Cooling System Acura RL II рестайлинг

Cooling System (mechanical) 34 illustrations ~1755 words

Scheme 1

Scheme 1: Component Location Index
Scheme 1: Component Location Index

Scheme 2

Scheme 2: Radiator Cap Test
Scheme 2: Radiator Cap Test
  1. Wait until the engine is cool, then carefully remove the radiator cap (A). Wet the radiator cap seal with engine coolant, then install it on a commercially available pressure tester (B).
  2. Apply a pressure of 93 - 123 kPa (0.95 - 1.25 kgf/cm 2 , 14 - 18 psi).
  3. Check for a drop in pressure.
  4. If the pressure drops, replace the cap.

Scheme 3

Scheme 3: Radiator Test
Scheme 3: Radiator Test
  1. Wait until the engine is cool, then carefully remove the radiator cap, and fill the radiator with engine coolant to the top of the filler neck.
  2. Attach a commercially available pressure tester (A) to the radiator, and apply a pressure of 93 - 123 kPa (0.95 - 1.25 kgf/cm 2 , 14 - 18 psi).
  3. Inspect for engine coolant leaks and a drop in pressure.
  4. Remove the tester, then reinstall the radiator cap.

Scheme 4

Scheme 4: Fan Motor Test
Scheme 4: Fan Motor Test
  1. Disconnect the 2P connectors from the radiator fan motor (A) and the condenser fan motor (B).
  2. Test each motor by connecting battery power to terminal No. 1 and ground to terminal No. 2.
  3. If either motor fails to run or does not run smoothly, replace it (see «FAN, FAN MOTOR, AND SHROUD REMOVAL AND INSTALLATION»(/acura/rl/ii-2008-2012/remont/cooling-system-mechanical/#cooling-system) ).

Thermostat Test

Replace the thermostat if it is stuck open at room temperature.

To test a closed thermostat

Scheme 5

Scheme 5: Thermostat Test
Scheme 5: Thermostat Test
  1. Suspend the thermostat (A) in a container of water. Do not let the thermometer (B) touch the bottom of the hot container.
  2. Heat the water and check the temperature with a thermometer. Check the temperature when the thermostat first opens, then check the temperature when the thermostat is fully open.
  3. Measure the lift height of the thermostat when it is fully open. Standard Thermostat Lift Height: Above 10.0 mm (0.39 in.) Starts Opening: 169-176°F (76-80°C) Fully Open: 194°F (90°C)

Scheme 6

Scheme 6: Water Pump Inspection
Scheme 6: Water Pump Inspection
  1. Remove the timing belt (see «TIMING BELT REMOVAL»(/acura/rl/ii-2008-2012/remont/mechanical/#cylinder-head) ).
  2. Turn the water pump counterclockwise, and make sure that it turns freely. If it doesn't, replace the water pump (see «WATER PUMP REPLACEMENT»(/acura/rl/ii-2008-2012/remont/cooling-system-mechanical/#cooling-system) ). NOTE: When you check the water pump, you may see a small amount of "weeping" from the bleed holes (A). This is normal.
  3. Install the timing belt (see «TIMING BELT INSTALLATION»(/acura/rl/ii-2008-2012/remont/mechanical/#cylinder-head__timing-belt-installation) ).

Scheme 7

Scheme 7: Water Pump Replacement
Scheme 7: Water Pump Replacement
  1. Drain the engine coolant (see «COOLANT REPLACEMENT»(/acura/rl/ii-2008-2012/remont/cooling-system-mechanical/#cooling-system) ).
  2. Remove the timing belt (see «TIMING BELT REMOVAL»(/acura/rl/ii-2008-2012/remont/mechanical/#cylinder-head) ).
  3. Remove the timing belt adjuster (see «TIMING BELT DRIVE PULLEY REPLACEMENT»(/acura/rl/ii-2008-2012/remont/mechanical/#cylinder-head) ).
  4. Remove the water pump (A) by removing the five bolts.
  5. Inspect and clean the O-ring groove and the mating surface of the engine block.
  6. Install the water pump with a new O-ring (B) in the reverse order of removal.
  7. Clean up any spilled engine coolant.
  8. Install the timing belt adjuster (see «TIMING BELT DRIVE PULLEY REPLACEMENT»(/acura/rl/ii-2008-2012/remont/mechanical/#cylinder-head) ).
  9. Install the timing belt (see «TIMING BELT INSTALLATION»(/acura/rl/ii-2008-2012/remont/mechanical/#cylinder-head__timing-belt-installation) ).
  10. Refill the radiator with engine coolant, then bleed the air from the cooling system (see step 8 ).

Scheme 8

Scheme 8: Coolant Check
Scheme 8: Coolant Check
  1. Check the coolant level in the coolant reservoir. Make sure it is between the MAX mark (A) and MIN mark (B).
  2. If the coolant level in the coolant reservoir is at or below the MIN mark, add coolant to bring it between the MIN and MAX marks, then inspect the cooling system for leaks.

Scheme 9

Scheme 9: Coolant Replacement
Scheme 9: Coolant Replacement

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12
  1. Start the engine. Set the heater temperature control dial to maximum heat, then turn off the ignition switch. Make sure the engine and the radiator are cool to the touch.
  2. Remove the radiator cap.
  3. Loosen the drain plug (A) and drain the coolant.
  4. Install a rubber hose (A) on the drain bolt (B) located at the rear of the cylinder block, then loosen the drain bolt.
  5. When the coolant stops draining, tighten the drain bolt. Remove the rubber hose.
  6. Tighten the radiator drain plug securely.
  7. Remove the coolant reservoir and drain the coolant, then reinstall the coolant reservoir.
  8. Fill the coolant reservoir to the MAX mark (A) with Acura Long Life Antifreeze/Coolant Type 2 (P/N OL999-9011A).
  9. Pour Acura Long Life Antifreeze/Coolant Type 2 into the radiator up to the base of the filler neck. NOTE: Always use Acura Long Life Antifreeze/Coolant Type 2 (P/N OL999-9011A). Using a non-Acura coolant can result in corrosion, causing the cooling system to malfunction or fail. Acura Long Life Antifreeze/Coolant Type 2 is a mixture of 50% antifreeze and 50% water. Do not add water. Engine Coolant Capacities (Including the reserve tank capacity of 0.58 L (0.153 US gal)): After Coolant Change: 6.0 L (1.59 US gal) After Engine Overhaul: 8.6 L (2.27 US gal)
  10. Install the radiator cap loosely.
  11. Start the engine and let it run until it warms up (the radiator fan comes on at least twice).
  12. Turn off the engine. Check the level in the radiator and add Acura Long Life Antifreeze/Coolant Type 2, if needed. NOTE: Removing the radiator cap while the engine is hot can cause the coolant to spray out. Always let the engine and the radiator cool before removing the cap.
  13. Put the radiator cap on tightly, then run the engine again and check for leaks.
  14. Clean up any spilled engine coolant.
  15. Connect the Honda Diagnostic System (HDS) to the data link connector (DLC) (see step 2 in «GENERAL TROUBLESHOOTING INFORMATION»(/acura/rl/ii-2008-2012/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems) ).
  16. Make sure the HDS communicates with the vehicle and the powertrain control module (PCM). If it doesn't communicate, troubleshoot the DLC circuit (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/rl/ii-2008-2012/remont/testing-diagnostics/#pgm-fi-system__dlc-circuit-troubleshooting) ).
  17. Turn the ignition switch to ON (II).
  18. Select BODY ELECTRICAL with the HDS.
  19. Select ADJUSTMENT in the GAUGE MENU with the HDS.
  20. Select RESET in the MAINTENANCE MINDER with the HDS.
  21. Select MAINTENANCE SUB ITEM 5 RESET with the HDS.

Scheme 13

Scheme 13: Thermostat Replacement
Scheme 13: Thermostat Replacement
  1. Do the battery removal procedure (see «REMOVAL»(/acura/rl/ii-2008-2012/remont/body-electrical/#battery__removal) ).
  2. Drain the engine coolant (see «COOLANT REPLACEMENT»(/acura/rl/ii-2008-2012/remont/cooling-system-mechanical/#cooling-system) ).
  3. Remove the thermostat cover, then remove the thermostat.
  4. Install the thermostat with a new rubber seal and with the pin on the top side.
  5. Do the battery installation procedure (see «INSTALLATION»(/acura/rl/ii-2008-2012/remont/body-electrical/#battery) ).
  6. Refill the radiator with engine coolant (see step 8 ), then bleed the air from the cooling system.
  7. Clean up any spilled engine coolant.

Scheme 14

Scheme 14: Water Passage Replacement
Scheme 14: Water Passage Replacement

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17
  1. Do the battery removal procedure (see «REMOVAL»(/acura/rl/ii-2008-2012/remont/body-electrical/#battery__removal) ).
  2. Drain the engine coolant (see «COOLANT REPLACEMENT»(/acura/rl/ii-2008-2012/remont/cooling-system-mechanical/#cooling-system) ).
  3. Remove the upper radiator hose (A) and the lower radiator hose (B), then disconnect engine coolant temperature (ECT) sensor 1 connector (C) and the exhaust gas recirculation (EGR) valve connector (D).
  4. Remove the water bypass hoses (A) and the heater hoses (B).
  5. Remove the EGR pipe.
  6. Remove the water passage and related parts.
  7. Install the water passage in the reverse order of the removal.
  8. Do the battery installation procedure (see «INSTALLATION»(/acura/rl/ii-2008-2012/remont/body-electrical/#battery) ).
  9. Refill the radiator with engine coolant (see step 8 ), and bleed the air from the cooling system with the heater valve open.
  10. Clean up any spilled engine coolant.

Scheme 18

Scheme 18: Removal
Scheme 18: Removal

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20

Scheme 21

Scheme 21
Scheme 21

Scheme 22

Scheme 22
Scheme 22
  1. Remove the right side fender trim (see «UPPER GRILLE REPLACEMENT»(/acura/rl/ii-2008-2012/remont/exteriorinterior-trim/#exterior-trim) ).
  2. Raise the vehicle on the lift to full height.
  3. Remove the splash shield (see step 31 in «ENGINE REMOVAL»(/acura/rl/ii-2008-2012/remont/mechanical/#engine-removal-and-installation) ).
  4. Remove the harness connectors (A), the ground cable (B), and the harness clamps (C).
  5. Loosen the A/C condenser fan shroud mounting bolts (D).
  6. Lower the vehicle on the lift.
  7. Remove the air intake duct cover (A) and the coolant reservoir (B).
  8. Disconnect the radiator fan control (RFC) connectors (A) and the A/C condenser fan motor connector (B), then remove the harness clamps (C).
  9. Remove the radiator fan control (RFC) unit (see «RFC UNIT REPLACEMENT»(/acura/rl/ii-2008-2012/remont/cooling-fan/#fan-controls) ).
  10. Remove the condenser fan shroud assembly (A).
  11. Remove the radiator fan shroud assembly (B) from right side of the engine compartment.
  12. Disassemble the fan shrouds.

Scheme 23

Scheme 23: Installation
Scheme 23: Installation

Scheme 24

Scheme 24
Scheme 24

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27
  1. Assemble the fan shrouds.
  2. Install the radiator fan shroud assembly (A).
  3. Install the condenser fan shroud assembly (B).
  4. Install the RFC unit (see «RFC UNIT REPLACEMENT»(/acura/rl/ii-2008-2012/remont/cooling-fan/#fan-controls) ).
  5. Connect the RFC connectors (A) and the A/C condenser fan motor connector (B), then install the harness clamps (C).
  6. Install the coolant reservoir (A), and the air intake duct cover (B).
  7. Raise the vehicle on the lift to full height.
  8. Tighten the A/C condenser fan shroud mounting bolts (A).
  9. Install the harness connectors (B), the ground cable (C), and the harness clamps (D).
  10. Install the splash shield (see step 39 on «ENGINE INSTALLATION»(/acura/rl/ii-2008-2012/remont/mechanical/#engine-removal-and-installation) ).
  11. Lower the vehicle on the lift.
  12. Install the right side fender trim (see «UPPER GRILLE REPLACEMENT»(/acura/rl/ii-2008-2012/remont/exteriorinterior-trim/#exterior-trim) ).

Scheme 28

Scheme 28: Radiator Replacement
Scheme 28: Radiator Replacement

Scheme 29

Scheme 29
Scheme 29

Scheme 30

Scheme 30
Scheme 30

Scheme 31

Scheme 31
Scheme 31

Scheme 32

Scheme 32
Scheme 32

Scheme 33

Scheme 33
Scheme 33

Scheme 34

Scheme 34
Scheme 34
  1. Drain the engine coolant (see «COOLANT REPLACEMENT»(/acura/rl/ii-2008-2012/remont/cooling-system-mechanical/#cooling-system) ).
  2. Remove the right side fender trim (see «UPPER GRILLE REPLACEMENT»(/acura/rl/ii-2008-2012/remont/exteriorinterior-trim/#exterior-trim) ).
  3. Raise the vehicle on the lift to full height.
  4. Remove the splash shield (see step 31 in «ENGINE REMOVAL»(/acura/rl/ii-2008-2012/remont/mechanical/#engine-removal-and-installation) ).
  5. Disconnect the lower radiator hose (A).
  6. Disconnect the automatic transmission fluid (ATF) cooler hoses (B), then plug the hose and line.
  7. Disconnect the engine coolant temperature (ECT) sensor 2 connector (C).
  8. Lower the vehicle on the lift.
  9. Disconnect the upper radiator hose (A) and the coolant reservoir hose (B).
  10. Remove the air intake duct cover (A), the coolant reservoir (B), and the radiator upper brackets (C).
  11. Remove the A/C condenser fan shroud assembly and the radiator fan shroud assembly (see «FAN, FAN MOTOR, AND SHROUD REMOVAL AND INSTALLATION»(/acura/rl/ii-2008-2012/remont/cooling-system-mechanical/#cooling-system) ).
  12. Pull up the radiator, then remove the radiator cap (A), the ETC sensor 2 (B), and the drain plug (C).
  13. Reassemble the radiator with new O-rings (D).
  14. Install the radiator. Make sure the lower cushions (E) are set securely.
  15. Install the radiator fan shroud assembly and the A/C condenser fan shroud assembly (see «INSTALLATION»(/acura/rl/ii-2008-2012/remont/cooling-system-mechanical/#cooling-system) ).
  16. Install the radiator upper brackets (A), the coolant reservoir (B), and the air intake duct cover (C).
  17. Install the upper radiator hose (A) and coolant reservoir hose (B).
  18. Lower the vehicle on the lift.
  19. Install the lower radiator hose (A) and the ATF cooler hoses (B).
  20. Connect the ECT sensor 2 connector (C).
  21. Install the splash shield (see step 39 in «ENGINE INSTALLATION»(/acura/rl/ii-2008-2012/remont/mechanical/#engine-removal-and-installation) ).
  22. Lower the vehicle on the lift.
  23. Install the right side fender trim (see «UPPER FENDER TRIM REPLACEMENT»(/acura/rl/ii-2008-2012/remont/exteriorinterior-trim/#exterior-trim) ).
  24. Refill the radiator with engine coolant, and bleed the air from the cooling system with the heater valve open (see step 8 ).
  25. Clean up any spilled engine coolant.
