Power Moonroof Acura RSX I

Sun Roof/t-Top/convertible Top 6 illustrations ~141 words

Scheme 26

Scheme 26: Component Location Index
Scheme 26: Component Location Index

Scheme 27

Scheme 27: Circuit Diagram
Scheme 27: Circuit Diagram

Scheme 28

Scheme 28: Switch Test/Replacement
Scheme 28: Switch Test/Replacement

Scheme 29

Scheme 29
Scheme 29
  1. Carefully pry out the driver's switch panel (see «DRIVER'S SWITCH PANEL REMOVAL/INSTALLATION»(/acura/rsx/i-2001-2004/remont/exteriorinterior-trim/#dashboard__drivers-switch-panel-removalinstallation) ).
  2. Disconnect the 6P connector (A) from the moonroof switch (B), then remove the switch.
  3. Check for continuity between the terminals in each switch position according to the table.
  4. If the continuity is not as specified, replace the illumination bulbs (C) or the switch.

Scheme 30

Scheme 30: Motor Test
Scheme 30: Motor Test

Scheme 31

Scheme 31
Scheme 31
  1. Remove the headliner (see «HEADLINER REMOVAL/INSTALLATION»(/acura/rsx/i-2001-2004/remont/exteriorinterior-trim/#interior-trim__headliner-removalinstallation) ).
  2. Disconnect the 2P connector (A) from the moonroof motor (B).
  3. Check the motor by connecting power and ground according to the table.
  4. If the motor does not run, replace it. NOTE: See closing force check (see «CLOSING FORCE AND OPENING DRAG CHECK»(/acura/rsx/i-2001-2004/remont/sun-rooft-topconvertible-top/#moonroof) ) for motor clutch test.
