Power Seats — Acura SLX I (1995-1999)

DESCRIPTION & OPERATION

WARNING

Vehicle is equipped with Supplemental Inflatable Restraint (SIR) system. When servicing vehicle, use care to avoid accidental air bag deployment. SIR system-related components are located in various locations throughout interior and exterior of vehicle, depending on application. Do not use electrical test equipment on or near these circuits. If necessary, deactivate SIR system before servicing components. See appropriate AIR BAG RESTRAINT SYSTEMS article in RESTRAINTS.

The power seat system components consist of front/rear tilt, slide and recliner seat switches, front and rear tilt motors (driver's seat only), slide motor and recliner motor. On all models, power seat motors can be actuated by operating seat switches enabling driver or passenger to adjust seat to desired position. Seat adjustment may be achieved with ignition on or off.

SEAT HEATERS

The circuit consists of the starter switch, seat heater switch and the heat unit. The seat heater is provided in driver's and front passenger seats. When the seat heater switch is on, the seat heater built in the seat back and cushion is switched on to warm the seats. To prevent the seats from being overheated, the circuit is fitted with a thermostat.

SYSTEM TESTS

Symptom	Perform Test
Driver Or Passenger Power Seat Inoperative	A
Driver Front Tilt Inoperative	B
Driver Rear Tilt Inoperative	C
Driver Or Passenger Slide Function Inoperative	D
Driver Or Passenger Recliner Inoperative	E

SYMPTOM INDEX (POWER SEATS)

Symptom	Perform Test
Seat Heaters On Both Sides Do Not Heat Up	F
Seat Heater On Driver Or Passenger Side Does Not Heat Up	G
Heat Or Keep Position Does Not Heat Up	H

SYMPTOM INDEX (SEAT HEATERS)

TEST A: DRIVER OR PASSENGER POWER SEAT INOPERATIVE

Check for normal operation of power seat circuit breaker (30-amp) located in passenger compartment fuse box. If circuit breaker is okay, go to next step. If circuit breaker is faulty, replace circuit breaker and retest system.
Check power seat ground circuit (Black wire) for proper connection to chassis ground. If ground circuit is okay, go to next step. If ground circuit is open or poorly connected, repair as necessary. Retest system.
Turn ignition on. Using a voltmeter, measure voltage of power feed circuit (Red wire) at appropriate seat switch. If battery voltage is present, go to next step. If battery voltage is not present, repair poor connection or open in power feed between circuit breaker and appropriate power seat switch.
Repair poor connection or open in ground circuit (Black wire) between appropriate power seat switch and chassis ground. Retest system.

TEST B: DRIVER FRONT TILT INOPERATIVE

Test tilt and slide switches. See «POWER SEAT SWITCH»(/acura/slx/i-1995-1999/remont/seats/#power-seats) under COMPONENT TESTS. If switches test okay, go to next step. If switches are faulty, repair as necessary. Retest system.
Test front tilt motor. See «POWER SEAT MOTOR»(/acura/slx/i-1995-1999/remont/seats/#power-seats__power-seat-motor) under COMPONENT TESTS. If motor tests okay, go to next step. If motor is faulty, repair as necessary. Retest system.
Repair open or short in wire harness between driver-side power seat switch and front tilt motor. Retest system.

TEST C: DRIVER REAR TILT INOPERATIVE

Test tilt and slide switches. See «POWER SEAT SWITCH»(/acura/slx/i-1995-1999/remont/seats/#power-seats) under COMPONENT TESTS. If switches test okay, go to next step. If switches are faulty, repair as necessary. Retest system.
Test rear tilt motor. See «POWER SEAT MOTOR»(/acura/slx/i-1995-1999/remont/seats/#power-seats__power-seat-motor) under COMPONENT TESTS. If motor tests okay, go to next step. If motor is faulty, repair as necessary. Retest system.
Repair open or short in wire harness between driver-side power seat switch and rear tilt motor. Retest system.

TEST D: DRIVER OR PASSENGER SLIDE FUNCTION INOPERATIVE

Test appropriate tilt and slide switches (passenger-side slide switch). See «POWER SEAT SWITCH»(/acura/slx/i-1995-1999/remont/seats/#power-seats) under COMPONENT TESTS. If switches test okay, go to next step. If switches are faulty, repair as necessary. Retest system.
Test appropriate slide motor. See «POWER SEAT MOTOR»(/acura/slx/i-1995-1999/remont/seats/#power-seats__power-seat-motor) under COMPONENT TESTS. If motor tests okay, go to next step. If motor is faulty, repair as necessary. Retest system.
Repair open or short in wire harness between appropriate power seat switch and slide motor. Retest system.

TEST E: DRIVER OR PASSENGER RECLINER INOPERATIVE

Test appropriate recliner switch. See «POWER SEAT SWITCH»(/acura/slx/i-1995-1999/remont/seats/#power-seats) under COMPONENT TESTS. If switch tests okay, go to next step. If switch is faulty, repair as necessary. Retest system.
Test appropriate recliner motor. See «POWER SEAT MOTOR»(/acura/slx/i-1995-1999/remont/seats/#power-seats__power-seat-motor) under COMPONENT TESTS. If motor tests okay, go to next step. If motor is faulty, repair as necessary. Retest system.
Repair open or short in wire harness between appropriate power seat switch and recliner motor. Retest system.

TEST F: SEAT HEATERS ON BOTH SIDES DO NOT HEAT UP

Check for normal operation of C-2 (15-amp) fuse located in dash fuse box. If fuse is okay, go to next step. If fuse is faulty, replace fuse and retest system.
Check power seat ground circuit (Black wire) for proper connection to chassis ground. If ground circuit is okay, go to next step. If ground circuit is open or poorly connected, repair as necessary. Retest system.
Repair poor connection or open in C-2 (15-amp) fuse and between appropriate power seat switch connector terminal No. 1 (Green/Red wire). Retest system.

TEST G: SEAT HEATER ON DRIVER OR PASSENGER SIDE DOES NOT HEAT UP

Disconnect the seat heater switch connector. Turn ignition on. Using a voltmeter, measure voltage of seat heater switch harness side connector (Green/Red wire) and ground. If battery voltage is present, go to next step. If battery voltage is not present, repair poor connection or open in power feed between circuit breaker and appropriate power seat switch.
Check if the seat heater switch functions normally. See «SEAT HEATER SWITCH»(/acura/slx/i-1995-1999/remont/seats/#power-seats__seat-heater-switch) under COMPONENT TESTS. If function is normal, go to next step. If function is not normal, replace the seat heater switch.
Disconnect the heat unit connector. Check for continuity between seat back connector terminal No. 1 (White/Blue wire), seat cushion connector terminal No. 2 (White wire), and seat cushion connector terminal No. 3 (White/Black wire). If there is continuity, go to next step. If there is no continuity, replace the heater unit. Retest system.
Repair poor connection or open in seat heater switch connector to seat back connector wire, seat heater switch connector to seat cushion connector wire, and seat cushion connector to ground. Retest system.

TEST H: HEAT OR KEEP POSITION DOES NOT HEAT UP

Check if the seat heater switch functions normally. See SEAT HEATER SWITCH under COMPONENT TESTS. If function is normal, replace the heat unit. If function is not normal, replace the seat heater switch.

POWER SEAT CIRCUIT TEST

Turn ignition off. Disconnect appropriate 6-pin power seat harness connector. (Scheme 1) Using an ohmmeter, check for continuity between terminal No. 4 (Black wire) and ground. Continuity should be present.
Turn ignition on. Using a voltmeter, check for voltage between terminal No. 1 (Black/Blue wire) and ground. Reading should be battery voltage. If circuit does not test as specified, check for an open or short in power feed or ground supply circuits. Repair as necessary.

Scheme 1

POWER SEAT MOTOR

Turn ignition off. Disconnect motor harness connector from motor to be tested. Using fused jumper wires, connect battery voltage and ground to specified motor terminals. See POWER SEAT MOTOR TESTING table. (Scheme 2) Replace appropriate power seat motor if it does not operate as specified.

Application	Apply Power To Terminal No.	Apply Ground To Terminal No.
Front Tilt
Up	1	2
Down	2	1
Rear Tilt
Up	1	2
Down	2	1
Slide
Forward	1	2
Rearward	2	1
Recline
Forward	3	6
Rearward	6	3

POWER SEAT MOTOR TESTING

Scheme 2

Driver Side

Turn ignition off. Remove driver-side power seat switch. Using an ohmmeter, ensure continuity exists between specified switch terminals while operating switch. See POWER SEAT SWITCH CONTINUITY (DRIVER SIDE) table. (Scheme 3) Replace power seat switch if continuity does not exist.

Function		Between Terminals
Front Tilt
Up		A1 & B1; A3 & A6
Down		A1 & A8; A6 & B1
Rear Tilt
Up		A2 & B1; A4 & A7
Down		A7 & B1; A2 & A9
Slide
Forward		A5 & B1; A10 & B2
Rearward		A10 & B1; A5 & B2
Recline
Forward		B1 & C3; C2 & C6
Rearward		B1 & C6; C3 & C5

POWER SEAT SWITCH CONTINUITY (DRIVER SIDE)

Scheme 3

Passenger Side

Turn ignition off. Remove passenger-side power seat switch. Using an ohmmeter, ensure continuity exists between specified switch terminals while operating switch. See POWER SEAT SWITCH CONTINUITY (PASSENGER SIDE) table. (Scheme 4) Replace power seat switch if continuity does not exist.

Function		Between Terminals
Slide
Forward		D1 & F1; D2 & F2
Rearward		D1 & F2; D2 & F1
Recline
Forward		D1 & E3; D2 & D6
Rearward		D1 & E6; E2 & E5

POWER SEAT SWITCH CONTINUITY (PASSENGER SIDE)

Scheme 4

SEAT HEATER SWITCH

Check the continuity between terminals of the seat heater switch. (Scheme 5) If continuity is not as specified, repair or replace the switch. See SEAT HEATER SWITCH under REMOVAL & INSTALLATION.

Scheme 5

Scheme 5: SEAT HEATER SWITCH

SEAT HEATER UNIT

Check continuity between connector terminals. (Scheme 6) If continuity is not as specified, replace the heat unit.

Scheme 6

Scheme 6: SEAT HEATER UNIT

REMOVAL & INSTALLATION

WARNING

CAUTION

When battery is disconnected, vehicle computer and memory systems may lose memory data. Driveability problems may exist until computer systems have completed a relearn cycle. See COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION before disconnecting battery.

Turn ignition off. Remove front and rear seat frame covers. Remove door sill plate. Remove rear passenger seat foot rest. Disconnect all wire harness connectors from seat. Loosen and remove 4 seat frame-to-floorboard attaching bolts. Remove seat. To install, reverse removal procedure. Tighten seat attaching bolts to 40 ft. lbs. (30 N.m).

Removal & Installation (Recliner Motor)

Turn ignition off. Remove appropriate seat. See «SEAT ASSEMBLY»(/acura/slx/i-1995-1999/remont/seats/#power-seats) . Remove seat back. Remove lower recliner retaining bolt, and separate seat back and seat cushion.
Disconnect heater harness connector (if equipped). Remove trim cover hog rings from seat back assembly. Move trim cover aside and remove upper recliner retaining bolt. Disconnect recliner connecting shaft and harness connectors. Remove recliner motor. To install, reverse removal procedure.

Removal & Installation (Tilt & Slide Motor Assembly)

Turn ignition off. Remove appropriate seat. See SEAT ASSEMBLY . Remove seat cushion-to-seat frame attaching bolts. Remove tilt and slide motor assembly. To install, reverse removal procedure.

Turn ignition off. Remove seat side cover from appropriate seat. Disconnect power seat switch harness connectors. Remove tilt and slide lever by pulling outward. Remove 4 screws and remove tilt, slide and recliner switches. To install, reverse removal procedure.

Remove front console assembly by removing 4 screws. Disconnect the seat heater switch by pushing the switch locks from the back side of the front console assembly.

Remove seat assembly. See SEAT ASSEMBLY. Remove heat unit. (Scheme 7) For installation, reverse removal procedure.

Scheme 7

Scheme 7: Removal & Installation

Fig. 8: Power Seats System Wiring Diagram

Scheme 8: Power Seats System Wiring Diagram

Heated Seat System Wiring Diagram. Scheme 8

Scheme 8: Heated Seat System Wiring Diagram
