Scheme 203: Component Location Index

DTC P1077: IMT Valve Stuck in High RPM Position

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review GENERAL TROUBLESHOOTING INFORMATION .

Scheme 204

Scheme 204: DTC P1077: IMT Valve Stuck in High RPM Position

Scheme 205

Scheme 206

Scheme 207

Scheme 208

Scheme 209

Scheme 210

Turn the ignition switch to ON (II).
Clear the DTC with the HDS.
Start the engine, and let it idle.
Make sure the IMT VALVE CMD is CLOSED in the DATA LIST with the HDS. Is CLOSED indicated? YES - Go to step 5 . NO - Go to step 29 .
Check the IMT VALVE SW in the DATA LIST with the HDS. Is OPEN indicated? YES - Go to step 6 . NO - Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the IMT actuator and the PCM.
Turn the ignition switch to LOCK (0).
Disconnect the IMT actuator 5P connector.
Turn the ignition switch to ON (II).
Check the IMT VALVE SW in the DATA LIST with the HDS. Is CLOSED indicated? YES - Go to step 14 . NO - Go to step 10 .
Turn the ignition switch to LOCK (0).
Jump the SCS line with the HDS.
Disconnect PCM connector B (24P).
Check for continuity between PCM connector terminal B11 and body ground. Is there continuity? YES - Repair short in the wire between the PCM (B11) and the IMT actuator, then go to step 25 . NO - Go to step 31 .
Turn the ignition switch to LOCK (0).
Jump the SCS line with the HDS.
Disconnect PCM connector B (24P).
Check for continuity between PCM connector terminal B4 and body ground. Is there continuity? YES - Repair short in the wire between the PCM (B4) and the IMT actuator, then go to step 25 . NO - Go to step 18 .
Connect IMT actuator 5P connector terminal No. 5 to body ground with a jumper wire.
Check for continuity between PCM connector terminal B4 and body ground. Is there continuity? YES - Go to step 20 . NO - Repair open in the wire between the PCM (B4) and the IMT actuator, then go to step 25 .
Check for continuity between PCM connector terminal B3 and body ground. Is there continuity? YES - Repair short in the wire between the PCM (B3) and the IMT actuator, then go to step 25 . NO - Go to step 21 .
Connect IMT actuator 5P connector terminal No. 4 to body ground with a jumper wire.
Check for continuity between PCM connector terminal B3 and body ground. Is there continuity? YES - Go to step 23 . NO - Repair open in the wire between the PCM (B3) and the IMT actuator, then go to step 25 .
Remove the IMT actuator (see «IMT ACTUATOR REPLACEMENT»(/acura/rl/ii-2008-2012/remont/testing-diagnostics/#intake-air-system) ).
Move the IMT valve by hand. Does it move smoothly? YES - Substitute a known-good IMT actuator (see «IMT ACTUATOR REPLACEMENT»(/acura/rl/ii-2008-2012/remont/testing-diagnostics/#intake-air-system) ), then go to step 25 and recheck. If DTC P1077 is not indicated, replace the IMT actuator (see «IMT ACTUATOR REPLACEMENT»(/acura/rl/ii-2008-2012/remont/testing-diagnostics/#intake-air-system) ), then go to step 25 . If DTC P1077 is indicated, go to step 33 . NO - Remove the engine cover (see «REMOVAL»(/acura/rl/ii-2008-2012/remont/mechanical/#intake-manifold-and-exhaust-system) ), and repair the stuck valve. If necessary, replace the intake manifold (see «INTAKE MANIFOLD REMOVAL AND INSTALLATION»(/acura/rl/ii-2008-2012/remont/mechanical/#intake-manifold-and-exhaust-system) ), then go to step 25 .
Reconnect all connectors.
Turn the ignition switch to ON (II).
Reset the PCM with the HDS.
Do «PCM IDLE LEARN PROCEDURE»(/acura/rl/ii-2008-2012/remont/testing-diagnostics/#idle-control-system__pcm-idle-learn-procedure) .
Check for Temporary DTCs or DTCs with the HDS. Is DTC P1077 Indicated? YES - Check for poor connections or loose terminals at the IMT actuator and the PCM. If the PCM was updated, substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rl/ii-2008-2012/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-pcm) ), then recheck. If the PCM was substituted, go to step 1 . NO - Go to step 30 .
Monitor the OBD STATUS for DTC P1077 in the DTCs MENU with the HDS. Does the screen indicate PASSED? YES - If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(/acura/rl/ii-2008-2012/remont/testing-diagnostics/#pgm-fi-system__pcm-replacement) ). If any other Temporary DTCs or DTCs were indicated in step 29, go to the indicated DTCs troubleshooting. NO - If the screen indicates FAILED, check for poor connections or loose terminals at the IMT actuator and the PCM. If the PCM was updated, substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rl/ii-2008-2012/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-pcm) ), then recheck. If the PCM was substituted, go to step 1 . If the screen indicates NOT COMPLETED, keep idling until a result comes on.
Turn the ignition switch to LOCK (0).
Reconnect all connectors.
Update the PCM if it does not have the latest software (see «PCM UPDATE»(/acura/rl/ii-2008-2012/remont/testing-diagnostics/#pgm-fi-system__pcm-update) ), or substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rl/ii-2008-2012/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-pcm) ).
Check for Temporary DTCs or DTCs with the HDS. Is DTC P1077 indicated? YES - Check for poor connections or loose terminals at the IMT actuator and the PCM. If the PCM was updated, substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rl/ii-2008-2012/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-pcm) ), then recheck. If the PCM was substituted, go to step 1 . NO - Go to step 35 .
Monitor the OBD STATUS for DTC P1077 in the DTCs MENU with the HDS. Does the screen indicate PASSED? YES - If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(/acura/rl/ii-2008-2012/remont/testing-diagnostics/#pgm-fi-system__pcm-replacement) ). If any other Temporary DTCs or DTCs were indicated in step 34, go to the indicated DTCs troubleshooting. NO - If the screen indicates FAILED, check for poor connections or loose terminals at the IMT actuator and the PCM. If the PCM was updated, substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rl/ii-2008-2012/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-pcm) ), then recheck. If the PCM was substituted, go to step 1 . If the screen indicates NOT COMPLETED, keep idling until a result comes on.

DTC P1078: IMT Valve Stuck in Low RPM Position

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review GENERAL TROUBLESHOOTING INFORMATION .

Scheme 211

Scheme 211: DTC P1078: IMT Valve Stuck in Low RPM Position

Scheme 212

Scheme 213

Scheme 214

Scheme 215

Scheme 216

Scheme 217

Scheme 218

Scheme 219

Scheme 220

Scheme 221

Scheme 222

Turn the ignition switch to ON (II).
Clear the DTC with the HDS.
Start the engine. Hold the engine speed above 4,000 rpm.
Make sure the IMT VALVE CMD is OPEN in the DATA LIST with the HDS.
Check the IMT VALVE SW in the DATA LIST with the HDS. Is CLOSED indicated? YES - Go to step 6 . NO - Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the IMT actuator and the PCM.
Let the engine idle, then turn the ignition switch to LOCK (0).
Disconnect the IMT actuator 5P connector.
Turn the ignition switch to ON (II).
Measure the voltage between IMT actuator 5P connector terminal No. 1 and body ground. Is there about 5 V? YES - Go to step 10 . NO - Repair open in the wire between the PCM (C14) and the IMT actuator, then go to step 27 .
Measure the voltage between IMT actuator 5P connector terminal No. 3 and body ground. Is there about 5 V? YES - Go to step 11 . NO - Go to step 16 .
Turn the ignition switch to LOCK (0).
Jump the SCS line with the HDS.
Disconnect PCM connector C (22P).
Connect IMT actuator 5P connector terminal No. 2 to body ground with a jumper wire.
Check for continuity between PCM connector terminal C12 and body ground. Is there continuity? YES - Go to step 21 . NO - Repair open in the wire between the PCM (C12) and the IMT actuator, then go to step 29 .
Turn the ignition switch to LOCK (0).
Jump the SCS line with the HDS.
Disconnect PCM connector B (24P).
Connect IMT actuator 5P connector terminal No. 3 to body ground with a jumper wire.
Check for continuity between PCM connector terminal B11 and body ground. Is there continuity? YES - Go to step 36 . NO - Repair open in the wire between the PCM (B11) and the IMT actuator, then go to step 27 .
Check for continuity between PCM connector terminal B4 and body ground. Is there continuity? YES - Repair short in the wire between the PCM (B4) and the IMT actuator, then go to step 29 . NO - Go to step 22 .
Connect IMT actuator 5P connector terminal No. 5 to body ground with a jumper wire.
Check for continuity between PCM connector terminal B4 and body ground. Is there continuity? YES - Go to step 24 . NO - Repair open in the wire between the PCM (B4) and the IMT actuator, then go to step 29 .
Check for continuity between PCM connector terminal B3 and body ground. Is there continuity? YES - Repair short in the wire between the PCM (B3) and the IMT actuator, then go to step 29 . NO - Go to step 25 .
Connect IMT actuator 5P connector terminal No. 4 to body ground with a jumper wire.
Check for continuity between PCM connector terminal B3 and body ground. Is there continuity? YES - Go to step 27 . NO - Repair open in the wire between the PCM (B3) and the IMT actuator, go to step 29 .
Remove the IMT actuator (see «IMT ACTUATOR REPLACEMENT»(/acura/rl/ii-2008-2012/remont/testing-diagnostics/#intake-air-system) ).
Move the IMT valve by hand. Does it move smoothly? YES - Substitute a known-good IMT actuator (see «IMT ACTUATOR REPLACEMENT»(/acura/rl/ii-2008-2012/remont/testing-diagnostics/#intake-air-system) ), then go to step 29 and recheck. If DTC P1078 is not indicated, replace the IMT actuator (see «IMT ACTUATOR REPLACEMENT»(/acura/rl/ii-2008-2012/remont/testing-diagnostics/#intake-air-system) ), then go to step 29 . If DTC P1078 is indicated, go to step 37 . NO - Remove the engine cover (see «REMOVAL»(/acura/rl/ii-2008-2012/remont/mechanical/#intake-manifold-and-exhaust-system) ), and repair the stuck valve. If necessary, replace the intake manifold (see «INTAKE MANIFOLD REMOVAL AND INSTALLATION»(/acura/rl/ii-2008-2012/remont/mechanical/#intake-manifold-and-exhaust-system) ), then go to step 29 .
Reconnect all connectors.
Turn the ignition switch to ON (II).
Reset the PCM with the HDS.
Do «PCM IDLE LEARN PROCEDURE»(/acura/rl/ii-2008-2012/remont/testing-diagnostics/#idle-control-system__pcm-idle-learn-procedure) .
Start the engine. Hold the engine speed at 4,000 rpm for 10 seconds, then let it idle.
Check for Temporary DTCs or DTCs with the HDS. Is DTC P1078 indicated? YES - Check for poor connections or loose terminals at the IMT actuator and the PCM, then go to step 1 . NO - Go to step 35 .
Monitor the OBD STATUS for DTC P1078 in the DTCs MENU with the HDS. Does the screen indicate PASSED? YES - Troubleshooting is complete. If any other Temporary DTCs or DTCs were indicated in step 34, go to the indicated DTCs troubleshooting. NO - If the screen indicates FAILED, check for poor connections or loose terminals at the IMT actuator and the PCM, then go to step 1 . If the screen indicates NOT COMPLETED, keep idling until a result comes on.
Reconnect all connectors.
Update the PCM if it does not have the latest software (see «PCM UPDATE»(/acura/rl/ii-2008-2012/remont/testing-diagnostics/#pgm-fi-system__pcm-update) ), or substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rl/ii-2008-2012/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-pcm) ).
Start the engine, and hold the engine speed at 4,000 rpm for 10 seconds, then let it idle.
Check for Temporary DTCs or DTCs with the HDS. Is DTC P1078 indicated? YES - Check for poor connections or loose terminals at the IMT actuator and the PCM. If the PCM was updated, substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rl/ii-2008-2012/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-pcm) ), then go to step 38 . If the PCM was substituted, go to step 1 . NO - Go to step 40 .
Monitor the OBD STATUS for DTC P1078 in the DTCs MENU with the HDS. Does the screen indicate PASSED? YES - If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(/acura/rl/ii-2008-2012/remont/testing-diagnostics/#pgm-fi-system__pcm-replacement) ). If any other Temporary DTCs or DTCs were indicated in step 39, go to the indicated DTCs troubleshooting. NO - If the screen indicates FAILED, check for poor connections or loose terminals at the IMT actuator and the PCM. If the PCM was updated, substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rl/ii-2008-2012/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-pcm) ), then go to step 38 . If the PCM was substituted, go to step 1 . If the screen indicates NOT COMPLETED, go to step 38 .

Carbon Accumulation Check

Note. If the malfunction indicator lamp (MIL) has been reported on, check for diagnostic trouble codes (DTCs).

Scheme 223

Scheme 223: Carbon Accumulation Check

Connect the HDS tot he data link connector (DLC) (A) located under the driver's side of the dashboard.
Turn the ignition switch to ON (II).
Make sure the HDS communicates with the PCM. If it does not, go to «DLC CIRCUIT TROUBLESHOOTING»(/acura/rl/ii-2008-2012/remont/testing-diagnostics/#pgm-fi-system__dlc-circuit-troubleshooting) .
Start the engine. Hold the engine speed at 3,000 rpm without load (in P or N) until the radiator fan comes on, then let it idle.
Check the REL TP SENSOR in the DATA LIST with the HDS. The reading should be below 2.46 deg. If it is not, clean the throttle body (see «THROTTLE BODY CLEANING»(/acura/rl/ii-2008-2012/remont/testing-diagnostics/#intake-air-system__throttle-body-cleaning) ).

Throttle Position Learning Check

Note. If the malfunction indicator lamp (MIL) has been reported on, check for diagnostic trouble codes (DTCs).

Scheme 224

Scheme 224: Throttle Position Learning Check

Connect the HDS to the data link connector (DLC) (A) located under the driver's side of the dashboard.
Turn the ignition switch to ON (II).
Make sure the HDS communicates with the PCM. If it does not, go to «DLC CIRCUIT TROUBLESHOOTING»(/acura/rl/ii-2008-2012/remont/testing-diagnostics/#pgm-fi-system__dlc-circuit-troubleshooting) .
Select the INSPECTION MENU with the HDS.
Do the TP LEARNING CHECK in the ETCS TEST. If needed, clean the throttle body (see «THROTTLE BODY CLEANING»(/acura/rl/ii-2008-2012/remont/testing-diagnostics/#intake-air-system__throttle-body-cleaning) ).

Throttle Body Cleaning

CAUTION

Do not insert your fingers into the installed throttle body when you turn the ignition switch to ON (II) or while the ignition switch is ON (II). If you do, you will seriously injure your fingers if the throttle valve is activated.

Scheme 225

Check for damage to the air cleaner element. If the air cleaner element is damaged, replace it (see «AIR CLEANER ELEMENT INSPECTION/ REPLACEMENT»(/acura/rl/ii-2008-2012/remont/testing-diagnostics/#intake-air-system) ).
Remove the throttle body (see «THROTTLE BODY REMOVAL/INSTALLATION»(/acura/rl/ii-2008-2012/remont/testing-diagnostics/#intake-air-system__throttle-body-removalinstallation) ).
Clean off the carbon from the throttle valve and inside the throttle body with a paper towel soaked in throttle plate cleaner. NOTE: Remove the throttle body to clean it. Be careful not to pinch your fingers. To avoid removing the molybdenum coating, do not clean the bearing area of the throttle shaft (A). Do not spray throttle plate cleaner directly on the throttle body. Use Acura throttle plate cleaner.
Install the throttle body (see «THROTTLE BODY REMOVAL/INSTALLATION»(/acura/rl/ii-2008-2012/remont/testing-diagnostics/#intake-air-system__throttle-body-removalinstallation) ).
Reset the PCM with the HDS.
Turn the ignition switch to ON (II), and wait 2 seconds.
Do «PCM IDLE LEARN PROCEDURE»(/acura/rl/ii-2008-2012/remont/testing-diagnostics/#idle-control-system__pcm-idle-learn-procedure) .

Scheme 226

Scheme 226: Air Cleaner Removal/Installation

Remove the battery trim (see «UPPER FENDER TRIM REPLACEMENT»(/acura/rl/ii-2008-2012/remont/exteriorinterior-trim/#exterior-trim) ), and the left upper fender trim (see «UPPER FENDER TRIM REPLACEMENT»(/acura/rl/ii-2008-2012/remont/exteriorinterior-trim/#exterior-trim) ).
Disconnect the MAF sensor/IAT sensor connector.
Remove the bolts (A) and the air cleaner (B).
Install the parts in the reverse order of removal.

Scheme 227

Scheme 227: Air Cleaner Element Inspection/ Replacement

Remove the battery trim (see «UPPER FENDER TRIM REPLACEMENT»(/acura/rl/ii-2008-2012/remont/exteriorinterior-trim/#exterior-trim) ), and the left upper fender trim (see «UPPER FENDER TRIM REPLACEMENT»(/acura/rl/ii-2008-2012/remont/exteriorinterior-trim/#exterior-trim) ).
Open the air cleaner housing cover (A).
Remove the air cleaner element (B) from the air cleaner housing cover.
Check the air cleaner element for damage or clogging. If it is damage or clogged, replace it. NOTE: Do not use compressed air to clean the air cleaner element.
Clean and remove any debris from inside the air cleaner housing.
Install the parts in the reverse order of removal. If you did not replace the air cleaner element, this procedure is complete. If the maintenance minder required air cleaner element replacement, reset «MAINTENANCE MINDER»(/acura/rl/ii-2008-2012/remont/reset-procedures/#maintenance) . If you replaced the air cleaner element, reset the PCM (see «PCM RESET»(/acura/rl/ii-2008-2012/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__pcm-reset) ), and do «PCM IDLE LEARN PROCEDURE»(/acura/rl/ii-2008-2012/remont/testing-diagnostics/#idle-control-system__pcm-idle-learn-procedure) .

Scheme 228

Scheme 228: Intake Air Resonator Removal/Installation

Scheme 229

Remove the front bumper (see «FRONT BUMPER REMOVAL/INSTALLATION»(/acura/rl/ii-2008-2012/remont/exterior-body-panels/#bumpers__front-bumper-removalinstallation) ).
Remove the air cleaner (see «AIR CLEANER REMOVAL/INSTALLATION»(/acura/rl/ii-2008-2012/remont/testing-diagnostics/#intake-air-system) ).
Remove the intake air duct (A) and the tube (B).
Remove the bolts and the intake air resonator (A).
Install the parts in the reverse order of removal.

Scheme 230

Scheme 230: IMT Actuator Replacement

Remove the engine cover (see «REMOVAL»(/acura/rl/ii-2008-2012/remont/mechanical/#intake-manifold-and-exhaust-system) ).
Disconnect the IMT actuator 5P connector (A).
Remove the bolts and the IMT actuator (B).
Install the parts in the reverse order of removal with a new O-ring (C).

Throttle Body Removal/Installation
