Wiper System & Washer System Acura RL II

Scheme 1

Scheme 2

Scheme 3

Scheme 4

DTC B1076: Windshield Wiper Signal Error

Note. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A ).

Scheme 5

Scheme 6

Scheme 7

1. Clear the DTCs with the HDS.
2. Turn the ignition switch OFF, and then back ON (II).
3. Turn the wiper switch to INT, LOW, then HIGH for at least 2 seconds each.
4. Check for DTCs with the HDS. Is DTC B1076 indicated? YES - Go to step 5. NO - Intermittent failure, the windshield wiper system is OK at this time. Check for loose poor connections.
5. With the wiper/washer switch OFF, select WINDSHIELD WIPERS from the BODY ELECTRICAL SYSTEM SELECT menu, and enter the DATA LIST.
6. Check the ON/OFF information of the windshield wiper switch (BACK-UP) in the DATA LIST. Is the information indicator OFF? YES - Go to step 7. NO - Go to step 11 .
7. Turn the wiper switch ON (low or high).
8. Check the ON/OFF information of the windshield wiper switch (BACK-UP) in the DATA LIST. Is the information indicator ON? YES - Faulty relay control module; replace the under-hood fuse/relay box. NO - Go to step 9.
9. Disconnect under-hood fuse/relay box connector J (10P) and the wiper/washer switch 8P connector.
10. Check for continuity between the No. 5 terminal of under-hood fuse/relay box connector J (10P) and the No. 5 terminal of the wiper/washer switch (combination switch control unit) 8P connector. Is there continuity? YES - Faulty combination switch control unit; replace the wiper/washer switch. NO - Repair an open in the PNK wire.
11. Disconnect under-hood fuse/relay box connector J (10P).
12. Check for continuity between the No. 5 terminal of under-hood fuse/relay box connector J (10P) and body ground. Is there continuity? YES - Go to step 13. NO - Faulty relay control module; replace the under-hood fuse/relay box.
13. Disconnect the wiper/washer switch 8P connector.
14. Check for continuity between the No. 5 terminal of under-hood fuse/relay box connector J (10P) and body ground. Is there continuity? YES - Repair a short in the PNK wire. NO - Faulty wiper/washer switch; replace it.

DTC B1077: Windshield Wiper (As) Signal Error

Note. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A ).

Scheme 8

Scheme 9

Scheme 10

Scheme 11

1. Clear the DTCs with the HDS.
2. Turn the ignition switch OFF, and then back ON (II).
3. Turn the wiper switch to LOW, then HIGH, for at least 15 seconds in each position.
4. Check for DTCs with the HDS. Is DTC B1077 indicated? YES - Go to step 5. NO - Intermittent failure, the windshield wiper system is OK at this time. Check for loose or poor connections.
5. Turn the ignition switch OFF.
6. Test the wiper motor (see «WIPER MOTOR TEST»(/acura/rl/ii-2004-2008/remont/wiperwasher-systems/#wiper-system-washer-system) ). Does the wiper motor operate correctly? YES - Go to step 7. NO - Replace the windshield wiper motor and recheck.
7. Turn the ignition switch ON (II).
8. Turn the wiper switch to LOW, then HIGH, and check wiper operation. Do the wipers operate normally? YES - Go to step 9. NO - Go to step 12 .
9. Disconnect under-hood fuse/relay box connector K (5P) and the windshield wiper motor 5P connector.
10. Check for continuity between the No. 4 terminal of the windshield wiper motor 5P connector and the No. 5 terminal of under-hood fuse/relay box connector K (5P). Is there continuity? YES - Go to step 11. NO - Repair an open in the WHT wire.
11. Check for continuity between the No. 5 terminal of under-hood fuse/relay box connector K (5P) and body ground. Is there continuity? YES - Repair a short in the WHT wire. NO - Faulty relay control module; replace the under-hood fuse/relay box.
12. Turn the ignition switch OFF, and check the No. 11 (7.5 A) fuse in the driver's under-dash fuse/relay box. Is the fuse OK? YES - Go to step 13. NO - Replace the blown fuse and recheck the system.
13. Turn the ignition switch ON (II).
14. Measure the voltage between the No. 2 terminal of the windshield wiper motor 5P connector and body ground. Is there battery voltage? YES - Go to step 15. NO - Check the No. 9 (30 A) fuse in the under-hood fuse/relay box. If the fuse is OK, repair an open in the RED wire, or replace the faulty windshield wiper motor relay in the under-hood fuse/relay box.
15. Check for continuity between the No. 3 and No. 5 terminals of the windshield wiper motor 5P connector and the No. 2 and No. 4 terminals of under-hood fuse/relay box connector K (5P) respectively. Is there continuity? YES - Faulty relay control module; replace the under-hood fuse/relay box. NO - Repair an open in the BLU or YEL wire.

DTC B1281: Windshield Wiper Switch MIST Position Circuit Malfunction; DTC B1282: Windshield Wiper Switch INT (AUTO) Position Circuit Malfunction; DTC B1283: Windshield Wiper Switch LOW Position Circuit Malfunction; DTC B1284: Windshield Wiper Switch HIGH Position Circuit Malfunction

Note. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A ).

1. Clear the DTCs with the HDS.
2. Turn the ignition switch OFF, and then back ON (II).
3. Turn the windshield wiper switch to MIST, and wait for 2 seconds.
4. Turn the windshield wiper switch OFF, and wait for 2 seconds.
5. Turn the windshield wiper switch to INT (AUTO), and wait for 2 seconds.
6. Turn the windshield wiper switch to LOW, and wait for 2 seconds.
7. Turn the windshield wiper switch in HIGH, and wait for 2 seconds.
8. Check for DTCs with the HDS. Is DTC B1281, B1282, B1283, and/or B1284 indicated? YES - Replace the wiper/washer switch. NO - Intermittent failure, the wiper/washer switch and the combination switch control unit are OK at this time. Check for loose or poor connections.

Wiper/Washer Switch Replacement

Note. The wiper/washer switch is built into the combination switch control unit. For the wiper/washer test, refer to the COMBINATION SWITCH CONTROL UNIT INPUT TEST .

Scheme 12

1. Remove the driver's dashboard undercover (see «DRIVER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION»(/acura/rl/ii-2004-2008/remont/exteriorinterior-trim/#dashboard) ), and the driver's dashboard lower cover (see «DRIVER'S DASHBOARD LOWER COVER REMOVAL/INSTALLATION»(/acura/rl/ii-2004-2008/remont/exteriorinterior-trim/#dashboard) ).
2. Remove the steering column covers (see «STEERING COLUMN REMOVAL AND INSTALLATION»(/acura/rl/ii-2004-2008/remont/manual-power-steering/#power-steering-system-electronic-power-steering-system__steering-column-removal-and-installation) ).
3. Disconnect the combination light switch 12P connector, and dashboard wire harness 8P connector (A) from the wiper/washer switch (B).
4. Remove the two screws, then slide out the wiper/washer switch.

Scheme 13

1. Before troubleshooting the wiper/washer system, troubleshoot the B-CAN System Diagnosis Test Mode A (see «TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A»(/acura/rl/ii-2004-2008/remont/communication-devices/#multiplex-integrated-control-system__troubleshooting-b-can-system-diagnosis-test) ).
2. Remove the driver's dashboard undercover (see «DRIVER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION»(/acura/rl/ii-2004-2008/remont/exteriorinterior-trim/#dashboard) ), and the driver's dashboard lower cover (see «DRIVER'S DASHBOARD LOWER COVER REMOVAL/INSTALLATION»(/acura/rl/ii-2004-2008/remont/exteriorinterior-trim/#dashboard) ).
3. Remove the steering column covers (see «STEERING COLUMN REMOVAL AND INSTALLATION»(/acura/rl/ii-2004-2008/remont/manual-power-steering/#power-steering-system-electronic-power-steering-system__steering-column-removal-and-installation) ).
4. Disconnect the 8P connector (A) from the wiper/washer switch (B).
5. Inspect the connector and socket terminals to be sure they are all making good contact. If the terminals are bent, loose or corroded, repair them as necessary, and recheck the system. If the terminals look OK, go to step 6.
6. With the connector still disconnected, make these input tests at the connector. If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, go to step 7. WIRE CAVITY REFERENCE CHART Cavity Wire Test condition Test: Desired result Possible cause if desired result is not obtained 5 PNK Under all conditions Check for continuity between the No. 5 terminal and under-hood fuse/relay box connector J (10P) No. 5 terminal: There should be continuity. An open in the wire Disconnect under-hood fuse/relay box connector J (10P) Check for continuity between the No. 5 terminal and body ground: There should be no continuity. A short to ground in the wire 4 LT GRN Under all conditions Check for continuity between the No. 4 terminal and driver's under-dash fuse/relay box connector N (45P) No. 28 terminal: There should be continuity. An open in the wire Disconnect driver's under-dash fuse/relay box connector N (45P) Check for continuity between the No. 4 terminal and body ground: There should be no continuity. A short to ground in the wire 1 WHT Under all conditions Check for continuity between the No. 1 terminal and under-hood fuse/relay box connector J (10P) No. 6 terminal: There should be continuity. An open in the wire Disconnect under-hood fuse/relay box connector J (10P) Check for continuity between the No. 1 terminal and body ground: There should be no continuity. A short to ground in the wire
7. Reconnect the 8P connector to the wiper/washer switch, and make these input tests at the connector. If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, replace the wiper/washer switch (combination switch control unit). WIRE CAVITY REFERENCE CHART Cavity Wire Test condition Test: Desired result Possible cause if desired result is not obtained 3 BLK Under all conditions Measure the voltage to ground: There should be less than 0.5 V. Poor ground (G501) An open in the wire 8 WHT Under all conditions Measure the voltage to ground: There should be battery voltage. Blown No. 15 (40 A) fuse in the under-hood fuse/relay box Blown No. 7 (10 A) fuse in the driver's under-dash fuse/relay box An open in the wire 7 YEL Ignition switch ON (II) Measure the voltage to ground: There should be battery voltage. Blown No. 21 (10 A) fuse in the driver's under-dash fuse/relay box An open in the wire

Scheme 14

Scheme 15

Scheme 16

1. Carefully pry the switch panel out from the dashboard.
2. Disconnect the 5P connector (A) from the headlight washer switch (B).
3. Check for continuity between the terminals in each switch position (Scheme 15)
4. If the continuity is not as specified, replace the bulb (C) or the headlight washer switch.
5. Install in the reverse order of removal.

Scheme 17

1. Open the hood, and remove the wiper arms (see «WIPER MOTOR REPLACEMENT»(/acura/rl/ii-2004-2008/remont/wiperwasher-systems/#wiper-system-washer-system) ). NOTE: Carefully remove the wiper arms so that they do not touch the hood.
2. Remove the hood seal and cowl covers.
3. Disconnect the 5P connector (A) from the wiper motor (B).
4. Test the motor by connecting battery power to the No. 2 terminal and grounding the No. 3 terminal of the wiper motor 5P connector. The motor should run at low speed. If the motor does not run or fails to run smoothly, replace the motor.
5. Test the motor by connecting battery power to the No. 2 terminal and grounding the No. 5 terminal of the wiper motor 5P connector. The motor should run at high speed. If the motor does not run or fails to run smoothly, replace the motor.
6. Connect an analog ohmmeter between the No. 1 and No. 4 terminals, and run the motor at low or high speed. The ohmmeter should indicate continuity and no continuity alternately. If it does not, replace the motor.

Scheme 18

1. Remove the right inner fender (see «FRONT INNER FENDER REPLACEMENT»(/acura/rl/ii-2004-2008/remont/exterior-body-panels/#fenderwell__front-inner-fender-replacement) ).
2. Disconnect the 2P connector (A) from the washer motor (B).
3. Test the motor by connecting battery power to the No. 1 terminal and grounding the Non terminal of the washer motor. The motor should run. If the motor does not run or fails to run smoothly, replace it. If the motor runs smoothly, but little or no washer fluid is pumped, check for a disconnected or blocked washer hose, or a clogged washer motor outlet.

Scheme 19

Scheme 20

Scheme 21

1. Open the hood.
2. Remove the caps, nuts (A), and the windshield wiper arms (B).
3. Remove the cowl covers (C).
4. Disconnect the 5P connector (A) from the wiper motor.
5. Remove the four bolts (B) and wiper linkage assembly (C).
6. Scribe a line (A) across the link and windshield wiper linkage to show the original adjustment. Separate the windshield wiper linkage (B) from the wiper motor (C).
7. Install in the reverse order to removal, and note these items: Apply multipurpose grease to the moving parts. Before reinstalling the wiper arms, turn the wiper switch ON, then OFF to return the wiper shafts to the park position. If necessary, replace any damaged clips. Check the wiper motor operation.

Scheme 22

Scheme 23

1. Remove the right inner fender (see «FRONT INNER FENDER REPLACEMENT»(/acura/rl/ii-2004-2008/remont/exterior-body-panels/#fenderwell__front-inner-fender-replacement) ).
2. Disconnect the washer tube (A) and washer motor 2P connector (B).
3. Remove the clip and three bolts (A), then remove the washer reservoir (B).
4. Install the reservoir in the reverse order of removal.

Scheme 24

1. Remove the right inner fender (see «FRONT INNER FENDER REPLACEMENT»(/acura/rl/ii-2004-2008/remont/exterior-body-panels/#fenderwell__front-inner-fender-replacement) ).
2. Disconnect the 2P connector (A) from the washer fluid level switch (B).
3. Remove the washer fluid level switch from the reservoir. NOTE: Fluid may flow out of the opening.
4. Check for continuity between the No. 1 and No. 2 terminals in each float position (C). There should be continuity when the float is down. There should be no continuity when the float is up.
5. If the continuity is not as specified, replace the switch.

Scheme 25

1. Remove the right inner fender (see «FRONT INNER FENDER REPLACEMENT»(/acura/rl/ii-2004-2008/remont/exterior-body-panels/#fenderwell__front-inner-fender-replacement) ).
2. Disconnect the 2P connector (A) from the washer motor (B).
3. Test the motor by connecting battery power to the No. 1 terminal and grounding the No. 2 terminal of the headlight washer motor. The motor should run. If the motor does not run smoothly, replace it. If the motor runs smoothly, but little or no washer fluid is pumped, check for a disconnected or blocked washer hose, or a clogged washer motor outlet.
4. Remove the bolt and bracket (C), then disconnect the headlight washer motor from the washer reservoir.
5. Install the headlight washer motor in the reverse order of removal. If the gasket (D) is damaged, replace it.

Scheme 26

1. Remove the front bumper (see «FRONT BUMPER REMOVAL/INSTALLATION»(/acura/rl/ii-2004-2008/remont/exterior-body-panels/#bumpers__front-bumper-removalinstallation) ), and disconnect the headlight washer tube from the headlight washer motor.
2. Disconnect the headlight washer tube (A) from the headlight washer nozzle (B).
3. Remove the headlight washer nozzle cover (C).
4. Remove the bolt and two screws, then remove the headlight washer nozzle.
5. Install the nozzle in the reverse order of removal. After installation, check the headlight washer operation.

Scheme 27

Scheme 28

Scheme 29

1. Adjust the wiper arms to the winter position (see «WIPER ARM/NOZZLE ADJUSTMENT»(/acura/rl/ii-2004-2008/remont/wiperwasher-systems/#wiper-system-washer-system__wiper-armnozzle-adjustment) ), then raise the wiper arms off the windshield. NOTE: Lift the driver's side first. Do not open the hood when the wiper arms are raised.
2. Push the edge of the cover on the blade assembly until the other side of the edge is pivoted out, and remove the cover (A).
3. Disconnect the blade assembly (B) from the wiper arm (C) by removing the two screws from the arm.
4. Remove the blade (A) from its holder by grasping the tabbed end of the blade. Pull firmly until the tabs come out of the holder.
5. Examine the new wiper blades. If they have no plastic or metal reinforcement (A), remove the metal reinforcement strips from the old wiper blades, and install them in the slots along the edge of the new blade.
6. Install the wiper blades onto the wiper arms in the reverse order of removal.
7. Check the wiper operation, if the blades slip, turn the wiper switch OFF, and reinstall the wiper blades securely.

Wiper Arm/Nozzle Adjustment

The Acura RL has two the wiper arms stop positions. One is the normal position (summer position) and the other is the winter position. To adjust the wiper arms to the winter position, hold the middle of both wiper blades (A) at the same time. Pull on the arms, parallel to the windshield, until they lock in the higher position. To return to the normal position (summer position), push the same area of both arms in the opposite direction.

Scheme 30

Wiper arms stop position

Scheme 31

Scheme 32

1. When the wiper arms stop at the automatic stop position, confirm the wiper arms are at the standard position. Normal position (Summer position) Position at about 4.5 in. (115 mm) from the top of cowl cover (D) Position at about 1.1 in. (28 mm) from the top of cowl cover (D) Winter position : Position at about 9.3 in. (237 mm) from the top of cowl cover (D) : Position at about 7.4 in. (187 mm) from the top of cowl cover (D) Washer nozzle position
2. When you turn on the washers, confirm 50% or more of the washer fluid lands within the spray area. If the spray area is not within the standard positions, adjust the nozzles. NOTE: The driver's side is symmetrical to the passenger's side. Position at about 16.7 in. (423 mm) from the top of the black ceramic area (E) at the lower windshield Position at about 13.2 in. (336 mm) from the top of the black ceramic area (E) at the lower windshield Position at about 15.4 in. (391 mm) from the top of the black ceramic area (E) at the lower windshield Position at about 16.5 in. (419 mm) from the windshield center line (C) Position at about 9.4 in. (238 mm) from the windshield center line (C) Position at about 1.7 in. (44 mm) from the windshield center line (C)

Scheme 33

1. Remove the right inner fender (see «FRONT INNER FENDER REPLACEMENT»(/acura/rl/ii-2004-2008/remont/exterior-body-panels/#fenderwell__front-inner-fender-replacement) ).
2. Remove the windshield washer nozzles and clips, then remove the tube.
3. Install in the reverse order of removal. Take care not to pinch the washer tube. Check the windshield washer operation.

Scheme 34

1. Remove the front bumper (see «FRONT BUMPER REMOVAL/INSTALLATION»(/acura/rl/ii-2004-2008/remont/exterior-body-panels/#bumpers__front-bumper-removalinstallation) ).
2. Remove the tube, mounting bolts and washer nozzles.
3. Install in the reverse order of removal. Take care not to pinch the washer tube. Check the headlight washer operation.
