Engine Block: Diagnosis Acura RDX I facelift

Crankshaft Inspection

Out-of-Round and Taper

Scheme 344

Scheme 345

1. Remove the crankshaft from the engine block (see «CRANKSHAFT AND PISTON REMOVAL»(ref-513865-S08345079242012111600000) ).
2. Clean the crankshaft oil passages with pipe cleaners or a suitable brush.
3. Clean the keyway slot and the threads holes for damage.
4. Measure the out-of-round at the middle of each rod and main journal in two places (A). The difference between measurements on each journal must not be more than the service limit. Journal Out-of-Round Standard (New): 0.004 mm (0.00016 in) max. Service Limit: 0.010 mm (0.00039 in)
5. Measure the taper at the edges of each rod and main journal (B). The difference between measurements on each journal must not be more than the service limit. Journal Taper Standard (New): 0.005 mm (0.00020 in) max. Service Limit: 0.010 mm (0.00039 in) Straightness
6. Place the V-block on a flat surface.
7. Check the total runout with the crankshaft supported on V-blocks.
8. Measure the runout on all of the main journals. Rotate the crankshaft two complete revolutions. The difference between measurements on each journal must not be more than the service limit. Crankshaft Total Runout Standard (New): 0.02 mm (0.0008 in) max. Service Limit: 0.04 mm (0.0016 in)

Scheme 346

Scheme 347

Scheme 348

Scheme 349

Scheme 350

1. Remove the pistons from the engine block (see «CRANKSHAFT AND PISTON REMOVAL»(ref-513865-S08345079242012111600000) ).
2. Check the piston for distortion or cracks.
3. Measure the piston skirt diameter (A) at a point 10 mm (0.39 in) from the bottom of the skirt. There are two standard-size pistons (/ (slash) and B). The letter is stamped on the top of the piston. Letters are also stamped on the engine block as cylinder bore sizes. Piston Diameter Standard (New): / (slash): 85.980-85.990 mm (3.38503-3.38543 in) B: 85.970-85.980 mm (3.38464-3.38503 in) Service Limit: / (slash): 85.930 mm (3.38306 in) B: 85.920 mm (3.38267 in) Oversize Piston Diameter 0.25: 86.230-86.240 mm (3.39499-3.39527 in)
4. Measure the wear and taper in direction X and Y at three levels in each cylinder as shown in illustration. If the measurements in any cylinder are beyond the oversize bore service limit, replace the engine block. If the engine block has to be rebored, refer to step 7 after reboring. Cylinder Bore Size Standard (New): A or I: 86.010-86.020 mm (3.38621-3.38661 in) B or II: 86.000-86.010 mm (3.38582-3.38621 in) Service Limit: 86.070 mm (3.38858 in) Oversize 0.25: 86.250-86.260 mm (3.39567-3.39606 in) Reboring Limit: 0.25 mm (0.010 in) max. Bore Taper Limit: (Difference between first and third measurement) 0.05 mm (0.002 in)
5. Hone any scored or scratched cylinder bores (see «CYLINDER BORE HONING»(ref-513865-S29632126302012111600000) ).
6. Check the top of the engine block for warpage. Measure along the edges and across the center as shown in illustration. Engine Block Warpage Standard (New): 0.07 mm (0.002 in) max.
7. Calculate the difference between the cylinder bore diameter and the piston diameter. If the clearance is near or exceeds the service limit, inspect the piston and cylinder bore for excessive wear. Piston-to-Cylinder Bore Clearance Standard (New): 0.020-0.040 mm (0.00079-0.00157 in) Service Limit: 0.05 mm (0.0020 in)

Scheme 351

1. Measure the cylinder bores (see «BLOCK AND PISTON INSPECTION»(ref-513865-S27568338032012111600000) ). If the engine block is to be reused, hone the cylinders and remeasure the bores. Only scored or scratched cylinder bores must be honed.
2. Remove the oil jets (see «OIL FILTER FEED PIPE REPLACEMENT»(ref-513834-S39886278932012111600000) ).
3. Hone the cylinder bores with honing oil and a fine (400 grit) stone in a 60 degree crosshatch pattern (A). NOTE: Use only a rigid hone with 400 grit or finer stone, such as Sunnen, Ammco, or equivalent. Do not use stones that are worn or broken.
4. When honing is complete, thoroughly clean the engine block of all metal particles. Wash the cylinder bores with hot soapy water, then dry and oil them immediately to prevent rusting. NOTE: Never use solvent, it will only redistribute the grit on the cylinder walls.
5. If scoring or scratches are still present in the cylinder bores after honing to the service limit, rebore the engine block. Some light vertical scoring and scratching is acceptable if it is not deep enough to catch your fingernail and does not run the full length of the bore.
6. Install the oil jets (see «OIL FILTER FEED PIPE REPLACEMENT»(ref-513834-S39886278932012111600000) ).

Scheme 352

Scheme 353

Scheme 354

1. Remove the pistons from the engine block (see «CRANKSHAFT AND PISTON REMOVAL»(ref-513865-S08345079242012111600000) ).
2. Apply new engine oil to the piston pin snap rings (A), and turn them in the ring grooves until the end gaps are lined up with the cutouts in the piston pin bores (B). NOTE: Take care not to damage the ring grooves.
3. Remove snap rings (A) from the both sides of each piston. Start at the cutout in the piston pin bore. Remove the snap rings carefully so they do not go flying or get lost. Wear eye protection.
4. Separately heat each piston and connecting rod assembly to about 158°F (70°C), then remove the piston pin.

Inspection

Note. Inspect the piston, the piston pin, and the connecting rod when they are at room temperature.

Scheme 355

Scheme 356

Scheme 357

Scheme 358

1. Measure the diameter of the piston pin. Piston Pin Diameter Standard (New): 21.962-21.965 mm (0.86464-0.86476 in) Service Limit: 21.953 mm (0.86429 in)
2. Zero the dial indicator to the piston pin diameter.
3. Check the difference between the piston pin diameter and the piston pin hole diameter on the piston. Piston Pin-to-Piston Clearance Standard (New): -0.005-0.002 mm (-0.00020-0.00008 in) Service Limit: 0.005 mm (0.00020 in)
4. Measure the piston pin-to-connecting rod clearance. Piston Pin-to-Connecting Rod Clearance Standard (New): 0.005-0.014 mm (0.00020-0.00055 in) Service Limit: 0.02 mm (0.0008 in)

Scheme 359

Scheme 360

Scheme 361

1. Install a piston pin snap ring (A) only on one side.
2. Coat the piston pin bore in the piston, the bore in the connecting rod, and the piston pin with new engine oil.
3. Heat the piston to about 158°F (70°C).
4. Assemble the piston (A) and the connecting rod (B) with the arrow (C) and the embossed mark (D) on the same side. Install the piston pin (E). NOTE: Apply new engine oil to the piston pin.
5. Install the remaining snap ring (F).
6. Reassemble the other pistons the same way.

Scheme 362

Scheme 363

Scheme 364

Scheme 365

Scheme 366

Scheme 367

1. Remove the piston from the engine block (see «CRANKSHAFT AND PISTON REMOVAL»(ref-513865-S08345079242012111600000) ).
2. Using a ring expander (A), remove the old piston rings (B).
3. Clean all the ring grooves thoroughly with a squared-off broken ring, or a ring groove cleaner with a blade to fit the piston grooves. File down the blade, if necessary. The top ring groove is 1.5 mm (0.059 in) wide, the second ring groove is 1.2 mm (0.047 in) wide, and the oil ring groove is 2.0 mm (0.079 in) wide. Do not use a wire brush to clean the ring grooves, or cut the ring grooves deeper with the cleaning tools. NOTE: If the piston is to be separated from the connecting rod, do not install new rings yet.
4. Using a piston, push a new ring (A) into the cylinder bore 15-20 mm (0.59-0.79 in) from the bottom.
5. Measure the piston ring end-gap (B) with a feeler gauge: If the gap is too small, check to see if you have the proper rings for your engine. If the gap is too large, recheck the cylinder bore diameter against the wear limits (see «BLOCK AND PISTON INSPECTION»(ref-513865-S27568338032012111600000) ). If the bore is beyond the service limit, the engine block must be rebored. Piston Ring End-Gap Top Ring: Standard (New): 0.20-0.30 mm (0.008-0.011 in) Service Limit: 0.60 mm (0.023 in) Second Ring: Standard (New): 0.40-0.50 mm (0.016-0.019 in) Service Limit: 0.75 mm (0.029 in) Oil Ring: Standard (New): 0.10-0.30 mm (0.004-0.011 in) Service Limit: 0.80 mm (0.031 in)
6. Install the rings as shown in illustration. The top ring (A) has a 1N mark and the second ring (B) has a 2N mark. The manufacturing marks (C) must be face upward. Piston Ring Dimensions
7. After installing a new set of rings, measure the ring-to-groove clearances. Top Ring Clearance Standard (New): 0.045-0.090 mm (0.002-0.003 in) Service Limit: 0.13 mm (0.005 in) Second Ring Clearance Standard (New): 0.040-0.065 mm (0.002-0.002 in) Service Limit: 0.13 mm (0.005 in) Oil Ring Clearance Standard (New): 0.020-0.050 mm (0.001-0.002 in) Service Limit: 0.08 mm (0.003 in)
8. Rotate the rings in their grooves to make sure they do not bind.
9. Position the ring end gaps as shown in illustration

Scheme 368

Scheme 369

Scheme 370

1. Set the crankshaft to bottom dead center (BDC) for each cylinder as its piston is installed.
2. Remove the connecting rod caps, then install the ring compressor. Check that the bearing is securely in place.
3. Apply new engine oil to the piston, inside of the ring compressor, and the cylinder bore, then attach the ring compressor to the piston/connecting rod assembly.
4. Position the piston/connecting rod assembly with the arrow (A) facing the cam chain side of the engine block.
5. Position the piston/ connecting rod assembly in the cylinder, and tap it in using the wooden handle of a hammer (A). Maintain downward force on the ring compressor (B) to prevent the rings from expanding before entering the cylinder bore.
6. Stop after the ring compressor pops free, and check the connecting rod-to-rod journal alignment before pushing the piston into place.
7. Check the connecting rod bearing clearance with a plastigage (see «CONNECTING ROD BEARING CLEARANCE INSPECTION»(ref-513865-S22329502972012111600000) ).
8. Inspect the connecting rod bolts (see «CONNECTING ROD BOLT INSPECTION»(ref-513865-S06903149662012111600000) ).
9. Apply new engine oil to the bolt threads, then install the rod caps with bearings. Torque the bolts to 29 N.m (3.0 kgf.m, 22 lbf.ft).
10. Tighten the connecting rod bolts an additional 90°. NOTE: Remove the connecting rod bolt if you tightened it beyond the specified angle, and go back to step 8 of the procedure. Do not loosen it back to the specified angle.

Scheme 371

Scheme 372

1. Remove the connecting rod caps, then install the ring compressor, and check that the bearing is securely in place.
2. Apply new engine oil to the piston, inside of the ring compressor, and the cylinder bore, then attach the ring compressor to the piston/connecting rod assembly.
3. Position the piston/connecting rod assembly with the arrow (A) facing the cam chain side of the engine block.
4. Position the piston/ connecting rod assembly in the cylinder, and tap it in using the wooden handle of a hammer (A). Maintain downward force on the ring compressor (B) to prevent the rings from expanding before entering the cylinder bore.
5. Position all pistons at top dead center (TDC).

Scheme 373

1. Measure the diameter of each connecting rod bolt at point A and point B.
2. Calculate the difference in diameter between point A and point B. Point A-Point B = Difference in Diameter Difference in Diameter Specification: 0-0.1 mm (0-0.004 in)
3. If the difference in diameter is out of specification, replace the connecting rod bolt.
