Turn Signal/hazard Flasher Acura RSX I

Exterior Lights 5 illustrations ~390 words

Scheme 32

Scheme 32: Component Location Index

Scheme 33

Scheme 33: Circuit Diagram

Scheme 34

Scheme 34: Turn Signal/Hazard Relay Input Test
  1. Remove the turn signal/hazard relay (A) from the under-dash fuse/relay box (B).
  2. Inspect the relay and fuse/relay box socket terminals to be sure they are all making good contact. If the terminals are bent, loose, or corroded, repair them as necessary, and recheck the system. If the terminals look OK, go to step 3.
  3. Make these input tests at the fuse/relay box. If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, the turn signal/hazard relay must be faulty; replace it. SYSTEM DESCRIPTION Cavity Test condition Test: Desired result Possible cause if result is not obtained 1 Under all conditions Check for continuity to ground: There should be continuity. Poor ground(G301) An open in the wire 3 Ignition switch ON (II) Check for voltage to ground: There should be battery voltage. Blown No. 19 (7.5 A) fuse in the under-dash fuse/relay box Faulty hazard warning switch An open in the wire Hazard warning switch ON Check for voltage to ground: There should be battery voltage. Blown No. 5 (15 A) [No. 15 (10 A)] fuse in the under-hood fuse/relay box Faulty hazard warning switch An open in the wire 2 Ignition switch ON (II) and turn signal switch in right or left position Connect No. 2 terminal to No. 3 terminal: Right or left turn signal lights should come on. Blown No. 19 (7.5 A) fuse in the under-dash fuse/relay box Poor ground (G201, G301, G401, G601) Faulty turn signal switch An open in the wire Hazard warning switch ON Connect No. 2 terminal to No. 3 terminal: Right or left turn signal lights should come on. Blown No. 5 (15 A) [No. 15 (10 A)] fuse in the under-hood fuse/relay box Poor ground (G201, G301, G401, G601) Faulty hazard warning switch An open in the wire [ ]: '05-06 models

Scheme 35

Scheme 35: Hazard Warning Switch Test

Scheme 36

Scheme 36
  1. Remove the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/rsx/i-2001-2004/remont/entertainment-systems/#audio-system) ).
  2. Disconnect the 10P connector (A) from the hazard warning switch (B).
  3. Remove the two screws and the hazard warning switch.
  4. Check for continuity between the terminals in each switch position according to the table.
  5. If the continuity is not as specified, replace the illumination bulb (C) or the switch.
