Moonroof — Acura RSX I (2001-2004)

Scheme 1

Scheme 1: Component Location Index

Symptom Troubleshooting Index

Symptom	Diagnostic procedure
Water leaks from moonroof	Check for a clogged drain tube. Check for a gap between the glass weatherstrip and the roof panel. Check for a defective or an improperly installed glass weatherstrip or drain channel. Check for a gap between the drain seal and the roof panel.
Wind noise from moonroof	Check for excessive clearance between the glass weatherstrip and the roof panel.
Motor noise from moonroof	Check for a loose motor. Check for a worn gear or bearing. Check for a deformed cable assembly.
Glass does not move, but motor turns	Check for a defective gear or inner cable. Check for foreign material stuck between the guide rail and the slider. Check for a loose inner cable. Make sure the cable assembly is attached properly.
Glass does not move and motor does not turn (glass can be moved with moonroof wrench)	Check for a blown fuse. Check for a faulty moonroof switch. Check for a run down battery. Check for a defective motor. Check for a faulty relay.

SYMPTOM CHART

Glass Height Adjustment

The roof panel (A) should be even with the glass weatherstrip (B), to within 2 +0.5/-1 mm (0.08 +0.02/-0.04 in.) all the way around. If not, make the following adjustment

Scheme 2

Scheme 2: Glass Height Adjustment

Scheme 3

Tilt-up the glass.
Loosen the bolts on each side, and adjust the glass (A).
If necessary, repeat on opposite side.
The side-to-side fit of the glass weatherstrip can be adjusted by loosening the frame mounting bolts and moving the frame right or left and forward or backward by hand (see «FRAME AND DRAIN TUBE REPLACEMENT»(/acura/rsx/i-2001-2004/remont/sun-rooft-topconvertible-top/#moonroof) ).

Scheme 4

Scheme 4: Glass Replacement

Scheme 5

Tilt-up the glass.
Remove the bolts from both sides.
Remove the glass (A) by lifting it up. Do not damage the roof panel.
Install the glass in the reverse order of removal, and adjust the glass height (see «GLASS HEIGHT ADJUSTMENT»(/acura/rsx/i-2001-2004/remont/sun-rooft-topconvertible-top/#moonroof__glass-height-adjustment) ).
Check for water leaks. Use free-flowing water from a hose without a nozzle. Do not use high-pressure water.

Scheme 6

Scheme 6: Sunshade Replacement

Remove the glass.
Remove the screws from the front edges of both sunshade rails (A).
Carefully slide the sunshade (B) forward, then remove it.
Install the sunshade in the reverse order of removal, and adjust the glass height (see «GLASS HEIGHT ADJUSTMENT»(/acura/rsx/i-2001-2004/remont/sun-rooft-topconvertible-top/#moonroof__glass-height-adjustment) ).
Check for water leaks. Use free-flowing water from a hose without a nozzle. Do not use high-pressure water.

Scheme 7

Scheme 7: Motor Replacement

Remove the headliner (see «HEADLINER REMOVAL/INSTALLATION»(/acura/rsx/i-2001-2004/remont/exteriorinterior-trim/#interior-trim__headliner-removalinstallation) ).
Put on gloves to protect your hands. Disconnect the connector (A), and remove the bolts, then remove the motor (B).
Install the motor in the reverse order of removal, and note these items: Make sure the connector is plugged in properly. Check the motor operation.

Scheme 8

Scheme 8: Frame and Drain Tube Replacement

Scheme 9

Scheme 10

Scheme 11

Remove these items: Headliner (see «HEADLINER REMOVAL/INSTALLATION»(/acura/rsx/i-2001-2004/remont/exteriorinterior-trim/#interior-trim__headliner-removalinstallation) ) Moonroof glass (see «GLASS HEIGHT ADJUSTMENT»(/acura/rsx/i-2001-2004/remont/sun-rooft-topconvertible-top/#moonroof__glass-height-adjustment) )
Put on gloves to protect your hands. Disconnect the motor connector (A) and drain tubes (B), and remove the interior harness (C) by detaching the harness clips (D) and removing the cushion tape (E).
With an assistant holding the frame (F), remove the bolts (G), starting at the rear. Release the rear hooks (H) by moving the frame forward, then remove the frame.
With the help of an assistant, carefully remove the frame through the door opening. Take care not to scratch the interior trim and body, or tear the seat covers.
To remove the front drain valve (A) from the body, remove the kick panel, left or right (see «TRIM REMOVAL/INSTALLATION - DOOR AREAS»(/acura/rsx/i-2001-2004/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-door-areas) ). Detach the clips (B, C), and on the left A-pillar, release the interior harness (D) from the clips (C).
To remove the rear drain valve (A) from the cargo area, remove the cargo area side trim panel, left or right (see «TRIM REMOVAL/INSTALLATION - CARGO AREA»(/acura/rsx/i-2001-2004/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-cargo-area) ). Release the rear drain tube (B) from the clip (C), and tie a string to the end of the drain tube, then pull the drain tube down out of the C-pillar.
Install the frame and drain tube in the reverse order of removal, and note these items: Before installing the frame, clear the drain tubes and drain valves using compressed air. Check the frame seal. Clean the surface of the frame. When installing the frame, first attach the rear hooks into the body holes. Make sure the connector is plugged in properly. When connecting the drain tube, slide it over the frame nozzle at least 10 mm (0.39 in.). Install the tube clip (A) on the drain tube (B) as shown.
Check for water leaks. Use free-flowing water from a hose without a nozzle. Do not use high-pressure water.

Cable Assembly Replacement

Note. Put on gloves to protect your hands.

Scheme 12

Scheme 12: Cable Assembly Replacement

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Remove the frame (see «FRAME AND DRAIN TUBE REPLACEMENT»(/acura/rsx/i-2001-2004/remont/sun-rooft-topconvertible-top/#moonroof) ).
Remove these items from the frame: Sunshade (see «SUNSHADE REPLACEMENT»(/acura/rsx/i-2001-2004/remont/sun-rooft-topconvertible-top/#moonroof) ) Motor (see «MOTOR REPLACEMENT»(/acura/rsx/i-2001-2004/remont/sun-rooft-topconvertible-top/#moonroof) )
Remove the screws, then remove the drain channel (A). Take care not to twist or lift the drain channel seal (B).
From both sides, remove the clips (A), nuts (B), and screws (C), then remove the front drain channels (D) and front rail holders (E).
Put on gloves to protect your hands. From the motor bracket portion and both guide rail portions, remove the screws (A, B) and nuts (C), then remove the guide rails (D), grommets (E), and cable assembly (F) from the frame (G). Take care not to bend the cable tubes (H).
From both sides, remove the anchor springs (A) and glass bracket (B), and slide cable assembly (C) rearward.
Remove the glass bracket (A), slider (B), lifter (C), and slide stop link (D) from the guide rail (E), and remove the inner cable end (F) from the lifter.
Separate the glass bracket (A), slider (B), slide stop link (C), and lifter (D).
Pull the anchor rod (A) out from the guide rail (B).
Install the cable assembly in the reverse order of removal, and note these items: Worn or damaged parts should be replaced. Apply multipurpose grease to the groove portions of the lifter (A) and slide stop link (B) and to the sliding portions of the guide rail (C) indicated by the arrows. After reinstalling the cable assembly (D) on the frame (E), fill the groove in both grommets (F) with sealant (G). Check the frame seal. When reinstalling the anchor rod (H), insert it into the guide rail (I) by turning the stop (J) 90°. Take care not to twist or lift the drain channel seal. Before reinstalling the motor, align the tilt-up position of the lifter (K) on each side. Be sure the bushing (L) on the glass bracket (M) contacts the top end of the groove (N) in the lifter. Before reinstalling the motor, install the frame and glass, then check the opening drag (see «CLOSING FORCE AND OPENING DRAG CHECK»(/acura/rsx/i-2001-2004/remont/sun-rooft-topconvertible-top/#moonroof) ).

Scheme 24

Scheme 24: Closing Force and Opening Drag Check

Scheme 25

Remove the headliner (see «HEADLINER REMOVAL/INSTALLATION»(/acura/rsx/i-2001-2004/remont/exteriorinterior-trim/#interior-trim__headliner-removalinstallation) ).
Closing force check: With a shop towel (A) on the leading edge of the glass (B), attach a spring scale (C) as shown. Have an assistant hold the switch to close the glass while you measure the force required to stop it. Read the force as soon as the glass stops moving, then immediately release the switch and spring scale. Closing Force: 200-290 N (20-30 kgf, 44-66 lbf)
If the force is not within specification, remove the moonroof motor (see «MOTOR REPLACEMENT»(/acura/rsx/i-2001-2004/remont/sun-rooft-topconvertible-top/#moonroof) ), then check these items: The gear position and the inner cable for breakage and damage. If the gear portion is broken, replace the motor. If the inner cable is damaged, remove the frame (see «FRAME AND DRAIN TUBE REPLACEMENT»(/acura/rsx/i-2001-2004/remont/sun-rooft-topconvertible-top/#moonroof) ), and replace the cable assembly (see «CABLE ASSEMBLY REPLACEMENT»(/acura/rsx/i-2001-2004/remont/sun-rooft-topconvertible-top/#moonroof__cable-assembly-replacement) ). The moonroof motor (see «MOTOR TEST»(/acura/rsx/i-2001-2004/remont/sun-rooft-topconvertible-top/#power-moonroof) ). If the motor fails to run or doesn't turn smoothly, replace it. The opening drag. Go to step 4.
Opening drag check: Protect the leading edge of the glass with a shop towel (A). Measure the effort required to open the glass using a spring scale (B) as shown.
If the load is over 40 N (4 kgf, 9 lbf), check these items: The side clearance and glass height adjustment (see «GLASS HEIGHT ADJUSTMENT»(/acura/rsx/i-2001-2004/remont/sun-rooft-topconvertible-top/#moonroof__glass-height-adjustment) ). For broken or damaged sliding parts. If any sliding parts are damaged, replace them.
