Scheme 16
Scheme 17
- Remove the support strut from each side (see «HATCH SUPPORT STRUT REPLACEMENT»(/acura/rsx/i-2001-2004/remont/exterior-body-panels/#hatch) ).
- Remove the headliner (see «HEADLINER REMOVAL/INSTALLATION»(/acura/rsx/i-2001-2004/remont/exteriorinterior-trim/#interior-trim__headliner-removalinstallation) ).
- Slightly loosen each screw and nut.
- Adjust the hatch (A) alignment in the following sequence: Adjust the hatch hinges (B) right and left, as well as forward and rearward, using the elongated holes. Turn the hatch edge cushions (C) in or out, as necessary, to make the hatch fit flush with the body at the side edges. Adjust the fit between the hatch and hatch opening by moving the striker (D).
- Tighten each screw and nut securely.
- Check that the hatch opens properly and locks securely.
- Reinstall the support struts securely.
- Reinstall all remaining removed parts.
- Apply multipurpose grease to the pivot portion of the hatch hinges as indicated by the arrows.
Note. Have an assistant help you when removing and installing the support strut. Take care not to scratch the body and hatch.
Scheme 18
- Remove the pivot bolt (A) from the body.
- Remove the pivot bolt (B) from the hatch, then remove the support strut (C).
- Install the support strut in the reverse order of removal.
Scheme 19
- Remove the hatch weatherstrip (A) by pulling out on it.
- Locate the painted alignment mark (B) on the hatch weatherstrip. Align the painted mark with the alignment tab in the center of the hatch opening, and install the hatch weatherstrip all the way around in the direction shown. Make sure there are no wrinkles in the weatherstrip.
- Check for water leaks.
