Measure resistance between EVAP canister vent shut valve 2P connector terminals No. 1 and No. 2. Is there about 25 - 30 ohm at room temperature? YES - Go to step 12 . NO - Go to step 17 .
  12. Jump the SCS line with the HDS.
  13. Disconnect ECM/PCM connector E (31P).
  14. Check for continuity between ECM/PCM connector terminal E10 and body ground. Is there continuity? YES - Repair short in the wire between the EVAP canister vent shut valve and the ECM/PCM (E10), then go to step 18 . NO - Go to step 15 .
  15. Connect EVAP canister vent shut valve 2P connector terminal No. 1 to body ground with a jumper wire.
  16. Check for continuity between ECM/PCM connector terminal E10 and body ground. Is there continuity? YES - Go to step 24 . NO - Repair open in the wire between the EVAP canister vent shut valve and the ECM/PCM (E10), then go to step 18 .
  17. Replace the EVAP canister vent shut valve (see «EVAP CANISTER VENT SHUT VALVE REPLACEMENT»(/acura/tl/iii-2003-2006/remont/auxiliary-emission-control-systems/#evap-system) ).
  18. Reconnect all connectors.
  19. Turn the ignition switch ON (II).
  20. Reset the ECM/PCM with the HDS.
  21. Do the «ECM/PCM IDLE LEARN PROCEDURE»(/acura/tl/iii-2003-2006/remont/testing-diagnostics/#idle-control-system__ecmpcm-idle-learn-procedure) .
  22. Select EVAP CVS ON in the INSPECTION MENU with the HDS.
  23. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P0498 is indicated, check for poor connections or loose terminals at the EVAP canister vent shut valve and the ECM/PCM, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTC's troubleshooting. NO - Troubleshooting is complete.
  24. Update the ECM/PCM if it does not have the latest software, or substitute a known-good ECM/PCM (see «HOW TO TROUBLESHOOT CIRCUITS AT THE ECM/PCM»(/acura/tl/iii-2003-2006/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__how-to-troubleshoot-circuits-at-the) ).
  25. Select EVAP CVS ON in the INSPECTION MENU with the HDS.
  26. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P0498 is indicated, check for poor connections or loose terminals at the EVAP canister vent shut valve and the ECM/PCM, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTC's troubleshooting. NO - If the ECM/PCM was updated, troubleshooting is complete. If the ECM/PCM was substituted, replace the original ECM/PCM (see «ECM/PCM REPLACEMENT»(/acura/tl/iii-2003-2006/remont/testing-diagnostics/#pgm-fi-system) ).

DTC P0499: EVAP Canister Vent Shut Valve Circuit High Voltage

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

  1. Turn the ignition switch ON (II)
  2. Clear the DTC with the HDS.
  3. Select EVAP CVS ON in the INSPECTION MENU with the HDS.
  4. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0499 indicated? YES - Update the ECM/PCM if it does not have the latest software, or substitute a known-good ECM/PCM (see «HOW TO TROUBLESHOOT CIRCUITS AT THE ECM/PCM»(/acura/tl/iii-2003-2006/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__how-to-troubleshoot-circuits-at-the) ), then recheck. If the symptom/indication goes away with a known-good ECM/PCM, replace the original ECM/PCM (see «ECM/PCM REPLACEMENT»(/acura/tl/iii-2003-2006/remont/testing-diagnostics/#pgm-fi-system) ). NO - Intermittent failure, system is OK at this time. Check for poor connections or loose terminals at the EVAP canister vent shut valve and the ECM/PCM.

DTC P1454, P2422: FTP Sensor Circuit Range/Performance Problem, EVAP Canister Vent Shut Valve Stuck Closed Malfunction

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 174

Scheme 174: DTC P1454, P2422: FTP Sensor Circuit Range/Performance Problem, EVAP Canister Vent Shut Valve Stuck
Scheme 174: DTC P1454, P2422: FTP Sensor Circuit Range/Performance Problem, EVAP Canister Vent Shut Valve Stuck

Scheme 175

Scheme 175
Scheme 175

Scheme 176

Scheme 176
Scheme 176
  1. Turn the ignition switch ON (II).
  2. Clear the DTC with the HDS.
  3. Turn the ignition switch OFF.
  4. Remove the fuel fill cap, and wait 1 minute.
  5. Check the FTP SENSOR in the DATA LIST with the HDS. Is it between -0.67 kPa (-0.2 and 0.2 in.Hg, -5 and 5 mmHg), or 2.4 and 2.6 V? YES - Go to step 6 . NO - Go to step 17 .
  6. Install the fuel fill cap.
  7. Clear the DTC with the HDS.
  8. Start the engine. Hold the engine speed at 3,000 rpm without load (in Park or neutral) until the radiator fan comes on, then let it idle.
  9. Monitor the OBD STATUS for DTC P1454 in the DTCs MENU with the HDS. Does the screen indicate FAILED? YES - Go to step 10 . NO - If the screen indicates PASSED, intermittent failure, system is OK at this time, check for a poor connections or loose terminals at the FTP sensor, or the EVAP canister vent shut valve and the ECM/PCM. Also check for a blockage in the canister filter, vent hoses, and drain joint. If the screen indicates NOT COMPLETED, go to step 7 and recheck.
  10. Clear the DTC with the HDS.
  11. Turn the ignition switch OFF.
  12. Remove the EVAP canister vent shut valve from the EVAP canister (see «EVAP CANISTER VENT SHUT VALVE REPLACEMENT»(/acura/tl/iii-2003-2006/remont/auxiliary-emission-control-systems/#evap-system) ).
  13. Connect the 2P connector to the EVAP canister vent shut valve.
  14. Turn the ignition switch ON (II).
  15. Select EVAP CVS ON in the INSPECTION MENU with the HDS.
  16. Check the EVAP canister vent shut valve (A) operation. Does the valve operate? YES - Check for a blockage in the EVAP canister, or the canister filter then install the EVAP canister vent shut valve, and go to step 23 . NO - Replace the EVAP canister vent shut valve (see «EVAP CANISTER VENT SHUT VALVE REPLACEMENT»(/acura/tl/iii-2003-2006/remont/auxiliary-emission-control-systems/#evap-system) ), then go to step 23 .
  17. Disconnect the air tube (A) from the FTP sensor (B).
  18. Check the FTP SENSOR in the DATA LIST with the HDS. Is it between - 0.67 kPa and 0.67 kPa (-0.2 and 0.2 in.Hg, - 5 and 5 mmHg), or 2.4 and 2.6 V? YES -Check for a blockage in the FTP sensor air tube, then go to step 23 . NO - Go to step 19 .
  19. Turn the ignition switch OFF.
  20. Remove the FTP sensor (A) from the EVAP canister with its connector connected (see «FTP SENSOR REPLACEMENT»(/acura/tl/iii-2003-2006/remont/auxiliary-emission-control-systems/#evap-system) ).
  21. Turn the ignition switch ON (II).
  22. Check the FTP SENSOR in the DATA LIST with the HDS. Is it between - 0.67 kPa and 0.67 kPa (-0.2 and 0.2 in.Hg, - 5 and 5 mmHg), or 2.4 and 2.6 V? YES - Check for debris or clogging at the EVAP canister, and the FTP sensor port, then go to step 23 . NO - Replace the FTP sensor (see «FTP SENSOR REPLACEMENT»(/acura/tl/iii-2003-2006/remont/auxiliary-emission-control-systems/#evap-system) ), then go to step 23 .
  23. Turn the ignition switch ON (II).
  24. Reset the ECM/PCM with the HDS.
  25. Do the ECM/PCM idle learn procedure (see «ECM/PCM IDLE LEARN PROCEDURE»(/acura/tl/iii-2003-2006/remont/testing-diagnostics/#idle-control-system__ecmpcm-idle-learn-procedure) ).
  26. Start the engine. Hold the engine speed at 3,000 rpm without load (in Park or neutral) until the radiator fan comes on, then let it idle.
  27. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P1454 and/or P2422 is indicated, check for poor connections or loose terminals at the FTP sensor, or the EVAP canister vent shut valve and the ECM/PCM, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTC's troubleshooting. NO - Go to step 28 .
  28. Monitor the OBD STATUS for DTC P1454 in the DTCs MENU with the HDS. Does the screen indicate PASSED? YES - Troubleshooting is complete. NO - If the screen indicates FAILED, check for poor connections or loose terminals at the FTP sensor, or the EVAP canister vent shut valve and the ECM/PCM, then go to step 1 . If the screen indicates NOT COMPLETED, go to step 26 and recheck.

Scheme 177

Scheme 177: EVAP Canister Replacement
Scheme 177: EVAP Canister Replacement

Scheme 178

Scheme 178
Scheme 178

Scheme 179

Scheme 179
Scheme 179
  1. Remove the EVAP canister cover (A).
  2. Remove the hoses (A), the FTP sensor 3P connector (B), and the EVAP canister vent shut valve 2P connector (C).
  3. Remove the bolts (D).
  4. Remove the EVAP canister assembly (E).
  5. Remove the EVAP canister bracket (A). NOTE: The canister filter remains on the bracket.
  6. Install the canister in the reverse order of removal.

Scheme 180

Scheme 180: FTP Sensor Replacement
Scheme 180: FTP Sensor Replacement
  1. Remove the EVAP canister (see «EVAP CANISTER REPLACEMENT»(/acura/tl/iii-2003-2006/remont/auxiliary-emission-control-systems/#evap-system) ).
  2. Remove the FTP sensor (A).
  3. Install the sensor in the reverse order of removal with a new O-ring (B).

Scheme 181

Scheme 181: EVAP Canister Purge Valve Replacement
Scheme 181: EVAP Canister Purge Valve Replacement
  1. Disconnect the hoses (A) and the EVAP canister purge valve 2P connector (B).
  2. Remove the EVAP canister purge valve (C).
  3. Install the valve in the reverse order of removal.

Scheme 182

Scheme 182: EVAP Canister Vent Shut Valve Replacement
Scheme 182: EVAP Canister Vent Shut Valve Replacement
  1. Remove the EVAP canister (see «EVAP CANISTER REPLACEMENT»(/acura/tl/iii-2003-2006/remont/auxiliary-emission-control-systems/#evap-system) ).
  2. Open the stoppers (A), then remove the EVAP canister vent shut valve (B). NOTE: Be careful not to damage the lock tabs.
  3. Install the valve in the reverse order of removal with a new O-ring (C). NOTE: Do not coat the O-ring with oil.

More articles — Engine
