Frame Acura RL II

Frames, Subframes & Crossmembers 8 illustrations ~535 words

Scheme 1

Scheme 1: Frame Brace Replacement
Scheme 1: Frame Brace Replacement

Special Tools Required

Frame positioning guide pin 070AG-SJAA10S

After removing the subframe mounting bolts and front suspension subframe rear bracket mounting bolts, be sure to replace them with new ones.

Scheme 2

Scheme 2: Front Subframe Torque
Scheme 2: Front Subframe Torque

Note. Using the special tool, make the front suspension subframe alignment as the following sequence.

Scheme 3

Scheme 3: Front Subframe Alignment
Scheme 3: Front Subframe Alignment
  1. Make the front suspension subframe (A) alignment. Lift the front suspension subframe up to the body, and loosely install the new subframe mounting bolts and the brackets (B). Insert the alignment pin (C) into the alignment hole in the right rear of the subframe, and then align the subframe with the body. Loosely tighten the subframe mounting bolt (D) at the right rear. Insert the alignment pin into the alignment hole in the left rear of the subframe, and then align the subframe with the body. Loosely tighten the subframe mounting bolt (E) at the left rear. Loosely tighten both front subframe mounting bolts (F). Insert the alignment pin into the alignment hole in the right rear of the subframe. Loosen the subframe mounting bolt at the right rear, and fit the lower insulator (G), in the subframe, and then tighten the mounting bolt to the specified torque values. Tighten the remaining subframe mounting bolts and the bracket mounting bolts (H) to the specified torque values.
  2. After reinstalling all removed parts, check and adjust the front wheel alignment (see «WHEEL ALIGNMENT»(/acura/rl/ii-2004-2008/remont/wheel-alignment/#front-suspension-and-rear-suspension-alignment__wheel-alignment) ).

After removing the subframe mounting bolts, be sure to replace them with new ones.

Scheme 4

Scheme 4: Rear Subframe Torque
Scheme 4: Rear Subframe Torque

Scheme 5

Scheme 5: Top View
Scheme 5: Top View

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7: Side View
Scheme 7: Side View

Scheme 8

Scheme 8
Scheme 8

SUPPLEMENTAL RESTRAINT SYSTEM (SRS) (If HVAC maintenance is required)

The Acura RL SRS includes a driver's airbag in the steering wheel hub, a passenger's airbag in the dashboard above the glove box, seat belt tensioners in the front seat belt retractors, side curtain airbags in the sides of the roof, and side airbags in the front seat-backs. Information necessary to safely service the SRS is located in the SRS (SUPPLEMENTAL RESTRAINT SYSTEM) article. Items marked with an asterisk (*) include or are located near SRS components. Servicing, disassembling, or replacing these items requires special precautions and tools, and should be done by an authorized Acura dealer.

  1. To avoid rendering the SRS inoperative, which could lead to personal injury or death in the event of a severe frontal or side collision, all SRS service work should be done by an authorized Acura dealer.
  2. Improper service procedures, including incorrect removal and installation of the SRS, could lead to personal injury caused by unintentional deployment of the airbags and/or side airbags.
  3. Do not bump or impact the SRS unit, front impact sensors, or side impact sensors when the ignition switch is ON (II), or for at least 3 minutes after the ignition switch is turned OFF; otherwise, the system may fail in a collision, or the airbags may deploy.
  4. SRS electrical connectors are identified by yellow color coding. Related components are located in the steering column, front console, dashboard, dashboard lower panel, in the dashboard above the glove box, in the front seats, in the roof side, and around the floor. Do not use electrical test equipment on these circuits.
