Accessory Power Sockets Acura RL II

Body Electrical 8 illustrations ~395 words

Scheme 71

Scheme 71: Component Location Index
Scheme 71: Component Location Index

Scheme 72

Scheme 72: Circuit Diagram
Scheme 72: Circuit Diagram

Scheme 73

Scheme 73: Front Accessory Power Socket Test/Replacement
Scheme 73: Front Accessory Power Socket Test/Replacement

Scheme 74

Scheme 74
Scheme 74

Scheme 75

Scheme 75
Scheme 75
  1. Remove the console panel (see «CENTER CONSOLE REMOVAL/INSTALLATION»(/acura/rl/ii-2004-2008/remont/exteriorinterior-trim/#consoles__center-console-removalinstallation) ).
  2. Disconnect the 2P connector (A) from the front accessory power socket (B).
  3. Inspect the connector terminals to be sure they are all making good contact. If the terminals are bent, loose, or corroded, repair them as necessary, and recheck the system. If the terminals look OK, go to step 4.
  4. Turn the ignition switch to ACC (I), and measure the voltage between the No. 1 terminal and body ground. There should be battery voltage. If there is battery voltage, go to step 5. If there is no battery voltage, check for: Blown No. 9 (20A) or No. 32 (10A) fuse in the driver's under-dash fuse/relay box. Faulty accessory power socket relay. Poor ground (G503, G601) An open in the wire.
  5. Check for continuity between the No. 2 terminal and body ground. There should be continuity. If there is continuity, go to step 6. If there is no continuity, check for: Poor ground (G503) An open in the wire.
  6. Remove the socket (A).
  7. Remove the ring (A).
  8. Install the power socket in the reverse order of removal.

Scheme 76

Scheme 76: Rear Accessory Power Socket Test/Replacement
Scheme 76: Rear Accessory Power Socket Test/Replacement

Scheme 77

Scheme 77
Scheme 77

Scheme 78

Scheme 78
Scheme 78
  1. Open the center console.
  2. Remove the screws and accessory power socket panel (A).
  3. Inspect the 2P connector (B) terminals to be sure they are all making good contact. If the terminals are bent, loose, or corroded, repair them as necessary, and recheck the system. If the terminals look OK, go to step 4.
  4. Turn the ignition switch to ACC (I), and measure the voltage between the No. 1 terminal and body ground. There should be battery voltage. If there is battery voltage, go to step 5. If there is no battery voltage, check for: Blown No. 9 (20A) or No. 32 (10A) fuse in the driver's under-dash fuse/relay box. Faulty accessory power socket relay. Poor ground (G 503, G601). An open in the wire.
  5. Check for continuity between the No. 2 terminal and body ground. There should be continuity. If there is continuity, go to step 6. If there is no continuity, check for: Poor ground (G 503). An open in the wire.
  6. Remove the socket (A).
  7. Remove the housing (A) from the panel (B).
  8. Install the power socket in the reverse order of removal.
