Voice Control Switch Replacement Acura RDX I рестайлинг

Voice Control Switch Replacement

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ), and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) in the SRS information before doing repairs or service.

Scheme 182

Scheme 183

Scheme 184

1. Remove the driver's airbag assembly (see «DRIVER'S AIRBAG REPLACEMENT»(/acura/rdx/i-2009-2012/remont/airbag/#srs-supplemental-restraint-system__drivers-airbag-replacement) ).
2. Remove the steering wheel (see «STEERING WHEEL REMOVAL»(/acura/rdx/i-2009-2012/remont/manual-power-steering/#steering) ).
3. Remove the covers (A) and the screws (B) and the steering wheel rear cover (C) from the steering wheel (D).
4. Remove the screws from the steering wheel (A).
5. Disconnect the connectors (B) from the paddle shifter switches (C), then remove the steering wheel trim (D).
6. Remove the screws (A), then disconnect the connector (C).
7. Install the voice control switch in the reverse order of removal.

Scheme 185

Scheme 186

1. Remove the rear license trim (see «TAILGATE SPOILER TRIM REPLACEMENT»(/acura/rdx/i-2009-2012/remont/exteriorinterior-trim/#exterior-trim__tailgate-spoiler-trim-replacement) ).
2. Remove the inner taillight (see «TAILLIGHT REPLACEMENT»(/acura/rdx/i-2009-2012/remont/exterior-lights/#exterior-lights) ).
3. Inside the tailgate, disconnect the rearview camera 6P connector (A) and free it from its mounting clip. Remove grommet (B) from the tailgate, then push the rearview camera connector through the hole in the tailgate.
4. Remove screws (A), then remove the rearview camera (B).
5. Install in the reverse order of removal.
