Deployment Tool Check Acura RDX I рестайлинг

Deployment Tool Check

1. Connect the yellow clips to both the switch protector handles on the tool.
2. Then connect the red lead to the positive battery post and the black lead to the negative battery post.
3. Push the operation switch: The green light should come on, indicating that the tool is operating properly and is ready for use. If the red light stays on, the tool is faulty, and another one must be used for the procedure.
4. Disconnect the tool clips and connectors from the protector handles and the battery.

Scheme 302

Scheme 303

Scheme 304

1. Make sure the front wheels are aligned straight ahead.
2. Do the battery terminal disconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(/acura/rdx/i-2009-2012/remont/body-electrical/#battery) ), then wait at least 3 minutes before starting work.
3. Remove the driver's airbag (see «DRIVER'S AIRBAG REPLACEMENT»(/acura/rdx/i-2009-2012/remont/airbag/#srs-supplemental-restraint-system__drivers-airbag-replacement) ).
4. Disconnect the 20P connector (A) from the cable reel, then remove the steering wheel bolt (B).
5. Confirm that the front wheels point straight ahead, then remove the steering wheel with a steering wheel puller (see step 5 under «STEERING WHEEL REMOVAL»(/acura/rdx/i-2009-2012/remont/manual-power-steering/#steering) ). Do not tap on the steering wheel or steering column shaft when removing the steering wheel.
6. Remove the upper and lower column cover (see «COLUMN COVER REMOVAL/INSTALLATION»(/acura/rdx/i-2009-2012/remont/gauges-instrument-panels/#dashboard__column-cover-removalinstallation) ).
7. Disconnect the dashboard wire harness 4P connector (A) from the cable reel 4P connector (B), then disconnect the dashboard wire harness 20P connector (C) from the cable reel (D).
8. Release the upper lock tab (A) under the cable reel connector with a 90° hook shaped tool (B). Slide the tool below the cable reel connector just above the lock tab. Release the lower lock tab (C), and slide the cable reel off the column.

Scheme 305

Scheme 306

Scheme 307

Scheme 308

Scheme 309

1. Before installing the steering wheel, make sure the front wheels are aligned straight ahead.
2. If not already done, disconnect the negative cable from the battery, then wait at least 3 minutes.
3. Set the turn signal canceling sleeve (A) so that the projections (B) are aligned vertically.
4. Carefully install the cable reel (A) on the steering column shaft. Then connect 20P connector (B) to the cable reel, and connect the 4P connector (C) to the dashboard wire harness 4P connector (D).
5. Install the upper and lower column covers (see «COLUMN COVER REMOVAL/INSTALLATION»(/acura/rdx/i-2009-2012/remont/gauges-instrument-panels/#dashboard__column-cover-removalinstallation) ).
6. Before installing the steering wheel, make sure the front wheels are pointing ahead, then center the cable reel (A). Do this by first rotating the cable reel clockwise until it stops. Then rotate it counterclockwise (about three turns) until the arrow mark (B) on the cable reel label points straight up.
7. Position the two tabs (A) of the turn signal canceling sleeve (B) as shown in illustration, and install the steering wheel on to the steering column shaft, making sure the steering wheel hub (C) engages the pins (D) of the cable reel and tabs of the turn signal canceling sleeve. Do not tap on the steering wheel or steering column shaft when installing the steering wheel.
8. Install a new steering wheel bolt (A), and tighten it to the specified torque, then connect the 20P connector (B).
9. Install the driver's airbag (see «INSTALLATION»(/acura/rdx/i-2009-2012/remont/airbag/#srs-supplemental-restraint-system__installation) ).
10. Do the battery terminal reconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(/acura/rdx/i-2009-2012/remont/body-electrical/#battery) ).
11. Clear any DTCs with the HDS (see «HOW TO CLEAR DTCS IN THE HDS»(/acura/rdx/i-2009-2012/remont/airbag/#srs-supplemental-restraint-system__how-to-clear-dtcs-in-the) ).
12. After installing the cable reel, confirm proper system operation: Turn the ignition switch to ON (II), and check that the SRS indicator comes on for about 6 seconds and then go off. After the SRS indicator has turned off, turn the steering wheel fully left and right to confirm the SRS indicator does not come on. Make sure the horn and turn signal switches work properly. Make sure the steering wheel switches work properly.
13. After installation, check the steering wheel spoke angle. If the steering spoke angles to the right and left are not equal (steering wheel is not centered), correct the engagement of the wheel/column shaft splines.

Scheme 310

1. Do the battery terminal disconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(/acura/rdx/i-2009-2012/remont/body-electrical/#battery) ), then wait at least 3 minutes before starting work.
2. Remove the center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(/acura/rdx/i-2009-2012/remont/gauges-instrument-panels/#consoles__center-console-removalinstallation) ).
3. Disconnect the SRS unit connector A (28P), SRS unit connector B (28P), and SRS unit connector C (16P).
4. Remove the TORX bolts (D) using a TORX T30 bit, then pull out the SRS unit.

Scheme 311

1. Install the SRS unit (A) with a new TORX bolts (B) using a TORX T30 bit, then connect the connectors (C) to the SRS unit; push them into position until they click. NOTE: Be sure the SRS unit is sitting squarely against it's bracket before torquing the TORX bolts.
2. Do the battery terminal reconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(/acura/rdx/i-2009-2012/remont/body-electrical/#battery) ).
3. Do the ODS unit initialization (see «ODS UNIT INITIALIZATION»(/acura/rdx/i-2009-2012/remont/airbag/#srs-supplemental-restraint-system__ods-unit-initialization) ).
4. Check the operation of the ODS unit with the HDS (see «ODS UNIT OPERATION CHECK»(/acura/rdx/i-2009-2012/remont/airbag/#srs-supplemental-restraint-system) ).
5. Confirm proper SRS operation: Turn the ignition switch to ON (II), and check that the SRS indicator comes on for about 6 seconds and then go off.
6. Install the center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(/acura/rdx/i-2009-2012/remont/gauges-instrument-panels/#consoles__center-console-removalinstallation) ).

Scheme 312

1. Do the battery terminal disconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(/acura/rdx/i-2009-2012/remont/body-electrical/#battery) ), then wait at least 3 minutes before starting work.
2. Remove the front seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/rdx/i-2009-2012/remont/seats/#seats__front-seat-removalinstallation) ).
3. Remove the B-pillar lower trim (see «B-PILLAR UPPER/LOWER TRIM»(/acura/rdx/i-2009-2012/remont/exteriorinterior-trim/#interior-trim__b-pillar-upperlower-trim) ).
4. Disconnect the SRS wire harness 4P connector (A) from the side impact sensor (first).
5. Remove the TORX bolt (B) using a TORX T30 bit, then remove the side impact sensor (first) (C).

Scheme 313

1. Install the side impact sensor (first) (A) with a new TORX bolt (B) using a TORX T30 bit, then connect the SRS wire harness 4P connector (C) to the side impact sensor (first).
2. Do the battery terminal reconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(/acura/rdx/i-2009-2012/remont/body-electrical/#battery) ).
3. Clear any DTCs with the HDS (see «HOW TO CLEAR DTCS IN THE HDS»(/acura/rdx/i-2009-2012/remont/airbag/#srs-supplemental-restraint-system__how-to-clear-dtcs-in-the) ).
4. Confirm proper SRS operation: Turn the ignition switch to ON (II), and check that the SRS indicator comes on for about 6 seconds and then go off.
5. Reinstall all removed parts.

Scheme 314

1. Do the battery terminal disconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(/acura/rdx/i-2009-2012/remont/body-electrical/#battery) ), then wait at least 3 minutes before starting work.
2. Remove the rear seat and seat side bolster (see «SEAT SIDE BOLSTER»(/acura/rdx/i-2009-2012/remont/seats/#seats__seat-side-bolster) ).
3. Disconnect the SRS wire harness 2P connector (A) from the side impact sensor (second).
4. Remove the TORX bolt (B) using a TORX T30 bit, then remove the side impact sensor (second) (C).

Scheme 315

1. Install the side impact sensor (second) (A) with a new TORX bolt (B) using a TORX T30 bit, then connect SRS wire harness 2P connector (C) to the side impact sensor (second).
2. Do the battery terminal reconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(/acura/rdx/i-2009-2012/remont/body-electrical/#battery) ).
3. Clear any DTCs with the HDS (see «HOW TO CLEAR DTCS IN THE HDS»(/acura/rdx/i-2009-2012/remont/airbag/#srs-supplemental-restraint-system__how-to-clear-dtcs-in-the) ).
4. Confirm proper SRS operation: Turn the ignition switch to ON (II), and check that the SRS indicator comes on for about 6 seconds and then go off.
5. Reinstall all removed parts.

Scheme 316

1. Do the battery terminal disconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(/acura/rdx/i-2009-2012/remont/body-electrical/#battery) ), then wait at least 3 minutes before starting work.
2. Remove the front passenger's seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/rdx/i-2009-2012/remont/seats/#seats__front-seat-removalinstallation) ).
3. Disconnect the SRS wire harness 2P connector (A) from the roll rate sensor.
4. Remove the TORX bolt (B) using a TORX T30 bit, then remove the roll rate sensor (C).

Scheme 317

1. Install the roll rate sensor (A) with a new TORX bolt (B) using a TORX T30 bit, then connect the SRS wire harness 2P connector (C) to the roll rate sensor.
2. Do the battery terminal reconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(/acura/rdx/i-2009-2012/remont/body-electrical/#battery) ).
3. Clear any DTCs with the HDS (see «HOW TO CLEAR DTCS IN THE HDS»(/acura/rdx/i-2009-2012/remont/airbag/#srs-supplemental-restraint-system__how-to-clear-dtcs-in-the) ).
4. Confirm proper SRS operation: Turn the ignition switch to ON (II), and check that the SRS indicator comes on for about 6 seconds and then go off.
5. Reinstall all removed parts.

Note. Removal of the front passenger's weight sensors must be done according to Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ). The front passenger's weight sensors is part of the seat rail and must be replaced as an assembly.

Scheme 318

1. Do the battery terminal disconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(/acura/rdx/i-2009-2012/remont/body-electrical/#battery) ), then wait at least 3 minutes before starting work.
2. Remove the front passenger's seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/rdx/i-2009-2012/remont/seats/#seats__front-seat-removalinstallation) ).
3. Remove the seat cushion cover/pad from the seat cushion frame (see «FRONT SEAT CUSHION COVER/PAD REPLACEMENT»(/acura/rdx/i-2009-2012/remont/seats/#seats__front-seat-cushion-coverpad-replacement) ).
4. Remove the TORX nuts (A) attaching the seat track (B) to the weight sensors (C) using a TORX E18 socket.
5. Disconnect the sensor connectors (D) from the front passenger's weight sensor, then remove the front passenger's seat slide assembly (E) including all four front passenger's weight sensors.

Note. Make sure to install the harness wires so they are not pinched or interfering with other parts.

Scheme 319

Scheme 320

1. Install the new front passenger's seat slide assembly under the seat track.
2. When tightening the TORX nuts (A), begin with the (1) and tighten them in crisscross pattern in two or more steps.
3. Torque the TORX nuts in the sequence shown in illustration in two or more steps.
4. Reassemble the front passenger's seat cushion cover/pad (see «FRONT SEAT CUSHION COVER/PAD REPLACEMENT»(/acura/rdx/i-2009-2012/remont/seats/#seats__front-seat-cushion-coverpad-replacement) ).
5. Reinstall the front passenger's seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/rdx/i-2009-2012/remont/seats/#seats__front-seat-removalinstallation) ).
6. Do the battery terminal reconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(/acura/rdx/i-2009-2012/remont/body-electrical/#battery) ).
7. Clear any DTCs with the HDS (see «HOW TO CLEAR DTCS IN THE HDS»(/acura/rdx/i-2009-2012/remont/airbag/#srs-supplemental-restraint-system__how-to-clear-dtcs-in-the) ).
8. Do the front passenger's weight sensor initialization (see «FRONT PASSENGER'S WEIGHT SENSOR INITIALIZATION»(/acura/rdx/i-2009-2012/remont/airbag/#srs-supplemental-restraint-system__front-passengers-weight-sensor-initialization) ).
9. Confirm proper SRS operation: Turn the ignition switch to ON (II), and check that the SRS indicator comes on for about 6 seconds and then go off.

Scheme 321

1. Do the battery terminal disconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(/acura/rdx/i-2009-2012/remont/body-electrical/#battery) ), then wait at least 3 minutes before starting work.
2. Remove the passenger's seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/rdx/i-2009-2012/remont/seats/#seats__front-seat-removalinstallation) ).
3. Pull out the seat-back cover/pad as needed (see «FRONT SEAT-BACK COVER/PAD REPLACEMENT»(/acura/rdx/i-2009-2012/remont/seats/#seats__front-seat-back-coverpad-replacement) ).
4. Remove the cover (A), then disconnect the OPDS sensor connectors (B), and front passenger's seat wire harness 18P connector (C) from the ODS unit (D).
5. Remove the two bolts (E), and the ODS unit.

Scheme 322

1. Place the ODS unit (A) on the seat-back frame. Tighten the two bolts (B), and connect the OPDS sensor connectors (C) and front passenger's seat wire harness 18P connector (D) to the ODS unit. Reinstall the cover (E).
2. Install the seat-back cover/pad in the reverse order of removal (see «FRONT SEAT-BACK COVER/PAD REPLACEMENT»(/acura/rdx/i-2009-2012/remont/seats/#seats__front-seat-back-coverpad-replacement) ).
3. Install the front passenger's seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/rdx/i-2009-2012/remont/seats/#seats__front-seat-removalinstallation) )
4. Do the battery terminal reconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(/acura/rdx/i-2009-2012/remont/body-electrical/#battery) ).
5. Set the seat-back in the normal position, and make sure there is nothing on the front passenger's seat.
6. Clear any DTCs with the HDS (see «HOW TO CLEAR DTCS IN THE HDS»(/acura/rdx/i-2009-2012/remont/airbag/#srs-supplemental-restraint-system__how-to-clear-dtcs-in-the) ).
7. Do the ODS unit Initialization (see «ODS UNIT INITIALIZATION»(/acura/rdx/i-2009-2012/remont/airbag/#srs-supplemental-restraint-system__ods-unit-initialization) ).
8. Confirm proper SRS operation: Turn the ignition switch to ON (II), and check that the SRS indicator comes on for about 6 seconds and then go off.

Scheme 323

1. Do the battery terminal disconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(/acura/rdx/i-2009-2012/remont/body-electrical/#battery) ), then wait at least 3 minutes before starting work.
2. Remove the front bumper (see «FRONT BUMPER REMOVAL/INSTALLATION»(/acura/rdx/i-2009-2012/remont/exterior-body-panels/#bumpers__front-bumper-removalinstallation) ).
3. Disconnect the engine compartment wire harness 2P connector (A) from the front impact sensor.
4. Remove the TORX bolts (B) using a TORX T30 bit, then remove the front impact sensor (C).

Scheme 324

1. Install the front impact sensor (A) with new TORX bolts (B) using a TORX T30 bit, then connect the engine compartment wire harness 2P connector (C) to the front impact sensor.
2. Do the battery terminal reconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(/acura/rdx/i-2009-2012/remont/body-electrical/#battery) ).
3. Clear any DTCs with the HDS (see «HOW TO CLEAR DTCS IN THE HDS»(/acura/rdx/i-2009-2012/remont/airbag/#srs-supplemental-restraint-system__how-to-clear-dtcs-in-the) ).
4. Confirm proper SRS operation: Turn the ignition switch to ON (II), and check that the SRS indicator comes on for about 6 seconds and then go off.
5. Reinstall all removed parts.

Note. Removal of the driver's seat position sensor must be done according to Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ). Do not turn the ignition switch to ON (II), and do not connect the battery cable while removing the driver's seat position sensor.

Scheme 325

1. Raise the driver's seat all the way up.
2. Do the battery terminal disconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(/acura/rdx/i-2009-2012/remont/body-electrical/#battery) ), then wait at least 3 minutes before starting work.
3. Remove the upper rail inner cover (see step 4 under «FRONT SEAT REMOVAL/INSTALLATION»(/acura/rdx/i-2009-2012/remont/seats/#seats__front-seat-removalinstallation) ).
4. Disconnect the driver's seat wire harness 2P connector (A) from the driver's seat position sensor (B).
5. Remove the TORX bolt (C) using a TORX T30 bit and nut (D), then remove the driver's seat position sensor.

Note. Be sure to install the harness so it does not pinched or interferes with other parts. Do not turn the ignition switch to ON (II) and do not connect the battery cable while installing the driver's seat position sensor.

Scheme 326

1. Install the driver's seat position sensor with a new TORX bolts (A) and new nut (B).
2. Connect the driver's seat wire harness 2P connector (C) to the driver's seat position sensor (D).
3. Do the battery terminal reconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(/acura/rdx/i-2009-2012/remont/body-electrical/#battery) ).
4. Clear any DTCs with the HDS (see «HOW TO CLEAR DTCS IN THE HDS»(/acura/rdx/i-2009-2012/remont/airbag/#srs-supplemental-restraint-system__how-to-clear-dtcs-in-the) ).
5. Check the operation of the driver's seat position sensor with the HDS (see «DRIVER'S SEAT POSITION SENSOR OPERATION CHECK»(/acura/rdx/i-2009-2012/remont/airbag/#srs-supplemental-restraint-system__drivers-seat-position-sensor-operation-check) ).
6. Confirm proper SRS operation: Turn the ignition switch to ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off.
7. Reinstall all removed parts.
