Engine Controls - Pin Voltage Charts Acura SLX I

Pin Voltage Charts 3 illustrations ~156 words

PIN VOLTAGES

PinWire ColorPin FunctionIgn. OnEng. Run
C1Green/RedInjector Cylinder #4B+B+
C2Brown/BlackShift "B" Solenoid0V0V
C3Green/YellowInjector Cylinder #6B+B+
C4RedIgnition Control (IC) #10V0.1V
C5YellowCrankshaft Position Sensor "A" Circuit0.3V2.2V
C6Not Used
C7Yellow/BlackPCM Ground0V0V
C8Black/RedPCM Ground0V0V
C9Black/BluePCM Ground0V0V
C10Black/RedTachometer8.8V10V @ Idle
C11Yellow/GreenUpshift Light Control0VB+
C12Red/WhiteAlternator Control Gain10.5VB+
C13Yellow/RedFuel Gauge PWM6V (Empty)5.7V (Empty)
C14WhiteBank 2 HO2S 1 High0.3V0-0.8V
C15RedBank 2 HO2S 1 Low0V0.1V
C16RedBank 2 HO2S 2 High0.3V0.7V

PCM PIN ID & VOLTAGE - 32-PIN WHITE CONNECTOR ROW "C"

PCM PIN IDENTIFICATION & VOLTAGE

PinWire ColorPin FunctionIgn. OnEng. Run
A1Red5-Volt Reference "A"5V5V
A2YellowKnock Sensor0V DC, 2 mV AC0V DC, 18 mV AC
A3Not Used
A4Red/WhiteBattery FeedB+B+
A5BlueIdle Air Control (IAC) "A" HighB+/0.8VB+/0.8V
A6Blue/WhiteIdle Air Control (IAC) "A" LowB+/0.8VB+/0.8V
A7Blue/BlackIdle Air Control (IAC) "B" LowB+/0.8VB+/0.8V
A8Blue/RedIdle Air Control (IAC) "B" HighB+/0.8VB+/0.8V
A9Orange/BlueTrans. Fluid LightB+B+
A10Pink/GreenWinter LightB+B+
A11Gray/BluePower LightB+B+
A12Purple/WhiteAnti-Lock Brake System (ABS) Light0V Or B+0V Or B+
A13PurpleMalfunction Indicator Light (MIL)0VB+
A14PinkCHECK TRANSMISSION Light Driver0VB+
A15Red/BlueEVAP Canister Purge SignalB+5.7V
A16Brown/YellowBand ApplyB+B+
(1) (Scheme 1)for terminal identification.
(1)

PCM PIN ID & VOLTAGE - 32-PIN RED CONNECTOR ROW "A" (1)

PinWire ColorPin FunctionIgn. OnEng. Run
B1Green/White5-Volt Reference "B"5V5V
B2Red/WhiteIgnition Control Module #40V0.1V
B3Red/BlackIgnition Control Module #20V0.1V
B4Red/GreenIgnition Control Module #60V0.1V
B5Not Used
B6Not Used
B7Yellow/RedEGR0.6V0.6V
B8Yellow/GreenIntake Air Temperature (IAT) SensorAbout 3VAbout 3V
B9Not Used
B10Green/Red"G" Sensor (Rough Road)2.8V2.8V
B11Green/YellowPower Steering Pressure SwitchB+B+
B12GreenIlluminated SwitchB+B+
B13Orange/GreenClass 2 Data0V0V
B14Green/RedA/C ClutchB+ (A/C Off)B+ (A/C Off)
B15Not Used
B16 (2)Not Used
(1) (Scheme 1)for terminal identification. (2) Depending on air temperature.
(1)
(2)

PCM PIN ID & VOLTAGE - 32-PIN RED CONNECTOR ROW "B" (1)

PinWire ColorPin FunctionIgn. OnEng. Run
C1Green/RedInjector Cylinder #4B+B+
C2Brown/BlackShift "B" Solenoid0V0V
C3Green/YellowInjector Cylinder #6B+B+
C4RedIgnition Control (IC) #10V0.1V
C5YellowCrankshaft Position Sensor "A" Circuit0.3V2.2V
C6Not Used
C7Black/BluePCM Ground0V0V
C8Black/PinkPCM Ground0V0V
C9Black/BluePCM Ground0V0V
C10Black/RedTachometer8.8V10V @ Idle
C11Orange/BlueUpshift Light Control0VB+
C12White/BlueAlternator Control Gain10.5VB+
C13Not Used
C14PinkBank 2 HO2S 1 High0.3V0-0.8V
C15BlueBank 2 HO2S 1 Low0V0.1V
C16GreenBank 2 HO2S 2 High0.3V0.7V
(1) (Scheme 2)for terminal identification.
(1)

PCM PIN ID & VOLTAGE - 32-PIN WHITE CONNECTOR ROW "C" (1)

PinWire ColorPin FunctionIgn. OnEng. Run
D1Green/OrangeInjector Cylinder #2B+B+
D2Brown/BlueTorque Converter Clutch (TCC)0V0V
D3Green/WhiteInjector Cylinder #1B+B+
D4BrownSerial Data (8192)5V5V
D5Red/YellowIgnition Control Cylinder #50V0.1V
D6Red/BlueIgnition Control Cylinder #30V0V
D7White/BlackSpeedometer0V0.1V
D8GreenSensor Ground 5V Reference "A" Return0V0V
D9Blue/YellowSensor Ground 5V Reference "B" Return0V0V
D10YellowMass Airflow (MAF) Sensor4.9V4.2V
D11WhiteCrankshaft Position Sensor5V Or Less Than One V4.6V
D12RedBank 1 HO2S 2 Low0V0.1V
D12WhiteBank 1 HO2S 3 Low0V0.1V
D13RedBank 1 HO2S 1 Low0.3V0.1, 0.9V
D13WhiteBank 1 HO2S 3 High0.4V0.1, 0.9V
D14GreenBank 1 HO2S 1 Low0V0.1V
D15RedBank 1 HO2S 1 Signal0.4V0.1, 0.9V
D16 (2)BlueBank 1 HO2S 2 Low0V0.1V
(1) (Scheme 2)for terminal identification. (2) Manual transmission only.
(1)
(2)

PCM PIN ID & VOLTAGE - 32-PIN WHITE CONNECTOR ROW "D" (1)

PinWire ColorPin FunctionIgn. OnEng. Run
E1RedVehicle Speed Sensor Signal0V0.1V
E2WhiteVehicle Speed Sensor Low0V0V
E3Purple/RedPressure Control Solenoid Low0V1.1V
E4Purple/WhitePressure Control Solenoid High0V0V
E5Black/YellowEGR IgnitionB+B+
E6YellowEGR IgnitionB+B+
E7PinkTransmission Range Signal "B"0V0V
E8BlueThrottle Position Sensor0.5 0.8V0.5 0.8V @ Idle
E9Blue/RedEngine Coolant Temperature (ECT) Sensor0.5 4.9V0.5 4.9V
E10Not Used
E11Yellow/RedCrankshaft Position Sensor 5V Reference5V Or Less Than One V5V
E12Pink/BlueTransmission Range Signal "A"B+B+
E13Red/WhiteFuel Pump Relay0VB+
E14Brown/WhiteShift HighB+B+
E15Green/OrangeA/C Request0V0V
E16Red/BlueIgnition FeedB+B+
(1) (Scheme 3)for terminal identification.
(1)

PCM PIN ID & VOLTAGE - 32-PIN BLUE CONNECTOR ROW "E" (1)

PinWire ColorPin FunctionIgn. OnEng. Run
F1Not Used
F2Blue/BlackTransmission Range Signal "C"0V0V
F3Pink/BlackTransmission Range Signal "P"B+0V
F4Green/YellowBrake Switch0V0V
F5Purple/RedPower SwitchB+B+
F6Purple/GreenWinter SwitchB+B+
F7Green/RedTrans. Fluid Temp.0.5, 4.9V0.5, 4.9V
F8RedMAP Sensor3.5, 4.9V0.6, 1.3V
F9Yellow/GreenVacuum SwitchB+B+
F10Gray/BlueCruise ControlB+B+
F11Light/BlueKickdown SwitchB+B+
F12"""Not Used
F13GreenInjector "C" Cyl. #3B+B+
F14Brown/RedShift "A" SolenoidB+B+
F15Green/BlackInjector Cylinder #5B+B+
F16Red/BlueIgnition FeedB+B+
(1) (Scheme 3)for terminal identification.
(1)

PCM PIN ID & VOLTAGE - 32-PIN BLUE CONNECTOR ROW "F" (1)

Scheme 1

Scheme 1
Scheme 1

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

TEST CONDITIONS

Pin voltage (values) are obtained using scan tool connected to Data Link Connector (DLC). The following conditions must be met before testing

  1. Engine at normal operating temperature.
  2. Engine at idle (closed throttle).
  3. Transmission in Park or Neutral.
  4. Accessories off.
  5. A/C system off.
  6. Closed-loop operation.

SCAN TOOL DATA VALUES

Scan Tool ParametersTypical Data Value
A/C ClutchOFF
A/C RequestNO
Air/Fuel Ratio14.7:1
BARO(1) 61-104 kPa
CHECK TRANS LightOFF
CMP Act. Counter(2) 0-255 Counts
Decel Fuel ModeInactive
ECT176-212°F (80-100°C)
EGR Closed Valve Pintle Position0-40 Counts
EGR Position (Desired)0%
EGR Duty Cycle0%
EGR Feedback0.45 - 0.80
EGR Position Error0-9%
EGR Position (Actual)0%
EGR Test Count0-14 Counts
Engine Load2.0-5.5%
Engine Speed(3)
EVAP Purge PWM0%
EVAP Vacuum SwitchOpen
Fuel PumpON
Fuel Trim LearnEnabled
Fuel Trim
Long Term FT (Banks 1 & 2)(8) 100-150 Counts
Short Term FT (Banks 1 & 2)(9) 85-160 Counts
"G" Sensor2.35-2.65 Volts
Gen. ControlInactive
HO2S (Bank 1, No. 1)(4) 50-950 mV
HO2S (Bank 1, No. 2) (5)(6) 200-700 mV
HO2S (Bank 1, No. 2) (7)(4) 50-950 mV
HO2S (Bank 1, No. 3) (7)(6) 200-700 mV
HO2S (Bank 2, No. 1)(4) 50-950 mV
HO2S (Bank 2, No. 2) (5)(6) 200-700 mV
HO2S (Bank 1, No. 1) StatusReady
HO2S (Bank 2, No. 1) StatusReady
HO2S Warm-Up Time
Bank 1, No. 125-45 Seconds
Bank 1, No. 2 (5)60-100 Seconds
Bank 1, No. 2 (7)50-80 Seconds
Bank 1, No. 3 (7)60-100 Seconds
Bank 2, No. 125-45 Seconds
Bank 2, No. 2 (5)60-100 Seconds
IAT(2) 32-212°F (0-100°C)
Idle (Desired)750 RPM
Ignition 112.8-14.1 Volts
Inj. Pulse Banks 1 & 22-4 mS
KS Retard0 Degrees
KS Noise Channel0.1-0.4 Volts
Loop StatusClosed
MAF2.85-6.65 Grams Per Sec.
MAF Input Frequency2100-2700 Hertz
MAP23-40 kPa Or 0.65-1.32 Volts
MILOFF
Misfire
Misfire (Current) Cyl. #1-6#0-2
Misfire (History) Cyl. #1-6#0
Total Misfire Current Count0-5
PNP"P" Or "N"
PSP SwitchNormal
Power EnrichmentInactive
Rich/Lean Banks 1 & 2(10)
Spark Advance15-22 Degrees BTDC
TCC EngagedNO
Torque ManagementInactive
TP Angle0%
TP Sensor0.50-0.82 Volts
TWC ProtectionInactive
(1) Varies with altitude and barometric pressure. (2) Always increasing. (3) Within less than 50 RPM or greater than 100 RPM of desired RPM. (4) Changing quickly. (5) Automatic transmission. (6) Changing slowly. (7) Manual transmission. (8) Or from -22 percent to 17 percent. (9) Or from -34 percent to 25 percent. (10) Varies.
(1)Varies with altitude and barometric pressure.
(2)Always increasing.
(3)Within less than 50 RPM or greater than 100 RPM of desired RPM.
(4)Changing quickly.
(5)Automatic transmission.
(6)Changing slowly.
(7)Manual transmission.
(8)Or from -22 percent to 17 percent.
(9)Or from -34 percent to 25 percent.
(10)Varies.

SCAN TOOL DATA VALUES
