Seat Heaters Acura RSX I

Seats 5 illustrations ~142 words

Scheme 39

Scheme 39: Canada
Scheme 39: Canada

Scheme 40

Scheme 40: Canada
Scheme 40: Canada

Scheme 41

Scheme 41: Canada
Scheme 41: Canada

Scheme 42

Scheme 42
Scheme 42
  1. Remove the dashboard center lower cover (see «DASHBOARD CENTER LOWER COVER REMOVAL/INSTALLATION»(/acura/rsx/i-2001-2004/remont/exteriorinterior-trim/#dashboard) ).
  2. Disconnect the 10P connector (A) from the seat heater switch (B), then remove the switch.
  3. Check for continuity in each switch position according to the table.
  4. If the check is not as specified, replace the bulb(s) (C) or the switch.

Scheme 43

Scheme 43: Canada
Scheme 43: Canada
  1. Remove the front seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/rsx/i-2001-2004/remont/seats/#seat-system__front-seat-removalinstallation) ).
  2. Disconnect the 2P connector (A) from the seat heater.
  3. The temperature of the seat must be below 122°F (50°C). Check for continuity between the No. 1 and No. 2 terminals. There should be continuity. If there is no continuity, replace the seat cushion (see «FRONT SEAT DISASSEMBLY/REASSEMBLY - DRIVER'S»(/acura/rsx/i-2001-2004/remont/seats/#seat-system__front-seat-disassemblyreassembly-drivers) ).
