Specifications: Other — Specifications — Mechanical - Hydraulic

Engine Electrical

Item	Measurement	Qualification	Standard or New	Service Limit
Ignition coil	Rated voltage		12V
Ignition coil	Firing order		1-3-4-2
Sparkplug	Type	NGK	SILKR8A-S
Sparkplug	Gap		0.7-0.8 mm (0.028-0.031 in)
Ignition timing	At idle Check the red mark	In N or P	14±2°BTDC
Drive belt	Tension		Auto-tensioner
Alternator	Output	At 13.5 V and normal engine temperature	105 A
	Coil (rotor) resistance	At 68°F (20°C)	3.2-4.0 ohms
	Slip ring O.D.		14.4 mm (0.567 in)	14.0 mm (0.551 in)
	Brush length		10.5 mm (0.413 in)	1.5 mm (0.059 in)
Starter	Output		1.6 kohms
	Commutator mica depth		0.40-0.50 mm (0.0157-0.0197 in)	0.15 mm (0.0059 in)
	Commutator runout		0.02 mm (0.0008 in) max.	0.05 mm (0.0020 in)
	Commutator O.D.		28.0-28.1 mm (1.102-1.106 in)	27.5 mm (1.083 in)
	Brush length		11.1-11.5 mm (0.437-0.453 in)	4.3 mm (0.169 in)
	Brush spring tension		13.7-17.7 N (1.40-1.80 kgf, 3.09-3.97 lbf)

Cylinder Head

Item	Measurement	Qualification	Standard or New	Service Limit
Head	Warpage		0.05 mm (0.0020 in) max.
Head	Height		103.95-104.05 mm (4.0925-4.0964 in)
Camshaft	End play		0.05-0.20 mm (0.0020-0.0079 in)	0.4 mm (0.016 in)
	Camshaft-to-holder oil clearance	No. 1 journal	0.030-0.069 mm (0.00118-0.00272 in)	0.15 mm (0.0059 in)
		No. 2 journal	0.060-0.099 mm (0.00236-0.00390 in)	0.15 mm (0.0059 in)
		No. 3 journal	0.060-0.099 mm (0.00236-0.00390 in)	0.15 mm (0.0059 in)
		No. 4 journal	0.060-0.099 mm (0.00236-0.00390 in)	0.15 mm (0.0059 in)
		No. 5 journal	0.060-0.099 mm (0.00236-0.00390 in)	0.15 mm (0.0059 in)
	Total runout		0.03 mm (0.0012 in) max.
	Cam lobe height	Intake PRI	33.925 mm (1.33563 in)
		Intake SEC	29.638 mm (1.16685 in)
		Exhaust	34.092 mm (1.34220 in)
Valve	Clearance (cold)	Intake	0.21-0.25 mm (0.009-0.009 in)
	Clearance (cold)	Exhaust	0.28-0.32 mm (0.011-0.012 in)
	Stem O.D.	Intake	5.475-5.485 mm (0.21555-0.21594 in)	5.445 mm (0.21437 in)
	Stem O.D.	Exhaust	5.450-5.460 mm (0.21457-0.21496 in)	5.420 mm (0.21339 in)
	Stem-to-guide clearance	Intake	0.030-0.055 mm (0.00118-0.00217 in)	0.08 mm (0.0031 in)
	Stem-to-guide clearance	Exhaust	0.055-0.080 mm (0.00217-0.00315 in)	0.11 mm (0.0043 in)
Valve seat	Width	Intake	1.25-1.55 mm (0.0492-0.0610 in)	2.00 mm (0.0787 in)
	Width	Exhaust	1.25-1.55 mm (0.0492-0.0610 in)	2.00 mm (0.0787 in)
	Stem installed height	Intake	44.0-44.5 mm (1.732-1.752 in)	44.7 mm (1.760 in)
	Stem installed height	Exhaust	44.1-44.6 mm (1.736-1.756 in)	44.8 mm (1.764 in)
Valve guide	Installed height	Intake	15.2-16.2 mm (0.598-0.638 in)
Valve guide	Installed height	Exhaust	15.5-16.5 mm (0.610-0.650 in)
Rocker arm	Arm-to-shaft clearance	Intake	0.025-0.052 mm (0.00098-0.00205 in)	0.08 mm (0.0031 in)
Rocker arm	Arm-to-shaft clearance	Exhaust	0.018-0.056 mm (0.00071-0.00220 in)	0.08 mm (0.0031 in)

Engine Block

Item	Measurement	Qualification	Standard or New	Service Limit
Block	Warpage of deck		0.07 mm (0.002 in) max.
	Bore diameter	A or I	86.010-86.020 mm (3.38621-3.38661 in)	86.070 mm (3.38858 in)
	Bore diameter	Borll	86.000-86.010 mm (3.38582-3.38621 in)	86.070 mm (3.38858 in)
	Bore taper			0.05 mm (0.0020 in)
	Reboring limit			0.25 mm (0.0098 in)
Piston	Skirt O.D. at 10 mm (0.4 in) from bottom of skirt	Letter B	85.970-85.980 mm (3.38464-3.38503 in)	85.920 mm (3.38267 in)
	Skirt O.D. at 10 mm (0.4 in) from bottom of skirt	/(slash)	85.980-85.990 mm (3.38503-3.38543 in)	85.930 mm (3.38306 in)
	Clearance in cylinder		0.020-0.040 mm (0.00079-0.00157 in)	0.05 mm (0.0020 in)
	Ring groove width	Top	1.535-1.565 mm (0.06043-0.06161 in)	1.25 mm (0.0492 in)
		Second	1.230-1.240 mm (0.04843-0.04882 in)	1.25 mm (0.0492 in)
		Oil	2.010-2.020 mm (0.07913-0.07953 in)	2.05 mm (0.0807 in)
Piston ring	Ring-to-groove clearance	Top	0.045-0.090 mm (0.002-0.003 in)	0.13 mm (0.005 in)
		Second	0.040-0.065 mm (0.002-0.002 in)	0.13 mm (0.005 in)
		Oil	0.020-0.050 mm (0.001-0.001 in)	0.08 mm (0.003 in)
	Ring end gap	Top	0.20-0.30 mm (0.008-0.011 in)	0.60 mm (0.023 in)
		Second	0.40-0.50 mm (0.016-0.019 in)	0.75 mm (0.029 in)
		Oil	0.10-0.30 mm (0.004-0.011 in)	0.80 mm (0.031 in)
Piston pin	O.D.		21.962-21.965 mm (0.86464-0.86476 in)	21.953 mm (0.86429 in)
Piston pin	Pin-to-piston clearance		0.005-0.002 mm (-0.00020-0.00008 in)	0.005 mm (0.00020 in)
Connecting rod	Pin-to-rod clearance		0.005-0.014 mm (0.00020-0.00055 in)	0.02 mm (0.0008 in)
	Small end bore diameter		21.970-21.976 mm (0.86496-0.86520 in)
	Big end bore diameter		51.0 mm (2.008 in)
	End play		0.15-0.35 mm (0.006-0.013 in)	0.40 mm (0.015 in)
Crankshaft	Main journal diameter	No. 1 journal	54.984-55.008 mm (2.16472-2.16566 in)
		No. 2 journal	54.984-55.008 mm (2.16472-2.16566 in)
		No. 3 journal	54.976-55.000 mm (2.16441-2.16535 in)
		No. 4 journal	54.984-55.008 mm (2.16472-2.16566 in)
		No. 5 journal	54.984-55.008 mm (2.16472-2.16566 in)
	Rod journal diameter		47.976-48.000 mm (1.88882-1.88976 in)
	Rod/main journal taper		0.005 mm (0.00020 in) max.	0.010 mm (0.00039 in)
	Rod/main journal out-of-round		0.004 mm (0.00016 in) max.	0.010 mm (0.00039 in)
	End play		0.10-0.35 mm (0.0039-0.0138 in)	0.45 mm (0.0177 in)
	Total runout		0.02 mm (0.0008 in) max.	0.04 mm (0.0016 in)
Crankshaft bearing	Main bearing-to-journal oil clearance	No. 1 journal	0.017-0.041 mm (0.00067-0.00161 in)	0.050 mm (0.00197 in)
		No. 2 journal	0.017-0.041 mm (0.00067-0.00161 in)	0.050 mm (0.00197 in)
		No. 3 journal	0.025-0.049 mm (0.00098-0.00193 in)	0.055 mm (0.00217 in)
		No. 4 journal	0.017-0.041 mm (0.00067-0.00161 in)	0.050 mm (0.00197 in)
		No. 5 journal	0.017-0.041 mm (0.00067-0.00161 in)	0.050 mm (0.00197 in)
	Connecting rod bearing-to-journal oil clearance		0.033-0.064 mm (0.00130-0.00252 in)	0.077 mm (0.00303 in)

Cooling System

Item	Measurement	Qualification	Standard or New
Radiator	Coolant capacities (including engine, heater, hoses, and reservoir)	Engine overhaul	8.4 L (2.22 US gal)
		Coolant change	7.0 L (1.85 US gal)
	Coolant type NOTE: If the vehicle is regularly driven in very low temperatures (under-31°F (-35°C)), a 60% concentration of coolant should be used		Acura Long Life Antifreeze/Coolant Type 2
Coolant reservoir	Coolant capacity		0.7 L (0.18 US gal)
Radiator cap	Opening pressure		93-123 kPa (0.95-1.25 kgf/cm 2 , 13.5-17.8 psi)
Thermostat	Opening temperature	Begins to open	169-176°F (76-80°C)
	Opening temperature	Fully open	194°F (90°C)
	Valve lift at fully open		8.0 mm (0.315 in) min.

NOTE
If the vehicle is regularly driven in very low temperatures (under-31°F (-35°C)), a 60% concentration of coolant should be used

Fuel and Emissions

Item	Measurement	Qualification	Standard or New
Fuel pressure regulator	Pressure with regulator vacuum hose disconnected		320-370 kPa (3.3-3.8 kgf/cm 2 , 47-54 psi)
Fuel tank	Capacity		68 L (18.0 US gal)
Engine idle	Idle speed without load	In N or P	720 ± 50 RPM
Engine idle	Idle speed with high electrical load	In N or P	720 ± 50 RPM

Automatic Transmission and A/T Differential

Item	Measurement	Qualification	Standard or New	Service Limit
Automatic transmission fluid	Capacity: use Acura ATF DW-1	Fluid change (2WD)	2.8 L (3.0 US qt)
		Fluid change (SH-AWD)	2.9 L (3.1 US qt)
		Overhaul (2WD)	8.3 L (8.8 US qt)
		Overhaul (SH-AWD)	7.8 L (8.2 US qt)
ATF pressure	Line pressure	At 2, 000 RPM in N or P	950-1, 010 kPa (9.7-10.3 kgf/cm 2 , 138-146 psi)	900 kPa (9.2 kgf/cm 2 , 131 psi)
	1st clutch pressure	At 2, 000 RPM in 1st gear in S	940-1, 020 kPa (9.6-10.4 kgf/cm 2 , 137-148 psi)	890 kPa (9.1 kgf/cm 2 , 129 psi)
	1st-hold clutch pressure	At 2, 000 RPM in 1st gear in S	680-760 kPa (6.9-7.7 kgf/cm 2 , 98-110 psi)	630 kPa (6.4 kgf/cm 2 , 91 psi)
	2nd clutch pressure	At 2, 000 RPM in 2nd gear in S	940-1, 020 kPa (9.6-10.4 kgf/cm 2 , 137-148 psi)	890 kPa (9.1 kgf/cm 2 , 129 psi)
	3rd clutch pressure	At 2, 000 RPM in 3rd gear in S	940-1, 020 kPa (9.6-10.4 kgf/cm 2 , 137-148 psi)	890 kPa (9.1 kgf/cm 2 , 129 psi)
	4th clutch pressure	At 2, 000 RPM in 4th gear in S	940-1, 020 kPa (9.6-10.4 kgf/cm 2 , 137-148 psi)	890 kPa (9.1 kgf/cm 2 , 129 psi)
	5th clutch pressure	At 2, 000 RPM in 5th gear in S	940-1, 020 kPa (9.6-10.4 kgf/cm 2 , 137-148 psi)	890 kPa (9.1 kgf/cm 2 , 129 psi)
Torque converter	Stall speed Check with vehicle on level ground		2, 300 RPM
Torque converter	Stall speed Check with vehicle on level ground	Service limit	2, 100-2, 500 RPM
Clutch	Clearance between clutch end-plate and top disc	1st	1.15-1.35 mm (0.0453-0.0531 in)	When discolored
		1st-hold	0.6-1.0 mm (0.024-0.039 in)	When discolored
		2nd	1.05-1.25 mm (0.0413-0.0492 in)	When discolored
		3rd	0.8-1.0 mm (0.031-0.039 in)	When discolored
		4th, 5th	0.75-0.95 mm (0.0295-0.0374 in)	When discolored
	Clutch return spring free length	1st	68.3 mm (2.689 in)	66.3 mm (2.610 in)
		2nd	48.3 mm (1.902 in)	46.3 mm (1.823 in)
		3rd	52.0 mm (2.047 in)	50.0 mm (1.969 in)
		4th	35.0 mm (1.378 in)	33.0 mm (1.299 in)
		5th	47.9 mm (1.886 in)	45.9 mm (1.807 in)
	Clutch disc thickness		1.94 mm (0.0764 in)
	Clutch plate thickness	1st	1.6 mm (0.063 in)	When discolored
		1st-hold	1.8 mm (0.071 in)	When discolored
		2nd	1.8 mm (0.071 in)	When discolored
		3rd	2.0 mm (0.079 in)	When discolored
		4th, 5th	1.6 mm (0.063 in)	When discolored
	1st clutch end-plate thickness	Mark 1	3.1 mm (0.122 in)	When discolored
		Mark 2	3.2 mm (0.126 in)	When discolored
		Mark 3	3.3 mm (0.130 in)	When discolored
		Mark 4	3.4 mm (0.134 in)	When discolored
		Mark 5	3.5 mm (0.138 in)	When discolored
		Mark 6	3.6 mm (0.142 in)	When discolored
		Mark 7	3.7 mm (0.146 in)	When discolored
		Mark 8	3.8 mm (0.150 in)	When discolored
		Mark 9	3.9 mm (0.154 in)	When discolored
	1st-hold clutch plate B thickness		5.0 mm (0.197 in)	When discolored
	2nd, 3rd, 4th, and 5th clutch end-plate thickness	Mark 1	2.1 mm (0.083 in)	When discolored
		Mark 2	2.2 mm (0.087 in)	When discolored
		Mark 3	2.3 mm (0.091 in)	When discolored
		Mark 4	2.4 mm (0.094 in)	When discolored
		Mark 5	2.5 mm (0.098 in)	When discolored
		Mark 6	2.6 mm (0.102 in)	When discolored
		Mark 7	2.7 mm (0.106 in)	When discolored
		Mark 8	2.8 mm (0.110 in)	When discolored
		Mark 9	2.9 mm (0.114 in)	When discolored
Mainshaft	Diameter of stator shaft needle bearing contact area		22.984-23.000 mm (0.90488-0.90551 in)	When worn or damaged
	5th gear I.D.		46.000-46.016 mm (1.81102-1.81165 in)	When worn or damaged
	5th gear axial clearance		0.10-0.22 mm (0.0039-0.0087 in)
	5th gear collar diameter of needle bearing contact area		39.981-39.991 mm (1.57405-1.57445 in)	When worn or damaged
	5th gear collar length		48.7-48.8 mm (1.917-1.921 in)
	5th gear collar flange thickness		4.5-4.7 mm (0.177-0.185 in)	When worn or damaged
	Sealing ring thickness		1.90-1.96 mm (0.0748-0.0772 in)	1.85 mm (0.0728 in)
	Sealing ring groove width		2.025-2.060 mm (0.07972-0.08110 in)	2.08 mm (0.0819 in)
Countershaft	Diameter of needle bearing contact area	At torque converter housing	40.505-40.515 mm (1.59468-1.59508 in)	When worn or damaged
	Diameter of needle bearing contact area	At 5th gear	34.975-34.991 mm (1.37697-1.37760 in)	When worn or damaged
	Diameter of 2nd gear at needle bearing contact area		61.975-61.991 mm (2.43996-2.44059 in)	When worn or damaged
	I.D. of gears	5th gear	41.000-41.016 mm (1.61417-1.61480 in)	When worn or damaged
		Idler gear	70.000-70.019 mm (2.75590-2.75665 in)	When worn or damaged
		Reverse gear	46.000-46.016 mm (1.81102-1.81165 in)	When worn or damaged
	Axial clearance of gears	2nd gear	0.005-0.040 mm (0.00020-0.00157 in)
		5th gear	0.12-0.27 mm (0.0047-0.0106 in)
		Idler gear	0.005-0.040 mm (0.001-0.001 in)
		Reverse gear	0.10-0.25 mm (0.0039-0.0098 in)
	Washer thickness (50.8 mm)	A	1.91 mm (0.0752 in)	When worn or damaged
		B	1.93 mm (0.0760 in)	When worn or damaged
		C	1.95 mm (0.0768 in)	When worn or damaged
		D	1.97 mm (0.0776 in)	When worn or damaged
		E	1.99 mm (0.0783 in)	When worn or damaged
		F	2.01 mm (0.0791 in)	When worn or damaged
		G	2.03 mm (0.0799 in)	When worn or damaged
		H	2.05 mm (0.0807 in)	When worn or damaged
		I	2.07 mm (0.0815 in)	When worn or damaged
		J	2.09 mm (0.0823 in)	When worn or damaged
		K	2.11 mm (0.0831 in)	When worn or damaged
		L	2.13 mm (0.0839 in)	When worn or damaged
		M	2.15 mm (0.0846 in)	When worn or damaged
		N	2.17 mm (0.0854 in)	When worn or damaged
	Washer thickness (50.8 mm)	O	2.19 mm (0.0862 in)	When worn or damaged
		P	2.21 mm (0.0870 in)	When worn or damaged
		Q	2.23 mm (0.0878 in)	When worn or damaged
		R	2.25 mm (0.0886 in)	When worn or damaged
		S	2.27 mm (0.0894 in)	When worn or damaged
		T	2.29 mm (0.0902 in)	When worn or damaged
		U	2.31 mm (0.0909 in)	When worn or damaged
		V	2.33 mm (0.0917 in)	When worn or damaged
		W	2.35 mm (0.0925 in)	When worn or damaged
		X	2.37 mm (0.0933 in)	When worn or damaged
		Y	2.39 mm (0.0941 in)	When worn or damaged
		Z	2.41 mm (0.0949 in)	When worn or damaged
		AA	2.43 mm (0.0957 in)	When worn or damaged
		AB	2.45 mm (0.0965 in)	When worn or damaged
	Washer thickness (61 mm)	A	1.525 mm (0.06004 in)	When worn or damaged
		B	1.505 mm (0.05925 in)	When worn or damaged
		C	1.485 mm (0.05846 in)	When worn or,_ damaged
		D	1.465 mm (0.05768 in)	When worn or damaged
		E	1.445 mm (0.05689 in)	When worn or damaged
		F	1.425 mm (0.05610 in)	When worn or damaged
		G	1.405 mm (0.05531 in)	When worn or damaged
	Thrust washer thickness		2.97-3.00 mm (0.1169-0.1181 in)	When worn or damaged
	Reverse selector hub O.D.		55.885-55.900 mm (2.20019-2.20078 in)	When worn or damaged
	Reverse gear collar O.D.		39.979-40.000 mm (1.57397-1.57480 in)	When worn or damaged
	Cotter thickness	4th gear	1.99-2.02 mm (0.0783-0.0795 in)
	Cotter thickness	2nd gear	7.49-7.52 mm (0.2949-0.2961 in)
Secondary shaft	Diameter of bearing contact area	At 2nd gear	43.986-43.999 mm (1.73173-1.73224 in)	When worn or damaged
		At torque converter housing	32.002-32.015 mm (1.25992-1.26043 in)	When worn or damaged
		At torque converter housing bearing (shaft end side)	28.592-28.608 mm (1.12567-1.12630 in)	When worn or damaged
	I.D. of gears	1st gear	44.000-44.013 mm (1.73228-1.73279 in)	When worn or damaged
	I.D. of gears	2nd gear	50.00-50.02 mm (1.9685-1.9693 in)	When worn or damaged
	Axial clearance of gears	1st gear	0.100-0.145 mm (0.00394-0.00571 in)
	Axial clearance of gears	2nd gear	0.060-0.488 mm (0.00236-0.01921 in)
	Diameter of 1st gear collar at needle bearing contact area		38.981-38.991 mm (1.53468-1.53508 in)	When worn or damaged
	Thrust washer thickness (52 mm)	A	2.705 mm (0.10650 in)	When worn or damaged
		B	2.680 mm (0.10551 in)	When worn or damaged
		C	2.655 mm (0.10453 in)	When worn or damaged
		D	2.630 mm (0.10354 in)	When worn or damaged
		E	2.605 mm (0.10256 in)	When worn or damaged
		F	2.580 mm (0.10157 in)	When worn or damaged
		G	2.555 mm (0.10059 in)	When worn or damaged
		H	2.530 mm (0.09961 in)	When worn or damaged
		I	2.505 mm (0.09862 in)	When worn or damaged
		J	2.480 mm (0.09764 in)	When worn or damaged
		K	2.455 mm (0.09665 in)	When worn or damaged
		L	2.430 mm (0.09567 in)	When worn or damaged
		M	2.405 mm (0.09468 in)	When worn or damaged
	Thrust shim thickness (65 mm)	OA	0.80 mm (0.0315 in)	When worn or damaged
		A	0.84 mm (0.0331 in)	When worn or damaged
		B	0.88 mm (0.0346 in)	When worn or damaged
		C	0.92 mm (0.0362 in)	When worn or damaged
		D	0.96 mm (0.0378 in)	When worn or damaged
		E	1.00 mm (0.0394 in)	When worn or damaged
		F	1.04 mm (0.0409 in)	When worn or damaged
		G	1.08 mm (0.0425 in)	When worn or damaged
		H	1.12 mm (0.0441 in)	When worn or damaged
		I	1.16 mm (0.0457 in)	When worn or damaged
		J	1.20 mm (0.0472 in)	When worn or damaged
		K	1.24 mm (0.0488 in)	When worn or damaged
		L	1.28 mm (0.0504 in)	When worn or damaged
		M	1.32 mm (0.0520 in)	When worn or damaged
		N	1.36 mm (0.0535 in)	When worn or damaged
		O	1.40 mm (0.0551 in)	When worn or damaged
		P	1.44 mm (0.0567 in)	When worn or damaged
		Q	1.48 mm (0.0583 in)	When worn or damaged
		R	1.52 mm (0.0598 in)	When worn or damaged
		S	1.56 mm (0.0614 in)	When worn or damaged
		T	1.60 mm (0.0630 in)	When worn or damaged
		U	1.64 mm (0.0646 in)	When worn or damaged
		V	1.68 mm (0.0661 in)	When worn or damaged
		W	1.72 mm (0.0677 in)	When worn or damaged
		X	1.76 mm (0.0693 in)	When worn or damaged
		Y	1.80 mm (0.0709 in)	When worn or damaged
		Z	1.84 mm (0.0724 in)	When worn or damaged
	Thrust shim thickness (65 mm)	AA	1.88 mm (0.0740 in)	When worn or damaged
		AB	1.92 mm (0.0756 in)	When worn or damaged
		AC	1.96 mm (0.0772 in)	When worn or damaged
		AD	2.00 mm (0.0787 in)	When worn or damaged
		AE	2.04 mm (0.0803 in)	When worn or damaged
		AF	2.08 mm (0.0819 in)	When worn or damaged
		AG	2.12 mm (0.0835 in)	When worn or damaged
		AH	2.16 mm (0.0850 in)	When worn or damaged
		AI	2.20 mm (0.0866 in)	When worn or damaged
		AJ	2.24 mm (0.0882 in)	When worn or damaged
		AK	2.28 mm (0.0898 in)	When worn or damaged
		AL	2.32 mm (0.0913 in)	When worn or damaged
		AM	0.76 mm (0.0299 in)	When worn or damaged
	1st gear collar length		63.3-63.4 mm (2.492-2.496 in)
	Splined washer thickness		8.966-9.010 mm (0.35299-0.35472 in)
	Sealing ring thickness		1.91-1.97 mm (0.0752-0.0776 in)	1.86 mm (0.0732 in)
Sealing ring groove width		2.025-2.060 mm (0.07972-0.08110 in)	2.08 mm (0.0819 in)
Feed pipe bushing I.D.	1st clutch	11.518-11.530 mm (0.45346-0.45394 in)	11.545 mm (0.45453 in)
Feed pipe bushing I.D.	1st-hold clutch	6.018-6.030 mm (0.23693-0.23740 in)	6.045 mm (0.23799 in)
ATF feed pipe O.D.	1st clutch	11.47-11.48 mm (0.4516-0.4520 in)	11.45 mm (0.4508 in)
ATF feed pipe O.D.	1st-hold clutch	5.97-5.98 mm (0.2350-0.2354 in)	5.95 mm (0.2343 in)
Intermediary shaft	I.D. of 3rd gear		36.000-36.016 mm (1.41732-1.41795 in)	When worn or damaged
	Axial clearance of 3rd gear		0.005-0.045 mm (0.00020-0.00177 in)	When worn or damaged
	Washer thickness (26.5 mm)	A	1.05 mm (0.0413 in)	When worn or damaged
		B	1.13 mm (0.0445 in)	When worn or damaged
		C	1.21 mm (0.0476 in)	When worn or damaged
		D	1.29 mm (0.0508 in)	When worn or damaged
		E	1.37 mm (0.0539 in)	When worn or damaged
		F	1.45 mm (0.0571 in)	When worn or damaged
		G	1.53 mm (0.0602 in)	When worn or damaged
		H	1.61 mm (0.0634 in)	When worn or damaged
		I	1.69 mm (0.0665 in)	When worn or damaged
		J	1.77 mm (0.0697 in)	When worn or damaged
		K	1.85 mm (0.0728 in)	When worn or damaged
		L	1.93 mm (0.0760 in)	When worn or damaged
		M	2.01 mm (0.0791 in)	When worn or damaged
		N	2.09 mm (0.0823 in)	When worn or damaged
		O	0.97 mm (0.0382 in)	When worn or damaged
	Splined washer thickness (53 mm)	A	3.995 mm (0.15728 in)	When worn or damaged
		B	4.015 mm (0.15807 in)	When worn or damaged
		C	4.035 mm (0.15886 in)	When worn or damaged
		D	4.055 mm (0.15965 in)	When worn or damaged
		E	4.075 mm (0.16043 in)	When worn or damaged
		F	4.095 mm (0.16122 in)	When worn or damaged
		G	4.115 mm (0.16201 in)	When worn or damaged
		H	4.135 mm (0.16279 in)	When worn or damaged
		I	4.155 mm (0.16358 in)	When worn or damaged
		J	4.175 mm (0.16437 in)	When worn or damaged
		K	4.195 mm (0.16516 in)	When worn or damaged
		L	4.215 mm (0.16594 in)	When worn or damaged
		M	4.235 mm (0.16673 in)	When worn or damaged
		N	4.255 mm (0.16752 in)	When worn or damaged
	Cotter thickness		2, 99-3.02 mm (0.1177-0.1189 in)
	Sealing ring thickness		1.89-1.95 mm (0.0744-0.0768 in)	1.84 mm (0.0724 in)
	Sealing ring groove width		2.025-2.060 mm (0.07972-0.08110 in)	2.08 mm (0.0819 in)
Reverse idler gear	Gear shaft O.D.		13.99-14.00 mm (0.5508-0.5512 in)	When worn or damaged
	I.D.		18.007-18.020 mm (0.70894-0.70945 in)	When worn or damaged
	I.D. of transmission housing at reverse idler gear shaft contact area		14.006-14.024 mm (0.55142-0.55212 in)
	Thrust washer thickness	Transmission housing side	1.00-1.05 mm (0.0394-0.0413 in)
	Thrust washer thickness	Holder side	1.00-1.05 mm (0.0394-0.0413 in)
	Axial clearance		0.07-0.38 mm (0.0028-0.0150 in)
ATF pump	ATF pump thrust clearance		0.03-0.06 mm (0.002-0.002 in)	0.07 mm (0.002 in)
	Clearance between ATF pump gear and main valve body	Drive gear	0.210-0.265 mm (0.009-0.010 in)
	Clearance between ATF pump gear and main valve body	Driven gear	0.070-0.125 mm (0.003-0.004 in)
	ATF pump driven gear I.D.		14.016-14.034 mm (0.55181-0.55252 in)	When worn or damaged
	ATF pump driven gear shaft O.D.		13.980-13.990 mm (0.55039-0.55079 in)	When worn or damaged
Stator shaft	I.D. at needle bearing contact area	At torque converter side	27.000-27.021 mm (1.06299-1.06382 in)	When worn or damaged
	I.D. at needle bearing contact area	At ATF pump side	31.000-31.025 mm (1.22047-1.22145 in)
	I.D. at mainshaft sealing ring contact area		31.000-31.025 mm (1.22047-1.22145 in)	31.05 mm (1.2224 in)
Reverse shift fork	Fork finger thickness		5.90-6.00 mm (0.2323-0.2362 in)	5.4 mm (0.213 in)
Park gear and pawl				When worn or damaged
Regulator valve body	Shift fork shaft bore I.D.		14.000-14.010 mm (0.55118-0.55157 in)
	Shift fork shaft/servo valve bore I.D.		37.000-37.039 mm (1.45669-1.45823 in)	37.045 mm (1.45846 in)
	Mainshaft sealing ring contact I.D.		31.000-31.025 mm (1.22047-1.22145 in)	31.05 mm (1.2224 in)
Main valve body	Intermediary shaft sealing ring contact I.D.		35.000-35.025 mm (1.37795-1.37893 in)	35.05 mm (1.3799 in)
ATF guide collar	Secondary shaft sealing ring contact 1. D.		29.000-29.021 mm (1.14173-1.14256 in)	29.05 mm (1.1437 in)
Main valve body spring	Shift valve A spring	Wire diameter	0.9 mm (0.035 in)
		O.D.	6.6 mm (0.260 in)
		Free length	50.5 mm (1.988 in)
		No. of coil	23.3
	Shift valve B spring	Wire diameter	0.8 mm (0.031 in)
		O.D.	6.6 mm (0.260 in)
		Free length	49.1 mm (1.933 in)
		No. of coil	21.7
	Shift valve E spring	Wire diameter	0.7 mm (0.028 in)
		O.D.	6.6 mm (0.260 in)
		Free length	42.4 mm (1.669 in)
		No. of coil	17.6
	Relief valve spring	Wire diameter	1.0 mm (0.039 in)
		O.D.	L9.6 mm (0.378 in)
		Free length	28.1 mm (1.106 in)
		No. of coil	7.7
	Torque converter check valve spring	Wire diameter	1.1 mm (0.043 in)
		O.D.	8.6 mm (0.339 in)
		Free length	35.0 mm (1.378 in)
		No. of coil	12.6
	Modulator valve spring	Wire diameter	1.6 mm (0.063 in)
		O.D.	10.4 mm (0.409 in)
		Free length	33.5 mm (1.319 in)
		No. of coil	9.8
	CPC valve A spring	Wire diameter	0.7 mm (0.028 in)
		O.D.	6.1 mm (0.240 in)
		Free length	17.8 mm (0.701 in)
		No. of coil	7.9
	Servo control valve spring	Wire diameter	0.9 mm (0.035 in)
		O.D.	9.6 mm (0.378 in)
		Free length	30.2 mm (1.189 in)
		No. of coil	8.4
	Lubrication control valve spring	Wire diameter	0.9 mm (0.035 in)
		O.D.	8.7 mm (0.343 in)
		Free length	25.0 mm (0.984 in)
		No. of coil	7.2
	Lock-up timing valve spring	Wire diameter	0.6 mm (0.024 in)
		O.D.	6.6 mm (0.260 in)
		Free length	30.9 mm (1.217 in)
		No. of coil	11.1
	Lock-up shift valve spring	Wire diameter	1.0 mm (0.039 in)
		O.D.	6.6 mm (0.260 in)
		Free length	35.5 mm (1.398 in)
		No. of coil	18.2
Secondary valve body spring	CPC valve B spring	Wire diameter	0.7 mm (0.028 in)
		O.D.	6.1 mm (0.240 in)
		Free length	17.8 mm (0.701 in)
		No. of coil	7.9
	CPC valve C spring	Wire diameter	0.7 mm (0.028 in)
		O.D.	6.1 mm (0.240 in)
		Free length	17.8 mm (0.701 in)
		No. of coil	7.9
	Shift valve C spring	Wire diameter	0.8 mm (0.031 in)
		O.D.	6.6 mm (0.260 in)
		Free length	49.1 mm (1.933 in)
		No. of coil	21.7
	Shift valve D spring	Wire diameter	0.7 mm (0.028 in)
		O.D.	6.6 mm (0.260 in)
		Free length	42.4 mm (1.669 in)
		No. of coil	17.6
	Reverse CPC valve spring	Wire diameter	0.8 mm (0.031 in)
		O.D.	6.1 mm (0.240 in)
		Free length	24.4 mm (0.961 in)
		No. of coil	14.6
	Reverse control valve spring	Wire diameter	0.8 mm (0.031 in)
		O.D.	6.6 mm (0.260 in)
		Free length	49.1 mm (1.933 in)
		No. of coil	21.7
Regulator valve body spring	3rd accumulator spring	Wire diameter	3.1 mm (0.122 in)
		O.D.	19.6 mm (0.772 in)
		Free length	41.4 mm (1.630 in)
		No. of coil	5.5
	Cooler check valve spring	Wire diameter	0.9 mm (0.035 in)
		O.D.	6.7 mm (0.264 in)
		Free length	31.5 mm (1.240 in)
		No. of coil	14.2
	Regulator valve spring A	Wire diameter	1.85 mm (0.0728 in)
		O.D.	14.7 mm (0.579 in)
		Free length	86.9 mm (3.421 in)
		No. of coil	16.2
	Regulator valve spring B	Wire diameter	1.4 mm (0.055 in)
		O.D.	8.8 mm (0.346 in)
		Free length	44.0 mm (1.732 in)
		No. of coil	12.0
	Stator reaction spring	Wire diameter	5.5 mm (0.217 in)
		O.D.	37.4 mm (1.472 in)
		Free length	30.3 mm (1.193 in)
		No. of coil	2.1
	Lock-up control valve spring (Type A)	Wire diameter	0.7 mm (0.028 in)
		O.D.	6.6 mm (0.260 in)
		Free length	42.9 mm (1.689 in)
		No. of coil	14.2
	Lock-up control valve spring (Type B)	Wire diameter	0.8 mm (0.031 in)
		O.D.	6.6 mm (0.260 in)
		Free length	44.3 mm (1.744 in)
		No. of coil	25.5
Accumulator body spring	1st accumulator spring A	Wire diameter	2.3 mm (0.091 in)
		O.D.	19.6mm (0.772in)
		Free length	60.8 mm (2.394 in)
		No. of coil	9.5
	1st accumulator spring B	Wire diameter	2.5 mm (0.098 in)
		O.D.	12.8 mm (0.504 in)
		Free length	46.0 mm (1.811 in)
		No. of coil	9.5
	1st-hold accumulator spring	Wire diameter	2.0 mm (0.079 in)
		O.D.	13.1 mm (0.516 in)
		Free length	42.9 mm (1.689 in)
		No. of coil	9.8
	2nd accumulator spring	Wire diameter	3.1 mm (0.122 in)
		O.D.	19.6 mm (0.772 in)
		Free length	53.4 mm (2.102 in)
		No. of coil	7.5
	4th accumulator spring	Wire diameter	3.3 mm (0.130 in)
		O.D.	19.6 mm (0.772 in)
		Free length	39.1 mm (1.539 in)
		No. of coil	5.8
	5th accumulator spring A	Wire diameter	2.4 mm (0.094 in)
		O.D.	19.6 mm (0.772 in)
		Free length	65.5 mm (2.579 in)
		No. of coil	12.0
	5th accumulator spring B	Wire diameter	2.6 mm (0.102 in)
		O.D.	13.2 mm (0.520 in)
		Free length	50.5 mm (1.988 in)
		No. of coil	10.1
A/T differential carrier	Pinion shaft contact area I.D.		18.000-18.025 mm (0.70866-0.70964 in)
	Driveshaft contact area I.D.		30.025-30.055 mm (1.18208-1.18327 in)
	Clearance between carrier and pinion shaft		0.013-0.054 mm (0.00051-0.00213 in)	0.1 mm (0.004 in)
	Clearance between carrier and driveshaft		0.045-0.096 mm (0.00177-0.00378 in)	0.13 mm (0.0051 in)
	Clearance between carrier and intermediate shaft		0.080-0.126 mm (0.00315-0.00496 in)
	Carrier bearing starting torque (preload)	For new bearing	3.9-5.1 N.m (40-52 kgf.cm, 35-45 lbf.in)	Adjust
	Carrier bearing starting torque (preload)	For reused bearing	3.6-4.8 N.m (37-49 kgf.cm, 32-43 lbf.in)	Adjust
A/T differential pinion gear	Backlash		0.05-0.15 mm (0.0020-0.0059 in)
	I.D.		18.042-18.066 mm (0.71031-0.71126 in)
	Clearance between pinion gear and pinion shaft		0.055-0.095 mm (0.00217-0.00374 in)	0.12 mm (0.0047 in)
Transfer output shaft	Diameter of bearing contact area	At transmission housing side	21.977-21.990 mm (0.86523-0.86575 in)	21.92 mm (0.8630 in)
	Diameter of bearing contact area	At torque converter housing side	40.002-40.018 mm (1.57488-1.57551 in)	39.95 mm (1.5728 in)
	Axial clearance		0-0.39 mm (0-0.0154 in)
	Thrust washer thickness (28.5 mm)	A	1.82 mm (0.0717 in)	When worn or damaged
		B	1.84 mm (0.0724 in)	When worn or damaged
		C	1.86 mm (0.0732 in)	When worn or damaged
		D	1.88 mm (0.0740 in)	When worn or damaged
		E	1.90 mm (0.0748 in)	When worn or damaged
		F	1.92 mm (0.0756 in)	When worn or damaged
		G	1.94 mm (0.0764 in)	When worn or damaged
		H	1.96 mm (0.0772 in)	When worn or damaged
		I	1.98 mm (0.0780 in)	When worn or damaged
		J	2.00 mm (0.0787 in)	When worn or damaged
		K	2.02 mm (0.0795 in)	When worn or damaged
		L	2.04 mm (0.0803 in)	When worn or damaged
		M	2.06 mm (0.0811 in)	When worn or damaged
		N	2.08 mm (0.0819 in)	When worn or damaged
		O	2.10 mm (0.0827 in)	When worn or damaged
		P	2.12 mm (0.0835 in)	When worn or damaged
		Q	2.14 mm (0.0843 in)	When worn or damaged
		R	2.16 mm (0.0850 in)	When worn or damaged
		S	2.18 mm (0.0858 in)	When worn or damaged
		T	2.20 mm (0.0866 in)	When worn or damaged
		U	2.22 mm (0.0874 in)	When worn or damaged
		V	2.24 mm (0.0882 in)	When worn or damaged
		W	2.26 mm (0.0890 in)	When worn or damaged
		X	2.28 mm (0.0898 in)	When worn or damaged
		Y	2.30 mm (0.0906 in)	When worn or damaged
		Z	2.32 mm (0.0913 in)	When worn or damaged
		AA	2.34 mm (0.0921 in)	When worn or damaged
Transfer assembly fluid	Capacity: Hypoid gear oil SAE90 viscosity, API classified GL4 or GL5 only	Fluid change	0.43 L (0.45 US qt)
Transfer assembly fluid		Overhaul	0.45 L (0.48 US qt)
Transfer assembly	Diameter of transfer hypoid drive gear/shaft assembly at tapered roller bearing contact area	At transfer cover side	50.002-50.018 mm (1.96858-1.96921 in)	49.95 mm (1.9665 in)
		At transfer gear side	24.987-25.000 mm (0.98374-0.98425 in)	24.93 mm (0.9815 in)
	Diameter of transfer output shaft (hypoid gear) at tapered roller bearing contact area	At transfer gear side	40.002-40.018 mm (1.57488-1.57551 in)	39.95 mm (1.5728 in)
		At companion flange side	31.975-31.988 mm (1.25886-1.25937 in)	31.92 mm (1.2567 in)
	Transfer gear backlash		0.06-0.16 mm (0.0024-0.0063 in)	Adjust
	Tapered roller bearing total starting torque (preload)		2.64-4.23 N.m (27.0-43.1 kgf.cm, 23.4-37.4 lbf.in)	Adjust
	Transfer output shaft (hypoid gear) starting torque		1.15-1.71 N.m (11.7-17.4 kgf.cm, 10.2-15.1 lbf.in)	Adjust
	Transfer hypoid gear/shaft starting torque		1.49-2.52 N.m (15.2-25.6 kgf.cm, 13.2-22.3 lbf.in)	Adjust

Rear Differential

Item	Measurement	Qualification	Standard or New	Service Limit
Rear differential fluid	Capacity: use Acura All-Wheel Drive Fluid (DPSF)	Fluid change	2.53 L (2.67 US qt)
Rear differential fluid	Capacity: use Acura All-Wheel Drive Fluid (DPSF)	Overhaul	2.77 L (2.93 US qt)

Steering

Item	Measurement	Qualification	Standard or New
Steering wheel	Rotational play measured at outside edge		0-10 mm (0-0.39 in)
Steering wheel	Initial turning load measured at outside edge with engine running		29 N (3.0 kgf, 6.6 lbf)
Gearbox	Angle of rack guide screw loosened from locked position		15 ±5°
Pump	Output pressure with shut-off valve closed		8, 140-8, 826 kPa (83-90 kgf/cm 2 , 1, 180-1, 280 psi)
Power steering fluid	Capacity: use Acura power steering fluid	System capacity	0.9L (1.0 US qt)
Power steering fluid	Capacity: use Acura power steering fluid	Reservoir capacity	0.3 L (0.3 US qt)

Suspension

Item	Measurement	Qualification	Standard or New	Service Limit
Wheel alignment	Camber	Front	0°10'±45'
	Camber	Rear	1° 00'±45'
	Caster	Front	2°57'±1°
	Total toe-in	Front	0±2mm (0±0.08in)
	Total toe-in	Rear	2.52 mm (0.098±0.08 in)
	Front wheel turning angle	Inward	35° 24' +2°
	Front wheel turning angle	Outward (reference)	30° 30'
Wheel	Runout	Axial	0-0.7 mm (0.00-0.028 in)	2.0 mm (0.079 in)
Wheel	Runout	Radial	0-0.7 mm (0.00-0.028 in)	1.5 mm (0.059 in)
Wheel bearing	End play	Front	0-0.05 mm (0.00-0.0020 in)
Wheel bearing	End play	Rear	0-0.05 mm (0.00-0.0020 in)

Brakes

Item	Measurement	Qualification	Standard or New	Service Limit
Parking brake	Number of clicks when pedal pressed with 294 N (30.0 kgf, 66.1 lbf) of force		6 to 7 clicks
	Drum I.D.		199.9-200.0 mm (7.870-7.874 in)	201.0 mm (7.913 in)
	Shoe lining thickness		3.2 mm (0.126 in)	1.0 mm (0.039 in)
Brake pedal	Height from floor		165 mm (6.50 in)
Brake pedal	Free play		1-5 mm (0.04-0.20 in)
Brake disc	Thickness	Front	27.8-28.1 mm (1.094-1.106 in)	26.0 mm (1.024 in)
	Thickness	Rear	8.9-9.1 mm (0.350-0.358 in)	7.5 mm (0.295 in)
	Runout			0.04 mm (0.0016 in)
	Parallelism			0.015 mm (0.00059 in)
Brake pad	Thickness	Front	11.5-12.2 mm (0.453-0.480 in)	1.6 mm (0.063 in)
Brake pad	Thickness	Rear	8.3-9.0 mm (0.327-0.354 in)	1.6 mm (0.063 in)

Air Conditioning

Item	Measurement	Qualification	Standard or New
Refrigerant	Type		HFC-134a (R-134a)
Refrigerant	Capacity of system		450-500 g (15.8-17.6 oz)
Refrigerant oil	Type		SP-10 (P/N 38897-P13-A01AH)
	Capacity of components	Condenser	40mL (1 1/3fl.oz)
		Evaporator	40mL (1 1/3fl.oz)
		Each line and hose	10mL (1/3 fl.oz)
		Receiver/dryer	10mL (1/3 fl.oz)
		Compressor	80-90 mL (2 2/3-3 fl.oz)
Compressor	Field coil resistance	At 68°F (20°C)	3.35-3.65 ohms
Compressor	Pulley-to-armature plate clearance		0.35-0.65 mm (0.0138-0.0256 in)

Location	Item	Torque
Starting system	Starter bolt (10 mm)	44 N.m (4.5 kgf.m, 33 lbf.ft)
	Starter bolt (12 mm)	64 N.m (6.5 kgf.m, 47 lbf.ft)
	Starter harness clamp nut	9.0 N.m (0.92 kgf.m, 6.6 lbf.ft)
Ignition system	Spark plugs	18 N.m (1.8 kgf.m, 13 lbf.ft)
Charging system	Alternator bolts	22 N.m (2.2 kgf.m, 16 lbf.ft)
	Drive belt auto-tensioner bolts	22 N.m (2.2 kgf.m, 16 lbf.ft)
	Drive belt auto-tensioner pulley bolt	56 N.m (5.7 kgf.m, 41 lbf.ft)

Engine Mechanical

Location	Item	Remark	Torque
Engine assembly	Engine mount bracket bolts		44 N.m (4.5 kgf.m, 33 lbf.ft)
	Side engine mount bolt (12 mm) (1) Qty 1 (Engine side)		72 N.m (7.3 kgf.m, 52 lbf.ft)
	Side engine mount bolts (12 mm) (1) Qty 2 (Body side)		64 N.m (6.5 kgf.m, 47 lbf.ft)
	Side engine mount stiffener bolts		74 N.m (7.5 kgf.m, 54 lbf.ft)
	Side engine mount bracket bolt (1)	Use new bolt	64 N.m (6.5 kgf.m, 47 lbf.ft)
	Side engine mount bracket nut (1)	Use new nut	64 N.m (6.5 kgf.m, 47 lbf.ft)
	Transumission mount bolt (1) (Transmission side)	Use new bolt	83 N.m (8.5 kgf.m, 61 lbf.ft)
	Transumission mount bolts (1) (Body side)	Use new bolts	83 N.m (8.5 kgf.m, 61 lbf.ft)
	Transumission mount nuts (1)	Use new nuts	83 N.m (8.5 kgf.m, 61 lbf.ft)
	Transumission mount stiffener bolts		22 N.m (2.2 kgf.m, 16 lbf.ft)
	Lower torque rod bracket bolts	Use new bolts	74 N.m (7.5 kgf.m, 54 lbf.ft)
	Lower torque rod bolts (12 mm) (1)	Use new bolts	64 N.m (6.5 kgf.m, 47 lbf.ft)
	Lower torque rod bolt (14 mm) (1)		93 N.m (9.5 kgf.m, 69 lbf.ft)
	Upper torque rod bolts (1)	Use new bolts	64 N.m (6.5 kgf.m, 47 lbf.ft)
	Upper torque rod stiffener bolts	Use new bolts	54 N.m (5.5 kgf.m, 40 lbf.ft)
Engine lubrication	Oil filter		12 N.m (1.2 kgf.m, 9 lbf.ft)
	Oil filter feed pipe	Use oil on threads	35 N.m (3.6 kgf.m, 26 lbf.ft)
	Oil pan drain bolt	Use new washer	39 N.m (4.0 kgf.m, 29 lbf.ft)
	Oil pressure switch	Use liquid gasket on threads	18 N.m (1.8 kgf.m, 13 lbf.ft)
Intake manifold and exhaust system	Intake manifold bolts		22 N.m (2.2 kgf.m, 16 lbf.ft)
	Intake manifold nuts		22 N.m (2.2 kgf.m, 16 lbf.ft)
	Intake manifold bracket bolt		22 N.m (2.2 kgf.m, 16 lbf.ft)
	Intake manifold bracket nut		22 N.m (2.2 kgf.m, 16 lbf.ft)
	Turbocharger outlet pipe nuts		22 N.m (2.2 kgf.m, 16 lbf.ft)
	Exhaust manifold bolts		44 N.m (4.5 kgf.m, 33 lbf.ft)
	Exhaust manifold self-locking nuts	Use new nuts	44 N.m (4.5 kgf.m, 33 lbf.ft)
	Turbocharger mounting nut		44 N.m (4.5 kgf.m, 33 lbf.ft)
	Turbocharger mounting bolts		44 N.m (4.5 kgf.m, 33 lbf.ft)
	Turbocharger bracket bolts		44 N.m (4.5 kgf.m, 33 lbf.ft)
	Oil feed nut	Use new washers	34 N.m (3.5 kgf.m, 25 lbf.ft)
	Oil feed bolt	Use new washers	74 N.m (7.5 kgf.m, 54 lbf.ft)
	Muffler and joint bolts		22 N.m (2.2 kgf.m, 16 lbf.ft)
NOTE: Refer to the Service Information for the precautions and complete procedures. Refer to the Service Information for the bolts/nuts not indicated here. (1) Follow the Service Information procedures closely for torque, sequence, and special steps.

NOTE
Refer to the Service Information for the precautions and complete procedures. Refer to the Service Information for the bolts/nuts not indicated here.

(1)	Follow the Service Information procedures closely for torque, sequence, and special steps.

Engine Cooling

Location	Item	Remark	Torque
Cooling system	Water passage bolts		44 N.m (4.5 kgf.m, 33 lbf.ft)
Cooling system	Water passage nuts		44 N.m (4.5 kgf.m, 33 lbf.ft)

Fuel Emissions

Location	Item	Torque
Fuel and emissions	A/F sensor	44 N.m (4.5 kgf.m, 33 lbf.ft)
	Fuel rail mounting nut	22 N.m (2.2 kgf.m, 16 lbf.ft)
	Knock sensor	31 N.m (3.2 kgf.m, 23 lbf.ft)
	Secondary HO2S	44 N.m (4.5 kgf.m, 33 lbf.ft)
	WU-TWC bracket mounting bolt (Access for secondary HO2S)	44 N.m (4.5 kgf.m, 33 lbf.ft)
	Rocker arm oil pressure switch	22 N.m (2.2 kgf.m, 16 lbf.ft)
	Fuel pressure regulator	29 N.m (3.0 kgf.m, 21 lbf.ft)
	Fuel pulsation damper	22 N.m (2.2 kgf.m, 16 lbf.ft)
	Fuel tank locknut (follow the Service Information for special steps)	70 N.m (7.1 kgf.m, 52 lbf.ft)
	Fuel tank support straps bolt	38 N.m (3.9 kgf.m, 28 lbf.ft)
	Throttle body mounting bolt	22 N.m (2.2 kgf.m, 16 lbf.ft)
	Throttle body mounting nut	22 N.m (2.2 kgf.m, 16 lbf.ft)
	Under-floor TWC mounting bolt	22 N.m (2.2 kgf.m, 16 lbf.ft)
	Under-floor TWC mounting nut	33 N.m (3.4 kgf.m, 25 lbf.ft)
	Warm up TWC mounting bolt	44 N.m (4.5 kgf.m, 33 lbf.ft)
	Warm up TWC mounting nut	44 N.m (4.5 kgf.m, 33 lbf.ft)
	PCV valve	44 N.m (4.5 kgf.m, 33 lbf.ft)
	EVAP canister bracket nut	22 N.m (2.2 kgf.m, 16 lbf.ft)

Automatic Transmission

Location	Item	Remark	Torque
Automatic transmission	ATF drain plug	Use new sealing washer	49 N.m (5.0 kgf.m, 36 lbf.ft)
	ATF filler bolt	Use new sealing washer	44 N.m (4.5 kgf.m, 33 lbf.ft)
	Clutch pressure inspection hole sealing bolts	Use new sealing washers	18 N.m (1.8 kgf.m, 13 lbf.ft)
	Drive plate bolts (1)		74 N.m (7.5 kgf.m, 54 lbf.ft)
	Shift cable end nut		22 N.m (2.2 kgf.m, 16 lbf.ft)
	Shift lever assembly bolts		22 N.m (2.2 kgf.m, 16 lbf.ft)
	Transfer fluid drain plug	Use new sealing washer	44 N.m (4.5 kgf.m, 33 lbf.ft)
	Transfer fluid filler plug	Use new sealing washer	44 N.m (4.5 kgf.m, 33 lbf.ft)
	Transfer assembly bolts		51 N.m (5.2 kgf.m, 38 lbf.ft)
	Transmission fluid pressure switches	Use new sealing washers	20 N.m (2.0 kgf.m, 14 lbf.ft)
	Transmission housing mounting bolts		64 N.m (6.5 kgf.m, 47 lbf.ft)
A/T gear position indicator	Selector control lever locknut	Use new lock washer	16 N.m (1.6 kgf.m, 12 lbf.ft)
A/T gear position indicator	Transmission range switch locknut	Use new lock washer	17 N.m (1.7 kgf.m, 1.3 lbf.ft)
(1) Follow the Service Information procedures closely for torque, sequence, and special steps.

(1)	Follow the Service Information procedures closely for torque, sequence, and special steps.

Location	Item	Remark	Torque
Rear differential	Filler plug	Use new sealing washer	47 N.m (4.8 kgf.m, 35 lbf.ft)
	Drain plug	Use new sealing washer	47 N.m (4.8 kgf.m, 35 lbf.ft)
	Rear differential front bolts	Use new bolts	74 N.m (7.5 kgf.m, 54 lbf.ft)
	Rear differential front nuts		38 N.m (3.9 kgf.m, 28 lbf.ft)
	Rear differential rear bolt	Use new bolt	74 N.m (7.5 kgf.m, 54 lbf.ft)
	Rear differential side case bolts (1)		27 N.m (2.8 kgf.m, 20 lbf.ft)
(1) Follow the Service Information procedures closely for torque, sequence, and special steps.

(1)	Follow the Service Information procedures closely for torque, sequence, and special steps.

Driveline/Axle

Location	Item	Remark	Torque
Driveline/axle	Spindle nut (26 mm)	Use oil on the seating surface Use new nut	328 N.m (33.5 kgf.m, 242 lbf.ft)
	Spindle nut (24 mm)	Use oil on the seating surface Use new nut	245 N.m (25.0 kgf.m, 181 lbf.ft)
	Intermediate shaft dowel bolts		39 N.m (4.0 kgf.m, 29 lbf.ft)
	Intermediate shaft flange bolt		39 N.m (4.0 kgf.m, 29 lbf.ft)
	Heat shield bolts		22 N.m (2.2 kgf.m, 16 lbf.ft)
	No. 1 propeller shaft bolts	Use new bolts	72 N.m (7.3 kgf.m, 53 lbf.ft)
	No. 2 propeller shaft bolts	Use new bolts	72 N.m (7.3 kgf.m, 53 lbf.ft)
	Propeller shaft protector bolts		22 N.m (2.2 kgf.m, 16 lbf.ft)
	Center support bearing bolts	Use new bolts	39 N.m (4.0 kgf.m, 29 lbf.ft)

Location	Item	Torque
Steering	Steering wheel bolt	39 N.m (4.0 kgf.m, 29 lbf.ft)
	Steering joint bolt	28 N.m (29 kgf.m, 21 lbf.ft)
	Steering column bolts (1)	22 N.m (2.2 kgf.m, 16 lbf.ft)
	Steering column nuts (1)	13 N.m (1.3 kgf.m, 10 lbf.ft)
	Steering pump bolts	22 N.m (2.2 kgf.m, 16 lbf.ft)
	Steering gearbox bolts	58 N.m (5.9 kgf.m, 43 lbf.ft)
	Steering gearbox bracket bolts	74 N.m (7.5 kgf.m, 54 lbf.ft)
	Tie-rod end ball joint nut	54 N.m (5.5 kgf.m, 40 lbf.ft)
	Tie-rod end locknut	44 N.m (4.5 kgf.m, 32 lbf.ft)
(1) Parts to be tightened in a particular order.

(1)	Parts to be tightened in a particular order.

Location	Item	Remark	Torque
Front suspension	Wheel nuts		108 N.m (11.0 kgf.m, 80.0 lbf.ft)
	Knuckle damper pinch bolts/nuts	Use new bolts/nuts	152 N.m (15.5 kgf.m, 112 lbf.ft)
	Lower arm ball joint castle nut	Use new nut	59-69 N.m (6.0-7.0 kgf.m, 43-51 lbf.ft)
	Lower arm bolts (12mm)	Use new bolts	59 N.m (6.0 kgf.m, 44 lbf.ft)
	Lower arm bolt (14mm)	Use new bolt	103 N.m (10.5 kgf.m, 76 lbf.ft)
	Lower ball Joint bolt		52 N.m (5.3 kgf.m, 38 lbf.ft)
	Lower ball Joint nuts	Use new nuts	52 N.m (5.3 kgf.m, 38 lbf.ft)
	Stabilizer bar bushing holder flange bolts		22 N.m (2.2 kgf.m, 16 lbf.ft)
	Stabilizer link flange nuts	Use new nuts	78 N.m (8.0 kgf.m, 58 lbf.ft)
	Damper upper flange nuts		44 N.m (4.5 kgf.m, 33 lbf.ft)
Rear suspension	Wheel nuts		108 N.m (11.0 kgf.m, 80 lbf.ft)
	Knuckle self-locking nuts (to trailing arm)	Use new nuts	118 N.m (12.0 kgf.m, 87 lbf.ft)
	Hub bearing unit bolts		98 N.m (10.0 kgf.m, 72 lbf.ft)
	Upper arm flange bolt	Use new bolt	103 N.m (10.5 kgf.m, 76 lbf.ft)
	Upper arm ball joint castle nut	Use new nut	54-64 N.m (5.5-6.5 kgf.m, 40-47 lbf.ft)
	Lower arm A self-locking nut	Use new nut	132 N.m (13.5 kgf.m, 97 lbf.ft)
	Lower arm A bolt	Use new bolt	103 N.m (10.5 kgf.m, 76 lbf.ft)
	Lower arm B nut	Use new nut	59 N.m (6.0 kgf.m, 44 lbf.ft)
	Lower arm B bolt	Use new bolt	103 N.m (10.5 kgf.m, 76 lbf.ft)
	Trailing arm bolts (to body)	Use new bolts	103 N.m (10.5 kgf.m, 76 lbf.ft)
	Stabilizer bar bushing holder flange bolts		39 N.m (4.0 kgf.m, 29 lbf.ft)
	Stabilizer link flange nut (to lower arm B)	Use new nut	39 N.m (4.0 kgf.m, 29 lbf.ft)
	Stabilizer link self-locking nut (to stabilizer bar)	Use new nut	40 N.m (4.1 kgf.m, 30 lbf.ft)
	Damper lower flange bolt	Use new bolt	103 N.m (10.5 kgf.m, 76 lbf.ft)
	Damper upper self-locking nut	Use new nut	29 N.m (3.0 kgf.m, 21 lbf.ft)

Location	Item	Remark	Torque
Conventional brake	Front brake caliper bolts		50 N.m (5.1 kgf.m, 37 lbf.ft)
	Front brake caliper bracket bolts		137 N.m (14.0 kgf.m, 101 lbf.ft)
	Front brake hose banjo bolt	Use new washers	34 N.m (3.5 kgf.m, 25 lbf.ft)
	Rear brake caliper bolts		23 N.m (2.3 kgf.m, 17 lbf.ft)
	Rear brake caliper bracket bolts		108 N.m (11.0 kgf.m, 80 lbf.ft)
	Rear brake hose banjo bolt	Use new washers	34 N.m (3.5 kgf.m, 25 lbf.ft)
	Master cylinder nuts		13 N.m (1.3 kgf.m, 10 lbf.ft)
	Master cylinder brake line		22 N.m (2.2 kgf.m, 16 lbf.ft)
	Brake booster/brake pedal nuts		12 N.m (1.2 kgf.m, 9 lbf.ft)
	Brake pedal bolt		22 N.m (2.2 kgf.m, 16 lbf.ft)
	Parking brake pedal bolts		22 N.m (2.2 kgf.m, 16 lbf.ft)
	Parking brake pedal nuts		22 N.m (2.2 kgf.m, 16 lbf.ft)
VSA	VSA modulator control unit brake line (10 mm)		15 N.m (1.5 kgf.m, 11 lbf.ft)
VSA	VSA modulator control unit brake line (12 mm)		22 N.m (2.2 kgf.m, 16 lbf.ft)

Body

Location	Item	Torque
Frame	Front suspension subframe bolt (14 mm) (1)	103 N.m (10.5 kgf.m, 76 lbf.ft)
	Front suspension subframe bolt (12 mm) (1)	54 N.m (5.5 kgf.m, 40 lbf.ft)
	Rear damper gusset bolt	22 N.m (2.2 kgf.m, 16 lbf.ft)
	Rear suspension subframe bolt	103 N.m (10.5 kgf.m, 76 lbf.ft)
	Rear suspension subframe front bracket bolt	38 N.m (3.9 kgf.m, 28 lbf.ft)
	Rear suspension subframe rear bracket nut	38 N.m (3.9 kgf.m, 28 lbf.ft)
	Steering gearbox stiffener bolt	54 N.m (5.5 kgf.m, 40 lbf.ft)
(1) Parts to be tightened in a particular order.

(1)	Parts to be tightened in a particular order.

Heating, Ventilation, and Air Conditioning

Location	Item	Torque
A/C compressor	A/C compressor bracket bolts	24 N.m (2.4 kgf.m, 17.7 lbf.ft)
	A/C compressor bolts (8 mm)	22 N.m (2.2 kgf.m, 16 lbf.ft)
	A/C compressor bolts (10 mm)	45 N.m (4.5 kgf.m, 32.5 lbf.ft)
	A/C compressor center nut	25.5 N.m (2.6 kgf.m, 18.8 lbf.ft)
	A/C compressor relief valve	9.8 N.m (1.0 kgf.m, 7.2 lbf.ft)
Receiver line	A/C pressure sensor	10.8 N.m (1.1 kgf.m, 8.0 lbf.ft)

Body Electrical

Location	Item	Remark	Torque
Wipers/washers	Windshield wiper arm nut		29 N.m (3.0 kgf.m, 21 lbf.ft)
Wipers/washers	Windshield wiper linkage nut		31 N.m (3.2 kgf.m, 23 lbf.ft)

Item	Measurement	Qualification		Specification
DIMENSIONS	Overall length			4, 635 mm (182.5 in)
	Overall width			1, 870 mm (73.6 in)
	Overall height			1, 655 mm (65.2 in)
	Wheelbase			2, 650 mm (104.3 in)
	Track	Front		1, 572 mm (61.9 in)
	Track	Rear		1, 590 mm (62.6 in)
	Seating capacity			Five (5)
WEIGHT	Gross Vehicle Weight Rating (GVWR)	2WD		2, 140 kg (4, 718 lbs)
WEIGHT	Gross Vehicle Weight Rating (GVWR)	SH-AWD		2, 220 kg (4, 894 lbs)
ENGINE	Type			Water cooled, 4-stroke DOHC i-VTEC gasoline engine, with turbocharger
	Cylinder arrangement			Inline 4-cylinder, transverse
	Bore and stroke			86 x 99 mm (3.39 x 3.90 in)
	Displacement			2, 300 cm 3 (140.4 cu in)
	Compression ratio			8.8
	Valve train			Chain drive, DOHC i-VTEC 4 valves per cylinder
	Lubrication system			Forced, wet sump, with trochoid pump
	Fuel required			Premium UNLEADED gasoline with 91 Pump Octane Number or higher
STARTER	Type			Gear Reduction
	Nominal output			1.6 kW
	Nominal voltage			12V
	Hour rating			30 seconds
	Direction of rotation			Clockwise as viewed from drive end
AUTOMATIC TRANSMISSION	Type			Electronically-controlled automatic, five-speed forward, one reverse, three-element torque converter with lock-up clutch
	Primary reduction			Direct 1:1
	Gear ratio	1st		2.697
		2nd		1.606
		3rd		1.071
		4th	2WD	0.693
		4th	SH-AWD	0.765
		5th	2WD	0.538
		5th	SH-AWD	0.612
		Reverse		1.888
	Secondary reduction	Gear ratio		1.238
	Final reduction	Type		Single helical gear
		Gear ratio	2WD	4.312
		Gear ratio	SH-AWD	4.533
STEERING	Type			Hydraulic power-assisted rack and pinion
	Overall ratio			15.06
	Turns, lock-to-lock			2.76
	Steering wheel diameter			380 mm (15.0 in)
SUSPENSION	Type	Front		Independent McPherson strut with stabilizer, coil spring
	Type	Rear		Independent double wishbone with stabilizer, coil spring
	Shock absorber	Front		Telescopic, hydraulic, nitrogen gas-filled
	Shock absorber	Rear		Telescopic, hydraulic, nitrogen gas-filled
TIRES	Size of front and rear tires			P235/55R18 99VM+S
TIRES	Size of spare			T165/80D17 104M
WHEEL ALIGNMENT	Camber	Front		0°10'
	Camber	Rear		1° 00'
	Caster	Front		2° 57'
	Total toe-in	Front		0 mm (0 in)
	Total toe-in	Rear		2.5 mm (0.082 in)
BRAKES	Type of service brake	Front		Power-assisted self-adjusting ventilated disc
	Type of service brake	Rear		Power-assisted self-adjusting solid disc
	Type of parking brake			Mechanical actuating, rear wheels
	Pad friction surface area	Front		60.5 cm 2 (9.38 sq in) x 2
	Pad friction surface area	Rear		27.9 cm 2 (4.32 sq in) x 2
AIR CONDITIONING	Compressor	Type		Scroll
		Capacity		97.9 mL (5.97 cu in)/rev.
		Maximum speed		10, 000 RPM
		Lubricant capacity		80mL (2 2/3fl.oz)
		Lubricant type		SP-10
	Condenser	Type		Corrugated fin
	Evaporator	Type		Corrugated fin
	Blower	Type		Stabilized swirling flow
		Motor type		222W/12V
		Speed control		Infinitely variable
		Maximum capacity		480 m3 (16, 951 cu ft)/h
	Temperature control			Air-mix type
	Compressor clutch	Type		Dry, single plate, poly V-belt drive
	Compressor clutch	Electrical power consumption at 68°F (20°C)		42 W maximum at 12 V
	Refrigerant	Type		HFC-134a (R-134a)
	Refrigerant	Capacity		450-500 g (15.8--17.6 qz)
ELECTRICAL RATINGS	Battery			12 V-65 Ah/20 HR (12 V-52 Ah/5 HR)
	Fuses	Under-hood fuse/relay box		100 A, 80 A, 50 A, 40 A, 30 A, 20 A, 15 A, 10 A, 7.5 A
		Auxiliary under-hood fuse/relay box		20A, 7.5A
		Under-dash fuse/relay box		30A, 20A, 15A, 10 A, 7.5 A
		Auxiliary under-dash fuse holder		7.5 A
	Light bulbs	Headlight high beam		12V-60W (HB3)
		Headlight low beam		12V-35W (D2S)HID
		Fog light		12V-55W (H11)
		Front turn signal/parking lights		24/2.2 CP (two filaments/amber)
		Front side marker lights		3CP
		Side turn signal lights		LED
		Rear turn signal lights		21 W
		Brake/taillights		12 V-21/5 W (two filaments)
		Inner taillights		3CP
		Rear side marker light		2CP
		High-mount brake light		16W
		Back-up lights		21 W
		License plate light		3CPx2
		Ceiling light		8W
		Front individual map lights		5 W (4CP)
		Vanity mirror lights		2W
		Door courtesy lights		2CP
		Cargo area light		5W
		A/T gear position console light		1.4W
		Glove box light		1.4W
		Console box light		1.4W
		Gauge lights		LED (non-replaceable)
		Footwell light		LED
		Indicator lights		LED, 14V-0.56W, 14V-0.84W, 14V-0.91 W, 14V-1.12W

Scheme 1

Scheme 1: Body Specifications

Specifications: Other Acura RDX I facelift

Engine Electrical

Cylinder Head

Engine Block

Cooling System

Fuel and Emissions

Automatic Transmission and A/T Differential

Rear Differential

Steering

Suspension

Brakes

Air Conditioning

Engine Mechanical

Engine Cooling

Fuel Emissions

Automatic Transmission

Driveline/Axle

Body

Heating, Ventilation, and Air Conditioning

Body Electrical

Scheme 1

More articles — Specifications

Login / Signup

Enter the code

You have successfully logged in!
